GETTING STARTED GUIDE

Cisco Aironet 702W Series Access Points

1 About this Guide

2 Introduction to the Access Point

3 Safety Instructions

4 Unpacking

5 Configurations

6 Access Point Ports and Connectors

7 Configuring the Access Point

8 Mounting the Access Point

9 Deploying the Access Point on the Wireless Network

10 Troubleshooting

11 Access Point Specifications Data Sheet

12 Declarations of Conformity and Regulatory Information

13 Configuring DHCP Option 43 and DHCP Option 60

14 Obtaining Documentation and Submitting a Service Request

OL-31342-01, February 27, 2014

1 About this Guide

This Guide provides instructions on how to install and configure your Cisco Aironet 702W Series Access Point. The 702W Series Access Point is referred to as the 702W series or the access point in this document.

2 Introduction to the Access Point

The 702W series supports high-performing two spatial stream rates over a deployable distance with high reliability when serving clients. The 702W series provides high reliability and overall wireless performance.

The 702W series offers dual-band radios (2.4 GHz and 5 GHz) with integrated internal antennas. The access point supports full inter-operability with leading 802.11n clients.

The 702W series access point is available in the controller-based configuration and supports:

• Simultaneous dual-band (2.4 GHz/5 GHz) radios

• Integrated internal antennas only

Note The 702W series access points will have the model number AIR-CAP702W-x-K9, where the ‘x’ represents the

regulatory domain. Refer to “Regulatory Domains” section on page 5 for a list of supported regulatory domains.

The features of the 702W series are:

• Processing sub-systems (including CPUs and memory) and radio hardware which supports:

–

Unified

–

FlexConnect

–

Monitor-mode

–

VideoStream

–

Location (not available on autonomous or standalone models)

–

WIDS/WIPS (not available on autonomous or standalone models)

–

Security

–

Radio Resource Management (RRM) (not available on autonomous or standalone models)

–

Rogue detection (not available on autonomous or standalone models)

–

Management Frame Protection (MFP) (not available on autonomous or standalone models)

–

BandSelect (not available on autonomous or standalone models)

• The following processor features:

–

128 MB NAND flash size

–

1 MB NOR flash size

–

128 MB DDR2 memory bus, x32

• 2.4 GHz and 5 GHz 802.11n radios with the following features:

–

802.11n standard compliant

–

A-MPDU TX

–

HT Duplicate Mode

–

2TX x 2RX

–

2-spatial streams, 300 Mbps PHY rate

–

Maximal ratio combining (MRC)

–

Cyclic Shift Diversity (CSD)

–

MCS0-MCS15; Short or Long Guard Intervals

–

DFS for UNII-2 and UNII-2 Extended channels, including 0.5us radar pulse detection

3 Safety Instructions

Translated versions of the following safety warnings are provided in the translated safety warnings document that is shipped with your access point. The translated warnings are also in the Translated Safety Warnings for Cisco Aironet Access Points, which is available on Cisco.com.

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device.

SAVE THESE INSTRUCTIONS

Read the installation instructions before you connect the system to its power source.

Installation of the equipment must comply with local and national electrical codes.

This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 20A.

Statement 1005

Do not operate your wireless network device near unshielded blasting caps or in an explosive environment unless the device has been modified to be especially qualified for such use.

Statement 1071

Statement 1004

Statement 1074

Statement 245B

Warning

Caution The fasteners you use to mount an access point on a wall must be capable of maintaining a minimum pullout force

Caution This product and all interconnected equipment must be installed indoors within the same building, including the

Note Use only with listed ITE equipment.

In order to comply with FCC radio frequency (RF) exposure limits, antennas should be located at a minimum of 7.9 inches (20 cm) or more from the body of all persons.

Statement 332

of 20 lbs (9 kg) and must use a minimum of 2 holes on the mounting bracket.

associated LAN connections as defined by Environment A of the IEEE 802.af/at Standard.

4 Unpacking

To unpack the access point, follow these steps:

Step 1 Unpack and remove the access point and the accessory kit from the shipping box.

Step 2 Return any packing material to the shipping container and save it for future use.

Step 3 Verify that you have received the items listed below. If any item is missing or damaged, contact your Cisco representative

or reseller for instructions.

• The access point

• Wall mounting bracket

• Mounting screws

• Tamper resistant screw

• Mylar label for tamper resistant screw

5 Configurations

The 702W series access point contains two simultaneous dual-band radios, the 2.4 GHz and 5 GHz 802.11n MIMO radios, in a controller-based mode.

The 702W series access point configuration is AIR-CAP702W-x-K9—two 2.4 GHz/5 GHz dual-band radios, with two integrated dual-band antennas.

For information on the regulatory domains (shown as “x” in the model numbers) see “Regulatory Domains” section on page 5.

Internal Antennas

The 702W model access points are configured with two dual-band antennas (two 2.4 GHz and two 5 GHz). The two antennas, deployed inside the access point, are inside the top housing. The basic features are as follows:

• Dual-Band antennas.

• Antenna elements integrated into 702W access point top housing.

• Peak gains are approximately 2 dBi in the 2.4 GHz band and 4 dBi in the 5 GHz band.

Regulatory Domains

The 702W series supports the following regulatory domains (shown as “x” in the model numbers):

• -A, -C, -D, -E, -H, -I, -K, -N, -Q, -R, -S, -T, -UX, -Z

The 702W series models that support the universal regulatory domain, have the following model number format:

• AIR-AP702W-UXK9

Countries Supported

Click this URL to browse to a list of countries and regulatory domains supported by the 702W:

www.cisco.com/go/aironet/compliance

6 Access Point Ports and Connectors

The 702W model access points have integrated antennas and do not have external connectors on the top of the unit. In addition to the integrated antennas the 702W model access points has the following interfaces and connectors:

• LED

• Four LAN ports

• Uplink port and Console port

• Mode button

• DC power connector

• Kensington lock slot

Figure 1 Access Point 702W (Front View)

Figure 2 Access Point 702W (Top View)

Security Screw Hole

Figure 3 Access Point LED (Bottom View)

LED Indicator

The ports and connections on the rear of the access point are shown in .

From left to right, LAN Ports 1 to 4. The right most port

(LAN 4) is PoE-out.

Figure 4 Access Point Ports and Connections (Rear View)

Console port

Uplink (Ethernet WAN) port

The DC Power Connector for the access point is shown in Figure 5.

Key hole slot for mounting on the wall

bracket

Mode button

Figure 5 Access Point AC Power Connector (Side View)

DC Power Connector

Kensignton Lock Slot

7 Configuring the Access Point

This section describes how to connect the access point to a wireless LAN controller. Because the configuration process takes place on the controller, see the Cisco Wireless LAN Controller Configuration Guide for additional information. This guide is available on Cisco.com.

The Controller Discovery Process

The access point uses standard Control and Provisioning of Wireless Access Points Protocol (CAPWAP) to communicate between the controller and other wireless access points on the network. CAPWAP is a standard, interoperable protocol which enables an access controller to manage a collection of wireless termination points. The discovery process using CAPWAP is identical to the Lightweight Access Point Protocol (LWAPP) used with previous Cisco Aironet access points. LWAPP-enabled access points are compatible with CAPWAP, and conversion to a CAPWAP controller is seamless. Deployments can combine CAPWAP and LWAPP software on the controllers.

Customers who have Layer 2 deployments should note that CAPWAP is not supported on Layer 2 as the CAPWAP packets are routed through Layer 3 only.

In a CAPWAP environment, a wireless access point discovers a controller by using CAPWAP discovery mechanisms and then sends it a CAPWAP join request. The controller sends the access point a CAPWAP join response allowing the access point to join the controller. When the access point joins the controller, the controller manages its configuration, firmware, control transactions, and data transactions.

Note For additional information about the discovery process and CAPWAP, see the Cisco Wireless LAN Controller Software

Configuration Guide. This document is available on Cisco.com.

Note CAPWAP support is provided in controller software release 5.2 or later. However, your controller must be running

release 8.0.x.x or later to support 702W series access points.

Note Make sure that the controller is set to the current time. If the controller is set to a time that has already occurred, the

access point might not join the controller because its certificate may not be valid for that time.

Access points must discovered a controller before they can become an active part of the network. The access point supports these controller discovery processes:

• Layer 3 CAPWAP discovery—The access point performs a local broadcast (255.255.255.255) discovery request to find any contollers on the same subnet/vlan. The request can be forwarded to other networks by the IP helper featuer that is present on switches and router.

• Locally stored controller IP address discovery—If the access point was previously joined to a controller, the IP addresses of the primary, secondary, and tertiary controllers are stored in the access point’s non-volatile memory. This process of storing controller IP addresses on an access point for later deployment is called priming the access point. For more information about priming, see the “Performing a Pre-Installation Configuration” section on page 11.

• DHCP server discovery—This feature uses DHCP option 43 to provide controller IP addresses to the access points. Cisco switches support a DHCP server option that is typically used for this capability. For more information about DHCP option 43, see the “Configuring DHCP Option 43 and DHCP Option 60” section on page 29.

• DNS discovery—The access point can discover controllers through your domain name server (DNS). For the access point to do so, you must configure your DNS to return controller IP addresses in response to CISCO-CAPWAP-CONTROLLER.localdomain, where localdomain is the access point domain name. Configuring the CISCO-CAPWAP-CONTROLLER provides backwards compatibility in an existing customer deployment. When an access point receives an IP address and DNS information from a DHCP server, it contacts the DNS to resolve CISCO-CAPWAP-CONTROLLER.localdomain. When the DNS sends a list of controller IP addresses, the access point sends discovery requests to the controllers.

Preparing the Access Point

Before you mount and deploy your access point, we recommend that you perform a site survey (or use the site planning tool) to determine the best location to install your access point.

You should have the following information about your wireless network available:

• Access point locations

• Access point mounting options (Wall mount only)

• Access point power options: power supplied by the recommended external power supply (with power adapter

AIR-PWR-C=), a DC power supply, PoE from a network device (802.3af/at), or a PoE power injector/hub (the Cisco-recommended injector is the AIR-PWRINJ4=), usually located in a wiring closet.

Note PoE-Out is available on via LAN port 4

Table 1 Access Point Power Sources and PoE-Out Levels

Power Input Source Maximum PoE-Out Power

802.3af / AIR-PWRINJ5 No power available for the PoE-out port

802.3at/AIR-PWRINJ4 Class 2, 6.49W (7W with cable losses)

AIR-PWR-C Class 0, 12.95W (15.4W with cable losses)
