Specifications
®
Cat
TH514
Telehandler
Engine
Model Cat® C4 .4 DITAAC
Gross Power 74.5 kW/101 hp
Ma ximum Torque 410 Nm/1400 rpm
Bore 105 mm (4 .13 in )
Stroke 127 mm (5 in)
Displacement 4.4 L (268.5 in
Weights
Operating Weight with
Carriage & Forks 10 760 kg (23,722 lb)
Operating Specifications
Rated Load Capacit y 4990 kg (11,000 lb)
Maximum Lift Height
Stabilizers Up 13.7 m (45 ft)
Stabilizers Down 13.7 m (45 ft)
Maximum Forward Reach 9.2 m (30 ft 3 in)
Top Travel Speed 32 kph (20 mph)
Load at Max Height
Stabilizers Up 1814 kg (4,000 lb)
Stabilizers Down 3175 kg (7,000 lb)
Load at Max Reach
Stabilizers Up 454 kg (1,000 lb)
Stabilizers Down 1361 kg (3,000 lb)
Outside Turning Radius Over Tires 3.92
m (12 ft 10 in)
Outside Turning Radius Over Forks 5.57
m (18 ft 3 in)
Drawbar Pull 74.5 kW 8972 kg (19,783 lb)
Service Refill Capacities
Fuel Tank 150 L (39.63 gal)
Hydraulic Tank 90 L (23.78 gal)
Hydraulic System
Maximum System Pressure 250 bar (3,626 PSI)
Maximum Pump Flow 150 L/min (39.63 gal/min)
Pump Type Variable displacement
load sensing axial
piston pump
3
)
Auxiliary Hydraulic Supply
Intermittent 80 L /min (21.13 gal/min)
Continuous 6 0 L/min (15.85 gal/min)
Transmission Speeds
Forward
1 7 kph (4.4 mph)
2 12 kph (7. 5 mph)
3 21 kph (13.1 mph)
4 32 kph (19.9 mph)
Reverse
1 7 kph (4.4 mph)
2 12 kph (7. 5 mph)
3 21 kph (13.1 mph)
Boom Performance
Boom Up 17.0 Seconds
Boom Down 10.0 Seconds
Tel e In 20.0 Seconds
Tel e Out 17.5 Seconds
Crowd Forward (dump) 4.0 Seconds
Crowd Backward 3.0 Seconds
Combined
Up and Out 28.0 Seconds
Down and In 19.0 Seconds
Bucket Breakout Force to ISO 8313 9687
kg (21,357 lb)
Boom Breakout Force 6424 kg (14,16 3 lb)
Tires
Standard 14.00-24 16PR TG-02
Brakes
Service Brakes Servo assisted on front axle
Parking Brakes Mechanical on front axle
Sound
Operator Sound 78 dB(A)
Exterior Sound (74.5 kW Engine) 106 dB(A)
Page 2
TH514 Telehandler
Dimensions
All dimensions are approximate.
Load Chart and Dimensions
TH514 Stabilizers Up
14.6 m (48 ft)
13.4 m (44 ft)
12.1 m (40 ft)
10.9 m (36 ft)
9.7 m (32 ft)
8.5 m (28 ft)
7.3 m (24 ft)
6.1 m (20 ft)
4.9 m (16 ft)
3.7 m (12 ft)
2.4 m (8 ft)
1.2 m (4 ft)
0 m (0 ft)
-1.2 m (-4 ft)
36 ft
(10.9 m)
10°
(9.7 m)
20°
0°
32 ft
1814 kg (4,000 lb)
40°
30°
907 kg (2,000 lb)
454 kg (1,000 lb)
24 ft
28 ft
(7.3 m)
(8.5 m)
50°
1361 kg (3,000 lb)
16 ft
20 ft
(4.9 m)
(6.1 m)
60°
2268 kg (5,000 lb)
3.7 m
(12 ft)
88 0 mm (3 4.65 i n)
20 78 mm (8 1.81 in)
24 40 mm ( 96.0 6 in)
70°
D
C
B
4082 kg
(9,000 lb)
3175 kg (7,000 lb)
4990 kg (11,000 lb)
24 ”
2.4 m
1.2 m
0 m
(8 ft)
(4 ft)
(0 ft)
26 30 mm
(10 3.54 i n)
197 9 mm
(7 7.91 i n)
40 1 mm
(15. 79 in)
122 5 mm
(48.23 in)
32 00 mm (12 5.98 i n)
50 91 mm (2 00. 43 in)
65 20 mm (2 56. 69 in)
TH514 Stabilizers Down
14.6 m (48 ft)
13.4 m (44 ft)
12.1 m (40 ft)
10.9 m (36 ft)
9.7 m (32 ft)
A
8.5 m (28 ft)
7.3 m (24 ft)
6.1 m (20 ft)
4.9 m (16 ft)
3.7 m (12 ft)
2.4 m (8 ft)
1.2 m (4 ft)
0 m (0 ft)
-1.2 m (-4 ft)
36 ft
(10.9 m)
-2.6°
(9.7 m)
20°
10°
32 ft
40°
30°
1361 kg (3,000 lb)
24 ft
28 ft
(7.3 m)
(8.5 m)
3175 kg (7,000 lb)
50°
3175 kg (7,000 lb)
2268 kg (5,000 lb)
16 ft
20 ft
(4.9 m)
(6.1 m)
70°
60°
4990 kg (11,000 lb)
4082 kg (9,000 lb)
3.7 m
2.4 m
1.2 m
(12 ft)
(8 ft)
(4 ft)
(0 ft)
D
C
B
A
24 ”
0 m
IMPORTANT
Rated lift capacities shown are with machine
equipped with carriage and pallet forks. The
machine must be level on a firm surface with
undamaged, properly inflated tires as specified
by the manufacturer. Machine specifications
and stabilit y are based on rated lif t capacities
at speci fic boom angles and boom lengths.
(If specifications are critical, t he proposed
application should be discussed with your dealer.)
For m ore compl ete inf ormati on on Cat pr oducts , dealer se rvices , and indu stry s olutio ns, vis it us on the w eb at ww w.cat .com
© 20 10 Caterpillar
All rights reserved .
Prin ted in U. S.A .
Mate rials and s pecifica tions ar e subject t o change wi thou t notice . Featur ed machine s in phot os may inclu de addit ional
equip ment. S ee your Ca t dealer fo r availabl e option s.
CAT, CAT ERPI LLA R, SA FET Y.CAT.C OM, the ir respec tive log os, “Ca terpil lar Yellow ” and the PO WER E DGE trad e dress,
as well a s corpor ate and pro duct iden tit y used here in, are tr ademark s of Cate rpillar a nd may not be u sed wit hout per missio n.
DO NOT exceed rated lift capacity loads, as unstable
and dangerous machine conditions will result.
DO NOT tip the machine forward to
determine the allowable load.
Use onl y JLG approved attachments w ith proper
material handler model/attachment load capacity
charts displayed in the operator’s cab. OSHA
requires all rough terrain forklift operators be
trained according to OSHA 2 9 CFR 1910.178 (1).
Due to continuous product improvements, machine
specifications and/or equipment changes may
be made without prior notification. This machine
meets or exceeds ANSI/ITSDF B56.6-2005 as
originally manufactured for intended applications.
