Casio SF-5780, SF-5580, SF-5980 User Manual 2
SF-5580
SF-5780
SF-5980
Owner’s Manual
Q
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THIS UNIT IN
THE U.S.A. (not applicable to other areas).
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Proper connectors must be used for connection to host computer and/or
peripherals in order to meet FCC emission limits.
Connector SB-62 ........ SF Unit to SF Unit
• CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or
loss resulting from the use of this manual.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or
claims by third parties which may arise through the use of the Digital Diary.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or
loss caused by deletion of data as a result of malfunction, repairs, or battery
replacement. Be sure to back up all important data on other media to protect
against its loss.
NOTICE
Before using the Digital Diary for the first time...
Use the following procedure to load battereis and reset the unit before using it for the
first time.
1. Remove the screw that holds the main battery compartment cover in place and
open the cover.
RESET
2. Load two new batteries into the battery compartment.
• Make sure that the positive (+) and negative (–) ends are facing correctly.
RESET
3. Replace the battery compartment cover and secure it with its screw.
• Take care that you do not overtighten the screw.
4. Pull the insulating tape from the back-up battery by pulling in the direction
indicated by the arrow printed on the tape.
RESET
– 1 –
– 2 –
5. Press the RESET button on the back of the Digital Diary with a thin, pointed
object.
RESET
button
RESET
6. Press Y.
7. Press OK to reset the Digital Diary or ESC to abort.
• At this time the message “SET TIME!” appears.
• After about two seconds, the Home Time screen appears.
8. Press FUNC, select “Time set”, and then use the procedure on page 18 to set the
Home Time.
• If you turn power off without setting the Home Time, the “SET TIME!” message
appears the next time you turn power on. The Digital Diary will not operate
properly until you set the Home Time.
Important!
• Turn on the unit at least once a month to check the current condition of the
batteries.
■ Turning Power On and Off
Press ON/OFF to turn power on and off.
Important!
• If nothing appears on the display when you turn on power, it means that the main
batteries are low. Replace the batteries (page 13) and press the RESET button
to resume normal operation.
• Be sure to press the RESET button (page 2) after loading main batteries for the
first time or if the previous set of batteries went dead.
– 3 –
Contents
Before using the Digital Diary for the first time... ............... 1
Turning Power On and Off ...........................................................3
Before using the Digital Diary... ............................................ 8
Introduction ................................................................................... 8
Write down important data somewhere! .................................... 8
Important Precautions ................................................................. 8
Getting Started ....................................................................... 9
General Guide ............................................................................... 9
Display .........................................................................................10
All-Reset ...................................................................................... 11
Power Supply ..............................................................................12
Turning Power On and Off .........................................................15
Function Menus .......................................................................... 16
System Language .......................................................................16
Display Contrast ......................................................................... 16
Key Input Sound ......................................................................... 16
Destructive Backspace .............................................................. 17
Home Time Mode ................................................................. 18
Using the Daily Alarm ................................................................. 19
World Time Mode ................................................................. 21
Zone Information Screen ........................................................... 22
Data Bank Operations.......................................................... 24
Inputting Text ..............................................................................24
Inputting Dates and Times .........................................................25
Display Formats .......................................................................... 26
Telephone Directory Mode .................................................. 27
Record Summary ........................................................................28
Memo Mode .......................................................................... 29
Record Summary ........................................................................29
Calendar Mode ..................................................................... 30
Maneuvering Around Calendars ............................................... 30
Appointment Markers ................................................................. 31
Highlighting Calendar Dates ..................................................... 32
Working Day Count ....................................................................33
Weekly Schedule Screen ...........................................................33
Schedule Keeper .................................................................. 34
Maneuvering Around Schedule Keeper Dates ......................... 34
Schedule Alarms ......................................................................... 36
How Schedule Keeper Data is Sorted ....................................... 36
Schedule Type Labels and Icons .............................................. 36
Daily Schedule Screen ............................................................... 38
Reminder Mode .................................................................... 39
Reminder Alarms ........................................................................ 40
To Do Mode ........................................................................... 41
Record Summary ........................................................................42
How To Do Data is Sorted .......................................................... 43
Priority Icons ............................................................................... 43
– 5 –
– 6 –
Expense Manager Mode ...................................................... 44
Expense Type Labels and Icons................................................45
Payment Type Labels ................................................................. 46
Exchange Rate ............................................................................46
Periodic Expense Report ........................................................... 47
Record Summary ........................................................................47
Searching for Data ............................................................... 48
Scroll Search ............................................................................... 48
Initial Character Search ............................................................. 48
Wild Card Search ........................................................................ 49
Date Search .................................................................................49
Editing Data .......................................................................... 50
Deleting Data ........................................................................ 51
Deleting a Single Data Item........................................................ 51
Deleting All Data Items In a Mode ............................................. 51
Deleting Marked Data Items Only .............................................. 52
Deleting All Data Items In Specific Modes ............................... 53
Secret Function .................................................................... 54
Conversion Modes ............................................................... 56
Metric Conversions .................................................................... 57
Currency Conversions ............................................................... 57
Game Modes ......................................................................... 59
Poker Game ................................................................................. 59
Blackjack Game .......................................................................... 61
Calculator Mode ................................................................... 63
Data Communications ......................................................... 66
Setting Up for Data Communications .......................................66
Sending Data ............................................................................... 68
Sending All Data Items In a Mode ............................................. 69
Technical Appendix ............................................................. 71
Memory Capacity ........................................................................71
How the Digital Diary sorts data ............................................... 72
Error Messages ........................................................................... 73
Message Table ............................................................................ 73
Specifications ............................................................................. 74
– 7 –
Before using the Digital Diary...
Introduction
Congratulations on your selection of CASIO’s new SF-5580/SF-5780/SF-5980
(referred to as Digital Diary in this manual). Please keep your manual and all
information handy for future reference.
Write down important data somewhere!
The memory of your Digital Diary holds information only while power is supplied by
the batteries. Always write down important data somewhere.
Important!
• Load batteries (page 1) and perform the all-reset operation described on page
11 before using the Digital Diary for the first time.
Important Precautions
• Never expose the Digital Diary to fire.
• Avoid temperature extremes. Do not locate the Digital Diary in direct sunlight,
near a window, near a heater, etc.
• In very low temperatures display response may slow down or fail entirely. This
condition is temporary and operation should resume under normal temperatures.
• Avoid areas subject to excessive moisture, dirt, and dust.
• Avoid dropping the Digital Diary and otherwise subjecting it to strong impact.
• Never bend or twist the Digital Diary.
• Never try to take the Digital Diary apart.
• Do not use a pen, pencil, or other sharp object to press keys.
• To clean the exterior of the Digital Diary, wipe it with a soft cloth dampened in a
weak solution of a mild neutral detergent and water. Be sure to wring out any
excess moisture from the cloth before wiping off the Digital Diary. Never use
benzene, thinner, or any other volatile agent to clean the unit. Doing so can
remove the figures printed on the case or otherwise damage the case finish.
• The contents of this manual are subject to change without notice.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or claims
by third parties that may arise from the use of this product.
• Note that once the backlight is lit, it will stay on as long as you continue to operate
the calculator.
Leaving the backlight on for long periods greatly reduces battery life!
Press the LIGHT key to manually turn off the backlight.
• Be sure to use alkaline batteries only to power this Digital Diary.
Getting Started
Make sure you read this part of the manual.
General Guide
Display
Mode key
Memory keys
10-key pad
Operator keys
ON/OFF key
Mode keys
Light key
ESC key
Function key
Display Change
key
Cursor keys
Scroll/Search
keys
Alpha keyboard
– 9 –
– 10 –
■ Display
When lighting is dim, you can turn on an EL (electro-luminescent) backlight for easier
viewing.
To turn on the EL backlight
Pressing the LIGHT key turns on the backlight of the display. If you do not perform
any operation for about 15 seconds, the backlight automatically turns off. However,
note that once the backlight is lit, it will stay on as long as you continue to operate the
Digital Diary.
Leaving the backlight on for long periods greatly reduces battery life!
Press the LIGHT key again to manually turn off the backlight when you are finished
using it.
Display Indicators
K
SHIFT
CAPS
CODE
NEW/EDIT
w
INDEX
~
DATA
SNOOZE
f
DAILY
KEY
C
L
2134567890q
1 Telephone Directory Mode
2 Memo Mode
3 To Do Mode
4 Reminder Mode
5 Schedule Keeper Mode
6 Calendar Mode
7 Expense Manager Mode
8 Home Time/World Time Mode
9 Calculator Mode
0 Conversion Modes
q Game Modes
w Indicates data above
e SHIFT key operation
r Upper-case input
t CODE key operation
y NEW/EDIT screen
u Index display
i Data display
o Snooze feature activated
p Daily alarm on
a Key sound on
s Memory locked
d Low battery warning
f Indicates data below
■ All-Reset
Use the following procedure to reset the unit to its initial settings.
Important!
• Do not use a very sharp pencil or other object to press the RESET button.
• Be sure to reset the unit before using it for the first time.
• Perform the reset operation only after main batteries and back-up battery are
correctly installed.
• Be sure to press the RESET button (page 2) after loading main batteries for the
first time or if the previous set of batteries went dead.
To start the all-reset operation
1. Turn power off.
2. Press the RESET button on the back of the Digital Diary with a thin, pointed
object.
3. Now you should press Y for “yes” or N for “no” in accordance with the conditions
described below.
When to press Y for “yes”
• When this is the first time you are using the unit.
• When you want to reset the unit and clear all data and settings.
• When you are resetting the unit after a data error (page 73).
1. Press Y in response to the message that appears on the display when you start
the all-reset operation.
2. Press OK to reset the Digital Diary or ESC to abort.
• At this time the message “SET TIME!” appears.
• After about two seconds, the Home Time screen appears.
– 11 –
– 12 –
3. Press FUNC, select “Time set”, and then use the procedure on page 18 to set the
Home Time.
• If you turn power off without setting the Home Time, the “SET TIME!” message
appears the next time you turn power on. The Digital Diary will not operate
properly until you set the Home Time.
When to press N for “no”
• After replacing the main batteries.
• When you are not resetting the unit to clear all data and settings.
• When you are not resetting the unit after a data error (page 73).
1. Press N in response to the message that appears on the display when you start
the all-reset operation.
• At this time the message “SET TIME!” appears.
• After about two seconds, the Home Time screen appears.
2. Press FUNC, select “Time set”, and then use the procedure on page 18 to set the
Home Time.
• If you turn power off without setting the Home Time, the “SET TIME!” message
appears the next time you turn power on. The Digital Diary will not operate
properly until you set the Home Time.
• Following are the initial settings of the unit after you perform the all-reset
operation.
Home Time: New York
World Time: London
Daily Alarm: 12:00 AM
Sound: Daily alarm — OFF
Messages: English
Character input: CAPS — OFF
JAN 1, 1996 (MON)
12:00 AM
12-hour format
Key — ON
■ Power Supply
Your Digital Diary is powered by two AAA-size batteries, and its memory is protected
by a single CR2032 lithium battery.
Low Battery Warning
Failure of anything to appear on the display after you turn on power or appearance
of the low battery message, “MAIN BATTERIES WEAK! REPLACE THEM! UNIT
WILL NOT TURN ON AGAIN!” (followed by the display turning off in about 10
seconds) normally indicates that main battery power is low.
Note, however, that pressing the RESET button on the back of the unit and then
performing steps 1 and 2 of the procedure under “When to press N for “no”” above
can sometimes restore normal operation. When the low battery message appears
on the display even if you perform these steps, it means you should replace the main
batteries as soon as possible.
Note
• Take care that you do not make a mistake and delete memory contents at this
time.
Important!
• Replace batteries only when low battery power is indicated by failure of the Digital
Diary to turn on when you press the ON key. Do not replace batteries as long as
the Digital Diary turns on normally when you press the ON key.
• There is not low battery warning for the back-up battery. Be sure to replace the
back-up battery once every 5 years.
• Be sure you keep a separate copy of all important data that you store in the Digital
Diary.
Battery Precautions
Incorrectly using batteries can cause them to burst or leak, possibly damaging the
interior of the Digital Diary. Note the following precautions.
• Be sure to use alkaline batteries only to power this Digital Diary.
• Be sure that the positive (+) side of each battery is facing in the correct directions.
• Never mix batteries of different types.
• Never mix old batteries and new ones.
• Do not expose batteries to direct heat, let them become shorted, or try to take
them apart.
• Never leave dead batteries in the battery compartment.
• Remove batteries if you do not plan to use the unit for a long time.
• Replace batteries at least once every five years, no matter how much you use the
unit during that period.
• Never try to recharge the batteries that come with the unit.
• Should a battery leak, clean out the battery compartment of the unit immediately,
taking care to avoid letting battery fluid come into direct contact with your skin.
Keep batteries out of the reach of small children. If swallowed, consult with a
physician immediately.
– 13 –
– 14 –
To replace the main batteries
Important!
• Do not remove the main batteries from the Digital Diary while the back-up battery
is removed.
• Be sure to replace both batteries with two new ones. Do not mix an old battery
with a new one.
• Be sure to press the RESET button (page 2) after loading main batteries for the
first time or if the previous set of batteries went dead.
• Replace batteries only when low battery power is indicated by failure of the Digital
Diary to turn on when you press the ON key. Do not replace batteries as long as
the Digital Diary turns on normally when you press the ON key.
1. Press OFF to turn power off.
2. Remove the screw that holds the battery compartment cover in place and open
the cover.
RESET
3. Remove both old batteries and replace them with new ones.
• Make sure that the positive (+) and negative (–) ends are facing correctly.
4. Replace the battery compartment cover and secure it with its screw.
• Take care that you do not overtighten the screw.
5. Press the RESET button.
• This causes the message “ARE YOU USING A NEW UNIT FOR THE FIRST
TIME (Y/N)?” to appear. Be sure to press N in response to this message (pressing
Y will delete all data in memory). Next, continue with the procedures in the section
title “All Reset” on page 11.
To replace the back-up battery
Important!
• Do not remove the back-up battery from the Digital Diary while the main batteries
are removed.
• Be sure to replace the back-up battery at least once every 5 years. Otherwise,
you run the risk of losing data stored in memory.
1. Press OFF to turn power off.
2. Remove the screw that holds the back-up battery compartment cover in place
and open the cover.
RESET
3. Insert a thin, pointed object into (A) and remove the old battery.
RESET
(A)
4. Load a new battery into the compartment, making sure that its positive side is
facing up (so you can see it).
5. Replace the battery compartment cover and secure it with its screw.
• Take care that you do not overtighten the screw.
■ Turning Power On and Off
Press ON/OFF to turn power on and off.
Important!
• If nothing appears on the display when you turn on power, it means that the main
batteries are low. Replace the batteries (page 13) and press the RESET button
to resume normal operation.
Auto Power Off Function
The unit automatically turns power off if you do not press any key for about three
minutes. Any alarms you set still sound, even if power is turned off.
– 15 –
– 16 –
■ Function Menus
• Pressing FUNC displays a function menu, whose contents differs depending on
the mode.
• Pressing SHIFT FUNC displays a function menu of general system settings
(system function menu).
• Input the number of the left of the function you want to use to select it.
• To exit from a function menu, press ESC.
■ System Language
Your Digital Diary is capable of producing messages in any one of three languages
(English, French, Spanish).
To select the system language
1. Press SHIFT FUNC and then select “Language”.
2. Press the number key that corresponds to the language that you want to use.
• To select “English”, you would press 1.
• The system language automatically changes to English whenever you perform
the RESET operation (page 11).
Note
• In this manual, all display messages are shown in English.
■ Display Contrast
Use the following procedure to make the figures on the display darker or lighter.
To adjust display contrast
1. Press SHIFT FUNC and then select “Display contrast”.
2. Use H and J to make display images darker or lighter.
3. Press OK to quit.
■ Key Input Sound
When the key input sound is turned on, your Digital Diary emits a beep each time
you press one of its keys.
To turn key input sound on and off
1. Press SHIFT FUNC and then select “Key tone”.
Currently selected setting
2. Use H and J to turn the key input sound on and off.
KEY
• The
3. Press OK to quit.
indicator is on the display while the key input sound is on.
■ Destructive Backspace
When destructive backspace is turned on, the character at the cursor position is
deleted when you press the BS key.
To turn destructive backspace on and off
1. Press SHIFT FUNC and then select “Backspace”.
2. Use H and J to turn destructive backspace on and off.
3. Press OK to quit.
– 17 –
Home Time Mode
The time kept in the Home Time Mode is used for control of various time based
functions.
To enter the Home Time Mode
Press the HOME/WORLD key once.
To set your Home Time zone
1. In the Home Time Mode, press FUNC and then select “Time zone change”.
2. Use K and L to scroll through the city names.
• See page 23 for a complete list of time zones.
3. When the city you want is displayed, press OK.
• You can change your Home Time zone later if you like. When you do, only the
zone changes, without affecting the time or date setting.
To set the time and date
1. In the Home Time Mode, press FUNC and then select “Time set”.
• The hour setting flashes on the display.
• Use H and J to move the flashing selection around the display.
2. Input numbers for the year, month, day, hour, and minutes.
• Input the year as four digits in the range of 1901 through 2099.
• Use 12-hour or 24-hour format depending on the Home Time format (page 19).
• All illegal input is ignored.
3. With 12-hour time format, press A for AM or P for PM.
4. Press OK to quit.
• Pressing OK resets the seconds count to “00”.
To switch between standard time and daylight saving time
In the Home Time Mode, press FUNC and then select “Daylight savings”.
• This toggles to the opposite setting and returns to the Home Time Mode screen.
indicates daylight saving time.
To switch between 12-hour and 24-hour timekeeping
In the Home Time Mode, press FUNC and then select “12/24 hours”.
• This toggles to the opposite setting and returns to the Home Time Mode screen.
The AM/PM indicator indicates 12-hour timekeeping.
• The time format you select is applied for all modes.
To select the date format
1. In the Home Time Mode, press FUNC and then select “Date format”.
2. Select the date format that you want to use.
• The following shows and example of each format
[1] Month/Date/Year: JAN 1, 1996 (MON)
[2] Date/Month/Year: 1 JAN, 1996 (MON)
[3] Year/Month/Date: 1996/1/1 (MON)
• The date format you select is applied in all modes.
■ Using the Daily Alarm
The Daily Alarm, it sounds at the same time every day for 20 seconds and the Daily
Alarm screen appears.
To change the Daily Alarm time
1. In the Home Time Mode, press FUNC and then select “Daily alarm set”.
• The hour setting flashes on the display.
• Use H and J to move the flashing.
2. Input numbers for the hour and minutes.
• All illegal input is ignored.
3. For 12-hour time format, press A for AM or P for PM.
4. Press OK to quit.
• Pressing OK automatically turns on the alarm.
To turn the Daily Alarm on and off
1. In the Home Time Mode, press FUNC and then select “Daily alarm sound”.
2. Use H and Jto turn the Daily Alarm on and off.
3. Press OK.
– 19 –
– 20 –
How the Daily Alarm works
The daily alarm sounds at the alarm time you set. A snooze feature sounds the alarm
more than once, helping to make sure you don’t oversleep or miss an appointment.
About the snooze feature
The snooze feature activates (and the SNOOZE indicator appears on the display) if
you do not press any key or if you press the SPACE key after the Daily Alarm starts
to sound.
• If you do not press any key, the alarm stops after 20 seconds, and sounds two
more times every 10 minutes. In this case (you do not press any key), the alarm
sounds a total of three times and then stops.
• Pressing the SPACE key while an alarm is sounding stops the alarm and resets
the snooze feature for three more alarm operations spaced at 10-minute
intervals.
• Pressing any key besides the SPACE key while an alarm is sounding stops the
alarm and cancels the snooze feature, so the alarm does not sound again until
an alarm time is reached.
Note
Note the following important points when you are using the Daily Alarm.
• If the alarm time is reached during data communications, the alarm does not
sound until you complete the communications procedure.
• The alarm may fail to sound if battery power is too low.
World Time Mode
With World Time you can view the current time in time zones around the world.
To enter the World Time Mode
Press the HOME/WORLD key twice. From the Home Time Mode, press HOME/
WORLD only once.
Hours different from
Home Time zone
Current World Time
setting
• Every time you press HOME/WORLD, the Digital Diary switches between the
Home Time Mode and World Time Mode.
To scroll through World Time Mode zones
In the World Time Mode, use K and L to scroll from zone-to-zone.
• Hold down either button to scroll at high speed.
To change a World Time zone’s settings
1. In the World Time Mode, display the zone you want.
2. Press FUNC.
3. Switch between 12/24 hour (page 19), switch between standard and daylight
saving time (page 19), and set the date format (page 19).
• Timekeeping format and date format settings are applied to all World Time zones
and to the Home Time Mode.
• The standard/daylight saving time setting is applied to the currently selected time
zone only.
• See page 22 for details on using the Zone Change function menu item.
– 21 –
– 22 –
■ Zone Information Screen
The zone information screen shows the name of a major city and the time difference
from your Home Time for each World Time zone.
To display the zone information screen
In either the World Time Mode or Home Time Mode, press DISP CHNG to change
to the zone information screen for the displayed zone.
Time difference from your Home Time zone
City in zone
• To exit the zone information screen, press DISP CHNG, ESC, or HOME/
WORLD.
To change zone information screen content
Note
If you change the city name of the zone information screen, the name you input will
also appear on the Home Time and World Time screens.
1. In the World Time Mode, display the zone you want.
2. Press FUNC and select “Zone change”.
3. Change the contents of the screen.
• Use H and J to move the cursor.
• You can input up to 13 characters for the city name.
4. After you make changes, press OK.
• At this time the message “Are you sure (Y/N)?” appears.
5. Press Y to store your changes or N to abort.
