Casio CTK6000 User Manual

Download

CTK-6000/WK-6500/CTK-7000/WK-7500/AT-

3/AT-5

MIDI Implementation

CASIO COMPUTER CO., LTD.

Contents

I MIDI Message Overview 7

1 Product Conﬁguration as a MIDI Device 7

1.1 System Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.2 Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 Sound Generator Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2 Timbre Type Speciﬁc Operation 9

3 Controlling Send/Receive of MIDI Messages in Each Instrument Part 9

4 Conditions that Disable Message Send and Receive 9

II Channel Message 10

5 Receive Channel 10

6 Send Channel 10

7 Note Oﬀ 10

8 Note On 10

9 Polyphonic Key Pressure 10

10 Control Change 11

10.1 Bank Select (00H,20H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

10.2 Modulation (01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

10.3 Data Entry (06H,26H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10.4 Volume (07H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10.5 Pan (0AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10.6 Expression (0BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10.7 General Use Controllers 1 through 8 (10H through 13H, 50H through 53H) . . . . . . . . 13

10.8 Hold1 (40H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

10.9 Sostenuto (42H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

10.10 Soft (43H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

10.11 Release Time (48H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

10.12 Attack Time (49H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

10.13 Filter Cut Oﬀ (4AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

10.14 Vibrato Rate (4CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

10.15 Vibrato Depth (4DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

10.16 Vibrato Delay (4EH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

10.17 Reverb Send (5BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

10.18 Chorus Send (5DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

10.19 NRPN (62H,63H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

10.20 RPN (64H,65H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

11 Mode Message 22

11.1 All Sound Oﬀ (78H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

11.2 Reset All Controllers (79H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

11.3 All Notes Oﬀ (7BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

11.4 Omni Oﬀ (7CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

11.5 Omni On (7DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

11.6 Mono (7EH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

11.7 Poly (7FH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

12 Program Change 23

13 Channel After Touch 24

14 Pitch Bend 24

III System Message 25

15 Timing Clock 25

16 Start 25

17 Stop 25

18 Active Sensing 25

19 System Exclusive Message 25

19.1 Universal Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 26

19.2 Instrument-Speciﬁc System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 29

IV Instrument-Speciﬁc System Exclusive Messages 30

20 Format 30

20.1 Message Classiﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

20.2 Basic Message Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

20.3 Format of Each Field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

21 Individual Parameter Operations 39

22 Parameter Set Transfer 39

22.1 Communication Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

22.2 One-way Mode Communication Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

22.3 Handshake Mode Communication Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

V Parameter List 49

23 Using the Parameter List 49

24 System Parameters 49

24.1 System Information Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

24.2 System Exclusive Protocol Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

24.3 Data Management Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

25 Patch Parameter 52

25.1 Analog Input Tune Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

25.2 Card Audio Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

25.3 DSP Output Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

25.4 DSP Setup Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

25.5 Master Tune Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

25.6 Master Mixer Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

25.7 Part Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

26 Tone Parameter 53

26.1 Drawbar Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

26.2 Tone Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

26.3 Modulation Setting Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

27 Scale Memory Parameter 54

27.1 Scale Memory Octave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

28 DSP Parameter 54

28.1 DSP Basic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

29 All Data Parameter 55

29.1 All Directory Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

30 Sequence Parameter 55

30.1 Sequence Directory Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

31 Registration Parameter 55

31.1 Registration Directory Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

32 Rhythm Parameter 55

32.1 Rhythm Directory Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

VI Parameter Set List 56

33 Parameter Set Table 56

33.1 CTK-6000/WK-6500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

33.2 CTK-7000/WK-7500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

33.3 AT-3/AT-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

VII DSP Parameter List 57

34 DSP Type List 57

34.1 Single DSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

34.2 Dual DSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

35 DSP Parameter Set Type 58

35.1 Wah . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

35.2 Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

35.3 Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

35.4 Enhancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

35.5 Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

35.6 Tremolo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

35.7 Phaser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

35.8 Flanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

35.9 Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

35.10 Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

35.11 Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

35.12 Rotary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

35.13 Ring Modulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

35.14 LoFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

35.15 Wah Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

35.16 Wah Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

35.17 Wah Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

35.18 Wah Flanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

35.19 Wah Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

35.20 Wah Tremolo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

35.21 Wah Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

35.22 Compressor Wah . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

35.23 Compressor Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

35.24 Compressor Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

35.25 Compressor Flanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

35.26 Compressor Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

35.27 Compressor Tremolo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

35.28 Compressor Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

35.29 Distortion Wah . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

35.30 Distortion Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

35.31 Distortion Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

35.32 Distortion Flanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

35.33 Distortion Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

35.34 Distortion Tremolo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

35.35 Distortion Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

35.36 Chorus Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

35.37 Chorus Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

35.38 Flanger Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

35.39 Flanger Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

35.40 Reﬂection Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

35.41 Reﬂection Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

35.42 Reﬂection Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

35.43 Tremolo Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

35.44 Tremolo Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

35.45 Tremolo Flanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

35.46 Tremolo Reﬂection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

VIII Setting Values and Send/ Receive Values 70

36 Setting Value Tables 70

36.1 Oﬀ/On Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

36.2 –64 - 0 - +63 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

36.3 –/+ Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

36.4 Pan Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

36.5 Fine Tune Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

36.6 Scale Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

36.7 Reverb Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

36.8 Reverb Time Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

36.9 Chorus Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

36.10 Drawbar Position Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

36.11 Normal/Vintage Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

36.12 0-3 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

36.13 0-5 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.14 Chorus Mode Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.15 Delay Level Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.16 Delay Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.17 LFO Wave Form1 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.18 LFO Wave Form2 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.19 LFO Wave Form3 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

36.20 LoFi Noise Level Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

36.21 Reﬂection Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

36.22 Ring Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

36.23 Rotate/Brake Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

36.24 Slow/Fast Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

IX MIDI Implementation Notation 75

37 Value Notation 75

37.1 Hexadecimal Notation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

37.2 Binary Notation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Part I

MIDI Message Overview

1 Product Conﬁguration as a MIDI Device

As a MIDI device, this Instrument consists of the System Section, Sound Generator Section, and Performance Controller Section described below. Each of these sections can send and receive speciﬁc MIDI Messages in accordance with its function.

1.1 System Section

The System Section manages the Instrument status and user data. A communication method known as a “bulk dump” can be used for two-way transfer of user data between the Instrument and a computer.

1.2 Performance Controller Section

The Performance Controller Section performs keyboard play and controller operations, and generates performance messages in accordance with auto play, etc. Basically, generated performance messages are sent to external destinations while also being transmitted to the Sound Generator Section. The channel number of the sent channel message is in accordance with the Instrument’s instrument part number.

MIDI Output Performance Information The following describes the performance information that is output and is not output as MIDI signals.

• Output performance

– Keyboard play and controller operations by the musician

– Auto accompaniment

– Recorded song playback

• Non-output performance

– Demo Songs

– Card song playback

1.3 Sound Generator Section

The Sound Generator Section mainly performs receive of performance information and sound source setting information. It consists of a common part that do es not depend on the channel and a musical instrument part that is independent of each channel.

1.3.1 Sound Generator Common Block

The common block consists of system eﬀects, master control, etc. These can be controlled by Instrument mixer function and/or general universal system exclusive messages, and the Instrument’s system exclusive messages.

1.3.2 Instrument Part Block

The instrument part section consists of a total of 32 instrument parts, divided into two groups, named Group A and Group B of 16 instruments each. Each part can perform operations and setting changes using the Instrument mixer function, and/or channel messages and Instrument’s system exclusive messages. Only Group B can be controlled by external channel messages.

As shown in the following table, there is a ﬁxed relationship between channel message receive channel

numbers and instrument parts.

Number Name MIDI Receive Ch MIDI Send Ch Assigned Function

00 A01 - 01-16(Note1) Keyboard UPPER 1 01 A02 - 02 Keyboard UPPER 2 02 A03 - 03 Keyboard LOWER 03 A04 - 04 Auto Harmonize 04 A05 - 05 Song Sequencer system track UPPER 1 05 A06 - 06 Song Sequencer system track UPPER 2 06 A07 - 07 Song Sequencer system track LOWER 07 A08 - - Metronome 08 A09 - 09 Auto Accompaniment (Percussion) 09 A10 - 10 Auto Accompaniment (Drum) 10 A11 - 11 Auto Accompaniment (Bass) 11 A12 - 12 Accompaniment (Chord 1) 12 A13 - 13 Accompaniment (Chord 2) 13 A14 - 14 Accompaniment (Chord 3) 14 A15 - 15 Accompaniment (Chord 4) 15 A16 - 16 Accompaniment (Chord 5) 16 B01 01 01 MIDI/Auto Performance Functions 17 B02 02 02 MIDI/Auto Performance Functions 18 B03 03 03 MIDI/Auto Performance Functions 19 B04 04 04 MIDI/Auto Performance Functions 20 B05 05 05 MIDI/Auto Performance Functions 21 B06 06 06 MIDI/Auto Performance Functions 22 B07 07 07 MIDI/Auto Performance Functions 23 B08 08 08 MIDI/Auto Performance Functions 24 B09 09 09 MIDI/Auto Performance Functions 25 B10 10 10 MIDI/Auto Performance Functions(Note2) 26 B11 11 11 MIDI/Auto Performance Functions 27 B12 12 12 MIDI/Auto Performance Functions 28 B13 13 13 MIDI/Auto Performance Functions 29 B14 14 14 MIDI/Auto Performance Functions 30 B15 15 15 MIDI/Auto Performance Functions 31 B16 16 16 MIDI/Auto Performance Functions

Note1 : Can be changed by the Keyboard Channel setting.

Note2 : This instrument part is basically a drum-only part. To specify a sound with a MIDI message, sp ecify a drum

sound whose setting is supported by the Instrument mixer.

2 Timbre Type Speciﬁc Operation

The sound source operation performed for a sound generator instrument receive message may depend on the value of the Timbre Type (see “About the Timbre Type” in “12 Program Change”) of each part’s operation mode. For details, see the explanation for each message.

3 Controlling Send/Receive of MIDI Messages in Each Instru-

ment Part

Send/receive of MIDI messages in each instrument part can be enabled/disabled by the Instrument’s mixer, the NRPN message explained under “10.19.1 Part Enable”, and the Part Enable Parameter explained under “25.7 Part Parameter”.

4 Conditions that Disable Message Send and Receive

All MIDI message send and receive is temporarily disabled while “Please Wait ...” is displayed.

Part II

Channel Message

5 Receive Channel

The channel number of the channel message received by each part is shown in the table under “1.3.2 Instrument Part Block”.

6 Send Channel

Basically, the MIDI channel of the channel message sent when the Instrument is played coincides with the MIDI channel of the part being played. Note, however, that the MIDI channel of the performance information that corresponds to the keyboard main part depends on the Keyboard Channel setting value.

7 Note Oﬀ

Message Format: 8nH kkH vvH

9nH kkH 00H(receive only)

n: MIDI Channel Number

kk: Key Number

vv: Velocity(Send:40H, Receive:Ignored)

Send Sent when the keyboard is played, when play is performed using Auto Accompaniment, and when recorded song data is played back. The key number changes in accordance with on the Transpose function and Octave Shift function.

Receive Receipt stops a note being sounded by a note on message.

8 Note On

Message Format: 9nH kkH vvH

n: MIDI Channel Number

kk: Key Number

vv: Velocity

Receive Receipt sounds a note of the corresponding instrument part.

9 Polyphonic Key Pressure

Message Format: AnH kkH vvH

n: MIDI Channel Number

kk: Key Number

vv: Pressure Value

Send This message is not sent by this Instrument.

Receive This message is not received by this Instrument.

10 Control Change

Message Format: BnH ccH vvH

n: MIDI Channel Number

cc: Control Number

vv: Value

Send Sent when the Instrument’s pedal is operated or when Instrument settings are changed.

Receive Receipt changes the pedal and other performance conditions, and Instrument settings.

10.1 Bank Select (00H,20H)

Message Format: BnH 00H mmH (MSB)

BnH 20H llH (LSB)

n: MIDI Channel Number

mm: MSB Value(Note1)

ll: LSB Value(Send:00H, Receive:Ignored)

Note1 : For details about the relationship between the MSB value and the tone, see the Tone List that comes with the

Instrument.

Send Sent when a tone is selected.

Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the

tone is not actually changed until a Program Change message is received. For details, see “12 Program Change”.

10.2 Modulation (01H)

Message Format: BnH 01H vvH

n: MIDI Channel Number

vv: Value

Send Sent when the modulation button is operated (CTK-7000, WK-7500, AT-3, AT-5 only).

Receive Receipt adds, to the tone being sounded, modulation of a depth speciﬁed by the value. In the case of a tone that already has modulation applied, receipt of this message increases the modulation depth. The modulation eﬀect diﬀers according to the tone b eing used.

10.3 Data Entry (06H,26H)

Message Format: BnH 06H mmH (MSB)

BnH 26H llH (LSB)

n: MIDI Channel Number

mm: MSB Value

ll: LSB Value

Send Sent when there is a change to the parameter assigned to RPN, NRPN.

Receive Receipt changes the parameter assigned to RPN, NRPN.

10.4 Volume (07H)

Message Format: BnH 07H vvH

n: MIDI Channel Number

vv: Value

Send Sent when the volume of any part is changed.

Receive Receipt changes the volume of the corresponding part.

10.5 Pan (0AH)

Message Format: BnH 0AH vvH

n: MIDI Channel Number

vv: Value(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.4 Pan Setting Value

Table” in “VIII Setting Values and Send/Receive Values”.

Send Sent when the pan of any part is changed.

Receive Receipt changes the pan of the corresponding part.

10.6 Expression (0BH)

Message Format: BnH 0BH vvH

n: MIDI Channel Number

vv: Value

Send Sent when Auto Accompaniment is used and during recorded song playback.

Receive Receipt changes the Expression value.

10.7 General Use Controllers 1 through 8 (10H through 13H, 50H through 53H)

On this Instrument, these messages are used to control DSP operation.

Message Format: BnH 10H vvH DSP Parameter7[1]

BnH 11H vvH DSP Parameter7[2]

BnH 12H vvH DSP Parameter7[3]

BnH 13H vvH DSP Parameter7[4]

BnH 50H vvH DSP Parameter7[5]

BnH 51H vvH DSP Parameter7[6]

BnH 52H vvH DSP Parameter7[7]

BnH 53H vvH DSP Parameter7[8]

n: MIDI Channel Number

vv: Value

Send Sent when the DSP parameter setting is conﬁgured.

Receive Receipt changes the value of DSP Parameter 7 [1 to 8] (7-bit parameter) assigned to the part

speciﬁed by the MIDI Channel Number. Any message received that corresponds to the parameter of a number not being used by the currently selected DSP is ignored. For details about Parameter 7 of each DSP, see the explanations under “VII DSP Parameter List”.

Received values and parameter setting values The range of the value of each DSP Parameter 7 array element depends on the selected DSP or array number. Unlike manipulation of a DSP parameter using a System Exclusive Message, a value received by this control change message is always in the range of 0 to 127, but the range is changed in accordance with the setting range of the applicable parameter setting. Because of this, it is impossible for a value to be outside of the range. Conversion to the parameter setting value from the value received with the message can be represented in general terms by the expression shown below.

„

Parameter Setting Value = Parameter Minimum Value + (Parameter Maximum Value − Parameter Minimum Value) ∗

Received Value

127

10.8 Hold1 (40H)

Message Format: BnH 40H vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when a pedal that has a sustain (damper) function is operated.

Receive Receipt performs an operation equivalent to a sustain pedal operation.

Timbre Type Speciﬁc Operation This operation diﬀers in accordance with the Timbre Type (see

“About the Timbre Type” in “12 Program Change”) setting.

• Timbre Type: Melody or Drawbar

Sustain oﬀ/on control is performed in accordance with the value of the received message.

• Timbre Type: Piano

Continuous control of the piano tone is performed in accordance with the value of the received message.

• Timbre Type: Drum

The received message does not aﬀect sound source operation.

10.9 Sostenuto (42H)

Message Format: BnH 42H vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when a pedal that has a sostenuto function is operated.

Receive Receipt performs an operation equivalent to a sostenuto pedal operation.

10.10 Soft (43H)

Message Format: BnH 43H vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when a pedal that has a soft function is operated.

Receive Receipt performs an operation equivalent to a soft pedal operation.

10.11 Release Time (48H)

Message Format: BnH 48H vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.2 –64 - 0 - +63

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the release time setting is conﬁgured.

Receive Receipt makes a relative change in the time it takes for a note to decay to zero after a key is

released.

10.12 Attack Time (49H)

Message Format: BnH 49H vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.2 –64 - 0 - +63

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the attack time setting is conﬁgured.

Receive Receipt makes a relative change in the time it takes for a note to rise to its maximum level.

10.13 Filter Cut Oﬀ (4AH)

Message Format: BnH 4AH vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.2 –64 - 0 - +63

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the ﬁlter cut oﬀ setting is conﬁgured.

Receive Receipt changes how the cut-oﬀ ﬁlter is applied.

10.14 Vibrato Rate (4CH)

Message Format: BnH 4CH vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.2 –64 - 0 - +63

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the vibrato rate setting is conﬁgured.

Receive Receipt changes the note vibrato rate.

10.15 Vibrato Depth (4DH)

Message Format: BnH 4DH vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.2 –64 - 0 - +63

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the vibrato depth setting is conﬁgured.

Receive Receipt changes the degree of pitch modulation.

10.16 Vibrato Delay (4EH)

Message Format: BnH 4EH vvH

n: MIDI Channel Number

vv: Value (Note1)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.2 –64 - 0 - +63

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the vibrato delay setting is conﬁgured.

Receive Receipt changes the time it takes until note vibrato starts.

10.17 Reverb Send (5BH)

Message Format: BnH 5BH vvH

n: MIDI Channel Number

vv: Value

Send Sent when the reverb send of any part is changed.

Receive Receipt changes the reverb send of the corresponding part.

10.18 Chorus Send (5DH)

Message Format: BnH 5DH vvH

n: MIDI Channel Number

vv: Value

Send Sent when the chorus send of any part is changed.

Receive Receipt changes the chorus send of the corresponding part.

10.19 NRPN (62H,63H)

Message Format: BnH 62H llH (LSB)

BnH 63H mmH (MSB)

n: MIDI Channel Number

ll: LSB Value

mm: MSB Value

10.19.1 Part Enable

Message Format: BnH 62H 00H

BnH 63H 02H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Send:00H, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when each part’s Part On/Oﬀ operation is performed.

Receive Receipt changes the part on/oﬀ setting of the corresponding part.

10.19.2 DSP Enable

Message Format: BnH 62H 01H

BnH 63H 02H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Send:00H, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when each part’s DSP Line On/Oﬀ operation is performed.

Receive Receipt changes the DSP on/oﬀ setting of the corresponding part.

10.19.3 Mixer Scale Tune Enable

Message Format: BnH 62H 00H

BnH 63H 03H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Send:00H, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when each part’s Scale On/Oﬀ operation is performed.

Receive Receipt changes the scale on/oﬀ setting of the corresponding part.

10.19.4 Drawbar Position

Message Format: BnH 62H ffH

BnH 63H 40H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

ff: Drawbar Foot(Feet) (Note1)

mm: Value (Note2)

ll: (Send:00H, Receive:Ignored)

Note1 : The following shows the relationship between the Drawbar Foot value and the actual foot bar.

ff Foot Bar

00 Ft16’ 01 Ft5 1/3’ 02 Ft8’ 03 Ft4’ 04 Ft2 2/3’ 05 Ft2’ 06 Ft1 3/5’ 07 Ft1 1/3’ 08 Ft1’

Note2 : For information about the relationship between setting values and send/receive values, see the “36.10 Drawbar

Position Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when a drawbar is operated (CTK-7000, WK-7500 only).

Receive Receipt changes the drawbar position in accordance with the message contents (CTK-7000,

WK-7500 only).

10.19.5 Drawbar Organ Click

Message Format: BnH 62H 09H

BnH 63H 40H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Not sent, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send This message is not sent by this Instrument.

Receive Receipt changes the drawbar parameter click (CTK-7000, WK-7500 only).

10.19.6 Drawbar Organ 2nd Percussion

Message Format: BnH 62H 0AH

BnH 63H 40H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Send:00H, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the 2nd percussion button is operated (CTK-7000, WK-7500 only).

Receive Receipt changes the drawbar parameter 2nd percussion (CTK-7000, WK-7500 only).

10.19.7 Drawbar Organ 3rd Percussion

Message Format: BnH 62H 0BH

BnH 63H 40H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Send:00H, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.1 Oﬀ/On Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the 3rd percussion button is operated (CTK-7000, WK-7500 only).

Receive Receipt changes the drawbar parameter 3rd percussion (CTK-7000, WK-7500 only).

10.19.8 Percussion Decay Time

Message Format: BnH 62H 0CH

BnH 63H 40H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value

ll: (Not sent, Receive:Ignored)

Send This message is not sent by this Instrument.

Receive Receipt changes the percussion decay time (CTK-7000, WK-7500 only).

10.19.9 Drawbar Organ Type

Message Format: BnH 62H 0DH

BnH 63H 40H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: Value (Note1)

ll: (Not sent, Receive:Ignored)

Note1 : For information about the relationship between setting values and send/receive values, see the “36.11 Nor-

mal/Vintage Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send This message is not sent by this Instrument.

Receive Receipt changes the drawbar parameter type (CTK-7000, WK-7500 only).

10.20 RPN (64H,65H)

Message Format: BnH 64H llH (LSB)

BnH 65H mmH (MSB)

n: MIDI Channel Number

ll: LSB Value

mm: MSB Value

10.20.1 Pitch Bend Sensitivity

Message Format: BnH 64H 00H

BnH 65H 00H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: MSB Value(00H - 18H)

ll: LSB Value(Send:00H, Receive:Ignored)

Send Sent when Bend Range of any part is changed.

Receive Receipt changes Bend Range of the corresponding part.

10.20.2 Fine Tune

Message Format: BnH 64H 01H

BnH 65H 00H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: MSB Value

ll: LSB Value

Send Sent when the ﬁne tune of any part is changed.

Receive Receipt changes the ﬁne tune of the corresponding part.

10.20.3 Coarse Tune

Message Format: BnH 64H 02H

BnH 65H 00H

BnH 06H mmH

BnH 26H llH

n: MIDI Channel Number

mm: MSB Value(28H - 58H)

ll: LSB Value(Not sent, Receive:Ignored)

Send Sent when the coarse tune of any part is changed.

Receive Receipt changes the coarse tune of the corresponding part. Does not aﬀect sound source

operation when the Timbre Type (see “About the Timbre Type” in “12 Program Change”) is Drum.

10.20.4 Null

Message Format: BnH 64H 7FH

BnH 65H 7FH

n: MIDI Channel Number

Send Sent when an RPN, NRPN message send operation is performed.

Receive Receipt de-selects RPN, NRPN.

11 Mode Message

11.1 All Sound Oﬀ (78H)

Message Format: BnH 78H 00H

n: MIDI Channel Number

Send Sent when the local control is set to OFF on the Instrument.

Receive Receipt stops all voices that are sounding.

11.2 Reset All Controllers (79H)

Message Format: BnH 79H 00H

n: MIDI Channel Number

Send Sent when MIDI send related settings are changed.

Receive Receipt initializes each performance controller.

11.3 All Notes Oﬀ (7BH)

Message Format: BnH 7BH 00H

n: MIDI Channel Number

Send Sent when MIDI send related settings are changed.

Receive Receipt releases (key release) all voices that are sounding.

11.4 Omni Oﬀ (7CH)

Message Format: BnH 7CH 00H

n: MIDI Channel Number

Send This message is not sent by this Instrument.

Receive Receipt performs the same operation as when All Notes Oﬀ is received.

11.5 Omni On (7DH)

Message Format: BnH 7DH 00H

n: MIDI Channel Number

Send This message is not sent by this Instrument.

Receive Receipt performs the same operation as when All Notes Oﬀ is received.

11.6 Mono (7EH)

Message Format: BnH 7EH 00H

n: MIDI Channel Number

Send This message is not sent by this Instrument.

Receive Receipt performs the same operation as when All Notes Oﬀ is received.

11.7 Poly (7FH)

Message Format: BnH 7FH 00H

n: MIDI Channel Number

Send This message is not sent by this Instrument.

Receive Receipt performs the same operation as when All Notes Oﬀ is received.

12 Program Change

Message Format: CnH ppH

n: MIDI Channel Number

pp: Program Number (Note1)

Note1 : For details about the relationship between the program number and the tone, see the Tone List that comes with

the Instrument.

Send Sent when a tone is selected.

Receive Receipt changes the ton of the corresponding part. The selected tone is determined by the

program value of this message and the Bank Select message value received prior to this message. Also note that receipt of this message also may change the Timbre Type that corresponds to the selected tone. For more information, see “About the Timbre Type” below.

About the Timbre Type Tones that are selected by each Instrument part have an attribute that depends on the sound source operation type. This attribute is called the “timbre type,” which is one of the types described below.

• Melody

This timbre type optimizes for normal melody tones. The damper pedal performs on/oﬀ operations.

• Piano

This setting optimizes for piano tones. The damper pedal performs on/oﬀ operations, but the decay speed of sounding voices changes in accordance with the Hold1 message value(CTK-7000, WK-7500, AT-3, AT-5 only).

• Drum

This setting optimizes for drum sounds. The damper pedal does not function. The Hold1, Channel Coarse Tune, and Master Coarse Tune messages are ignored if they are received.

• Drawbar

This setting optimizes for drawbar tones. The damper pedal performs on/oﬀ operations.

13 Channel After Touch

Message Format: DnH vvH

n: MIDI Channel Number

vv: Value

Send This message is not sent by this Instrument.

Receive Receipt adds, to the tone being sounded, modulation of a depth speciﬁed by the value. In

the case of a tone that already has modulation applied, receipt of this message increases the modulation depth. The modulation eﬀect diﬀers according to the tone b eing used.

14 Pitch Bend

Message Format: EnH llH mmH

n: MIDI Channel Number

ll: Value LSB

mm: Value MSB

Send Sent when the bender is operated.

Receive Receipt changes the pitch of the currently sounding note. The range of the pitch change

depends on the Bend Range value setting.

Part III

System Message

15 Timing Clock

Message Format: F8H

Send Sent when auto accompaniment is used.

Receive This message is not received by this Instrument.

16 Start

Message Format: FAH

Send Sent when auto accompaniment is used.

Receive This message is not received by this Instrument.

17 Stop

Message Format: FCH

Send Sent when auto accompaniment is used.

Receive This message is not received by this Instrument.

18 Active Sensing

Message Format: FEH

Send This message is not sent by this Instrument.

Receive Once this message is received, the Active Sensing mode is entered. If no MIDI message is

received for a speciﬁed amount of time, voices being sounded by this Instrument’s sound source are released, the controller is reset, and the Active Sensing mode is exited.

19 System Exclusive Message

Message Format: F0H....F7H

The Instrument sends and receives standard universal system exclusive messages, and system exclusive

messages that have Instrument-speciﬁc formats.

19.1 Universal Real Time System Exclusive Message

Message Format: F0H 7FH....F7H

19.1.1 Master Volume

Message Format: F0H 7FH 7FH 04H 01H llH mmH F7H

ll: LSB Value(Send:00H, Receive:Ignored)

mm: MSB Value

Send Sent when the Master Volume is changed.

Receive Receipt changes the Master Volume.

19.1.2 Master Pan

Message Format: F0H 7FH 7FH 04H 02H llH mmH F7H

ll: LSB Value(Send:00H, Receive:Ignored)

mm: MSB Value(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.4 Pan Setting Value

Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the Master Pan is changed.

Receive Receipt changes the Master Pan.

19.1.3 Master Fine Tuning

Message Format: F0H 7FH 7FH 04H 03H llH mmH F7H

ll: LSB Value(Note1)

mm: MSB Value(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.5 Fine Tuning Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send This message is sent when the tuning setting is changed.

Receive Receipt changes the tuning setting.

19.1.4 Master Coarse Tuning

Message Format: F0H 7FH 7FH 04H 04H llH mmH F7H

ll: LSB Value(Not sent, Receive:Ignored)

mm: MSB Value

Send This message is not sent by this Instrument.

Receive Receipt changes the Patch Master Coarse Tune parameter.

19.1.5 Reverb Type

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H

vv: Value(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.7 Reverb Type

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the Reverb Type is changed.

Receive Receipt changes the Reverb Type.

19.1.6 Reverb Time

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 01H vvH F7H

vv: Value(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.8 Reverb Time

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send This message is not sent by this Instrument.

Receive Receipt changes the Reverb duration.

19.1.7 Chorus Type

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 00H vvH F7H

vv: Value(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.9 Chorus Type

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the Chorus Type is changed.

Receive Receipt changes the Chorus Type.

19.1.8 Modulation Rate

Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 01H vvH F7H

vv: Value

Send This message is not sent by this Instrument.

Receive Receipt changes the Chorus Rate.

19.1.9 Scale/Octave 2 Byte Real Time Tuning

Message Format: F0H 7FH 7FH 08H 09H ffH ggH hhH ssH ttH ... F7H

ff: Channel Byte 1 (bits 0 to 1 = channel 15 to 16)

gg: Channel Byte 2 (bits 0 to 6 = channel 8 to 14)

hh: Channel Byte 3 (bits 0 to 6 = channel 1 to 7)

ss tt ...: Tuning offset(Note1)

Note1 : For information about the relationship between setting values and send/receive values, see “36.6 Scale Setting Value

Table” in “VIII Setting Values and Send/Receive Values” of this document.

Send Sent when the scale setting is changed. The value of (ffH, ggH, hhH) is (03H, 7FH, 7FH) only.

Receive Receipt is ignored when the value of (ffH, ggH, hhH) is (00H, 00H, 00H), and changes Instrument’s scale setting for other values.

19.1.10 GM System On

Message Format: F0H 7EH 7FH 09H 01H F7H

Send This message is not sent by this Instrument.

Receive Receipt puts the sound source into a GM sound source mode.

19.1.11 GM System Oﬀ

Message Format: F0H 7EH 7FH 09H 02H F7H

Send This message is not sent by this Instrument.

Receive Receipt changes the sound source setting to the Instrument presetting.

19.1.12 GM2 System On

Message Format: F0H 7EH 7FH 09H 03H F7H

Send This message is not sent by this Instrument.

Receive Though the Instrument does not support GM2, receipt of the GM2 System On message has

the same result as receipt of the GM System On message.

19.1.13 GS Message

Message Format: F0H 41H ddH 42H 12H 40H 00H 7FH 00H 41H F7H

dd: Device ID(Ignored)

Send This message is not sent by this Instrument.

Receive Receipt performs the same operation as when the GM System On message is received.

19.2 Instrument-Speciﬁc System Exclusive Message

Message Format: F0H 44H 16H 02H ... F7H

This message can be used to send the Instrument memory status, for two-way transfer of special operation commands and user data, to perform sound source parameter operations, etc. For more information, see “IV Instrument-Speciﬁc System Exclusive Messages”.

Part IV

Instrument-Speciﬁc System Exclusive Messages

20 Format

This section explains the format of the Instrument-speciﬁc System Exclusive Messages. See “V Parameter List” and “VI Parameter Set List” for information about how parameter sets actually are transferred.

20.1 Message Classiﬁcations

Basically, the operation that corresponds to Instrument-speciﬁc system exclusive messages is parameter data transfer.

The following operations can be performed from an external device using this parameter transfer message.

• Modiﬁcation of an individual Instrument parameter

• Batch modiﬁcation of a particular Instrument parameter set

• Import of an individual Instrument parameter value

• Batch import of a particular Instrument parameter set

In addition to parameters being used as device setting values, some parameters act as commands when received by the Instrument and as device status information when sent from the Instrument.

The following table shows the parameter category for each type of transfer.

Function Section Parameter Category Description System System Commands to the Instrument, Instrument stats

All All user data

Performance Controller Scale Memory User Scale Memory

Sequence Song Sequencer Registration Registration Rhythm User Rhythm

Sound Generator Patch Sound source common settings (system eﬀects, mas-

ter settings, etc.) Instrument part settings (tone selection, mixer channel setting, tuning, etc.)

Tone Tone Setting, Drawbar Organ Setting, Modulation

Setting

DSP DSP Parameter Setting

20.2 Basic Message Structure

Instrument-speciﬁc system exclusive message operation can be broadly divided between two methods: Individual Parameter Transfer (single parameter send/receive) and Bulk Parameter Set Transfer (batch parameter send/receive). Each method includes a number of diﬀerent messages.

The ﬁeld in the system exclusive message that speciﬁes the message type is the action (act) ﬁeld. The format of the body part of the message depends on the act value.

The table below shows the body format for each action of Instrument-speciﬁc system exclusive messages. An actual message consists of the items indicated by Y, from left to right.

<- body (Depends on act ) ->

SX MAN MOD dev act cat mem pset blk prm idx len data img crc EOX

IPR Y Y Y Y Y Y Y Y Y Y Y Y - - - Y

IPS Y Y Y Y Y Y Y Y Y Y Y Y Y - - Y

OBR Y Y Y Y Y Y Y Y - - - - - - - Y

OBS Y Y Y Y Y Y Y Y - - - Y - Y Y Y

HBR Y Y Y Y Y Y Y Y - - - - - - - Y

HBS Y Y Y Y Y Y Y Y - - - Y - Y Y Y

EXI Y Y Y Y Y - - - - - - - - - - Y

SBS Y Y Y Y Y - - - - - - - Y - - Y

ACK Y Y Y Y Y Y Y Y - - - - - - - Y

RJC Y Y Y Y Y Y Y Y - - - - - - - Y

ESS Y Y Y Y Y Y Y Y - - - - - - - Y

EBS Y Y Y Y Y Y Y Y - - - - - - - Y

ERR Y Y Y Y Y - - - - - - - Y - - Y

20.3 Format of Each Field

20.3.1 SX : System Exclusive message Status

Format: 11110000B (F0H)

This is the System Exclusive Message status byte established by the MIDI standard.

20.3.2 MAN : Manufacturer’s ID

Format: 01000100B (CASIO = 44H)

Indicates this Instrument’s manufacturer ID.

20.3.3 MOD : Model ID

Format: MSB 00010110B (16H)

LSB 00000010B (02H)

These two successive bytes (MSB, LSB) indicate the CTK-6000/WK-6500/CTK-7000/WK-7500/AT3/AT-5 model ID.

20.3.4 dev : MIDI Device ID 00H - 7FH

Format: 0dddddddB

The contents of this ﬁeld in a received message are compared with the Model’s MIDI Device ID, and receipt of the incoming message is allowed only when the two IDs match. When a message containing 7FH is received, receipt of the message is always allowed, regardless of the Instrument’s ID setting. Note, however, that the Instrument does not have a speciﬁc Device ID, so use only 7FH for send and receive.

20.3.5 act : Action

Format: 0aaaaaaaB

This ﬁeld indicates the operation of the Instrument-speciﬁc System Exclusive Message.

aaaaaaaB Action Function

00H IPR Individual Parameter Request

01H IPS Individual Parameter Send

02H OBR One-way Bulk Parameter Set Request

03H OBS One-way Bulk Parameter Set Send

04H HBR Handshake Bulk Parameter Set Request

05H HBS Handshake Bulk Parameter Set Send

08H SBS Start of Bulk Dump Session Session

09H EXI Extend Interval

0AH ACK Acknowledge

0BH RJC Reject

0DH ESS End of Sub-session

0EH EBS End of Bulk Dump Session

0FH ERR Error

IPR:Individual Parameter Request Indicates an individual parameter value send request message. When the Instrument receives this action, it uses an IPS message to return the speciﬁed parameter value.

IPS:Individual Parameter Send Indicates an individual parameter value send message. When the Instrument receives this action, it rewrites the value speciﬁed by the data ﬁeld with the speciﬁed parameter value.

OBR:One-way Bulk Parameter Set Request Indicates a send request message using parameter set image one-way mode. When the Instrument receives this action, it uses an OBS message to return the speciﬁed parameter set.

OBS:One-way Bulk Parameter Set Bulk Send Indicates a parameter set image send message using one-way mode. When the parameter set to be transferred is greater than a preset size, it is divided into multiple packets and transferred at prescribed time intervals. The time interval is set in accordance with the Oneway Current Interval parameter described under “24.2 System Exclusive Protocol Parameter”.

HBR:Handshake Bulk Parameter Set Request Indicates a send request message using the parameter set image handshake mode. When the Instrument receives this action, it uses an HBS message to return the speciﬁed parameter set.

HBS:Handshake Bulk Parameter Set Send Indicates a parameter set image send message using handshake mode. The parameter set to be transferred is divided into multiple packets when it is greater than a prescribed size. The packets are transferred in accordance with handshake mode.

EXI:Extend Interval During a dump session, message sent by a devices that should send the next message to tell a device waiting for the next message to extend the message interval. Receipt of this message causes the message wait elapsed time to reset to 0.

SBS:Start of Bulk Dump Session This message is sent to both devices to start a session to transfer a series of parameter sets using one-way protocol or handshake protocol. The protocol used during the session and the data transfer direction is determined in accordance with the value of the data ﬁeld. For details, see the explanation about the data ﬁeld. When there is a request to start a handshake protocol session, the devices that receive this message return ACK after setting up to enable a session. This message is ignored if the outlook is that a session cannot be enabled.

ACK:Acknowledge Indicates a message used by the receiver during parameter set handshake mode transfer to convey to the sender that it is ready for send of the next packet. The cat, mem, and pset ﬁelds indicate the value carried by the last received message.

RJC:Reject Indicates a message to convey to the other side that an ongoing parameter set one-way mode or handshake mode send or receive session was interrupted. The cat, mem, and pset ﬁelds indicate the value carried by the last received message.

ESS:End of Sub-session Indicates there is a message to convey to the receiving device that a one-way mode or handshake mode serial packet transfer for sending a sub-session (one parameter set) is complete. The cat, mem, and pset ﬁelds indicate the values in the last received message.

EBS:End of Bulk Dump Session Indicates there is a message to convey to the receiving device that a one-way mode or handshake mode serial parameter set transfer session send, which was launched by some operation, is complete. The cat, mem, and pset ﬁelds indicate the values in the last received message.

ERR:Error This message is sent to a device that sent a message during a parameter set transfer session using handshake protocol bulk dump, when the device that received the message encounters some communication problem. The generated error type depends on the value in the data ﬁeld. For details, see the explanation about the data ﬁeld.

20.3.6 cat : Category

Format: 0cccccccB

The category indicates the categories of data handled by the System Exclusive Message. The ID number (ID) of the Category is indicated on the left, while the communication operation (Action) is indicated on the right.

Category Transfer

ID (c) Parameter Set Individual Parameter One-way Bulk Handshake Bulk

00H System A - -

02H Patch A - -

03H Tone A A A

12H Scale Memory A(Note1) A(Note1) A(Note1)

13H DSP A A A

1FH All F A A

21H Sequence F A A

22H Registration F A A

24H Rhythm F A A

A · · · Available (Also including when only some parameters are available.)

F · · · File Information (Not the data itself. Name, size, and other ﬁle information only.)

- · · · Not Available

Note1 : AT-3/AT-5 only.

20.3.7 mem : Memory Area ID

Format: 0mmmmmmmB

Speciﬁes the memory area that is the object of the parameter transfer. The following are deﬁned for this Instrument.

mem Data Type Meaning

0 User area Read/write enabled

1 Preset area Read/write disabled

2 Store area Read/write enabled

20.3.8 pset : Parameter Set Number

Format: LSB 0nnnnnnnB

MSB 0mmmmmmmB

This ﬁeld is a 2-byte (LSB, MSB) value indicating the number of the parameter set (mmmmmmmnnnnnnnB, Binary) being transferred.

20.3.9 blk Block Number

The block number is a supplementary number that speciﬁes which block parameter is to be accessed when there are multiple blocks (instrument parts, etc.) that include parameters with the same ID within a single parameter set. The array structure of a block can be expressed up to 4 dimensions, and the size of a 1-dimensional array is expressed as 14 bits.

Format: index3 LSB 0iiiiiiiB

index3 MSB 0jjjjjjjB

index2 LSB 0kkkkkkkB

index2 MSB 0lllllllB

index1 LSB 0mmmmmmmB

index1 MSB 0nnnnnnnB

index0 LSB 0oooooooB

index0 MSB 0pppppppB

Note : Arranged in high dimension sequence.

1-dimension array block [index0]

Value Meaning

00jjjjjjjiiiiiiiB 0000H

00lllllllkkkkkkkB 0000H

00nnnnnnnmmmmmmmB 0000H

00pppppppoooooooB index0

2-dimension array block [index1][index0]

Value Meaning

00jjjjjjjiiiiiiiB 0000H

00lllllllkkkkkkkB 0000H

00nnnnnnnmmmmmmmB index1

00pppppppoooooooB index0

3-dimension array block [index2][index1][index0]

Value Meaning

00jjjjjjjiiiiiiiB 0000H

00lllllllkkkkkkkB index2

00nnnnnnnmmmmmmmB index1

00pppppppoooooooB index0

4-dimension array block [index3][index2][index1][index0]

Value Meaning

00jjjjjjjiiiiiiiB index3

00lllllllkkkkkkkB index2

00nnnnnnnmmmmmmmB index1

00pppppppoooooooB index0

20.3.10 prm : Parameter ID

Format: LSB 0pppppppB

MSB 0qqqqqqqB

The Parameter ID indicates the parameter type. When transferring parameters (see “V Parameter List” below) individually (as opposed to bulk transfer), this ﬁeld is used to identify the parameter being transferred by its parameter ID.

20.3.11 idx : Data Index Number

Format: LSB 0iiiiiiiB

MSB 0jjjjjjjB

The data index number indicates the ﬁrst array number of the array from which transfer starts.

20.3.12 len : Data Length

Format: LSB 0lllllllB

MSB 0mmmmmmmB

As shown below, the meaning of this ﬁeld diﬀers depending on whether an individual transfer or a bulk parameter set transfer is being performed.

Individual Parameter Transfer The value of this ﬁeld speciﬁes the size of the parameter value stored in the data ﬁeld. Data length indicates the length of the array being transferred minus 1 when the parameter contains a character string or other similar array structure.

Bulk Parameter Set Transfer The value of this ﬁeld speciﬁes the size of the parameter set memory image stored in the img ﬁeld. Data length indicates the number of bytes of data included within a packet. When this value is zero, it means the data itself does not exist.

20.3.13 data : Parameter Data

Individual Parameter Transfer

Format: index0 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

index1 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

index2 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

: :

indexN 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB)

Parameter data indicates the parameter value. Data is repeatedly placed in an array of the size equivalent to len+1. For the structure of one data item, the length depends on the data bit width(Parameter List Size), as shown below.

Size Number of Data

1 - 7 1

8 - 14 2

15 - 21 3

22 - 28 4

29 - 32 5

Each block of data is packed from the lowest order byte ﬁrst. In the case of multiple-byte data, the lowest weighted bit is the least signiﬁcant digit of the ﬁrst data byte, and the highest weighted bit is the most signiﬁcant digit of the ﬁnal data byte. The following shows an example of how data would be divided for transfer in the case of 32-bit data.

7 6 5 4 3 2 1 0

data0: 0 [bit06] [bit05] [bit04] [bit03] [bit02] [bit01] [bit00]

data1: 0 [bit13] [bit12] [bit11] [bit10] [bit09] [bit08] [bit07]

data2: 0 [bit20] [bit19] [bit18] [bit17] [bit16] [bit15] [bit14]

data3: 0 [bit27] [bit26] [bit25] [bit24] [bit23] [bit22] [bit21]

data4: 0 0 0 0 [bit31] [bit30] [bit29] [bit28]

SBS (Start of Bulk Dump Session)

Format: 0bbbbbbbB

The relationship between the data value and error 0bbbbbbB is deﬁned as shown below.

• Data = 0 : Start OBR Session

Start session to request data using one-way protocol.

• Data = 1 : Start OBS Session

Start session to send data using one-way protocol.

• Data = 2 : Start HBR Session

Start session to request data using handshake protocol. If a device that receives this message accepts the session, it needs to return ACK.

• Data = 3 : Start HBS Session

Start session to send data using handshake protocol. If a device that receives this message accepts the session, it needs to return ACK.

ERR (Error)

Format: 0eeeeeeeB

The relationship between the data value and error 0eeeeeeeB is deﬁned as shown below.

• Data = 0 : Time Out Error

This error message is generated when a preset amount of time elapses without a receiving device receiving an expected message. This error is also generated when an unexpected message is received instead of the expected message. The preset time is set in accordance with the Handshake Max Interval parameter described under “24.2 System Exclusive Protocol Parameter”.

• Data = 1 : Format Error

This error message is issued in the case of an invalid format in an Instrument System Exclusive message received by a receiving device.

• Data = 2 : CRC Error

This error message is issued in the case of an invalid CRC value in an HBS message received by the data receiving device.

Single Parameter Data Size Limit Under initial default settings for the Instrument’s System Exclusive message format, the size of a single message cannot exceed 256 bytes in the case of bulk dump using handshake protocol, and cannot exceed 48 bytes in all other cases. The data size and the array size, however, can cause a packet to exceed 48 bytes when transferring a single parameter array. In this case, the IPS and IPR message data length and data index number values can be modiﬁed to enable division of a single parameter value into multiple messages so it can be sent that way. These message sizes can be changed with the system parameter.

20.3.14 img : Parameter Set Memory Image

Format: Data0 0aaaaaaaB

Data1 0bbbbbbaB

Data2 0cccccbbB

Data3 0ddddcccB

: :

During data transfer, the memory image data of the parameter set to be sent is read sequentially in 1-byte units starting from the ﬁrst address. That value is transformed starting from the lower bit to a 7-bit wide data string.

Example: 33-byte data transfer In the case of memory image transfer of the 33 bytes such as Table 1, for example, the transfer image is transformed to 38 bytes as shown in Table 2.

Table 1

7 6 5 4 3 2 1 0

Memory data 00: [00.7] [00.6] [00.5] [00.4] [00.3] [00.2] [00.1] [00.0]

Memory data 01: [01.7] [01.6] [01.5] [01.4] [01.3] [01.2] [01.1] [01.0]

Memory data 02: [02.7] [02.6] [02.5] [02.4] [02.3] [02.2] [02.1] [02.0]

Memory data 32: [32.7] [32.6] [32.5] [32.4] [32.3] [32.2] [32.1] [32.0]

(Bit M of the NNth byte is indicated at [NN.M].)

Table 2

7 6 5 4 3 2 1 0

Send data 00: 0 [00.6] [00.5] [00.4] [00.3] [00.2] [00.1] [00.0]

Send data 01: 0 [01.5] [01.4] [01.3] [01.2] [01.1] [01.0] [00.7]

Send data 02: 0 [02.4] [02.3] [02.2] [02.1] [02.0] [01.7] [01.6]

Send data 37: 0 0 0 [32.7] [32.6] [32.5] [32.4] [32.3]

Though transferred data always sequentially uses from bit 0 through bit 7, unused upper bit ﬁelds in the ﬁnal transfer data are ﬁlled in with 0.

Parameter Set Packet Splitting When a parameter set is transferred, a single parameter set memory image can be split so it can ﬁt into the preset transfer message size, and transferred as multiple packets. Even when a packet is split, the memory image must be transferred from the beginning in the sequence it is arranged without interruption. When sending a parameter set to the Instrument, the size of a System Exclusive message for a single packet must ﬁt within a preset size. The parameter set memory image to be transferred can be split into 1-byte units, and it does not matter whether the length of each packet is diﬀerent. When a packet receive error is generated, the sending device needs to resend, but the size of the packet sent does not necessarily need to be the same size as the packet sent when the error was generated. Even the sizes of parameter sets are small, using a single packet to send multiple parameter sets is not supported. With this Instrument, the data size, transfer time interval, and other communication parameters for split packets can be adjusted using the parameters described under “24.2 System Exclusive Protocol Parameter”. For details, see “24.2 System Exclusive Protocol Parameter.”

20.3.15 crc : Cyclic Redundancy Check

Format: LSB 0aaaaaaaB

0bbbbbbaB

0cccccbbB

0ddddcccB

MSB 0000ddddB

CRC32 (in accordance with ISO 8802-3 or IEEE803.2 regulations) 32-bit value (ddddddddccccccccbbbbbbbbaaaaaaaaB) calculated for the byte string from “MAN: Manufacturer’s ID” to the last byte of “img: Parameter Set Memory Image” is stored in this “crc: Cyclic Redundancy Check”. The receiving unit checks the value, and if it is not correct sends an error as a re-request.

20.3.16 EOX : End of System Exclusive Message

Format: 11110111B (F7H)

This is the End of System Exclusive Message status byte established by the MIDI standard.

21 Individual Parameter Operations

There are two parameter unit operations: Individual Parameter Transfer and Individual Parameter Request. For one session, in response to an IPR (Individual Parameter Request) from an external device, this Instrument returns an IPS (Individual Parameter Send) or the session is concluded when the external device or this Instrument spontaneously sends an IPS. If this Instrument received an IPS, the value of the applicable parameter is changed. Depending on the function of a parameter, Individual Parameter Send may be used to issue a command to the Instrument and Individual Parameter Request may be used to check Instrument status information.

Data Receiver Data Sender Operation

IPR → Send Request(Optional)

← IPS Data Transfer

22 Parameter Set Transfer

22.1 Communication Modes

22.1.1 One-way and Handshake

In order to ensure maximum speed for bulk dumping of Parameter Sets, the data format is diﬀerent from the data format used for Individual Parameter Send. Data is transferred as-is, using the Model’s memory image. Parameter Sets can be transferred by bulk dump using the message exchange types described below.

• One-way mode Parameter Set send/receive

• One-way mode Parameter Set send request send/receive

• Handshake mode Parameter Set send/receive

• Handshake mode Parameter Set send request, receive rejected, error notiﬁcation send/receive

With the one-way mode, the sending device sends data and ends the session without regard to the response of the receiving device. This mode is best for one-way transfers from a sequencer or similar device.

With the handshake mode, the sending device sends the data and then waits for a response from the receiving device before advancing to the next session. This is a high-speed mode in which there is no time wasted waiting.

See “VI Parameter Set List” for details about Instrument parameter sets.

22.1.2 Session and Subsession

Subsession “One subsession” refers to transfer of one parameter set. A subsession transfers one

parameter set or a parameter set that has been divided into multiple packets for transfer, with ESS (End of Sub-session) at the end to terminate the send. Division of a parameter set into multiple packets is used when the size of the parameter set is greater than a prescribed size. The packet number in the packet index ﬁeld indicates the sequential position of a packet relative to the other packets. A single packet cannot be used to transfer multiple small parameter sets. A parameter set delimiter always must be transferred as a packet delimiter.

Session “One session” refers to a series of processes that occur for one user operation. One subsession or multiple subsessions make up a session. The sender sends EBS (End of Bulk Dump Session) to end a session. Regardless of whether there is a single parameter set or multiple parameter sets being transferred, a bulk dump always takes the form of a session, never a subsession only.

22.2 One-way Mode Communication Flow

A single session starts when an external device, which wants to start communication for data send/receive using one-way protocol, sends an SBS (Start of Bulk Dump Session) message to this Instrument, which is its communication partner. The external device starts a request send using OBR or a data send using OBS. The sub session ends when one parameter set that needs to be transferred by the data send device is complete. After the send of all the parameter sets is complete, the external device that started the communication sends an EBS to inform the Instrument that the session is ended. The transfer messages of a single parameter set cannot exceed a preset size. To do this, messages are split into multiple packets that are less than the preset size, and transfer is performed according to a preset interval. The preset size and preset time are determined in accordance with the parameters described under “24.2 System Exclusive Protocol Parameter”.

22.2.1 Example: Sending Data from the Instrument to an External Device in Response

to a Request from the External Device

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(OBR) -----> Session Start

Request

Interval 1 *Note1

OBR -----> Send Request (Start

Sub Session)

<----- OBS Send Packet

Interval 2 *Note2

<----- OBS Send Packet

Interval 2 *Note2

<----- OBS Send Packet

Send Other Packet

<----- ESS End of Data (End

Sub Session)

Other Sub Session

EBS -----> End of Session

Note1 : Interval 1 is no less than Oneway Min Interval and no more than Oneway Max Interval, which are explained under

“24.2 System Exclusive Protocol Parameter”. If the interval exceeds these values, the partner device will issue a timeout error.

Note2 : Interval 1 is a Oneway Current Interval, which is explained under “24.2 System Exclusive Protocol Parameter”.

22.2.2 Example: Data send to Instrument from external device

Data Sender Data Receiver Operation

(External Device) (This Instrument)

SBS(OBS) -----> Session Start

Request

Interval *Note

OBS -----> Send Packet (Start

Sub Session)

Interval *Note

OBS -----> Send Packet

Interval *Note

OBS -----> Send Packet

Interval *Note

Send Other Packet

ESS ----->

<----- ACK End Sub Session

Other Sub Session

EBS -----> End of Session

Note : The interval is no less than Oneway Min Interval and less than Oneway Max Interval, which are explained under

“24.2 System Exclusive Protocol Parameter”. If the interval exceeds these values, the partner device will issue a timeout error.

22.3 Handshake Mode Communication Flow

22.3.1 Session Start

A single session starts when an external device, which wants to start communication for sending or receiving data using handshake protocol, sends an SBS (Start of Bulk Dump Session) message to this Instrument, which is its communication partner. The external device cannot send an HBS or HBR until this Instrument receives ACK.

22.3.2 Message Timeout Processing

Failure of the next message expected for receipt to arrive within a preset amount of time is viewed as a timeout error, and ERR (Data = Time Out Error) is sent to the partner device, which then returns to the message standby state. The device that received the ERR sends the message it believes the partner device that is in the message receive standby state. If the desired message does not arrive after a preset number of retries, RJC is sent and the session is terminated. The standby time and number of retries are determined in accordance with the parameters described under “24.2 System Exclusive Protocol Parameter”.

22.3.3 Message Format Error Processing

The message receive device returns ERR (Format Error) if it discovers an illegal format in the received message. When the message sending device receives ERR (Format Error) from the receiving device,

it resends the last data sent. If the correct message does not arrive after a preset number of retries, RJC is sent and the session is terminated. The number of retries is determined in accordance with the parameters described under “24.2 System Exclusive Protocol Parameter”.

22.3.4 Message CRC Error Processing

The message receive device returns ERR (CRC Error) if it discovers an illegal format in the received message. When the sending device receives ERR (CRC Error) from the receiving device, it resends the last data sent. If the correct CRC message does not arrive after a preset number of retries, RJC is sent and the session is terminated. The number of retries is determined in accordance with the parameters described under “24.2 System Exclusive Protocol Parameter”.

22.3.5 Processing when Multiple Errors are Generated

While communication retry is in progress following generation of a timeout error, format error, or CRC error, the retry count is not reset even if another error is generated. Also the error code of the last send error message is determined by the cause of the last error generated.

22.3.6 Session End

When the data send device is an external device, the session is concluded when the external device sends ESS and EBS in response to an ACK by this Instrument after the external device ﬁnishes sending all of the Parameter Sets that need to be transferred. When the data send device is an this Instrument, the session is concluded when the external device sends EBS after this Instrument ﬁnishes sending all of the Parameter Sets that need to be transferred. The maximum interval until one device sends a message following receipt of a message from another device is no greater than the Handshake Max Interval explained under “24.2 System Exclusive Protocol Parameter”. If the interval exceeds these values, the partner device will issue a timeout error.

22.3.7 Example: Sending Data from the Instrument to an External Device in Response

to a Request from the External Device

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(HBR) -----> Session Start

Request

<----- ACK Acknowledge

HBR -----> Send Request (Start

Sub Session)

<----- HBS Send Packet

ACK -----> Acknowledge

<----- HBS Send Packet

ACK -----> Acknowledge

<----- HBS Send Packet

ACK -----> Acknowledge

Send Other Packet

ACK -----> Acknowledge

<----- ESS End Data (End Sub

Session)

Other Sub Session

EBS -----> End of Session

22.3.8 Example: Data send to Instrument from external device

Data Sender Data Receiver Operation

(External Device) (This Instrument)

SBS(HBS) -----> Session Start

Request

<----- ACK Acknowledge

HBS -----> Send Packet

<----- ACK Acknowledge

HBS -----> Send Packet

<----- ACK Acknowledge

HBS -----> Send Packet

<----- ACK Acknowledge

Send Other Packet

ESS -----> End of Data

Other Sub Session

EBS -----> End of Session

22.3.9 Example: Session Generating a Timeout Error

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(HBR) -----> Session Start

Request

Interval *Note1

ERR(Time Out Error) -----> Timeout Error

<----- ACK Acknowledge

HBR -----> Send Request

(Optional)

<----- HBS Send Packet

ACK -----> Acknowledge

Interval *Note1

ERR(Time Out Error) -----> Timeout Error

Interval *Note1

ERR(Time Out Error) -----> 2 consecutive

timeout errors (Note2)

<----- HBS Acknowledge

Interval *Note1

<----- ERR(Time Out Error) Timeout Error

ACK -----> Acknowledge

<----- HBS Send Packet

Note1 : Interval that exceeds the time stipulated by Handshake Max Interval explained under “24.2 System Exclusive

Protocol Parameter”.

Note2 : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “24.2 System

Exclusive Protocol Parameter”.

22.3.10 Example: Session Generating a Format Error

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(HBR) -----> Session Start Request

<----- ACK Acknowledge

HBR -----> Send Request

(Optional)

<----- HBS Send Packet

ACK -----> Acknowledge

<-???- HBS Send Packet (Note1)

ERR(Format Error) -----> Format Error

<----- HBS Resend Packet

ACK -???-> Acknowledge

<----- ERR(Format Error) Format Error

ACK -???-> Acknowledge

<----- ERR(Format Error) 2 consecutive format

errors(*Note2)

ACK -----> Acknowledge

<----- HBS Send Packet

Note1 : “<-???-” or “-???->” indicates transfer failed.

Note2 : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “24.2 System

Exclusive Protocol Parameter”.

22.3.11 Example: Session Generating a CRC Error

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(HBR) -----> Session Start Request

<----- ACK Acknowledge

HBR -----> Send Request

(Optional)

<----- HBS Send Packet

ACK -----> Acknowledge

<-???- HBS Send Packet

ERR(CRC Error) -----> CRC error

<-???- HBS Resend Packet

ERR(CRC Error) -----> 2 consecutive CRC

errors(*Note)

<----- HBS Resend Packet

ACK -----> Acknowledge

<----- HBS Send Packet

Note : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “24.2 System

Exclusive Protocol Parameter”.

22.3.12 Example: Session Termination by Error Generation

Data Receiver Data Sender Operation

SBS(HBR) -----> Session Start Request

<----- ACK Acknowledge

HBR -----> Send Request

(Optional)

<----- HBS Send Packet

ACK -----> Acknowledge

<-???- HBS Send Packet

ERR(CRC Error) -----> Error

<-???- HBS Resend Packet

ERR(Format Error) -----> 2 consecutive errors

<-???- HBS Resend Packet

ERR(Time Out Error) -----> 3 consecutive errors

<-???- HBS Resend Packet

ERR(CRC Error) -----> N consecutive

errors(*Note)

<-???- HBS Resend Packet

RJC -----> Abandon Session

Note : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “24.2 System

Exclusive Protocol Parameter”. Also, the maximum number of retries is the same, even if multiple instances of the same error are

generated or if multiple diﬀerent errors are generated.

22.3.13 Example: Intentional Session Termination by an External Device

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(HBR) -----> Session Start Request

<----- ACK Acknowledge

HBR -----> Send Request

<----- HBS Send Packet

ACK -----> Acknowledge

<----- HBS Send Packet

ACK -----> Acknowledge

<----- HBS Send Packet

RJC -----> Terminate Session

22.3.14 Example: Intentional Session Termination by This Instrument

Data Sender Data Receiver Operation

(External Device) (This Instrument)

SBS(HBS) -----> Session Start Request

<----- ACK Acknowledge

HBS -----> Send Packet

<----- ACK Acknowledge

HBS -----> Send Packet

<----- ACK Acknowledge

HBS -----> Send Packet

<----- RJC Terminate Session

22.3.15 Example: Session Pause

Session ﬂow when the session is temporarily paused for some reason and then restarted is shown below. A session can be paused by sending an EXI message from an external device or this Instrument to the other device.

Data Receiver Data Sender Operation

(External Device) (This Instrument)

SBS(HBR) -----> Session Start

Request

<----- ACK Acknowledge

HBR -----> Send Request

<----- HBS Send Packet

ACK -----> Acknowledge

<----- HBS Send Packet

Interval *Note1

EXI -----> Extend Interval

(Pause Session)

Interval *Note1

EXI -----> Extend Interval

Interval *Note1

ACK -----> Acknowledge

(Restart Session)*Note2

<----- HBS Send Packet

ESS -----> End of Data

Other Sub Session

EBS -----> End of Session

Note1 : Interval less than the time stipulated by Handshake Max Interval explained under “24.2 System Exclusive Protocol

Parameter”. There is no limit on the number of extensions using EXI.

Note2 : The sessions can be paused by sending RJC here.

Part V

Parameter List

This section explains the parameters that actually can be transferred by the Instrument.

23 Using the Parameter List

• Parameter ﬁeld

Shows the parameter name.

• ID ﬁeld

Shows the parameter ID as a hexadecimal number.

• R/W ﬁeld

Shows “R” to indicate that an IPR (Individual Parameter Request) read operation (Read) is possible or “W” to indicate that an IPS (Individual Parameter Send) write operation is possible.

• Block ﬁeld

Shows the bit ﬁeld allo cation of the block number. The bit ﬁeld position is shown as a decimal format number.

• Size ﬁeld

Shows the parameter bit width as a decimal format value.

• Array ﬁeld

Shows the parameter array size as a hexadecimal value.

• Min-Def-Max ﬁeld

Shows the minimum value, default value, and maximum value for parameter acquisition as a hexadecimal value.

• Description ﬁeld

Explains the meaning of parameter values. Unless otherwise speciﬁed, setting values are all indicated in decimal format.

24 System Parameters

These parameters make it possible for an external device to check the status of the Instrument and for an external device to command some operation of the Instrument.

24.1 System Information Parameter

This parameter is a container for system information.

Parameter ID R/W Block Size Array Min-Def-Max Description

Model Name 0000 R 00000000 7 08 00-20-7F Ascii Character

General Register 000D R/W ↑ 8 01 00-00-FF General-purpose register for communication test

CTK-6000..."CTK-6000" CTK-7000..."CTK-7000"

WK-6500...."WK-6500 "

WK-7500...."WK-7500 "

AT-3......."AT-3 "

AT-5......."AT-5 "

24.2 System Exclusive Protocol Parameter

These parameters are related to the System Exclusive message protocol.

Parameter ID R/W Block Size Array Min-Def-Max Description

Oneway Min Interval 000E R 00000000 14 01 0000-0014-3FFF Minimum time interval time value (msec)

Oneway Max Interval 000F R/W ↑ 14 01 0000-0800-3FFF Maximum allowable message wait time

Oneway Current Interval 0010 R/W ↑ 14 01 0000-0014-3FFF Current time interval value between

Oneway Max Data Length 0011 R ↑ 14 01 0000-0080-3FFF Maximum memory size value (bytes) of

Oneway Curent Data Length 0012 R/W ↑ 14 01 0000-0080-3FFF Current memory size value (bytes) of

Handshake Max Interval 0013 R/W ↑ 14 01 0000-0800-3FFF Maximum allowable message wait time

Handshake Max Data Length 0014 R ↑ 14 01 0000-0080-3FFF Maximum memory size value (bytes) of

Handshake Currnet Data Length 0015 R/W ↑ 14 01 0000-0080-3FFF Maximum memory size value (bytes) of

Handshake Retry Number 0016 R/W ↑ 7 01 00-03-7F Number of retries after error generation

between packets during One-way Bulk Dump receive by Instrument

(msec) during One-way Bulk Dump receive by Instrument

packets during One-way Bulk Dump send by Instrument

transfer data included in one packet during One-way Bulk Dump send/receive by Instrument

transfer data included in one packet during One-way Bulk Dump send by Instrument

(msec) during Handshake Bulk Dump receive by Instrument

transfer data included in one packet during Handshake Bulk Dump send/receive by Instrument

transfer data included in one packet during Handshake Bulk Dump send by Instrument

during Handshake Bulk Dump send

24.3 Data Management Parameter

These are information acquisition and operation command parameters for this Instrument’s Data Manager PC application.

Parameter ID R/W Block Size Array Min-Def-Max Description

Ps Category 0019 W 00000000 7 01 00-00-7F Specifiesthe category ID of the

Ps Memory 001A W ↑ 7 01 00-00-7F Specifies the memory ID of the

Ps Number 001B W ↑ 14 01 0000-0001-3FFF Specifies the number of the parameter

Ps Data Type 001C R ↑ 8 01 00-00-FF This the data type of the parameter

Current Ps Existence 001D R ↑ 1 01 00-00-01 Whether a parameter set exists in the

Current Ps Protect 001E R ↑ 1 01 00-00-01 Protect status of a parameter set data

Current Ps Size 001F R ↑ 32 01 00000000-00000000-FFFFFFFF Size of a parameter set in the

Current Sub Ps Size 0020 R ↑ 32 01 00000000-00000000-FFFFFFFF 00000000-00000000-FFFFFFFF Total size

Current Ps Name 0021 R ↑ 8 10 00-20-7F Name of a parameter set in the

Max Ps Size 0022 R ↑ 32 01 00000000-00000000-FFFFFFFF Maximum size of parameter sets in the

Max Ps Number 0023 R ↑ 14 01 0000-0000-FFFF Maximum number parameter sets in the

Area Size 0024 R ↑ 32 01 00000000-00000000-FFFFFFFF Maximum size (bytes) of parameter sets

Available Size 0025 R ↑ 32 01 00000000-00000000-FFFFFFFF Maximum size (bytes) writable to

Free Size 0026 R ↑ 32 01 00000000-00000000-FFFFFFFF Current size (bytes) of parameter set

Delete Ps 0027 W ↑ 1 01 00-00-01 Deletes parameter sets in the

parameter set that corresponds to an operation.

set that corresponds to an operation.

set in the specified category. Compatibility is providedbetween

models with the same type.

specified category.

0...No

1...Yes

in the specified category.

0...Off

1...On

specified category/number (bytes).

of a parameter sets under the specified category (bytes).

specified category (ASCII characters).

specified category (bytes).

in specified category

parameter sets in specified category/number

free space in specified category

specified category. Values are ignored.

25 Patch Parameter

The main function of patch parameters is to conﬁgure the settings of the sound source of a device.

25.1 Analog Input Tune Parameter

These parameters are for analog input tuning. They correspond to the MIC part of the Instrument’s mixer function (CTK-6000, WK-6500) or to the EXT part (CTK-7000, WK-7500, AT-3, AT-5).

Parameter ID R/W Block Size Array Min-Def-Max Description

Part Enable 0074 R/W 00000000 1 01 00-01-01 0...Off

Line Select 0075 R/W ↑ 1 01 00-00-01 0...System Chorus

Level 0076 R/W ↑ 7 01 00-64-7F 0 - 127 Pan 0077 R/W ↑ 7 01 00-40-7F 0 - 127 Rev Send 0078 R/W ↑ 7 01 00-00-7F 0 - 127 Cho Dsp Send 0079 R/W ↑ 7 01 00-00-7F 0 - 127 Noise Gate Threshold 007A R/W ↑ 7 01 00-14-7F (CTK-7000, WK-7500, AT-3, AT-5 only)

Noise Gate Release 007B R/W ↑ 7 01 00-40-7F (CTK-7000, WK-7500, AT-3, AT-5 only)

Auto Level Control 007C R/W ↑ 2 01 00-00-03 (CTK-7000, WK-7500, AT-3, AT-5 only)

1...On

1...DSP

0 - 127

0..Off

1..1

2..2

3..3

25.2 Card Audio Parameter

These parameters conﬁgure card audio output settings (CTK-7000, WK-7500, AT-3, AT-5 only).

Parameter ID R/W Block Size Array Min-Def-Max Description

Level 0081 R/W 00000000 7 01 00-7F-7F 0 - 127

25.3 DSP Output Parameter

These parameters conﬁgure DSP output settings.

Parameter ID R/W Block Size Array Min-Def-Max Description

Part Enable 007D R/W 00000000 1 01 00-01-01 0...Off

Level 007E R/W ↑ 7 01 00-64-7F 0 - 127 Pan 007F R/W ↑ 7 01 00-40-7F 0 - 127 Rev Send 0080 R/W ↑ 7 01 00-20-7F 0 - 127

1...On

25.4 DSP Setup Parameter

These parameters conﬁgure DSP enable/disable and type settings.

Parameter ID R/W Block Size Array Min-Def-Max Description

Disable 0082 R/W 00000000 1 01 00-00-01 0...enable DSP operation

Number 0083 R/W 00000000 8 01 00-00-C8 0.........Tone Dsp

1...disable DSP operation

1-100.....Preset Dsp

101-200...User Dsp

25.5 Master Tune Parameter

These parameters conﬁgure the Master Tuning settings.

Parameter ID R/W Block Size Array Min-Def-Max Description

Master Fine Tune 0000 R/W 00000000 10 01 0000-0200-03FF -100/512 - 0 - 100/512(cent) Master Coarse Tune 0001 R/W ↑ 7 01 28-40-58 -24 - 0 - +24(semitone)

25.6 Master Mixer Parameter

These parameters conﬁgure the Master settings of the mixer.

Parameter ID R/W Block Size Array Min-Def-Max Description

Master Volume 0002 R/W 00000000 7 01 00-7F-7F 0 - 127 Master Pan 0003 R/W ↑ 7 01 00-40-7F -64 - 0 - +63 Master Line Select 0004 R/W ↑ 1 01 00-00-01 0...System Chorus

1...DSP

25.7 Part Parameter

Part parameters conﬁgure the settings of each musical instrument part.

Parameter ID R/W Block Size Array Min-Def-Max Description

Part Enable 0068 R/W 4-0:Part # 1 01 00-01-01 0...Off

Scaletune Enable 0069 R/W ↑ 1 01 00-01-01 0...Disable

Tone Num 006A R/W ↑ 14 01 0000-0000-3FFF 0 - 16383 Fine Tune 006B R/W ↑ 10 01 0000-0200-03FF -100/512 - 0 - 100/512(cent) Coarse Tune 006C R/W ↑ 7 01 28-40-58 -24 - 0 - +24(semitone) Volume 006D R/W ↑ 7 01 00-64-7F 0 - 127 Acmp Volume 006E R/W ↑ 7 01 00-7F-7F 0 - 127 Pan 006F R/W ↑ 7 01 00-40-7F -64 - 00 - +63 Cho Send 0070 R/W ↑ 7 01 00-00-7F 0 - 127 Rev Send 0071 R/W ↑ 7 01 00-28-7F 0 - 127 Bend Range 0072 R/W ↑ 7 01 00-02-18 0 - 24 Line Select 0073 R/W ↑ 1 01 00-00-01 0...System Chorus

1...On

1...Enable

1...DSP

26 Tone Parameter

These parameters conﬁgure tone settings.

26.1 Drawbar Parameter

These parameters conﬁgure drawbar organ settings (CTK-7000, WK-7500 only).

Parameter ID R/W Block Size Array Min-Def-Max Description

Position 001E R/W 3-0:Select Bar 2 01 00-00-03 0-3 Percussion 001F R/W 00000000 2 01 00-00-03 0...off

Percussion Decay Time 0020 R/W ↑ 7 01 00-00-7F 0-127 Click 0021 R/W ↑ 1 01 00-00-01 0...off

Type 0022 R/W ↑ 1 01 00-00-01 0...Normal

1...2nd

2...3rd

3...2nd+3rd

1...on

1...Vintage

26.2 Tone Parameter

These parameters conﬁgure settings of tone basic settings.

Parameter ID R/W Block Size Array Min-Def-Max Description

Attack Time 0008 R/W 00000000 7 01 00-40-7F -64 - 0 - 63 Release Time 0009 R/W ↑ 7 01 00-40-7F -64 - 0 - 63 Cutoff Freq 000A R/W ↑ 7 01 00-40-7F -64 - 0 - 63 Vibrato Type 000B R/W ↑ 7 01 00-00-03 0...Sine

Vibrato Depth 000C R/W ↑ 7 01 00-40-7F -64 - 0 - 63 Vibrato Speed 000D R/W ↑ 7 01 00-40-7F -64 - 0 - 63 Vibrato Delay 000E R/W ↑ 7 01 00-40-7F -64 - 0 - +63 Octave Shift 000F R/W ↑ 7 01 3E-40-42 -2 - 0 - +2 Volume 0010 R/W ↑ 7 01 00-7F-7F 0-127 Touch Sense 0011 R/W ↑ 7 01 00-7F-7F -64 - 0 - 63 Reverb Send 0012 R/W ↑ 7 01 00-28-7F 0-127 Chorus Send 0013 R/W ↑ 7 01 00-00-7F 0-127

1...Triangle

2...Saw

3...Square

26.3 Modulation Setting Parameter

These parameters conﬁgure modulation button settings (CTK-7000, WK-7500, AT-3, AT-5 only).

Parameter ID R/W Block Size Array Min-Def-Max Description

Type 001C R/W 00000000 1 01 00-00-01 0...Modulation

Depth 001D R/W ↑ 7 01 00-40-7F 0-127

1...DSP

27 Scale Memory Parameter

27.1 Scale Memory Octave

Scale memory parameters store scale memory data (AT-3, AT-5 only).

Parameter ID R/W Block Size Array Min-Def-Max Description

Tune 0000 R/W 3-0: Note # 16 01 7E00-8000-81FF -100/512 - 0 - 100/512(cent)

Onoff 0001 R/W ↑ 1 01 00-00-01 Scale Button

Block: Note #

0....C

1....C#

2....D

3....D#

4....E

5....F

6....F#

7....G

8....G#

9....A

10...A#

11...B

0...Off

1...On

28 DSP Parameter

28.1 DSP Basic

These parameters store DSP data.

Parameter ID R/W Block Size Array Min-Def-Max Description

Name 0000 R/W 00000000 7 10 00-20-7F Ascii Character Rev Send 0001 R/W ↑ 7 01 00-28-7F 0 - 127 Algorithm 0002 R/W ↑ 14 01 0000-000A-3FFF ID

Parameter7 0003 R/W ↑ 7 08 00-40-7F 0 - 127 Rotary Sw Onoff 0004 R/W ↑ 1 01 00-00-01 0...Off

Parameter Index 0005 R/W 0:Button Selection 4 01 00-00-08 0.....No Assign

On Value 0006 R/W ↑ 7 01 00-00-7F 0 - 127 Off Value 0007 R/W ↑ 7 01 00-00-7F 0 - 127

Note1 : For details about the relationship between the Algorithm ID and the DSP Type Number, see “34 DSP Type List”.

(Note1)

1...On

1-8...Parameter 1-8 Block: Button Selection

0...Modulation Button(CTK-7000, WK-7500, AT-3, AT-5 only)

1...Rotary Slow/Fast Button(CTK-7000, WK-7500 only)

29 All Data Parameter

29.1 All Directory Info

The All data parameter stores all data directory information.

Parameter ID R/W Block Size Array Min-Def-Max Description

Size 0001 R 000000 32 01 00000000-00000000-00FFFFFF 0 - 0xFFFFFFFF

30 Sequence Parameter

30.1 Sequence Directory Info

The sequence parameter stores recorder song directory information.

Parameter ID R/W Block Size Array Min-Def-Max Description

Size 0001 R 000000 32 01 00000000-00000000-00FFFFFF 0 - 0xFFFFFFFF

31 Registration Parameter

31.1 Registration Directory Info

The registration parameter stores registration data directory information.

Parameter ID R/W Block Size Array Min-Def-Max Description

Size 0001 R 000000 32 01 00000000-00000000-00FFFFFF 0 - 0xFFFFFFFF

32 Rhythm Parameter

32.1 Rhythm Directory Info

The rhythm parameter stores rhythm directory information.

Parameter ID R/W Block Size Array Min-Def-Max Description

Name 0000 R 00000000 7 10 20-20-7F Ascii Character Size 0002 R ↑ 32 01 00000000-00000000-00FFFFFF 0 - 0xFFFFFFFF

Part VI

Parameter Set List

This section explains actually how parameter sets can be transferred by the Instrument with bulk dump.

33 Parameter Set Table

Field Contents

• cat ﬁeld

Shows the category value.(Note1)

• mem ﬁeld

Shows the memory area ID value.(Note1)

• pset ﬁeld

Shows the parameter set number value. Applicable parameter set numbers are those in the user area where the top number is zero, and are not the same numbers as those displayed by the Instrument. (Note1)

Note1 : Operation is not guaranteed for values other than those noted here.

33.1 CTK-6000/WK-6500

Parameter Set Category cat mem pset description

Tone 03H 02H 0000H - 0009H (User Tone 1 - 10)

DSP 13H 02H 0000H - 0063H (User DSP 101 - 200)

All 1FH 02H 0000H - 000AH (All Data)

Sequence 21H 02H 0000H - 0004H (Song Sequencer 1 - 5)

Registration 22H 02H 0000H (Registration)

Rhythm 24H 02H 0000H - 0009H (User Rhythm 1 - 10)

Music Preset 25H 02H 0000H - 0031H (User Preset 1 - 50)

33.2 CTK-7000/WK-7500

Parameter Set Category cat mem pset description

Tone 03H 02H 0000H - 0063H (User Tone 1 - 100)

02H 0064H - 0095H (User Drawbar 1 - 50)

DSP 13H 02H 0000H - 0063H (User DSP 101 - 200)

All 1FH 02H 0000H - 0037H (All Data)

Sequence 21H 02H 0000H - 0004H (Song Sequencer 1 - 5)

Registration 22H 02H 0000H (Registration)

Rhythm 24H 02H 0000H - 0063H (User Rhythm 1 - 100)

Music Preset 25H 02H 0000H - 0063H (User Preset 1 - 100)

33.3 AT-3/AT-5

Parameter Set Category cat mem pset description

Tone 03H 02H 0000H - 0063H (User Tone 1 - 100)

Scale Memory 12H 02H 0000H (User Scale Memory)

DSP 13H 02H 0000H - 0063H (User DSP 101 - 200)

All 1FH 02H 0000H - 0037H (All Data)

Sequence 21H 02H 0000H - 0004H (Song Sequencer 1 - 5)

Registration 22H 02H 0000H (Registration)

Rhythm 24H 02H 0000H - 0063H (User Rhythm 1 - 100)

Music Preset 25H 02H 0000H - 0063H (User Preset 1 - 100)

Part VII

DSP Parameter List

34 DSP Type List

This is a list of DSP types built into the Instrument.

34.1 Single DSP

Number ID Type

01 01H Wah 02 02H Compressor 03 03H Distortion 04 04H Enhancer 05 05H Pan 06 06H Tremolo 07 07H Phaser 08 08H Flanger 09 09H Chorus 10 0AH Delay 11 0BH Reﬂection 12 0CH Rotary 13 0DH RingModulator 14 0EH LoFi

34.2 Dual DSP

Number ID Type

15 41H Wah-Comp 16 42H Wah-Dist 17 43H Wah-Cho 18 44H Wah-Flan 19 45H Wah-Ref 20 46H Wah-Trem 21 47H Wah-Pan 22 48H Comp-Wah 23 49H Comp-Dist 24 4AH Comp-Cho 25 4BH Comp-Flan 26 4CH Comp-Ref 27 4DH Comp-Trem 28 4EH Comp-Pan 29 50H Dist-Wah 20 51H Dist-Comp 31 53H Dist-Cho 32 54H Dist-Flan 33 55H Dist-Ref 34 56H Dist-Trem 35 57H Dist-Pan 36 5DH Cho-Ref 37 5FH Cho-Pan 38 65H Flan-Ref 39 67H Flan-Pan 30 6AH Ref-Dist 41 6BH Ref-Cho 42 6FH Ref-Pan 43 72H Trem-Dist 44 73H Trem-Cho 45 74H Trem-Flan 46 75H Trem-Ref

35 DSP Parameter Set Type

35.1 Wah

Parameter Number Parameter Name Value Notes

Parameter7[1] Resonance 00 - 7F

Parameter7[2] Manual 00 - 7F

Parameter7[3] LFO Rate 00 - 7F

Parameter7[4] LFO Depth 00 - 7F

Parameter7[5] LFOWvform 00 - 7F Note1

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.2 Compressor

Parameter Number Parameter Name Value Notes

Parameter7[1] Attack 00 - 7F

Parameter7[2] Release 00 - 7F

Parameter7[3] Level 00 - 7F

Parameter7[4] Threshold 00 - 7F

35.3 Distortion

Parameter Number Parameter Name Value Notes

Parameter7[1] Gain 00 - 7F

Parameter7[2] Level 00 - 7F

35.4 Enhancer

Parameter Number Parameter Name Value Notes

Parameter7[1] Low Freq 00 - 7F

Parameter7[2] Low Phase 00 - 7F

Parameter7[3] High Freq 00 - 7F

Parameter7[4] HighPhase 00 - 7F

35.5 Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] LFO Rate 00 - 7F

Parameter7[2] LFO Depth 00 - 7F

Parameter7[3] LFOWvform 00 - 7F Note1

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.6 Tremolo

Parameter Number Parameter Name Value Notes

Parameter7[1] LFO Rate 00 - 7F

Parameter7[2] LFO Depth 00 - 7F

Parameter7[3] LFOWvform 00 - 7F Note1

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.7 Phaser

Parameter Number Parameter Name Value Notes

Parameter7[1] Resonance 00 - 7F

Parameter7[2] LFO Rate 00 - 7F

Parameter7[3] LFO Depth 00 - 7F

Parameter7[4] LFOWvform 00 - 7F Note1

Note1 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.8 Flanger

Parameter Number Parameter Name Value Notes

Parameter7[1] LFO Rate 00 - 7F

Parameter7[2] LFO Depth 00 - 7F

Parameter7[3] LFOWvform 00 - 7F Note1

Parameter7[4] Feedback 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.9 Chorus

Parameter Number Parameter Name Value Notes

Parameter7[1] LFO Rate 00 - 7F

Parameter7[2] LFO Depth 00 - 7F

Parameter7[3] LFOWvform 00 - 7F Note1

Parameter7[4] Feedback 00 - 7F

Parameter7[5] Type 00 - 7F Note2

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.14 Chorus Mode

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.10 Delay

Parameter Number Parameter Name Value Notes

Parameter7[1] DelayTime 00 - 7F

Parameter7[2] Feedback 00 - 7F

Parameter7[3] Ratio Lch 00 - 7F

Parameter7[4] Ratio Rch 00 - 7F

Parameter7[5] Wet Level 00 - 7F Note1

Parameter7[6] Type 00 - 7F Note2

Note1 : For information about the relationship between setting values and send/receive values, see “36.15 Delay Level

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.16 Delay Type

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.11 Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] Type 00 - 7F Note1

Parameter7[2] Feedback 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.21 Reﬂection Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.12 Rotary

Parameter Number Parameter Name Value Notes

Parameter7[1] Od Gain 00 - 7F Note1

Parameter7[2] Od Level 00 - 7F

Parameter7[3] Speed 00 - 7F Note2

Parameter7[4] Brake 00 - 7F Note3

Parameter7[5] FallAccel 00 - 7F

Parameter7[6] RiseAccel 00 - 7F

Parameter7[7] Slow Rate 00 - 7F

Parameter7[8] Fast Rate 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.12 0-3 Setting Value

Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.24 Slow/Fast Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note3 : For information about the relationship between setting values and send/receive values, see “36.23 Rotate/Brake

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.13 Ring Modulator

Parameter Number Parameter Name Value Notes

Parameter7[1] OSC Freq 00 - 7F

Parameter7[2] LFO Rate 00 - 7F

Parameter7[3] LFO Depth 00 - 7F

Parameter7[4] Type 00 - 7F Note1

Note1 : For information ab out the relationship between setting values and send/receive values, see “36.22 Ring Type Setting

Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.14 LoFi

Parameter Number Parameter Name Value Notes

Parameter7[1] WF Rate 00 - 7F

Parameter7[2] WF Depth 00 - 7F

Parameter7[3] Nz1 Level 00 - 7F Note1

Parameter7[4] Nz2 Level 00 - 7F Note2

Parameter7[5] Density 00 - 7F Note3

Parameter7[6] Bit 00 - 7F Note4

Note1 : For information about the relationship between setting values and send/receive values, see “36.20 LoFi Noise Level

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.20 LoFi Noise Level

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note3 : For information about the relationship between setting values and send/receive values, see “36.13 0-5 Setting Value

Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note4 : For information about the relationship between setting values and send/receive values, see “36.12 0-3 Setting Value

Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.15 Wah Compressor

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] CmpThresh 00 - 7F

Parameter7[5] Cmp Level 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.16 Wah Distortion

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] Dst Gain 00 - 7F

Parameter7[5] Dst Level 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.17 Wah Chorus

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] ChoWvform 00 - 7F Note2

Parameter7[5] Cho Rate 00 - 7F

Parameter7[6] Cho Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.18 Wah Flanger

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] FlnWvform 00 - 7F Note2

Parameter7[5] Fln Rate 00 - 7F

Parameter7[6] Fln Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.19 Wah Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] Ref Fbk 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.20 Wah Tremolo

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] TrmWvform 00 - 7F Note2

Parameter7[5] Trm Rate 00 - 7F

Parameter7[6] Trm Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.21 Wah Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] WahWvform 00 - 7F Note1

Parameter7[2] Wah Rate 00 - 7F

Parameter7[3] Wah Depth 00 - 7F

Parameter7[4] PanWvform 00 - 7F Note2

Parameter7[5] Pan Rate 00 - 7F

Parameter7[6] Pan Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.22 Compressor Wah

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] WahWvform 00 - 7F Note1

Parameter7[4] Wah Rate 00 - 7F

Parameter7[5] Wah Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.23 Compressor Distortion

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] Dst Gain 00 - 7F

Parameter7[4] Dst Level 00 - 7F

35.24 Compressor Chorus

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] ChoWvform 00 - 7F Note1

Parameter7[4] Cho Rate 00 - 7F

Parameter7[5] Cho Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.25 Compressor Flanger

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] FlnWvform 00 - 7F Note1

Parameter7[4] Fln Rate 00 - 7F

Parameter7[5] Fln Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.26 Compressor Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] Ref Fbk 00 - 7F

35.27 Compressor Tremolo

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] TrmWvform 00 - 7F Note1

Parameter7[4] Trm Rate 00 - 7F

Parameter7[5] Trm Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.28 Compressor Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] CmpThresh 00 - 7F

Parameter7[2] Cmp Level 00 - 7F

Parameter7[3] PanWvform 00 - 7F Note1

Parameter7[4] Pan Rate 00 - 7F

Parameter7[5] Pan Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.29 Distortion Wah

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] WahWvform 00 - 7F Note1

Parameter7[4] Wah Rate 00 - 7F

Parameter7[5] Wah Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.17 LFO Wave Form1

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.30 Distortion Compressor

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] CmpThresh 00 - 7F

Parameter7[4] Cmp Level 00 - 7F

35.31 Distortion Chorus

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] ChoWvform 00 - 7F Note1

Parameter7[4] Cho Rate 00 - 7F

Parameter7[5] Cho Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.32 Distortion Flanger

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] FlnWvform 00 - 7F Note1

Parameter7[4] Fln Rate 00 - 7F

Parameter7[5] Fln Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.33 Distortion Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] Ref Fbk 00 - 7F

35.34 Distortion Tremolo

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] TrmWvform 00 - 7F Note1

Parameter7[4] Trm Rate 00 - 7F

Parameter7[5] Trm Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.35 Distortion Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] Dst Gain 00 - 7F

Parameter7[2] Dst Level 00 - 7F

Parameter7[3] PanWvform 00 - 7F Note1

Parameter7[4] Pan Rate 00 - 7F

Parameter7[5] Pan Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.36 Chorus Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] ChoWvform 00 - 7F Note1

Parameter7[2] Cho Rate 00 - 7F

Parameter7[3] Cho Depth 00 - 7F

Parameter7[4] Ref Fbk 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.37 Chorus Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] ChoWvform 00 - 7F Note1

Parameter7[2] Cho Rate 00 - 7F

Parameter7[3] Cho Depth 00 - 7F

Parameter7[4] PanWvform 00 - 7F Note2

Parameter7[5] Pan Rate 00 - 7F

Parameter7[6] Pan Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.38 Flanger Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] FlnWvform 00 - 7F Note1

Parameter7[2] Fln Rate 00 - 7F

Parameter7[3] Fln Depth 00 - 7F

Parameter7[4] Ref Fbk 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.39 Flanger Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] FlnWvform 00 - 7F Note1

Parameter7[2] Fln Rate 00 - 7F

Parameter7[3] Fln Depth 00 - 7F

Parameter7[4] PanWvform 00 - 7F Note2

Parameter7[5] Pan Rate 00 - 7F

Parameter7[6] Pan Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.40 Reﬂection Distortion

Parameter Number Parameter Name Value Notes

Parameter7[1] Ref Fbk 00 - 7F

Parameter7[2] Dst Gain 00 - 7F

Parameter7[3] Dst Level 00 - 7F

35.41 Reﬂection Chorus

Parameter Number Parameter Name Value Notes

Parameter7[1] Ref Fbk 00 - 7F

Parameter7[2] ChoWvform 00 - 7F Note1

Parameter7[3] Cho Rate 00 - 7F

Parameter7[4] Cho Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.42 Reﬂection Pan

Parameter Number Parameter Name Value Notes

Parameter7[1] Ref Fbk 00 - 7F

Parameter7[2] PanWvform 00 - 7F Note1

Parameter7[3] Pan Rate 00 - 7F

Parameter7[4] Pan Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.43 Tremolo Distortion

Parameter Number Parameter Name Value Notes

Parameter7[1] TrmWvform 00 - 7F Note1

Parameter7[2] Trm Rate 00 - 7F

Parameter7[3] Trm Depth 00 - 7F

Parameter7[4] Dst Gain 00 - 7F

Parameter7[5] Dst Level 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.44 Tremolo Chorus

Parameter Number Parameter Name Value Notes

Parameter7[1] TrmWvform 00 - 7F Note1

Parameter7[2] Trm Rate 00 - 7F

Parameter7[3] Trm Depth 00 - 7F

Parameter7[4] ChoWvform 00 - 7F Note2

Parameter7[5] Cho Rate 00 - 7F

Parameter7[6] Cho Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.45 Tremolo Flanger

Parameter Number Parameter Name Value Notes

Parameter7[1] TrmWvform 00 - 7F Note1

Parameter7[2] Trm Rate 00 - 7F

Parameter7[3] Trm Depth 00 - 7F

Parameter7[4] FlnWvform 00 - 7F Note2

Parameter7[5] Fln Rate 00 - 7F

Parameter7[6] Fln Depth 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Note2 : For information about the relationship between setting values and send/receive values, see “36.18 LFO Wave Form2

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

35.46 Tremolo Reﬂection

Parameter Number Parameter Name Value Notes

Parameter7[1] TrmWvform 00 - 7F Note1

Parameter7[2] Trm Rate 00 - 7F

Parameter7[3] Trm Depth 00 - 7F

Parameter7[4] Ref Fbk 00 - 7F

Note1 : For information about the relationship between setting values and send/receive values, see “36.19 LFO Wave Form3

Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.

Part VIII

Setting Values and Send/ Receive Values

36 Setting Value Tables

36.1 Oﬀ/On Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH Off

7FH 40H - 7FH On

36.2 –64 - 0 - +63 Setting Value Table

Transmit Value Receive Value Parameter

00H 00H -64

: : :

40H 40H 0

: : :

7FH 7FH +63

36.3 –/+ Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH -

7FH 40H - 7FH +

36.4 Pan Setting Value Table

Transmit Value Receive Value Parameter

00H 00H Left

: : :

40H 40H Center

: : :

7FH 7FH Right

36.5 Fine Tune Setting Value Table

Transmit Value Receive Value Parameter

(LSB, MSB)

(43H, 00H) (00H, 00H) - (5FH, 00H) 415.5 Hz

(65H, 00H) (60H, 00H) - (7FH, 00H) 415.6 Hz

(07H, 01H) (00H, 01H) - (1FH, 01H) 415.7 Hz

(29H, 01H) (20H, 01H) - (3FH, 01H) 415.8 Hz

: : :

(40H, 3FH) (30H, 3FH) - (4FH, 3FH) 439.8 Hz

(60H, 3FH) (50H, 3FH) - (6FH, 3FH) 439.9 Hz

(00H, 40H) (70H, 3FH) - (1FH, 40H) 440.0 Hz

(20H, 40H) (20H, 40H) - (3FH, 40H) 440.1 Hz

(40H, 40H) (40H, 40H) - (5FH, 40H) 440.2 Hz

: : :

(54H, 7EH) (50H, 7EH) - (6FH, 7EH) 465.6 Hz

(73H, 7EH) (70H, 7EH) - (0FH, 7FH) 465.7 Hz

(11H, 7FH) (10H, 7FH) - (2FH, 7FH) 465.8 Hz

(30H, 7FH) (30H, 7FH) - (7FH, 7FH) 465.9 Hz

36.6 Scale Setting Value Table

Transmit Value Receive Value Parameter

(ssH, ttH)

(00H, 50H) (00H, 00H) - (00H, 7FH) -99 cent

(01H, 20H) (01H, 00H) - (01H, 4FH) -98

(01H, 70H) (01H, 50H) - (02H, 1FH) -97

(02H, 40H) (02H, 20H) - (02H, 7FH) -96

: : :

(40H, 00H) (3FH, 60H) - (40H, 2FH) 0

: : :

(7EH, 50H) (7EH, 40H) - (7FH, 0FH) +98

(7FH, 20H) (7FH, 10H) - (7FH, 7FH) +99

Note : An actual note is changed by 100/512 cent.

36.7 Reverb Type Setting Value Table

Transmit Value Receive Value Parameter

01H 01H Room 1

02H 02H Room 2

03H 03H Room 3

04H 04H Room 4

05H 05H Hall 1

06H 06H Hall 2

07H 07H Hall 3

08H 08H Hall 4

09H 09H Stadium 1

0AH 0AH Stadium 2

36.8 Reverb Time Setting Value Table

Transmit Value Receive Value Parameter

- 00H - 07H 0(shortest)

- 08H - 0FH 1

- 10H - 17H 2

- 18H - 1FH 3

- 20H - 27H 4

- 28H - 2FH 5

- 30H - 37H 6

- 38H - 3FH 7

- 40H - 47H 8

- 48H - 4FH 9

- 50H - 57H 10

- 58H - 5FH 11

- 60H - 67H 12

- 68H - 6FH 13

- 70H - 77H 14

- 78H - 7FH 15(longest)

36.9 Chorus Type Setting Value Table

Transmit Value Receive Value Parameter

01H 01H Chorus 1

02H 02H Chorus 2

03H 03H Chorus 3

04H 04H Chorus 4

05H 05H Chorus 5

36.10 Drawbar Position Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 1FH 0

20H 20H - 3FH 1

40H 40H - 5FH 2

60H 60H - 7FH 3

36.11 Normal/Vintage Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH Normal

7FH 40H - 7FH Vintage

36.12 0-3 Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 1FH 0

2AH 20H - 3FH 1

55H 40H - 5FH 2

7FH 60H - 7FH 3

36.13 0-5 Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 14H 0

19H 15H - 29H 1

33H 2AH - 3FH 2

4CH 40H - 54H 3

66H 55H - 69H 4

7FH 6AH - 7FH 5

36.14 Chorus Mode Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 29H mono

40H 2AH - 54H stereo

7FH 55H - 7FH tri

36.15 Delay Level Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 14H 0

19H 15H - 29H 1

33H 2AH - 3FH 2

4CH 40H - 54H 3

66H 55H - 69H 4

7FH 6AH - 7FH 5

36.16 Delay Type Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH determined by Delay Time

7FH 40H - 7FH determined by Delay Time and Ratio L/R

36.17 LFO Wave Form1 Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 1FH off

2AH 20H - 3FH sin

55H 40H - 5FH tri

7FH 60H - 7FH random

36.18 LFO Wave Form2 Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 29H sin

40H 2AH - 54H tri

7FH 55H - 7FH random

36.19 LFO Wave Form3 Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH sin

7FH 40H - 7FH tri

36.20 LoFi Noise Level Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 14H 0

19H 15H - 29H 1

33H 2AH - 3FH 2

4CH 40H - 54H 3

66H 55H - 69H 4

7FH 6AH - 7FH 5

36.21 Reﬂection Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 0FH 1

12H 10H - 1FH 2

24H 20H - 2FH 3

36H 30H - 3FH 4

49H 40H - 4FH 5

5BH 50H - 5FH 6

6DH 60H - 6FH 7

7FH 70H - 7FH 8

36.22 Ring Type Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 29H ring modulated signal only

40H 2AH - 54H ring modulated signal and input signal

7FH 55H - 7FH ring modulated signal and input signal, applied chorus effect

36.23 Rotate/Brake Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH rotate

7FH 40H - 7FH stop

36.24 Slow/Fast Setting Value Table

Transmit Value Receive Value Parameter

00H 00H - 3FH slow

7FH 40H - 7FH fast

Part IX

MIDI Implementation Notation

37 Value Notation

37.1 Hexadecimal Notation

MIDI implementation sometimes requires that data be expressed in hexadecimal format. Hexadecimal values are indicated by the letter “H” after the value. The hexadecimal equivalents of decimal values 10 through 15 are expressed as the letters A through F.

The table below shows the hexadecimal equivalents for decimal values 0 through 127, which are often used in MIDI messages.

Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal

0 00H 32 20H 64 40H 96 60H 1 01H 33 21H 65 41H 97 61H 2 02H 34 22H 66 42H 98 62H 3 03H 35 23H 67 43H 99 63H 4 04H 36 24H 68 44H 100 64H 5 05H 37 25H 69 45H 101 65H 6 06H 38 26H 70 46H 102 66H 7 07H 39 27H 71 47H 103 67H 8 08H 40 28H 72 48H 104 68H

9 09H 41 29H 73 49H 105 69H 10 0AH 42 2AH 74 4AH 106 6AH 11 0BH 43 2BH 75 4BH 107 6BH 12 0CH 44 2CH 76 4CH 108 6CH 13 0DH 45 2DH 77 4DH 109 6DH 14 0EH 46 2EH 78 4EH 110 6EH 15 0FH 47 2FH 79 4FH 111 6FH 16 10H 48 30H 80 50H 112 70H 17 11H 49 31H 81 51H 113 71H 18 12H 50 32H 82 52H 114 72H 19 13H 51 33H 83 53H 115 73H 20 14H 52 34H 84 54H 116 74H 21 15H 53 35H 85 55H 117 75H 22 16H 54 36H 86 56H 118 76H 23 17H 55 37H 87 57H 119 77H 24 18H 56 38H 88 58H 120 78H 25 19H 57 39H 89 59H 121 79H 26 1AH 58 3AH 90 5AH 122 7AH 27 1BH 59 3BH 91 5BH 123 7BH 28 1CH 60 3CH 92 5CH 124 7CH 29 1DH 61 3DH 93 5DH 125 7DH 30 1EH 62 3EH 94 5EH 126 7EH 31 1FH 63 3FH 95 5FH 127 7FH

37.2 Binary Notation

When a MIDI implementation data value is expressed in binary, the letter “B” (for “binary”) is aﬃxed at the end of the value. The table below shows the binary equivalents for the decimal values 0 through 127, which are often used for settings.

Decimal Hexadecimal Binary

0 00H 00000000B

1 01H 00000001B

2 02H 00000010B

3 03H 00000011B

4 04H 00000100B

5 05H 00000101B

6 06H 00000110B

7 07H 00000111B

8 08H 00001000B

9 09H 00001001B 10 0AH 00001010B 11 0BH 00001011B 12 0CH 00001100B 13 0DH 00001101B 14 0EH 00001110B 15 0FH 00001111B 16 10H 00010000B

: :

125 7DH 01111101B 126 7EH 01111110B 127 7FH 01111111B

MA1012-A
