Page 1

Photo All-in-One

Quick Start Guide

Page 2

Getting Help from Canon

Help Us Help You Better

Before you contact Canon, please record the following information.

Serial Number (located on the inside of the product):_________________________________________

Model Number (located on the front of the product): _________________________________________

Setup CD-ROM number (located on the CD-ROM): __________________________________________

Purchase Date: ______________________________________________________________________

Customer Technical Support Sequence*

1.Internet — www.canontechsupport.com

For quick and comprehensive self-help in an intuitively guided interactive troubleshooting environment, the place to start is our helpful tech support web site. In addition, the latest driver downloads, answers to frequently asked questions, product information, and “where to buy” instructions are found here.

2.Email Tech Support — www.canontechsupport.com

For individual attention to a special issue, try emailing our friendly technical support representatives, specially trained to communicate quick, easy, and logical solutions to your inquiries within 24 hours.

3.Toll-Free Live Tech Support — (1-800-828-4040)

This option provides live telephone technical support, free of service charges, MondaySaturday (excluding holidays), during your product’s 1 year limited warranty period. Telephone Device for the Deaf (TDD) support is available at (1-866-251-3752).

4.Extended Service and Support — www.canonesp.com

Canon CarePAK Extended Service Plan is a cost-attractive and easy-to-use extended service program that provides up to three full years of service and support coverage at a very attractive price. CarePAK offers toll-free Canon technical support and includes Canon’s superb InstantExchange product replacement program. For further information about extending your Canon service and support, call (1-800-385-2155), or visit our Web site at www.canonesp.com. CarePAK must be purchased during your product’s warranty period.

For more information and updated program specifics, please visit our web site at www.canontechsupport.com.

* Support program specifics are subject to change without notice.

Page 3

Photo All-in-One

Quick Start Guide

Page 4

Canon PIXMA MP960 Photo All-in-One Quick Start Guide.

This manual is copyrighted by Canon U.S.A., Inc. with all rights reserved. Under the copyright laws, this manual may not be reproduced in any form, in whole or in part, without the prior written consent of Canon U.S.A., Inc.

Disclaimer

Canon U.S.A., Inc. has reviewed this manual thoroughly in order that it will be an easy-to-use guide to your Canon PIXMA MP960 Photo All-in-One. All statements, technical information and recommendations in this manual and in any guides or related documents are believed reliable, but the accuracy and completeness thereof are not guaranteed or warranted, and they are not intended to be, nor should they be understood to be, representation or warranties concerning the products described.

Specifications are subject to change without notice.

As an ENERGY STAR

Partner, Canon Inc. has determined that this product meets the ENERGY

STAR guidelines for efficiency.

The International ENERGY STAR

Office Equipment Program is a global program that promotes energy saving through the use of computer and other office equipment. The program backs the development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business can participate voluntarily. The targeted products are office equipment such as computers, monitors, printers, faxes and copiers.

Their standards and logos are uniform among participating nations.

All information regarding non-Canon products was compiled from publicly available information. No representation is made regarding the accuracy thereof.

About Consumables

Consumables (ink tanks / FINE Cartridges) are available for 5 years after production has stopped.

Trademarks

z Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in

the U.S. and/or other countries.

z Macintosh and Mac are trademarks of Apple Computer, Inc., registered in the U.S. and other

countries.

z Photo Rag is a trademark of Hahnemühle FineArt GmbH.

z SmartMedia is a trademark of Toshiba Corporation.

z MEMORY STICK, Memory Stick PRO, MEMORY STICK Duo and Memory Stick Pro Duo are

trademarks of Sony Corporation.

z xD-Picture Card is a trademark of Fuji Photo Film Co., Ltd.

z MultiMediaCard is a trademark of the MultiMediaCard Association.

z SD card and miniSD Card are trademarks of SD Association.

z Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. and are licensed to Canon Inc.

Canon U.S.A., Inc. One Canon Plaza Lake Success, NY 11042

Bluetooth ID: B02954

Page 5

Table of Contents

Before Printing................................................2

Basic Operation for the Operation Panel ........2

Turning the Machine On and Off .................... 4

Handling the Original Document..................... 6

Loading Printing Paper...................................8

Changing the Paper and Print Settings ........22

Printing from Your Computer......................27

Printing with Windows................................... 27

Printing with Macintosh.................................28

Scanning Images..........................................29

Scanning Methods ........................................ 29

Copying .........................................................30

Making Copies .............................................. 30

Using Other Copy Functions.........................31

Printing from a Memory Card ......................32

Memory Cards Supported by

This Machine ................................................ 32

Inserting the Memory Card ...........................33

Removing the Memory Card.........................34

Printing Photographs Stored on

a Memory Card .............................................34

Using Other Printing Functions..................... 35

Using Useful Display Functions .................... 35

Printing Using the Photo Index Sheet...........36

Photo Printing from Photo or Film..............37

Scanning a Photo ......................................... 37

Scanning a Film............................................ 37

Printing Scanned Photographs ..................... 41

Using Other Useful Printing Functions..........42

Using Useful Display Functions .................... 42

Printing Photographs Directly from a

Compliant Device...................................43

Printing from a PictBridge Compliant

Device...........................................................43

Routine Maintenance ...................................50

Replacing an Ink Tank ..................................50

Keeping the Best Printing Results ................ 55

When Printing Becomes Faint or Colors

Are Incorrect ................................................. 56

Printing the Nozzle Check Pattern ................57

Examining the Nozzle Check Pattern ........... 58

Print Head Cleaning...................................... 60

Print Head Deep Cleaning ............................62

Aligning the Print Head ................................. 64

Cleaning Your Machine ................................68

Troubleshooting...........................................71

Error Message Is Displayed on the LCD ......72

LCD Cannot Be Seen At All..........................74

An Unintended Language Is Displayed

on the LCD.................................................... 75

Cannot Install the MP Drivers ....................... 76

Cannot Connect to Computer Properly ........77

Print Results Not Satisfactory ....................... 78

Printing Does Not Start ................................. 82

Paper Does Not Feed Properly .................... 84

Paper Jams .................................................. 85

Error Message Appears on the Screen ........ 88

Cannot Print Properly from a Digital

Camera ......................................................... 91

Cannot Print Properly from a Photo Index

Sheet ............................................................ 92

Cannot Scan Films ....................................... 93

Appendix.......................................................94

Reading the On-screen Manuals.................. 94

Specifications ............................................... 95

Safety Precautions....................................... 98

Legal Limitations on Use of Your Product

and Use of Images .....................................101

Users in the U.S.A. ..................................... 102

Index............................................................ 106

Page 6

Before Printing

Basic Operation for the Operation Panel

(A) HOME button

(B) Easy-Scroll Wheel

(A) (B) (C)

 Easy-Scroll Wheel

Turn the Easy-Scroll Wheel left or right to select the setting item. The selected item is highlighted or surrounded by a frame. You can also use the {, }, [ or ] button to select the setting items.

 HOME button

This section describes the procedure to display each mode from the HOME screen.

1 Display the HOME screen.

(1) Press the HOME button.

The HOME screen will be displayed.

2 Select the mode.

(1) Turn the Easy-Scroll Wheel to select the

mode, then press the OK button. Example: Select Memory card.

The selected mode screen will be appeared.

Note

When you select a mode and press the Function button (f2/Introduction), the instructions for the selected mode are displayed.

You can select the following modes on the HOME screen:

Copy: You can copy in various layouts. See “Copying” on page 30. Scan: You can save the scanned data to a connected computer using

Photo index sheet: You can easily print the photos from a memory card using the

2 Before Printing

the Operation Panel. See “Scanning Images” on page 29.

Photo Index Sheet. See “Printing Using the Photo Index Sheet” on page 36.

(1)

Page 7

Settings: You can perform the maintenance or change the various settings

Easy photo reprint: You can scan printed photos and then print them. See “Photo

Film print: You can scan the image data on the 35 mm film strips and slides

Memory card: Print the photo data stored in a memory card of a digital camera.

of the machine. See “When Printing Becomes Faint or Colors Are Incorrect” on page 56, “Cleaning Your Machine” on page 68, or “Changing the Machine Settings” in the User's Guide on-screen manual.

Printing from Photo or Film” on page 37.

and then print them. See “Photo Printing from Photo or Film” on page 37.

See “Printing from a Memory Card” on page 32.

 Other Buttons

(A) NAVI button

(B) Function buttons

(A) (B)

z NAVI Button

You can easily reach the function that you want to perform. Select what you want to do on the navigation menu, then press the OK button.

z Function Buttons

Two Function buttons enable you to select menus displayed at the bottom of the LCD. The screen that appears when you press a Function button depends on the screen that is

displayed and which Function button you press.

(B)(A)

(A) Function button (f1): When you press the Function button (f1/Remaining ink vol) on the

HOME screen, the remaining ink volume screen is displayed.

(B) Function button (f2): When you press the Function button (f2/Introduction) on the

HOME screen, the introductions for the selected mode functions are displayed.

When you press them on screens other than the HOME screen, an operation procedure or menus is displayed.

3Before Printing

Page 8

Turning the Machine On and Off

Turn on the machine before printing.

 Turning on the Machine

Before turning on the machine, confirm the following.

z The Print Head and ink tanks are set into place.

If you are using the machine connected to a computer, confirm also the following.

z The machine is connected to your computer (or a compatible device).

z The MP Drivers are installed.

Note

If preparatory operations above are not complete, follow the Easy Setup Instructions to complete them.

1 Open the Operation Panel and press the ON/

OFF button to turn on the machine.

The POWER lamp flashes blue, and changes to steady, non-flashing light.

Important

If the ALARM lamp lights up or flashes orange and an error message is displayed on the LCD, see “Error Message Is Displayed on the LCD” on page 72.

2 If you are using the machine connected to a

computer, turn on your computer.

 Turning off the Machine

1 To turn off the machine, press the ON/OFF

button.

When the POWER lamp stops flashing, the machine is turned off.

Important

About the Power Plug

When removing the power plug after turing off the machine, be sure to confirm that the POWER lamp is not lit. If the power plug is removed from the wall outlet with the POWER lamp still lit or flashing blue, the machine may become unable to print.

See “Keeping the Best Printing Results” on page 55.

4 Before Printing

Page 9

z Setting the Power Save Mode

The machine enters Power save mode if not operated for a certain interval. In the Power save mode, the internal fluorescent lamp is turned off, and only the POWER lamp stay lit. You can configure the interval that the machine waits before entering Power save mode. See "Other Settings" in "Changing the Machine Settings" of User's Guide on-screen manual.

When you try to copy or scan, the machine will exit from Power save mode.

If you use the machine frequently, we recommend that you set the Power save transfer time to 1 hour or 4 hours.

z The Screen-saver Mode

The LCD goes out if the machine is not operated for 5 minutes. Press any button to restore the display. You cannot change the wait time before the LCD goes out.

5Before Printing

Page 10

Handling the Original Document

This section describes how to load the original document on the Platen Glass.

 Original Document Requirements

The original documents you load on the Platen Glass for copying or scanning must meet these requirements:

Document type

Size (W x L) Max. 8.5 x 11.7 inches / 216 x 297 mm

Thickness Max. 0.98 inches / 25 mm

Paper documents

Photographs

Books

Films

* For details on positive and negative 35 mm film strips and 35 mm slides, see “Photo Printing from Photo or Film” on page 37.

 Loading Original Documents

Load originals to copy or scan on the Platen Glass. For details on how to load a photo, see “Scanning a Photo” on page 37. For details on how to load a film, see “Scanning a Film” on page 37.

Note

Make sure any glue, ink, correction fluid, or the like on the original document is completely dry before loading it on the Platen Glass.

1 Load the original document on the Platen Glass.

(1) Lift the Document Cover.

(2) Load the original on the Platen Glass.

Place the original face down on the Platen Glass.

Align the upper left corner of your original with the alignment mark on the upper left corner of the Platen Glass.

(1)

6 Before Printing

(2)

Page 11

Important

z Do not place any objects weighing more than 4.4 lb / 2 kg on the Platen Glass. z Do not press or put weight on the original with pressure exceeding 4.4 lb / 2 kg.

Doing so may cause the scanner to malfunction or the Platen Glass to break.

Note

z The machine cannot scan the area within about 0.04 inches / 1 mm from the rear edge, and

within about 0.04 inches / 1 mm from the left edge of the Platen Glass.

z You can also scan in originals that are up to 0.98 inches / 25 mm thick, such as books. Set them

on the Platen Glass in the same way as paper documents.

2 Gently close the Document Cover.

7Before Printing

Page 12

Loading Printing Paper

This section describes how to load printing paper in the Auto Sheet Feeder and the Cassette.

 Paper Handling

z Recommended Paper and Requirements

Media Type

Model

Paper Support Load Limit Machine Auto Sheet Feeder Cassette

Setting for Media Type

Plain Paper — 0.52 inches / 13 mm 0.52 inches / 13 mm Plain paper Envelopes High Resolution

Paper Super White

Paper Glossy Photo

Paper

Glossy Photo Paper “Everyday Use”

Matte Photo Paper

Photo Paper Glossy

Photo Paper Plus Glossy

Photo Paper Plus Double Sided

Photo Paper Plus Semi-gloss

Photo Paper Pro

Photo Stickers

Fine Art Paper “Photo Rag”*2, *7,

T-Shi rt Transfers

*2, *4

*6, *9

— 10 envelopes 5 envelopes — HR-101N 80 sheets (A4, Letter) 80 sheets (A4, Letter) —

SW-201 0.52 inches / 13 mm

(A4, Letter)

GP-401 10 sheets (A4, Letter),

20 sheets (4" x 6" / 101.6 x 152.4 mm, Credit card)

0.52 inches / 13 mm (A4, Letter)

10 sheets (A4, Letter), 20 sheets (4" x 6" / 101.6

x 152.4 mm), Not loadable (Credit card)

GP-501 10 sheets (A4),

20 sheets (4" x 6" / 101.6 x 152.4 mm)

MP-101 10 sheets (A4, Letter),

20 sheets (4" x 6" /101.6 x 152.4 mm)

GP-502 10 sheets (Letter),

20 sheets (4" x 6" / 101.6 x 152.4 mm)

PP-101 10 sheets (A4, Letter, 5"x

7" / 127.0 x 177.8 mm), 20 sheets (4" x 6" / 101.6 x 152.4 mm)

PP-101D 10 sheets (A4, Letter, 5"x

7" / 127.0 x 177.8 mm)

SG-101, SG-201

10 sheets (A4, Letter), 10 sheets (8" x 10" /

203.2 x 254.0 mm) 20 sheets (4" x 6" /101.6

x 152.4 mm)

PR-101 10 sheets (A4, Letter, 8"x

10" / 203.2 x 254.0 mm), 20 sheets (4" x 6" / 101.6 x 152.4 mm, Wide)

10 sheets (A4), 20 sheets (4" x 6" / 101.6

x 152.4 mm) 10 sheets (A4, Letter), 20 sheets (4" x 6" / 101.6

x 152.4 mm) 10 sheets (Letter), 20 sheets (4" x 6" / 101.6

x 152.4 mm) 10 sheets (A4, Letter, 5"x

7" / 127.0 x 177.8 mm), 20 sheets (4" x 6" /101.6 x 152.4 mm)

10 sheets (A4, Letter, 5"x 7" / 127.0 x 177.8 mm)

10 sheets (A4, Letter), 10 sheets (8" x 10" /

203.2 x 254.0 mm)*5, 20 sheets (4" x 6" / 101.6

x 152.4 mm) 10 sheets (A4, Letter, 8"x

10" / 203.2 x 254.0 mm), 20 sheets (4" x 6" / 101.6 x 152.4 mm, Wide)

PS-101 1 sheet Not loadable

FA-PR1 1 sheet (A4, Letter)

Not loadable —

TR-301 1 sheet 1 sheet —

Plain paper

Glossy Photo Paper

Matte Phot o Paper

Glossy Photo Paper

Photo Plus Glossy

—

Photo Plus Glossy

Photo Paper Pro

Photo Plus Glossy

8 Before Printing

Page 13

Paper with a Model Number is Canon specialty media.

You may not be able to purchase some Canon genuine papers depending on your country.

*1 Paper is not sold in the US by Model Number. Purchase paper by name.

*2 Available only when printing from your computer.

*3 Feeding this paper from the Cassette can damage the machine. Load in the Auto Sheet

Feeder.

*4 When loading a stack of paper, the printed side may become marked when it is fed in. In this

case, load paper one sheet at a time.

*5 SG-201 only

*6 You can specify the print setting easily by using the Easy-Photo Print provided with the

Setup CD-ROM.

*7 Canon genuine paper is produced and stored to get optimum printing quality. We

recommend using Canon genuine paper.

*8 If you are using this paper, you cannot print in the 1.38 inches / 35 mm margin on the top and

bottom edges. If you choose a special paper size for Fine Art Paper in the printer driver, a limit is set to prevent printing in the 1.38 inches / 35 mm margin on the top and bottom edges of the paper.

We recommend checking the area being printed in the preview screen before printing. Refer to the Printer Driver Guide on-screen manual.

*9 When copying printed photos onto sticker paper, be sure to select Sticker print in Easy

photo reprint mode. Refer to “Printing on a Sticker (Sticker Print)” in “Using Other Useful Printing Functions” of the User’s Guide on-screen manual.

When copying photos onto sticker paper from a film, be sure to select Sticker print in Film print mode. Refer to “Printing on a Sticker (Sticker Print)” in “Using Other Useful Printing Functions” of the User’s Guide on-screen manual.

When printing photos stored in a memory card to sticker paper, be sure to select Sticker print in the Memory card mode. Refer to “Printing on Stickers (Sticker Print)” in “Using Other Useful Printing Functions” of the User’s Guide on-screen manual.

When printing photos saved on your mobile phone to sticker paper, select Stickers for paper size in Wireless print settings. Refer to “Setting Items” in “Setting the Page Size, Media Type, and Layout When Printing from a Mobile Phone” of the User’s Guide on-screen manual.

z To specify the page size and media type when printing from your computer, refer to the Printer

Driver Guide on-screen manual.

z To specify the page size and media type when printing photos saved on mobile phones, refer

to “Setting the Page Size, Media Type, and Layout When Printing from a Mobile Phone” in the User’s Guide on-screen manual.

Note

For a detailed description of printing media types, refer to “Printing Media” in the User’s Guide on- screen manual.

9Before Printing

Page 14

z Media Types You Cannot Use

Do not use the following types of paper. Using such paper will not only produce unsatisfactory results, but can also cause the machine to jam or malfunction. Additionally, when printing on A5 or smaller sized paper, do not use paper thinner than a post card, including plain paper or notepad paper cut to a small size.

z Folded, curled, or wrinkled paper

z Damp paper

z Paper that is too thin (weighing less than 17 lb / 64 gsm)

z Paper that is too thick (non-Canon genuine paper weighing more than 28 lb / 105 gsm)

z Picture postcards

z Postcards affixed with photos or stickers

z Envelopes with double flaps

z Envelopes with sticker flaps

z Envelopes with an embossed or treated surface

z Any type of paper with holes

z Paper that is not rectangular

z Paper bound with staples or glue

z Paper with adhesives

z Paper decorated with glitter, etc.

z Photo Paper Pro Guidelines

z Do not touch the print surface until the ink is dry (approximately 30 minutes). Colors in dark

images may appear indistinct at first, but will become clearer after approximately 30 minutes.

z Images may become smudged if you place printouts in an album before the ink is completely

dry. We recommend to allow the ink to dry for 24 hours before placing your printouts in an album.

z Do not attempt to dry the ink with a hair dryer or by exposing printouts to direct sunlight.

z Do not store or display printouts in hot or humid conditions. Never expose them to heat or

direct sunlight.

z Store printouts in photo albums, photo frames, or presentation binders to protect them from

direct exposure to air or sunlight.

z Do not mount printouts in an adhesive-type album as you may not be able to remove them.

Note that some types of clear plastic folders and albums may cause the edges of the paper to turn yellow.

10 Before Printing

Page 15

 Using Specialty Media

Canon recommends that you use Canon genuine media to ensure optimal print quality.

z Photo Quality Media

z Glossy Photo Paper

z Matte Photo Paper

z Photo Paper Plus Double Sided

z Photo Paper Plus Glossy

z Photo Paper Plus Semi-gloss

z Photo Paper Pro

z Fine Art Paper “Photo Rag

z Photo Stickers

”

z Media Suited for Business

Documents

z High Resolution Paper

 Using the Auto Sheet Feeder and the Cassette

This machine offers two paper sources to load printing paper; the Auto Sheet Feeder, found at the top of the machine, and the Cassette, found at the front of the machine.

(A)

(A) Auto Sheet Feeder

(B) Cassette

(B)

11Before Printing

Page 16

z When Printing for the First Time

At purchase, the machine is set to feed from the Auto Sheet Feeder. If you are printing without changing paper source settings, load paper in the Auto Sheet

Feeder.

Note

For details on loading paper, see “Loading Paper in the Auto Sheet Feeder” on page 17.

(A)

(A) Load plain paper in the Auto Sheet Feeder.

z To Change the Paper Source

The Auto Sheet Feeder lamp lights up when feeding from the Auto Sheet Feeder, and the Cassette lamp lights up when feeding from the Cassette.

Before you print, make sure that the paper source selection matches the paper source where you actually loaded paper.

To change the paper source, simply press the Paper Feed Switch. For details, see “Changing the Paper Source” on page 15.

Note

You can also select the paper source using the printer driver. For details on paper source selection using the printer driver, refer to the Printer Driver Guide on-screen manual.

(A)

(A) Press to change the paper source

12 Before Printing

Page 17

 Paper Source Selection Scenarios

Deciding on the usage of the two paper sources to print with minimum reloading of paper depends mainly on the variety of the type of paper you use regularly.

z If you print regularly on photo paper as well as on plain paper

If you use photo paper as much as plain paper, you can load photo paper in the Auto Sheet Feeder and plain paper in the Cassette. This way, you can switch the paper source according to the type of paper just by pressing the Paper Feed Switch.

You can also specify the type and size of paper to be fed from the Cassette using the printer driver. You can print more efficiently by specifying the type of paper you use regularly this way, since the paper source will be switched automatically to the Cassette for this paper.

Note

z Some types and sizes of paper are not loadable in the Cassette and requires the use of the

Auto Sheet Feeder. See “Paper Handling” on page 8. For details on loading paper, see “Loading Paper” on page 16.

z For details on printer driver settings, refer to the Printer Driver Guide on-screen manual.

(A)

(B)

(A) Auto Sheet Feeder: Load paper of various types and sizes, including photo paper.

(B) Cassette: Load paper you use most regularly, such as plain paper.

13Before Printing

Page 18

z If you print mainly on plain paper

You can load plain paper of the same size in both paper sources, and set the printer driver to automatically switch the paper source when either paper source runs out of paper during printing.

Note

z For details on how to load paper, see “Loading Paper” on page 16. z For details on printer driver settings, refer to the Printer Driver Guide on-screen manual.

(A)

(B)

(A) Auto Sheet Feeder: Load plain paper

(B) Cassette: Load plain paper

14 Before Printing

Page 19

 Changing the Paper Source

Before printing, confirm that the location where you have loaded paper is selected as the paper source. Press the Paper Feed Switch to change the paper source.

Important

When Printing from Your Computer z If Paper Feed Switch is not selected for Paper Source in the printer driver, the Paper Feed

Switch on the machine will be disabled when printing. Confirm the setting in the printer driver.

See “Printing with Windows” on page 27 or “Printing with Macintosh” on page 28.

z If a setting other than Paper Feed Switch is selected for Paper Source in the printer driver, the

printer driver settings takes precedence when printing. For details on paper source selection using the printer driver, refer to the Printer Driver Guide on-screen manual.

(A)

(B)

(C)

(A) Auto Sheet Feeder lamp

(B) Paper Feed Switch

Note

Press the Paper Feed Switch to select the paper source so that the Auto Sheet Feeder lamp is lit when feeding from the Auto Sheet Feeder, and the Cassette lamp is lit when feeding from the Cassette.

15Before Printing

Page 20

 Loading Paper

Important

z If you cut plain paper to 4" x 6" / 101.6 x 152.4 mm, 5" x 7" / 127.0 x 177.8 mm, or 2.13" x 3.39"

/ 54.0 x 86.0 mm (credit card-size) for a trial print, it can cause paper jams.

z You cannot print on postcards affixed with photos or stickers. z Always load paper in portrait orientation (A). Loading paper in landscape orientation (B) can

cause the paper to be jammed.

(A) (B)

Note

z For details on the specialty media Canon provides for use with its various printers, refer to

“Printing Media” in the User’s Guide on-screen manual.

z For detailed instructions on how to load specialty media into the machine, refer to “Printing

Media” in the User’s Guide on-screen manual.

When Printing on Plain Paper

z You can use general copy paper or Canon’s Super White Paper. When printing on both sides,

we recommend Canon’s Super White Paper Double-Sided. Paper size: – Standard sizes: A4, B5, A5, Letter, and Legal (Auto Sheet Feeder only) – Non-standard sizes for the Auto Sheet Feeder: 2.13" x 3.39" to 8.5" x 23" / 54.0 x 86.0 mm to

215.9 x 584.2 mm

– Non-standard sizes for the Cassette: 3.5" x 5" to 8.5" x 11.69" / 89.0 x 127.0 mm to 215.9 x

297.0 mm Paper weight: 17 to 28 lb / 64 to 105 gsm (non-Canon genuine plain paper) *However, you can use art paper that is not produced by Canon that is up to 53 lb / 200 gsm

(only in the Auto Sheet Feeder). Do not use paper heavier than this (except for supported Canon genuine paper), as it could jam in the machine.

z You can load up to 150 sheets of plain paper (17 lb / 64 gsm, 0.52 inches / 13 mm in height).

However, proper feeding of paper may not be possible at this maximum capacity depending on the type of paper or environmental conditions (either very high or low temperature and humidity). In such cases, reduce the sheets of paper you load at a time to around half (around

0.2 inches / 5 mm in paper stack height).

z Do not stack more than 50 sheets in the Paper Output Tray.

When Printing on 5" x 7", 4" x 6", or 2.13" x 3.39" (Credit Card-sized) paper

z Load 2.13" x 3.39" (credit card-sized) paper only in the Auto Sheet Feeder. z You can load up to 20 sheets of 4" x 6" or 2.13" x 3.39" (credit card-sized) paper and 10 sheets

of 5" x 7" paper.

z We recommend using genuine Canon photo media when printing photographs.

Refer to “Printing Media” in the User’s Guide on-screen manual.

16 Before Printing

Page 21

z Loading Paper in the Auto Sheet Feeder

(A)

(4)

1 Flatten the four corners of the paper before loading it.

Note

z Align the edges of paper neatly before loading. Loading paper without aligning the edges may

cause paper jams.

z If paper is curled, hold the opposing curled corners and gently bend them in the opposite

direction until the paper becomes completely flat. See “Paper is curled.” on page 81.

z To avoid curling, handle paper as follows.

– Put unused paper back into the package and keep them on a level surface. – Take out only the necessary number of sheets from the package, just before printing.

2 Prepare to load paper.

(1) Open the Sheet Feeder Cover and pull out the

Paper Support.

(2) Open the Paper Output Tray.

Put your finger on the top of the Paper Output Tray and open it gently.

(3) Open the Output Tray Extension.

(4) Press the Paper Feed Switch so that the Auto

Sheet Feeder lamp (A) lights.

Note

You can also select the paper source with the printer driver. For details, refer to the Printer Driver Guide on-screen manual.

(3)

(1)

(2)

17Before Printing

Page 22

3 Load the paper.

(1) Load the paper in the Auto Sheet Feeder with

the print side facing UP.

(2) Align the paper stack against the Cover Guide

on the right side of the Paper Support.

Note

Make sure that the Cover Guide is set upright when you load paper in the Auto Sheet Feeder.

(3) Pinch the Paper Guide and slide it against the

left side of the paper stack.

Note

When performing copy direct printing without using a computer, select the page size selected in Page size in each menu. For details on settings in each menu, see “Changing the Paper and Print Settings” on page 22. When using the machine connected to a computer, select the page size of the loaded paper in Page Size in the printer driver. For details on printer driver settings, see “Printing with Windows” on page 27 or “Printing with Macintosh” on page 28.

z Loading Paper in the Cassette

Some types and sizes of paper are not loadable in the Cassette and requires the use of the Auto Sheet Feeder. If you intend to use only the Cassette, check for any usage restrictions in advance. See “Paper Handling” on page 8.

(A)

(1)

(3)

Do not load higher than the Load Limit Mark (A).

(2)

Important

z Do not leave photo paper, such as Photo Paper Pro, in the Cassette for a long time. This may

cause paper discoloration due to natural aging.

z If you load photo paper such as Photo Paper Pro in the Cassette, you may get roller traces on

the print surface. To avoid this, load paper in the Auto Sheet Feeder.

1 Flatten the four corners of the paper before loading it.

See “Flatten the four corners of the paper before loading it.” on page 17.

2 Prepare to load paper.

(1) Pull out the Cassette from the machine.

18 Before Printing

(1)

Page 23

3 Load the paper with the print side facing

DOWN.

(1) Load the paper in the Cassette with the print

side facing DOWN and the leading edge to the far side.

(2) Align the paper stack against the right side of

the Cassette.

(3) Slide the paper guides to fit to the loaded

paper stack.

4 Insert the Cassette into the machine.

(1) Insert the Cassette into the machine.

Push the Cassette all the way into the machine.

(A)

(1) (2)

(3)

Do not load higher than the Load Limit Mark (A).

(1)

5 Prepare the Paper Output Tray.

(1) Open the Paper Output Tray.

Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

(3) Press the Paper Feed Switch so that the

Cassette lamp (A) lights.

Note

z When performing copy direct printing without using

a computer, select the page size selected in Page size in each mode. For details on settings in each mode, see “Changing the Paper and Print Settings” on page 22.

When using the machine connected to a computer, select the page size of the loaded paper in Page Size in the printer driver.

For details on printer driver settings, see “Printing with Windows” on page 27 or “Printing with Macintosh” on page 28.

z You can also select the paper source with the

printer driver. For details, refer to the Printer Driver Guide on-

screen manual.

(3)

(A)

(2) (1)

19Before Printing

Page 24

 Loading Envelopes

Use either European DL or US Comm. Env. #10-sized envelope.

Important

z You need to print from the computer to print on envelopes. z Do not use envelopes with embossed or treated surfaces, a double flap, pressure seals, or

sticker flaps.

z Select either DL Env. or Comm. Env. #10 in the printer driver according to the envelope size

you are using. If you do not, the address will be printed in the wrong direction.

z Loading Envelopes in the Auto Sheet Feeder

1 Load the envelope against the Cover Guide

(the right side of the Paper Support).

Load with the front face UP and the rear flaps DOWN on the left.

A maximum of 10 envelopes can be loaded at once.

Important

Make sure that the Cover Guide is set upright when you load paper in the Auto Sheet Feeder.

*1 Printing orientation *2 Make sure the flaps are folded.

2 Pinch the Paper Guide and slide it against the

left side of the envelope.

3 Press the Paper Feed Switch so that the Auto Sheet Feeder lamp lights up.

4 In the printer driver, select Envelope in Media Type, and then select DL Env. or

Comm. Env. #10 in Page Size.

For details on printer driver settings, see “Printing with Windows” on page 27 or “Printing with Macintosh” on page 28.

20 Before Printing

Page 25

z Loading Envelopes in the Cassette

1 Align the envelope stack against the right side

of the Cassette.

Load with the front face DOWN. The flap of the envelope will appear facing UP on the left side.

A maximum of 5 envelopes can be loaded at once.

*1 Make sure the flaps are folded.

2 Slide the Paper Guides against the side of the envelope.

3 Press the Paper Feed Switch so that the

Cassette lamp lights up.

*1 Printing orientation

4 In the printer driver, select Envelope in Media Type, and then select DL Env. or

Comm. Env. #10 in Page Size.

For details on printer driver settings, see “Printing with Windows” on page 27 or “Printing with Macintosh” on page 28.

21Before Printing

Page 26

Changing the Paper and Print Settings

This section describes the Settings screen that can be specified on the Operation Panel when copying, or when printing from a memory card, printed photo or film.

 Setting Items in Each Mode

Items in each mode are as follows.

When you select the item to set and press the OK button, a screen with various settings is displayed.

Note

Depending on the functions, some setting items cannot be specified in combination.

z Copy Mode

This section describes paper and print settings for Copy mode.

(1) (2) (3) (4) (5) (6)

You can specify the paper settings for printing or print quality.

Note

Paper size, media type, and print quality settings are specified for the paper source selected by the

Paper Feed Switch. Confirm the selected paper source.

(1) You can specify the reduction or enlargement method.

Fit-to-page, Zoom (25 - 400%), 100%, Preset ratio

(2) You can specify the intensity.

Turn the Easy-Scroll Wheel clockwise to increase intensity or counterclockwise to decrease it. You can also use the [ or ] button to make settings.

Press the Function button (f2/Switch auto/man) in the intensity screen to automatically match the intensity to the original on the Platen Glass and then print the image. See “Function Buttons” on page 3.

The slide bar for the intensity adjustment on the LCD changes to Auto when it is done.

22 Before Printing

Page 27

Important

While Auto is selected, you can not change the intensity by using the Easy-Scroll Wheel. Press the Function button (f2/Switch auto/man) to enable manual intensity settings again and then specify the intensity. See “Function Buttons” on page 3.

(3) Select the paper source.

Before printing, confirm that the location where you have loaded paper is selected as the paper source. Press the OK button to change the paper source.

(4) Specify the page size.

Credit card, A5, B5, A4, 8.5" x 11" (215 x 279), 5" x 7" (127 x 177.8), 4" x 6" (101.6 x

152.4)

Important

Credit card can be selected when the Auto Sheet Feeder is selected as the paper source.

Note

Some of these options are not available depending on the country of purchase.

(5) Specify the media type.

Glossy Photo Paper, Matte Photo Paper, Photo Plus Glossy, Plain paper, Photo Paper Pro

(6) Adjust print quality according to the original.

Fast (speed-priority), Standard, High(quality-priority)

Note

z Fast (speed-priority) can be selected when Plain paper is selected as the media type. z If you used Fast (speed-priority) with media type set to Plain paper and the quality is not

as good as expected, select Standard or High(quality-priority) and try copying again.

z Select High(quality-priority) to copy in grayscale. Grayscale renders tones in a range of

grays instead of black or white.

23Before Printing

Page 28

z Memory Card, Easy Photo Reprint, and Film Print Modes

This section describes the paper and print settings for Memory card, Easy photo reprint, and Film print modes.

Print Settings Confirmation Screen

You can specify the paper settings for printing or print quality.

Note

Paper size, media type, and print quality settings are specified for the paper source selected by the Paper Feed Switch. Confirm the selected paper source.

Example: Screens displayed in Select and print in the Memory card mode, the Easy photo reprint mode, or the Film print mode

See “Printing Photographs Stored on a Memory Card” on page 34 or “Printing Scanned Photographs” on page 41.

(1) (2) (3) (4)

(1) Select the paper source.

Before printing, confirm that the location where you have loaded paper is selected as the paper source. Press the OK button to change the paper source.

(2) Select the page size.

Credit card, A4, 8.5" x 11" (215 x 279), 8" x 10" (203.2 x 254.0)*, 5" x 7" (127 x 177.8), 4" x 6" (101.6 x 152.4), Wide 4" x 7.1" (101 x 180)

Important

Credit card can be selected when the Auto Sheet Feeder is selected as the paper source.

Note

Some of these options are not available depending on the country of purchase.

(3) Select the media type.

Glossy Photo Paper, Matte Photo Paper, Photo Plus Glossy, Plain paper*, Photo Paper Pro

(4) Select the print quality.

Standard, High(quality-priority)

* Can be selected only in Memory card mode.

24 Before Printing

Page 29

Advanced Print Settings Screen

When you press the Function button (f1/Advanced) in the print settings confirmation screen, the advanced print settings screen is displayed. See “Function Buttons” on page 3.

You can optimize photos and advanced print settings with the functions below.

Memory card mode

(1) (2) (3) (4)

(5) (6) (7) (8)

(9) (10) (11) (12)

(13)

Easy photo reprint and Film print modes

(14)

(1) Select bordered or borderless print.

Bordered, Borderless

Note

When Plain paper is selected in Media type, bordered printing will be performed even if you select Borderless.

(2) Activate/deactivate to print the shooting date on a photo.

Print the shooting date on a photo. Date OFF, Date ON

(3) Activate/deactivate to print the file no. on a photo.

Print the file no. on a photo. File no. OFF, File no. ON

Note

It is not possible to print both the shooting date and the file no. under the following conditions:

z Layout print is selected as a print function in the Memory card mode, and/or z Credit card is selected in Page size.

Under these conditions, even if both Date ON and File no. ON are set, only the shooting date will be printed. If you want to print the file no., select Date OFF.

25Before Printing

Page 30

(4) Activate/deactivate Red eye correction.

Corrects red eyes in portraits caused by flash photography. Red eye correc. OFF, Red eye correc. ON

(5) Activate/deactivate Vivid photo function.

Makes green and blue more lively. Vivid photo OFF, Vivid photo ON

(6) Activate/deactivate the Photo Optimizer pro function.

Automatically optimizes brightness and tone of a photo. Photo opt. pro OFF, Photo opt. pro ON

(7) Activate/deactivate the Noise reduction function.

Reduces the noise on blue areas like the sky as well as on black areas. Noise reduction OFF, Noise reduction ON

(8) Activate/deactivate Face brightener function.

Brightens a darkened face on the photo taken against the light. Face brightener OFF, Face brightener ON

(9) Activate/deactivate Image optimizer function.

Corrects and smooths the jagged contours for printing. Image optimizer OFF, Image optimizer ON

(10) Adjust brightness.

Brightness -2, Brightness -1, Brightness standard, Brightness +1, Brightness +2

(11) Adjust contrast.

Contrast -2, Contrast -1, Contrast standard, Contrast +1, Contrast +2

(12) Adjust color hue.

Color hue red +2, Color hue red +1, Color hue original, Color hue yellow +1, Color hue yellow +2

(13) Activate/deactivate Effects

Applies special effects to the photo, such as printing in sepia tones or with a sketch illustration like effect.

No effects, Effect: Sepia, Simulate illustration

(14) Activate/deactivate Fade restoration

Corrects the color when printing photos that have faded or color cast over time. Fade restoration OFF, Fade restoration ON

*1 Can be selected only in Memory card mode.

*2 Can be selected only in Easy photo reprint or Film print mode.

26 Before Printing

Page 31

Printing from Your Computer

This section describes procedure for basic printing.

Printing with Windows

Turn on the machine and load the paper in the machine.

See “Turning the Machine On and Off” on page 4 and “Loading Printing Paper” on page 8.

2 Make sure that the proper paper source is selected.

See “Changing the Paper Source” on page 15.

3 Create a document or open a file to print using an appropriate application software.

4 Select Print on the application software’s File

menu.

5 Make sure that Canon MP960 Printer is

selected, and click Preferences (or Properties).

6 Specify the required settings and click OK.

Make sure that Paper Feed Switch is selected in Paper Source.

Note

For details on other printer driver functions, click Help or Instructions to view the online help or the Printer Driver Guide on-screen manual. Instructions is only displayed when the on-screen manuals are installed.

7 Click Print (or OK).

27Printing from Your Computer

Page 32

Printing with Macintosh

Turn on the machine and load the paper in the machine.

See “Turning the Machine On and Off” on page 4 and “Loading Printing Paper” on page 8.

2 Make sure that the proper paper source is selected.

See “Changing the Paper Source” on page 15.

3 Create a document or open a file to print using an appropriate application software.

4 Select Page Setup on the application

software’s File menu.

5 Confirm that MP960 is selected in Format

for.

6 Select the desired paper size in Paper Size.

7 Click OK.

8 Select Print on the application software’s File

menu.

9 Select Quality & Media in the pop-up menu.

10 Specify the required settings.

Make sure that Paper Feed Switch is selected in Paper Source.

Note

For details on other printer driver functions, click to view the Printer Driver Guide on-screen manual. If the on-screen manuals are not installed, the Printer Driver Guide on-screen manual is not displayed even if is clicked.

11 Click Print.

28 Printing from Your Computer

Page 33

Scanning Images

You can scan images from the machine to a computer without printing them and save them in popular file formats, such as JPEG, TIFF, bitmaps, or PDF. If you are scanning printed text, you can use the OCR (Optical Character Recognition) software to convert it to text data.

Scanning Methods

 Scanning Using the MP Navigator

Using MP Navigator, you can scan originals loaded on the Platen Glass and view images saved on your computer or on a memory card. Scanned documents can be previewed and be easily printed and edited according to your needs.

You can use the bundled software applications to edit or print the document you have scanned.

For detailed operations of the MP Navigator, refer to the Scanning Guide on-screen manual.

 Scanning Using the Operation Panel of the Machine

1 Turn on the machine.

See “Turning the Machine On and Off” on page 4.

2 Load the original document on the Platen Glass.

See “Handling the Original Document” on page 6, and on setting a photo, see “Scanning a Photo” on page 37.

3 Select Scan on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

4 Select the scan operation, then press the OK button.

5 Press the Color or Black button.

The operation to be performed after scanning the original depends on the scan operation setting you have selected in step 4. For details on how to modify the operation settings, refer to the Scanning Guide on-screen manual.

 Scanning from an Application Software

You can scan an image from a TWAIN- or WIA- (Windows® XP only) compliant application software and handle the scanned image in the application software. For detailed operations, refer to the Scanning Guide on-screen manual.

29Scanning Images

Page 34

Copying

Making Copies

This section describes the basic procedure to make copies.

1 Turn on the machine.

See “Turning the Machine On and Off” on page 4.

2 Select Copy on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

3 Load paper.

See “Loading Printing Paper” on page 8.

4 Make sure that the proper paper source is selected.

See “Changing the Paper Source” on page 15.

5 Specify copy settings.

(1) Confirm the page size, media type, or other

settings. To change the settings, select the item and press the OK button.

(2) Use the + or - button to specify the number of

copies.

6 Load the original on the Platen Glass.

See “Loading Original Documents” on page 6.

(1)

(2)

7 Press the Color button for color copying, or the Black button for black & white

copying.

30 Copying

Page 35

Using Other Copy Functions

Reduced/Enlarged Copy

Reduces or enlarges copies.

Two-sided copy

Copies two original pages onto the sides of a single sheet of paper.

Borderless copy

Copies color images so that they fill the entire page without borders.

2-on-1 copy

Copies two original pages onto a single sheet of paper by reducing each image.

4-on-1 copy

Copies four original pages onto a single sheet of paper by reducing each image. Four different layouts are available.

Image repeat

Copies an image multiple times onto a single page. For the number of times to repeat the image, you can select from Auto layout or the machine’s pre-defined settings.

31Copying

Page 36

Printing from a Memory Card

Memory Cards Supported by This Machine

The following memory cards are compatible with this machine.

Memory cards that can be directly inserted into the Card Slot:

Compact Flash (CF) Card

Supports Type I/II (3.3 V)

Microdrive

SmartMedia

Supports 3.3 V card only

1 MB and 2 MB cards are not supported

MEMORY STICK

MEMORY STICK PRO

SD Secure Digital memory card

MultiMediaCard (ver.3.31)

Memory cards that can be inserted in the Card Slot using the adapter:

xD-Picture Card

MEMORY STICK Duo

MEMORY STICK PRO Duo*2

Mini SD Card

*1 Requires purchase of a separate compact flash card adapter for xD-Picture cards.

*2 Use the special adapter provided with the card.

32 Printing from a Memory Card

Page 37

Inserting the Memory Card

Turn on the machine.

See “Turning the Machine On and Off” on page 4.

2 Open the Card Slot Cover.

Push the upper right-hand corner of the Card Slot Cover as illustrated and open it.

3 Insert one and only one memory card into the Card Slot.

Card Type Inserting Card

Compact Flash (CF) card

Microdrive

xD-Picture card*

SmartMedia

Insert into the left Card Slot.

Lights up

Insert into the right Card Slot.

Lights up

MEMORY STICK

MEMORY STICK PRO

MEMORY STICK Duo*

MEMORY STICK PRO Duo*

SD Secure Digital memory card

MiniSD Card*

MultiMediaCard (ver.3.31)

* Be sure to attach the memory card to the special adapter before inserting it into the Card

Slot.

Insert into the center part of the right Card Slot.

Lights up

4 Confirm that the Access lamp has lit up.

5 Close the Card Slot Cover.

33Printing from a Memory Card

Page 38

Removing the Memory Card

Open the Card Slot Cover.

Push the upper right-hand corner of the Card Slot Cover and open it.

See “Inserting the Memory Card” on page 33.

2 Make sure that the Access lamp is not flashing, then remove the memory card.

3 Close the Card Slot Cover.

Printing Photographs Stored on a Memory Card

Prepare for printing.

(1) Turn on the machine.

See “Turning the Machine On and Off” on page 4.

(2) Load paper.

See “Loading Printing Paper” on page 8.

(3) Make sure that the proper paper source is selected.

See “Changing the Paper Source” on page 15.

2 Insert the memory card.

(1) Select Memory card on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

(2) Insert the memory card into the Card Slot.

See “Inserting the Memory Card” on page 33.

3 Select the print menu.

(1) Select Select and print, then press the OK button.

(2) Confirm the paper size, media type, and other settings, select Next, and then press the

OK button. To change the settings, select the item and press the OK button.

4 Select the photo to print and specify the number of copies for each photo.

(1) Use the Easy-Scroll Wheel or the [ or ] button to display a photo to print.

(2) Use the + or - button to specify the number of copies.

(3) Repeat steps (1) and (2) to specify the number of copies for each photo.

(4) Press the OK button.

34 Printing from a Memory Card

Page 39

5 Start printing.

(1) Confirm the print setting. To change the

settings, select the item and press the OK button.

(2) Confirm the total number of copies for the

selected photos.

(3) Confirm the selected photos and number of

copies for each photo.

(4) Change the advanced print settings.

(5) Press the Color button.

The specified number of copies of each photo will be printed.

(1)

(2)

(4) (3)

Using Other Printing Functions

Layout print

Prints photos your pasted in the specified layout.

Sticker print

Prints your favorite photo with a frame on Canon Photo Stickers.

DPOF print

Prints according to the Digital Print Order Format (DPOF) settings on your digital camera, if you have specified them.

Captured info print

Prints information on photographs at the time of its shooting (Exif info) in the margin of Photo index print or selected individual photos.

Photo index print

Prints an index of all the photos saved on a memory card.

Print all photos

Prints all photos saved on the memory card.

Using Useful Display Functions

Change display

The display method of a photograph can be changed.

Trimming

Edits images displayed on the LCD by cropping them.

When there are a lot of photos saved on the memory card, displays and prints only photos shot on the specified date or within the specified range of dates.

35Printing from a Memory Card

Page 40

Printing Using the Photo Index Sheet

Turn on the machine, and load A4 or Letter-sized paper.

See “Turning the Machine On and Off” on page 4 and “Loading Printing Paper” on page 8.

2 Make sure that the proper paper source is selected.

See “Changing the Paper Source” on page 15.

3 Select Photo index sheet on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

4 Select Index sheet print, then press the OK button.

5 Insert a memory card into the Card Slot.

See “Inserting the Memory Card” on page 33.

6 Select a range of images to include in the Photo Index Sheet, then press the OK

button.

7 Press the Color button.

8 Fill in the appropriate circles in the Photo

Index Sheet.

9 Load the type of paper you selected in the

Photo Index Sheet.

See “Loading Printing Paper” on page 8.

10 Select Scan sheet and print, then press the

OK button.

11 Place the Photo Index Sheet face-down on

the Platen Glass, then press the OK button.

36 Printing from a Memory Card

Page 41

Photo Printing from Photo or Film

You can scan photos and 35 mm film into and then print them from the machine. For film, both film strips (six connected frames per strip after regular developing) and slides (one frame per mounted slide) are supported. Various effects can be applied to the images before printing them.

Scanning a Photo

Turn on the machine.

See “Turning the Machine On and Off” on page 4.

2 Select Easy photo reprint on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

3 Lift the Document Cover and load the photos on the Platen Glass.

Place the photos face down on the Platen Glass as follows.

4"x 6" / 101.6 x 152.4 mm or 5"x 7" / 127 x 177.8 mm originals

Credit card-sized originals

0.4" / 10 mm

0.4" / 10 mm 0.4" / 10 mm 0.4" / 10 mm

0.4" / 10 mm

4 Gently close the Document Cover and press the OK button.

Scanning a Film

Turn on the machine.

See “Turning the Machine On and Off” on page 4.

2 Display the Film print screen.

See “Basic Operation for the Operation Panel” on page 2.

3 Select the type of film to scan, then press OK.

37Photo Printing from Photo or Film

Page 42

4 Remove the FAU Protective Sheet from the Document Cover and then remove the

film guide for film strip from the back of the FAU Protective Sheet.

Note

Before scanning 35 mm slides, prepare the film guide for slides provided with the machine.

5 Mount film in the appropriate film guide.

For a 35 mm film strip, see “Mounting a 35 mm Film Strip” on page 38.

For 35 mm slides, see “Mounting 35 mm Slides” on page 40.

6 Gently close the Document Cover and press the Color button.

 Mounting Films

z Mounting a 35 mm Film Strip

(1) On the film guide, open the film holder.

Gently squeeze in the edges of the film holder to release it.

(2) Mount the film in the film guide with the front

side (the side showing the correct image) face down, with the frame order running from left to right and with the tip of the film set under the tabs of the film guide. Position the film in the film guide so that the white line marks of the film guide do not obscure the film frames.

(3) Squeeze the film holder inward lightly and

close it completely.

38 Photo Printing from Photo or Film

(2)

(3)

Page 43

Note

z If the film holder will not close properly,

reposition the film so that its perforations are set properly in the film guide slots, and try again.

z Make sure that all the protrusions on the outer

edges of the film holder fit into the slots in the film guide when closing the film holder. If the film holder does not close completely, press the whole film holder gently downward.

Mounting a film strip that is shorter than the film guide

When a film strip that is shorter than the film guide is mounted, parts of the images around the blank area may appear pale. In this case, set the Filler Sheet for film strip (A) over the blank area to shield it before scanning.

Setting the Filler Sheet for film strip

z Mounting a film strip in positions 1 to 4 of the

film guide: Set the Filler Sheet for film strip (A) over the blank area (positions 7 to 12) to shield it as illustrated. You do not have to shield position 5 or 6, even though there is no film mounted in it.

(A)

z Mounting a film strip in positions 1 to 9 of the

film guide: Set the Filler Sheet for film strip (A) over the

blank area (positions 10 to 12) to shield it as illustrated. Load the film guide on the Platen Glass as is, even though the Filler Sheet sticks out of the film guide.

(A)

(4) With the mark on the film guide facing up,

align the film guide with the indentations on the right and left sides of the Platen Glass.

(4)

(5) Confirm that the front side of the film (the side

showing the correct image) faces down.

(5)

Note

Labels attached to areas of the film without images may be interpreted as images and be included in the scan.

39Photo Printing from Photo or Film

Page 44

z Mounting 35 mm Slides

(1) Load the film guide with its sides to the right

and left grooves of the Platen Glass.

(2) Mount the slides in the film guide with the front

side (the side showing the correct image) face down, the frame order running from left to right, and with the image upside down. Load the slides, making sure they are not loose in the film guide.

Note

Mount the slides in numerical order from the left side (1 to 4, and 5 to 8) making sure blank areas between the slides.

Blank areas on the film guide

If there is a blank area on the film guide, parts of the images around this area may appear pale. In this case, set the Filler Sheet for slides (B) over the blank area (positions 5 to 8) to shield it.

Setting the Filler Sheet for slides

z Mounting slides in positions 1 to 3 of the film

guide: Set the Filler Sheet for slides (B) over the blank

area (positions 5 to 8) to shield it as illustrated. You do not have to shield position 4, even though there is no slide mounted in it.

z Mounting slides in positions 1 to 6 of the film

guide: Set the Filler Sheet for slides (B) over the blank

area (positions 7 to 8) to shield it as illustrated. Load the film guide on the Platen Glass as is, even though the Filler Sheet sticks out of the

film guide.

40 Photo Printing from Photo or Film

(B)

Page 45

Note

z Film is scanned in the order from left to right. z Mount the slides in the film guide with the upper edge of the photograph towards you to prevent

the scanned photographs from being displayed upside down on the LCD. Depending on the model or brand of your camera, the scanning order may differ from the frame order of the film.

scanning order

*1 35 mm film strip *2 35 mm slide

Printing Scanned Photographs

Prepare for printing.

(1) Load paper.

See “Loading Printing Paper” on page 8.

(2) Scan a photo.

See “Scanning a Photo” on page 37 or “Scanning a Film” on page 37.

(3) Make sure that the proper paper source is selected.

See “Changing the Paper Source” on page 15.

2 Select the print menu.

(1) Select Select and print, then press the OK button.

(2) Confirm the paper size, media type, and other settings, then select Next, and then press

the OK button. To change the settings, select the item and press the OK button.

3 Select the photo to print and specify the number of copies for each photo.

(1) Use the Easy-Scroll Wheel or the [ or ] button to display a photo to print.

(2) Use the + or - button to specify the number of copies.

(3) Repeat steps (1) and (2) to specify the number of copies for each photo.

(4) Press the OK button.

41Photo Printing from Photo or Film

Page 46

4 Start printing.

(1) Confirm the print setting. To change the

settings, select the item and press the OK button.

(2) Confirm the total number of copies for selected

photos.

(3) Change the advanced print settings.

(4) Press the Color button to print in color, or the

Black button to print in black & white.

The specified number of copies of each photo will be printed.

(1)

(2)

Using Other Useful Printing Functions

Sticker print

Prints your favorite photo on Canon Photo Stickers to create your own stickers.

Print all photos

Prints all scanned photos.

Using Useful Display Functions

Change display

The display method of a photograph can be changed.

Trimming

Edits images displayed on the LCD by cropping them.

(3)

42 Photo Printing from Photo or Film

Page 47

Printing Photographs Directly from a Compliant Device

Printing from a PictBridge Compliant Device

You can connect a PictBridge compliant device such as a digital camera, camcorder, or mobile phone and print recorded images directly without using a computer.

Note

z PictBridge is an industry standard enabling a range of digital photo solutions, including the direct

printing of photos from a digital still camera, camcorder or mobile phone* without the need to use a computer. A device can be connected to this machine for direct printing regardless of the manufacturer or the model as long as it complies with the PictBridge standard.

z You can select the images to print and specify various print settings from your camera or mobile phone.

* PictBridge compatible digital still cameras, digital camcorders, and camera-equipped mobile phones

are hereafter collectively referred to as “PictBridge compliant device”.

A device with this mark is PictBridge-compatible.

 Connecting a PictBridge Compliant Device

To connect a PictBridge compliant device to this machine, use a USB cable recommended by the device’s manufacturer.

Caution

Do not connect any equipment other than PictBridge compliant devices or optional Bluetooth Units BU-20 to the Direct Print Port of the machine. If you do so, electric shock, fire, or damage to the device could result.

Note

When printing photos with the digital device connected to the machine, we recommend the use of the AC adapter supplied with the device. If you are using the device battery, be sure to charge it fully.

1 Set up the machine.

Refer to the Easy Setup Instructions to set up the machine and make it ready for printing.

Note

The Print Head cannot be aligned using the controls of the PictBridge compliant device. If Print Head alignment is not yet performed and the MP Drivers are not installed in the computer, be sure to align the Print Head. See “Aligning the Print Head” on page 64.

2 Turn on the machine and load the paper in the machine.

See “Turning the Machine On and Off” on page 4 and “Loading Printing Paper” on page 8.

43Printing Photographs Directly from a Compliant Device

Page 48

3 Connect the PictBridge compliant device to the machine.

Note

Depending on the model or brand of your device, you may have to select a print mode compliant with PictBridge before connecting the device. You may also have to turn on the device or select Play mode manually after connecting the device to the machine.

Perform necessary operations on the PictBridge compliant device before connecting it to this machine according to instructions given in the device’s instruction manual.

(1) Make sure that the PictBridge compliant

device is turned off.

(2) Connect the PictBridge compliant device to

the machine using a USB cable recommended by the manufacturer of the device. The device turns on automatically.

If your device does not turn on automatically, turn it on manually.

(3) Set up the PictBridge compliant device for

direct printing.

will appear on the LCD of the device

when the machine is correctly connected.

Note

If does not appear, see “Cannot Print Properly from a Digital Camera” on page 91.

(2)

44 Printing Photographs Directly from a Compliant Device

Page 49

 Printing Photographs Directly from a PictBridge Compliant Device

When operating the device, be sure to follow the instructions given in the instruction manual of your PictBridge compliant device. This section describes the page size, media type, layout, image optimization modes, and date printing mode that can be set on a PictBridge compliant device connected to the machine.

z Confirming or Changing PictBridge Print Settings from Your Camera

To change the page size or media type, operate the device to select the PictBridge print setup mode and confirm or change the settings.

About the Settings Explained Below

Some setting items explained below may not be available on some devices. In this case, the Default setting explained below is applied for the setting item.

* In the following description, names of settings items are given according to those used in

Canon-brand PictBridge compliant devices. Setting item names may be different depending on the brand or model of your device.

The settings below can be changed in the PictBridge settings screen on the machine when a PictBridge compliant device is connected. However, changes can be made in the PictBridge settings screen on the machine only when the corresponding items below are in the Default setting items (the setting to follow that of the machine) on the PictBridge compliant device.

See “Confirming or Changing PictBridge Print Settings on the Machine” on page 48.

PictBridge compliant device setting items

Paper size: Default You can change the following settings on the PictBridge

Paper type: Default

Layout: Default

Image optimize: Default You can change the following settings on the PictBridge

Machine setting on the Print Setting screen

settings screen: Page size, Media type, Bordered/Borderless

For the setting items, see “Setting items” on page 48.

settings screen: Photo opt.pro, Vivid photo, Face brightener, Noise

reduction, Image optimizer, Red eye correc., Brightness, Contrast, Color hue, Effects

For the setting items, see “Setting items” on page 48.

z Printable Image Data Format

This machine prints images taken with a DCF® (Design rule for Camera File system)compatible digital camera*, as well as PNG files.

* Exif2.21 compliant

45Printing Photographs Directly from a Compliant Device

Page 50

z Paper Size and Paper Type Settings

If these settings are set to Default (the setting to follow that of the machine) on the PictBridge compliant device, the Page size and the Media type settings specified in the PictBridge settings of the machine are applied.

The following sizes and types of printing paper can be loaded according to the Paper size and Paper type settings.

Paper Size Setting Paper Type Setting

Loadable Paper

10 x 15 cm/4" x 6" Photo Photo Paper Plus Glossy

Fast Photo Photo Paper Pro

Photo Photo Paper Plus Semi-gloss

Photo Glossy Photo Paper

Glossy Photo Paper “Everyday Use”

Photo Paper Glossy

Photo Stickers

13 x 18 cm/5" x 7"

*3, *4

Photo Photo Paper Plus Glossy

Fast Photo Photo Paper Pro

Photo Photo Paper Plus Semi-gloss

Photo Glossy Photo Paper

Photo Glossy Photo Paper “Everyday

Use”

8.5" x 11" (Letter)

*3, *4

Photo Photo Paper Plus Glossy

Fast Photo Photo Paper Pro

Photo Photo Paper Plus Semi-gloss

Photo Glossy Photo Paper

Photo Photo Paper Glossy

5.4 x 8.6 cm/Credit card Photo Glossy Photo Paper

20 x 25 cm/8" x 10"

10.1 x 18 cm/4" x 7.1"

Fast Photo Photo Paper Pro

*1 Exclusively used to print photo stickers. When printing on sticker paper, select 10 x 15

cm/4" x 6" in Paper size. *2 Can be selected only on certain Canon-brand PictBridge compatible devices. *3 Plain Paper can be selected for Paper type only when Paper size is set to A4 or 8.5" x

11" (Letter). When Paper type is set to Plain Paper, borderless printing will be disabled

even when Layout is set to Borderless. *4 You can print in 4-up layout when Paper size is set to A4 or 8.5" x 11" (Letter). *5 Feeding this paper from the Cassette can damage the machine. Load in the Auto Sheet

Feeder. *6 You may not be able to purchase some Canon genuine papers depending on your

country. *7 When printing on Photo Paper Plus Semi-gloss 8" x 10" / 203.2 x 254.0 mm (SG-201),

select 20 x 25 cm/8" x 10" for Paper size and Default for Paper type.

* Select Photo Plus Glossy for Media type in the PictBridge settings screen on the

machine. See “Confirming or Changing PictBridge Print Settings on the Machine” on page 48.

*1, *5

46 Printing Photographs Directly from a Compliant Device

Page 51

z Layout and Trimming Settings

If Layout is set to Default (the setting to follow that of the machine) on the PictBridge compliant device, the print setting specified in the PictBridge settings of the machine is applied. The setting on the PictBridge compliant device is applied for Trim ming.

When printing onto Photo Stickers (PS-101), select N-up for Layout, then select 16-up. * Some PictBridge compliant devices may display the Layout option 2-up, 4-up, 9-up, and

16-up. In this case always select 16-up.

* If there are no options on the PictBridge compliant device that correspond to 16-up,

printing on stickers is not possible.

* When printing on Photo Stickers (PS-101), do not set Layout to Borderless.

z Image Optimize Setting

If Image optimize is set to Default (the setting to follow that of the machine) on the PictBridge compliant device, the print setting specified in the PictBridge settings of the machine is applied. For details on the setting, see “Confirming or Changing PictBridge Print Settings from Your Camera” on page 45.

If you are using a Canon-brand PictBridge compatible device, additional options of VIVID,

NR, Face, or Red eye may be available, depending on the model. * VIVID prints green and blue portions of photos more vividly.

NR (Noise Reduction) reduces noise in blue portions, such as the sky, and dark portions. Face corrects the contrast of backlit images. Red eye corrects red eyes.

z Date/File No. Print Setting

You cannot change this setting on this machine. The setting on the PictBridge compliant device is applied.

If the images already have dates superimposed when shot, set this PictBridge setting item to Off. If you select Date, File No., or Both, the date and/or file number will be printed over the date printed by the camera’s function.

z Other Settings

The following additional options are available for Canon-brand PictBridge-compliant devices, depending on the model. For details, refer to your Canon-brand PictBridge compliant device’s instruction manual.

Shooting Info (Exif Data)

You can print shooting Info (Exif Data) on photos in list format, or in the margins of specified photos. In Layout select the item with the “i” icon.

35 mm Film Style Layout (Contact Printing Layout)

You can print selected photos or index-specified photos in 35 mm film style layout (contact printing layout).

In Layout select the item with the film icon.

Note

z Never disconnect the USB cable during printing unless when explicitly allowed to by the

PictBridge compliant device. When disconnecting the USB cable between the PictBridge compliant device and machine, follow the instructions given in the device’s instruction manual.

z You cannot set or do the following by operating on the PictBridge compatible device.

– Print quality setting – Machine maintenance

47Printing Photographs Directly from a Compliant Device

Page 52

z Confirming or Changing PictBridge Print Settings on the Machine

You can confirm and change the print settings such as media type and size that are preset to the machine and applied to PictBridge printing.

z Displaying the PictBridge Settings Screen and Specifying the Settings

(1) Turn on the machine.

See “Turning the Machine On and Off” on page 4.

(2) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

(3) Select Device settings, then press the OK button.

(4) Select PictBridge settings, then press the OK button.

(5) Select the item to set, then press the OK button.

(6) Select the item, then press the OK button.

(7) Confirm the print settings, select Next and then press the OK button.

(8) Repeat steps (5) and (6) to specify the item.

(9) After finishing all settings you need, select OK and then press the OK button.

z Setting items

Page size

Select the page size, when printing directly from a PictBridge compliant device.

Media type

Select the media type, when printing directly from a PictBridge compliant device.

Print quality

Select the print quality, when printing directly from a PictBridge compliant device.

Bordered/Borderless

Select bordered or borderless print.

Photo opt.pro

Activate/deactivate the Photo Optimizer pro function.

Automatically optimizes brightness and tone of a photo.

Vivid photo

Activate/deactivate Vivid photo function.

Makes green and blue more lively.

Face brightener

Activate/deactivate Face brightener function.

Brightens a darkened face on the photo taken against the light.

Noise reduction

Activate/deactivate the Noise reduction function.

Reduces the noise on blue areas like the sky as well as on black areas.

Image optimizer

Activate/deactivate Image optimizer function.

Corrects and smooths the jagged contours for printing.

Red eye correc.

Activate/deactivate Red eye correction.

Corrects red eyes in portraits caused by flash photography.

Brightness

Adjust brightness.

48 Printing Photographs Directly from a Compliant Device

Page 53

Contrast

Adjust contrast.

Color hue

Adjust color hue.

Effects

Applies special effects to the photo, such as printing in sepia tones or with a sketch

illustration like effect.

49Printing Photographs Directly from a Compliant Device

Page 54

Routine Maintenance

Replacing an Ink Tank

When ink runs out, replace the ink tank. The machine will not print if the wrong type of ink tank is used, or if it is installed in the incorrect position.

The machine uses the following ink tanks.

Black: CLI-8BK Cyan: CLI-8C

Photo Cyan: CLI-8PC Photo Magenta: CLI-8PM

Black: PGI-5BK Yellow: CLI-8Y

Magenta: CLI-8M

Note

z Be sure to install the ink tanks in the correct order. The proper arrangement from the left is Black ,

Photo Cyan , Black , Magenta , Cyan , Photo Magenta , Yellow .

z If printing becomes faint or white streaks appear despite sufficient ink levels, see “When Printing

Becomes Faint or Colors Are Incorrect” on page 56.

 Getting the Ink Level Information

You can confirm the ink level in each ink tank by the ink lamps. Open the Scanning Unit (Printer Cover) of the machine to confirm how the ink lamps light or flash.

Ink is low:

......Repeats

The ink lamp flashes slowly (at around 3-second intervals). You can continue printing for a while, but we recommend you to have a replacement ink tank available.

Ink is out:

......Repeats

The ink lamp flashes quickly (at around 1-second intervals). Replace the ink tank with a new one.

* If an ink tank related error message is displayed on the LCD, an ink tank error has occurred

and the machine is unable to print. For details, see “Error Message Is Displayed on the LCD” on page 72.

50 Routine Maintenance

Page 55

 Knowing When to Replace Ink Tank

Identify the empty ink tank on the LCD and replace it.

If the “!” symbol is displayed above an ink tank

If the machine detects low ink when you start printing, the “!” symbol is displayed on the LCD.

Obtain a replacement tank as soon as possible.

(A)

(A) Ink tanks with low ink

If the “X” symbol is displayed above an ink tank

(B)

(B) Ink tanks that may have run out of ink.

z Ink may have run out. Replacing the ink tank is recommended.

z Press the Stop/Reset button to cancel printing. Replace the ink tank with a new one.

z If printing is in progress and you want to continue printing, press the OK button with the ink

tank installed. Then printing can continue. Replacing the ink tank is recommended after the printing. The machine may be damaged if printing is continued under the ink out condition.

If an empty ink tank is displayed distinctly from other ink tanks

(C)

z Ink has run out. Replace the ink tank.

Printing under the current condition may damage the machine.

z If you want to continue printing in this condition, you need to release the function for detecting

the remaining ink level. Press and hold the Stop/Reset button for at least 5 seconds, and then release it.

* With this operation, releasing the function for detecting the remaining ink level is

memorized. Please be advised that Canon shall not be liable for any malfunction or trouble which may be caused by continuation of printing under the ink out condition.

51Routine Maintenance

Page 56

 Replacing Ink Tanks

When ink tanks run out of ink, replace them using the following steps.

Important

Handling Ink

z To maintain optimal printing quality, we recommend the use of specified Canon brand ink tanks.

Refilling ink is not recommended.

z Once you remove an ink tank, replace it immediately. Do not leave the machine with ink tanks

removed.

z Replace empty tanks with new ones. Inserting partially used ink tanks may cause the nozzles to

clog. Furthermore, with such tanks, the machine will not be able to inform you when to replace the tanks properly.

z Once an ink tank has been installed, do not remove it from the machine and leave it out in the

open. This will cause the ink tank to dry out, and the machine may not operate properly when it is reinstalled. To maintain optimal printing quality, use an ink tank within six months of first use.

z Color ink may be consumed even when printing a black-and-white document or when black-

and-white printing is specified. Color ink is also consumed in Print Head Cleaning and Print Head Deep Cleaning, which may be necessary to maintain the machine’s performance. When an ink tank is out of ink, replace it

immediately with a new one.

1 Open the Paper Output Tray.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

2 Make sure that the machine is turned on, and

raise the Scanning Unit (Printer Cover) until it stops.

The Print Head Holder moves to the center.

Caution

z Do not hold the LCD or the Operation Panel. z If the Document Cover is opened, you cannot open

the Scanning Unit (Printer Cover). Be sure to open the Scanning Unit (Printer Cover) and the Document Cover at the same time.

Important

If the Scanning Unit (Printer Cover) is left open for more than 10 minutes, the Print Head Holder moves to the right. Close and reopen the Scanning Unit (Printer Cover) to return the holder to the center.

3 Open the Inner Cover.

Caution

z Do not hold the Print Head Holder to stop or move

it.

z Do not touch the metallic parts inside the machine.

52 Routine Maintenance

Page 57

4 Remove the ink tank whose lamp is flashing

fast.

(1) Push the tab and remove the ink tank.

Important

z Handle ink tanks carefully to avoid staining clothing

or the surrounding area.

z Discard empty ink tanks according to the local laws

and regulations regarding disposal of consumables.

Note

z Do not remove more than one ink tank at a time. Be

sure to replace ink tanks one by one when replacing more than one ink tank.

z For details on ink lamp flashing speeds, see

“Getting the Ink Level Information” on page 50.

*1 Do NOT touch the Print Head Lock

Lever; remove only the ink tank.

5 Prepare the replacement tank.

(1) Remove the new ink tank from its packaging,

then pull the orange tape in the direction of the

arrow (A) so that the protective film does not

remain on the air hole (B). Then remove the

film completely (C).

Important

Make sure that all the orange tape has been peeled off along the perforation. If part of the orange tape is remaining, ink may leak out when you remove the protective cap and may not eject properly when printing.

(2) Remove the orange protective cap from the

bottom of the ink tank.

Discard the cap once it is removed.

Important

z Be sure to remove the clear film from the ink tank in

the exact order shown in step 5-(1), as failure to follow this step may cause the ink to leak and stain your clothes and hands.

z Do not squeeze the side of ink tanks as this may

cause the ink to leak out and stain your clothes and hands.

z Do not re-attach the protective cap once you have

removed it. Discard it according to the local laws and regulations regarding disposal of consumables.

z Do not touch the open ink port once the protective

cap is removed, as this may prevent the ink from being ejected properly.

z Be careful not to stain your clothes and hands with

ink on the removed protective cap.

(1)

(C)

(2)

*2 *1

*1 Do not touch the electrical contacts

on the ink tank. Doing so can cause the machine to malfunction or become unable to print.

*2 Carefully hold the protective cap

when removing it to prevent the ink from staining your fingers.

(A)

(B)

53Routine Maintenance

Page 58

6 Install the ink tank.

(1) Insert the front end of the ink tank into the Print

Head.

(2) Press on the mark on the ink tank until the

ink tank snaps firmly into place.

(3) Make sure that the ink lamp lights up red.

Important

The machine cannot be used unless all the ink tanks are installed.

7 Close the Inner Cover.

(1)

(2)(3)

*1 Make sure the position of the tank

matches the label.

Note

Make sure that the Inner Cover is closed. Printing will not start with the Inner Cover open since paper can not be fed properly.

8 Gently close the Scanning Unit (Printer Cover).

Caution

z Be sure to hold the Scanning Unit (Printer Cover) firmly using both hands, and be careful not to

get your fingers caught.

z Do not hold the LCD or the Operation Panel.

Note

z If the error message is still displayed after the Scanning Unit (Printer Cover) is closed, see

“Error Message Is Displayed on the LCD” on page 72.

z When you start printing after replacing the ink tank, Print Head Cleaning is performed

automatically. Do not perform any other operations until Print Head Cleaning finishes.

54 Routine Maintenance

Page 59

Keeping the Best Printing Results

To avoid drying of the Print Head and clogging of the nozzles, note the following.

 When You Turn Off the Machine

Follow the procedure below to turn off the machine.

(1) Press the ON/OFF button to turn off the machine.

(2) Confirm that the POWER lamp has gone out.

This takes a few seconds or as long as around 30 seconds.

(3) Unplug the power cord from the wall outlet.

If you are using a power outlet strip, you can switch it off instead.

When you press the ON/OFF button to turn off the machine, the machine automatically puts a protective cap on the Print Head to prevent the ink from drying. If you remove the power cord or switch off the power outlet strip before the POWER lamp goes out, this capping will not be done properly, causing the Print Head to dry and clog.

 When You Are Not Using the Machine for a Long Time

When you are not using the machine for a long time, print or copy in both black & white and in color, or perform Print Head Cleaning, about once a month to prevent degradation of the Print Head.

Numerous nozzles are installed in the Print Head for high-precision printing. Just as the uncapped tip of a ballpoint pen or marker becomes dry and unusable if it is not used for a long period of time, the print head nozzles become blocked by dried ink. Periodically printing or cleaning the Print Head can prevent this blockage.

Note

z If the printed area is traced with a highlight pen or paint-stick or stained with water or sweat, ink

may blur depending on the paper.

z If the print head nozzles get clogged, printouts will become faint or particular colors will not be

printed properly. For details, see “When Printing Becomes Faint or Colors Are Incorrect” on page 56.

55Routine Maintenance

Page 60

When Printing Becomes Faint or Colors Are Incorrect

When printing becomes faint or colors are incorrect even if ink remains in the ink tanks, the print head nozzles are probably clogged. Print the nozzle check pattern to confirm the condition of the nozzles and then perform Print Head Cleaning.

If the ruled lines are shifted after running print head maintenance, align the Print Head.

Note

Before performing maintenance

z Open the Scanning Unit (Printer Cover) and make sure that all lamps for the ink tanks are lit red.

– If any one of the lamps is flashing slowly, the associated ink tank is running low. You can continue

printing for a while, but we recommend you to have a replacement ink tank available.

– If any one of the lamps is flashing fast, the associated ink tank is empty. Replace the ink tank.

See “Replacing Ink Tanks” on page 52. If an ink lamp is flashing fast even though ink remains in that ink tank, it is inserted in the wrong position. Make sure that the ink tank of the correct color is inserted in each position, matching the label. See “Replacing an Ink Tank” on page 50.

– If the ink lamp is not lit, the tank is not set properly. Press the mark on the ink tank until the tank

clicks into place. Make sure that all packaging material is peeled off the ink tank. See “Prepare the replacement tank.” on page 53.

z Increase the Print Quality setting in the printer driver settings.

See “Print Results Not Satisfactory” on page 78.

Step 1

See “Printing the Nozzle Check Pattern” on page 57.

If lines are missing or if white streaks appear After cleaning the

Print Head, print

and examine the

nozzle check

pattern.

Step 2

See “Print Head Cleaning” on page 60.

If the problem is not resolved after performing

Print Head Cleaning twice

Step 3

See “Print Head Deep Cleaning” on page 62.

Note

If Print Head Deep Cleaning does not resolve the problem, the Print Head may be damaged. Contact your Canon service representative.

z If the Ruled Lines Are Shifted

Step 1

See “Aligning the Print Head” on page 64.

56 Routine Maintenance

Page 61

Printing the Nozzle Check Pattern

Print the nozzle check pattern to determine whether the ink ejects properly from the Print Head.

Note

Make sure that the Inner Cover is closed.

1 Make sure that the machine is turned on, then load a sheet of A4 or Letter-sized

plain paper in the Auto Sheet Feeder or the Cassette.

2 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

3 Press the Paper Feed Switch to select the paper source where you have loaded

paper.

4 Print the nozzle check pattern.

(1) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

(2) Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

(3) Select Nozzle check pattern and then press

the OK button.

The pattern print confirmation screen is

displayed.

(3)

(4) Select Yes and then press the OK button.

The nozzle check pattern is printed, and the

pattern confirmation screens are displayed

alternately.

(4)

5 Examine the pattern and take the appropriate action.

See “Examining the Nozzle Check Pattern” on page 58.

57Routine Maintenance

Page 62

Examining the Nozzle Check Pattern

Follow the procedure below to examine the nozzle check pattern, and perform cleaning if necessary.

Note

If the ink level is low, the nozzle check pattern is not printed correctly. Replace the relevant ink tank. See “Replacing an Ink Tank” on page 50.

1 Check the nozzle check pattern you printed.

(1)

(2)

(1) Check if lines in this pattern are missing.

(A) (B)

(A) Good

(B) Lines are missing

(2) Check if there are white streaks in this pattern.

(A) (B)

(A) Good

(B) White streaks present

58 Routine Maintenance

Page 63

2 The confirmation screens for white streaks and missing lines are displayed

alternately. Select the pattern that is closer to the nozzle check pattern that you printed.

z If There Are No Missing Lines and No White Streaks

(1) Select All A and press the OK button.

The LCD returns to the Maintenance screen.

(1)

z If Lines Are Missing or White Streaks Are

Present

(1) Select Also B and press the OK button.

The cleaning confirmation screen is

displayed.

(1)

(2) Select Yes and press the OK button to start

Print Head Cleaning.

See “Print Head Cleaning” on page 60.

(2)

59Routine Maintenance

Page 64

Print Head Cleaning

Clean the Print Head if lines are missing or if white streaks appear in the printed nozzle check pattern. Cleaning unclogs the nozzles and restores the print head condition. Note that cleaning the Print Head causes used ink to be absorbed in the ink absorber. Cleaning the Print Head consumes ink, so perform Print Head Cleaning only when necessary.

Note

Make sure that the Inner Cover is closed.

1 Make sure that the machine is turned on, then load a sheet of A4 or Letter-sized

plain paper in the Auto Sheet Feeder or the Cassette.

2 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

3 Press the Paper Feed Switch to select the paper source where you have loaded

paper.

4 Start Print Head Cleaning.

(1) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

(2) Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

(3) Select Cleaning, then press the OK button.

The confirmation screen is displayed.

(4) Select Yes, then press the OK button.

Print Head Cleaning starts.

Do not perform any other operations until Print

Head Cleaning finishes. This takes about 1

minute.

The pattern print confirmation screen is

displayed.

(5) Select Yes, then press the OK button.

The nozzle check pattern is printed.

60 Routine Maintenance

(3)

(4)

Page 65

5 Check the print head condition with the printed nozzle check pattern, and take

appropriate action.

See “Examining the Nozzle Check Pattern” on page 58.

Note

If the problem is not resolved after performing steps 4 and 5 twice, try Print Head Deep Cleaning. See “Print Head Deep Cleaning” on page 62.

61Routine Maintenance

Page 66

Print Head Deep Cleaning

If print quality does not improve by standard Print Head Cleaning, try Print Head Deep Cleaning, which is a more powerful process. Note that cleaning the Print Head causes used ink to be absorbed in the ink absorber. Print Head Deep Cleaning consumes more ink than standard Print Head Cleaning, so perform this procedure only when necessary.

Note

Make sure that the Inner Cover is closed.

1 Make sure that the machine is turned on, then load a sheet of A4 or Letter-sized

plain paper in the Auto Sheet Feeder or the Cassette.

2 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

3 Press the Paper Feed Switch to select the paper source where you have loaded

paper.

4 Start Print Head Deep Cleaning.

(1) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

(2) Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

(3) Select Deep cleaning, then press the OK

button.

The confirmation screen is displayed.

(4) Select Yes, then press the OK button.

Print Head Deep Cleaning starts.

Do not perform any other operations until Print

Head Deep Cleaning finishes. This takes about

1 minute 30 seconds.

62 Routine Maintenance

(3)

(4)

Page 67

5 Check the condition of the Print Head.

(1) Print the nozzle check pattern to check the print head condition.

See “Printing the Nozzle Check Pattern” on page 57.

If a particular color is not printed properly, replace the ink tank of that color.

See “Replacing an Ink Tank” on page 50.

(2) If the print head nozzles are still not clean, turn off the machine and perform another Print

Head Deep Cleaning after 24 hours.

(3) If this does not solve the problem, the Print Head may be damaged. Contact your Canon

service representative.

63Routine Maintenance

Page 68

Aligning the Print Head

If ruled lines are printed misaligned or print results are otherwise unsatisfactory, adjust the print head position.

Note

Make sure that the Inner Cover is closed.

 Automatic Print Head Alignment

Note

You cannot feed paper from the Cassette when performing Automatic Print Head Alignment. Always load paper in the Auto Sheet Feeder.

1 Make sure that the machine is turned on, and then load a sheet of A4 or Letter-

sized plain paper in the Auto Sheet Feeder.

2 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

3 Adjust the print head position.

(1) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

(2) Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

(3) Select Auto head align, then press the OK

button.

The confirmation screen is displayed.

Note

If you select Head alignment print, the machine exits the process after printing the current head position adjustment values.

(4) Select Yes, then press the OK button.

The print head is aligned automatically, and the

print head pattern after the adjustment is

printed out. This takes about 3 minutes 30

seconds.

Note

z The print head alignment pattern is printed in

black and blue.

z If adjustment was not done successfully, the

“Auto head align has failed.” error message is displayed on the LCD. For details, see “Error Message Is Displayed on the LCD” on page 72.

z If results of Automatic Print Head Alignment

are not satisfactory, perform Manual Print Head Alignment. For details, see “Manual Print Head Alignment” on page 65.

64 Routine Maintenance

(3)

(4)

Page 69

 Manual Print Head Alignment

If the results of Automatic Print Head Alignment are not satisfactory, follow the procedure below to perform Manual Print Head Alignment.

For details on performing Automatic Print Head Alignment, see “Automatic Print Head Alignment” on page 64.

1 Make sure that the machine is turned on, and then load three sheets of A4 or

Letter-sized plain paper in the Auto Sheet Feeder or the Cassette.

Important

You cannot print the print head alignment pattern if paper of size other than A4 or Letter is loaded. Be sure to use A4 or Letter-sized plain paper.

2 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

3 Press the Paper Feed Switch to select the paper source where you have loaded

paper.

4 Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

5 Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

6 Select Manual head align, then press the OK button.

Confirmation screen is displayed.

Note

If you select Head alignment print, the machine exits the process after printing the current head position adjustment values.

7 Select Yes, then press the OK button.

8 When the Print Head alignment pattern is printed, select Ye s, then press the OK

button.

65Routine Maintenance

Page 70

9 Look at the printout. From the patterns, select

the most even, least irregular patterns for each column and input their numbers. Press the OK button.

(1) Select a column to input the pattern number. (2) Use the [ or ] button to input the number of

the pattern.

(3) Repeat the steps (1) and (2) until you finish

inputting all pattern numbers, press the OK

button.

10 When the confirmation message is displayed, press the OK button.

11 Look at the printout. From the patterns, select

the best patterns for each column and input their numbers. Press the OK button.

In the same way in step 9, input the numbers.

Columns G to J are striped vertically and column K is striped horizontally. For Column K, the best pattern will be smooth and have no streaks in the border indicated by the arrows.

Note

If it is difficult to pick the best pattern, pick the setting that produces the least noticeable vertical white streaks.

(B)(A)

(A) Less noticeable white streaks

(B) More noticeable white streaks

12 When the confirmation message is displayed, press the OK button.

66 Routine Maintenance

Page 71

13 Look at the printout. From the patterns, select

the most even patterns for each column and input their numbers. Press the OK button.

In the same way in step 9, input the numbers.

Note

When you turn off the machine, be sure to press the ON/OFF button on the machine. Otherwise, the settings made here will not be saved.

67Routine Maintenance

Page 72

Cleaning Your Machine

This section describes the cleaning procedure that is needed to maintain your machine.

Caution

z Be sure to turn off the power and disconnect the power cord before cleaning the machine. z Do not use tissue paper, paper towels, or similar materials for cleaning. Paper tissue powders or fine

threads may remain inside the machine and cause problems such as a blocked Print Head and poor printing results. Use a soft cloth to avoid scratching the components.

z Never use volatile liquids such as thinners, benzene, acetone, or any other chemical cleaner to clean

the machine; these can damage the machine’s components.

 Cleaning the Platen Glass and Document Cover

Moisten a clean, soft, lint-free cloth and wring out excess water. With it, wipe the Platen Glass (A), the inner side of the Document Cover (white sheet) (B), and FAU lamp (C). Then wipe with another clean, soft, dry, lint-free cloth, making sure not to leave any residue, especially on the Platen Glass.

Important

The sheet (B) is easily damaged, so wipe it gently.

(B)

(A)

(C)

 Cleaning the Paper Feed Rollers (Roller Cleaning)

Clean the paper feed rollers if paper is not fed properly. Cleaning the paper feed rollers will wear the rollers, so perform this only when necessary.

Note

Make sure that the Inner Cover is closed.

1 Make sure that the machine is turned on, and then remove any paper from the Auto

Sheet Feeder and Cassette.

2 Press the Paper Feed Switch to select the paper source to clean.

68 Routine Maintenance

Page 73

3 Clean the paper feed rollers.

(1) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

The Settings screen is displayed.

(2) Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

(3) Select Roller cleaning, then press the OK button.

The confirmation screen is displayed.

(4) Select Yes, then press the OK button.

The Paper Feed Rollers will rotate as they clean.

4 Repeat step 3 twice.

5 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

6 Load three or more sheets of A4 or Letter-sized plain paper in portrait orientation in

the paper source you selected in step 2.

7 Repeat step 3 three times.

The paper cleans the inside of the machine as it feeds through the machine.

If there are no signs of improvement after performing cleaning three times, contact a Canon service representative.

 Cleaning the Inside of the Machine (Bottom Plate Cleaning)

This section describes how to clean the inside of the machine. If the inside of the machine becomes dirty, printed paper may get dirty, so we recommend performing cleaning regularly.

Note

Make sure that the Inner Cover is closed.

1 Make sure that the machine is turned on, and then remove any paper from the Auto

Sheet Feeder.

2 Open the Paper Output Tray, and then open the Output Tray Extension.

(1) Put your finger on the top of the Paper Output Tray and open it gently.

(2) Open the Output Tray Extension.

3 Fold a single sheet of A4 or Letter-sized plain paper in half widthwise, and then

unfold the paper.

69Routine Maintenance

Page 74

4 Load this and only this sheet of paper in the

Auto Sheet Feeder with the open side to the front.

5 Perform bottom plate cleaning.

(1) Select Settings on the HOME screen.

See “Basic Operation for the Operation Panel” on page 2.

The Settings screen is displayed.

(2) Select Maintenance, then press the OK button.

The Maintenance screen is displayed.

(3) Select Bottom plate cleaning, then press the OK button.

The confirmation screen is displayed.

(4) Select Yes, then press the OK button.

The paper cleans the inside of the machine as it feeds through the machine.

If the ejected paper is smudged, clean the inside of the machine again.

If the problem is not resolved after performing cleaning again, the protrusions inside the

machine may be stained. Clean them according to instructions. See “Cleaning the

Protrusions Inside the Machine” on page 70.

Important

z Even if the Cassette is selected as the paper source, paper will be fed from the Auto Sheet

Feeder.

z Do not perform any other operation while the bottom plate is being cleaned.

 Cleaning the Protrusions Inside the Machine

If protrusions inside the machine are stained, wipe off any ink from the protrusions using a cotton swab or the like.

Important

Before cleaning the inner parts, be sure to turn the machine off.

70 Routine Maintenance

Page 75

Troubleshooting

This section describes troubleshooting tips for problems you may encounter when using the machine.

Note

If you cannot find appropriate tips for your problem, refer to the on-screen manuals.

z “Error Message Is Displayed on the LCD” on page 72

z “LCD Cannot Be Seen At All” on page 74

z “An Unintended Language Is Displayed on the LCD” on page 75

z “Cannot Install the MP Drivers” on page 76

z “Cannot Connect to Computer Properly” on page 77

z “Printing Speed Is Slow / USB 2.0 Hi-Speed Connection Does Not Work” on page 77

z ““Hi-Speed USB Device Plugged into non-Hi-Speed USB Hub” or “This Device Can

Perform Faster” Message Is Displayed (Windows XP Only)” on page 77

z “Print Results Not Satisfactory” on page 78

z “Cannot Print to End of Job” on page 78

z “Part of the Page Is Not Printed” on page 78

z “Colors Are Unclear” on page 78

z “Ink Does Not Come Out/Printing Does Not Start/Printing Is Blurred/Colors Are Wrong/

Straight Lines Are Misaligned” on page 79

z “White Streaks” on page 80

z “Printed Paper Curls or Has Ink Blots” on page 80

z “Printed Surface Is Scratched/Paper Is Smudged” on page 80

z “Colors Are Uneven or Streaked” on page 82

z “Printing Problems When Copying” on page 82

z “Printing Does Not Start” on page 82

z “Paper Does Not Feed Properly” on page 84

z “Paper Jams” on page 85

z “Error Message Appears on the Screen” on page 88

z “Writing Error/Output Error/Communication Error” on page 88

z “Error Regarding Automatic Duplex Printing Is Displayed” on page 89

z “Error No.: 300 Is Displayed” on page 89

z “Error No.: 1700 Is Displayed” on page 90

z “Error No.: 1851 Is Displayed” on page 90

z “Error No.: 1856 Is Displayed” on page 90

z “Error No.: 2001 Is Displayed” on page 90

z “Error No.: 2500 Is Displayed” on page 90

z “Cannot Print Properly from a Digital Camera” on page 91

z “Cannot Print Properly from a Photo Index Sheet” on page 92

z “Cannot Scan Films” on page 93

z “Cannot Obtain a Clean Scan or Colors Scan Incorrectly (Displayed Image Is Not Clear)” on

page 93

z “Frames Are Not Detected Correctly” on page 93

71Troubleshooting

Page 76

If an Error Occurs When the Machine Is Connected to a Computer

When an error occurs in printing such as the machine is out of paper or paper is jammed, a troubleshooting message is displayed automatically. Take the appropriate action described in the message.

The message may vary depending on the version of your Windows operating system.

Error Message Is Displayed on the LCD

If an error message is displayed on the LCD, take the corresponding action described below.

Message Action

“There are no photos in memory card.”

“The following ink may have run out. Replacing the ink tank is recommended.”

U041

“The following ink has run out. Replace the ink tank.”

U163

z There are no image data stored on the memory card that can be read by this

machine.

z The machine may not recognize the file if the file name or the folder path

contains certain characters. Use only alphanumeric characters.

z Photo data edited or processed on a computer must be printed from the

computer.

If the lamp on the ink tank is flashing, ink may have run out.

Replacing the ink tank is recommended.

If printing is in progress and you want to continue printing, press the OK button with the ink tank installed. Then printing can continue. Replacing the ink tank is recommended after the printing. The machine may be damaged if printing is continued under the ink out condition. See “Replacing an Ink Tank” on page 50.

Note

If multiple ink lamps are flashing red, check how fast they are flashing. Fast flashing (at about 1-second intervals) indicates the tank is empty. Slow flashing (at about 3-second intervals) indicates ink is low. For details on different flashing speeds, see “Getting the Ink Level Information” on page 50.

Ink has run out. (The lamp on the ink tank flashes.)

Replace the ink tank and close the Scanning Unit (Printer Cover).

Printing under the current condition may damage the machine.

If you want to continue printing in this condition, you need to release the function for detecting the remaining ink level. Press and hold the Stop/Reset button for at least 5 seconds, and then release it.

* With this operation, releasing the function for detecting the remaining ink

level is memorized. Please be advised that Canon shall not be liable for any malfunction or trouble which may be caused by continuation of printing under the ink out condition. See “Replacing an Ink Tank” on page 50.

72 Troubleshooting

Page 77

Message Action

“Print head is not installed. Install the print head.”

U051

“The type of print head is incorrect. Install the correct print head.”

U052

“Inner cover is open. Close the inner cover and press OK.”

“Some ink tanks are not installed in place.”

U072

“More than one ink tank of the following color is installed.”

U071

“The ink absorber is almost full. Press OK to continue printing. Contact the service center.”

“The device may be incompatible. Remove the device and check the manual supplied with the connected device.”

“Auto head align has failed. Press OK and repeat operation. <See manual>”

Follow the directions given in the Easy Setup Instructions to install the Print Head.

If the Print Head is already installed, remove the Print Head once and then reinstall it.

If the error is not resolved, the Print Head may be damaged. Contact your Canon service representative.

If the Inner Cover is open when starting printing, close it and then press the OK button on the machine.

Do not open or close the Inner Cover while printing, as this can damage the machine.

Possible causes are as follows:

z Some ink tanks are not installed in the correct position.

z More than one ink tanks of the same color are installed.

Confirm that the ink tanks are installed in the appropriate positions.

See “Replacing an Ink Tank” on page 50.

The machine has a built-in ink absorber to hold the ink used during Print Head Cleaning, for example.

This error message indicates that the ink absorber is nearly full.

Press the OK button to cancel the error so you can continue printing.

However, because printing is disabled once the ink absorber becomes completely full and until the ink absorber is replaced, you are recommended to contact a Canon service representative as early as possible. (You will need to replace a particular part of the machine.)

Disconnect the cable connecting the machine and the device, and then reconnect it.

Depending on the model or brand of your device, you may have to select a PictBridge-compliant print mode on the device before connecting it to the machine. You may also have to turn on the camera or select Play mode manually after connecting the device to the machine. Perform necessary operations according your device’s instruction manual.

If the error is still not resolved, there is a possibility that you are using a digital camera or digital video camcorder that is not supported by this machine. Use a digital camera or digital video camcorder compatible with this machine.

Possible causes are as follows:

z Paper of size other than A4 or Letter is loaded in the Auto Sheet Feeder.

Press the OK button on the machine to dismiss the error message, then load a sheet of A4/Letter-sized paper in the Auto Sheet Feeder.

Automatic Print Head Alignment cannot be performed using paper from the Cassette. For Automatic Print Head Alignment, always load paper in the Auto Sheet Feeder.

z Print Head nozzles are clogged.

Press the OK button to dismiss the error message, and print the nozzle check pattern to check the status of the Print Head. See “Printing the Nozzle Check Pattern” on page 57.

z The Paper Output Slot is exposed to strong light.

Press the OK button to dismiss the error message, and then adjust your operating environment and/or the position of the machine so that the Paper Output Slot is not exposed directly to strong light.

After carrying out the above measures, if the problem continues after aligning the Print Head again, press the OK button to dismiss the error message, and then perform Manual Print Head Alignment. For details on Manual Print Head Alignment, see “Manual Print Head Alignment” on page 65.

73Troubleshooting

Page 78

Message Action

“The remaining level of the follo wing ink cannot be correctly detected. Replace the ink tank.”

U130

“The following ink tank cannot be recognized.”

U140

U150

“**** Error code”

“Scanner is not operating correctly.” Turn off the machine, and unplug the power cord of the machine from the power

“Release the scanner lock switch and turn the power off and back on.”

“The card is currently write-enabled. Set to read-only mode before performing operation.”

The remaining ink level cannot be correctly detected.

Replace the ink tank and close the Scanning Unit (Printer Cover).

Printing with an ink tank that was once empty may damage the machine.

* With this operation, releasing the function for detecting the remaining ink

level is memorized. Please be advised that Canon shall not be liable for any machine malfunction or damage caused by refilled ink tanks. See “Replacing an Ink Tank” on page 50.

z The ink tank is not compatible with this machine. (The lamp on the ink tank is

off.)

Install an appropriate ink tank.

See “Replacing an Ink Tank” on page 50.

z An Ink tank error has occurred. (The lamp on the ink tank is off.)

Replace the ink tank.

See “Replacing an Ink Tank” on page 50.

Turn off the machine, and unplug the power cord of the machine from the power supply. After a while, plug the power cord of the machine back in, and then turn on the machine. If the same error occurs, contact a Canon service representative.

supply. After a while, plug the power cord of the machine back in, and then turn on the machine. If the same error occurs, contact a Canon service representative.

The Scanner Lock Switch is not released. Slide the Scanner Lock Switch to the release position and press the ON/OFF button to turn the machine off. Then, turn the power back on.

If this error still remains, contact a Canon service representative.

The Card Slot is set to Read/write mode.

You cannot print in this mode. After writing on the memory card, set to Read-

only mode.

LCD Cannot Be Seen At All

Cause Action

Cannot see the display on the LCD.

74 Troubleshooting

z If the POWER lamp is off

The machine is not powered on. Connect the power cord and press the ON/ OFF button. The machine will power on and the LCD will display a message.

z If the POWER lamp is lit

The LCD may be in the screen-saver mode. On the Operation Panel, press a button other than the ON/OFF button.

Page 79

An Unintended Language Is Displayed on the LCD

Cause Action

The language you want to be displayed is not selected.

Select the language you want to be displayed according to the following procedure.

(1)Press the HOME button. Wait for about 5 seconds, select , and then

press the OK button.

(2)Press the ] button to select , then press the OK button. (3)Press the } button four times, then press the OK button.

If the Bluetooth unit is connected to the machine, press the } button five times, and then press the OK button.

(4)Press the { or } button to select the language you want to be displayed,

then press the OK button.

75Troubleshooting

Page 80

Cannot Install the MP Drivers

Cause Action

If you were unable to proceed beyond the Printer Connection screen, follow

Unable to proceed beyond the Printer Connection screen.

Installation does not start automatically when the Setup CD-ROM is inserted into your computer’s disc drive.

the procedure below to reinstall the MP Drivers.

(1)Click Cancel on the Printer Connection screen.

(2)Click Start Over on the Installation Failure screen.

(3)Click Back on the screen that appears next.

(4)Click Exit on the Welcome screen, then remove the CD-ROM.

(5)Turn the machine off.

(6)Restart the computer.

(7)Make sure you have no application software running, including anti-virus

software.

(8)Follow the procedure described in the Easy Setup Instructions to reinstall the

MP Drivers.

Click Start > My Computer > double-click the CD-ROM icon .

In non-XP Windows, open the My Computer window and then double-click the CD-ROM icon .

Note

To use the Run command to start the setup program, specify your disc drive and then the name of the setup program, Msetup4.exe. The drive letter of the disc drive depends on your computer.

Installation procedure not followed correctly.

76 Troubleshooting

Double-click the CD-ROM icon on your desktop to start installation.

If the CD-ROM icon is not displayed on the desktop, there may be a problem with the CD-ROM. Contact a Canon service representative.

Follow the procedure described in the Easy Setup Instructions for proper installation.

If the drivers were not installed correctly, uninstall the MP Drivers, restart your computer, and then reinstall the drivers. Refer to the Printer Driver Guide onscreen manual.

Note

If the installer was forced to be terminated due to an Windows error, the system may be in an unstable condition and you may not be able to install the drivers.

Restart your computer before reinstalling.

Page 81

Cause Action

The Setup CD-ROM is defective.

Click Start, select My Computer, and confirm that the CD-ROM icon is visible.

In non-XP Windows, double-click the My Computer icon and confirm that the CD-ROM icon is visible in the window.

Confirm that the CD-ROM icon is displayed when you insert the CD-ROM.

If the CD-ROM icon is not displayed, restart your computer. If the icon is still not displayed, try different disks and see if they are displayed. If other disks are displayed, there is a problem with the Setup CD-ROM. Contact a Canon service representative.

Cannot Connect to Computer Properly

 Printing Speed Is Slow / USB 2.0 Hi-Speed Connection Does Not Work

Cause Action

Your system environment is not fully compatible with USB 2.0 Hi-Speed.

If your system environment is not fully compatible with USB 2.0 Hi-Speed, the machine will operate at a lower speed provided under USB 1.1. In this case, the machine operates properly but printing speed may slow down due to communication speed.

Check the following to ensure that your system environment supports USB 2.0 Hi-Speed connection.

z The USB port on your computer supports USB 2.0 Hi-Speed connection.

z The USB cable, and the USB hub if you are using one, support USB 2.0 Hi-

Speed connection.

Be sure to use a certified USB 2.0 Hi-Speed cable. We recommend the cable to be no longer than around 10 feet (3 meters).

z The operating system of your computer supports USB 2.0 Hi-Speed

connection.

Obtain and install the latest update for your computer.

z The USB 2.0 Hi-Speed driver operates properly.

Obtain the latest version of the USB 2.0 Hi-Speed driver compatible with your hardware and install it on your computer.

Important

For details on USB 2.0 Hi-Speed of your system environment, contact the manufacturer of your computer, USB cable, or USB hub.

 “Hi-Speed USB Device Plugged into non-Hi-Speed USB Hub” or “This

Device Can Perform Faster” Message Is Displayed (Windows XP Only)

Cause Action

The machine is connected to a computer that does not support USB

2.0 Hi-Speed.

Your system environment is not compatible with USB 2.0.

See “Printing Speed Is Slow / USB 2.0 Hi-Speed Connection Does Not Work” on page 77.

77Troubleshooting

Page 82

Print Results Not Satisfactory

 Cannot Print to End of Job

Cause Action

In Windows XP and Windows 2000, click Print Options on the Page Setup sheet. Then, select the Reduce spool data size check box in the displayed

Size of the print data is extremely large (Windows XP/Windows 2000 only).

 Part of the Page Is Not Printed

Cause Action

Page Size setting in the Operation

Panel does not match the actual size of the paper loaded in the machine.

You are performing automatic duplex printing.

dialog.

Selecting Reduce spool data size may reduce the print quality.

If the Page Size setting set in the Operation Panel does not match the actual size of the printing paper, part of the page may not be printed.

Check the Page Size setting on the Operation Panel.

When performing automatic duplex printing, the printable area at the top of the page will be 0.08 inches / 2 mm narrower than the usual. For this reason, the bottom of the page may not be printed. To prevent this, select Use reduced

printing from the printer driver.

Important

Reduced printing may affect the layout depending on your document.

(1)Open the printer properties dialog box.

Refer to “Opening the Printer Properties Dialog Box Directly from the Start Menu” in “Opening the Printer Properties Dialog Box (Windows)” of the User’s Guide on-screen manual.

(2)Click Print Area Setup in the Page Setup sheet and select Use reduced

printing.

 Colors Are Unclear

Cause Action

Media Type setting in the Operation

Panel does not match the actual type of paper.

78 Troubleshooting

(1)Open the Print dialog box.

Refer to “Opening the Print Dialog Box” in “Opening the Page Setup and Print Dialog Box (Macintosh)” of the User’s Guide on-screen manual.

(2)Select Duplex Printing & Margin in the pop-up menu.

(3)Select Automatic Duplex Printing and click Use reduced printing in Print

Area.

Check that the Media Type set in the Operation Panel matches the type of the loaded printing paper.

If you are printing a photograph or an illustration, incorrect Media Type setting may reduce the quality of printout color. The quality of printout color may also be reduced in borderless printing depending on the Media Type setting.

Page 83

 Ink Does Not Come Out/Printing Does Not Start/Printing Is Blurred/

Colors Are Wrong/Straight Lines Are Misaligned

Cause Action

Ink tank is empty. Open the Scanning Unit (Printer Cover) and check the ink lamps.

Ink tank is not installed securely. / Part of the orange tape is remaining.

Media Type setting in the Operation Panel does not match the actual type of paper.

Print Head nozzles are clogged. Print the nozzle check pattern to check for uneven ink output.

If an ink lamp is flashing red slowly at about 3-second intervals, ink is running low. If an ink lamp is flashing red fast at about 1-second intervals or is not lit, the tank is empty.

Replace the ink tank, and close the Scanning Unit (Printer Cover).

See “Replacing an Ink Tank” on page 50.

Note

For details on different flashing speeds, see “Getting the Ink Level Information” on page 50.

Open the Scanning Unit (Printer Cover) and check the ink lamps. If the ink lamp is not lit, press the mark on the ink tank until it clicks into place. The ink lamp lights up red when the ink tank is fully inserted.

Make sure all of the orange tape is peeled off the ink tank and the air hole is completely exposed, as illustrated in (A). If any orange parts are left as in (B), remove all of the orange parts.

(A) (B)

(A) Correct

L-shaped air hole.

(B) Incorrect

Part of the orange tape is remaining. Peel off the tape completely along the perforation.

Make sure that the Media Type set in the Operation Panel matches the type of the loaded printing paper.

z If the nozzle check pattern does not print out properly

Check if any of the missing colors are due to empty tanks.

If there is plenty of ink and the machine does not print, clean the Print Head and then print the nozzle check pattern to check that ink is ejecting properly.

z If the problem is not resolved after performing Print Head Cleaning

twice

Perform Print Head Deep Cleaning.

If the problem is not resolved after performing Print Head Deep Cleaning, turn off the machine and perform Print Head Deep Cleaning again after 24 hours or later.

z If the problem is still not resolved after performing Print Head Deep

Cleaning twice

The Print Head may be damaged. Contact your Canon service representative.

For details on how to print the nozzle check pattern, how to clean the Print Head, and how to perform Print Head Deep Cleaning, see “When Printing Becomes Faint or Colors Are Incorrect” on page 56.

79Troubleshooting

Page 84

Cause Action

The media is loaded with the wrong side facing upwards.

Print Head is misaligned. If you did not align the Print Head after installation, straight lines may be printed

Print quality is not set appropriately. In the Operation Panel, set Print quality in each mode to High(quality-

Many types of paper are made to be printed on only a particular side of the paper.

Printing on the wrong side may cause unclear prints or prints with reduced quality.

Refer to “Printing Media” in the User’s Guide on-screen manual.

misaligned. Make sure to align the Print Head after you install it.

See “Automatic Print Head Alignment” on page 64 and perform Automatic Print Head Alignment. If this does not solve the problem, see “Manual Print Head Alignment” on page 65 and perform Manual Print Head Alignment.

priority).

 White Streaks

Cause Action

Media Type setting in the Operation

Panel does not match the actual type of paper.

Print quality is not set appropriately. In the Operation Panel, set Print quality in each mode to High(quality-

Check that the Media Type set in the Operation Panel matches the type of the loaded printing paper.

priority).

Especially when using coated (high-quality) paper, increasing the Print quality setting is effective in reducing white streaks.

 Printed Paper Curls or Has Ink Blots

Cause Action

Paper is too thin. When printing data with high color saturation such as photographs or images in

Media Type setting in the Operation Panel does not match the actual type of paper.

Print quality is not set appropriately. In the Operation Panel, set Print quality in each mode to High(quality-

deep color, we recommend using Photo Paper Pro or other Canon specialty paper. See “Media Types You Cannot Use” on page 10.

Check that the Media Type set in the Operation Panel matches the type of the loaded printing paper.

priority).

This will reduce blurs even when printing images with plenty of adjacent contrasting colors.

 Printed Surface Is Scratched/Paper Is Smudged

Cause Action

Paper Feed Roller is dirty. If paper is not feeding properly, clean the Paper Feed Rollers. Cleaning the

Inside of the machine is dirty. When performing Two-sided copy, if the paper size specified using the

Paper Feed Rollers will wear the rollers, so perform this procedure only when necessary.

For details on cleaning, see “Cleaning the Paper Feed Rollers (Roller Cleaning)” on page 68.

Operation Panel does not match the actual size of paper loaded in the paper source, the inside will become stained with ink, causing printed paper to become smudged.

Perform the Bottom Plate Cleaning to clean the inside of the machine.

For details on cleaning, see “Cleaning the Inside of the Machine (Bottom Plate Cleaning)” on page 69.

80 Troubleshooting

Page 85

Cause Action

Printing on inappropriate type of paper.

Paper is curled. If you are using paper with either any of the corners or the whole printing

Printing on thick paper. Selecting the Prevent paper abrasion setting will widen the clearance between

z Check to see if the paper you are printing on is not too thick or curled.

See “Media Types You Cannot Use” on page 10.

z When performing Borderless Printing, print quality may be reduced at the top

and bottom edges of the paper. Make sure that the paper you are using is suitable for Borderless Printing.

For details, refer to the Printer Driver Guide on-screen manual.

surface curled, the paper may become dirty, not feed properly, or both. Use such paper after correcting paper curl as follows.

(1)With the printing side (A) facing up, cover the paper with a fresh sheet of

plain paper to avoid staining or scratching the surface.

(2)Roll up the paper in a direction opposite to paper curl as seen below.

(1) (2)

(A)

(3)Check to see that the paper curl is corrected to within approximately 0.08 to

0.2 inches / 2 to 5 mm (B) in height.

(A)

(B)

We recommend printing curl-corrected paper one sheet at a time.

the Print Head and the loaded paper. If you notice abrasion even with the media type set correctly to match the loaded paper, set the machine to prevent paper abrasion.

* Clear the Prevent paper abrasion check box once printing is complete, and

then click Send.

Open the printer properties dialog box, and in Custom Settings in the Maintenance sheet, select the Prevent paper abrasion check box, and then click Send.

In the Canon IJ Printer Utility, select Custom Settings in the pop-up menu, select the Prevent paper abrasion check box, and then click Send.

To open the printer properties dialog box (Windows), refer to “Opening the Printer Properties Dialog Box (Windows)” in the User’s Guide on-screen manual.

To open the Canon IJ Printer Utility (Macintosh IJ Printer Utility (Macintosh)” in the User’s Guide on-screen manual.

When Prevent paper abrasion is selected, the setting is also applied to direct printing from a digital camera.

When performing copy direct printing without using a computer, select Print settings, set Prevent paper abrasion to ON. For details on settings, refer to “Changing the Machine Settings” in the User’s Guide on-screen manual.

), refer to “Opening the Canon

81Troubleshooting

Page 86

Cause Action

Media Type setting in the Operation

Panel does not match the actual type of paper.

Printing graphics with Intensity setting set too high.

Printing beyond the recommended printing area.

Check that the Media Type set in the Operation Panel matches the type of the loaded printing paper.

If you notice abrasion even with the media type set correctly to match the loaded paper, set Prevent paper abrasion to ON in Print settings.

Refer to “Changing the Machine Settings” in the User’s Guide on-screen manual.

Especially if you are using plain paper to print images with high intensity, the paper may absorb too much ink and become wavy, causing paper abrasion. In this case, reduce the Intensity setting in the Operation Panel and try printing again.

If you are printing beyond the recommended printing area of your printing paper, the lower edge of the paper may become stained with ink.

Resize your original document in your application software.

For details on recommended printing area, refer to “Printing Area” in the User’s Guide on-screen manual.

 Colors Are Uneven or Streaked

Cause Action

Print quality is not set appropriately. In the Operation Panel, set Print quality in each mode to High(quality-

priority).

Especially when printing a document that requires a lot of ink, increasing the Print quality setting is effective in reducing uneven colors.

 Printing Problems When Copying

Cause Action

The original document is not loaded correctly.

The print quality setting is not suitable for the original.

The original document is not loaded with the side to be copied faced down.

The original document is a printout from this machine.

The Platen Glass or the inner side of the Document Cover is dirty.

Check that the original is loaded correctly on the Platen Glass.

See “Loading Original Documents” on page 6.

Set the print quality to suit the type of your document.

See “Setting Items in Each Mode” on page 22.

When loading the original on the Platen Glass, the side to be copied should be faced down.

Print quality may be reduced if you copy a printout.

Instead of copying a printout, print the original directly either from the digital camera, memory card, or your computer.

Clean the Platen Glass and the inner side of the Document Cover.

See “Cleaning the Platen Glass and Document Cover” on page 68.

Printing Does Not Start

Cause Action

Ink tank is empty. Open the Scanning Unit (Printer Cover) and check the ink lamps.

82 Troubleshooting

If an ink lamp is flashing red at about 1-second intervals, the tank is empty.

Replace the ink tank, and close the Scanning Unit (Printer Cover). See “Replacing an Ink Tank” on page 50.

If you want to continue printing, confirm the message displayed on the LCD and take the appropriate action. See “Error Message Is Displayed on the LCD” on page 72.

Note

If multiple ink lamps are flashing, check how fast they are flashing.

Fast flashing (at about 1-second intervals) indicates the tank is empty. Slow flashing (at about 3-second intervals) indicates ink is low. For details on different flashing speeds, see “Getting the Ink Level Information” on page 50.

Page 87

Cause Action

Ink tank not installed in proper position. Open the Scanning Unit (Printer Cover) and check the ink lamps.

Ink tank is not installed securely. / Part of the orange tape is remaining.

Unnecessary print jobs are left in queue. / Computer problems.

If there is still sufficient ink but its ink lamp is flashing red, an ink tank may be installed in a wrong position.

Confirm that the ink tanks are installed in the appropriate positions. See “Replacing an Ink Tank” on page 50.

Open the Scanning Unit (Printer Cover) and check the ink lamps.

If the ink lamp is not lit, press the mark on the ink tank until it clicks into place. The ink lamp lights up red when the ink tank is fully inserted.

Make sure all of the orange tape is peeled off the ink tank and the air hole is completely exposed, as illustrated in (A). If any orange parts are left as in (B), remove all of the orange parts.

(A) (B)

(A) Correct

L-shaped air hole.

(B) Incorrect

Part of the orange tape is remaining. Peel off the tape completely along the perforation.

Restarting your computer may solve the problem.

If there are any unnecessary print jobs, follow the procedure below to delete them.

(1)Open the printer properties dialog box.

Refer to “Opening the Printer Properties Dialog Box Directly from the Start Menu” in “Opening the Printer Properties Dialog Box (Windows)” of the User’s Guide on-screen manual.

(2)Click the Maintenance tab and then View Printer Status.

(3)Click Display Print Queue.

(4)Select Cancel All Documents (Purge Print Documents in Windows Me or

Windows 98) on the Printer menu.

You may not be able to select individual print jobs in Windows XP or Windows 2000.

(5)When the confirmation message is displayed, click Yes.

The print jobs are deleted.

(1)Click the printer icon in the Dock to display the list of print jobs in progress.

OS X v.10.2.8, click the printer icon in the Dock to start up the Print

In Mac

Center and double-click the name of your machine in the Printer List.

(2)Select the print job to delete and click .

The print jobs are deleted.

83Troubleshooting

Page 88

Paper Does Not Feed Properly

Cause Action

Printing on inappropriate type of paper. Check to see if the paper you are printing on is not too thick or curled.

Paper Feed Rollers are dirty. If paper is not feeding properly, clean the Paper Feed Rollers. Cleaning the

Paper not loaded properly. Make sure of the following when you load paper in the machine.

Paper source selection is inappropriate.

Too mu ch plain paper loaded. You can load approximately up to 150 sheets of 17 lb / 64 gsm plain paper (0.52

Foreign object in the Auto Sheet Feeder or Cassette.

Envelopes not prepared or loaded properly.

Inner Cover is not completely closed. Close the Inner Cover completely. Paper does not feed properly if the Inner

See “Media Types You Cannot Use” on page 10.

Paper Feed Rollers will wear the rollers, so perform this procedure only when necessary.

For details on cleaning, see “Cleaning the Paper Feed Rollers (Roller Cleaning)” on page 68.

z When loading two or more sheets of paper, align the edges of the sheets

before loading.

z Always load the paper in portrait orientation, either in the Auto Sheet Feeder

or the Cassette, regardless of the printing orientation.

z When loading paper in the Auto Sheet Feeder, load the paper with the print

side facing UP. Align the right edge of the paper stack against the Cover Guide and slide the Paper Guide so that it just touches the left edge of the stack.

z When loading paper in the Cassette, load the paper with the print side facing

DOWN. Align the right edge of the paper stack against the right edge of the Cassette and slide the Paper Guide against the left edge of the stack.

For details on loading paper, see “Loading Paper” on page 16.

Make sure that the proper paper source is selected. If not, change the paper source using the Paper Feed Switch or the printer driver. For details, see “Changing the Paper Source” on page 15.

Note

When printing from your computer, if a setting other than Paper Feed Switch is selected for Paper Source in the printer driver, the printer driver settings takes precedence when printing. For details on paper source selection using the printer driver, refer to the Printer Driver Guide on-screen manual.

inches / 13 mm in stack height). However, proper feeding of paper may not be possible at this maximum capacity depending on the type of paper or environmental conditions (either very high or low temperature and humidity).

In such cases, reduce the sheets of paper you load at a time to around half (around 0.2 inches / 5 mm in paper stack height).

For details on loading paper, see “Loading Paper” on page 16.

Make sure that there are no foreign objects in the Auto Sheet Feeder or Cassette.

When printing on envelopes, refer to “Envelopes” in the User ’s Guide on-screen manual, and prepare the envelopes before printing.

Once you have prepared the envelopes, load them in the machine in portrait orientation. If the envelopes are placed in landscape orientation, they will not feed properly.

Cover is even slightly open.

84 Troubleshooting

Page 89

Paper Jams

Cause Action

Paper jammed in the Paper Output Slot or the Auto Sheet Feeder.

Landscape credit card-sized paper jammed inside the machine.

Remove the paper following the procedure below.

(1)Slowly pull the paper out, either from the Auto Sheet Feeder or from the

Paper Output Slot, whichever is easier.

z If the paper tears and a piece remains inside the machine, open the

Scanning Unit (Printer Cover) and remove it.

After removing all paper, close the Scanning Unit (Printer Cover), turn the machine off, and turn it back on.

* Be careful not to touch the components inside the machine.

z If you cannot pull the paper out, turn the machine off and turn it back on. The

paper will be ejected automatically.

(2)Reload the paper in the machine, and press the OK button on the machine.

If you turned off the machine in step 1, all print jobs in queue are canceled. Reprint if necessary.

Note

z For details on how to load paper, see “Loading Printing Paper” on page 8.

z When reloading the paper in the machine, see “Paper Does Not Feed

Properly” on page 84 to confirm that you are using the correct paper and are loading it into the machine correctly.

z A5-sized paper are suited to print documents consisting mainly of text. We do

not recommend using such paper to print documents with photos or graphics, since the printout may curl and cause paper exit jams.

If you cannot remove the paper or the paper tears inside the machine, or if the paper jam error continues after removing the paper, contact your Canon service representative.

Do not load credit card-sized paper in the landscape orientation.

Remove the paper following the procedure below.

(1)Load a single sheet of the same paper in the Auto Sheet Feeder in portrait

orientation.

Do not load it in the landscape orientation.

(2)Turn off the machine.

(3)Turn on the machine.

The paper is fed and then pushes out the jammed paper as it ejects.

If you cannot remove the jammed paper or the paper jam error continues after removing the paper, contact your Canon service representative.

85Troubleshooting

Page 90

Cause Action

Landscape 4" x 6" / 101.6 x 152.4 mm paper loaded in the Cassette jammed inside the machine.

Paper jammed inside the machine at the transport unit.

Always load 4" x 6" / 101.6 x 152.4 mm media in portrait orientation regardless of the printing orientation.

Remove the paper following the procedure below.

(1)Turn off the machine, and then open the Rear Cover.

(2)Fold a piece of A4 or Letter-sized plain paper in four, push it in until it hits the

jammed paper, then pull out the paper folded in four.

(3)Close the Rear Cover, then turn on the machine.

Wait until the jammed paper is automatically ejected.

If you cannot remove the jammed paper or the paper jam error continues after removing the paper, contact your Canon service representative.

Remove the paper following the procedure below.

(1)Open the Rear Cover.

(2)If you can see the jammed paper, slowly pull the paper out.

86 Troubleshooting

z Be careful not to touch the components inside the machine.

z If you cannot pull the paper out, turn the machine off and turn it back on. The

paper will be ejected automatically.

(3)Close the Rear Cover.

(4)If you were not able to remove the paper out in step 2, remove the Cassette.

(5)Slowly pull the jammed paper out.

(6)If any paper is sticking out of the Cassette, reload the paper in the Cassette.

(7)Insert the Cassette into the machine again, and press the OK button on the

machine.

If you turned off the machine in step 2, all print jobs in queue are canceled.

Reprint if necessary.

Page 91

Cause Action

Paper jammed inside the machine at the transport unit.

(Continued)

Paper jammed inside the machine at the duplex transport section.

Note

When reloading the paper in the machine, see “Paper Does Not Feed Properly” on page 84 to confirm that you are using the correct paper and are loading it into the machine correctly.

If you cannot remove the paper or if the paper tears inside the machine, or if the paper jam error continues after removing the paper, contact your Canon service representative.

Remove the paper following the procedure below.

(1)Remove the Cassette.

If the paper is loaded in the Auto Sheet Feeder, remove the paper from the Auto Sheet Feeder and close the Paper Support.

(2)Stand the machine with the left side down.

(3)Slowly pull the jammed paper out while pulling the green cover toward you.

Caution

Set the machine back to its original position immediately after removing the jammed paper.

(4)If any paper is sticking out of the Cassette, reload the paper in the Cassette.

Reload paper in the Auto Sheet Feeder, if necessary.

(5)Insert the Cassette into the machine.

(6)Press the OK button on the machine.

Note

When reloading the paper into the machine, see “Paper Does Not Feed Properly” on page 84 to confirm that you are using the correct paper and are loading it into the machine correctly.

If you cannot remove a sheet of paper or a teared piece of paper inside the machine, or if the paper jam error continues after removing the paper, contact your Canon service representative.

87Troubleshooting

Page 92

Error Message Appears on the Screen

 Writing Error/Output Error/Communication Error

Cause Action

The machine is not ready. Confirm that the POWER lamp is lit blue.

Paper is not loaded. An out of paper error may have been left unattended for a period of time.

Printer port setting does not match the computer’s interface connecting the machine.

The machine is not connected properly. Make sure that the printer cable is securely plugged in to the machine and the

MP Drivers are not installed properly. The MP Drivers may not be installed properly. Uninstall them following the

If the POWER lamp is off, turn the machine on.

While the POWER lamp is flashing blue, the machine is initializing. Wait until the POWER lamp stops flashing and remains lit blue.

If the ALARM lamp is lit orange, an error may have occurred in the machine.

For details on how to resolve the error, see “Error Message Is Displayed on the LCD” on page 72.

Load paper and press the OK button.

If paper is loaded, make sure that the paper source (the Auto Sheet Feeder or Cassette) is selected correctly. If the paper source is not selected correctly, press the Paper Feed Switch or use the printer driver to change the paper source.

Check the printer port settings.

(1)Click Start > Control Panel > Printers and Other Hardware > Printers and

Faxes.

In non-XP Windows, click Start > Settings > Printers.

(2)Click the Canon MP960 Printer icon.

(3)Open the File menu and select Properties.

(4)Click the Ports tab to confirm the port settings.

Make sure that a port named USBnnn (Canon MP960 Printer) (where n is a number) is selected for Print to the following port(s).

In Windows Me or Windows 98, click the Details tab and make sure that

MPUSBPRNnn (Canon MP960 Printer) is selected for Print to the following port.

If the port setting is not correct, change the port setting according to the interface you are using, or reinstall the MP Drivers.

computer.

z If you are using a relay device such as a USB hub, disconnect it, connect the

machine directly to the computer, and try printing again. If printing starts normally, there is a problem with the relay device.

Consult the reseller of the relay device for details.

z There could also be a problem with the USB cable. Replace the USB cable

and try printing again.

procedure described in the Printer Driver Guide on-screen manual and reinstall them following the procedure described in the Easy Setup Instructions.

88 Troubleshooting

Page 93

 Error Regarding Automatic Duplex Printing Is Displayed

Cause Action

The correct media size is not selected in the MP Drivers.

First, check the Page Size setting in the application software you are printing from.

Then, check the Page Size setting on the Page Setup sheet in the printer properties dialog box (Windows) or the Page Setup dialog box (Macintosh).

The page sizes that can be used for Automatic Duplex Printing are Letter, A4, B5, A5, and 5" x 7" / 127.0 x 177.8 mm. Check that the page size of the loaded paper is correct.

Note

To switch to manual duplex printing, follow the procedure below.

On the Page Setup sheet, clear the Automatic check box. Then try printing again.

Manual duplex printing is not available.

 Error No.: 300 Is Displayed

Cause Action

The machine is not ready. Make sure that the machine is turned on, and that it is connected securely to the

Machine is not connected properly. Make sure that the USB cable is plugged in securely to the computer and the

Your machine is not selected in Printer on the Print dialog box.

computer.

If the POWER lamp is off, turn the machine on.

While the POWER lamp is flashing blue, the machine is initializing. Wait until the POWER lamp stops flashing and remains lit blue.

When the ALARM lamp is lit orange, an error may have occurred on the machine. For details on how to resolve the error, see “Error Message Is Displayed on the LCD” on page 72.

machine.

z If you are using a relay device such as a USB hub, disconnect it, connect the

machine directly to the computer, and try printing again. If printing starts normally, there is a problem with the relay device.

Consult the reseller of the relay device for details.

z There could also be a problem with the USB cable. Replace the USB cable

and try printing again.

Select MP960 in Printer on the Print dialog box.

If MP960 does not appear in Printer, follow the procedure below to check that the driver for your machine is installed to your computer.

(1)Select Print and Fax Preferences from Printer.

In Mac OS X v.10.2.8 or 10.3.x, select Edit Printer List from Printer.

(2)Check that MP960 is displayed in the list of printers and that the check box is

selected.

In Mac OS X v.10.2.8, check that MP960 is displayed in Printer List.

(3)If MP960 is not displayed, click Add(+) to add the machine.

If you cannot add the machine, follow the procedure described in the Easy Setup Instructions to reinstall the MP Drivers.

89Troubleshooting

Page 94

 Error No.: 1700 Is Displayed

Cause Action

The ink absorber is almost full. The machine has a built-in ink absorber to hold the ink used during Print Head

Cleaning, for example.

This error message indicates that the ink absorber is nearly full.

Press the OK button to cancel the error so you can continue printing.

 Error No.: 1851 Is Displayed

Cause Action

Inner Cover was open when you started printing.

Close Inner Cover, press the OK button on the machine. Printing will start again.

 Error No.: 1856 Is Displayed

Cause Action

Inner Cover was opened while printing was in progress.

Close the Inner Cover, then press the OK button on the machine.

A page of print data being sent at the time of the error will be erased, so print that page again.

 Error No.: 2001 Is Displayed

Cause Action

No response from connected digital camera or video camcorder. / Connected digital camera or video camcorder connected is not compatible with this machine.

Disconnect the cable connecting the machine and the device, and then reconnect it.

Perform necessary operations according your device’s instruction manual before reconnecting it to the machine.

If the error is still unresolved, there is a possibility that you are using a digital camera or digital video camcorder that is not supported by this machine. Use a digital camera or digital video camcorder compatible with this machine.

 Error No.: 2500 Is Displayed

Cause Action

Automatic Print Head Alignment has failed.

See “Auto head align has failed. Press OK and repeat operation. <See manual>” in “Error Message Is Displayed on the LCD” on page 72.

90 Troubleshooting

Page 95

Cannot Print Properly from a Digital Camera

The following are the possible errors that may occur when printing directly from a digital still camera or digital video camcorder*, and the actions to resolve them.

* Hereafter, the digital still cameras and digital video camcorders are collectively referred to as

“digital camera” or “camera”.

Note

z PictBridge compatible digital cameras can be connected to your machine for direct printing. z This section describes errors that are indicated on Canon-brand PictBridge compatible cameras. The

error messages and operations may vary depending on the camera you are using. If you are using a non-Canon PictBridge compatible camera and not sure how to dismiss the printer error message from the camera, check the error message displayed on the LCD and dismiss the error message. For details on dismissing an error message from the machine, see “Error Message Is Displayed on the LCD” on page 72.

z A communication time out occurs if printing takes a long time or if it takes too much time to send data.

This may cancel printing. In such cases, disconnect the cable between the machine and the camera, and then reconnect it. Turn the camera on if it does not turn on automatically. If the problem is still not resolved, select a different photo and check if it can be printed.

z Your PictBridge compatible device may need to be switched to printing mode before it is connected to

the machine, depending on the model of the camera. Also, it may need to be turned on manually or switched to playback mode after connected to the machine. Refer to your camera’s instruction manual and take perform necessary operation before connection.

z The print head nozzles may be clogged if printing becomes faint or colors are incorrect. See “When

Printing Becomes Faint or Colors Are Incorrect” on page 56.

z If the paper is curled or its surface is scratched during printing, make sure that you are using the correct

type of paper. If the problem is not resolved by using the correct type of paper, turn on the Prevent paper abrasion function. See “Printing on thick paper.” on page 81.

z For the errors indicated on the camera and their solution, also refer to your camera’s instruction

manual. For details on other troubles with a digital camera, contact the manufacturer of the camera.

Error Message On Camera Action

“Printer in use” The machine is busy, perhaps processing a print job from the computer.

“No paper” Load paper in the paper source, or press the Paper Feed Switch to select the

“Paper Error”

“Paper jam” Select Stop in the display on your camera to stop printing.

“Printer cover open” Close the Scanning Unit (Printer Cover) on the machine.

“No Print Head” The Print Head is not installed or is defective.

Wait until printing is complete. If the machine is warming up, wait until the warmup is complete. When it is ready, the machine starts printing your print job automatically.

paper source where you have loaded paper (the Auto Sheet Feeder or the Cassette), and select Continue

z The page size that cannot be fed from the Cassette is selected. Load paper

in the Auto Sheet Feeder, press the Paper Feed Switch to select the Auto Sheet Feeder as the paper source, and try printing again.

For details, see “Changing the Paper Source” on page 15.

z If the Paper Output Tray is closed, open it. The machine resumes printing. If

the Inner Cover is open, close it and select Stop in the display on your camera to stop printing.

Remove the jammed paper, load new paper, press the OK button on the machine, and reprint.

Follow the directions described in the Easy Setup Instructions to install the Print Head.

If the Print Head is already installed, remove the Print Head and then reinstall it.

If the error is still not resolved, the Print Head may be damaged. Contact your Canon service representative.

in the display on your camera.

91Troubleshooting

Page 96

Error Message On Camera Action

“Waste tank (ink absorber*2) full”/

“ink absorber

“No ink” An ink tank is not installed properly, or is out of ink.

“Ink Error” An ink tank that was once empty is installed.

“Hardware Error” An ink tank error has occurred. Replace the ink tank. See “Replacing an Ink

“Printer error” An error requiring servicing may have occurred. (Machine’s POWER lamp

full”

*1 To resume printing, you can also press the OK button on the machine instead of selecting

Continue on the camera.

*2 The ink absorber absorbs ink used during cleaning, for example. If this message appears, you

will need to call for servicing to replace the absorber and to check the machine for proper operation.

This error message indicates that the ink absorber is nearly full.

The machine has a built-in ink absorber to hold the ink used during Print Head Cleaning, for example.

You can continue printing by selecting Continue camera.

Confirm the error message displayed on the LCD and take the appropriate action to resolve the error. For details, see “Error Message Is Displayed on the LCD” on page 72.

Replace the ink tank and close the Scanning Unit (Printer Cover).

Printing with an ink tank that was once empty may damage the machine.

* With this operation, releasing the function for detecting the remaining ink

level is memorized. Please be advised that Canon shall not be liable for any machine malfunction or damage caused by refilled ink tanks. See “Replacing an Ink Tank” on page 50.

Tank” on page 50.

flashes blue and ALARM lamp flashes orange alternately.)

Disconnect the cable between the machine and the camera, turn off the machine, and unplug the power cord of the machine from the power supply.

After a while, plug the power cord of the machine back in, turn on the machine, and then reconnect the camera to the machine.

If the same error occurs, contact your Canon service representative.

on the display on your

Cannot Print Properly from a Photo Index Sheet

Cause Action

“Failed to scan Photo Index Sheet.” is displayed.

92 Troubleshooting

z Make sure the Photo Index Sheet is set in the correct position and orientation

on the Platen Glass.

z Make sure the Platen Glass and the Photo Index Sheet are not dirty.

z Make sure all required circles on the Photo Index Sheet are filled in. If the

filled circles on the sheet are not marked dark enough, the machine may not read the settings.

Refer to “Printing by Using the Photo Index Sheet” in “Using Other Useful Printing Functions” of the User’s Guide on-screen manual.

Page 97

Cannot Scan Films

Cause Action

Film guide not correctly placed on the Platen Glass.

The Document Cover is not closed. Close the Document Cover properly.

The FAU Protective Sheet is not removed.

The Scanner Lock Switch is not released.

 Cannot Obtain a Clean Scan or Colors Scan Incorrectly (Displayed

Image Is Not Clear)

Cause Action

Dust or dirt is stuck to the Platen Glass or the FAU Lamp.

The original film is dirty. Remove any dirt from the film.

The condition of the original film is poor (faded colors, etc.).

The slide mount you are using is white and the reflection is affecting scan quality.

Light from the FAU lamp get in through the blank area.

Insert the film in the film guide supplied for this machine and place the guide in the correct position on the Platen Glass.

For loading the film, see “Mounting Films” on page 38.

Remove the FAU Protective Sheet from the Document Cover.

Slide the Scanner Lock Switch to the release position and turn the machine off. Then, turn the power back on.

Remove any dust and dirt from the Platen Glass and the FAU Lamp. See “Cleaning the Platen Glass and Document Cover” on page 68.

If you are scanning from a computer, in Image Settings the ScanGear’s Advanced Mode, select Fading Correction or Grain Correction to scan with image correction. Refer to the Scanning Guide on-screen manual.

Note

If there is no problem with the quality of the image seen on your computer screen, but the printout quality is unsatisfactory or has unwanted margin space, you need to adjust the print settings. Otherwise, it may be a machine problem.

See “Print Results Not Satisfactory” on page 78.

Use black mounts, or mask the slide mount with a black frame.

Place the Filler Sheet over the blank area correctly to shield it.

 Frames Are Not Detected Correctly

Cause Action

Film is out of position. Reposition the film in the film guide so that the white line marks of the guide do

The frame of a film is scanned on the edge of an image. / The edge of an image is missing.

not obscure the film frames.

For loading the film, see “Mounting Films” on page 38.

Note

Repositioning the film may not resolve the problem, depending on the film. In this case, scan from the computer. For details, refer to the Scanning Guide on- screen manual.

Adjust Film print cutting range and rescan.

See “Print Settings” in “Changing the Machine Settings” of the User’s Guide onscreen manual.

93Troubleshooting

Page 98

Appendix

Reading the On-screen Manuals

Along with this Quick Start Guide, on-screen manuals are also supplied with your machine. For

detailed instructions on installing the on-screen manuals, refer to your setup sheet.

You can view the on-screen manuals in the following way:

To view the on-screen manual, double-click the MP960 On-screen Manual shortcut icon on the desktop, or click Start > All Programs (or Programs) > Canon MP960 Manual > MP960 On-

screen Manual.

System Requirements

Browser: Windows HTML Help Viewer

Note

z Microsoft® Internet Explorer 5.0 or later must be installed. z The on-screen manual may not be displayed properly depending on your operating system or

Internet Explorer version. We recommend that you keep your system up to date with Windows Update.

To view the on-screen manual, double-click the MP960 On-screen Manual alias on the desktop.

Note

Users in Asia

If you installed the User’s Guide from the Manual folder in the Setup CD-ROM, open the folder in which you copied the User’s Guide and double-click top.htm.

System Requirements

Browser: Help Viewer

Note

z The on-screen manual may not be displayed properly depending on your operating system. We

recommend that you keep your system up to date.

z We recommend using Safari as your Web browser to view the HTML format on-screen

manuals. If Safari is not installed on your computer, download it from Apple Computer, Inc. website and install it.

94 Appendix

Page 99

Specifications

General Specifications

Printing resolution (dpi) 9600 (horizontal)* x 2400 (vertical)

Print speed*

* Based on Canon standard

pattern. Print speed may vary depending on system configuration, software, document complexity, print mode and page coverage.

Print width 8 inches / 203.2 mm max.

Acoustic noise level Approx. 33.2 dB (A) (when printing in the highest print quality mode on Photo Paper

Operating environment Temperature: 5 to 35°C (41 to 95°F)

Storage environment Temperature: 0 to 40°C (32 to 104°F)

Power supply AC 100-240 V, 50/60 Hz

Power consumption Printing (Copy): Approx. 24 W

External dimensions (with the Paper Support and Paper Output Tray retracted)

Weight Approx. 12.0 kg (Approx. 26.5 lb.)

Print Head Total 3,584 nozzles (C/M/Y/PC/PM/Dye Bk/BK: each 512 nozzles)

* Ink droplets can be placed with a pitch of 1/9600 inch at minimum.

Black printing (text pattern)

Max Speed (Custom Setting 5): 30 ppm

Standard: 14.9 ppm

Color printing

Max Speed (Custom Setting 5): 22 ppm

Standard: 9.8 ppm

(for Borderless Printing: 8.5 inches / 216 mm)

Pro)

Humidity: 10 to 90%RH (no condensation)

Humidity: 5 to 95% RH (no condensation)

Standby (minimum): Approx. 1.7 W

OFF: Approx. 0.9 W

Approx. 18.5 (W) x 16.8 (D) x 8.9 (H) inches /

Approx. 471 (W) x 428 (D) x 226 (H) mm

Copy Specifications

Copy speed

* Based on Canon standard

pattern. Copy speed may vary depending on document complexity, copy mode, page coverage and the number of copies.

Multiple copy 1 - 99 pages

Intensity adjustment 9 positions, Auto intensity (AE copy)

Zoom 25% - 400% (1% unit)

Black & white: Fast mode approx. 30 cpm

Color: Fast mode approx. 22 cpm

Scan Specifications

Scanner driver TWAIN / WIA (Windows XP only)

Maximum scanning size A4/Letter, 8.5" x 11.7" / 216 x 297 mm

Scanning resolution Optical resolution (horizontal x vertical) max: 4800 dpi x 4800 dpi

Gradation (Input/Output) 48bit/8bit

Interpolated resolution max: 19200 dpi x 19200 dpi

48bit/24bit (RGB each 16bit/8bit)

95Appendix

Page 100

Camera Direct Print (PictBridge)

Paper size Default (Selections based on the machine setting)

Paper type Default (Selections based on the machine setting), Photo (Photo Paper Plus Glossy,

Layout Default (Selections based on the machine setting), Borderless, Bordered, N-up (2, 4,

Image optimize Default (Selections based on the machine setting), On, Off, “VIVID”*, “NR” (Noise

Print data & file no. Default (Off: No printing), Date, File No., Both, Off

Trimming Default (Off: No trimming), On (follow camera’s setting), Off

10 x 15 cm / 4" x 6" (Photo Paper Plus Glossy, Photo Paper Pro, Photo Paper Plus Semi-gloss, Glossy Photo Paper, Glossy Photo Paper “Everyday Use”, Photo Paper Glossy, Photo Stickers 13 x 18 cm / 5" x 7" (Photo Paper Plus Glossy) A4 / 8.5" x 11" (Photo Paper Plus Glossy A4/Letter, Photo Paper Pro A4/Letter, Photo Paper Plus Semi-gloss A4/Letter, Glossy Photo Paper A4/Letter, Glossy Photo Paper “Everyday Use” A4, Photo Paper Glossy Letter, Plain Paper A4/Letter)

5.4 x 8.6 cm / Credit card (Glossy Photo Paper Card Size) 20 x 25 cm / 8" x 10" (Photo Paper Pro)

10.1 x 18 cm / 4" x 7.1" (Photo Paper Pro)

*1 Canon-brand sticker. Printing on this paper is available only when the Layout

function on your camera has a 16-up option. See “Recommended Paper and Requirements” on page 8.

)

*2 If using a Canon PictBridge-compatible camera, you can select it.

Glossy Photo Paper), Fast Photo (Photo Paper Pro), Plain Paper (A4/Letter only)

, 35-up

9, 16)

*1 Layout compatible with Canon-brand sticker above. See “Recommended Paper

and Requirements” on page 8.

*2 Selected photos are printed in 35 mm film style layout (contact printing layout).

This print setting is only available with certain Canon PictBridge-compliant devices.

You can print shooting Info (Exif Data) on photos in list format, or in the margins of specified photos.

Select Layout, then select the item displayed with the [i] icon.

(Note that this print setting cannot be used for some models.)

See “Recommended Paper and Requirements” on page 8.

Reduction)*, “Face”*, “Red eye”*

* If using a Canon PictBridge-compatible camera, you can select it.

Minimum System Requirements*1

Interface Operating System Processor RAM Hard Disk

USB 2.0 Hi-Speed Windows XP SP1,SP2 Pentium III*3

Windows 2000 Professional SP4

USB Windows XP SP1, SP2 Pentium II 300

Windows 2000 Professional SP2, SP3, SP4

Windows Millennium Edition

Windows 98

, 98 Second Edition

(Celeron 566 MHz)

MHz

128 MB 550 MB

Interface Operating System Processor RAM Hard Disk

USB 2.0 Hi-Speed

USB

Mac OS X v.10.4 Intel processor

Mac OS X v.10.2.8 - v.10.3 128 MB

PowerPC G3/ G4/G5

256 MB 450 MB

Space

96 Appendix

Canon MP960 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
