Canon G5 User Manual

C KNOW HOW

™

1-800-OK-CANON/www.usa.canon.com

Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042 U.S.A.

Canon Canada Inc.
6390 Dixie Road, Mississauga, Ontario L5T 1P7 Canada

Canon Mexicana, S. DE R.L. DE C.V.
Periférico Sur No. 4124, 5º y 6º pisos
Col. Ex-Rancho de Anzaldo, 01900 México, D.F.

Canon Latin America
703 Waterford Way, Suite 400, Miami, FL 33126 U.S.A.

0038W041

©2003 canon u.s.a., inc. printed in u.s.a.

revol

u

tion zei

d

digital tionizedphotography

we revolu

digital

™

A. PowerShot G5 Body
B. Compact Power Adapter CA-560
C. Neck Strap NS-DC2
D. Lens Cap
E. Battery Pack BP-511
F. CompactFlash Card FC-32M

G. Wireless Controller WL-DC100
H. Digital Camera Solution CD-ROM
I. ArcSoft Camera Suite CD-ROM
J. Interface Cable IFC-300PCU
K. AV Cable AVC-DC100

SUPPLIED ACCESSORIES

A

C

J

H

E

K

I

B

F

SPECIFICATIONS

IMAGE STORAGE CAPACITY

www.powershot.com

G

D

Small/N Small/F Small/SF Medium1/N Medium1/F Medium1/SF Medium2/N Medium2/F

File Size 84KB 150KB 249KB 278KB 558KB 1,002KB 170KB 320KB

CF-32MB 337 196 120 108 54 30 174 94
CF-64MB 676 393 241 217 109 61 349 189
CF-256MB 2,720 1,563 962 868 440 246 1,390 762
CF-340MB 3,640 2,183 1,323 1,213 614 343 1,898 1,065
CF-1GB 8,202 5,468 3,645 3,280 1,726 993 4,687 2,982

Medium2/SF Large/N Large/F Large/SF Movie/Low Movie/Med RAW

File Size 570KB 695KB 1,395KB 2,503KB 120KB/sec. 330KB/sec. 4,725KB

CF-32MB 53 43 21 11 242 sec. 91 sec. 5
CF-64MB 107 88 43 24 486 sec. 183 sec. 12
CF-256MB 431 355 177 99 1,954 sec. 735 sec. 51
CF-340MB 597 495 247 138 2,729 sec. 1,015 sec. 72
CF-1GB 1,726 1,426 728 409 6,562 sec. 2,733 sec. 219

Note: N=Normal F =Fine SF=SuperFine
Storage capacity varies depending on the scene or the subjects. Thisdata is estimated from Canon’s standard shooting conditions. Figures for Movie
Mode represent total capacity of CompactFlash Card.

Type: Compact digital still camera with built-in flash, 4x
optical zoom and 4x digital zoom, 16xcombined zoom.
Image Capture Device: 5.0 M pixel, 1/1.8 in. charge
coupled device (CCD).

Sensitivity: Auto; 50/100/200/400 (Equivalent to ISO).
Resolution (Recording Pixels):

2,592 x 1,944 (Large),

1,600 x 1,200

(Medium 1),

1,024 x 768 (Medium 2),

640 x 480 pixels (Small),

Movie:

320 x 240

or 160 x 120.

Image Quality Modes: Normal, Fine, SuperFine.
File Format: Design rule for Camera File system, DPOF

Version 1.1 (Digital Print Order Format), JPEG (Exif 2.2
compliant).
Image Recording Format: Still Image: JPEG (Exif 2.2
compliant) / RAW; Movie: QuickTime AVI.

Recording Media: CompactFlash (CF) Card Type I or II.
Shooting Modes:

Auto, Creative (P, Av, Tv, M), Image
(Portrait, Landscape, Night Scene, Stitch Assist),
Movie, Custom 1, Custom 2.
Photo Effect: Vivid Color, Neutral Color, Low
Sharpening, Sepia, Black & White and Custom.
Playback Modes: Single, Index (9 thumbnails),
Magnification (approx. 2x to 10x), Slide Show or Movie.
Erase Modes: Still images— Single image, All images;
Movie— Part of movie, All movie.
Interfaces: USB, AV Out (Video: NTSC or PAL
Selectable, Audio: Monaural).
Direct Printing: Direct connection to Canon Card Photo
Printer CP-200, CP-300 and Bubble Jet Direct Photo
Printers.

Lens: 7.2–28.8mm f/2.0–3.0 zoom Lens (equivalent
to 35–140mm in 35mm format).

Shutter Speed: 15–1/2,000 sec. (Slow shutter of 1.3
sec. and more operates with noise reduction.)

Focus Range: Normal AF: 20 in. to Infinity/ 50cm to
Infinity; Macro AF: 2 in. to 20 in./5cm to 50cm
(WIDE); 6 in. to 20 in./15cm to 50cm (TELE).

Light Metering Method: Evaluative metering, Center­weighted average metering or Spot metering.

Exposure Control: Program AE, Shutter-priority,
Aperture-priority or Manual; AE Lock is available.

Compensation: +/- 2.0 EV in 1/3-step increments.

Built-in Flash: Auto, Red-Eye Reduction On/Off,

Slow-Sync, Flash On, Flash Off.

Flash Range: 2.3 ft to 16.5 ft / 70cm to 5.0m (WIDE);

2.3 ft to 13.1 ft / 70cm to 4.0m (TELE) (When ISO
Speed is set to 100 equivalent).

White Balance Control: TTL Auto White Balance,
Pre-set (Daylight, Cloudy, Tungsten, Fluorescent,
Fluorescent H, or Flash), and Custom White Balance
(Two settings).

Optical Viewfinder: Real-image zoom viewfinder.
LCD Monitor: 1.8 inch low-temperature

polycrystalline sillicon TFT color LCD.

Power Sources: Rechargeable Lithium-ion battery (BP­511/512) or Compact Power Adapter CA-560, Car
Battery Cable Kit CR-560.

Dimensions: 4.8(W) x 2.9(H) x 2.8(D) in. /

121.0(W) x 73.9(H) x 69.9(D)mm.

Weight (w/o batteries or CF card): 14.5 oz./410g.

All data are based on Canon’s Standard Test Method. Subject to change without notice. Canon, PowerShotare registered trademarks and
“digital revolutionized photography we revolutionized digital”, DIGICand Canon Know How are trademarks of Canon Inc. All other products
and brand names are registered trademarks, trademarks, or service marksof their respective owners.

With a stunning combination
of resolution, speed and control,
all housed in a rugged, elegant
new black enclosure, the
PowerShot G5 takes the lead
as Canon’s flagship PowerShot.
The PowerShot G5 features an
all-new 1/1.8˝ 5 megapixel
CCD sensor, capturing a huge
2592 x 1944 pixel image with
exceptional detail and color
fidelity. It has a fast, high
resolution 4x optical zoom
lens with iris-type aperture
and User-operated, multi-stop
control for spectacular depth

of field, or elegant blur.
Perfect focus, exposure, and
color are achieved quickly
with the combination of
Canon’s exclusive ≥
imaging processor with iSAPS
(Intelligent Scene Analysis
based on Photographic Space)
technology, an Intelligent
Orientation Sensor, and the
use of primary color filters.
All these features, plus a host
of manual and automatic
functions ensure that the
PowerShot G5 will get the
perfect shot every time.

This image was taken
with the PowerShot G5.
