CANON Digital Ixus 300 User Manual

Camera User Guide

Flowchart and Reference Guide

This Guide

Shooting with the Camera

Software Starter Guide

Installing the Software

This Guide

Connecting the Camera to a Computer

Software Starter Guide

Downloading Images to a Computer

• Please start by reading the Precaution on the reverse side of this cover.

• Please see the user’ s guide for the printer for operating instructions for Card Photo Printer CP-10.

ENGLISH

Precautions

Camera Body Temperature

If your camera is used for prolonged periods, the camera body may become warm. Please be aware of this and take care when operating the camera for an extended period.

About the LCD monitor

The LCD monitor is produced with extremely high-precision manufacturing techniques. With more than 99.99% of the pixels operating to specifications, less than 0.01% of the pixels may occasionally misfire or appear as black, red or green dots. This has no effect on the recorded image and does not constitute a malfunction.

Notice: Please ensure that you read and follow the handling and

safety precautions on pages 5 to 9 of this guide before attempting to use the camera.

Video Format

Please set the camera’s video signal format to the one used in your region before using it with a TV monitor (p. 77).

Charging the Date/Time Battery

• The camera has a built-in rechargeable lithium battery that maintains the date, time and other camera settings. This battery recharges when the main battery pack is inserted into the camera. When you first purchase the camera, place a charged battery pack in it or use the AC adapter kit (sold separately) for at least 4 hours to charge the date/time battery. It will charge even when the camera power is set to Off.

• If the Set Date/Time menu appears when the camera power is turned on, it means that the date/time battery charge is depleted. Recharge it as described above.

Table of Contents

Read This First

Please Read.......................................................................... 5

Safety Precautions ............................................................... 5

Warnings ............................................................................. 6

Cautions...............................................................................8

Preventing Malfunctions..................................................... 9

Preparing the Camera

Guide to Components ....................................................... 10

Front View ...................................................................10

Back View .................................................................... 11

Operation Panel............................................................ 12

Mode Dial .................................................................... 13

Charging the Battery Pack ................................................14

Installing the Battery Pack ................................................16

Using the Household Power Source .................................18

Installing a CF Card ...........................................................19

Setting the Date and Time................................................21

Attaching the Wrist Strap .................................................22

Quick Start

Shooting ............................................................................23

Replaying...........................................................................24

Erasing Shortcut ................................................................ 24

T able of Contents

Basic Functions

Turning the Power On/Off ................................................ 25

Using the Viewfinder ........................................................27

Using the LCD Monitor .....................................................28

Information Displayed on the LCD Monitor..................... 29

Pressing the Shutter Button..............................................31

Reviewing an Image Immediately after Recording It ...... 31

Adjusting the Zoom (Depth of Field) ...............................33

Shooting

Selecting a Shooting Mode...............................................34

Changing Resolution/Compression Settings..................... 34

Using the Flash ..................................................................37

Shooting Close-Ups/Infinity Shots.....................................39

Using the Self-Timer..........................................................40

Shooting Continuously .....................................................40

Adjusting the Exposure Compensation ............................41

Setting the White Balance ................................................42

Shooting in Stitch Assist Mode ......................................... 43

Shooting a Movie ..............................................................46

Functions Available in Each Shooting Mode....................48

Shooting Mode ............................................................28

Replay Mode ................................................................29

Shooting Mode ............................................................29

Replay Mode (Standard Display) ....................................30

Replay Mode (Detailed Display) .....................................30

Changing the Default Review Setting ............................32

Telephoto/Wide Angle ..................................................33

Digital Zoom ................................................................33

Framing a Subject ......................................................... 43

Shooting ......................................................................44

Table of Contents

Replaying

Displaying Images Singly (Single Image Replay) .............. 49

Zooming an Image .......................................................49

Displaying Images in Sets of Nine (Index Replay) ............50

Switching between Sets of Nine Images ........................51

Replaying a Movie............................................................. 52

Rotating Images in the Display .........................................53

Automating Playback (Auto Play) ....................................54

Protecting Images .............................................................56

Erasing Images

Erasing Images Singly........................................................57

Erasing All Images .............................................................58

Print Settings (DPOF Settings)

Displaying the Print Settings Menu .................................. 59

Setting the Print Style ....................................................... 60

Selecting Images for Printing............................................ 61

Resetting Print Settings.....................................................64

Printing with Card Photo Printer CP-10

Connecting Card Photo Printer CP-10 ..............................65

Printing ..............................................................................66

Printing the Displayed Image.........................................66

Printing with DPOF Print Settings................................... 67

Setting the Print Style ....................................................... 70

T able of Contents

Camera Settings

Displaying the Rec. Menu ................................................. 72

Resetting the File Number ................................................73

Setting the Beep On/Off ................................................... 74

Formatting CF Cards..........................................................75

Changing Other Settings ..................................................76

Switching the Auto Power Down Function On/Off .........76

Setting the Video Signal Format ....................................77

Setting the Language.................................................... 78

Shooting/Replaying with a TV Monitor

Shooting/Replaying with a TV Monitor............................ 79

Downloading Images to a Computer

Downloading Directly from a CF Card.............................. 80

Inserting the CF Card....................................................80

Downloading Images .................................................... 81

Connecting the Camera to a Computer with a USB Cable 82

Connecting to a USB Port .............................................83

Appendices

Care and Maintenance of the Camera ............................. 85

Troubleshooting ................................................................86

List of Messages................................................................. 90

Specifications.....................................................................93

Index ..................................................................................96

Canon Customer Support Help Desk ................................98

Read This First

Please Read

Test Shots

Before you shoot images of subjects of importance to you, we str ongly recommend that you shoot several trial images to confirm that you are operating the camera correctly. Please note that Canon Inc., its subsidiaries and affiliates, and distributors of its digital cameras ar e not liable for any consequential damages arising from any malfunction of the Canon digital camera or CompactFlash™ card (CF card) resulting in the failure of an image to be recor ded or to be recorded in a format that is machine sensible.

Warning Against Copyright Infringement

Please note that Canon digital cameras are intended for personal use and must be used in a manner that respects international and domestic copyright laws and regulations. Please be advised that in certain cases the copying of images from performances, exhibitions, or commercial properties by means of a camera or other device may contravene copyright or other legal rights even if the image was recorded for personal use.

Warranty Limitations

This camera’s warranty is only effective in the country of sale. If a problem arises while the camera is in use abroad, please convey it back to the country of sale before proceeding with a warranty claim to a Canon Customer Support Help Desk.

Safety Precautions

• Before using the camera, please ensure that you have read and understood the safety precautions described below. Always ensure that the camera is operated correctly.

• The safety precautions noted on the following pages are intended to instruct you in the safe and correct operation of the camera and its accessories to prevent injuries or damage to yourself, other persons and equipment.

• In the next few pages, the term “equipment” refers primarily to the camera, battery charger and optional compact power adapter.

Read This First

WARNINGS

• Do not aim the camera directly into the sun or at other intense light sources which could damage your eyesight.

• Do not trigger the flash in close proximity to human or animal eyes. Exposure to the intense light produced by the flash may damage eyesight. In particular, remain at least one meter (39 inches) away from infants when using the flash.

• Store this equipment out of the reach of children and infants. Accidental damage to the camera or batteries by a child could result in serious injury. In addition, placement of the wrist strap around the child’s neck could result in asphyxiation.

• Do not attempt to disassemble or alter any part of the equipment that is not expressly described in this guide. Disassembly or alteration may result in high-voltage electrical shock. Internal inspections, alterations and repairs should be conducted by qualified service personnel authorized by your camera distributor or a Canon Customer Support Help Desk.

• To avoid the risk of high-voltage electrical shock, do not touch the flash portion of the camera if it has been damaged. Similarly, never touch internal portions of the equipment which become exposed as a result of damage. There is a risk of high-voltage electrical shock. Please take the first opportunity to consult your camera distributor or a Canon Customer Support Help Desk.

• Stop operating the equipment immediately in the event that it emits smoke or noxious fumes. Failure to do so may result in fire or electrical shock. Immediately turn the camera’s power off and remove the camera battery or unplug the power cord from the electrical outlet. Confirm that smoke or fume emissions have ceased. Please consult your camera distributor or the closest Canon Customer Support Help Desk.

• Stop operating the equipment if it is dropped or the casing is damaged. Failure to do so may result in fire or electrical shock. Immediately turn the camera’s power off and remove the camera battery or unplug the power cord from the electrical outlet. Please consult your camera distributor or the closest Canon Customer Support Help Desk.

Read This First

• Do not allow the equipment to come into contact with, or become immersed in, water or other liquids. Do not allow liquids to enter the interior . The camera has not been waterpr oofed. If the exterior comes into contact with liquids or salt air , wipe it dr y with a soft, absorbent cloth. In the event that water or other foreign substances enter the interior , immediately turn the camera’s power off and remove the camera battery or unplug the power cord from the electrical outlet. Continued use of the equipment may result in fire or electrical shock. Please consult your camera distributor or the closest Canon Customer Support Help Desk.

• Do not use substances containing alcohol, benzene, thinners or other flammable substances to clean or maintain the equipment. The use of these substances may lead to fire.

• Do not cut, damage, alter or place heavy items on the power adapter cord. Any of these actions may cause an electrical short circuit, which may lead to fire or electrical shock. Replace a broken or damaged power adapter cord.

• Do not handle the power cord if your hands are wet. Handling it with wet hands may lead to electrical shock. When unplugging the cord, ensure that you hold the solid portion of the plug. Pulling on the flexible portion of the cord may damage or expose the wire and insulation, creating the potential for fires or electrical shocks.

• Use of power sources not expressly recommended for this equipment may lead to overheating, distortion of the equipment, fire, electrical shock or other hazards. Use only the recommended power accessories.

• Do not place the batteries near a heat source or expose them to direct flame or heat. Neither should you immerse them in water. Such exposure may damage the batteries and lead to the leakage of corrosive liquids, fire, electrical shock, explosion or serious injury.

• Do not attempt to disassemble, alter or apply heat to the batteries. There is serious risk of injury due to an explosion. Immediately flush with water any area of the body, including the eyes and mouth, or clothing, that comes into contact with the inner contents of a battery. If the eyes or mouth contact these substances, immediately flush with water and seek medical assistance.

• Avoid dropping or subjecting the batteries to severe impacts that could damage the casings. It could lead to leakage and injury.

• Do not short-circuit the battery terminals with metallic objects, such as key holders. It could lead to overheating, burns and other injuries. Use the supplied battery case to transport or store the battery pack.

Read This First

• Before you discard a battery, cover the terminals with tape or other insulators to prevent direct contact with other objects. Contact with the metallic components of other materials in waste containers may lead to fire or explosions. Discard the batteries in specialized waste facilities if available in your area.

• Use of batteries not expressly recommended for this equipment may cause explosions or leaks, resulting in fire, injury and damage to the surroundings. Use only recommended batteries and accessories.

• Use only the recommended battery charger to charge the Battery Pack NB-1L rechargeable batteries. Use of chargers not expressly recommended may result in overheating, distortion, fire or electrical shock.

• Disconnect the battery charger or the compact power adapter from both the camera and electrical outlet after recharging and when the camera is not in use to avoid fires and other hazards.

• The camera terminal of the battery charger cord and the compact power cord is designed for exclusive use with your camera. Do not use it with other products or batteries. There is a risk of fire and other hazards.

CAUTIONS

• Avoid using, placing or storing the equipment in places subject to strong sunlight or high temperatures, such as the dashboard or trunk (boot) of a car. Exposure to intense sunlight and heat may cause the batteries to leak, overheat or explode, resulting in fire, burns or other injuries. High temperatures may also cause deformation of the casing. Ensure that there is good ventilation when using the compact power adapter to charge the battery pack or power the camera.

• Do not store the equipment in humid or dusty areas. Storage in such areas could lead to fire, electrical shock or other damage.

• Be careful not to bang the camera or subject it to strong impacts or shocks that could lead to injury or damage the equipment when wearing or holding it by the wrist strap.

• Be careful not to cover the flash with your fingers when shooting. In addition, do not touch the surface of the flash after taking several pictures in rapid succession. Either action could result in burns.

• If your camera is used for prolonged periods, the camera body may become warm. Please take care when operating the camera for an extended period as your hands may experience a burning sensation.

Read This First

Preventing Malfunctions

Avoid Strong Magnetic Fields

Never place the camera in close proximity to electric motors or other equipment generating strong electromagnetic fields. Exposure to strong magnetic fields may cause malfunctions or corrupt image data.

Avoid Condensation Related Problems

Moving the equipment rapidly between hot and cold temperatures may cause condensation (water droplets) to form on its external and internal surfaces. You can avoid this by placing the equipment in an airtight, resealable plastic bag and letting it adjust to temperature changes slowly before removing it from the bag.

If Condensation Forms Inside the Camera

Stop using the camera immediately if you detect condensation. Continued use may damage the equipment. Remove the CF card and battery or power cord (if connected) from the camera and wait until the moisture evaporates completely before resuming use.

Extended Storage

When not using the camera for extended periods of time, remove the battery pack and store the equipment in a safe place. Storing the camera for extended periods with a battery pack installed will run down the battery pack and may damage the camera. Please note, however, that the date, time and other camera settings may reset to the default settings if the battery pack has been removed for more than three weeks. Follow the instructions in this guide to reset the desired settings.

Preparing the Camera

Guide to Components

Front View

=Microphone =Optical Viewfinder Window ➜ p. 27 =AF Auxiliary Light Emitter =Red-Eye Reduction Lamp ➜ p. 37 =Self-Timer Lamp ➜ p. 40

=Flash ➜ p. 37

=A/V OUT (Audio/

Video Out) Terminal ➜ p. 79

=DIGITAL (Digital)

Terminal* ➜ p. 65, 83

=Terminal Cover

=Lens

* To connect Card Photo Printer CP-10 (Optional), use the direct interface

cable provided with the printer. To connect a computer, use the USB interface cable supplied with the camera.

Back View

Preparing the Camera

=Viewfinder ➜ p. 27 =Lock for the CF Card Slot Cover ➜ p. 19

=CF Card Slot Cover ➜ p. 19 =Strap Eyelet ➜ p. 22

=Battery Cover ➜ p. 16

=DC Coupler Ter minal Cover ➜ p. 18

=LCD Monitor ➜ p. 28 =Tripod Socket

Preparing the Camera

Operation Panel

=Power Lamp (glow: Power

= (Display) Button ➜ p. 28

=Indicators

= (Menu) Button

= (Exposure Compensation)/ (White Balance)

Button ➜ pp. 41-42

= (Macro)/ (Infinity)/ (Right) Button ➜ p. 39

= (Continuous)/ (Self-Timer)/ (Left) Button

➜ p. 40 = (Flash)/ (Set) Button ➜ p. 37

Indicators

• The indicators will glow or flash at various stages when the main switch or shutter button is pressed.

Upper Indicator

Green: Ready to record Flashing Green: During camera warm-up/Recording to CF card/

Orange: Ready to record with flash Flashing Orange:

Lower Indicator

Yellow: Macro mode

Reading CF card/Deleting CF card images/ Transmitting images to or from a CF card (while connecting to a computer)

Ready to record but the camera blur warning is flashing

on/Ready to communicate (while connecting to a computer))

=Mode Dial ➜ p. 13 =Main Switch ➜ p. 25 =Shutter Button ➜ p. 31

=Zoom Button

Shooting: (Telephoto)/

(Wide Angle) Button

➜ p. 33 Replay: (Magnify) /

(Index) Button ➜ pp. 49-51

Preparing the Camera

Mode Dial

The mode dial is used to select shooting or replay modes.

Shooting Modes

(Auto)

The camera selects most settings automatically (p. 23).

(Manual)

You can set the exposure compensation, white balance and other settings manually.

(Stitch Assist)

Shoot images in overlapping series to create panoramas (p. 43).

(Movie)

Shoot movie clips (p. 46).

Replay Mode

(Replay)

•Images recorded onto the CF card can be replayed or erased (pp. 49-58).

•Images can be printed with a Card Photo Printer CP-10 (sold separately) connected (pp. 65-71).

•Images can be downloaded to and viewed on a computer when it is connected (pp. 80-84).

• The icon displays on the LCD monitor while the Card Photo Printer CP-10 is connected.

• The LCD monitor shuts off while a computer is connected.

Preparing the Camera

Charging the Battery Pack

Recharge the battery pack with battery charger CB-2LS or CB-2LSE the first time you use the camera or when the “Change the battery pack” message is displayed.

Battery charger model names and types vary by region.

CB-2LS

Charging Indicator

CB-2LSE

Charging Indicator

•Insert the battery pack all the way into the battery charger and plug the charger into an electrical outlet.

•The charging indicator will glow orange while the battery pack is charging. It will change to a steady green when the charge is complete.

•After charging, unplug the battery charger and remove the battery pack from it.

• Since this is a lithium ion battery pack, you need not completely use or discharge it before recharging.

• It takes approximately 130 minutes to fully charge the battery pack from a fully discharged state (based on standard Canon testing conditions). Please charge it at an ambient temperate ranging between 5 and 40 ºC (41 and 104 ºF).

• Charge times may vary according to the ambient temperature and the charge state of the battery pack.

• To protect and prolong the life of the battery pack, do not charge it for longer than 24 hours at a time.

Preparing the Camera

Handling Precautions

• Do not rapidly overturn or wave the battery charger around when the battery pack is in it. There is a danger of the battery pack flying out.

• At low temperatures, the battery pack performance may be reduced and the low battery icon may appear earlier than usual. Under these conditions, resuscitate the battery pack by warming it in a pocket immediately before use. However, ensure that there are no metallic items in the pocket that could cause the battery pack to short circuit, such as key holders, etc.

• Do not place anything, such as tablecloths, carpets, bedding or cushions, on top of the battery charger while it is charging. Heat will build up and could result in a fire.

• Do not charge batteries other than Battery Pack NB-1L in this charger.

• The battery pack continues to discharge a minimal portion of its power while installed in the camera, even with the camera power off or inserted into the battery charger. This will shorten battery life. To conserve the battery pack, store it in its case in a cool, dry place. Recharge it fully before using it again.

• If the performance of the battery pack diminishes substantially even when it is fully charged, the battery pack should be replaced.

Preparing the Camera

Installing the Battery Pack

Install Battery Pack NB-1L (supplied) as shown below.

• Please recharge the battery pack ( p. 14) before you use it for the first time.

• Slide the battery cover in the direction of the arrows.

• Press the battery lock while inserting the battery pack all the way in until the lock clicks.

• To remove the battery pack, press the battery lock and pull the battery pack out.

Battery Lock

• Slide the battery cover closed.

• When the camera’s indicator flashes green, do not turn off the power or open the battery cover. The camera is writing, reading, erasing or transmitting an image to or from the CF card.

• Remove the battery pack from the camera when the camera is not in use. Please note, however , that the date, time and other camera settings may reset to the default settings if the battery pack has been removed for more than three weeks.

• Please use a household power source for extended use of the camera (p. 18).

Preparing the Camera

Battery Performance

Recordable Images

LCD Monitor On LCD Monitor Off

Battery Pack NB-1L

(fully charged)

• The actual performance may vary from the above data according to the shooting conditions and the shooting mode.

• Excludes movie data.

• At low operating temperatures, the battery performance may drop and the low battery icon may apper sooner than at high temperatures. To improve performance at these temperatures, warm the battery in your pocket just before using it in the camera.

Shooting: Room temperature (23ºC, 73ºF), alternating between wide angle and

Replay: Room temperature (23ºC, 73ºF), continuous replay at 3 seconds per

telephoto every 20 seconds, flash used one in four shots, power turned off and on again after every eighth shot


Approx. 120 shots Approx. 270 shots Approx. 85 min.

Replay Time

Battery Pack Charge

The following icons and messages will display when the charge of the battery pack is low.

Battery pack charge is low. Recharge it as soon as possible before it is required for an extended period. When the LCD monitor is off, this icon will display when you press the , / or / button.

Change the battery pack

Battery charge is insufficient to operate the camera. Replace the battery pack immediately.

Preparing the Camera

Using the Household Power Source

It is best to power the camera with AC Adapter Kit ACK500 (sold separately) when you are using it for long periods of time or connecting it to a computer.

• Turn the camera power off before connecting or disconnecting the AC adapter .

• Connect the power cord to the compact power adapter first and then plug the other end into the electrical outlet.

Compact Power Adapter CA-PS500

• Open the battery cover and press the battery lock in the direction shown

TO BE REPLACED

Battery Lock

DC Coupler DR-500

while inserting DC Coupler DR-500. Insert the DC coupler all the way in until the battery lock clicks. Slide the battery cover closed.

• Open the DC coupler terminal cover and attach the cord to the DC terminal.

• After you have finished using the camera, unplug the AC adapter from the electrical outlet.

• Use of an AC adapter kit other than ACK500 may cause a malfunction in the camera or kit.

Preparing the Camera

Installing a CF Card

Turn the camera power off and insert the CF card with the following procedures.

• Slide the lock down and open the CF card slot cover.

• Insert the CF card until the slot’s eject button fully extends. Close the CF card slot cover.

• To remove the CF car d, push the eject

button and pull the CF card out.

CF Card Eject Button

• When the camera’s indicator flashes green, do not turn off the power or remove the CF card. The camera is writing, reading, erasing or transmitting an image to or from the CF card.

• Please note that CF cards from other manufacturers, or CF cards which have been edited with application software using other formats, may not operate correctly in the camera.

Preparing the Camera

Handling Precautions for CF Cards

• CF cards are high-precision electronic devices. Do not bend them, apply force to them, or subject them to shocks or vibration.

• Do not attempt to disassemble or alter a CF card.

• Moving a CF card rapidly between temperature extremes will cause condensation to form in the card and lead to a malfunction. To avoid condensation, place the CF card in a sealed plastic bag before moving it into a different temperature zone and allow it to adjust slowly to the new temperature. If condensation forms on the CF card, store it at room temperature until the water droplets have evaporated naturally.

• Place the CF card in the supplied case for storage.

• Do not use or store CF cards in the following types of location.

- Location subject to dust or sand

- Locations subject to high humidity and high temperatures

CF Cards and Estimated Capacities (Recordable Images)

FC-8M FC-16M FC-32M FC-64M FC-128M

7153164128

(

1600 x 1200 pixels

(

1024 x 768 pixels

(

640 x 480 pixels

MOVIE (

)

) 24 49 102 205 412

) 50 99 206 415 831

(

640 x 480 pixels 320 x 240 pixels

(

160 x 120 pixels

11 24 49 100 200 24 48 99 200 401 16 32 67 135 271

46 92 189 379 760 35 70 143 288 577

87 172 353 707 1417

sec.13 sec.27 sec.56 sec.

)18

sec.36 sec.75 sec.

)48

sec.97 sec.

198

sec.

152 399

sec. sec.

113 305 799

sec. sec. sec.

• These figures reflect standard shooting conditions established by Canon. Actual totals may vary according to the subject, shooting conditions and shooting mode.

• The maximum length of a movie clip recording is approximately: 4 seconds ( ), 10 seconds ( ) or 30 seconds ( ). The times shown are the

maximum continuous recording times.

• (Large), (Medium), (Small), , and indicate the recording resolution.

• (Superfine), (Fine) and (Normal) indicate the compression setting.

Preparing the Camera

Setting the Date and Time

• The Set Date/Time menu will appear the first time the camera power is turned on or whenever the built-in rechargeable lithium battery charge is low. Start from Step 5 to set the date and time.

• Press the main switch until the power lamp lights.

• Turn the mode dial to the , ,

or position.

• Use the or button to select the icon.

• Use the

or button to select

the icon.

• Select a field (year, month, day, hour, minutes and date format) with the

button.

• The factory default for the date format in some regions may differ from that shown.

Preparing the Camera

• Use the or button to change the value in a field.

• Press the button.

• The LCD monitor will return to the shooting mode.

• Please note that the date and time settings may reset to the default settings if the camera battery has been removed for more than three weeks. Reset them when this occurs.

Attaching the Wrist Strap

Thread the small loop of the wrist strap through the strap holder on the camera and pull the large loop through the small loop until the small loop fits snugly against the strap holder.

• Be careful not to wave the camera about or catch it on other items when dangling it from the wrist strap.

Quick Start

Shooting (Auto)

Press the main switch.

Press the main switch until the green power lamp beside the mode dial lights ➜ p. 25.

Turn the mode dial to the

(Auto) position.

Press the shutter button.

Press the shutter button lightly (halfway), wait until two beeps sound, and then press it all the way . Another beep will sound, indicating that the shot been taken ➜ p. 31.

To zoom, press the (Telephoto) or (Wide Angle) button.

• If the Set Date/Time menu appears, set the date and time (p. 21).

Quick start

Replaying (Single Image Replay)

Erasing Shortcut

Press the button while the image is displayed.

Press the main switch. Turn the mode dial to the

(Replay) position.

The last recorded image will display in the LCD monitor.

Press these buttons to switch to another image.

button displays the

The previous image. The button displays the next image.

Use the button to select [OK] and press the button.

• When you have finished viewing or erasing, press the main switch to turn off the power.

Basic Functions

Turning the Power On / Off

Press the main switch until the green power lamp lights.

• The upper indicator beside the viewfinder eyepiece will flash green.

• The lens will extend when the mode dial is turned to the

position.

• The lens will retract approximately 1 minute after the mode dial is turned

from any other mode.

• When the mode dial is set to the

or position, the LCD monitor will turn on regardless of its On/Off status.

Press the main switch again to turn off the power.

• The Set Date/Time menu will appear the first time the camera is turned on. Please set the date and time (p. 21).

• If the auto power down function activates, press the main switch again to restore power.

, , or

Basic Functions

Auto Power Down Function

Shooting Mode

The power will automatically shut off approximately 3 minutes after the last function is accessed.

Replay Mode

The power will automatically shut off approximately 5 minutes after the last function is accessed.

Connected to Card Photo Printer CP-10

The power will automatically shut off approximately 5 minutes after the last camera function is accessed or Card Photo Printer CP-10 (sold separately) ceases to print an image.

While Connected to a Computer (

A warning message will appear on the computer screen approximately 5 minutes after the last function is accessed. The power will automatically shut off approximately 1 minute later if no functions are accessed. (Except when the camera is powered by a household power source)

• The auto power down function will not activate while the camera is

in auto play mode.

• The camera’s settings can be changed to turn off the auto power

down function. (p. 76)

Auto power down function always active

)

Basic Functions

Using the Viewfinder

This camera is equipped with an optical viewfinder.

Align the square brackets (autofocus metering field) inside the viewfinder on the primary subject to compose the image.

Viewfinder

About the Autofocus Function

This camera employs AiAF (artificial intelligence autofocus) technology which uses a broad metering field to calculate the focal distance with high precision. It delivers a crisp focus even when the photographic subject is slightly off-center.

Using the Focus Lock

The following types of subject may not be suited to autofocus photography. Use the focus lock in these situations.

• Subjects with extremely low contrast to the surroundings

• Subjects with extremely bright objects at the center of the composition

• Subjects that are moving quickly

• Subjects through glass Tr y to shoot as close to the glass as possible to reduce the chances of light reflecting back off the glass.

How to Use the Focus Lock

1. Aim the camera so that a subject at the same focal distance as the

main subject is centered in the brackets in the optical viewfinder.

2. Press the shutter button halfway and wait until two beeps sound.

3. Re-aim the camera to compose the shot as desired and press the

shutter button all the way.

Basic Functions

Using the LCD Monitor

The LCD monitor can be used to compose images while shooting, adjust settings menus and replay images.

• The image in the LCD monitor will darken in strong sunlight or bright light. This does not constitute a

LCD Monitor

Shooting Mode

(

, , and on the mode dial)

Indicator

• The LCD monitor setting (On or Off) is saved by the camera when the power is turned off so that the same setting is automatically available when the power is turned on again. However , the setting may be lost when the power has been turned off after the “Change the battery pack” message has displayed, while the LCD monitor was on in shooting mode.

• In macro mode, the parallax phenomenon may cause images composed with the viewfinder to be off-center. Use the LCD monitor to compose close-ups in macro mode (p. 39).

malfunction.

• Pressing the button turns the LCD monitor on or off.

• Set the flash to On or affix the camera to a tripod when the upper indicator flashes orange and the camera blur warning icon ( ) appears in the LCD monitor after the metering preparations are complete.

+ 74 hidden pages
