Thank you for purchasing the CANDY induction hob. Please read this instruction manual

carefully before using the hob and keep it in a safe place for future reference.

EN-1

By placing the CE mark on this product, we are confirming compliance to all relevant European safety, health and environmental requirements which are applicable in legislation for this product.

Safety Warnings

Your safety is important to us. Please read this information before using your hob.

Installation Electrical Shock Hazard

• Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it.

• Connection to a good earth wiring system is essential and mandatory.

• Alterations to the domestic wiring system must only be made by a qualified electrician.

• Failure to follow this advice may result in electrical shock or death.

Cut Hazard

• Take care - panel edges are sharp.

• Failure to use caution could result in injury or

cuts.

Important safety instructions

• Read these instructions carefully before installing or using this appliance.

• No combustible material or products should be placed on this appliance at any time.

• Please make this information available to the

EN-2

person responsible for installing the appliance as it could reduce your installation costs.

• In order to avoid a hazard, this appliance must be installed according to these instructions for installation.

• This appliance is to be properly installed and earthed only by a suitably qualified person.

• This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply.

• Failure to install the appliance correctly could invalidate any warranty or liability claims.

Operation and maintenance

Electrical Shock Hazard

• Do not cook on a broken or cracked hob surface. If the hob surface should break or crack,switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician.

• Switch the hob off at the wall before cleaning or maintenance.

• Failure to follow this advice may result in electrical shock or death.

Health Hazard

• This appliance complies with electromagnetic

EN-3

safety standards.

• However, persons with cardiac pacemakers or other electrical implants (such as insulin pumps) must consult with their doctor or implant manufacturer before using this appliance to make sure that their implants will not be affected by the electromagnetic field.

• Failure to follow this advice may result in death.

Hot Surface Hazard

• During use, accessible parts of this appliance will become hot enough to cause burns.

• Do not let your body, clothing or any item other than suitable cookware contact the Induction glass until the surface is cool.

• Beware: magnetisable metal objects worn on the body may become hot in the vicinity of the cooktop. Gold or silver jewellery will not be affected.

• Keep children away.

• Handles of saucepans may be hot to touch.

Check saucepan handles do not overhang other cooking zones that are on. Keep handles out of reach of children.

• Failure to follow this advice could result in burns and scalds.

EN-4

Cut Hazard

• The razor-sharp blade of a hob surface scraper is exposed when the safety cover is retracted.Use with extreme care and always store safely and out of reach of children.

• Failure to use caution could result in injury or cuts.

Important safety instructions

• Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite.

• Never use your appliance as a work or storage surface.

• Never leave any objects or utensils on the appliance.

• Do not place or leave any magnetisable objects (e.g. credit cards, memory cards) or electronic devices (e.g. computers, MP3 players) near the appliance, as they may be affected by its electromagnetic field.

• Never use your appliance for warming or heating the room.

• After use, always turn off the cooking zones and the hob as described in this manual(i.e. by using the touch controls). Do not rely on the pan detection feature to turn off the cooking zones when you remove the pans.

EN-5

• Do not allow children to play with the appliance or sit, stand, or climb on it.

• Do not store items of interest to children in cabinets above the appliance. Children climbing on the cooktop could be seriously injured.

• Do not leave children alone or unattended in the area where the appliance is in use.

• Children or persons with a disability which limits their ability to use the appliance should have a responsible and competent person to instruct them in its use. The instructor should be satisfied that they can use the appliance without danger to themselves or their surroundings.

• Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician.

• Do not use a steam cleaner to clean your hob.

• Do not place or drop heavy objects on your

hob.

• Do not stand on your hob top.

• Do not use pans with jagged edges or drag

pans across the Induction glass surface as this can scratch the glass.

• Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can scratch the Induction

EN-6

glass.

• If the power supply cable is damaged, it must only be replaced by a qualified technician.

• This appliance is designed for domestic use only.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

• WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.

• Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.

• After use, switch off the hob element by its control and do not rely on the pan detector.

• The appliance is not intended to be operated by means of an external timer or separate remote-control system.

1. Heating zone selection controls

2. Timer control

3. Boiling prompt control

4. keep warm control

5. Flexible zone control

6. Power / Timer slider touch control

7. Boost control

8. Keylock control

9. ON/OFF control

EN-7

Congratulations on the purchase of your new Induction Hob.

We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.

Product Overview

Top View

1. max. 1800/3000 W zone

2. max. 1800/3000 W zone

3. max. 3000/4000 W zone

4. max. 1400/2000 W zone

5. Flexible zone. 3000/4000 W

6. Glass plate

7. Control panel

Control Panel

3 4

987

iron pot

magnetic circuit ceramic glass plate induction coil induced currents

EN-8

A Word on Induction Cooking

Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up.

Before using your New Induction Hob

• Read this guide, taking special note of the ‘Safety Warnings’ section.

• Remove any protective film that may still be on your Induction hob.

Using the Touch Controls

• The controls respond to touch, so you don’t need to apply any pressure.

• Use the ball of your finger, not its tip.

• You will hear a beep each time a touch is registered.

• Make sure the controls are always clean, dry, and that there is no object (e.g.

a utensil or a cloth) covering them. Even a thin film of water may make the controls difficult to operate.

EN-9

Choosing the right Cookware

• Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the

• You can check whether your cookware is suitable by carrying out

• If you do not have a magnet:

1. Put some water in the pan you want to check.

2. Follow the steps under ‘To start cooking’.

3. If does not flash in the display and the water is heating, the pan is suitable.

• Cookware made from the following materials is not suitable: pure stainless steel, aluminium or copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

Do not use cookware with jagged edges or a curved base.

packaging or on the bottom of the pan.

a magnet test. Move a magnet towards the base of the pan. If it is attracted, the pan is suitable for induction.

Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider energy will be used at its maximum efficiency. If you use smaller pot efficiency could be less than expected. Pot less than 140 mm could be undetected by the hob. Always centre your pan on the cooking zone.

Always lift pans off the Induction hob – do not slide, or they may scratch the glass.

Cooking zone

The base diameter of induction cookware

Minimum (mm)

Maximum (mm)

1,2,

140

220 3 220

300 4 120

160

Flexible zone

220

220x400

EN-10

Pan Dimension

The cooking zones are, up to a limit, automatically adapted to the diameter of the pan. However the bottom of this pan must have a minimum of diameter according to the corresponding cooking zone. To obtain the best efficiency of your hob, please place the pan in the centre of the cooking zone.

Using your Induction Hob

To start cooking

1. Touch the ON/OFF control.

After power on, the buzzer beeps once, timer control

show “ CL “ ，heating zone selection controls show “ 00, indicating that the induction hob has entered the state of standby mode.

2. Place a suitable pan on the cooking zone that you wish to use.

• Make sure the bottom of the pan and the surface

of the cooking zone are clean and dry.

3.Touching the heating zone selection control,

and a indicator upon you touched will flash

EN-11

4. Adjust heat setting by touching the slider control.

• If you don’t choose a heat setting within 1

minute, the Induction hob will automatically

switch off. You will need to start again at step 1.

• You can modify the heat setting at any time

during cooking.

If the display flashes alternately with the heat setting

This means that:

• you have not placed a pan on the correct cooking zone or,

• the pan you’re using is not suitable for induction cooking or,

• the pan is too small or not properly centred on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone. The display will automatically turn off after 1 minute if no suitable pan is placed on it.

When you have finished cooking

1. Touching the heating zone selection control that you wish to switch off.

2. Turn the cooking zone off by touching the slider to the left. Make sure the display shows”0”.

EN-12

3. Turn the whole hob off by touching the

ON/OFF control.

4. Beware of hot surfaces H will show which cooking zone is hot to touch. It will disappear when the

surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot.

Using the Boost function

Actived the boost function

1. Touching the heating zone selection control

2. Touching the boost control ,the zone indicator shows “b” and the power reaches Max.

Cancel the Boost function

1. Touching the heating zone selection control For which you wish to cancel the boost function.

EN-13

2. a: Touching the boost control “ ”, then the cooking zone will revert to its

original setting. b: Touching the slider control, then the cooking zone will revert to the level you select.

• The function can work in all cooking zones

• The cooking zone returns to its original setting after 5 minutes.

• As the boost function of 1st cooking zone is activated ,the 2nd cooking zone is

limited under level 2 automatically. vice versa

• If the original heat setting equals 0, it will return to 15 after 5 minutes.

Using the Keep Warm function

Actived the keep warm function

1. Touching the heating zone selection control

2. Touching the keep warm control ,the zone indicator show “ | ” .

EN-14

Cancel the keep warm function

1. Touching the heating zone selection control

2. a: Touching the slider control, then the cooking zone will revert to the level you select.

b: Touching the function control such as or , then the cooking zone will revert to the level you previously selected.

FLEXIBLE AREA

• This area can be used as a single zone or as two separate zones, accordingly

to the cooking needs.

• The flexible area is made of two independent inductors that can be controlled

separately. When working as a single zone, if a cookware is moved from one

zone to the other one within the flexible area it will keep the same power level

of the zone where the cookware originally was placed, and the part that is not

covered by cookware will automatically switch off.

• IMPORTANT：Make sure to place the cookwares in the center of the single

cooking zone. In case of large pan, oval, rectangular and long pans make sure

it is placed in the center of the cooking zone covering both logos.

EN-15

Examples of correct pan placement and incorrect pan placement.

As large zone

1. To activate the flexible area as a single large zone, simply press the

dedicated keys.

2. The power setting works as any other normal area.

3. If the pan is moved from the front to the rear part (or vice versa),the

flexible area detects automatically the new position, keeping the same power.

4. To add a further pan, press again the dedicated keys, in order to detect the

cookware.

Two independent zones To use the flexible area as two separete zones with different power settings, press the dedicated keys.

Power level

Keep warm

1~5

6~10

11~14

Default working timer (hour)

8 4 2

EN-16

Locking the Controls

• You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on).

• When the controls are locked, all the controls except the ON/OFF control are disabled.

To lock the controls

Touch the keylock control. The timer indicator will show “Loc “

To unlock the controls

1. Touch and hold the keylock control for a while.

2. You can now start using your Induction hob.

When the hob is in the lock mode, all the controls are disable except the ON/OFF, you can always turn the induction hob off with the ON/OFF control in an emergency, but you shall unlock the hob first in the next operation

Over-Temperature Protection

A temperature sensor equipped can monitor the temperature inside the Induction hob. When an excessive temperature is monitored, the Induction hob will stop operation automatically.

Detection of Small Articles

When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork, key) has been left on the hob, the hob automatically go on to standby in 1 minute. The fan will keep cooling down the induction hob for a further 1 minute.

Auto Shutdown Protection

Auto shut down is a safety protection function for your induction hob. It shuts down automatically if ever you forget to turn off your cooking. The default working times for various power levels are shown in the below table: .

When the pot is removed, the induction hob can stop heating immediately and the hob automatically switch off after 2 minutes.

EN-17

People with a heart pace maker should consult with their doctor before using this unit.

Using the Timer

You can use the timer in two different ways:

• You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up.

• You can set it to turn cooking zones off after the set time is up.

• You can set the timer for up to 99 minutes.

Using the Timer as a Minute Minder

If you are not selecting any cooking zone

1. Make sure the cooktop is turned on.

Note: you can use the minute minder even if you’re not selecting any cooking zone.

2. Touch timer control , the “10” will be shown in the

timer display where you touched and the “0” flashes.

3. Set the time by touching the slider control. (e.g. 6)

4. Touch timer control again, the “1” will flash.

5. set the time by touching the slider control (e.g.9),

now the timer you set is 96 minutes.

EN-18

6. Buzzer will beep for 30 seconds and the timer indicator shows “00 “ when the setting time finished.

Setting the timer to turn cooking zones off

If the timer is set on one zone:

1. Touching the heating zone selection control that you want to set the timer for.

2. Touch timer control , the “10” will be shown on the

timer display and the “0” flashes.

3. Set the time by touching the slider control. (e.g. 6)

4. Touch timer control again, the “1” will flash.

set the time by touching the slider control (e.g.9), 5.

now the timer you set is 96 minutes.

+ 43 hidden pages
