Portable Air Compressors
Compresseurs d’Air Portatifs
Compresores de Aire Portátiles
Replacement Parts List |
|
Liste de Pièces de Rechange |
VT640300, VT640400, VT640600 |
Lista de Repuestos |
|
|
|
38
23
31
|
|
|
29 |
30 |
|
|
32 |
|
|
|
|
|
|
|
33 |
|
|
|
27 |
|
|
|
25 |
|
|
4 |
|
15 |
13 |
|
10 |
|
|
||
|
|
A |
12 |
|
|
U |
|
|
|
T |
|
|
|
O OFF |
|
11 35
14
34
36
|
20 |
|
28 |
|
22 |
26 |
19 |
|
|
18 |
21 |
|
|
|
|
|
4 |
|
17 |
|
24 |
16 |
|
|
|
37
8
1
15 9
|
4 |
7 |
|
2 |
3 |
5 |
6 |
|
|
© 2008 Campbell Hausfeld/Scott Fetzer
IN625800AV 6/08
For parts, product & service information
visit www.chpower.com
VT640300, VT640400 and VT640600
For replacement parts or technical assistance, call 1-800-543-6400
Please provide following information: |
Address parts correspondence to: |
- Model number |
Campbell Hausfeld |
- Serial number (if any) |
Attn: Customer Service |
- Part description and number as shown in parts list |
100 Production Drive |
|
Harrison, OH 45030 |
Repair Parts List
Ref. |
|
|
Part Number For Models |
|
|
No. |
Description |
VT640300 |
VT640600 |
VT640400 |
Qty |
1 |
Tank |
AR044700CG |
AR044800CG |
AR044800CG |
1 |
2 |
Drain cock |
D-1403 |
D-1403 |
D-1403 |
1 |
3 |
Rubber foot kit |
HL021300AV |
HL021300AV |
HL021300AV |
2 |
4 |
5/16 in. - 18 Locknut |
-- |
-- |
-- |
10 |
5 |
10 in. Wheel |
▲ |
▲ |
▲ |
2 |
6 |
Axle bolt |
▲ |
▲ |
▲ |
2 |
7 |
Hex nut |
▲ |
▲ |
▲ |
2 |
8 |
Handle |
■ |
■ |
■ |
1 |
9 |
Handle screw |
■ |
■ |
■ |
1 |
10 |
Pressure switch |
CW217400AV |
CW217400AV |
CW217400AV |
1 |
11 |
Motor cord |
EC012800AV |
EC012800AV |
EC012800AV |
1 |
12 |
Power cord and plug assembly |
EC012601AV |
EC012601AV |
EC012901AV |
1 |
13 |
ASME Safety valve |
V-215105AV |
V-215105AV |
V-215105AV |
1 |
14 |
1/4 in. Nipple |
-- |
-- |
-- |
1 |
15 |
Gauge |
GA016300AV |
GA016300AV |
GA016300AV |
2 |
16 |
Check valve |
VT911300AV |
VT911300AV |
VT911300AV |
1 |
17 |
Discharge tube |
VT910700AV |
VT910700AV |
VT910700AV |
1 |
18 |
Oil drain cap |
ST150100AV |
ST150100AV |
ST150100AV |
1 |
19 |
Oil drain extension |
ST083800AV |
ST083800AV |
ST083800AV |
1 |
20 |
Pump |
VT480000KB |
VT480000KB |
VT470000KB |
1 |
21 |
5/16 in. - 18 x 11/4 in. Screw |
ST016000AV |
ST016000AV |
ST016000AV |
4 |
22 |
Filter assembly |
VH901700AV |
VH901700AV |
VH901700AV |
1 |
23 |
Belt guard assembly |
VT911000AV |
VT911000AV |
VT911000AV |
1 |
24 |
Flywheel |
PU015900AJ |
PU015900AJ |
PU015900AJ |
1 |
25 |
3/16 in. Key |
KE000900AV |
KE000900AV |
KE000900AV |
1 |
26 |
3/8 in. - 16 x 3/4 in. Setscrew |
-- |
-- |
-- |
1 |
27 |
Pulley |
PU015200AV |
PU015200AV |
PU012600AV |
1 |
28 |
1/4 in. - 20 x 1/2 in. Setscrew |
-- |
-- |
-- |
1 |
29 |
Belt |
BT020400AV |
BT020400AV |
BT020400AV |
1 |
30 |
Electric motor |
MC015502SJ |
MC015502SJ |
MC015403SJ |
1 |
31 |
3/16 in. sq. x 11/4 in. Key |
KE000903AV |
KE000903AV |
KE000903AV |
1 |
32 |
5/16 in. - 18 Hex head screw |
-- |
-- |
-- |
4 |
33 |
5/16 in. Washer |
-- |
-- |
-- |
4 |
34 |
Regulator |
RE206203AV |
RE206203AV |
RE206203AV |
1 |
35 |
1/4 in. x 1/8 in. Reducer |
-- |
-- |
-- |
1 |
36 |
1/4 in. Nipple |
-- |
-- |
-- |
1 |
37 |
Unloader Tube (includes nut and ferrule) |
VT911500AV |
VT911600AV |
VT911600AV |
1 |
38 |
Beltguard connector |
VT911100AV |
VT911100AV |
VT911100AV |
6 |
▲ |
Warning decal 3 Piece |
DK747600AV |
DK747600AV |
DK747600AV |
1 |
REPAIR PARTS KITS |
|
|
|
|
|
▲ |
Wheel Kit |
VT910600AV |
VT910600AV |
VT910600AV |
|
■ |
Handle Kit |
VT910800AV |
VT910800AV |
VT910800AV |
|
--Not available
See compressor nameplate for exact model number when ordering pump repair parts.
▲Not shown
