BTC 9000A User Manual

99000000AA MMuullttiimmeeddiiaa KKeeyybbooaarrdd UUsseerr''ss GGuuiiddee

Congratulations on your purchasing this multimedia keyboard. You'll discover
your performance will be enhanced to a high level with this keyboard for power
management, multimedia and the Web.

System Requirement

! Microsoft® Windows® 95, Windows® 98, Windows® ME, Windows NT®

4.0 or Windows® 2000 operating system

! Microsoft Internet Explorer 5.0 or later version (for Internet buttons)
! CD-ROM drive & standard sound card (for CD and Video operation)
! The system supporting ACPI or APM II (for power management buttons)
! ATX mother board and ATX power supply (for power management

buttons)

Multimedia Buttons & ACPI Key

To have following buttons work, the KeyMaestro keyboard driver enclosed is
needed to install. Please refer to the file readme.htm in the disk for installation.
As for applying advanced functions, please refer to the help.htm the in the driver.

ACPI Key

Power Off

Multimedia Buttons

Help
My Favourites
Shortcut
WWW Search

WWW Next / Fast Forward
Mute

Play / Pause

Sleep Wake up

Volume Control
Volume Control Knob
Previous / Fast Backward
Eject

Stop

Keyboard Cable Connector

PS/2 Compatible Cable (6-pin Miniatures Din Connector)

Pin # Signal Name Voltage
1 Keyboard Clock +5VDC Signal
2 Ground 0
3 Keyboard Data +5VDC Signal
4 Reserved 0
5 +5VDC +5VDC
6 Reserved 0
