BASIC USER’S GUIDE

MFC-J430W

Version 0

CHN-ENG

To create a better environment

Please cooperate

Firstly, thank you very much indeed for using our Brother products!

Brother focuses on the earth environment concerned. And make a basic policy which is to concern about the earth environment, including any workflow from product development to discard. The local citizen should be responsible for local society and its environment during these environment protection activities.

Therefore, we hope you'll take part in this environment plan, and pay attention to environment protection points as below while discarding used consumables.

1 Please deliver the used package materials to relevant waste disposal office for recycle.

2 When you discard used consumables, please follow and carry on relevant local regulations

properly.

3 When the machine need replacing parts for the maintenance and repair, please discard used

circuit boards, used electrical parts and products as disposed electrical materials.

4 Some parts in the machine can be used on the same series model machines which produced

by the same factory.

Note: If you want to replace the parts, please contact your local Brother repair station.

User's Guides and where do I find it?

Which manual? What's in it? Where is it?

Product Safety Guide Read this Guide first. Please read the Safety

Instructions before you set up your machine. See this Guide for trademarks and legal limitations.

Quick Setup Guide Follow the instructions for setting up your

machine and installing the drivers and software for the operating system and connection type you are using.

Basic User's Guide Learn the basic Fax, Copy and Scan operations

and how to replace consumables. See troubleshooting tips.

Advanced User's Guide Learn more advanced operations: Fax, Copy,

security features, printing reports and performing routine maintenance.

Software User's Guide Follow these instructions for Printing, Scanning,

Network Scanning, PC-Fax Send, Web Services (Scan), and using the Brother ControlCenter utility.

Network Glossary This Guide provides basic information about

advanced network features of Brother machines along with explanations about general networking and common terms.

Printed / In the box

PDF file / CD-ROM

Network User's Guide This Guide provides useful information about

wireless network settings and security settings using the Brother machine. You can also find supported protocol information for your machine and detailed troubleshooting tips.

Mobile Print/Scan Guide This Guide provides useful information about

printing data from your mobile phone and transmitting scanned data from the Brother machine to your mobile phone.

Visit us at http://solutions.brother.com/.

PDF file / CD-ROM

PDF file / Brother Solutions Center

(BASIC USE'S GUIDE)

1 General information 1

Using the documentation .......................................................................................1

Symbols and conventions used in the documentation ....................................1

Accessing the Advanced User’s Guide, Software User’s Guide, Network User’s

Guide, and Network Glossary.............................................................................2

Viewing Documentation...................................................................................2

Accessing Brother Support (Windows

Accessing Brother Support (Macintosh) ................................................................5

Control panel overview ..........................................................................................6

LCD screen indications....................................................................................8

Basic Operations .............................................................................................8

Volume Settings.....................................................................................................9

Ring Volume ....................................................................................................9

Beeper Volume..............................................................................................10

Speaker Volume ............................................................................................10

LCD display .........................................................................................................10

Setting the backlight brightness.....................................................................10

LCD Language ..............................................................................................10

Setting the Fax Logic (sending and receiving sequence)....................................11

)................................................................4

2 Loading paper 12

Loading paper and other print media...................................................................12

Loading envelopes and postcards.................................................................15

Printable area ................................................................................................17

Paper settings......................................................................................................18

Paper Type ....................................................................................................18

Paper Size .....................................................................................................18

Acceptable paper and other print media..............................................................19

Recommended print media ...........................................................................19

Handling and using print media .....................................................................20

Choosing the right print media.......................................................................21

3 Loading documents 23

How to load documents .......................................................................................23

Using the ADF ...............................................................................................23

Using the scanner glass ................................................................................24

Unscannable area .........................................................................................25

4 Sending a fax 26

How to send a fax................................................................................................26

Stop faxing.....................................................................................................27

Setting scanner glass size for faxing.............................................................27

Color fax transmission...................................................................................27

Cancelling a fax in progress ..........................................................................27

Transmission Verification Report...................................................................28

5 Receiving a fax 29

Receive Modes....................................................................................................29

Using Receive Modes..........................................................................................30

Receive Mode settings ........................................................................................31

Ring Delay .....................................................................................................31

F/T Ring Time (Fax/Tel mode only)...............................................................31

Fax Detect .....................................................................................................32

6 Telephone and external devices 33

Voice operations..................................................................................................33

Tone or pulse.................................................................................................33

Fax/Tel mode.................................................................................................33

Phone line services..............................................................................................33

Do you have Voice Mail?...............................................................................33

Telephone Service...............................................................................................34

Caller ID (Caller IDentification) (not available in certain area).......................34

Advantages of Caller ID.................................................................................35

Setup Method ................................................................................................35

Caller ID feature ............................................................................................35

Connecting an external TAD (telephone answering device)................................36

Connections settings .....................................................................................36

Recording an outgoing message (OGM) on an external TAD.......................37

Multi-line connections (PABX) .......................................................................37

External and extension telephones......................................................................37

Connecting an external or extension telephone ............................................37

Operation from external and extension telephones.......................................38

Using a cordless external telephone .............................................................38

Using remote codes.......................................................................................38

iii

7 Dialling and storing numbers 40

How to dial ...........................................................................................................40

Manual dialling...............................................................................................40

Speed Dialling ...............................................................................................40

Search ...........................................................................................................40

Fax Redial .....................................................................................................41

Additional Dialling Operations..............................................................................41

Outgoing Call history .....................................................................................41

Caller ID history .............................................................................................42

Storing numbers ..................................................................................................43

Storing a pause .............................................................................................43

Storing Speed Dial numbers..........................................................................43

Changing Speed Dial names or numbers......................................................43

8 Making copies 45

How to copy .........................................................................................................45

Stop copying..................................................................................................45

Copy settings.................................................................................................45

Paper Options................................................................................................46

9 How to print from a computer 47

Printing a document.............................................................................................47

10 How to scan to a computer 48

Scanning a document ..........................................................................................48

Scanning using the SCAN key.............................................................................48

Scanning using a scanner driver .........................................................................49

Scanning using the ControlCenter.......................................................................49

A Routine maintenance 50

Replacing the ink cartridges ................................................................................50

Cleaning and checking the machine....................................................................53

Cleaning the scanner glass ...........................................................................53

Cleaning the print head .................................................................................54

Checking the print quality ..............................................................................54

Checking the print alignment .........................................................................55

Packing and shipping the machine ......................................................................56

B Troubleshooting 58

Error and Maintenance messages.......................................................................58

Error animations display ................................................................................63

Transferring your faxes or Fax Journal report ...............................................63

Document jam ...............................................................................................64

Printer jam or paper jam ................................................................................65

Troubleshooting ..................................................................................................68

If you are having difficulty with your machine................................................68

Dial Tone detection........................................................................................75

Telephone line interference / VoIP ................................................................75

Machine Information ............................................................................................76

Checking the serial number...........................................................................76

Reset functions..............................................................................................76

How to reset the machine..............................................................................76

C Menu and features 77

On-screen programming......................................................................................77

Menu table...........................................................................................................78

Entering Text .......................................................................................................91

Inserting spaces ............................................................................................91

Making corrections ........................................................................................91

Repeating letters ...........................................................................................91

Special characters and symbols....................................................................91

D Specifications 92

General................................................................................................................92

Print media...........................................................................................................94

Fax.......................................................................................................................95

Copy ....................................................................................................................96

Scanner ...............................................................................................................97

Printer ..................................................................................................................98

Interfaces.............................................................................................................99

Computer requirements.....................................................................................100

Consumable items.............................................................................................101

Network (LAN) ...................................................................................................102

E Index 103

Table of Contents

(Advanced USE'S GUIDE)

The Advanced User’s Guide explains the following features and operations.

You can view the Advanced User’s Guide on the CD-ROM.

1 General setup

Memory storage Sleep Mode LCD display Mode Timer

2 Security features

TX Lock

3 Sending a fax

Additional sending options Additional sending operations

4 Receiving a fax

Additional receiving operations

5 Dialling and storing numbers

Additional dialling operations Additional ways to store numbers

6 Printing reports

Fax reports Reports

7 Making copies

Copy settings

A Routine maintenance

Cleaning and checking the machine

B Glossary

C Index

General information 1

Using the documentation

Thank you for buying a Brother machine! Reading the documentation will help you make the most of your machine.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injuries.

CAUTION

Symbols and conventions used in the documentation 1

The following symbols and conventions are used throughout the documentation.

Bold Bold typeface identifies specific

buttons on the machine’s control panel, or on the computer screen.

Italics Italicized typeface emphasizes

an important point or refers you to a related topic.

Courier

New

Text in the Courier New font identifies messages on the LCD of the machine.

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injuries.

IMPORTANT

IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in damage to property or loss of product functionality.

Notes tell you how you should respond to a situation that may arise or give tips about how the operation works with other features.

Electrical Hazard icons alert you to possible electrical shocks.

Chapter 1

Note

Accessing the Advanced User’s Guide, Software User’s Guide, Network User’s Guide, and Network Glossary

This Basic User’s Guide does not contain all the information about the machine, such as how to use the advanced features of the Fax, Copy, Printer, Scanner, PC-Fax, and Network. When you are ready to learn detailed information about these operations, you can read the Advanced User’s Guide,

Software User’s Guide, Network User’s Guide, and Network Glossary that are on the CD-ROM.

c If the language screen appears, click

your language. The CD-ROM Top Menu will appear.

d Click Documentation. e Click PDF documents. If the country

screen appears, choose your country. After the list of User’s Guides appears, choose the guide you want to read.

Viewing Documentation 1

Viewing Documentation (Windows

To view the documentation, from the Start menu, select Brother, MFC-XXXX (where XXXX is your model name) from the programs list, and then choose User’s Guides.

If you have not installed the software, you can find the documentation on the CD-ROM by following the instructions below:

)

a Turn on your PC. Insert the Brother

CD-ROM into your CD-ROM drive.

If the Brother screen does not appear automatically, go to My Computer (Computer), double-click the CD-ROM icon, and then double-click

start.exe.

b If the model name screen appears, click

your model name.

General information

Note

Viewing Documentation (Macintosh)

a Turn on your Macintosh. Insert the

Brother CD-ROM into your CD-ROM drive. The following window will appear.

b Double-click the Documentation icon. c Double-click your language folder.

How to find Scanning instructions 1

There are several ways you can scan documents. You can find the instructions as follows:

Software User’s Guide

 Scanning

 ControlCenter

 Network Scanning

Presto! PageManager User’s Guide

(Windows

 Instructions for scanning directly from

Presto! PageManager. The complete Presto! PageManager User’s Guide can be viewed from the Help section in the Presto! PageManager application.

Presto! PageManager User’s Guide (Macintosh users)

users)

d Double-click top.pdf. If the country

screen appears, choose your country.

e After the list of User’s Guides appears,

choose the guide you want to read.

Presto! PageManager must be downloaded and installed before use. See Accessing Brother Support (Macintosh) uu page 5 for further instructions.

 The complete Presto! PageManager

User’s Guide can be viewed from the Help section in the Presto! PageManager application.

Chapter 1

How to find Network setup instructions

Your machine can be connected to a wireless network.

Basic setup instructions uuQuick Setup Guide

If your wireless access point or router supports Wi-Fi Protected Setup or AOSS™ uuQuick Setup Guide

Network setup uuNetwork User’s Guide

Support (Windows

You can find all the contacts you will need, such as Web support (Brother Solutions Center) on the CD-ROM.

 Click Brother Support on the Top Menu.

The following screen will appear:

) 1

Accessing Brother

 To access our website, click

Brother Home Page.

 For the latest news and product support

information, click Brother Solutions Center.

 To visit our website for original Brother

Supplies, click Supplies Information.

 To access the Brother CreativeCenter for

FREE photo projects and printable downloads, click Brother CreativeCenter.

 To return to the top menu, click Back or if

you have finished, click Exit.

Accessing Brother

General information

Support (Macintosh)

You can find all the contacts you will need, such as Web support (Brother Solutions Center) on the CD-ROM.

 Double-click the Brother Support icon.

The following screen will appear:

 To download and install Presto!

PageManager, click

Presto! PageManager.

 For the latest news and product support

information, click Brother Solutions Center.

 To visit our website for original Brother

Supplies, click Supplies Information.

Chapter 1

Control panel overview

1 Mode keys:

 FAX

Lets you access the FAX mode.

 SCAN

Lets you access the SCAN mode.

 COPY

Lets you access the COPY mode.

2 Telephone keys:

 Redial/Pause

Redials one of the last 30 numbers called. It also inserts a pause when dialling.

 Hook

Press before dialling if you want to make sure a fax machine will answer, and then press Mono Start or Color Start.

Also, press this key after picking up the handset of an external telephone during the F/T Ring (fast double-ring).

3 Start keys:

 Mono Start

Lets you start sending faxes or making copies in monochrome. Also lets you start a scanning operation (in color or mono depending on the scan setting in the ControlCenter software).

 Color Start

Lets you start sending faxes or making copies in full color. Also lets you start a scanning operation (in color or mono, depending on the scan setting in the ControlCenter software).

4 Stop/Exit

Stops an operation or exits the menu.

5 Dial Pad

Use these keys to dial telephone and fax numbers and as a keyboard for entering information into the machine.

General information

6 Menu keys:

 Volume keys

d c

While the machine is idle, you can press these keys to adjust the ring volume.

 Speed Dial key

Lets you store, look up, and dial numbers that are stored in the memory.

 d or c

Press d or c to move the selected area left or right on the LCD.

 a or b

Press a or b to scroll through the menus and options.

 Menu

Access the main menu.

 Clear

Press to delete characters or to go back to the previous menu level.

 OK

Lets you choose a setting.

7 LCD (Liquid Crystal Display)

Displays messages on the screen to help you set up and use your machine.

8 On/Off

You can turn the machine on and off.

Press On/Off to turn the machine on.

Press and hold down On/Off to turn the

machine off. The LCD will show Shutting Down and will stay on for a few seconds before going off.

If you have connected an external telephone or TAD, it is always available.

If you turn the machine off using the

button, it will still periodically clean the print head to maintain print quality. To prolong print head life, provide the best ink cartridge economy, and maintain print quality, you should keep your machine connected to the power at all times.

On/Off

Chapter 1

LCD screen indications 1

The LCD shows the current machine status when the machine is idle.

432

1 Wireless Status

A four level indicator shows the current wireless signal strength if you are using a wireless connection.

Basic Operations 1

The following steps show how to change a setting in the machine. In this example the Receive Mode setting is changed from Fax Auto to Fax/Tel.

a Press Menu. b Press a or b to choose Initial

Setup.

Press OK.

c Press a or b to choose Receive Mode.

0Max

2 Current Receive Mode

Lets you see the current Receive Mode.

 Fax (Fax Auto)  F/T (Fax/Tel)  TAD (External TAD)  Mnl (Fax Manual)

3 Memory Status

Lets you see the available memory in the machine.

4 Ink indicator

Lets you see the available ink volume.

The warning icon appears when there is an error or maintenance message. For

details, see Error and Maintenance messages uu page 58.

Press OK.

General information

d Press a or b to choose Fax/Tel.

Press OK. You can see the current setting on the LCD:

e Press Stop/Exit.

Volume Settings

Ring Volume 1

You can choose from a range of ring volume levels, from High to Off.

While the machine is idle, press d or c to adjust the volume level. The LCD shows the current setting, and each key press will change the volume to the next level. The machine will keep the new setting until you change it.

You can also change the volume through the menu, by following the instructions below:

Setting the Ring Volume from the menu

a Press Menu.

b Press a or b to choose

General Setup. Press OK.

c Press a or b to choose Volume.

Press OK.

d Press a or b to choose Ring.

Press OK.

e Press a or b to choose Low, Med, High

or Off. Press OK.

f Press Stop/Exit.

Chapter 1

Beeper Volume 1

When the beeper is on, the machine will beep when you press a key, make a mistake, or after you send or receive a fax.

You can choose from a range of beeper volume levels, from High to Off.

a Press Menu. b Press a or b to choose

General Setup. Press OK.

c Press a or b to choose Volume.

Press OK.

d Press a or b to choose Beeper.

Press OK.

e Press a or b to choose Low, Med, High

or Off. Press OK.

f Press Stop/Exit.

LCD display

Setting the backlight brightness 1

If you are having difficulty reading the LCD, try changing the brightness setting.

a Press Menu. b Press a or b to choose

General Setup. Press OK.

c Press a or b to choose LCD Settings.

Press OK.

d Press a or b to choose Backlight.

Press OK.

e Press a or b to choose Light, Med or

Dark.

Press OK.

f Press Stop/Exit.

Speaker Volume 1

You can choose a range of speaker volume levels, from High to Off.

a Press Menu. b Press a or b to choose

General Setup. Press OK.

c Press a or b to choose Volume.

Press OK.

d Press a or b to choose Speaker.

Press OK.

e Press a or b to choose Low, Med, High

or Off. Press OK.

f Press Stop/Exit.

LCD Language 1

You can change the LCD Language.

a Press Menu. b Press a or b to choose

Initial Setup. Press OK.

c Press a or b to choose

Local Language. Press OK.

d Press a or b to choose

English or Chinese. Press OK.

Press

Stop/Exit

Setting the Fax Logic

Note

General information

(sending and receiving sequence)

You can change the process of manual fax send or receive. If you often send or receive a fax manually to/from the other party at the end of a conversation, set the Fax Mode to Easy Mode.

You can send or receive a fax manually just simply press Start. If you are a caller, press Start to send a fax. If you are a receiver, press Start to receive a fax.

If you set to Advanced Mode: No matter you are a caller or receiver, you can choose you will send or receive a fax manually. When you press Start, the

machine will ask you:

Send/Receive?

If you want to send a fax, press Send. If you want to receive a fax, press Receive.

Even if you set either Easy Mode or Advanced Mode and if there is a document in the ADF, the document in the

ADF will be sent by pressing Start.

a Press Menu. b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Miscellaneous. Press OK.

d Press a or b to choose Fax Mode.

Press OK.

e Press a or b to choose Easy Mode or

Advanced Mode.

Press OK.

f Press Stop/Exit.

Note

Loading paper 2

Loading paper and other print media

Load only one size of paper and one type of paper in the paper tray at any one time.

a Pull the paper tray completely out of the

machine.

If the paper support flap (1) is open, close it, and then close the paper support (2).

b Lift the output paper tray cover (1).

c With both hands, gently press and slide

the paper side guides (1) and then the paper length guide (2) to fit the paper size. Make sure that the triangular marks (3) on the paper side guides (1) and paper length guide (2) line up with the marks for the paper size you are using.

Loading paper

Note

IMPORTANT

Note

d Fan the stack of paper well to avoid

paper jams and misfeeds.

Always make sure that the paper is not curled or wrinkled.

e Gently put the paper into the paper tray

print side down and top edge in first. Check that the paper is flat in the tray.

Be careful not to push the paper in too far; it may lift at the back of the tray and cause paper feed problems.

When there are only a few sheets of paper left in the paper tray, the machine may start to misfeed. Load at least 10 sheets of paper into the paper tray.

Chapter 2

f Gently adjust the paper side guides (1)

to fit the paper using both hands. Make sure the paper side guides touch the sides of the paper.

g Close the output paper tray cover.

i While holding the paper tray in place,

pull out the paper support (1) until it clicks, and then unfold the paper support flap (2).

h Slowly push the paper tray completely

into the machine.

Loading paper

IMPORTANT

Loading envelopes and postcards 2

About envelopes 2

 Use envelopes that weigh between 80 to

95 g/m

 Some envelopes need margin settings to

be set in the application. Make sure you do a test print first before printing many envelopes.

DO NOT use any of the following types of envelopes, as they will cause paper feed problems:

• That are of a baggy construction.

• That have windows.

Loading envelopes and postcards 2

a Before loading, press the corners and

sides of envelopes or postcards to make them as flat as possible.

If envelopes or postcards are “doublefeeding”, put one envelope or postcard in the paper tray at a time.

• That are embossed (have raised writing on them).

• That have clasps or staples.

• That are pre-printed on the inside.

Glue Double flaps

Occasionally you may experience paper feed problems caused by the thickness, size and flap shape of the envelopes you are using.

Chapter 2

b Put envelopes or postcards in the paper

tray with the address side down and the leading edge (top of the envelopes) in first as shown in the illustration. Using both hands, gently press and slide the paper side guides (1) and paper length guide (2) to fit the size of the envelopes or postcards.

If you have problems printing on envelopes with the flap on the short edge, try the following:

a Open the envelope flap. b Put the envelope into the paper tray with

the address side down and the flap positioned as shown in the illustration.

c Select Reverse Print in the printer

driver’s dialog box and then adjust the size and margin in your application.

Software User’s Guide: Printing

(Windows

uuSoftware User’s Guide: Printing and Faxing (Macintosh)

)

Loading paper

Note

Printable area 2

The printable area depends on the settings in the application you are using. The figures below show the unprintable areas on cut sheet paper and envelopes. The machine can print in the shaded areas of cut sheet paper when the Borderless print feature is available and turned on.

uuSoftware User’s Guide: Printing (Windows uuSoftware User’s Guide: Printing and Faxing (Macintosh)

Cut Sheet Paper Envelopes

)

Top (1) Bottom (2) Left (3) Right (4)

Cut Sheet 3mm 3mm 3mm 3mm

Envelopes 22mm 22mm 3mm 3mm

The Borderless feature is not available for envelopes.

Chapter 2

Note

Paper settings

Paper Type 2

To get the best print quality, set the machine for the type of paper you are using.

Press Menu.

a b Press a or b to choose

General Setup. Press OK.

c Press a or b to choose Paper Type.

Press OK.

d Press a or b to choose Plain Paper,

Inkjet Paper, Brother BP71, Brother BP61, Other Glossy or Transparency.

Press OK.

Paper Size 2

You can use four sizes of paper for printing copies: A4, A5, Letter and 10  15 cm and

two sizes for printing faxes: A4 and Letter. When you change the size of paper you load in the machine, you will need to change the paper size setting at the same time so your machine can fit an incoming fax on the page.

a Press Menu. b Press a or b to choose

General Setup. Press OK.

c Press a or b to choose Paper Size.

Press OK.

d Press a or b to choose A4, A5, 10x15cm

or Letter. Press OK.

e Press Stop/Exit.

The machine ejects the paper with the printed surfaces face up, onto the paper tray at the front of the machine. When you use transparencies or glossy paper, remove each sheet at once to prevent smudging or paper jams.

e Press Stop/Exit.

Loading paper

Acceptable paper and other print media

The print quality can be affected by the type of paper you use in the machine.

To get the best print quality for the settings you have chosen, always set the Paper Type to match the type of paper that is loaded in the tray.

You can use plain paper, inkjet paper (coated paper), glossy paper, transparencies and envelopes.

We recommend testing various paper types before buying large quantities.

For best results, use Brother paper.

 When you print on inkjet paper (coated

paper), transparencies and glossy paper, be sure to choose the correct print media in the “Basic” tab of the printer driver or in the Paper Type setting of the menu. (See Paper Type uu page 18.)

Recommended print media 2

To get the best print quality, we suggest using Brother paper. (See the table below.)

If Brother paper is not available in your country, we recommend testing various papers before purchasing large quantities.

We recommend using “3M Transparency Film” when you print on transparencies.

Brother paper

Paper Type Item

A4 Plain BP60PA

A4 Glossy Photo BP71GA4

A4 Inkjet (Matte) BP60MA

10  15 cm Glossy Photo

BP71GP

 When you print on Brother Photo paper,

load one extra sheet of the same photo paper in the paper tray. An extra sheet has been included in the paper package for this purpose.

 When printing on to transparencies, load

one extra sheet in the paper tray.

 When you use transparencies or photo

paper, remove each sheet at once to prevent smudging or paper jams.

 Avoid touching the printed surface of the

paper immediately after printing; the surface may not be completely dry and may stain your fingers.

Chapter 2

IMPORTANT

Handling and using print media 2

 Store paper in its original packaging and

keep it sealed. Keep the paper flat and away from moisture, direct sunlight and heat.

 Avoid touching the shiny (coated) side of

photo paper. Load photo paper with the shiny side facing down.

 Avoid touching either side of

transparencies because they absorb water and perspiration easily, and this may cause decreased output quality. Transparencies designed for laser printers/copiers may stain your next document. Use only transparencies recommended for inkjet printing.

Paper capacity of the output paper tray cover

Up to 50 sheets of 80 g/m2 A4 paper.

 Transparencies and photo paper must be

picked up from the output paper tray cover one page at a time to avoid smudging.

DO NOT use the following kinds of paper:

• Damaged, curled, wrinkled, or irregularly shaped paper

1 2 mm or greater curl may cause jams

to occur.

• Extremely shiny or highly textured paper

• Paper that cannot be arranged uniformly when stacked

• Short grain paper

Loading paper

Choosing the right print media 2

Paper type and size for each operation 2

Paper Type Paper Size Usage

Fax Copy Printer

Cut Sheet A4 210  297 mm (8.3  11.7 in.) Yes Yes Yes

Letter 215.9  279.4 mm (8 1/2  11 in.) Yes Yes Yes

Executive 184  267 mm (7 1/4  10 1/2 in.) – – Yes

JIS B5 182  257 mm (7.2  10.1 in.) – – User

Defined

A5 148  210 mm (5.8  8.3 in.) – Yes Yes

A6 105  148 mm (4.1  5.8 in.) – – Yes

Cards 10  15 cm (4  6 in.) – Yes Yes

13  18 cm (5  7 in.) – – Yes

127  203 mm (5  8 in.) – – Yes

Postcard 1 100  148 mm (3.9  5.8 in.) – – User

Defined

Postcard 2 (Double)

Envelopes C5 Envelope 162  229 mm (6.4  9 in.) – – Yes

DL Envelope 110  220 mm (4.3  8.7 in.) – – Yes

COM-10 105  241 mm (4 1/8  9 1/2 in.) – – Yes

Monarch 98  191 mm (3 7/8  7 1/2 in.) – – Yes

Y4 Envelope 105  235 mm (4.1  9.3 in.) – – User

Transparencies A4 210  297 mm (8.3  11.7 in.) – Yes Yes

Letter 215.9  279.4 mm (8 1/2  11 in.) – Yes Yes

A5 148  210 mm (5.8 

148  200 mm (5.8  7.9 in.) – – User

Defined

8.3 in.) – Yes Yes

Chapter 2

Paper weight, thickness and capacity 2

Paper Type Weight Thickness No. of

sheets

Cut Sheet Plain Paper

64 to 120 g/m

0.08 to 0.15 mm

100

Inkjet Paper

Glossy Paper

Cards Photo Card

Index Card

Postcard

Envelopes

64 to 200 g/m

Up to 220 g/m

Up to 120 g/m

Up to 200 g/m

75 to 95 g/m

0.08 to 0.25 mm 20

Up to 0.25 mm

Up to 0.15 mm 30

Up to 0.25 mm 30

Up to 0.52 mm 10

Transparencies – – 10

Up to 100 sheets of 80 g/m2paper.

BP71 (260 g/m2) paper is especially designed for Brother inkjet machines.

IMPORTANT

Loading documents 3

How to load documents

You can send a fax, make copies, and scan from the ADF (automatic document feeder) and from the scanner glass.

Using the ADF 3

The ADF can hold up to 15 pages1 and feeds

each sheet individually. Use 90 g/m and always fan the edges of the pages before placing them in the ADF.

The ADF can hold up to 20 pages, if you stagger the pages and meet the following conditions: Temperature: 20 - 26 C Humidity: 40 - 50% without condensation

Paper: XEROX4200 75 g/m

Document Sizes and Weights 3

Length: 148 to 355.6 mm

Width: 148 to 215.9 mm

Weight:

64 to 90 g/m

paper

a Unfold the ADF Document Support (1)

and the ADF Document Support

Flap (2).

b Fan the pages well. c Adjust the paper guides (1) to fit the

width of your documents. Stagger the pages of the documents and place them face down, top edge first in the ADF underneath the guides until you feel them touch the feed rollers. The screen will display ADF Ready.

How to load documents 3

• DO NOT pull on the document while it is feeding.

• DO NOT use paper that is curled, wrinkled, folded, ripped, stapled, paper clipped, pasted or taped.

• DO NOT use cardboard, newspaper or fabric with the ADF. Instead use the scanner glass.

Make sure documents written with ink or modified with correction fluid are completely dry.

Chapter 3

IMPORTANT

Note

DO NOT leave thick documents on the scanner glass. If you do this, the ADF may jam.

d After using the ADF, close the ADF

Document Support Flap and push the upper-left portion of the ADF Document Support to close it completely.

How to load documents 3

To use the scanner glass, the ADF must be empty.

a Lift the document cover. b Using the document guidelines on the

left and top, place the document face down in the upper left corner of the scanner glass.

Using the scanner glass 3

You can use the scanner glass to fax, copy or scan pages of a book or one page at a time.

Document Sizes Supported 3

Length: Up to 297 mm

Width: Up to 215.9 mm

Weight: Up to 2 kg

c Close the document cover.

IMPORTANT

If you are scanning a book or thick

document, DO NOT slam the cover down or press on it.

Loading documents

Unscannable area 3

The scannable area depends on the settings in the application you are using. The figures below show unscannable areas.

Usage

Fax A4 3 mm

Document Size

Top (1)

Bottom (2)

Left (3)

Right (4)

3mm

Letter 4 mm

Legal

Copy All paper

Scan

The unscannable area is 1 mm when you use the ADF.

sizes

3mm

Note

Sending a fax 4

How to send a fax 4

The following steps show how to send a fax.

a When you want to send a fax or change

the settings for sending or receiving

faxes, press the (FAX).

 The LCD shows:

c You can change the following fax

sending settings. Press a or b to scroll through the fax settings. When the setting you want is displayed, press OK and choose your option.

(Basic User's Guide)

For details about changing the following fax sending settings, see pages 27 to

28.

 Glass ScanSize

 Color Fax Transmission

(Advanced User's Guide)

For more advanced fax sending operations and settings

uuAdvanced User’s Guide: Sending a fax

 Choosing multiple settings

 Contrast

b Do one of the following to load your

document:

 Place the document face down in the

ADF. (See Using the ADF uu page 23.)

 Load your document face down on

the scanner glass. (See Using the scanner glass uu page 24.)

• To send color faxes with multiple pages use the ADF.

• If you send a mono fax from the ADF when the memory is full, it will be sent in real time.

• You can use the scanner glass to fax pages of a book one at a time. The documents can be up to A4 or Letter size.

• Since you can only scan one page at a time, it is easier to use the ADF if you are sending a multiple-page document.

 Fax Resolution

 Set New Defaults

 Factory Reset

 Dual Access

 Faxing at End of Call

 Broadcasting

 Real Time Transmission

 Overseas Mode

 Cancelling Waiting Jobs

d Enter the fax number.

Using the dial pad

Using Speed Dial

 Speed Dial

Using call history

 Outgoing Call

 Caller ID hist.

Sending a fax

Note

e Press Mono Start or Color Start.

Faxing from the ADF 4

 The machine starts scanning the

document to be sent.

Faxing from the scanner glass 4

 If you pressed Mono Start, the

machine starts scanning the first page. Go to step f.

 If you pressed Color Start, the LCD

asks if you want to send a color fax. Press 1 to choose Yes(Send) to confirm. The machine starts scanning and sending the document.

f When the LCD asks you Next Page?,

do one of the following:

 To send a single page, press 2 to

choose No(Send) (or press Mono Start again).

The machine starts sending the document.

Stop faxing 4

To stop faxing, press Stop/Exit.

Setting scanner glass size for faxing 4

When documents are Letter size, you need to set Scan Size to Letter. If you do not, the side portion of the faxes will be missing.

a Press (FAX).

b Press a or b to choose

Advanced Settings. Press OK.

c Press a or b to choose

Glass ScanSize. Press OK.

d Press a or b to choose A4 or Letter.

Press OK.

 To send more than one page, press

1 to choose Yes and go to step g.

g Place the next page on the scanner

glass. Press OK. The machine starts scanning the page. (Repeat steps f and g for each additional page.)

h After all the pages have been scanned,

press 2 or Mono Start to start.

• You can save the setting you use most often by setting it as the default. (uuAdvanced User’s Guide: Setting your changes as a new default)

• This setting is only available for sending documents from the scanner glass.

Color fax transmission 4

Your machine can send a color fax to machines that support this feature.

Color faxes cannot be stored in the memory. When you send a color fax, the machine will send it in real time (even if Real Time TX is set to Off).

Cancelling a fax in progress 4

If you want to cancel a fax while the machine is scanning, dialling or sending, press

Stop/Exit.

Chapter 4

Note

Transmission Verification Report 4

You can use the Transmission Verification Report as proof that you sent a fax. This report lists the sender’s name or fax number, the time and date of transmission, duration of transmission, number of pages sent, and whether or not the transmission was successful.

There are several settings available for the Transmission Verification Report:

 On: Prints a report after every fax you

send.

 On+Image: Prints a report after every fax

you send. A portion of the fax’s first page appears on the report.

 Off: Prints a report if your fax is

unsuccessful due to a transmission error. Off is the default setting.

• If you choose On+Image or Off+Image the image will only appear on the Transmission Verification Report if Real Time Transmission is set to Off. (uuAdvanced User’s Guide: Real Time Transmission)

• If your transmission is successful, "OK" will appear next to "RESULT" on the Transmission Verification Report. If the transmission is not successful, "ERROR" will appear next to "RESULT".

 Off+Image: Prints a report if your fax is

unsuccessful due to a transmission error. A portion of the fax’s first page appears on the report.

a Press Menu. b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Report Setting. Press OK.

d Press a or b to choose Transmission.

Press OK.

e Press a or b to choose On, On+Image,

Off or Off+Image.

Press OK.

f Press Stop/Exit.

Receiving a fax 5

Receive Modes 5

By factory default, the factory setting of Receive Mode is “Fax”. Your machine will automatically receive any faxes that are sent to it. There are four receive modes of this machine as below.

For more detailed information on the receive modes, see Using Receive Modes uu page 30.

Operation Display LCD Display Factory Default Ring Delay

Fax Auto Fax Ring Delay: 2 times

Fax detection: On

Fax/Tel F/T Ring Delay: 2 times

Time: 30 seconds

Fax Manual Mnl

External TAD TAD

To set a receive mode follow the instructions below:

a Press Menu. b Press a or b to choose Initial Setup.

Press OK.

c Press a or b to choose Receive Mode.

Press OK.

d Press a or b to choose Fax Auto, Fax/Tel, External TAD or Fax Manual.

Press OK.

e Press Stop/Exit.

The LCD will display the current Receive Mode.

Chapter 5

Using Receive Modes

Mode Function Help

Fax (Fax Auto) Each call

recognized as fax and send fax signal. However, you can answer the call within the number of rings.

F/T (Fax/Tel) Automatically

determine whether the incoming call is telephone or fax calls.

Non-Fax call will make a fast double-ring to inform you answer the phone.

Mnl (Fax Manual)

Machine doesn’t recognize each call, only as a common phone call that you need to determine after answering the phone.

TAD (External TAD)

The external answering machine (TAD) automactically answers every call. Voice messages are stored on the external TAD. Fax messages are printed.

Factory setting of Ring Delay is 2 (0-10 times available, please see Ring Delay uu page 31). After ringing 2 times, the fax machine send fax-receiving signals automatically;

Tip: If your machine is connecting an external answering phone device, and often use it to answer incoming calls, you could set the ring time through 4 to 6 times.

Within the recommended ringing times, you can use the external answering phone device to answer and talk.

Factory setting of Ring Delay is 2 (0-10 times available, please see Ring Delay uu page 31. Factory setting of F/T ring time (a fast double-ring) is 30 seconds (20, 30, 40, 70 seconds available, please see F/T Ring Time (Fax/Tel mode only) uu page 31).

According to incoming call after the fax machine rings 2 times:

1) For the fax call, send fax received signal;

2) For the telephone call, make a fast double-ring, waiting for you answer the phone.

Tip: If your machine is connecting an external answering phone device, you could set the ringing time through 4 to 6 times to answer the call.

Answering the call, or if the caller wants to send you a fax, press Mono Start or Color Start button (under easy mode) to receive faxes.

Tip: If your machine is connecting an external answering phone device, you can use the external answering phone device to answer and talk.

Use this mode if you have connected an external answering machine to your machine. The TAD setting works only with an external answering machine.

Note: Ring Delay and F/T Ring Time do not work in this setting.

If the caller wants to send a fax during a call or the caller sends you a fax call, please press Mono Start or Color Start button (under easy mode) on the control panel of the machine or press l 51 keys on the external answering phone device (you have to turn on the remote codes first, please see Using remote codes uu page 38) to give fax receiving

signals.

Receiving a fax

Note

Receive Mode settings

Ring Delay 5

The Ring Delay sets the number of times the machine rings before it answers in Fax Auto or Fax/Tel mode. If you have external or extension telephones on the same line as the machine choose the maximum number of rings.

(See Operation from external and extension

telephones uu page 38 and Fax Detect uu page 32.)

a Press Menu. b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Setup Receive. Press OK.

F/T Ring Time (Fax/Tel mode only) 5

When somebody calls your machine, you and your caller will hear the normal telephone ring. The number of rings is set by the Ring Delay setting.

If the call is a fax, then your machine will receive it; however, if it is a voice call the machine will sound the F/T Ring (a fast double-ring) for the time you have set in the F/T Ring Time setting. If you hear the F/T Ring it means that you have a voice caller on the line.

Because the F/T Ring is made by the machine, extension and external telephones will not ring; however, you can still answer the call on any telephone by using a remote code. (For more information see Using remote codes uu page 38.)

a Press Menu.

d Press a or b to choose Ring Delay.

Press OK.

e Press a or b to choose how many times

you want the machine to ring before it answers. Press OK. If you choose 0, the machine will answer immediately and the line will not ring at all.

f Press Stop/Exit.

b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Setup Receive. Press OK.

d Press a or b to choose

F/T Ring Time. Press OK.

Press aorb to choose how long the machine will ring to alert you that you have a voice call (20, 30, 40 or 70 seconds). Press OK.

f Press Stop/Exit.

Even if the caller hangs up during the fast double-ring, the machine will continue to ring for the set time.

Chapter 5

Note

Fax Detect 5

If Fax Detect is On: 5

Fax Detect is turned On as default.

The machine receives a fax call automatically, even if you answer the call. When you see Receiving on the LCD or when you hear “chirps” through the handset you are using, just replace the handset. Your machine will do the rest.

If Fax Detect is Off: 5

If you are at the machine and answer a fax call by lifting the handset, press Mono Start or Color Start, then press 2 to receive the fax.

If you answered at an extension or external telephone, press l 51. (See Operation from external and extension telephones uu page 38.)

• If this feature is set to On, but your machine does not connect a fax call when you lift an extension or external telephone handset, press the remote activation code l 51.

• If you send faxes from a computer on the same telephone line and the machine intercepts them, set Fax Detect to Off.

a Press Menu. b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Setup Receive. Press OK.

d Press a or b to choose Fax Detect.

Press OK.

e Press a or b to choose On (or Off).

Press OK.

f Press Stop/Exit.

Telephone and external devices 6

Voice operations 6

Tone or pulse 6

If you have a Pulse dialling service, but need to send tone signals (for example, for telephone banking), follow the instructions below:

a Press Hook. b Press # on the machine’s control panel.

Any digits dialled after this will send tone signals.

When you are finished with the call, the machine will return to the Pulse dialling service.

Fax/Tel mode 6

When the machine is in Fax/Tel mode, it will use the F/T Ring (fast double-ring) to alert you to pick up a voice call.

If you are at an external telephone, lift the handset of the external telephone, and then press Hook to answer.

If you are at an extension telephone, you'll need to lift the handset during the F/T Ring

Time and then press #51 between the fast double-rings. If no one is on the line, or if someone wants to send you a fax, send the call back to the machine by pressing l 51.

Phone line services 6

Your machine supports the Caller ID subscriber telephone service that some telephone companies offer.

Features like Voice Mail, Call Waiting, Call Waiting/Caller ID, RingMaster, answering services, alarm systems or other custom features on one phone line may create problems with the operation of your machine.

Do you have Voice Mail? 6

If you have Voice Mail on the phone line that you will install your new machine on, there is

a strong possibility that Voice Mail and the machine will conflict with each other while receiving incoming calls. However, the

Distinctive Ring feature allows you to use more than one number on your line, so both Voice Mail and the machine can work together without any problems. If each one

has a separate phone number, neither will interfere with the other’s operations.

If you decide to get the Distinctive Ring service from the telephone company, you will need to follow the directions on next page to ‘register’ the new Distinctive Ring pattern they give you. This is so your machine can recognise its incoming calls.

Chapter 6

Note

Telephone Service

The caller ID feature of this machine lets you use the caller ID subscriber service offered by certain telephone companies.

Caller ID (Caller IDentification) (not available in certain area)

The Caller ID is a telephone service that allows the subscriber to see a display of the caller's phone number as the telephone rings. It is a fast way to screen your calls. You can respond quickly to calls you missed, because caller IDs are received and stored in your fax machine memory. Besides the standard Caller ID feature, you can also select a single caller's phone number and call back.

 To get the Caller ID service, you have

to apply for it at your local telephone company.

 FSK and DTMF are the two modes for

displaying your calls. Please ask your local telephone

company for whether your mode is FSK or DTMF. If your local telephone company uses DTMF mode, please switch your mode as follows. Contact your local telephone company or Brother dealer in the case that the feature does not work normally. Caller ID feature is not available in the following situation:

1 You have not applied for it at your local

telephone company.

2 The fax machine is connected to an

internal switchboard or other switch device.

3 Due to the switchboard problems or

line problems of local telephone companies, the feature may not work in some areas.

Telephone and external devices

Note

Advantages of Caller ID 6

For Business 6

All businesses profit from a quicker response to customer calls.

For Home 6

Residential customers can protect themselves from unwanted calls.

Setup Method 6

a Press Menu. b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Miscellaneous. Press OK.

Caller ID feature 6

The Caller ID feature of this machine lets you use the Caller ID subscriber service offered by many local phone companies.

You can view the list or choose one of these numbers to fax to, add to Speed Dial or delete from the history. (See Caller ID history uu page 42.)

After a few rings, the screen displays the telephone number of your caller (or name, if available). Once you answer the call, the Caller ID information disappears from the screen, but the call information remains stored in the Caller ID memory.

 ID Unknown display means call

originates outside your Caller ID service area.

 ID Withheld display means the caller

has intentionally blocked transmission of information.

d Press a or b to choose

Caller ID Type. Press OK.

e Press a or b to choose Auto, FSK or

DTMF.

Press OK.

f Press Stop/Exit.

You can print a list of the Caller ID information

received by your machine. (u User's Guide: How to print a report)

You can print a list of Caller ID information received by your machine.

Caller ID service varies with different carriers. Call your local phone company to determine the kind of service available in your area.

Advanced

Chapter 6

Note

IMPORTANT

Connecting an external TAD (telephone answering device)

You may choose to connect an external answering device. However, when you have an external TAD on the same telephone line as the machine, the TAD answers all calls and the machine “listens” for fax calling (CNG) tones. If it hears them, the machine takes over the call and receives the fax. If it does not hear CNG tones, the machine lets the TAD continue playing your outgoing message so your caller can leave you a voice message.

The TAD must answer within two rings (the recommended setting is two rings). The machine cannot hear CNG tones until the TAD has answered the call, and with four rings there are only 8 to 10 seconds of CNG tones left for the fax “handshake”. Make sure you carefully follow the instructions in this guide for recording your outgoing message. We do not recommend using the toll saver feature on your external answering machine if it exceeds five rings.

LINE

EXT.

1TAD

When the TAD answers a call, the LCD shows Telephone.

DO NOT connect a TAD elsewhere on the same telephone line.

EXT.

LINE

Connections settings 6

If you do not receive all your faxes, shorten the Ring Delay setting on your external TAD.

The external TAD must be connected as shown in the previous illustration.

a Set your external TAD to one or two

rings. (The machine's Ring Delay setting does not apply.)

b Record the outgoing message on your

external TAD.

c Set the TAD to answer calls. d Set the Receive Mode to

External TAD. (See Receive Modes

uu page 29.)

Telephone and external devices

Note

EXT.

LINE

EXT.

LINE

Recording an outgoing message (OGM) on an external TAD 6

Timing is important in recording this message.

Record 5 seconds of silence at the

beginning of your message. (This allows your machine time to listen for the fax CNG tones of automatic transmissions before they stop.)

b Limit your speaking to 20 seconds.

We recommend beginning your OGM with an initial 5-second silence because the machine cannot hear fax tones over a resonant or loud voice. You may try omitting this pause, but if your machine has trouble receiving, then you must re-record the OGM to include it.

External and extension telephones

Connecting an external or extension telephone 6

You can connect a separate telephone to your machine as shown in the diagram below.

Multi-line connections (PABX)6

Most offices use a central telephone system.

Brother recommends that all our machines be connected to a discreet (dedicated) line. Although a particular PABX may appear to work with a particular model of fax machine, we cannot guarantee that the unit will operate correctly.

While it is often relatively simple to connect a fax machine to a PABX, (Private Automatic Branch Exchange), we suggest that you contact the company that installed your telephone system and ask them to connect the fax machine for you.

Brother does not recommend the use of a PABX line. PABX limitations in general can cause some functions of the fax machine not to work correctly.

1 Extension telephone

2 External telephone

When you are using a telephone on the same phone line, the LCD shows Telephone.

Chapter 6

Note

Operation from external and extension telephones 6

If you answer a fax call on an extension or an external telephone, you can make your machine take the call by using the Remote Activation Code. When you press the Remote Activation Code l 51, the machine starts to receive the fax.

If the machine answers a voice call and fast double-rings for you to take over, use the Remote Deactivation Code #51 to take the call at an extension telephone. (See F/T Ring Time (Fax/Tel mode only) uu page 31.)

If you answer a call and no one is on the line:

You should assume that you're receiving a manual fax.

Press l 51 and wait for the chirp or until the LCD shows Receiving, and then hang up.

You can also use the Fax Detect feature to make your machine automatically take the call. (See Fax Detect uu page 32.)

Using a cordless external telephone 6

Using remote codes 6

Remote Activation Code 6

If you answer a fax call on an extension or external telephone, you can tell your machine to receive it by dialling the Remote Activation Code l 51. Wait for the chirping sounds then replace the handset. (See Fax Detect uu page 32.)

If you answer a fax call at the external telephone, you can make the machine receive the fax by pressing Mono Start and 2 to choose Receive when you select the

Fax Mode to Advanced Mode. (See Setting the Fax Logic (sending and receiving

sequence) uu page 11.)

Remote Deactivation Code 6

If you receive a voice call and the machine is in Fax/Tel mode, it will start to sound the F/T Ring (fast double-ring), after the initial Ring Delay. If you pick up the call on an extension telephone you can turn the F/T Ring off by pressing #51 (make sure you press this between the rings).

If the machine answers a voice call and fast double-rings for you to take over, you can take the call at the external telephone by pressing Hook.

Once the base unit of the cordless telephone has been connected to the same telephone line as the machine (see External and extension telephones uu page 37), it is easier to answer calls during the Ring Delay if you carry the cordless handset around with you.

If you let the machine answer first, you will have to go to the machine and press Hook to send the call to the cordless handset.

Changing the remote codes 6

Note

If you want to use Remote Activation, you have to turn on the remote codes. The preset Remote Activation Code is l 51. The preset Remote Deactivation Code is #51. If you want to, you can replace them with your own codes.

a Press Menu. b Press a or b to choose Fax.

Press OK.

c Press a or b to choose

Setup Receive. Press OK.

Telephone and external devices

d Press a or b to choose Remote Codes.

Press OK.

e Press a or b to choose On (or Off).

Press OK.

f Enter the new Remote Activation Code.

Press OK.

g Enter the new Remote Deactivation

Code. Press OK.

h Press Stop/Exit.

• If you are always disconnected when accessing your external TAD remotely, try changing the Remote Activation Code and Remote Deactivation Code to another three-digit code using the numbers 0-9, l,

• Remote Codes might not work with some telephone systems.

Note

Dialling and storing numbers 7

How to dial 7

Manual dialling 7

Press all of the digits of the fax or telephone number.

If the LCD shows Not Registered when you enter or search a Speed Dial number that has not been stored at this location.

d Press a or b to choose the number you

want to dial. Press OK.

e Press OK to choose Send a fax.

Search 7

You can search for names you have stored in the Speed Dial memory.

Speed Dialling 7

a Press (Speed Dial).

You can also choose Speed Dial by

pressing (FAX).

b Press a or b to choose Search.

Press OK.

c Do one of the following:

 Press a or b to choose

Alphabetical Order or Numerical Order.

Press OK.

Press (Speed Dial).

You can also choose Speed Dial by

pressing (FAX).

b Press a or b to choose Search.

Press OK.

c Press a or b to choose

Alphabetical Order or Numerical Order.

Press OK.

d If you chose Alphabetical Order in

step c, use the dial pad to enter the first letter of the name, and then press a or b to choose the name and number you want to call. Press OK.

 Press the 2-digit Speed Dial number

using the dial pad. (See Storing Speed Dial numbers uu page 43.)

Dialling and storing numbers

Note

Fax Redial 7

If you are sending a fax manually and the line is busy, press Hook, Redial/Pause, and then press Mono Start or Color Start to try again.

Redial/Pause only works if you dialled from the control panel. If you are sending a fax automatically and the line is busy, the machine will automatically redial up to three times at five minute intervals.

a Press Redial/Pause. b Press a or b to choose the number you

want to redial. Press OK.

c Press a or b to choose Send a fax.

Press OK.

d Press Mono Start or Color Start.

Additional Dialling Operations

Outgoing Call history 7

The last 30 numbers you sent a fax to will be stored in the outgoing call history. You can choose one of these numbers to fax to, add to Speed Dial, or delete from the history.

a Press Redial/Pause.

You can also choose Outgoing Call

by pressing (FAX).

b Press a or b to choose the number you

want. Press OK.

c Do one of the following:

In Real Time Transmission the automatic redial feature does not work when using the scanner glass.

 To send a fax, press a or b to choose

Send a fax.

Press OK.

Press Mono Start or Color Start.

 If you want to store the number,

press a or b to choose Add to Speed Dial.

Press OK.

(uuAdvanced User’s Guide: Storing

Speed Dial numbers from Outgoing Calls)

 If you want to delete the number from

the Outgoing Call history list, press a or b to choose Delete.

Press OK.

Press 1 to confirm.

d Press Stop/Exit.

Chapter 7

Note

Caller ID history 7

This feature requires the Caller ID subscriber service offered by many local telephone companies. (See Caller ID (Caller IDentification) (not available in certain area) uu page 34.)

The numbers, or names if available, from the last 30 faxes and telephone calls you received will be stored in the Caller ID history. You can view the list or choose one of these numbers to fax to, add to Speed Dial, or delete from the history. When the thirty-first call comes into the machine, it replaces information about the first call.

If you are not a Caller ID subscriber, you can still view call dates from the Caller ID history, and delete entries from the list.

Press 1 to confirm.

d Press Stop/Exit.

You can print the Caller ID list. (uuAdvanced User’s Guide: How to print a report)

a Press Redial/Pause and press l.

You can also choose Caller ID hist. by pressing

(FAX).

b Press a or b to choose the number you

want. Press OK.

c Do one of the following:

 To send a fax, press a or b to choose

Send a fax.

Press OK.

Press Mono Start or Color Start.

 If you want to store the number,

press a or b to choose Add to Speed Dial.

Press OK.

(uuAdvanced User’s Guide: Storing

Speed Dial numbers from the Caller ID history)

 If you want to delete the number from

the Caller ID history list, press a or b to choose Delete.

Press OK.

Dialling and storing numbers

Note

Storing numbers

You can set up your machine to do the following types of easy dialling: Speed Dial and Groups for broadcasting faxes. When you dial a Quick Dial number, the LCD shows the number.

If you lose electrical power, the Quick Dial numbers that are in the memory will not be lost.

Storing a pause 7

Press Redial/Pause to put a 3.5 second pause between numbers. If you are dialling overseas, you can press Redial/Pause as many times as needed to increase the length of the pause.

Storing Speed Dial numbers 7

d Do one of the following:

 Enter the name (up to 16 characters)

using the dial pad.

Press OK.

(To help you enter letters, see Entering Text uu page 91.)

 To store the number without a name,

press OK.

e Enter the fax or telephone number (up to

20 digits). Press OK.

f Press a or b to choose Complete.

Press OK.

g Do one of the following:

 To store another Speed Dial

number, go to step c.

 If you are finished storing numbers,

press Stop/Exit.

You can store up to 40 2-digit different Speed Dial numbers with a name, and each name has one number. When you dial you will only have to press a few keys (for example:

(Speed Dial), Search, OK, the two-digit

number, and Mono Start or Color Start).

a Press (Speed Dial).

b Press a or b to choose

Set Speed Dial. Press OK.

c Press a or b to choose the 2-digit

Speed Dial location where you want to store the number in. Press OK.

Changing Speed Dial names or numbers 7

You can change a Speed Dial name or number that has already been stored.

a Press (Speed Dial).

b Press a or b to choose

Set Speed Dial. Press OK.

c Press a or b to choose the 2-digit

Speed Dial location you want to change. Press OK.

d Do one of the following:

 Press a or b to choose Change.

Press OK.

 Press a or b to choose Delete.

Press OK.

Press 1 to confirm. Go to step h.

Chapter 7

Note

How to change the stored name or number:

If you want to change a character, press d or c to position the cursor under the character you want to change, and then press Clear. Re-enter the character.

e If you want to change the name, press

a or b to choose Name, then press OK and enter the new name using the dial pad (up to 16 characters). Press OK. (See Entering Text uu page 91.)

f If you want to change the fax or

telephone number, press a or b to choose Fax/Tel:, then press OK and enter the new fax or telephone number using the dial pad (up to 20 digits). Press OK.

g Press a or b to choose Complete.

Press OK.

h Press Stop/Exit.

Note

Making copies 8

How to copy 8

The following steps show the basic copy operation.

a Make sure you are in copy mode, press

(COPY).

 The LCD shows:

c If you want more than one copy, enter

the number (up to 99).

d Press Mono Start or Color Start.

Stop copying 8

To stop copying, press Stop/Exit.

Copy settings

You can change the following copy settings. Press COPY and then press a or b to scroll through the copy settings. When the setting you want is highlighted, press OK.

(Basic User's Guide)

For details about changing the following copy settings uupage 46.

 Paper Type

1 No. of Copies

You can enter the number of copies you want by using the dial pad.

The default setting is FAX mode. You can change the amount of time that the machine stays in COPY mode after the last copy operation. (uuAdvanced User’s Guide: Mode Timer)

b Do one of the following to load your

document:

 Place the document face down in the

ADF.

(See Using the ADF uu page 23.)

 Place the document face down on

the scanner glass.

 Paper Size

(Advanced User’s Guide)

For details about changing the following copy settings uuAdvanced User’s Guide: Copy settings

 Quality

 Enlarge/Reduce

 Page Layout

 2in1(ID)

 Stack/Sort

 Density

 Set New Default

 Factory Reset

If you want to sort copies, use the ADF.

(See Using the scanner glass uu page 24.)

Chapter 8

Paper Options 8

Paper Type 8

If you are copying on a special type of paper, set the machine for the type of paper you are using to get the best print quality.

a Press (COPY).

b Load your document. c Enter the number of copies you want. d Press a or b to choose Paper Type.

Press OK.

e Press a or b to choose Plain Paper,

Inkjet Paper, Brother BP71, Brother BP61, Other Glossy or Transparency.

Press OK.

Paper Size 8

If you are copying on paper other than A4 size, you will need to change the Paper Size setting. You can copy only on A4, A5, Photo 10  15 cm or Letter paper.

a Press (COPY).

b Load your document. c Enter the number of copies you want. d Press a or b to choose Paper Size.

Press OK.

e Press a or b to choose A4, A5, 10x15cm

or Letter. Press OK.

f If you do not want to change additional

settings, press Mono Start or Color Start.

f If you do not want to change additional

settings, press Mono Start or Color Start.

How to print from a computer 9

Printing a document 9

The machine can receive data from your computer and print it. To print from a computer, you must install the printer driver.

uuSoftware User’s Guide: Printing

(Windows

uuSoftware User’s Guide: Printing and Faxing (Macintosh)

a Install the Brother printer driver from the

CD-ROM. (uuQuick Setup Guide)

b From your application, choose the Print

command.

)

c Choose the name of your machine in the

Print dialog box and click Preferences.

d Choose the settings you want to change

in the Properties dialog box.

 Media Type



Print Quality

 Paper Size

 Orientation

 Colour/Greyscale

 InkSaveMode

 Scaling

e Click OK. f Click Print to begin printing.

How to scan to a computer 10

Scanning a document 10

There are several ways to scan documents. You can use the SCAN key on the machine or the scanner drivers on your computer.

a To use the machine as a scanner, you

must install a scanner driver. If the machine is on a Network, configure it with a TCP/IP address.

 Install the MFL-Pro Suite (including

scanner drivers) on the Installation CD-ROM. (uuQuick Setup Guide.)

 Configure the machine with a TCP/IP

address if network scanning does not work.

uuSoftware User’s Guide:

Configuring Network Scanning for

Windows

uuSoftware User’s Guide:

Configuring network scanning for Macintosh

b Load your document. (See How to load

documents uu page 23.)

 Use the ADF to scan multiple pages

of documents. It feeds each sheet automatically.

 Use the scanner glass to scan a

page of a book or one sheet at a time.

Scanning using the SCAN key

For more information

uuSoftware User’s Guide: Using the Scan key

a Press (SCAN).

b Choose the scan mode you want.

 Scan to File

 Scan to E-mail

 Scan to OCR

 Scan to Image

 Web Service (Web Services

Scan)

(Macintosh users) Presto! PageManager must be downloaded and installed before use. See Accessing Brother Support (Macintosh) uu page 5 for further instructions.

(Windows® users only) (uuSoftware User’s Guide: Using Web

Services for scanning on your network

(Windows Vista

Windows

7))

c (For network users)

Choose the computer you want to send the data to.

SP2 or later and

c Do one of the following:

 To scan using the SCAN key, go to

Scanning using the SCAN key.

 To scan using a scanner driver at

your computer, go to Scanning using a scanner driver.

d Press Start to begin scanning.

How to scan to a computer

Scanning using a scanner driver

uuSoftware User’s Guide: Scanning a document using the TWAIN driver

(Windows

uuSoftware User’s Guide: Scanning a document using the WIA driver (Windows

uuSoftware User’s Guide: Scanning a document using the TWAIN driver

(Macintosh)

uuSoftware User’s Guide: Scanning a document using the ICA driver (Mac OS X

10.6.x)

a Start a scanning application and click

the Scan button.

b Adjust the settings such as Resolution,

Brightness and Scan Type in the Scanner Setup dialog box.

)

Scanning using the

ControlCenter

uuSoftware User’s Guide: ControlCenter4 (Windows

uuSoftware User’s Guide: ControlCenter2 (Macintosh)

)

c Click Start or Scan to begin scanning.

Note

CAUTION

IMPORTANT

Routine maintenance A

Replacing the ink cartridges

Your machine is equipped with an ink dot counter. The ink dot counter automatically monitors the level of ink in each of the four cartridges. When the machine detects an ink cartridge is running out of ink, the machine will display a message on the LCD.

For example, when one of the ink cartridges is nearly empty, the LCD will display Ink low (name of color).

You should purchase a replacement cartridge in preparation for when the machine indicates the color is completely empty.

When one of the ink cartridges is empty, the LCD will display Cannot Print or B&W Print Only.

You should only replace the actual ink cartridge when this message Cannot Print or B&W Print Only appears on the LCD.

Brother multifunction machines are designed to work with ink of a particular specification and will work to a level of optimum performance and reliability when used with Brother Original ink cartridges. Brother cannot guarantee this optimum performance and reliability if ink or ink cartridges of other specifications are used. Brother does not therefore recommend the use of cartridges other than Brother Original cartridges or the refilling of used cartridges with ink from other sources. If damage is caused to the print head or other parts of this machine as a result of using incompatible products with this machine, any repairs required as a result may not be covered by the warranty.

a Open the ink cartridge cover.

If one or more of the ink cartridges have reached the end of their life, the LCD shows B&W Print Only or Cannot Print.

The LCD will show which ink cartridge is low or needs replacing. Be sure to follow the LCD prompts to replace the ink cartridges in the correct order.

Even though the machine tells you to replace an ink cartridge, there will be a small amount of ink left in the ink cartridge. It is necessary to keep some ink in the ink cartridge to prevent air from drying out and damaging the print head assembly.

If ink gets in your eyes, wash it out with water at once and call a doctor if you are concerned.

Routine maintenance

b Press the lock release lever as shown to

release the cartridge indicated on the LCD. Remove the cartridge from the machine.

d Turn the green release lever on the

orange protective packing (1) clockwise until it clicks to release the vacuum seal. Then remove the orange protective packing as shown.

c Open the new ink cartridge bag for the

color shown on the LCD, and then take out the ink cartridge.

e Each color has its own correct position.

Insert the ink cartridge in the direction of the arrow on the label.

f Gently push the back of the ink cartridge

Note

IMPORTANT

᥼

marked “PUSH” until it clicks, and then close the ink cartridge cover.

g The machine will automatically reset the

ink dot counter.

• If you replaced an ink cartridge, for example Black, the LCD may ask you to verify that it was a brand new one (for

example, Did You Change Black). For each new cartridge you installed, press 1 (Yes) to automatically reset the ink dot counter for that color. If the ink cartridge you installed is not a brand new one, be sure to press 2 (No).

• DO NOT take out ink cartridges if you do not need to replace them. If you do so, it may reduce the ink quantity and the machine will not know the quantity of ink left in the cartridge.

• DO NOT touch the cartridge insertion slots. If you do so, the ink may stain your skin.

• If ink gets on your skin or clothing immediately wash it off with soap or detergent.

• If you mix the colors by installing an ink cartridge in the wrong position, clean the print head several times after correcting the cartridge installation.

• Once you open an ink cartridge, install it in the machine and use it up within six months of installation. Use unopened ink cartridges by the expiration date written on the cartridge package.

• DO NOT dismantle or tamper with the ink cartridge; this can cause the ink to leak out of the cartridge.

• If the LCD shows No Ink Cartridge or Cannot Detect after you install the ink cartridges, check that the ink cartridges are brand new Original Brother and that they are installed correctly.

Cleaning and checking

Note

Routine maintenance

the machine

Cleaning the scanner glass A

Unplug the machine from the electrical

socket.

b Lift the document cover (1). Clean the

scanner glass (2) and the white plastic (3) with a soft lint-free cloth moistened with a non-flammable glass cleaner.

In addition to cleaning the glass strip with a non-flammable glass cleaner, run your finger tip over the glass strip to see if you can feel anything on it. If you feel dirt or debris, clean the glass strip again concentrating on that area. You may need to repeat the cleaning process three or four times. To test, make a copy after each cleaning attempt.

When there is a spot of dirt or correction fluid on the glass strip the printed sample shows a vertical line.

After the glass strip is cleaned the vertical line is gone.

c In the ADF unit, clean the white bar (1)

and the glass strip (2) with a lint-free cloth moistened with a non-flammable glass cleaner.

Cleaning the print head A

IMPORTANT

Note

Checking the print quality A

To maintain good print quality, the machine will automatically clean the print head when needed. You can start the cleaning process manually if there is a print quality problem.

Clean the print head if you get a horizontal line in the text or graphics, or blank text on your printed pages. You can clean Black only, three colors at a time (Yellow/Cyan/Magenta), or all four colors at once.

Cleaning the print head consumes ink. Cleaning too often uses ink unnecessarily.

DO NOT touch the print head. Touching the print head may cause permanent damage and may void the print head's warranty.

a Press Menu.

If faded or streaked colors and text appear on your printouts, some of the print head nozzles may be clogged. You can check this by printing the Print Quality Check Sheet and looking at the nozzle check pattern.

a Press Menu. b Press a or b to choose Ink.

Press OK.

c Press a or b to choose Test Print.

Press OK.

d Press a or b to choose

Print Quality. Press OK.

e Press Color Start.

The machine begins printing the Print Quality Check Sheet.

f Check the quality of the four color blocks

on the sheet.

b Press a or b to choose Ink.

Press OK.

c Press a or b to choose Cleaning.

Press OK.

Press a or b to choose Black, Color or

All. Press OK. The machine cleans the print head. When cleaning is finished, the machine will go back to the Ready mode automatically.

If you clean the print head at least five times and the print has not improved, try installing a new Brother Original Innobella™ ink cartridge for each problem color. Try cleaning the print head again up to five more times. If the print has not improved call your Brother dealer.

g The LCD asks you if the print quality is

OK. Do one of the following:

 If all lines are clear and visible, press

1 (Yes) to finish the Print Quality check and go to step k.

 If you can see missing short lines as

shown below, press 2 to choose No.

OK Poor

h The LCD asks you if the print quality is

OK for black and then the three colors. Press 1 (Yes) or 2 (No).

Routine maintenance

IMPORTANT

Note

i The LCD asks you if you want to start

cleaning. Press 1 (Yes). The machine starts cleaning the print head.

j After the cleaning procedure is finished,

press Color Start. The machine starts printing the Print Quality Check Sheet again and repeat the procedure from step f.

k Press Stop/Exit.

If you repeat this procedure at least five times and the print quality is still poor, replace the ink cartridge for the clogged color. After replacing the ink cartridge, check the print quality. If the problem still exists, repeat the cleaning and test print procedures at least five times for the new ink cartridge. If ink is still missing, call your Brother dealer.

Checking the print alignment A

You may need to adjust the print alignment after transporting the machine, if your printed text becomes blurred or images become faded.

a Press Menu. b Press a or b to choose Ink.

Press OK.

c Press a or b to choose Test Print.

Press OK.

d Press a or b to choose Alignment.

Press OK.

e Press Mono Start or Color Start.

The machine starts printing the Alignment Check Sheet.

DO NOT touch the print head. Touching the print head may cause permanent damage and may void the print head's warranty.

When a print head nozzle is clogged the printed sample looks like this.

After the print head nozzle is cleaned, the horizontal lines are gone.

f For the “A” pattern, press the number of

the test print that has the least visible vertical stripes (1-9).

g For the “B” pattern, press the number of

the test print that has the least visible vertical stripes (1-9).

h For the “C” pattern, press the number of

the test print that has the least visible vertical stripes (1-9).

i For the “D” pattern, press the number of

the test print that has the least visible vertical stripes (1-9).

j Press Stop/Exit.

Packing and shipping

IMPORTANT

the machine

When you transport the machine, use the packing materials that came with your machine. Follow the instructions below to correctly package your machine. Damage caused to your machine during transit may not be covered by your warranty.

It is important to allow the machine to “park” the print head after a print job. Listen carefully to the machine before unplugging it to make sure that all mechanical noise has stopped. Not allowing the machine to finish this process may lead to print problems and possible damage to the print head.

a Open the ink cartridge cover. b Remove all four ink cartridges. Press

the ink release lever above each cartridge to release it. (See Replacing the ink cartridges uu page 50)

c Install the orange protective part and

then close the ink cartridge cover.

• Make sure the plastic tab on the right side of the orange protective part (1) clicks securely into place (2).

• If you are not able to find the orange protective part, ship the machine without it. DO NOT install the ink cartridges as an alternative before shipping.

d Lift the machine from the front and hook

the tab of the orange protective part into the keyed opening (1) on the bottom of the paper tray. Then latch the protective part over the raised portion of the paper tray (2).

Routine maintenance

e Unplug the machine from the telephone

wall socket and take the telephone line cord out of the machine.

f Unplug the machine from the electrical

socket.

g Using both hands, use the plastic tabs

on both sides of the machine to lift the scanner cover into the open position. Then unplug the interface cable from the machine, if it is connected.

h Using both hands, grasp the plastic tabs

on both sides of the machine and gently close the scanner cover.

j Pack the machine and the printed

materials in the original carton with the original packing material as shown below.

i Wrap the machine in the bag.

k Close the carton and tape it shut.

Troubleshooting B

Error and Maintenance messages B

As with any sophisticated office product, errors may occur and consumable items may need to be replaced. If this happens, your machine identifies the error and shows an error message. The most common error and maintenance messages are shown in the following table.

You can correct most errors and routine maintenance by yourself. If you need more help, the Brother Solutions Center offers the latest FAQs and troubleshooting tips.

Visit us at http://solutions.brother.com/

Error Message Cause Action

B&W Print Only

Replace Ink

One or more of the color ink cartridges have reached the end of their life.

You can use the machine in monochrome mode for approximately four weeks depending on the number of pages you print.

While this message appears on the LCD, each operation works in the following way:

 Printing

If you choose Greyscale in the Advanced tab of the printer driver

you can use the machine as a monochrome printer.

 Copying

If the paper type is set to Plain Paper you can make copies in monochrome.

Replace the ink cartridges. (See Replacing the ink cartridges uu page 50.)

If you unplug the machine or take out the ink cartridge, you cannot use the machine until you change to a new ink cartridge.

 Faxing

If the paper type is set to

Plain Paper or Inkjet Paper, the machine will

receive and print the faxes in monochrome.

If a sending machine has a color fax, the machine’s “handshake” will ask that the fax be sent as monochrome.

If the paper type is set to

Other Glossy, Brother BP71 or Brother BP61 the machine will stop

all print operations.

Error Message Cause Action

Troubleshooting

Cannot Detect You installed a new ink cartridge too

quickly and the machine did not detect it.

If you are using non Brother Original ink the machine may not detect the ink cartridge.

An ink cartridge is not installed correctly.

Cannot Print

Replace Ink

Comm.Error Poor telephone line quality caused a

One or more of the ink cartridges have reached the end of their life. The machine will stop all print operations. While memory is available, monochrome faxes will be stored in the memory. If a sending machine has a color fax, the machine's “handshake” will ask that the fax be sent as monochrome.

communication error.

Take out the new ink cartridge and re-install it slowly until it clicks.

Replace the cartridge with a Brother Original ink cartridge. If the error message remains, contact your Brother dealer.

Take out the new ink cartridge and re-install it slowly until it clicks. (See Replacing the ink cartridges uu page 50.)

Replace the ink cartridges. (See Replacing the ink cartridges uu page 50.)

If the problem continues, call the telephone company and ask them to check your telephone line.

Cover is Open The scanner cover is not completely

closed.

The ink cartridge cover is not completely closed.

Data Remaining Print data is left in the machine's

memory.

Disconnected The other person or other person's fax

machine stopped the call.

Document Jam The document was not inserted or fed

correctly, or the document scanned from the ADF was too long.

High Temperature The print head is too warm. Allow the machine to cool down.

Lift the scanner cover and then close it again.

Firmly close the ink cartridge cover until it clicks.

Press Stop/Exit. The machine will cancel the job and clear it from the memory. Try to print again.

Try to send or receive again. If calls are stopped repeatedly and you are using a VoIP (Voice over IP) system, try changing the Compatibility to Basic (for VoIP). (See Telephone line interference / VoIP uu page 75.)

(See Using the ADF uu page 23.)

(See Document jam uu page 64.)

Note

Error Message Cause Action

Ink Absorber Full The ink absorber box or flushing box is

full. These components are periodic maintenance items that may require replacement after a period of time to ensure optimum performance from your Brother machine. Because these components are periodic maintenance items, the replacement is not covered under the warranty. The need to replace these items and the time period before replacement is dependent on the number of purges and flushes required to clean the ink system. These boxes acquire amounts of ink during the different purging and flushing operations. The number of times a machine purges and flushes for cleaning varies depending on different situations. For example, frequently powering the machine on and off will cause numerous cleaning cycles since the machine automatically cleans upon power up. The use of non-Brother ink may cause frequent cleanings because non-Brother ink could cause poor print quality which is resolved by cleaning. The more cleaning the machine requires the faster these boxes will fill up.

The ink absorber box or flushing box will need to be replaced. Contact Brother Customer Service or your local Brother Authorised Service Centre to have your machine serviced.

Other reasons for cleaning are:

1 After a paper jam has been

cleared, the machine automatically cleans itself before the next received fax is printed.

2 The machine automatically cleans

itself after sitting idle for more than 30 days (infrequent use).

3 The machine automatically cleans

itself after the ink cartridges for each color have been replaced 12 times.

Repairs resulting from the use of non-Brother supplies may not be covered under the stated product warranty.

Ink Absorber NearFull

Ink low One or more of the ink cartridges are

The ink absorber box or flushing box is near full.

near the end of their life. If a sending machine has a color fax to send, your machine’s “handshake” will ask that

Call Brother Customer Service / your Brother dealer.

Order a new ink cartridge. You can continue printing until the LCD shows

Cannot Print. (See Replacing the ink cartridges uu page 50.)

the fax be sent as monochrome. If the sending machine has the ability to convert it, the color fax will be printed at your machine as a monochrome fax.

Low Temperature The print head is too cold. Allow the machine to warm up.

Error Message Cause Action

Troubleshooting

No Caller ID There is no incoming call history. You

did not receive calls or you have not subscribed to the Caller ID service from your telephone company.

No Ink Cartridge An ink cartridge is not installed

correctly.

No Paper Fed The machine is out of paper or paper

is not correctly loaded in the paper tray.

The paper is jammed in the machine. Remove the jammed paper by

If you want to use the Caller ID feature call your telephone company. (See

Caller ID (Caller IDentification) (not available in certain area)

page 34.)

Take out the new ink cartridge and reinstall it slowly until it clicks. (See Replacing the ink cartridges uu page 50.)

Do one of the following:

 Refill the paper in the paper tray,

and then press Mono Start or Color Start.

 Remove the paper and load it

again, and then press Mono Start or Color Start. (See Loading paper and other print media uu page 12.)

following the steps in Printer jam or paper jam uu page 65.

Paper dust has accumulated on the surface of the paper pick-up rollers.

The Jam Clear Cover is not closed correctly.

No Response/Busy The number you dialled has not

answered or is busy.

Not Registered You tried to access a Speed Dial

number that is not programmed.

Out of Memory The machine's memory is full. If a copy operation is in process

Paper Jam Paper is jammed in the machine. Remove the jammed paper by

Clean the paper pick-up rollers. (uuAdvanced User’s Guide: Cleaning the paper pick-up rollers)

Check the Jam Clear Cover is closed evenly at both ends. (See Printer jam or paper jam uu page 65.)

Verify the number and try again.

Set up the Speed Dial number. (See Storing Speed Dial numbers uu page 43.)

Press Stop/Exit and wait until the other operations that are in progress finish, and then try again.

following the steps in Printer jam or paper jam uu page 65.

Make sure the paper length guide is set to the correct paper size.

Error Message Cause Action

Unable to CleanXX

Unable to Init.XX

Unable to PrintXX

Unable to ScanXX

Wrong Ink Colour A color ink cartridge has been installed

Wrong Paper Size The Paper Size setting does not

The machine has a mechanical problem.

—OR—

A foreign object such as a paper clip or ripped paper is in the machine.

in the Black ink cartridge position.

match the size of paper in the tray. Or, you did not set the paper guides in the tray to the indicators for the paper size you are using.

Open the scanner cover and remove any foreign objects and paper scraps from inside the machine. If the error message continues, see Transferring your faxes or Fax Journal report uu page 63 before disconnecting the machine so you will not lose any important messages. Then, disconnect the machine from the power for several minutes and reconnect it.

Check which ink cartridges are not matched by color to their ink cartridge positions and move them to their correct positions.

1 Check that the paper size you

choose matches the size of paper in the tray.

2 Make sure you loaded the paper in

a Portrait position, by setting the paper guides at the indicators for your paper size.

3 After you have checked the paper

size and the paper position, press

Mono Start or Color Start.

Troubleshooting

Error animations display B

Error animations display step-by-step instructions when paper gets jammed. You can read the steps at your own pace by pressing c to see the next step and d to go back a step.

Transferring your faxes or Fax Journal report B

If the LCD shows:

 Unable to CleanXX

 Unable to Init.XX

 Unable to PrintXX

 Unable to ScanXX

We recommend transferring your faxes to another fax machine. (See Transferring faxes to another fax machine uu page 63.)

You can also transfer the Fax Journal report to see if there are any faxes you need to transfer. (See Transferring the Fax Journal report to another fax machine uu page 63.)

Transferring faxes to another fax machine

If you have not set up your Station ID, you cannot enter fax transfer mode. (uuQuick Setup Guide: Enter personal information (Station ID))

a Press Stop/Exit to interrupt the error

temporarily.

f Do one of the following:

 If the LCD shows No Data, there

are no faxes left in the machine's memory.

Press Stop/Exit.

 Enter the fax number to which faxes

will be forwarded.

g Press Mono Start.

Transferring the Fax Journal report to another fax machine

If you have not set up your Station ID, you cannot enter fax transfer mode. (uuQuick Setup Guide: Enter personal information (Station ID))

Press Stop/Exit to interrupt the error

temporarily.

b Press Menu. c Press a or b to choose Service.

Press OK.

d Press a or b to choose

Data Transfer.

Press OK.

e Press a or b to choose

Report Trans.

Press OK.

f Enter the fax number to which the Fax

Journal report will be forwarded.

g Press Mono Start.

b Press Menu. c Press a or b to choose Service.

Press OK.

d Press a or b to choose

Data Transfer. Press OK.

e Press a or b to choose Fax Transfer.

Press OK.

Document jam B

IMPORTANT

Documents can jam in the ADF unit if they are not inserted or fed correctly, or if they are too long. Follow the steps below to clear a document jam.

Document is jammed inside the ADF unit

a Take out any paper from the ADF that is

not jammed.

b Lift the document cover.

Document is jammed in the top of the ADF unit

a Take out any paper from the ADF that is

not jammed.

b Open the ADF cover. c Remove the jammed document by

pulling it upward.

c Pull the jammed document out to the

left.

Close the document cover.

d e Press Stop/Exit.

d Close the ADF cover. e Press Stop/Exit.

To avoid document jams close the ADF cover correctly by pushing it gently in the middle.

Troubleshooting

IMPORTANT

Printer jam or paper jam B

Take out the jammed paper depending on where it is jammed in the machine.

If the LCD shows Paper Jam follow these steps:

Before you unplug the machine from the power source, you can transfer your faxes that are stored in the memory to another fax machine so you will not lose any important messages. (See Transferring your faxes or Fax Journal report uu page 63.)

a Unplug the machine from the electrical

socket.

c Pull the two green levers inside the

machine to release the jammed paper.

d Pull out the jammed paper (1).

b If the paper support flap is open, close it,

and then close the paper support. Pull the paper tray completely out of the machine.

e Lift the Jam Clear Flap, and remove the

jammed paper.

f Open the Jam Clear Cover (1) at the

back of the machine.

i Using both hands, use the plastic tabs

on both sides of the machine to lift the scanner cover (1) to the open position.

g Pull the jammed paper out of the

machine.

Move the print head (if necessary) to take out any paper remaining in this area. Make sure that jammed paper is not left in the corners of the machine (2) and (3).

h Close the Jam Clear Cover.

Make sure the cover is closed correctly.

IMPORTANT

• If the paper is jammed under the print head, unplug the machine from the power source, and then move the print head to take out the paper.

• If the print head is in the right corner as shown in the illustration, you cannot move it. Re-connect the power cord. Hold down Stop/Exit until the print head moves to the centre. Then unplug the machine from the power source and take out the paper.

Troubleshooting

k Push the two green levers back to their

original positions.

• If ink gets onto your skin, immediately wash with soap and plenty of water.

j Using both hands, grasp the plastic tabs

on both sides of the machine and gently close the scanner cover.

l Push the paper tray firmly back into the

machine.

m While holding the paper tray in place,

pull out the paper support (1) until it clicks, and unfold the paper support flap (2).

Make sure you pull out the paper support until it clicks.

n Re-connect the power cord.

Troubleshooting

If you think there is a problem with your machine, check the chart below and follow the troubleshooting tips.

Most problems can be easily resolved by yourself. If you need additional help, the Brother Solutions Center offers the latest FAQs and troubleshooting tips. Visit us at http://solutions.brother.com/

If you are having difficulty with your machine B

Printing

Difficulty Suggestions

No printout. Check the interface cable or wireless connection on both the machine and your

computer. (uuQuick Setup Guide)

Check that the machine is plugged in and that the On/Off key is on.

One or more ink cartridges have reached the end of their life. (See Replacing the ink cartridges uu page 50.)

Check to see if the LCD is showing an error message. (See Error and Maintenance messages uu page 58.)

If the LCD shows Cannot Print and Replace Ink, see Replacing the ink cartridges uu page 50.

Check that the correct printer driver has been installed and chosen.

Make sure that the machine is online.

(Windows Click Start and then Printers and Faxes. Right-click Brother MFC-XXXXX (where XXXXX is your model name). If the printer is offline, it will show Use Printer Online. Select this option to enable the printer.

(Windows Vista

XP)

)

Click , Control Panel, Hardware and Sound and then Printers. Right-click

Brother MFC-XXXXX (where XXXXX is your model name). If the printer is offline,

it will show Use Printer Online. Select this option to enable the printer.

(Windows

Click and then Devices and Printers. Right-click Brother MFC-XXXXX

(where XXXXX is your model name) and choose Seewhat’sprinting. Click Printer and make sure that Use Printer Offline is unchecked.

Troubleshooting

Printing (continued)

Difficulty Suggestions

Poor print quality. Check the print quality. (See Checking the print quality uu page 54.)

Make sure that the Media Type setting in the printer driver or the Paper Type setting in the machine’s menu matches the type of paper you are using. See Paper Type uu page 18.

uuSoftware User’s Guide: Printing (Windows uuSoftware User’s Guide: Printing and Faxing (Macintosh)

Make sure that your ink cartridges are fresh. The following may cause ink to clog:

 The expiration date written on the cartridge package has passed. (Brother

Original cartridges stay usable for up to two years if kept in their original packaging.)

 The ink cartridge has been in your machine for over six months.

 The ink cartridge may not have been stored correctly before use.

Make sure you are using Brother Original Innobella™ ink. Brother does not recommend the use of cartridges other than Brother Original cartridges or the refilling of used cartridges with ink from other sources.

Try using the recommended types of paper. (See Acceptable paper and other print media uu page 19.)

The recommended environment for your machine is between 20 C to 33 C.

White horizontal lines appear in text or graphics.

The machine prints blank pages. Clean the print head. (See Cleaning the print head uu page 54.)

Characters and lines are blurred. Check the printing alignment. (See Checking the print alignment uu page 55.)

Printed text or images are skewed. Make sure the paper is loaded correctly in the paper tray and the paper side

Smudge or stain at the top centre of the printed page.

Printing appears dirty or ink seems to run.

Stains appear on the reverse side or at the bottom of the page.

Clean the print head. (See Cleaning the print head uu page 54.)

Make sure you are using Brother Original Innobella™ ink.

Try using the recommended types of paper. (See Acceptable paper and other print media uu page 19.)

Make sure you are using Brother Original Innobella™ ink.

guides are adjusted correctly. (See Loading paper and other print media uu page 12.)

Make sure the Jam Clear Cover is closed correctly.

Clean the paper pick-up rollers. (uuAdvanced User’s Guide: Cleaning the paper pick-up rollers)

Make sure the paper is not too thick or curled. (Acceptable paper and other print media uu page 19)

Make sure you are using the recommended types of paper. (See Acceptable paper and other print media uu page 19.) Don't handle the paper until the ink is dry.

Make sure you are using Brother Original Innobella™ ink.

If you are using photo paper, make sure that you have set the correct paper type. If you are printing a photo from your PC, set the Media Type of the printer driver.

Make sure the printer platen is not dirty with ink. (uu Cleaning the machine’s printer platen)

Make sure you are using Brother Original Innobella™ ink.

Make sure you are using the paper support flap. (See Loading paper and other print media uu page 12.)

)

Advanced User’s Guide:

Printing (continued)

Difficulty Suggestions

The machine prints dense lines on the page.

The printouts are wrinkled.

Cannot perform “Page Layout” printing.

Print speed is too slow. Try changing the printer driver setting. The highest resolution needs longer data

Color Enhancement is not working correctly.

Photo paper does not feed correctly.

Machine feeds multiple pages. Make sure the paper is loaded correctly in the paper tray. (See Loading paper and

There is a paper jam. Make sure the paper length guide is set to the correct paper size. (See Printer jam

Printed pages are not stacked neatly.

Machine does not print from

Adobe

Illustrator®.

Ink is smudged or running when using glossy photo paper.

Check Reverse Order in the Basic tab of the printer driver.

(Windows

users) In the printer driver Advanced tab, click Colour Settings, and uncheck Bi-Directional Printing.

(Macintosh users) In the printer driver, choose Print Settings, click Advanced, choose Other Print Options, and uncheck Bi-Directional Printing.

Make sure you are using Brother Original Innobella™ ink.

Check that the paper size setting in the application and in the printer driver are the same.

processing, sending and printing time. Try the other quality settings in the printer driver Advanced tab (Windows

) or Print Settings (Macintosh). Also, click

Colour Settings, and make sure you uncheck Colour Enhancement.

Turn the borderless feature off. Borderless printing is slower than normal printing. uuSoftware User’s Guide: Printing (Windows

)

uuSoftware User’s Guide: Printing and Faxing (Macintosh)

If the image data is not full color in your application (such as 256 color), Color Enhancement will not work. Use at least 24 bit color data with the Color Enhancement feature.

When you print on Brother Photo paper, load one extra sheet of the same photo paper in the paper tray. An extra sheet has been included in the paper package for this purpose.

Clean the paper pick-up rollers. (uuAdvanced User’s Guide: Cleaning the paper

pick-up rollers)

other print media uu page 12.)

or paper jam uu page 65.)

Make sure you are using the paper support flap. (See Loading paper and other print media uu page 12.)

Try to reduce the print resolution.

uuSoftware User’s Guide: Printing (Windows®) uuSoftware User’s Guide: Printing and Faxing (Macintosh)

Make sure to check the front and back of the paper. Place the glossy surface (printing surface) face down. (See Paper Type uu page 18.)

If you use glossy photo paper, make sure that the paper type setting is correct.

Troubleshooting

Printing Received Faxes

Difficulty Suggestions

Condensed print and white streaks across the page or the top and bottom of sentences are cut off.

Vertical black lines when receiving. The sender's scanner may be dirty. Ask the sender to make a copy to see if the

Received color fax prints only in black and white.

Left and Right margins are cut off or a single page is printed on two pages.

You probably had a bad connection, with static or interference on the telephone line. Ask the other party to send the fax again.

problem is with the sending machine. Try receiving from another fax machine.

Replace the color ink cartridges that have reached the end of their life, and then ask the other person to send the color fax again. (See Replacing the ink cartridges uu page 50.)

Turn on Auto Reduction. (uuAdvanced User’s Guide: Printing a reduced incoming fax)

Telephone Line or Connections

Difficulty Suggestions

Dialling does not work. (No dial tone)

The machine does not answer when called.

Make sure the machine is plugged in and turned on.

Check the line cord connections.

Change the Tone/Pulse setting. (uuQuick Setup Guide)

Lift the external telephone’s handset and listen for a dial tone. If there is no dial tone, ask your telephone company to check the line and/or socket.

Make sure the machine is in the correct Receive Mode for your setup. (See Receive Modes uu page 29.) Check for a dial tone. If possible, call your machine to hear it answer. If there is still no answer, check the telephone line cord connection. If there is no ringing when you call your machine, ask your telephone company to check the line.

Sending Faxes

Difficulty Suggestions

Cannot send a fax. Check all line cord connections. Make sure the telephone line cord is plugged into

the telephone wall socket and the LINE socket on the machine.

Ask the other party to check that the receiving machine has paper.

Print the Transmission Verification Report and check for an error. (uuAdvanced User’s Guide: Reports)

Transmission Verification Report says ”RESULT:ERROR”.

Poor fax send quality. Try changing your resolution to Fine or S.Fine. Make a copy to check your

Vertical black lines when sending. Black vertical lines on faxes you send are typically caused by dirt or correction fluid

There is probably temporary noise or static on the line. Try sending the fax again. If you send a PC FAX message and get “RESULT:ERROR” on the Transmission Verification Report, your machine may be out of memory. If the problem continues, ask the telephone company to check your telephone line.

If you often get transmission errors due to possible interference on the telephone line, try changing the menu setting of Compatibility to Basic(for VoIP). (See Telephone line interference / VoIP uu page 75.)

machine's scanner operation. If the copy quality is not good, clean the scanner. (See Cleaning the scanner glass uu page 53.)

on the glass strip. Clean the glass strip. (See Cleaning the scanner glass uu page 53.)

Handling Incoming Calls

Difficulty Suggestions

The machine “hears” a voice as a CNG Tone.

Sending a fax call to the machine. If you answered on an extension or external telephone, press your Remote

Custom features on a single line. If you have Call Waiting, Call Waiting/Caller ID, an alarm system or other custom

If Fax Detect is set to On, your machine is more sensitive to sounds. It may mistakenly interpret certain voices or music on the line as a fax machine calling and respond with fax-receiving tones. Deactivate the machine by pressing Stop/Exit. Try avoiding this problem by turning Fax Detect to Off. (See Fax Detect uu page 32.)

Activation Code (the factory default is l 51). If you answered on an external telephone, press Start to receive the fax. When your machine answers, hang up.

feature on a single telephone line with your machine, it may create a problem sending or receiving faxes.

For example: If you subscribe to Call Waiting or some other custom service and its signal comes through the line while your machine is sending or receiving a fax, the signal can temporarily interrupt or disrupt the faxes. Brother's ECM (Error Correction Mode) feature should help overcome this problem. This condition is related to the telephone system industry and is common to all devices that send and receive information on a single, shared line with custom features. If avoiding a slight interruption is crucial to your business, a separate telephone line with no custom features is recommended.

Copying Difficulties

Difficulty Suggestions

Poor copy results when using the ADF.

Vertical black lines or streaks appear in copies.

Fit to Page does not work correctly. Make sure your source document is not skewed.

Try using the scanner glass. (See Using the scanner glass uu page 24.)

Vertical black lines or streaks on copies are typically caused by dirt or correction fluid on the glass strip. Clean the glass strip. (See Cleaning the scanner glass uu page 53.)

Reposition the document and try again.

Scanning Difficulties

Difficulty Suggestions

TWAIN or WIA errors appear when starting to scan. (Windows

TWAIN or ICA errors appear when starting to scan. (Macintosh)

Poor scanning results when using the ADF.

OCR does not work. Try increasing the scanner resolution.

)

Make sure the Brother TWAIN/WIA driver is chosen as the primary source. In Presto! PageManager with OCR, click File, Select Source and choose the Brother TWAIN/WIA driver.

Make sure the Brother TWAIN driver is chosen as the primary source. In PageManager, click File, Select Source and choose the Brother TWAIN driver. Mac OS X 10.6.x users can also scan documents using the ICA Scanner Driver.

uuSoftware User’s Guide: Scanning a document using the ICA driver (Mac OS X

10.6.x)

Try using the scanner glass. (See Using the scanner glass uu page 24.)

(Macintosh users)

Presto! PageManager must be downloaded and installed before use. See Accessing Brother Support (Macintosh) uu page 5 for further instructions.

Troubleshooting

Software Difficulties

Difficulty Suggestions

Cannot install software or print.

“Device Busy” Make sure the machine is not showing an error message on the LCD.

Cannot print images from FaceFilter Studio.

(Windows Run the Repair MFL-Pro Suite program on the CD-ROM. This program will repair and reinstall the software.

To use FaceFilter Studio, you must install the FaceFilter Studio application from the CD-ROM supplied with your machine. (uuQuick Setup Guide)

Also, before you start FaceFilter Studio for the first time, you must make sure your Brother machine is turned on and connected to your computer. This will allow you to access all the functions of FaceFilter Studio.

users only)

Network Difficulties

Difficulty Suggestions

Cannot print over the network. Make sure that your machine is powered on, is online and in the Ready mode.

Print a Network Configuration Report (uuAdvanced User’s Guide: Reports) and check the current Network settings printed in this list.

If you are using a wireless connection or are having Network problems uuNetwork User’s Guide: Troubleshooting

The network scanning feature does not work.

The Brother software cannot be installed.

(Windows

It is necessary to configure the third-party Security/Firewall Software to allow Network scanning. To add port 54925 for Network scanning, enter the information below:

In Name: Enter any description, for example Brother NetScan.

In Port number: Enter 54925.

In Protocol: UDP is selected.

Please refer to the instruction manual that came with your third-party Security/Firewall Software or contact the software manufacturer.

(Macintosh users)

Re-select your machine in the Device Selector application located in Macintosh HD/Library/Printers/Brother/Utilities/DeviceSelector or from the model list in ControlCenter2.

(Windows

Allow network access to the following programs if your security software displays an alert message during MFL-Pro Suite installation.

users)

(Macintosh users)

If you are using a firewall function of anti-spyware or antivirus security software, temporarily disable it and then install the Brother software.

Cannot connect to wireless network.

Reset the network settings. Press the Menu key, choose Network and then press OK. Choose

Investigate the problem using the WLAN Report. Press the Menu key, choose Print Reports and then press OK. Choose WLAN Report. (uuNetwork User’s Guide)

Network Reset. (uuNetwork User’s Guide)

Troubleshooting

Note

Dial Tone detection B

When you send a fax automatically, by default your machine will wait for a fixed amount of time before it starts to dial the number. By changing the Dial Tone setting to Detection you can make your machine dial as soon as it detects a dial tone. This setting can save a small amount of time when sending a fax to many different numbers. If you change the setting and start having problems when dialling, you should change it back to the No Detection setting.

a Press Menu. b Press a or b to choose

Initial Setup. Press OK.

c Press a or b to choose Dial Tone.

Press OK.

Telephone line interference / VoIP B

If you are having problems sending or receiving a fax due to possible interference on the telephone line, you can change the compatibility setting, which reduces the modem speed to minimise errors.

a Press Menu. b Press a or b to choose

Initial Setup. Press OK.

c Press a or b to choose

Compatibility. Press OK.

d Press a or b to choose Normal or

Basic(for VoIP).

Press OK.

d Press a or b to choose Detection or

No Detection.

Press OK.

e Press Stop/Exit.

 Basic(for VoIP) cuts the

modem speed to 9,600 bps and turns off color fax receiving and ECM, except for color fax sending. Unless interference is a recurring problem on your telephone line, you may prefer to use it only when needed.

To improve compatibility with most VoIP services, Brother recommends changing the compatibility setting to Basic(for VoIP).

 Normal sets the modem speed at

14,400 bps.

e Press Stop/Exit.

• VoIP (Voice over IP) is a type of phone system that uses an internet connection, rather than a traditional phone line.

• Brother does not recommend the use of a VoIP line. VoIP limitations in general can cause some functions of the fax machine not to work correctly.

Machine Information

Checking the serial number B

You can see the machine’s serial number on the LCD.

Press Menu.

a b Press a or b to choose

Machine Info.

Press OK.

c Press a or b to choose Serial No.

Press OK.

3 All Settings

You can restore all settings to their factory defaults.

Brother strongly recommends performing this procedure before handing over or disposing of the machine.

How to reset the machine B

a Press Menu. b Press a or b to choose

Initial Setup. Press OK.

d Press Stop/Exit.

Reset functions B

The following reset functions are available:

1 Network

You can reset the print server back to its default factory settings, such as the password and IP address information.

2 Speed Dial&Fax

Speed Dial & Fax resets the following settings:

 Speed Dial

(Speed-Dial and Setup Groups)

 Station ID

(Name and Number)

 Report settings

c Press a or b to choose Reset.

Press OK.

d Press a or b to choose the type of reset

(Network, Speed Dial&Fax or All Settings) you want to use.

Press OK. Press 1 to confirm.

e Press 1 to reboot the machine.

(Transmission Verification Report, Quick Dial List and Fax Journal)

 History

(Caller ID history and Outgoing Call)

 Faxes in memory

Menu and features C

On-screen programming

Your machine is designed to be easy to operate with LCD on-screen programming using the menu keys. User-friendly programming helps you take full advantage of all the menu selections your machine has to offer.

Since your programming is done on the LCD, we have created step-by-step on-screen instructions to help you program your machine. All you need to do is follow the instructions as they guide you through the menu selections and programming options.

Menu table

The menu table will help you understand the menu selections and options that are found in the machine's programs. The factory settings are shown in Bold with an asterisk.

Menu ( ) C

Level1 Level2 Level3 Options Descriptions Page

Ink Test Print — Print Quality

Alignment

Cleaning — Black

Color

All

Ink Volume — — Lets you check the

General Setup Mode Timer — Off

0Sec

30Secs

Lets you check the print quality or alignment.

Lets you clean the print head.

available ink volume.

Sets the amount of time before the machine returns to FAX mode.

See .

1Min

2Mins*

5Mins

Paper Type — Plain Paper*

Inkjet Paper

Brother BP71

Brother BP61

Other Glossy

Transparency

Paper Size — A4*

10x15cm

Letter

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

Sets the type of paper in the paper tray.

Sets the size of paper in the paper tray.

Menu and features

Level1 Level2 Level3 Options Descriptions Page

General Setup

Volume Ring Off

Adjusts the ring volume. 9

(Continued)

Beeper Off

Speaker Off

LCD Settings LCD Contrast

Backlight Light*

Dim Timer Off

Low

Med*

High

Low*

Med

High

Low

Med*

High

Med

Dark

10Secs

20Secs

Adjusts the beeper volume.

Adjusts the speaker volume.

Adjust the contrast of the LCD.

You can adjust the brightness of the LCD backlight.

You can set how long the LCD backlight stays on for after the last key press.

See .

30Secs*

Sleep Mode — 1Min

2Mins

3Mins

5Mins*

10Mins

30Mins

60Mins

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

You can choose how long the machine will remain idle before it goes into Sleep mode.

Level1 Level2 Level3 Options Descriptions Page

Fax Setup Receive Ring Delay 0

F/T Ring Time 20Secs

Fax Detect On*

Remote Codes On*

Auto Reduction

Setup Speed Dial

Set Speed Dial

Setup Groups — You can set up Group

Sets the number of rings

30Secs*

40Secs

70Secs

Off

(l51, #51)

Off

On*

Off

— Stores Speed Dial

before the machine answers in Fax Auto or Fax/Tel mode.

Sets the length of the fast double-ring time in Fax/Tel mode.

Receives fax messages automatically when you answer a call and hear fax tones.

Allows you to answer all calls at an extension or external telephone and use codes to turn the machine on or off. You can personalize these codes.

Cuts the size of incoming faxes to fit the paper size.

numbers, so you can dial by pressing only a few keys (and Start).

numbers for broadcasting.

See .

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

Menu and features

Level1 Level2 Level3 Options Descriptions Page

Fax

(Continued)

Report Setting

Remaining Jobs

Miscellaneous TX Lock — Prohibits most functions

Transmission On

On+Image

Off*

Off+Image

Journal Period

— — Check which jobs are in

Caller ID Type

Fax Mode Easy Mode*

Off

Every 50 Faxes

Every 6 Hours

Every 12 Hours

Every 24 Hours

Every 2 Days

Every 7 Days

Auto*

FSK

DTMF

Advanced Mode

Choose the initial setup for Transmission Verification Report.

Sets the interval for the automatic printing of the

Fax Journal. If you have chosen an option other than Off or Every 50 Faxes, you can set the time for the chosen option. If you have chosen Every 7 Days, you can set the day of the week.

the memory and cancel chosen jobs.

except receiving faxes.

You can switch the mode if Caller ID cannot be displayed normally.

Selects the transmission process when sending/receiving the faxes manually.

See .

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

Network menu C

Level1 Level2 Level3 Options Descriptions Page

Network TCP/IP BOOT Method Auto*

Static

RARP

BOOTP

DHCP

IP Address [000-255].

[000-255].

[000-255]

Subnet Mask [000-255].

[000-255].

[000-255]

Gateway [000-255].

[000-255].

Chooses the BOOT method that best suits your needs.

Enter the IP address.

Enter the Subnet mask.

Enter the Gateway address.

See .

[000-255].

[000-255]

Node Name

WINS Config Auto*

WINS Server (Primary)

DNS Server (Primary)

APIPA On*

Setup Wizard — — You can manually

WPS/AOSS — — You can easily configure

BRWXXXXXXXXXXXX

Static

000.000.000.000

(Secondary)

000.000.000.000

(Secondary)

000.000.000.000

Off

Enter the Node name.

Chooses the WINS configuration mode.

Specifies the IP address of the primary or secondary server.

Automatically allocates the IP address from the link-local address range.

configure your print server for a wireless network.

your wireless network settings using the onebutton push method.

Network User’s Guide

The factory settings are shown in Bold with an asterisk.

Menu and features

Level1 Level2 Level3 Options Descriptions Page

Network

(Continued)

WPS w/PIN Code

WLAN Status Status — You can see the current

MAC Address — — You can see your

WLAN Enable — On

Network Reset — — Restore all network

— — You can easily configure

your wireless network settings using WPS with a PIN code.

wireless network status.

Signal — You can see the current

wireless network signal strength.

SSID — You can see the current

SSID.

Comm. Mode — You can see the current

Communication Mode.

machine’s MAC address from the control panel.

Lets you use the wireless

Off*

network connection.

settings to factory default.

See .

Network User’s Guide

The factory settings are shown in Bold with an asterisk.

Menu ( ) (continued) C

Level1 Level2 Level3 Options Descriptions Page

Print Reports XMIT Verify — — Prints these lists and

Quick Dial — Alphabetical

Order

Numerical Order

Fax Journal ——

User Settings ——

Network Config

WLAN Report ——

Caller ID hist.

Machine Info. Serial No. — — Lets you check the serial

Initial Setup Receive Mode — Fax Auto*

Date&Time — — Sets the date and time on

Station ID — Fax:

Tone/Pulse — Tone*

——

Fax/Tel

External TAD

Fax Manual

Name:

reports.

number of your machine.

Choose the Receive Mode that best suits your needs.

the LCD and in the headings of the faxes you send.

Enter your name and fax number to appear on each page you fax.

Choose the dialling mode.

See .

Pulse

Dial Tone — Detection

No Detection*

Compatibility — Normal*

Basic(for VoIP)

Advanced User’s Guide

Quick Setup Guide

The factory settings are shown in Bold with an asterisk.

Turns Dial Tone Detection on or off.

Adjusts the modem speed to help resolve transmission problems.

Menu and features

Level1 Level2 Level3 Options Descriptions Page

Initial Setup

(Continued)

Reset Network — Resets the print server

back to its factory settings, such as the password and IP address information.

Local Language

Speed Dial&Fax

All Settings — Resets all the machine’s

— Chinese*

— Deletes all stored

Speed Dial numbers and faxes, restores the Station ID, Quick Dial List, Transmission Verification Report and Fax Journal back to the factory settings.

settings back to the factory settings.

Always you to change the

English

LCD language.

Advanced User’s Guide

Quick Setup Guide

The factory settings are shown in Bold with an asterisk.

FAX ( ) C

Level1 Level2 Level3 Options Descriptions Page

Fax Resolution

Contrast ——Auto*

Speed Dial Search — Alphabetical

Outgoing Call Send a fax

Caller ID hist.

Advanced Settings

——Standard*

Fine

S.Fine


Light

Dark

Order

Numerical Order

Set Speed Dial

Setup Groups — — You can set up Group

Add to Speed Dial

Delete

Send a fax

Add to Speed Dial

Delete

Broadcasting Add Number — You can send the same

— — Stores Speed Dial

— — You can choose a number

Speed Dial Alphabetical

Order

Sets the resolution for outgoing faxes.

Changes the lightness or darkness of faxes you send.

You can dial by pressing only a few keys (and Start).

numbers, so you can dial by pressing only a few keys (and Start).

numbers for broadcasting.

from the Outgoing Call history and then send a fax to it, add it to Speed Dial, or delete it.

from the Caller ID history and then send a fax to it, add it to Speed Dial, or delete it.

fax message to more than one fax number.

See .

Numerical Order

Complete —

Real Time TX — On

Off*

Overseas Mode — On

Off*

Glass ScanSize

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

— Letter

A4*

You can send a fax without using the memory.

If you are having difficulty sending faxes overseas, set this to On.

Sets the glass scan size for faxes.

Menu and features

Level1 Level2 Level3 Options Descriptions Page

Set New Default

Factory Reset — — — You can restore all

— — — You can save your fax

settings.

settings back to the factory default.

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

See .

SCAN ( ) C

Level1 Option1 Option2 Option3 Descriptions Page

Scan to File — — — You can scan a

monochrome or a color document into your computer.

Scan to E-mail

Scan to OCR

(Available after Presto! PageManager is downloaded and installed for Macintosh users. See Accessing

Brother Support (Macintosh)

uu page 5.)

Scan to Image — — — You can scan a color

Web Service

(Appears when you install Web Services Scanner, which is displayed in your computer’s

Windows Explorer.)

— — — You can scan a

monochrome or a color document into your E-mail application.

— — — You can have your text

document converted to an editable text file.

picture into your graphics application.

Scan — — You can scan data by

Scan for E-mail ——

Scan for OCR ——

Scan for Fax ——

Scan for Print ——

using the Web Services protocol.

See .

Software User’s Guide

The factory settings are shown in Bold with an asterisk.

COPY ( ) C

Level1 Level2 Level3 Options Descriptions Page

Quality ——Fast

Normal*

Best

Paper Type ——Plain Paper*

Inkjet Paper

Brother BP71

Brother BP61

Other Glossy

Transparency

Paper Size ——A4*

10x15cm

Letter

Enlarge/Reduce

100%* —— —

Enlarge —

Reduce — 97% LTRiA4

198% 10x15cmiA4

186% 10x15cmiLTR

141% A5iA4

93% A4iLTR

83% LGLiA4

Choose the Copy resolution for the next copy.

Choose the paper type that matches the paper in the tray.

Choose the paper size that matches the paper in the tray.

You can choose the enlargement ratio for the next copy.

You can choose the reduction ratio for the next copy.

See .

69% A4iA5

47% A4i10x15cm

Fit to Page — — Your machine will adjust

the size automatically to the paper size you set.

Custom(25-400%)

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

— — You can choose the

enlargement or reduction ratio for your type of document.

Menu and features

Level1 Level2 Level3 Options Descriptions Page

Density ——

Stack/Sort ——Stack*

Page Layout ——Off(1in1)*

-2

-1

Sort

2in1(P)

2in1(L)

2in1(ID)

4in1(P)

4in1(L)

Adjusts the density of copies.

You can choose to stack or sort multiple copies.

You can make N in 1, 2 in 1 ID, or Poster copies.

See .

Poster (2x1)

Poster (2x2)

Poster (3x3)

Set New Default

— — — You can save your copy

settings.

Factory Reset — — — You can restore all the

settings back to the factory default.

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

Speed Dial ( ) C

Level1 Level2 Level3 Options Descriptions Page

Search ——Alphabetical

Order

Numerical Order

Set Speed Dial

———Stores Speed Dial

You can search for names you have stored in the Speed Dial memory.

numbers, so you can dial by pressing only a few keys (and Start).

Setup Groups ———Sets up Group numbers

for broadcasting.

See .

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

Redial/Pause ( ) C

Level1 Level2 Level3 Options Descriptions Page

Outgoing Call

history

Caller ID hist.

Send a fax

Add to Speed Dial

Delete

Send a fax

Add to Speed Dial

Delete

Advanced User’s Guide

The factory settings are shown in Bold with an asterisk.

— — You can choose a number

from the Outgoing Call history and then send a fax to it, add it to Speed Dial, or delete it.

— — You can choose a number

from the Caller ID history and then send a fax to it, add it to Speed Dial, or delete it.

See .

Menu and features

Entering Text

When you are setting certain menu selections, such as the Station ID, you may need to enter text into the machine. Most dial pad keys have three or four letters printed on keys. The keys for 0, # and l do not have printed letters because they are used for special characters.

Press the appropriate dial pad key the number of times shown in this reference table to access the character you want.

Press

Key

2 ABC2A

3 DEF 3D

4 GH I 4G

5 JKL5J

6 MNO 6M

7 PQRS 7

8 TUV8T

9 WX Y Z 9

one

time

two

times

three

times

four

times

five

times

Inserting spaces C

To enter a space in a fax number, press c once between numbers. To enter a space in a name, press c twice between characters.

Making corrections C

If you entered an incorrect letter and want to change it, press d to move the cursor under the incorrect character. Then press Clear. Re-enter the correct character. You can also back up and insert letters.

Repeating letters C

If you need to enter a letter that is on the same key as the letter before, press c to move the cursor to the right before you press the key again.

Special characters and symbols C

Press l or # repeatedly until you see the special character or symbol you want.

Press l for (space) ! " # $ % & ' ( ) + , - . /

Press # for : ; < = > ? @ [ ] ^ _

Note

Specifications D

General D

This chapter provides a summary of the machines’ specifications. For additional specifications visit http://www.brother.com/

Printer Type Inkjet

for details.

Print Head Mono:

Color:

Memory Capacity 40 MB

LCD (Liquid Crystal Display)

Power Source AC 220 to 240 V 50/60 Hz

Power Consumption

Measured when the machine is connected to the USB interface.

When using ADF, resolution: standard / document: ISO/IEC 24712 printed pattern.

1.9 in. (49.0 mm) STN Color LCD

Copying Mode:

Ready Mode: Approx. 6 W

Sleep Mode: Approx. 2.5 W

Off: Approx. 0.45 W

Piezo with 210 nozzles  1
