Brother MFC-9970CDW User Guide

Download

BASIC USER’S GUIDE

MFC-9970CDW

Version A

UK/IRE

If you need to call Customer Service

Please complete the following information for future reference:

Model Number: MFC-9970CDW

Serial Number:

Date of Purchase:

Place of Purchase:

The serial number is on the back of the unit. Retain this User’s Guide with your sales receipt as a permanent record of your purchase, in the event of theft, fire or warranty service.

http://www.brother.com/registration/

User's Guides and where do I find it?

Which manual? What's in it? Where is it?

Safety and Legal Read this Guide first. Please read the

Safety Instructions before you set up your machine. See this Guide for trademarks and legal limitations.

Quick Setup Guide Follow the instructions for setting up

your machine and installing the drivers and software for the operating system and connection type you are using.

Basic User's Guide Learn the basic Fax, Copy, Scan and

Direct Print operations and how to replace consumables. See troubleshooting tips.

Advanced User's Guide Learn more advanced operations: Fax,

Copy, security features, printing reports and performing routine maintenance.

Software User's Guide Follow these instructions for Printing,

Scanning, Network Scanning, Remote Setup, PC-Fax, and using the Brother ControlCenter utility.

Network Glossary This Guide provides basic information

about advanced network features of Brother machines along with explanations about general networking and common terms.

Printed / In the box

For HUN/BUL/ROM/POL/SVK/CZE: PDF file / Documentation CD-ROM / In the box

PDF file / Documentation CD-ROM / In the box

Network User's Guide This Guide provides useful information

about wired and wireless network settings and security settings using the Brother machine. You can also find supported protocol information for your machine and detailed troubleshooting tips.

PDF file / Documentation CD-ROM / In the box

(BASIC USER’S GUIDE)

1 General information 1

Using the documentation .......................................................................................1

Symbols and conventions used in the documentation ....................................1

Accessing the Advanced User’s Guide, Software User’s Guide and

Network User’s Guide.........................................................................................2

Viewing Documentation...................................................................................2

Accessing Brother Support (Windows

Accessing Brother Support (Macintosh) ................................................................4

Control panel overview ..........................................................................................6

LCD Touchscreen............................................................................................8

Basic Operations .............................................................................................9

Volume settings ...................................................................................................10

Ring volume...................................................................................................10

Beeper volume ..............................................................................................10

Speaker volume.............................................................................................10

2 Loading paper 11

Loading paper and print media ............................................................................11

Loading paper in the standard paper tray......................................................11

Loading paper in the multi-purpose tray (MP tray) ........................................13

Unscannable and unprintable areas ..............................................................17

Paper settings......................................................................................................18

Paper Size and Type .....................................................................................18

Tray Use in copy mode..................................................................................19

Tray Use in fax mode ....................................................................................19

Tray Use in print mode ..................................................................................20

Acceptable paper and other print media..............................................................21

Recommended paper and print media ..........................................................21

Type and size of paper ..................................................................................21

Handling and using special paper .................................................................23

)................................................................4

3 Loading documents 26

How to load documents .......................................................................................26

Using the automatic document feeder (ADF) ................................................26

Using the scanner glass ................................................................................27

4 Sending a fax 28

How to send a fax ................................................................................................28

Faxing Letter/Legal/Folio size documents from the scanner glass................29

Colour fax transmission.................................................................................30

Cancelling a fax in progress ..........................................................................30

Transmission verification report.....................................................................30

5 Receiving a fax 32

Receive modes ....................................................................................................32

Choosing the receive mode...........................................................................32

Using receive modes ...........................................................................................33

Fax Only ........................................................................................................33

Fax/Tel...........................................................................................................33

Manual...........................................................................................................33

External TAD .................................................................................................33

Receive Mode settings ........................................................................................34

Ring Delay.....................................................................................................34

F/T Ring Time (Fax/Tel mode only)...............................................................34

Fax Detect .....................................................................................................35

6 Telephone and external devices 36

Telephone line services .......................................................................................36

Setting the telephone line type ......................................................................36

Connecting an external TAD................................................................................37

Connections...................................................................................................37

Recording an outgoing message (OGM).......................................................38

Multi-line connections (PBX) .........................................................................38

External and extension telephones...................................................................... 39

Connecting an external or extension telephone ............................................39

Operation from external or extension telephones..........................................39

For Fax/Tel mode only...................................................................................39

Using extension telephones (U.K. only) ........................................................39

Using a non-Brother cordless external handset ............................................40

Using Remote Codes ....................................................................................41

7 Dialling and storing numbers 42

How to dial...........................................................................................................42

Manual dialling............................................................................................... 42

One Touch dialling.........................................................................................42

Speed dialling ................................................................................................42

Search ...........................................................................................................43

LDAP search .................................................................................................43

Fax redial.......................................................................................................43

Storing numbers ..................................................................................................44

Storing a pause .............................................................................................44

One Touch and Speed Dial Storage Options ................................................45

Storing One Touch Dial numbers ..................................................................46

Storing Speed Dial numbers..........................................................................48

Changing or Deleting One Touch and Speed Dial numbers .........................49

Tone or Pulse ................................................................................................50

8 Making copies 51

How to copy.........................................................................................................51

Stop copying..................................................................................................51

Copy settings.................................................................................................51

iii

9 Printing data from a USB Flash memory drive or digital camera

supporting mass storage 52

Creating a PRN or PostScript® 3™ file for direct printing ....................................52

Printing data directly from the USB Flash memory drive or digital camera

supporting mass storage ..................................................................................53

Changing the default settings for direct print .................................................54

10 How to print from a computer 55

Printing a document.............................................................................................55

11 How to scan to a computer 56

Scanning a document as PDF file using ControlCenter4 (Windows®) ................56

Changing the SCAN key settings ........................................................................59

Before scanning.............................................................................................59

SCAN key settings.........................................................................................59

Scanning using the SCAN key ......................................................................61

A Routine maintenance 62

Replacing the consumable items.........................................................................62

Replacing a Toner cartridge ..........................................................................66

Replacing the drum unit.................................................................................72

Replacing the belt unit ...................................................................................78

Replacing the waste toner box ......................................................................84

Cleaning and Checking the machine ...................................................................91

Cleaning the outside of the machine .............................................................91

Cleaning the scanner glass ...........................................................................92

Cleaning the laser scanner windows .............................................................93

Cleaning the corona wires .............................................................................97

Cleaning the drum unit ................................................................................101

Cleaning the paper pick-up rollers...............................................................107

Calibration ...................................................................................................108

Auto Registration.........................................................................................109

Manual Registration.....................................................................................110

Frequency (Colour Correction) ....................................................................110

B Troubleshooting 111

Error and maintenance messages .....................................................................111

Transferring your faxes or Fax Journal report .............................................118

Document jams..................................................................................................119

Document is jammed in the top of the ADF unit ..........................................119

Document is jammed under the document cover ........................................119

Removing small documents jammed in the ADF.........................................120

Document is jammed at the output tray.......................................................120

Paper jams.........................................................................................................121

Paper is jammed in the MP tray ..................................................................121

Paper is jammed in paper tray 1 or tray 2 ...................................................122

Paper is jammed at the back of the machine .............................................. 123

Paper is jammed inside the machine........................................................... 125

Paper is jammed underneath paper tray 1 ..................................................129

If you are having difficulty with your machine ....................................................132

Setting Dial Tone detection .........................................................................141

Telephone line interference / VoIP ..............................................................141

Improving the print quality..................................................................................142

Machine Information ..........................................................................................149

Checking the Serial Number........................................................................149

Reset functions............................................................................................149

How to reset the machine............................................................................150

C Menu and features 151

On-screen programming....................................................................................151

Menu table...................................................................................................151

MENU button and mode keys............................................................................151

Menu table......................................................................................................... 152

Entering text ......................................................................................................187

D Specifications 188

General..............................................................................................................188

Document Size ..................................................................................................190

Print media.........................................................................................................191

Fax.....................................................................................................................193

Copy ..................................................................................................................194

Scanner .............................................................................................................195

Printer................................................................................................................196

Interfaces...........................................................................................................197

Direct Print feature.............................................................................................198

Scan to USB feature..........................................................................................199

Computer requirements ....................................................................................200

Consumable items.............................................................................................202

Network (LAN) ...................................................................................................203

E Index 204

Table of Contents

(ADVANCED USER’S GUIDE)

The Advanced User's Guide explains the following features and operations.

You can view the Advanced User's Guide on the Documentation CD-ROM in the box.

1 General Setup

Memory storage

Automatic daylight savings time

Ecology features

LCD screen

Mode Timer

2 Security features

Secure Function Lock 2.0

Setting Lock

Restricting dialling

3 Sending a fax

Additional sending options

Additional sending operations

Polling overview

4 Receiving a fax

Remote Fax Options (black & white only)

Additional receiving operations

Polling overview

A Routine maintenance

Cleaning and checking the machine

Replacing periodic maintenance parts

Packing and shipping the machine

B Options

Optional paper tray (LT-300CL)

Memory board

C Glossary

D Index

5 Dialling and storing numbers

Telephone line services

Additional dialling operations

Additional ways to store numbers

6 Printing reports

Fax reports

Reports

7 Making copies

Copy settings

General information 1

Using the documentation

Thank you for buying a Brother machine! Reading the documentation will help you make the most of your machine.

Symbols and conventions used in the documentation 1

The following symbols and conventions are used throughout the documentation.

Bold Bold style identifies keys on the

machine control panel or computer screen.

Italics Italicized style emphasizes an

important point or refers you to a related topic.

Courier

New

Courier New font identifies the messages shown on the LCD of the machine.

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injuries.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injuries.

IMPORTANT

IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in damage to property or loss of product functionality.

Electrical Hazard icons alert you to a possible electrical shock.

Hot Surface icons warn you not to touch machine parts that are hot.

Notes tell you how you should respond to a situation that may arise or give tips about how the current operation works with other features.

Chapter 1

Note

Accessing the Advanced User’s Guide, Software User’s Guide and Network User’s Guide

This Basic User's Guide does not contain all the information about the machine such as how to use the advanced features Fax, Copy, Printer, Scanner, PC-Fax and Network. When you are ready to learn detailed information about these operations, read the

Advanced User's Guide, Software User’s Guide, Network User’s Guide, and Network Glossary that are on the

Documentation CD-ROM.

Viewing Documentation 1

a Turn on your computer. Insert the

Documentation CD-ROM into your CD-ROM drive.

c Click your country.

d Point to your language, point to

View Guide, and then click the guide you want to read.

(Windows® users) If the screen does not appear automatically, go to My Computer (Computer), double-click the CD-ROM icon, and then double-click index.html.

b (Macintosh users) Double-click the

Documentation CD-ROM icon, and then double-click index.html.

General information

Note

Presto! PageManager User’s Guide

• (Windows® users only) Your web browser may display a yellow bar at the top of the page that contains a security warning about Active X controls. For the page to be displayed correctly, you must click on

Allow Blocked Content, then click on Yes in the Security Warning dialog box.

• (Windows

users only)1 For faster access, you can copy all user documentation in PDF format to a local folder on your computer. Point to your language, then click Copy to local disk.

Microsoft® Internet Explorer® 6.0 or greater.

How to find Scanning instructions 1

There are several ways you can scan documents. You can find the instructions as follows:

Software User's Guide

 Scanning

 ControlCenter

(Macintosh)

Presto! PageManager must be downloaded and installed before use. See Accessing Brother Support (Macintosh) on page 4 for further instructions.

 The complete Presto! PageManager

User’s Guide can be viewed from the Help section in the Presto! PageManager application.

How to find Network setup instructions

Your machine can be connected to a wireless or wired network. You can find basic setup instructions in the Quick Setup Guide. If your wireless access point or router supports Wi-Fi Protected Setup or AOSS™, you can also follow the steps in the Quick Setup Guide. For more information about network setup please see the Network User's Guide on the Documentation CD-ROM.

 Network Scanning

ScanSoft™ PaperPort™12SE with OCR How-to-Guides

(Windows

)

 The complete ScanSoft™

PaperPort™12SE with OCR How-toGuides can be viewed from the Help section in the ScanSoft™ PaperPort™12SE application.

Chapter 1

Accessing Brother Support (Windows®) 1

You can find all the contacts you will need, such as Web support (Brother Solutions Center) on the Installation CD-ROM.

 Click Brother Support on the main menu.

The following screen will appear:

 To access our website

(http://www.brother.com/ Home Page.

 For the latest news and product support

information (http://solutions.brother.com/ Brother Solutions Center.

 To visit our website for original Brother

Supplies (http://www.brother.com/original/ Supplies Information.

 To access the Brother CreativeCenter

(http://www.brother.com/creativecenter/ for FREE photo projects and printable downloads, click Brother CreativeCenter.

), click Brother

), click

)

Accessing Brother Support (Macintosh) 1

You can find all the contacts you will need, such as Web support (Brother Solutions Center) on the Installation CD-ROM.

 Double-click the Brother Support icon.

The following screen will appear:

 To download and install Presto!

PageManager, click Presto! PageManager.

 To register your machine from the Brother

Product Register Page (http://www.brother.com/registration/ click On-Line Registration.

 For the latest news and product support

information (http://solutions.brother.com/ Brother Solutions Center.

 To visit our website for original Brother

Supplies (http://www.brother.com/original/ Supplies Information.

), click

 To return to the main page, click Back or

if you have finished, click Exit.

General information

Chapter 1

01.01.2011 15:15

Fax

Address Book

Secure Print

Direct Print

Control panel overview 1

1 One Touch keys

These 20 keys give you instant access to 40 previously stored numbers.

21-40 b The 21-40 b lets you access One Touch

numbers 21 to 40 when held down.

2LCD

This is a Touchscreen LCD. You can access the menus and options by pressing buttons displayed on the screen.

3 Mode keys:

FAX

Puts the machine in Fax mode.

SCAN

Puts the machine in Scan mode.

COPY

Puts the machine in Copy mode.

4Dialpad

5Stop/Exit

6Start:

Use these keys to dial telephone and fax numbers and as a keyboard for entering information into the machine.

This function transfers to the touchscreen when you store quick dial numbers.

The # key temporarily switches the dialling mode from Pulse to Tone during a telephone call.

Stops an operation or exits from a menu.

Colour

Lets you start sending faxes or making copies in full colour.

Mono

Lets you start sending faxes or making copies in black & white.

General information

2345

678

01.01.2011 15:15

Fax

Address Book

Secure Print

Direct Print

7 FAX keys:

Tel/R

This key is used to have a telephone conversation after picking up the external handset during the F/T fast double-ring.

When connected to a PBX, you can use this key to gain access to an outside line, to recall an operator, or to transfer a call to another extension.

Redial/Pause

Machine Status Description

Ready Mode

The machine is ready to print, in sleep mode, there is no print data, or the power switch is off.

Receiving Data

The machine is either receiving data from the computer, processing data in memory, or printing data.

Redials the last number called. It also inserts a pause when programming quick dial numbers or when dialling a number manually.

8 Print Data / Job Cancel

Cancels a programmed print job and clears it from the machine’s memory. To cancel multiple print jobs, hold down this key until the

Green (blinking)

Data Remaining

in Memory

Green

Print data remains in the machine memory.

LCD shows Cancel Printing (All).

Also, this key will flash depending on the machine’s status.

Chapter 1

11 10 9 8

2435 6 7

01.01.2011 15:15

Fax

Address Book

Secure Print

Setting Lock

Direct Print

LCD Touchscreen 1

The LCD Touchscreen shows the current machine status when the machine is idle.

1 Date and Time

Lets you see date and time.

2MENU

Lets you access the main menu.

3 Fax duplex (2–sided) receiving indicator

Appears when duplex printing is set to on for received faxes.

4 Secure Print

Lets you access the secure print menu.

Active only when the machine has secure print data.

5 Fax in memory

Shows how many received faxes are in the memory.

6 Wireless Status

In FAX mode and SCAN mode a four level indicator shows the current wireless signal strength if you are using a wireless connection.

8 Direct Print

Lets you print data from a USB flash memory drive or a digital camera supporting mass storage directly to the machine. (See Printing

data directly from the USB Flash memory drive or digital camera supporting mass storage

on page 53.)

Active only when you insert a USB flash memory drive or digital camera in the machine's USB direct interface.

9 Security indicator

Shows machine's security status. Appears when you turn on Secure Function Lock or Setting Lock.

10 Warning icon

Appears when there is an error or maintenance message; press the Warning icon to view it, and then press Stop/Exit to return to the Ready screen.

11 Address Book

Lets you search the number you want to fax/dial/E-mail/I-Fax.

0Max

7 Current Receive Mode

Lets you see the current receive mode.

 Fax (Fax only)

 F/T (Fax/Tel)

 TAD (External TAD)

 Mnl (Manual)

General information

IMPORTANT

General Setup

Fax

Printer

Print Reports

Mode Timer

Tray Setting

Volume

Ecology

General Setup

Backlight

Dim Timer

Light

Off

MENU > General Setup

LCD Settings

Light

Dark

Med

MEMU > General Setup > LCD Settings

Backlight

Basic Operations 1

To operate the Touchscreen use your finger to press the menu or option button directly on the LCD screen.

To display and access all the screen menus or options in a setting, press a b or d c to scroll through them.

Press to return to the previous menu.

DO NOT press the Touchscreen with a sharp object, such as a pen or stylus. It may damage the machine.

The following steps show how to change a setting in the machine. In this example the LCD back light setting is changed from Light to Dark.

a Press MENU.

d Press Backlight.

e Press Dark.

f Press Stop/Exit.

b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display LCD Settings.

Press LCD Settings.

Chapter 1

Volume settings 1

Ring volume 1

You can choose a range of ring volume levels, from High to Off.

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display Volume.

Press Volume.

d Press Ring. e Press Low, Med, High or Off. f Press Stop/Exit.

Beeper volume 1

Speaker volume 1

You can choose a range of speaker volume levels, from High to Off.

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display Volume.

Press Volume.

d Press Speaker. e Press Low, Med, High or Off. f Press Stop/Exit.

When the beeper is on, the machine will beep when you press a key, make a mistake, or after you send or receive a fax. You can choose a range of volume levels, from High to Off.

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display Volume.

Press Volume.

d Press Beeper. e Press Low, Med, High or Off. f Press Stop/Exit.

WARNING

Loading paper 2

Loading paper and print media

The machine can feed paper from the standard paper tray, optional lower tray or multi-purpose tray.

When you put paper into the paper tray, note the following:

 If your application software supports

paper size selection on the print menu, you can select it through the software. If your application software does not support it, you can set the paper size in the printer driver or by pressing the buttons on the Touchscreen.

Loading paper in the standard paper tray 2

You can load up to 250 sheets for Tray 1 and 500 sheets for the optional lower tray (Tray 2). Paper can be loaded up to the maximum paper mark (b b b) on the sliding paper width guide. (For recommended paper to use, see Paper capacity of the paper trays on page 22.)

Printing on plain paper, thin paper or recycled paper from the standard

paper tray (Tray 1) 2

a Pull the paper tray completely out of the

machine.

DO NOT touch the shaded parts shown in the illustration. These rollers may be rotating at high speed.

Chapter 2

b While pressing the green paper-guide

release lever (1), slide the paper guides to fit the paper size you are loading in the tray. Make sure that the guides are firmly in the slots.

d Put paper in the tray and make sure:

 The paper is below the maximum

paper mark (b b b) (1).

Overfilling the paper tray will cause paper jams.

 The side to be printed on must be

face down.

 The paper guides touch the sides of

the paper so it will feed properly.

e Put the paper tray firmly back in the

machine. Make sure that it is completely inserted into the machine.

c Fan the stack of paper well to avoid

paper jams and misfeeds.

f Lift up the support flap (1) to prevent

paper from sliding off the face-down output tray or remove each page as soon as it comes out of the machine.

Loading paper

Loading paper in the multi-purpose tray (MP tray) 2

You can load up to 3 envelopes or special print media in the MP tray or up to 50 sheets of plain paper. Use this tray to print or copy on thick paper, bond paper, glossy paper, labels, or envelopes. (For recommended paper to use, see Paper capacity of the paper trays on page 22.)

Printing on plain paper, bond paper, labels or glossy paper from the MP tray

a Open the MP tray and lower it gently.

b Pull out the MP tray support and unfold

the flap (1).

Chapter 2

Note

c Put paper in the MP tray and make sure:

 The paper stays under the maximum

paper mark (1).

 The top of paper edge is positioned

between the arrows (2).

 The side to be printed on must be

face up with the leading edge (top of the paper) in first.

d Lift up the support flap to prevent paper

from sliding off the face-down output tray, or remove each page as soon as it comes out of the machine.

When you are using glossy paper, put only one sheet at a time in the MP tray to avoid a paper jam.

Loading paper

Printing on envelopes and thick paper from the MP tray 2

Before loading, press the corners and sides of the envelopes to make them as flat as possible.

a Open the MP tray and lower it gently.

b Pull out the MP tray support and unfold

the flap (1).

c Lift up the support flap to prevent

envelopes or thick sheets of paper from sliding off the face-down output tray. If the support flap is closed you should remove each envelope as soon as it comes out of the machine.

d Put up to 3 envelopes or up to 25 sheets

of thick paper (163 g/m

) in the MP tray. If you add more envelopes or paper it may cause a jam. Make sure:

 The top edge of the envelope is

positioned between the arrows (1).

 The side to be printed on must be

face up.

Chapter 2

Note

f Pull down the two grey levers, one on

the left-hand side and one on the righthand side, to the envelope position as shown in the illustration below.

e Open the back cover (Face-up output

tray).

g Close the back cover. h Send the print data to the machine. i When you have finished printing, open

the back cover and reset the two grey levers which were pulled down in step f back to their original positions.

• Remove each printed envelope immediately to prevent a paper jam.

• If your thick paper curls during printing, put only one sheet at a time in the MP tray and open the back cover (face-up output tray) to let the printed pages exit to the face-up output tray.

Loading paper

Unscannable and unprintable areas 2

The figures below show maximum unscannable and unprintable areas. The unscannable and unprintable areas may vary depending on the paper size or settings in the application you are using.

Usage Document

Size

Top (1)

Bottom (1)

Left (2)

Right (2)

Fax (Sending) Letter 3 mm 4 mm

A4 3 mm 3 mm

Copy

a single copy

Letter 4 mm 4 mm

A4 4 mm 4 mm

or a 1 in 1 copy

Scan Letter 3 mm 3 mm

A4 3 mm 3 mm

Print Letter 4 mm 4 mm

A4 4 mm 4 mm

Chapter 2

Note

Paper settings 2

Paper Size and Type 2

When you change the size of paper in the tray, you will also need to change the setting for paper size at the same time so your machine can fit the document or an incoming fax on the page.

You can use the following sizes of paper for printing copies: A4, Letter, Legal, Executive, A5, A5 L, A6, B5, B6 and Folio and the following sizes for printing faxes: A4, Letter, Legal or Folio (8.5 in. × 13 in.).

Following on the paper size setting, you can set up the machine for the type of paper you are using. This will give you the best print quality.

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

e Press d or c to display the paper size

options. Press A4, Letter, Legal,

Executive, A5, A5 L, A6, B5, B6, Folio or Any.

• The Any option appears only when you choose the MP tray.

• If you choose Any for the MP Tray Paper Size: You must choose MP Only for the Tray Use setting. You cannot use the Any Paper Size selection for the MP tray when making N in 1 copies. You must choose one of the other available Paper Size selections for the MP tray.

• A5 L and A6 size are not available for Tray#2.

f Press Thin, Plain, Thick, Thicker,

Recycled Paper or Glossy.

g Press Stop/Exit.

c Press a or b to display Tray Setting.

Press Tray Setting.

d Do one of the following:

 To set the paper type for the

MP Tray press a or b to display MP Tray.

Press MP Tray

 To set the paper type for Tray#1

press a or b to display Tray#1.

Press Tray#1

 To set the paper type for Tray#2

press a or b to display Tray#2.

Press Tray#2 optional tray.

The Tray#2 button will be selectable if the optional tray is inst alled.

if you installed the

You can choose Glossy for the MP Tray.

Loading paper

Note

Tray Use in copy mode 2

You can change the priority tray that the machine will use for printing copies.

When you choose Tray#1 Only, MP Only

or Tray#2 Only paper only from that tray. If the selected tray is out of paper, No Paper will appear on the LCD. Insert the paper in the empty tray.

To change the tray setting follow the instructions below:

, the machine pulls the

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display Tray Setting.

Press Tray Setting.

d Press a or b to display

Tray Use:Copy. Press Tray Use:Copy.

e Press Tray#1 Only, Tray#2 Only

MP Only, MP>T1>T2

The Tray#2 Only or T2 appears only if the optional tray is installed.

or T1>T21>MP.

f Press Stop/Exit.

• When loading the documents in the ADF and MP>T1>T2 or T1>T2>MP is selected, the machine looks for the tray with the most suitable paper and pulls paper from that tray. If no tray has suitable paper, the machine pulls paper from the higher priority tray.

Tray Use in fax mode 2

You can change the default tray that the machine will use for printing received faxes.

When you choose Tray#1 Only, MP Only

or Tray#2 Only paper only from that tray. If the selected tray is out of paper, No Paper will appear on the LCD. Insert the paper in the empty tray.

When you choose T1>T2 pulls paper from Tray #1 until it is empty, then from Tray #2, and then from the MP tray.

When you choose MP>T1>T2 pulls paper from the MP tray until it is empty, then from Tray #1, and then from Tray #2.

• You can use four sizes of paper for printing faxes: A4, Letter, Legal or Folio. When a suitable size is not in any of the trays received faxes will be stored in the machine’s memory and Size mismatch will appear on the LCD. (For details, see

Error and maintenance messages on page 111.)

• If the tray is out of paper and received faxes are in the machine’s memory, No Paper will appear on the LCD. Insert paper in the empty tray.

, the machine pulls the

>MP, the machine

, the machine

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display Tray Setting.

Press Tray Setting.

• When using the scanner glass, your document is copied from the higher priority tray even if more suitable paper is in another paper tray.

d Press a or b to display Tray Use:Fax.

Press Tray Use:Fax.

e Press Tray#1 Only, Tray#2 Only

MP Only, MP>T1>T2

The Tray#2 Only or T2 appears only if the optional tray is installed.

or T1>T21>MP.

f Press Stop/Exit.

Chapter 2

Tray Use in print mode 2

You can change the default tray the machine will use for printing from your computer.

a Press MENU. b Press a or b to display

General Setup. Press General Setup.

c Press a or b to display Tray Setting.

Press Tray Setting.

d Press a or b to display

Tray Use:Print. Press Tray Use:Print.

e Press Tray#1 Only, Tray#2 Only

MP Only, MP>T1>T2

The Tray#2 Only or T2 appears only if the optional tray is inst alled.

or T1>T21>MP.

f Press Stop/Exit.

Loading paper

Acceptable paper and other print media 2

Print quality may vary according to the type of paper you are using.

You can use the following types of print media: thin paper, plain paper, thick paper, bond paper, recycled paper, glossy paper, labels or envelopes.

For best results, follow the instructions below:

 DO NOT put different types of paper in the

paper tray at the same time because it may cause paper jams or misfeeds.

 For correct printing, you must choose the

same paper size from your software application as the paper in the tray.

 Avoid touching the printed surface of the

paper immediately after printing.

 Before you buy a lot of paper, test a small

quantity to make sure the paper is suitable.

Recommended paper and print media 2

Paper Type Item

Plain paper

Recycled Paper

Labels Avery laser label L7163

Envelope Antalis River series (DL)

Glossy Paper

Xerox Premier TCF 80 g/m

Xerox Business 80 g/m

Xerox Recycled Supreme

80 g/m

International Paper Rey

Color Laser Gloss 140g/m

Type and size of paper 2

The machine feeds paper from the installed standard paper tray, multi-purpose tray or optional lower tray.

The name for the paper trays in the printer driver in this Guide are as follows: 2

Tray and optional unit Name

Standard paper tray Tray 1

Multi-purpose tray MP Tray

Optional lower tray Tray 2

Chapter 2

Paper capacity of the paper trays 2

Paper size Paper types No. of sheets

Paper Tray (Tray 1)

A4, Letter, Legal, B5, Executive, A5,

Plain paper, Thin paper and Recycled paper

up to 250 [80 g/m

]

A5 (Long Edge), A6, B6,

Folio

Multi-purpose Tray (MP Tray)

Width: 69.8 to 216 mm

Length: 116 to 406.4 mm

Plain paper, Thin paper, Thick paper, Thicker paper, Bond paper,

50 sheets [80 g/m

3 Envelopes

1 Glossy paper

]

Recycled paper, Envelopes, Labels and Glossy paper

Optional Lower Tray (Tray 2)

Folio size is 8.5 in. × 13 in. (215.9 mm x 330.2 mm)

A4, Letter, Legal, B5, Executive, A5, B6,

Folio

Plain paper, Thin paper and Recycled paper

up to 500 [80 g/m

]

Recommended paper specifications 2

The following paper specifications are suitable for this machine.

Basis weight

75-90 g/m

Thickness 80-110 μm

Roughness Higher than 20 sec.

Stiffness

90-150 cm

Grain direction Long grain

Volume resistivity

Surface resistivity

Filler

10e

CaCO

Ash content Below 23 wt%

Brightness Higher than 80%

Opacity Higher than 85%

/100

-10e11 ohm

-10e12 ohm-cm

(Neutral)

 Use paper made for plain paper copying.

 Use paper that is 75 to 90 g/m

 Use long grain paper with a neutral Ph value, and a moisture content of approx. 5%.

 This machine can use recycled paper that meets DIN 19309 specifications.

Loading paper

IMPORTANT

Handling and using special paper 2

The machine is designed to work well with most types of xerographic and bond paper. However, some paper variables may have an effect on print quality or handling reliability. Always test samples of paper before purchasing to ensure desirable performance. Store paper in its original packaging and keep it sealed. Keep the paper flat and away from moisture, direct sunlight and heat.

Some important guidelines when selecting paper are:

 DO NOT use inkjet paper because it may

cause a paper jam or damage your machine.

 Preprinted paper must use ink that can

withstand the temperature of the machine’s fusing process 200 degrees centigrade (392 degrees Fahrenheit).

 If you use bond paper, paper having a

rough surface or paper that is wrinkled or creased, the paper may exhibit degraded performance.

 When you are using glossy paper, put only

one sheet at a time in the MP tray to avoid a paper jam.

Types of paper to avoid 2

Some types of paper may not perform well or may cause damage to your machine.

DO NOT use paper:

• that is highly textured

• that is extremely smooth or shiny

• that is curled or warped

1 A curl of 2 mm or greater may cause

jams to occur.

• that is coated or has a chemical finish

• that is damaged, creased or folded

• that exceeds the recommended weight specification in this guide

• with tabs and staples

• with letterheads using low temperature dyes or thermography

• that is multipart or carbonless

• that is designed for inkjet printing

If you use any of the types of paper listed, they may damage your machine. This damage is not covered under any Brother warranty or service agreement.

Chapter 2

IMPORTANT

Envelopes 2

Most envelopes designed for laser printers will be suitable for your machine. However, some envelopes may have feed and printquality problems because of the way they have been made. A suitable envelope should have edges with straight, well-creased folds and the leading edge should not be thicker than two sheets of paper. The envelope should lie flat and not be of baggy or flimsy construction. You should buy quality envelopes from a supplier who understands that you will be using the envelopes in a laser machine.

We recommend that you print a test envelope to make sure the print results are what you want.

Types of envelopes to avoid 2

DO NOT use envelopes:

• that are damaged, curled, wrinkled or an unusual shape

• that are extremely shiny or textured

• with windows, holes, cut-outs or perforations

• with glue on surface as shown in figure below

• with double flaps as shown in figure below

• with sealing flaps that are not folded down when purchased

• with sealing flaps as shown in figure below

• with clasps, staples, snaps or tie strings

• with self-adhesive closures

• that are of a baggy construction

• that are not sharply creased

• that are embossed (have raised writing on them)

• that were previously printed by a laser machine

• that are pre-printed on the inside

• that cannot be arranged neatly when stacked

• that are made of paper that weighs more than the paper weight specifications for the machine

• with edges that are not straight or consistently square

• with each side folded as shown in figure below

If you use any of the types of envelopes listed above, they may damage your machine. This damage may not be covered under any Brother warranty or service agreement.

Labels 2

IMPORTANT

The machine will print on most types of labels designed for use with a laser machine. Labels should have an adhesive that is acrylic-based since this material is more stable at the high temperatures in the fuser unit. Adhesives should not come in contact with any part of the machine, because the label stock may stick to the drum unit or rollers and cause jams and print quality problems. No adhesive should be exposed between the labels. Labels should be arranged so that they cover the entire length and width of the sheet. Using labels with spaces may result in labels peeling off and causing serious jams or print problems.

All labels used in this machine must be able to withstand a temperature of 200 degrees centigrade (392 degrees Fahrenheit) for a period of 0.1 seconds.

Loading paper

Types of labels to avoid 2

Do not use labels that are damaged, curled, wrinkled or an unusual shape.

• DO NOT feed part used label sheets. The exposed carrier sheet will damage your machine.

• Label sheets should not exceed the paper weight specifications described in this User’s Guide. Labels exceeding this specification may not feed or print correctly and may cause damage to your machine.

• DO NOT reuse or insert labels that have previously been used or are missing a few labels on the sheet.

IMPORTANT

Note

Loading documents 3

How to load documents

You can send a fax, make copies, and scan from the ADF (Automatic Document Feeder) and the scanner glass.

Using the automatic document feeder (ADF) 3

The ADF can hold up to 50 pages and feeds each sheet individually. Use standard

80 g/m before putting them in the ADF.

Document Sizes Supported 3

paper and always fan the pages

• To scan documents that are not suitable for the ADF, see Using the scanner glass on page 27.

• It is easier to use the ADF if you are loading a multiple page document.

• Make sure documents with correction fluid or written with ink are completely dry.

a Unfold the ADF document support (1).

Lift up and unfold the ADF document output support flap (2).

Length: 147.3 to 356.0 mm

Width: 147.3 to 215.9 mm

Weight:

64 to 90 g/m

How to load documents 3

• DO NOT leave thick documents on the scanner glass. If you do this, the ADF may jam.

• DO NOT use paper that is curled, wrinkled, folded, ripped, stapled, paperclipped, pasted or taped.

• DO NOT use cardboard, newspaper or fabric.

• To avoid damaging your machine while using the ADF, DO NOT pull on the document while it is feeding.

b Fan the pages well. c Place your document face up top edge

first in the ADF until the LCD display message changes and you feel it touch the feed rollers.

d Adjust the paper guides (1) to fit the

width of your document.

Note

• To avoid damaging your machine while

Note

IMPORTANT

using the ADF, DO NOT pull on the document while it is feeding.

• To scan non-standard documents, see Using the scanner glass on page 27.

Using the scanner glass 3

You can use the scanner glass to fax, copy or scan pages of a book one page at a time.

Document Sizes Supported 3

Length: Up to 355.6 mm

Width: Up to 215.9 mm

Weight: Up to 2.0 kg

Loading documents

b Using the document guidelines on the

left and top, place the document face down in the upper left corner of the

scanner glass.

How to load documents 3

To use the scanner glass, the ADF must be empty.

a Lift the document cover.

c Close the document cover.

If the document is a book or is thick, do not slam or press on the cover.

Note

Duplex Fax

Address Book

Fax

Resolution

Off Standard

FAX

Sending a fax 4

How to send a fax 4

The following steps show how to send a fax.

a When you want to send a fax, or change

fax send or receive settings, press the

(FAX) key to illuminate it in blue.

 The LCD shows:

b Do one of the following to load your

document:

 Place the document face up in the

ADF. (See Using the automatic document feeder (ADF) on page 26.)

 Load your document face down on

the scanner glass. (See Using the scanner glass on page 27.)

To send colour faxes with multiple pages use the ADF.

c Set the scanner glass size, fax

resolution or contrast if you want to change them.

For more advanced fax sending operations and settings, see Sending a

fax in Chapter 3 of the Advanced User's Guide:

• Broadcasting

• Duplex Fax (2-sided fax layout)

• Delayed Fax

• Batch TX

• Real Time TX

• Polled TX

• Overseas Mode

• Fax Resolution

• Contrast

• Glass ScanSize

• Coverpage Setup

• Coverpage Note

• Set New Default

• Factory Reset

d Choose one of the options below:

 If you want to send a single-sided

document, go to step e.

 If you want to send a 2-sided

document, you need to choose the duplex scanning format of your 2-sided document. Press Duplex Fax and choose

DuplexScan :LongEdge or DuplexScan :ShortEdge.

You can send 2-sided documents from the ADF.

Sending a fax

Note

e Enter the fax number using the dial pad.

You can also enter the fax number on the LCD by pressing Address Book and Send a fax, or you can press an One Touch key on the machine’s control panel. (For details, see How to dial on page 42.)

f Press Mono Start or Colour Start.

Faxing from the ADF

 The machine starts scanning the

document.

Faxing from the scanner glass

If Real Time TX is On, the machine will send the document without asking if there are additional pages to scan.

 If you press Mono Start, the

machine starts scanning the first page.

Do one of the following:

• To send a single page, press No

(or press Mono Start again). The machine starts sending the document.

Faxing Letter/Legal/Folio size documents from the scanner glass 4

When faxing Letter/Legal/Folio size documents, you will need to set the scan glass size to Letter or Legal/Folio; otherwise, a portion of your faxes will be missing.

a Press (FAX). b Press d or c to display

Glass ScanSize. Press Glass ScanSize.

c Press Letter or Legal/Folio. d Press Stop/Exit.

You can save the setting you use most often by setting it as the default. (See

Setting your changes as the new default in Chapter 3 of the Advanced User's Guide.)

• To send more than one page, press Yes and place the next page on the scanner glass. Press Mono Start. The machine starts scanning the page. (Repeat this step for each additional page.)

 If you press Colour Start and

Yes (Color fax), the machine starts sending the document.

To cancel, press Stop/Exit.

Chapter 4

Colour fax transmission 4

Your machine can send a colour fax to machines that support this feature. Colour faxes cannot be stored in the machine's memory. When you send a colour fax, the machine will send it in real time (even if Real Time TX is set to Off).

Cancelling a fax in progress 4

Press Stop/Exit to cancel the fax. If you press Stop/Exit while the machine is dialling or sending, the LCD will show Cancel Job?.

Press Yes to cancel the fax.

Transmission verification report 4

You can use the Transmission Verification Report as proof that you sent a fax. This report lists the receiving party’s name or fax number, the time and date of transmission, duration of transmission, number of pages sent, and whether or not the transmission was successful.

There are several settings available for the Transmission Verification Report:

 On: Prints a report after every fax you

send.

 On+Image: Prints a report after every fax

you send. A portion of the fax’s first page appears on the report.

 Off: Prints a report if your fax is

unsuccessful due to a transmission error. Off is the default setting.

 Off+Image: Prints a report if your fax is

unsuccessful due to a transmission error. A portion of the fax’s first page appears on the report.

a Press MENU. b Press a or b to display Fax.

Press Fax.

c Press a or b to display

Report Setting. Press Report Setting.

d Press XMIT Report. e Press On, On+Image, Off or

Off+Image.

f Press Stop/Exit.

Note

• If you choose On+Image or Off+Image, the image will only appear on the Transmission Verification Report if Real Time Transmission is set to Off. (See Real Time Transmission in Chapter 3 of the Advanced User's Guide.)

• If your transmission is successful, OK will appear next to RESULT on the Transmission Verification Report. If transmission is not successful, ERROR will appear next to RESULT.

Sending a fax

Receiving a fax 5

Do you want to use the telephone features of your machine (if available) or an external telephone or external telephone answering device connected on the same line as the machine?

Yes

Fax Only

Manual

Yes

External TAD

Fax/Tel

Are you using the voice message function of an external telephone answering device?

Do you want the machine to answer fax and telephone calls automatically?

Yes

Receive modes 5

You must choose a receive mode depending on the external devices and telephone services you have on your line.

Choosing the receive mode 5

By default, your machine will automatically receive any faxes that are sent to it. The diagrams below will help you choose the correct mode. (For more detailed information about the receive modes, see Using receive modes on page 33.)

To set the receive mode follow the instructions below.

a Press MENU. b Press a or b to display Initial Setup.

Press Initial Setup.

c Press a or b to display Receive Mode.

Press Receive Mode.

d Press Fax Only, Fax/Tel, External TAD or Manual. e Press Stop/Exit.

The LCD will display the current receive mode.

Receiving a fax

Using receive modes 5

Some receive modes answer automatically (Fax Only and Fax/Tel). You may want to change the Ring Delay before using these modes. (See Ring Delay on page 34.)

Fax Only 5

Fax Only mode will automatically answer every call as a fax.

Fax/Tel 5

Fax/Tel mode helps you automatically manage incoming calls, by recognising whether they are fax or voice calls and dealing with them in one of the following ways:

 Faxes will be automatically received.

 Voice calls will start the F/T ring to tell you

to pick up the line. The F/T ring is a fast double-ring made by your machine.

(Also see F/T Ring Time (Fax/Tel mode only) on page 34 and Ring Delay on page 34.)

Manual 5

Manual mode turns off all automatic answering functions unless you are using the

BT Call Sign

BT Call Sign is for U.K. only.

To receive a fax in Manual mode lift the handset of the external telephone. When you hear fax tones (short repeating beeps), press Mono Start or Colour Start, and choose Receive to receive the fax. You can also use the Fax Detect feature to receive faxes by lifting a handset on the same line as the machine.

(Also see Fax Detect on page 35.)

feature.

External TAD 5

External TAD mode lets an external answering device manage your incoming calls. Incoming calls will be dealt with in the following ways:

 Faxes will be automatically received.

 Voice callers can record a message on the

external TAD.

(For more information see Connecting an external TAD on page 37.)

Chapter 5

Receive Mode settings 5

Ring Delay 5

The Ring Delay setting sets the number of times the machine rings before it answers in Fax Only and Fax/Tel modes.

If you have external or extension telephones on the same line as the machine, choose the maximum number of rings. (See Operation from external or extension telephones on page 39 and Fax Detect on page 35.)

a Press MENU. b Press a or b to display Fax.

Press Fax.

c Press a or b to display

Setup Receive. Press Setup Receive.

d Press a or b to display Ring Delay.

Press Ring Delay.

F/T Ring Time (Fax/Tel mode only) 5

When somebody calls your machine, you and your caller will hear the normal telephone ring sound. The number of rings is set by the Ring Delay setting.

If the call is a fax, then your machine will receive it; however, if it is a voice call the machine will sound the F/T ring (a fast double-ring) for the time you have set in the F/T Ring Time setting. If you hear the F/T ring it means that you have a voice caller on the line.

Because the F/T ring is made by the machine, extension and external telephones will not ring; however, you can still answer the call on any telephone. (For more information see Using Remote Codes on page 41.)

a Press MENU. b Press a or b to display Fax.

Press Fax.

e Press the button on the LCD to choose

how many times the line rings before the machine answers.

f Press Stop/Exit.

c Press a or b to display

Setup Receive. Press Setup Receive.

d Press a or b to display

F/T Ring Time. Press F/T Ring Time.

e Press how long the machine will ring to

alert you that you have a voice call (20, 30, 40 or 70 seconds).

f Press Stop/Exit.

Fax Detect 5

Note

If Fax Detect is On: 5

The machine can receive a fax automatically, even if you answer the call. When you see Receiving on the LCD or hear a click on the phone line through the handset you are using, just replace the handset. Your machine will do the rest.

If Fax Detect is Off: 5

If you are at the machine and answer a fax call first by lifting the external handset, then press Mono Start or Colour Start, and then press Receive to receive the Fax.

If you answered at an extension telephone press l51. (See Operation from external or extension telephones on page 39.)

Receiving a fax

• If this feature is set to On, but your machine does not connect a fax call when you lift an extension telephone handset, press the fax receive code l51.

• If you send faxes from a computer on the same telephone line and the machine intercepts them, set Fax Detect to Off.

a Press MENU. b Press a or b to display Fax.

Press Fax.

c Press a or b to display

Setup Receive. Press Setup Receive.

d Press a or b to display Fax Detect.

Press Fax Detect.

e Press On or Off. f Press Stop/Exit.

Note

Telephone and external devices 6

Telephone line services

Setting the telephone line type 6

If you are connecting the machine to a line that features a PBX or ISDN to send and receive faxes, it is necessary to change the Telephone Line Type accordingly by completing the following steps. If you are using a line that features a PBX, you can set your machine so that it always accesses the outside line (using the prefix you entered), or accesses the outside line when Tel/R is pressed.

a Press MENU. b Press a or b to display

Initial Setup. Press Initial Setup.

c Press a or b to display

Phone Line Set. Press Phone Line Set.

d Press PBX, ISDN (or Normal). e Do one of the following:

 If you chose ISDN or Normal, go to

step i.

 If you chose PBX, go to step f.

g Do one of the following:

 If you want to change the current

prefix number, press Dial Prefix and go to step h.

 If you do not want to change the

current prefix number, go to step i.

h Enter the prefix number (up to 5 digits)

on the dial pad. Press OK.

You can use the numbers and symbols 0 to 9, #, l and !. (You cannot use ! with any other numbers and symbols.)

i Press Stop/Exit.

PBX and TRANSFER 6

The machine is initially set to Normal, which lets the machine connect to a standard PSTN (Public Switched Telephone Network) line. However, many offices use a central telephone system or Private Branch Exchange (PBX). Your machine can be connected to most types of PBX. The machine’s recall feature supports timed break recall only (TBR). TBR will work with most PBX systems allowing you to gain access to an outside line, or transfer calls to another extension. The feature works when Tel/R is pressed.

f Press On or Always.

• If you choose On, pressing Tel/R will let

you access an outside line.

• If you choose Always, you can access an

outside line without pressing Tel/R.

Telephone and external devices

Note

(Example for U.K.)

Connecting an external TAD 6

You can connect an external Telephone Answering Device (TAD) to the same line as your machine. When the TAD answers a call, your machine will “listen” for the CNG (fax calling) tones sent by a sending fax machine. If it hears them it will take over the call and receive the fax. If it does not hear them, it will let your TAD take a voice message and the display will show Telephone.

The external TAD must answer within four rings (we recommend you set it to two rings). This is because your machine cannot hear the CNG tones until the external TAD has picked up the call. The sending machine will send CNG tones for only eight to ten seconds longer. We do not recommend using the toll saver feature on your external TAD if it needs more than four rings to activate it.

Connections 6

The external TAD must be connected as shown in the illustration below.

1TAD

a Set your external TAD to one or two

rings. (The machine’s Ring Delay setting does not apply.)

b Record the outgoing message on your

external TAD.

c Set the TAD to answer calls. d Set the Receive Mode to

External TAD. (See Choosing the receive mode on page 32.)

If you have problems receiving faxes, reduce the ring delay setting on your external TAD.

Chapter 6

Note

Recording an outgoing message (OGM) 6

a Record 5 seconds of silence at the

beginning of your message. This allows your machine time to listen for fax tones.

b Limit your speaking to 20 seconds. c End your 20-second message by giving

your Remote Activation code for people sending manual faxes. For example: “After the beep, leave a message or press l51 and Start to send a fax.”

• You need to turn the Remote Codes setting to on to use the Fax Activation Code l51. (See Using Remote Codes on page 41.)

• We recommend beginning your OGM with an initial 5 second silence because the machine cannot hear fax tones over a loud voice. You may try leaving out this pause, but if your machine has trouble receiving, then you should re-record the OGM to include it.

Multi-line connections (PBX) 6

We suggest you ask the company who installed your PBX to connect your machine. If you have a multi line system we suggest you ask the installer to connect the unit to the last line on the system. This prevents the machine being activated each time the system receives telephone calls. If all incoming calls will be answered by a switchboard operator we recommend that you set the Receive Mode to Manual.

We cannot guarantee that your machine will operate properly under all circumstances when connected to a PBX. Any difficulties with sending or receiving faxes should be reported first to the company who handles your PBX.

Telephone and external devices

Note

(Example for U.K.)

External and extension telephones 6

You need to turn the Remote Codes setting to on to use the Remote Activation Code l51 and Remote Deactivation Code #51. (See Using Remote Codes on page 41.)

Connecting an external or extension telephone 6

You can connect a separate telephone directly to your machine as shown in the diagram below.

1 Extension telephone

2 External telephone

When you are using an external telephone, the LCD shows Telephone.

Operation from external or extension telephones 6

If you answer a fax call on an extension telephone, or an external telephone that is correctly connected to the machine through the T-piece connection, you can make your machine take the call by using the Remote Activation code. When you press the Remote Activation code l51 the machine starts to receive the fax.

If you answer a call and no one is on the line: 6

You should assume that you’re receiving a manual fax.

Press l51 and wait for the chirp or until the LCD shows Receiving, and then hang up.

You can also use the Fax Detect feature to make your tactically take the call. (See Fax Detect on page 35.)

For Fax/Tel mode only 6

When the machine is in Fax/Tel mode, it will use the F/T Ring Time (fast double-ringing) to alert you to pick up a voice call.

Lift the external telephone’s handset, and then press Tel/R to answer.

If you are at an extension telephone, you will need to lift the handset during the F/T Ring Time and then press #51 between the fast double-ringings. If no one is on the line, or if someone wants to send you a fax, send the call back to the machine by pressing l51.

Using extension telephones (U.K. only) 6

Your premises may already be wired with parallel extension telephones (those connected to sockets in other rooms in the building), or perhaps you intend to add extension telephones to your line. While the simplest arrangement is a parallel connection, there are some reasons why this arrangement may cause problems.

The most common problem, is someone picking up an extension telephone while the machine is trying to send a fax.

Chapter 6

FAX

(Example for U.K.)

FAX

(Example for U.K.)

Such problems can easily be eliminated, if you arrange modification of your extension wiring circuit, such that extension devices are connected “downstream” of your machine, in a master/slave configuration (see figure 2). In such a configuration, this machine can always detect whether a telephone is in use, so it will not attempt to seize the line during that time. This is known as “telephone off-hook detection”.

The inadvisable configuration is shown in figure 1, and the recommended master/slave configuration is shown in figure 2.

This new connection configuration can be arranged by contacting BT, Kingston upon Hull Telecommunications, your PBX maintainer or a qualified telephone installation company as appropriate. Simply explained, the extension telephone circuit should be terminated on a normal modular plug (BT 431A style), which in turn should be inserted into the modular socket of the white “T”-shaped connector provided as part of the line cord assembly.

Figure 1:

Figure 2: Recommended connection of extension sockets

1 Extension socket

2 Master socket

3 Incoming line

These phones are now connected as external devices as shown on page 39, because they are connected to the fax machine via the T-connector.

Using a non-Brother cordless external handset 6

If your non-Brother cordless telephone is connected to the telephone line cord (see page 39) and you typically carry the cordless handset elsewhere, it is easier to answer calls during the Ring Delay.

1 Extension socket

2 Master socket

3 Incoming line

If you let the machine answer first, you will have to go to the machine so you can press Tel/R to transfer the call to the cordless handset.

Telephone and external devices

Using Remote Codes 6

Remote Activation Code 6

If you answer a fax call on an external or extension telephone, you can tell your machine to receive it by pressing the Remote Activation Code l 51. Wait for the chirping sounds then replace the handset. (See Fax Detect on page 35.) Your caller will have to press start to send the fax.

If you answer a fax call at the external telephone, you can make the machine receive the fax by pressing Mono Start or

Colour Start.

Remote Deactivation Code 6

If you receive a voice call and the machine is in F/T mode, it will start to sound the F/T (fast double-ring) after the initial ring delay. If you pick up the call on an extension telephone you can turn the F/T ring off by pressing #51 (make sure you press this between the rings).

If the machine answers a voice call and fast double-rings for you to take over, you can take the call at the external telephone by pressing Tel/R.

f If you do not want to change the Remote

Activation Code, press on the LCD.

g Press Stop/Exit.

Changing the Remote Codes 6

The preset Remote Activation Code is l51. The preset Remote Deactivation Code is #51. If you are always disconnected when accessing your External TAD, try changing the three-digit remote codes, for example ### and 555.

a Press MENU. b Press a or b to display Fax.

Press Fax.

c Press a or b to display

Setup Receive. Press Setup Receive.

d Press a or b to display Remote Codes.

Press Remote Codes.

e Press On or Off. f If you chose On in step e, enter the new

Remote Activation Code. Press OK.

Turning on the Remote Codes 6

You need to turn the Remote Codes setting to on to use the Fax Receive Code and Telephone Answer Code.

g Enter the new Remote Deactivation

Code. Press OK.

h Press Stop/Exit.

a Press MENU. b Press a or b to display Fax.

Press Fax.

c Press a or b to display

Setup Receive. Press Setup Receive.

d Press a or b to display Remote Codes.

Press Remote Codes.

e Press On.

Note

Dialling and storing numbers 7

How to dial 7

You can dial in any of the following ways.

Manual dialling 7

Use the dial pad to enter all the digits of the telephone or fax number.

One Touch dialling 7

Press the One Touch key that stores the number you want to call. (See Storing One Touch Dial numbers on page 46.)

Speed dialling 7

a Press Address Book. b Press the three-digit number you want

to call. You can also display the numbers in alphabetical order by pressing on the Touchscreen.

c Press Send a fax or

Send a E-mail.

d Press Mono Start or Colour Start.

If the LCD shows Not Registered when you enter or search a Speed Dial number, a number has not been stored at this location.

To dial One Touch numbers 21 to 40, hold down 21-40 as you press the One Touch key.

Dialling and storing numbers

Note

Search 7

You can search alphabetically for names you have stored in the One Touch and Speed Dial memories. (See Storing One Touch Dial

numbers on page 46 and Storing Speed Dial numbers on page 48.)

a Press Address Book. b Press on the Touchscreen. c Press the first few letters of the name on

the Touchscreen. Press OK.

d Press a or b to scroll until you find the

name you are looking for. Press the name you are looking for.

e Press Send a fax or

Send a E-mail.

f Press Mono Start or Colour Start.

Fax redial 7

If you are sending a fax automatically and the line is busy, the machine will automatically redial up to three times at five minute intervals.

If you are sending a fax manually and the line is busy, press Redial/Pause and try it again. You can call the last number dialled, by pressing Redial/Pause.

Redial/Pause only works if you dialled from the control panel.

• If the LCD shows Results cannot be found. when you enter the first few letters of the name, it means that a name for the letter is not stored.

• One Touch Dial number and Speed Dial numbers stored without the name cannot be retrieved by the search function.

LDAP search 7

If the machine is connected to your LDAP server, you can search for information such as fax numbers and E-mail addresses from your server. (For details about how to set up LDAP see the Network User's Guide.)

Chapter 7

Storing numbers 7

You can set up your machine to do the following types of easy dialling: One Touch, Speed Dial and Groups for Broadcasting faxes. You can also specify the default resolution for each One Touch and Speed Dial number. When you dial a quick dial number, the LCD shows the name, if you stored it, or the number. A scan profile can also be stored along with the fax number.

If you lose electrical power, the quick dial numbers stored in the memory will not be lost.

A scan profile is the resolution and other scan settings that you choose when you store a number.

Storing a pause 7

Press Pause to insert a 2.8-second pause between numbers. You can press Pause as many times as needed to increase the length of the pause.

Dialling and storing numbers

Note

One Touch and Speed Dial Storage Options 7

The following chart shows the selections for the settings for One Touch and Speed Dial numbers.

When you store numbers, the LCD instructs you to choose from the options shown in the following steps.

Step 1

Enter Name

Enter the name you want to store

Press OK

Step 2

Select Registration Type

Fax Enter the Fax

IFAX Enter the E-mail

E-Mail Color PDF 100 dpi, 200 dpi,

E-Mail Color JPEG 100 dpi, 200 dpi,

E-Mail Color XPS 100 dpi, 200 dpi,

E-Mail Gray PDF 100 dpi, 200 dpi,

E-Mail Gray JPEG 100 dpi, 200 dpi,

E-Mail Gray XPS 100 dpi, 200 dpi,

E-Mail B&W PDF 200 dpi,

E-Mail B&W TIFF 200 dpi,

Step 3

Enter Number or E-mail Address

Number

Address

Step 4

Select Resolution

Standard, Fine, S.Fine, Photo

Standard, Fine, Photo

300 dpi, 600 dpi

300 dpi

200 x 100 dpi

Step 5

Select File type

PDF, PDF/A, Secure PDF, Signed PDF

• If you choose Signed PDF, you must install a certificate on your machine using Web Based Management. Choose Configure Signed PDF Settings from Administrator Settings in Web Based Management. For how to install a certificate, see the Network User's Guide.

• PDF/A is a PDF file format intended for long-term archiving. This format contains all the necessary information to be able to reproduce the document after long-term storage.

• A Signed PDF helps prevent data tampering and the impersonation of an author by including a digital certificate within the document.

Chapter 7

Note

Storing One Touch Dial numbers 7

Your machine has 20 One Touch keys where you can store 40 fax or telephone numbers or E-mail addresses for automatic dialling. To access numbers 21 to 40, hold down 21-40 as you press the One Touch key.

a Press the One Touch key where you

want to store the number or E-mail address. If a number or E-mail address is not stored there, the LCD shows

Not Registered Register Now?.

Press Yes. Or, you can use the LCD buttons by pressing Address Book, More and Set One Touch Dial, and then enter the number of the One Touch key where you want to store the number or E-mail address and press OK.

c Press d or c to select

Fax, IFAX, E-Mail B&W PDF, E-Mail B&W TIFF, E-Mail Color PDF, E-Mail Color JPEG, E-Mail Color XPS, E-Mail Gray PDF, E-Mail Gray JPEG or E-Mail Gray XPS.

d Enter the telephone, fax number (up to

20 characters each) or E-mail address (up to 60 characters each). Use the chart on Entering text on page 187 to help you enter letters. Press OK.

• If you selected an E-mail Registration

Type in step c and save the E-mail address, you can only use the E-mail address when you are in Scan mode.

• If you selected the IFAX Registration Type

in step c and save the E-mail address, you can only use the E-mail address when you are in Fax mode.

If the One Touch number you choose is already taken, the OK button on the LCD will not work. Choose a different number.

b Do one of the following:

 Enter the name (up to 15 characters)

by pressing the buttons on the Touchscreen. Use the chart on Entering text on page 187 to help you enter letters.

Press OK.

 Press OK to store the number or

E-mail address without a name.

Dialling and storing numbers

Note

e To save a fax/scan resolution along with

the number/E-mail address, go to the appropriate step as shown in the following table.

Option selected in step c Go to step

Fax f

IFAX g

E-Mail Color PDF

hE-Mail Color JPEG

E-Mail Color XPS

E-Mail Gray PDF

iE-Mail Gray JPEG

E-Mail Gray XPS

E-Mail B&W PDF

E-Mail B&W TIFF

• When you do a broadcast and you have saved a scan profile along with the number or E-mail address, the scan profile of the One Touch, Speed Dial or Group number you chose first will be applied to the broadcast.

• For details about the file format, see Using

the Scan key in the Software User's Guide.

f Select the resolution from Standard,

Fine, S.Fine or Photo and go to step l.

i Select the resolution from 100 dpi,

200 dpi or 300 dpi.

 If you chose E-Mail Gray PDF, go

to step k.

 If you chose E-Mail Gray JPEG or

E-Mail Gray XPS, go to step l.

j Select the resolution from 200 dpi or

200 x 100 dpi.

 If you chose E-Mail B&W PDF, go

to step k.

 If you chose E-Mail B&W TIFF, go

to step l.

k Select the PDF type from PDF, PDF/A,

Secure PDF or Signed PDF that will be used to send to your PC.

If you choose Secure PDF, the machine will ask you to enter a fou-digit password using numbers 0-9 before it starts scanning.

l When the LCD displays your settings,

press OK to confirm.

m Press Stop/Exit.

g Select the resolution from Standard,

Fine or Photo and go to step l.

h Select the resolution from 100 dpi,

200 dpi, 300 dpi or 600 dpi.

 If you chose E-Mail Color PDF,

go to step k.

 If you chose E-Mail Color JPEG

or E-Mail Color XPS, go to step l.

Chapter 7

Note

Storing Speed Dial numbers 7

You can store your frequently used numbers as Speed Dial numbers, so that when you dial you will only have to press a few keys (for example: press Address Book, the number you want to call and Send a fax). The machine can store 300 Speed Dial numbers (001-300).

a Press Address Book. b Press More. c Press Set Speed Dial. d Do one of the following:

 Enter the name (up to 15 characters)

by pressing the buttons on the Touchscreen. Use the chart on Entering text on page 187 to help you enter letters.

Press OK.

 Press OK to store the number or

E-mail address without a name.

e Press d or c to select

Fax, IFAX, E-Mail B&W PDF, E-Mail B&W TIFF, E-Mail Color PDF, E-Mail Color JPEG, E-Mail Color XPS, E-Mail Gray PDF, E-Mail Gray JPEG or E-Mail Gray XPS.

f Enter the fax/telephone number (up to

20 characters each) or E-mail address (up to 60 characters each). Use the chart on Entering text on page 187 to help you enter letters. Press OK.

• If you selected an E-mail Registration

Type in step e and save the E-mail address, you can only use the E-mail address when you are in Scan mode.

• If you selected the IFAX Registration Type

in step e and save the E-mail address, you can only use the E-mail address when you are in Fax mode.

g To save a fax/scan resolution along with

the number/E-mail address, go to the appropriate step as shown in the following table.

Option selected in step e Go to step

Fax h

IFAX i

E-Mail Color PDF

jE-Mail Color JPEG

E-Mail Color XPS

E-Mail Gray PDF

kE-Mail Gray JPEG

E-Mail Gray XPS

E-Mail B&W PDF

E-Mail B&W TIFF

• For details about the file format, see the Software User's Guide.

h Select the resolution from Standard,

Fine, S.Fine or Photo and go to step n.

i Select the resolution from Standard,

Fine or Photo and go to step n.

Dialling and storing numbers

Note

j Select the resolution from 100 dpi,

200 dpi, 300 dpi or 600 dpi.

 If you chose E-Mail Color PDF,

go to step m.

 If you chose E-Mail Color JPEG

or E-Mail Color XPS, go to step n.

k Select the resolution from 100 dpi,

200 dpi or 300 dpi.

 If you chose E-Mail Gray PDF, go

to step m.

 If you chose E-Mail Gray JPEG or

E-Mail Gray XPS, go to step n.

l Select the resolution from 200 dpi or

200 x 100 dpi.

 If you chose E-Mail B&W PDF, go

to step m.

 If you chose E-Mail B&W TIFF, go

to step n.

m Select the PDF type from PDF, PDF/A,

Secure PDF or Signed PDF that will be used to send to your PC.

Changing or Deleting One Touch and Speed Dial numbers 7

You can change or delete a One Touch or Speed Dial number that has already been stored.

If the stored number has a scheduled job, such as a delayed fax or a fax forwarding number, it will be dimmed on the LCD. You cannot select the number to make changes or to delete it unless you first cancel the scheduled job. (See Checking and canceling

waiting jobs in chapter 3 of the Advanced User's Guide.)

a Press Address Book. b Press More. c Do one of the following:

 Press Change to edit the name,

number or E-mail address and go to step d.

 Press Delete to delete all

information in a Speed Dial or One Touch number.

If you choose Secure PDF, the machine will ask you to enter a four-digit password using numbers 0-9 before it starts scanning.

n Enter a three-digit Speed Dial location

number (001-300). Press OK.

o When the LCD displays your settings,

press OK to confirm.

p Press Stop/Exit.

Select the number you want to delete by pressing it to display a red check mark.

Press OK.

When Erase This Data? appears, press Yes to accept it.

Go to step h.

d Press a or b to display the number you

want to change. Press the number you want to change.

One Touch Dial numbers begin with l. Speed Dial numbers begin with #.

Chapter 7

Note

e Press Name:

Number/Address: Resolution: or PDF Type:

f Do one of the following:

 If you chose Name:, enter the name

(up to 15 characters) by pressing the buttons on the Touchscreen.

Press OK.

 If you chose Number/Address:,

enter the new number (up to 20 digits) or E-mail address (up to 60 digits) by pressing the buttons on the Touchscreen.

Press OK.

 If you chose Resolution:, press

one of the available resolution options displayed on the Touchscreen.

 If you chose PDF Type:, press one

of the available file type options displayed on the Touchscreen.

Tone or Pulse 7

If you have a Pulse dialling service, but need to send Tone signals (for example, for telephone banking), follow the instructions below. If you have Touch Tone service, you will not need this feature to send tone signals.

a Lift the handset of the external

telephone.

b Press # on the machine’s control panel.

Any digits dialled after this will send tone signals. When you hang up, the machine will return to the Pulse dialling service.

How to change the stored name or number:

If you want to change a character, press d or c to position the cursor under the character you want to change, and then

press . Re-enter the character.

The LCD will display your new setting.

g Do one of the following:

 To finish changing, press OK.

 To change more details, go to

step f.

h Press Stop/Exit.

Note

Enlarge/ Reduce

Quality

Duplex Copy

100% OffAuto

Favorite

Copy

Making copies 8

How to copy 8

The following steps show the basic copy operation. For details about each option, see the Advanced User's Guide.

a When you want to make a copy, press

(COPY) to illuminate it in blue.

 Make sure you are in Copy mode.

 The LCD shows:

c Press Mono Start or Colour Start.

If the LCD shows Please Wait and the machine stops copying while you are making multiple copies, please wait for 30 to 40 seconds until the machine finishes the colour registrations and cleaning process of the belt unit.

Stop copying 8

To stop copying, press Stop/Exit.

Copy settings 8

Press COPY and then press d or c to choose the setting you want. For details about changing the copy settings, see Copy

settings in Chapter 7 of the Advanced User's Guide.

You can change the following copy settings:

You can enter the number of copies you want by pressing the + and buttons on the Touchscreen.

The default setting is Fax mode. You can change the amount of time that the machine stays in Copy mode after the last copy operation. (See Mode Timer in Chapter 1 of the Advanced User's Guide.)

b Do one of the following to load your

document:

 Place the document face up in the

ADF. (See Using the automatic document feeder (ADF) on page 26.)

 Load your document face down on

the scanner glass. (See Using the scanner glass on page 27.)

 Quality

 Enlarge/Reduce

 Duplex Copy

 Tray Use

 Brightness

 Contrast

 Stack/Sort

 Page Layout

 2in1(ID)

 Color Adjust (Saturation)

 Set New Default

 Factory Reset

 Favorite Settings

 Favorite

Note

Printing data from a USB Flash

memory drive or digital camera supporting mass storage

With the Direct Print feature, you do not need a computer to print data. You can print by just plugging your USB Flash memory drive into the machine’s USB direct interface. You can also connect and print directly from a camera set to USB mass storage mode.

• Some USB Flash memory drives may not work with the machine.

• If your camera is in PictBridge mode, you cannot print data. Please refer to the documentation supplied with your camera to switch from PictBridge mode to mass storage mode.

Creating a PRN or

PostScript direct printing

The screens in this section may vary depending on your application and operating system.

a From the menu bar of an application,

click File, then Print.

3™ file for

b Choose Brother MFC-XXXX Printer (1)

and check the Print to file box (2). Click Print.

c Choose the folder you want to save the

file to and enter the file name if you are prompted to. If you are prompted for a file name only,

you can also specify the folder you want to save the file in by entering the directory name. For example: C:\Temp\FileName.prn If you have a USB Flash memory drive or digital camera connected to your computer, you can save the file directly to the USB Flash memory drive.

Printing data from a USB Flash memory drive or digital camera supporting mass storage

Note

Printing data directly from the USB Flash memory drive or digital camera supporting mass storage

a Connect your USB Flash memory drive

or digital camera to the USB direct interface (1) on the front of the machine. Press Direct Print. Your machine will enter Direct Print Mode.

• Make sure your digital camera is turned on.

• If your machine has been set to Secure Function Lock On, you may not be able to access Direct Print. (For explanations

about error messages that may occur, see

Switching Users in chapter 2 of the Advanced User's Guide.)

b Press a or b to choose the folder name

and file name you want to print. If you have chosen the folder name, press a or b to choose the file name you want to print.

• Your digital camera must be switched from PictBridge mode to mass storage mode.

• If you want to print an index of the files, press Index Print on the Touchscreen. Press Mono Start or Colour Start to print the data.

• When the machine is in Deep Sleep mode, the LCD does not show any information even if you connect a USB flash memory drive to the USB direct interface. Press the Touchscreen or any key to wake up the machine. Press Direct Print on the Touchscreen, the LCD will show the Direct Print menu.

c Choose the number of copies you want

by pressing the + and - buttons on the Touchscreen.

d Do one of the following:

 Press Print Settings. Go to

step e.

 If you do not need to change the

current default settings, go to step g.

Chapter 9

Note

IMPORTANT

Note

e Press a or b to display an option setting

you need to change. Press the option and change the setting.

• You can choose the following settings:

Paper Size

Paper Type

Multiple Page

Orientation

Duplex

Collate

Tray Use

Print Quality

PDF Option

• Depending on the file type, some of these settings may not appear.

f Do one of the following:

 If you want to change other option

settings, repeat step e.

 If you do not want to change any

other options, press and go to step g.

Changing the default settings for direct print 9

You can change the default settings for Direct Print.

a Connect your USB Flash memory drive

or digital camera to the USB direct interface on the front of the machine.

b Press Direct Print on the LCD. c Press Default Settings. d Press a or b to display the setting you

want to change. Press the setting.

e Press the new option you want. Repeat

steps d to e for each setting you want to change.

How to display all available options:

When the LCD displays the d and c buttons, press d or c to display all available options.

g Press Mono Start or Colour Start to

print the data.

• To prevent damage to your machine, DO NOT connect any device other than a digital camera or USB Flash memory drive to the USB direct interface.

• DO NOT remove the USB Flash memory drive or digital camera from the USB direct interface until the machine has finished printing.

How to print from a computer 10

Printing a document 10

The machine can receive data from your computer and print it. To print from a computer, install the printer driver. (See

Printing for Windows for Macintosh in the Software User's Guide for the details about the print settings.)

a Install the Brother printer driver on the

Installation CD-ROM. (See the Quick Setup Guide.)

b From your application, choose the Print

command.

c Choose the name of your machine in the

Print dialog box and click Properties.

d Choose the settings you want in the

Properties dialog box.

 Paper Size

or Printing and Faxing

 Orientation

 Copies

 Media Type

 Print Quality

 Colour / Mono

 Multiple Page

 Duplex / Booklet

 Paper Source

Click OK.

e Click OK to begin printing.

Note

How to scan to a computer 11

Scanning a document as PDF file using

ControlCenter4 (Windows

(For Macintosh users) See Scanning in the Software User's Guide.

The screens on your PC may vary depending on your model.

ControlCenter4 is a software utility that lets you quickly and easily access the applications you use most often. Using ControlCenter4 eliminates the need to manually launch specific applications. You can use ControlCenter4 on your computer.

a Load your document. (See How to load documents on page 26.) b Open ControlCenter4 by clicking start/All Programs/Brother/XXX-XXXX (where

XXX-XXXX is your model name)/ControlCenter4. The ControlCenter4 application will open.

c Choose Home Mode or Advanced Mode before you use ControlCenter4.

) 11

d Make sure the machine you want to use is selected from the Model pull-down list.

How to scan to a computer

e Set the file type for saving to a folder. By default, the scanned data is saved as JPEG (*.jpg).

Click Configuration, and then select Button settings, Scan and File.

The configuration dialog box appears. You can change the default settings.

1 Choose PDF (*.pdf) from the File Type pull-down list.

2 You can enter the file name you want to use for the document.

3 You can save the file to the default folder, or choose your preferred folder by clicking the

Browse button.

4 You can choose a scanning resolution from the Resolution pull-down list.

5 You can choose the document size from the pull-down list.

f Click OK.

Chapter 11

g Click File.

The machine starts the scanning process. The folder where the scanned data is saved will open automatically.

How to scan to a computer

Changing the SCAN key settings 11

Before scanning 11

To use the machine as a scanner, install a scanner driver. If the machine is on a network, configure it with a TCP/IP address.

 Install the scanner drivers on the Installation CD-ROM. (See the Quick Setup Guide.)

 Configure the machine with a TCP/IP address if network scanning does not work. (See

Configuring Network Scanning in the Software User's Guide.)

SCAN key settings 11

You can change your machine’s SCAN key settings using ControlCenter4.

a Open ControlCenter4 by clicking start/All Programs/Brother/XXX-XXXX (where

XXX-XXXX is your model name)/ControlCenter4. The ControlCenter4 application will open.

b Make sure the machine you want to use is selected from the Model pull-down list. c Click the Device Settings tab. d Click Device Scan Settings.

Chapter 11

e Choose the File tab. You can change the default settings.

1 You can choose the file type from the pull-down list.

2 You can enter the file name you want to use for the document.

3 You can save the file to the default folder, or choose your preferred folder by clicking the

Browse button.

4 You can choose a scanning resolution from the Resolution pull-down list.

5 You can choose the document size from the pull-down list.

f Click OK.

How to scan to a computer

Note

Scanning using the SCAN key 11

a Load your document. (See How to load documents on page 26.) b Press (SCAN). c Press Scan to PC. d Press File. e (For Network users)

Press a or b to choose the destination computer you want to send to. Press OK. If the LCD prompts you to enter a PIN number, enter the 4-digit PIN number for the destination computer using the dial pad on the control panel. Press OK.

f Do one of the following:

 If you want to change the duplex setting, press Duplex Scan. Then press Off,

DuplexScan :LongEdge or DuplexScan :ShortEdge.

 To start scanning without changing additional settings, go to step g.

g Press Mono Start or Colour Start.

The machine starts the scanning process.

Choose the scan mode you want.

Scan to:

• USB

• Network

• FTP

• E-mail (Server)

• E-mail

• Image

• OCR

• File

Routine maintenance A

Replacing the consumable items A

The following messages appear on the LCD in the Ready mode. These messages provide advanced warnings to replace the consumable items before they reach the end of their life. To avoid any inconvenience, you may want to buy spare consumable items before the machine stops printing.

Toner cartridge Drum unit

See Replacing a Toner cartridge on page 66.

Model Name: TN-320BK, TN-325BK, TN-328BK,

TN-320C, TN-325C, TN-328C, TN-320M, TN-325M,

TN-328M, TN-320Y, TN-325Y, TN-328Y,

See Replacing the drum unit on page 72.

Model Name: DR-320CL

Belt unit Waste toner box

See Replacing the belt unit on page 78.

Model Name: BU-300CL

See Replacing the waste toner box on page 84.

Model Name: WT-300CL

Routine maintenance

LCD messages Consumable item

Approximate life How to replace Model name

to replace

Toner Low

Prepare New Toner Cartridge.X

Toner cartridge

X = Black, Cyan, Magenta, Yellow

<Black>

2,500 pages

4,000 pages

6,000 pages

123

124

125

<Cyan, Magenta, Yellow>

123

124

125

Replace Parts

Waste toner box

1,500 pages

3,500 pages

6,000 pages

50,000 pages

WT Box End Soon

A4 or Letter size single-sided pages.

Approx. cartridge yield is declared in accordance with ISO/IEC 19798.

Standard toner cartridge

High capacity toner cartridge

Super high capacity toner cartridge

See page 66.

See page 84. WT-300CL

TN-320BK

TN-325BK

TN-328BK

TN-320C

TN-325C

TN-328C

TN-320M

TN-325M

TN-328M

TN-320Y

TN-325Y

TN-328Y

You will need to clean the machine regularly and replace the consumable items when the following messages are displayed on the LCD.

LCD messages Consumable item

to replace

Replace TonerX Toner cartridge

X = Black, Cyan, Magenta, Yellow

Replace Parts

Drum unit

Drum Unit

Drum Stop

Replace Parts

Belt unit

Belt Unit

Replace WT Box Waste toner box

Replace Parts

Fuser unit

Fuser Unit

Replace Parts

Laser unit

Laser Unit

Replace Parts

Paper feeding kit 1

PF Kit 1

Replace Parts

Paper feeding kit 2

PF Kit 2

Replace Parts PF Kit MP

Paper feeding kit MP

Approximate life How to replace Model name

<Black>

2,500 pages

4,000 pages

6,000 pages

125

126

127

<Cyan, Magenta, Yellow>

1,500 pages

3,500 pages

6,000 pages

125

126

127

25,000 pages

50,000 pages

100,000 pages

See page 66.

134

See page 73. DR-320CL

See page 78. BU-300CL

See page 84. WT-300CL

Call your Brother dealer for a

TN-320BK

TN-325BK

TN-328BK

TN-320C

TN-325C

TN-328C

TN-320M

TN-325M

TN-328M

TN-320Y

TN-325Y

TN-328Y

replacement fuser unit.

100,000 pages

Call your Brother dealer for a replacement laser unit.

100,000 pages

Call your Brother dealer for a replacement paper feeding kit 1.

100,000 pages

Call your Brother dealer for a replacement paper feeding kit 2.

50,000 pages

Call your Brother dealer for a replacement paper feeding kit MP.

A4 or Letter size single-sided pages.

Approx. cartridge yield is declared in accordance with ISO/IEC 19798.

1 page per job.

Drum life is approximate and may vary by type of use.

Standard toner cartridge

High capacity toner cartridge

Super high capacity toner cartridge

Routine maintenance

Note

• Go to http://www.brother.com/original/index.html for instructions on how to return your used consumable items to the Brother collection program. If you choose not to return your used consumable, please discard the used consumable according to local regulations, keeping it separate from domestic waste. If you have questions, call your local waste disposal office. (See EU Directive 2002/96/EC and EN 50419 in the Safety and Legal Booklet.)

• We recommend placing used consumable items on a piece of paper to prevent accidentally spilling or scattering the material inside.

• If you use paper that is not a direct equivalent for the recommended paper, the life of consumable items and machine parts may be reduced.

• The projected life of the toner cartridges is based on ISO/IEC 19798. Frequency of replacement will vary depending on the complexity of printed pages, percentage of coverage and type of media used.

Replacing a Toner cartridge A

Note

Model Name: For the model name of toner cartridges, see Replacing the consumable items on page 62.

The Standard toner cartridges can print approximately 2,500 pages (black) or approximately 1,500 pages (cyan, magenta,

yellow) print approximately 4,000 pages (black) or approximately 3,500 pages (cyan, magenta,

yellow) cartridges can print approximately 6,000

pages (black, cyan, magenta, yellow) Actual page count will vary depending on your average type of document. When a toner cartridge is running low, the LCD shows Toner Low.

The toner cartridges that come supplied with the machine are standard toner cartridges.

. The High Yield toner cartridges can

. The Super High Yield toner

Approx. cartridge yield is declared in accordance with ISO/IEC 19798.

Toner Low A

If the LCD shows Toner Low Prepare New Toner Cartridge.X, buy

a new toner cartridge and have it ready before you get a Replace Toner message. The LCD shows the toner colour that is near the end of its life (Cyan, Magenta, Yellow or Black).

Replace Toner A

When the LCD shows Replace Toner the machine will stop printing until you replace the toner cartridge. The message on the LCD will indicate which colour you need to replace.

A new or unused Brother Original toner cartridge will reset the Replace Toner mode.

• It is a good idea to keep a new toner cartridge ready for use when you see the Toner Low warning.

• To ensure high quality printing, we recommend that you use only Brother Original toner cartridges. When you want to buy toner cartridges, please call your Brother dealer.

• We recommend that you clean the machine when you replace the toner cartridge. See Cleaning and Checking the machine on page 91.

• If you change the print density setting for lighter or darker printing, the amount of toner used will change.

• Wait to unpack the toner cartridge until immediately before you put it into the machine.

Routine maintenance

Replacing the toner cartridges A

a Make sure that the machine is turned

on.

b Press the front cover release button and

then open the front cover.

c Hold the green handle of the drum unit.

Pull the drum unit out until it stops.

d Hold the handle of the toner cartridge

WARNING

IMPORTANT

Note

and slightly push it toward the machine to unlock it. Then pull it out of the drum unit. Repeat this for all the toner cartridges.

DO NOT put a toner cartridge into a fire. It could explode, resulting in injuries.

DO NOT use cleaning materials that contain ammonia, alcohol, any type of spray or any type of flammable substance to clean the inside or outside of the machine. Doing this may cause a fire or electrical shock.

See To use the product safely in the Safety and Legal Booklet for how to clean the machine.

Be careful not to inhale toner.

• We recommend that you place the drum unit and/or the toner cartridge on a clean, flat, level, stable surface with a sheet of disposable paper or cloth underneath it in case you accidentally spill or scatter toner.

• Handle the toner cartridge carefully. If toner scatters on your hands or clothes, immediately wipe or wash it off with cold water.

• To avoid print quality problems, DO NOT touch the shaded parts shown in the illustration.

• Be sure to seal up the toner cartridge tightly in a suitable bag so that toner powder does not spill out of the cartridge.

• Go to http://www.brother.com/original/ index.html for instructions on how to return your used consumable items to the Brother collection program. If you choose not to return your used consumable, please discard the used consumable according to local regulations, keeping it separate from domestic waste. If you have questions, call your local waste disposal office. (See EU Directive 2002/96/EC and EN 50419 in the Safety and Legal Booklet)

Routine maintenance

Note

e Push to release the latches of the

corona wire cover (1), and then open the cover.

f Clean the corona wires inside the drum

unit by gently sliding the green tabs from left to right and right to left several times.

Be sure to return the tab to the home position (a) (1). If you do not, printed pages may have a vertical stripe.

g Close the corona wire cover.

IMPORTANT

h Repeat steps e to g to clean each of

three remaining corona wires.

i Unpack the new toner cartridge. Gently

shake it from side to side several times to distribute the toner evenly inside the cartridge.

• Unpack the toner cartridge just before you put it in the machine. If a toner cartridge is left unpacked for a long time, the toner life will be shortened.

• If an unpacked drum unit is put in direct sunlight or room light, the unit may be damaged.

• Brother machines are designed to work with toner of a particular specification and will work to a level of optimum performance when used with Brother Original toner cartridges. Brother cannot guarantee this optimum performance if toner or toner cartridges of other specifications are used. Brother does not therefore recommend the use of cartridges other than Brother Original cartridges with this machine, or the refilling of empty cartridges with toner from other sources. If damage is caused to the drum unit or other part of this machine as a result of the use of toner or toner cartridges other than Brother Original products due to the incompatibility or lack of suitability of those products with this machine, any repairs required as a result may not be covered by the warranty.

Routine maintenance

IMPORTANT

j Pull off the protective cover.

Put the toner cartridge in the drum unit immediately after you have removed the protective cover. To prevent any degradation to the print quality, DO NOT touch the shaded parts shown in the illustrations.

k Hold the handle of the toner cartridge

and slide the toner cartridge into the drum unit, then slightly pull it toward you until you hear it click into place. Make sure that you match the toner cartridge colour to the same colour label on the drum unit. Repeat this for all the toner cartridges.

C - Cyan M - Magenta

Y - Yellow K - Black

l Push the drum unit in until it stops.

Note

IMPORTANT

Replacing the drum unit A

Model name: DR-320CL

A new drum unit can print approximately 25,000 A4 or Letter size single-sided pages.

For best performance, use a Brother Original drum unit and Brother Original toner units. Printing with a third-party drum unit or toner unit may reduce not only the print quality but also the quality and life of the machine itself. Warranty coverage may not apply to problems caused by the use of a third-party drum unit or toner unit.

Drum Error A

The corona wires have become dirty. Clean the corona wires in the drum unit. (See Cleaning the corona wires on page 97.)

If you cleaned the corona wires and Drum Error was not cleared then the drum unit is at the end of its life. Replace the drum unit with a new one.

m Close the front cover of the machine.

After you replace a toner cartridge, DO NOT turn off the machine's power switch or open the front cover until the LCD clears the Please Wait message and returns to Ready mode.

Replace Parts Drum

The drum unit has exceeded its rated life. Please replace the drum unit with a new one. We recommend a Brother Original drum unit be installed at this time.

After replacement, reset the drum counter by following the instructions included with the new drum unit.

Drum Stop A

We cannot guarantee the print quality. Please replace the drum unit with a new one. We recommend a Brother Original drum unit be installed at this time.

After replacement, reset the drum counter by following the instructions included with the new drum unit.

Routine maintenance

IMPORTANT

Replacing the drum unit A

• While removing the drum unit, handle it carefully because it may contain toner. If toner scatters on your hands or clothes, immediately wipe or wash it off with cold water.

• Every time you replace the drum unit, clean the inside of the machine. (See Cleaning and Checking the machine on page 91.)

a Make sure that the machine is turned

on.

b Press the front cover release button and

then open the front cover.

c Hold the green handle of the drum unit.

Pull the drum unit out until it stops.

d Turn the green lock lever (1) at the left of

IMPORTANT

the machine anticlockwise to the release position. Holding the green handles of the drum unit, lift the front of the drum unit and remove it from the machine.

• We recommend that you place the drum unit and/or the toner cartridge on a clean, flat surface with a sheet of disposable paper or cloth underneath it in case you accidentally spill or scatter toner.

• To prevent damage to the machine from static electricity, DO NOT touch the electrodes shown in the illustration.

• Hold the green handles of the drum unit when you carry it. DO NOT hold the sides of the drum unit.

e Hold the handle of the toner cartridge

WARNING

IMPORTANT

Note

and slightly push it to unlock it. Then pull it out of the drum unit. Repeat this for all the toner cartridges.

DO NOT put a toner cartridge into a fire. It could explode, resulting in injuries.

DO NOT use cleaning materials that contain ammonia, alcohol, any type of spray, or any type of flammable substance to clean the outside or inside of the machine. Doing this may cause a fire or electrical shock.

See To use the product safely in the Safety and Legal Booklet for how to clean the machine.

Be careful not to inhale toner.

Routine maintenance

• Handle the toner cartridge carefully. If toner scatters on your hands or clothes, immediately wipe or wash it off with cold water.

• To avoid print quality problems, DO NOT touch the shaded parts shown in the illustrations.

• Be sure to seal up the used drum unit tightly in a bag so that toner powder does not spill out of the unit.

• Go to http://www.brother.com/original/ index.html for instructions on how to return your used consumable items to the Brother collection program. If you choose not to return your used consumable, please discard the used consumable according to local regulations, keeping it separate from domestic waste. If you have questions, call your local waste disposal office. (See EU Directive 2002/96/EC and EN 50419 in the Safety and Legal Booklet)

f Unpack the new drum unit and remove

IMPORTANT

the protective cover.

g Hold the handle of the toner cartridge

and slide the toner cartridge into the new drum unit, then slightly pull it toward you until you hear it click into place. Make sure that you match the toner cartridge colour to the same colour label on the drum unit. Repeat this for all the toner cartridges.

• To avoid print quality problems, DO NOT touch the shaded parts shown in the illustrations.

• Unpack the drum unit just before you put it in the machine. Exposure to direct sunlight or room light may damage the drum unit.

C - Cyan M - Magenta

Y - Yellow K - Black

Routine maintenance

h Make sure the green lock lever (1) is in

the release position as shown in the illustration.

i Match the guide ends (2) of the drum

unit to the c marks (1) on both sides of the machine, then gently slide the drum unit into the machine until it stops at the green lock lever.

j Turn the green lock lever (1) clockwise

to the lock position.

k Push the drum unit in until it stops.

l Close the front cover of the machine.

Resetting the drum counter A

IMPORTANT

When you replace a drum unit with a new one, you will need to reset the drum counter by completing the following steps:

a Press MENU.

Replacing the belt unit A

Model name: BU-300CL

A new belt unit can print approximately 50,000 A4 or Letter size single-sided pages.

b Press a or b to display

Machine Info.. Press Machine Info..

c Press Reset Menu. d Press Drum. e The machine will display

Reset Drum?.

f Press Yes, and then press Stop/Exit.

Replace Parts Belt Unit

When the Replace Parts Belt Unit message appears on the LCD, you will need to replace the belt unit:

• DO NOT touch the surface of the belt unit. If you touch it, it could degrade print quality.

• Damage caused by incorrect handling of the belt unit may void your warranty.

a Make sure that the machine is turned

on.

Routine maintenance

b Press the front cover release button and

then open the front cover.

c Hold the green handle of the drum unit.

Pull the drum unit out until it stops.

d Turn the green lock lever (1) at the left of

IMPORTANT

the machine anticlockwise to the release position. Holding the green handles of the drum unit, lift the front of the drum unit and remove it from the machine.

• To prevent damage to the machine from static electricity, DO NOT touch the electrodes shown in the illustration.

• Hold the green handles of the drum unit when you carry it. DO NOT hold the sides of the drum unit.

Routine maintenance

IMPORTANT

• To avoid print quality problems, DO NOT touch the shaded parts shown in the illustrations.

e Hold the green handle of the belt unit

with both hands and lift the belt unit up, then pull it out.

To avoid print quality problems, DO NOT touch the shaded parts shown in the illustration.

f Unpack the new belt unit.

g Put the new belt unit back in the

machine. Make sure the belt unit is level and fits firmly into place.

h Make sure the green lock lever (1) is in

the release position as shown in the illustration.

i Match the guide ends (2) of the drum

unit to the c marks (1) on both sides of the machine, then gently slide the drum unit into the machine until it stops at the green lock lever.

Routine maintenance

j Turn the green lock lever (1) clockwise

to the lock position.

k Push the drum unit in until it stops.

Resetting the belt unit counter A

When you replace a belt unit with a new one, you will need to reset the belt unit counter by completing the following steps:

a Press MENU. b Press a or b to display

Machine Info.. Press Machine Info..

c Press Reset Menu. d Press Belt Unit. e The machine will display Reset Belt

Unit?.

f Press Yes, and then press Stop/Exit.

l Close the front cover of the machine.

Replacing the waste toner

WARNING

IMPORTANT

box A

Model name: WT-300CL

A new waste toner box can print approximately 50,000 A4 or Letter size single-sided pages.

Replace Parts WT Box End Soon A

If the LCD shows Replace Parts WT Box End Soon, it means the waste

toner box is near the end of its life. Buy a new waste toner box and have it ready before you get a Replace WT Box message.

Replace WT Box A

When the Replace WT Box message appears on the LCD, you will need to replace the waste toner box:

b Press the front cover release button and

then open the front cover.

DO NOT put the waste toner box into a fire. It could explode.

Be careful not to spill the toner. DO NOT inhale or allow it to get into your eyes.

DO NOT reuse the waste toner box.

a Make sure that the machine is turned

on.

Routine maintenance

c Hold the green handle of the drum unit.

Pull the drum unit out until it stops.

d Turn the green lock lever (1) at the left of

the machine anticlockwise to the release position. Holding the green handles of the drum unit, lift the front of the drum unit and remove it from the machine.

IMPORTANT

• To prevent damage to the machine from static electricity, DO NOT touch the electrodes shown in the illustration.

• To avoid print quality problems, DO NOT touch the shaded parts shown in the illustrations.

• Hold the green handles of the drum unit when you carry it. DO NOT hold the sides of the drum unit.

Routine maintenance

IMPORTANT

Note

e Hold the green handle of the belt unit

with both hands and lift the belt unit up, then pull it out.

To avoid print quality problems, DO NOT touch the shaded parts shown in the illustration.

f Remove the two pieces of orange

packing material and discard them.

This step is only necessary when you are replacing the waste toner box for the first time, and are not required for the replacement waste toner box. The orange packing pieces are installed at the factory to protect your machine during shipment.

g Hold the green handle of the waste toner

CAUTION

Note

box and remove the waste toner box from the machine.

Handle the waste toner box carefully in case you accidentally spill or scatter toner. If toner scatters on your hands or clothes, immediately wipe or wash it off with cold water.

h Unpack the new waste toner box and

put the new waste toner box in the machine using the green handle. Make sure the waste toner box is level and fits firmly into place.

Discard the used waste toner box according to local regulations, keeping it separate from domestic waste. If you have questions, call your local waste disposal office.

Routine maintenance

i Put the belt unit back into the machine.

Make sure the belt unit is level and fits firmly into place.

j Make sure the green lock lever (1) is in

the release position as shown in the illustration.

k Match the guide ends (2) of the drum

unit to the c marks (1) on both sides of the machine, then gently slide the drum unit into the machine until it stops at the green lock lever.

l Turn the green lock lever (1) clockwise

to the lock position.

m Push the drum unit in until it stops.

n Close the front cover of the machine.

Routine maintenance

WARNING

IMPORTANT

Cleaning and Checking the machine A

Clean the outside and inside of the machine regularly with a dry, lint-free cloth. When you replace the toner cartridge or the drum unit, make sure that you clean the inside of the machine. If printed pages are stained with toner, clean the inside of the machine with a dry, lint-free cloth.

DO NOT use any flammable substances, spray or organic solvent/liquids containing alcohol/ammonia to clean the inside or outside of the machine. Doing this may cause a fire or electrical shock.

Cleaning the outside of the machine A

a Turn off the machine. Unplug the

telephone line cord first, disconnect all cables, and then unplug the power cord from the electrical socket.

b Pull the paper tray completely out of the

machine.

Be careful not to inhale toner.

Use neutral detergents. Cleaning with volatile liquids such as thinner or benzine will damage the surface of the machine.

c Wipe the outside of the machine with a

dry, lint-free soft cloth to remove dust.

d Remove any paper that is in the paper

tray.

e Wipe the inside and the outside of the

paper tray with a dry, lint-free soft cloth to remove dust.

f Re-load the paper and put the paper tray

firmly back in the machine.

g Plug the machine’s power cord back into

the electrical socket first, connect all cables, and then plug in the telephone line cord. Turn on the machine.

Cleaning the scanner glass A

a Turn off the machine. Unplug the

telephone line cord first, disconnect all cables, and then unplug the power cord from the electrical socket.

b Unfold the ADF document support (1)

and then open the ADF cover (2). Clean the white bar (3) and the scanner glass strip (4) underneath it with a soft lint-free cloth moistened with water. Close the ADF cover (2) and fold the ADF document support (1).

c Lift the document cover (1).

Clean the white plastic surface (2) and scanner glass (3) underneath it with a soft lint-free cloth moistened with water.

Brother MFC-9970CDW User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

User's Guides and where do I find it?

Table of Contents

General information 1

Using the documentation

Symbols and conventions used in the documentation 1

Accessing the Advanced User’s Guide, Software User’s Guide and Network User’s Guide

Viewing Documentation 1

How to find Scanning instructions 1

Accessing Brother Support (Windows®) 1

Accessing Brother Support (Macintosh) 1

Control panel overview 1

LCD Touchscreen 1

Basic Operations 1

Volume settings 1

Ring volume 1

Beeper volume 1

Speaker volume 1

Loading paper 2

Loading paper and print media

Loading paper in the standard paper tray 2

Loading paper in the multi-purpose tray (MP tray) 2

Printing on plain paper, bond paper, labels or glossy paper from the MP tray

Printing on envelopes and thick paper from the MP tray 2

Unscannable and unprintable areas 2

Paper settings 2

Paper Size and Type 2

Tray Use in copy mode 2

Tray Use in fax mode 2

Tray Use in print mode 2

Acceptable paper and other print media 2

Recommended paper and print media 2

Type and size of paper 2

The name for the paper trays in the printer driver in this Guide are as follows: 2

Paper capacity of the paper trays 2

Recommended paper specifications 2

Handling and using special paper 2

Types of paper to avoid 2

Envelopes 2

Types of envelopes to avoid 2

Labels 2

Types of labels to avoid 2

Loading documents 3

How to load documents

Using the automatic document feeder (ADF) 3

Document Sizes Supported 3

How to load documents 3

• To scan non-standard documents, see Using the scanner glass on page 27.

Document Sizes Supported 3

How to load documents 3

Sending a fax 4

How to send a fax 4

Faxing Letter/Legal/Folio size documents from the scanner glass 4

Colour fax transmission 4

Cancelling a fax in progress 4

Transmission verification report 4

Receiving a fax 5

Receive modes 5

Choosing the receive mode 5

Using receive modes 5

Fax Only mode will automatically answer every call as a fax.

Fax/Tel mode helps you automatically manage incoming calls, by recognising whether they are fax or voice calls and dealing with them in one of the following ways:

Manual mode turns off all automatic answering functions unless you are using the

External TAD mode lets an external answering device manage your incoming calls. Incoming calls will be dealt with in the following ways:

Receive Mode settings 5

Ring Delay 5

F/T Ring Time (Fax/Tel mode only) 5

Fax Detect 5

Telephone and external devices 6

Telephone line services

Setting the telephone line type 6

PBX and TRANSFER 6

Connecting an external TAD 6

Connections 6

Recording an outgoing message (OGM) 6

Multi-line connections (PBX) 6

External and extension telephones 6
