FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: MFC1025
© Copyright Brother 1997
All rights reserved
No part of this publication may be reproduced in any form
or by any means without permission in writing from the
publisher.
Specifications are subject to change without prior notice.
NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q' ty
(3) Description
Note: No orders without Parts Code or Tool No. can be accepted.
[Example]
(1) (2) (3)
REF.NO. CODE Q' TY DESCRIPTION REMARKS
2. Parts change will be informed by the technical information.
COUNTRIES
GERMANY ----- GER
FRANCE ----- FRA
UNITED KINGDOM ----- UK
NORWAY ----- NOR
NETHERLANDS ----- NLD
SWITZERLAND ----- CHE
SWEDEN ----- SWE
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1 1. PLATEN FRAME & MAIN FRAME ATTACHEMENT
2 UF8070001 1 RECORDING HEAD ASSY
3 UF8072001 3 SPRING, COMPRESSION
4 UG5009001 1 HEAD-MAIN HARNESS
5 UG5010001 1 HEAD-POWER HARNESS
6 UF8018001 1 RECORDER FRAME
7 UF8073001 1 HEAD PROTECTION PLATE
8 U24014001 2 TAPTITE, CUP S M3.0X6
9 087320815 4 TAPTITE, CUP S M3X8
10 UF8140003 1 MAIN COVER, WHITE(1138)
10-1 UF6761001 2 RUBBER
11 UF7095000 1 MJ COVER, H/S FOR UK
12 UF5745000 1 MJ COVER, EXT FOR GER/NLD/CHE/SWE
13 UF4759000 1 PC I/F COVER FOR UK
14 LG2049001 1 SPEAKER ASSY
15 UF8150002 1 SIDE COVER R, WHITE(1397)
16 UF8147002 1 SIDE COVER L, WHITE(1397)
17 UF8151004 1 ROM COVER, GRAY(1267)
18 UF8143003 1 INNER COVER, WHITE(1138)
19 UF5571001 2 PANEL LOCK SPRING
20 087310815 4 TAPTITE, CUP B M3X8
21 UF8164003 1 HANDSET HOLDER ASSY, WHITE(1138)
FOR GER/FRA/NOR/NLD/CHE/SWE
21-1 UF8165003 1 UPPER HANDSET HOLDER, WHITE(1138)
FOR GER/FRA/NOR/NLD/CHE/SWE
21-2 UF8167003 1 ACTUATOR HOOK, WHITE(1138) FOR GER/FRA/NOR/NLD/CHE/SWE
21-3 UF8166003 1 LOWER HANDSET HOLDER, WHITE(1138)
FOR GER/FRA/NOR/NLD/CHE/SWE
22 UF8251001 1 B/T HANDSET HOLDER ASSY, WHITE(1138) FOR UK
22-1 UF8252001 1 B/T UPPER HANDSET HOLDER, WHITE(1138) FOR UK
22-2 UF8253001 1 B/T LOWER HANDSET HOLDER, WHITE(1138) FOR UK
23 087320815 2 TAPTITE, CUP S M3X8
24 UF8155003 1 RECORDING PAPER COVER ASSY, WHITE(1138)
24-1 UF4418001 1 SPRING, COMPRESSION
24-2 UF8153003 1 PAPER REAR COVER, WHITE(1138)
25 UF8162003 2 PAPER GUIDE, WHITE(1138)
26 087320815 2 TAPTITE, CUP S M3X8
27 UF8235003 1 CONTROL PANEL ASSY, WHITE(1138)
27-1 UF8193003 1 CONTROL PANEL, WHITE(1138)
27-2 UF4393003 1 KEY, TEL, WHITE(1138)
27-3 UF8176003 3 KEY, ONE TOUCH, WHITE(1138)
27-4 UF8172002 1 KEY, START, BLUE(6155)
27-5 UF8173001 1 KEY, STOP, ORANGE(3159)
27-6 UF8174001 1 KEY, COPY, GRAY(1267)
27-7 UF8179003 1 KEY, COPY MODE, GRAY(1267)
27-8 UF8177003 1 KEY, MODE, WHITE(1138)
27-9 UL5712003 1 KEY, OPERATION, WHITE(1138)
27-10 UF4576003 1 KEY, SHIFT, WHITE(1138)
27-11 UG5035001 1 PANEL PCB ASSY
27-12 LG2351001 1 LCD
27-13 UG5021001 1 FPC KEY
27-14 UG5018001 1 PANEL-MAIN HARNESS
27-15 UF6761001 1 RUBBER
27-16 UF8178001 1 PANEL REAR COVER ASSY
27-16-1 UF8175001 1 PANEL REAR COVER
27-16-2 UF5585001 1 ADF SPRING PLATE
27-16-3 UF5584000 1 SEPARATION RUBBER
MFC1025/Ver.L
REF.NO. CODE Q'TY DESCRIPTION REMARKS
27-16-4 UF5586001 1 SPRING PLATE, ADF FRONT
27-16-5 UF5587001 1 PRESSURE ROLLER
27-16-6 UF8257001 1 EJECTION ROLLER
27-16-7 UF8285001 1 ANTI-STATIC BRUSH
27-17 087310815 2 TAPTITE, CUP B M3X8
28 UF8583001 1 PANEL SHEET FOR GER
28 UF8584001 1 PANEL SHEET FOR UK
28 UF8585001 1 PANEL SHEET FOR FRA
28 UF8586001 1 PANEL SHEET FOR NOR
28 UF8587001 1 PANEL SHEET FOR NLD
28 UF8588001 1 PANEL SHEET FOR CHE/UK
28 UF8589001 1 PANEL SHEET FOR SWE
29 UF8628001 1 LCD PLATE FOR GER
29 UF8632001 1 LCD PLATE FOR UK/CHE
29 UF8629001 1 LCD PLATE FOR FRA
29 UF8630001 1 LCD PLATE FOR NOR
29 UF8631001 1 LCD PLATE FOR NLD
29 UF8633001 1 LCD PLATE FOR SWE
30 UF8183003 1 ADDRESS LABEL
31 UG5003001 1 MODULAR PCB ASSY
32 UG5059021 1 MAIN PCB SUB ASSY
33 UG2944003 1 ONE TIME PROM:1025-2M FOR GER
33 UG2948004 1 ONE TIME PROM:1025-2M FOR UK
33 UG2432005 1 PROM:1025-2M FOR FRA
33 UG2944007 1 ONE TIME PROM:1025-2M FOR NOR
33 UG2432009 1 PROM:1025-2M FOR NLD
33 UG2944010 1 ONE TIME PROM:1025-2M FOR CHE
33 UG2944026 1 ONE TIME PROM:1025-2M FOR SWE
34 UG3713003 1 NCU PCB ASSY FOR GER
34 UG3709004 1 NCU PCB ASSY FOR UK
34 UG3711005 1 NCU PCB ASSY FOR FRA
34 UG3709007 1 NCU PCB ASSY FOR NOR/SWE
34 UG3707009 1 NCU PCB ASSY FOR NLD
34 UG3705010 1 NCU PCB ASSY FOR CHE
35 UG5061001 1 POWER SUPPLY PCB ASSY FOR WITHOUT CHE
35 UG5057001 1 POWER SUPPLY PCB ASSY FOR CHE
36 UG3308001 1 AC CORD ASSY FOR GER/FRA/NOR/NLD/SWE
36 UG3304001 1 AC CORD ASSY FOR UK
36 UG3306001 1 AC CORD ASSY FOR CHE
37 UF4444001 1 SCREW, PAN(P WASHER) M4X6
38 UG5019001 1 MAIN-POWER HARNESS
39 UG5051001 1 POWER-HEAD HARNESS
40 UF8152001 1 BOTTOM PLATE
41 087310815 6 TAPTITE, CUP B M3X8
42 U24014001 2 TAPTITE, CUP S M3.0X6
43 UF6857003 1 HANDSET, WHITE(1138) FOR GER/FRA/NOR/NLD/CHE/SWE
44 UF6403001 1 B/T HANDSET, WHITE(1138) FOR UK
45 UL8019009 1 HANDSET CURLED CORD ASSY, WHITE(1255)
FOR GER/FRA/NOR/NLD/CHE/SWE
46 UG3625001 1 TELEPHONE LINE CORD FOR GER
46 UG3626001 1 TELEPHONE LINE CORD FOR UK
46 UG3627001 1 TELEPHONE LINE CORD FOR FRA
46 UG3629001 1 TELEPHONE LINE CORD FOR NOR
46 UG3631001 1 TELEPHONE LINE CORD FOR NLD
46 UG3469000 1 TELEPHONE LINE CORD FOR CHE
46 UG3635001 1 TELEPHONE LINE CORD FOR SWE
47 UL6856000 1 TRAY EXTENSION
MFC1025/Ver.L
REF.NO. CODE Q'TY DESCRIPTION REMARKS
48 UF8048001 1 RECORDING PAPER SUPPORT
49 UF8247001 1 DOCUMENT SUPPORT
50 UF8246001 1 DOCUMENT EJECTION TRAY ASSY
(51) UF8387001 1 RIBBON CASSETTE UNIT
(51-1) UF8245001 1 STARTER RIBBON (30M)
(52) UF8618002 1 MYLAR LABEL FOR GER
(52) UF8618001 1 MYLAR LABEL FOR UK/NOR/CHE/SWE
(52) UF8618003 1 MYLAR LABEL FOR FRA
(53) UF8660001 1 OWNER'S MANUAL FAX1025-1 FOR GER
(53) UF8654004 1 OWNER'S MANUAL FAX1025-1 FOR UK
(53) UF8361005 1 OWNER'S MANUAL FAX1025-1 FOR FRA
(53) UF8361007 1 OWNER'S MANUAL FAX1025-1 FOR NOR
(53) UF8361009 1 OWNER'S MANUAL FAX1025-1 FOR NLD
(53) UF8361010 1 OWNER'S MANUAL FAX1025-1 FOR CHE (GERMAN)
(53) UF8361026 1 OWNER'S MANUAL FAX1025-1 FOR SWE
(53) UF8362008 1 OWNER'S MANUAL FAX1025-2 FOR CHE (FRENCH)
(54) UF8610001 1 MULTI FUNCTION LINK MANUAL FOR GER/UK/FRA/NLD/CHE
(54) UF4310001 1 MULTI FUNCTION LINK MANUAL FOR NOR/SWE
(55) UF8306001 2 PROTECTION PAPER
(56) UE1745001 1 CARTON, BROTHER FAX1025 FOR GER/FRA/UK/NOR/CHE/SWE
(56) UE1746001 1 CARTON, BROTHER FAX1025 FOR NLD
(57) UE1514001 1 CARTON (FOR ACCESSORY)
(58) UE1511001 1 STYROFOAM
(59) UF8997001 1 ADJUSTING SHEET, A
(60) UF8263001 1 TEST CHART-027
(60) UF4310001 1 TEST CHART-028
<Eliminated>
(61) UF8609001 1 FLOPPY DISK ASSY FOR GER/UK/NLD/CHE
(61) UF8663001 1 FLOPPY DISK ASSY FOR NOR/SWE
(62) UF2647001 1 CLEANING KIT ASSY
(63) LE0218001 1 EJECTION SUPPORT
(64) LE0544001 1 SEPARATION PAD HOLDER SUPPLY ASSY
MFC1025/Ver.L
1. PLATEN FRAME & MAIN FRAME ATTACHEMENT
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1 UF8116001 1 PAPER FEED ROLLER ASSY
2 UF0026001 1 PAWLED BUSHING
3 UF8118001 1 PAPER FRONT COVER SENSING ACTUATOR
4 UF8111001 1 PAPER-EDGE SENSOR ACTUATOR
5 UF8112001 1 PAPER EJECTION SENSOR ACTUATOR
6 UF8109001 1 PAPER FEED CHUTE ASSY
(INCLUDING PAPER FEED CHUTE, CHUTE FILM, PAPER FEED
SUB CHUTE, SUB CHUTE FILM, SEPARATION PAD, SPRING,
SENSOR PCB ASSY, SENSOR-MAIN HARNESS, PAPER EDGE
SENSOR ACTUATOR, AND PAPER EJECTION SENSOR ACTUATOR)
7 UF8139001 1 CHUTE FILM
8 UF8104001 1 PAPER FEED SUB CHUTE
9 UF8249001 1 SUB CHUTE FILM
10 UF8265001 1 SEPARATION PAD
11 UL5184001 1 SPRING, COMPRESSION
12 UF8086001 1 CHUTE ASSY
13 087320815 2 TAPTITE, CUP S M3X8
14 UG5000001 1 SENSOR PCB ASSY
15 UG5014001 1 SENSOR-MAIN HARNESS
16 UF0761001 1 PAPER EJECTION ROLLER
17 UF8090001 1 CURVED WASHER
18 UF8105001 1 BUSHING
19 UF6048000 1 GEAR, 40
20 UF0026001 1 PAWLED BUSHING
21 UF8505001 1 LOCK LEVER SHAFT
22 UF8506001 1 LOCK LEVER R
23 UF8504001 1 LOCK LEVER L
24 UF8126001 1 LOCK SPRING R
25 UF8125001 1 LOCK SPRING L
26 UF8095001 1 PLATEN
27 UF8097001 2 BUSHING
28 UF8101001 1 GEAR,33 RB
29 UF8098001 1 GEAR,23
30 UF8076001 1 CLUTCH GEAR ASSY
32 UF8094001 2 GEAR,18/41
33 UF8088001 1 PLASTIC RETAINING RING
34 UF8087001 1 SPRING, COMPRESSION
35 UF8122001 1 GEAR,55
36 UF8123001 1 PLANET GEAR,34
37 UF8093001 1 GEAR,39/24
38 UF3665000 2 RIBBON BUSHING
39 UF8013001 2 PAWLED RIBBON BUSHING
40 UF8039001 1 GEAR,33/45
41 UF8025001 2 GEAR,18
42 UF8034001 2 GEAR,39
43 UF8046001 1 ARM C ASSY
44 UF8036001 2 GEAR,33
45 UF8040001 1 GEAR,36/27
46 UF8149001 1 ACTUATOR SPRING
47 UF8148001 1 COVER SENSOR ACTUATOR
48 UF8030001 1 ARM A ASSY
49 UF8032001 1 ARM B ASSY
50 UF8029001 1 GEAR,20/90
51 UF8035001 1 SEPARATION ROLLER GEAR
MFC1025/Ver.B
1. PLATEN FRAME & MAIN FRAME ATTACHEMENT
REF.NO. CODE Q'TY DESCRIPTION REMARKS
52 UF5511001 1 SEPARATION ROLLER
53 UF8037001 1 GEAR,20/40
54 UF8038001 1 CLUTCH LEVER
55 UF6664001 1 SPRING, EXTENSION
56 UG3086001 1 SOLENOID
57 UF6616000 3 GEAR, 14/20
58 UF8144001 1 DOCUMENT EJECTION ROLLER
59 UF8146001 1 BUSHING
60 Z26436001 1 MOTOR
61 U09759001 1 SCREW, PAN (S/P WASHER) M3X6
62 UG5012001 1 MOTOR-MAIN HARNESS
63 UF6069000 1 SLIP GEAR, 40
64 UF6067001 1 FRICTION PAD
65 048030345 1 RETAINING RING, E3
66 UF8043001 1 BACK TENSION SPRING
67 UF8028001 1 GEAR,24
68 UF8037001 1 GEAR,20/40
69 UF8023001 1 FRICTION TORQUE TRANSMISSION ASSY (GEAR,46 ASSY)
71 UF8022001 1 DOCUMNET FRONT SENSOR ACTUATOR
72 UF8024001 1 DOCUMNET REAR SENSOR ACTUATOR
73 UG5064001 1 CIS UNIT
74 UF8578001 1 CIS HOLDER R
75 UF8579001 1 CIS HOLDER L
76 087310815 2 TAPTITE, CUP B M3X8
77 UG5013001 1 CIS-MAIN HARNESS
78 UF8041001 1 CIS LEAF SPRING
79 UF8053001 1 WHITE PRESSURE ROLLER ASSY
79 UF8054001 1 WHITE PRESSURE ROLLER
79 UF8056001 1 BUSHING L
79 UF8057001 1 WHITE PRESSURE ROLLER GEAR
80 UF8058001 1 BUSHING R
MFC1025/Ver.B
