Bath Cabinets

August 2008

When remodeling or building, it’s fun and exciting to

coordinate fixtures, colors, fabrics and accessories. The

Studio V and Gallery Collections of bath cabinets expand

these possibilities, allowing you to integrate creative design

ideas with beautiful and functional storage solutions. With

frame, cabinet and installation options, as well as customization

opportunities, you can truly express yourself.

NuTone Cabinets

Shown: Gallery Deluxe 72SS244D with a recessed cherry frame 74CY24

Lights shown above are not available from NuTone Premier

72WH346D (35" tall, 6" deep, beveled mirror, with 74WH34 Recessed Frame)

B 72SS244D (25" tall, 4" deep,

beveled mirror with 75CY24 surface mount Cherry frame)

C 72WH344D (35" tall, 4" deep,

beveled mirror, recessed with no frame)

72SS244D (25" tall, 4" deep,

beveled mirror with 760024

Surface Mount Side Mirror Kit)

Gallery Deluxe bath cabinets represent the pinnacle in artistry

and craftsmanship—combining style, design and materials in a

functional piece of art. Choose either a stainless steel or white

interior cabinet body, frame options, and let your creativity

flourish. Do you wish to install a single cabinet over a pedestal sink

or multiple units in a row over a long counter? Would you like a

traditional aesthetic using our hardwood frames, or would you prefer

a sleek and modern frameless presentation? What about creating

your own custom frame, matching your home’s woodwork and stain?

Gallery Deluxe offers infinite possibilities with frame, gang kit,

recessed, semi-recessed and surface-mount kit options. See pages 8

and 9 for more installation and customization details.

Gallery Deluxe

25" or 35" tall, 4" or 6" deep

Gallery Deluxe interior is available in two cabinet styles: A. Fabricated stainless steel

cabinet with a black door

B. Enameled white steel

cabinet with a white door

Reversible mounting allows left- or right-hand door opening

Exterior mirror is premium float glass that provides a deep rich reflection

Eurodesign hinges open 170° for added viewing space

Dark

Cherry

Unfinished

Cherry

1" beveled trim on the front mirror

Adjustable 1/4" thick glass shelves for superior light reflection; 24" model: 3 shelves, 34" model: 4 shelves

Snap-fit shelf supports lock glass shelves in place

Interior back panel mirror

Interior door mirror

Integral recessed door

Shown: 72SS244D, recessed with no frame

Model Cabinet Frame Door Mirror Overall Size Wall Opening

Number Body Style Type Shape w h w h d

Gallery Deluxe Beveled Mirror Cabinet Recessed, Semi-recessed* or Surface Mount**

72SS244D Stainless Frameless Single Rectangle 15 25 141⁄4 24 4

72SS344D Stainless Frameless Single Rectangle 15 35 141⁄4 34 4

72SS246D Stainless Frameless Single Rectangle 15 25 141⁄4 24 6

72SS346D Stainless Frameless Single Rectangle 15 35 141⁄4 34 6

72WH244D White Frameless Single Rectangle 15 25 141⁄4 24 4

72WH344D White Frameless Single Rectangle 15 35 141⁄4 34 4

72WH246D White Frameless Single Rectangle 15 25 141⁄4 24 6

72WH346D White Frameless Single Rectangle 15 35 141⁄4 34 6

Note: All measurements are in inches. *Only models with a 6" depth can be Semi-recessed and require a Semi-recessed Mirror Kit. **Only models with a 4" depth can be surface mounted and require either a Surface Mount Side Mirror Kit or a Surface Mount Frame.

For information on Surface Mount and Semi-recessed Side Mirror Kits, and Gang Attachment Kits, see page 8.

finger pull

Full perimeter bumper cushions the door for a quiet close

Unfinished

Poplar

(Paintable)

Gloss

White

Four frame options are available for both recessed or surfacemount applications. See pages 8 and 9 for design ideas, and specifications.

Shown: 72WH304D (30" tall,

4" deep, with beveled mirror)

125°

Gallery bath cabinets are well known for beauty and craftsmanship.

And now, they are known for even more — storage space, that is. Gallery

Oversize cabinets are now available a full ten inches wider. That provides

an additional 180 square inches of storage space on four glass shelves

and the base of the cabinet. Whether recessed or surface mounted, the

beautiful, rich, beveled float glass mirrors provide a timeless complement

to every bath or powder room.

30" tall, 4" deep

Gallery Oversize interiors are available in two cabinet styles: A. Fabricated stainless steel cabinet

with a black door (shown right)

B. Enameled white steel cabinet

with a white door

Reversible mounting allows left- or right-hand door opening

Exterior mirror is premium float glass that provides a deep rich reflection—framed in a 1/2" beveled trim

Gallery Oversize

Four adjustable 1/4" thick glass shelves for superior light reflection

Snap-fit shelf supports lock glass shelves in place

Interior mirrors on the back of the cabinet and the inside door add light and functionality

Integral recessed door finger pull

A rubber bumper around the perimeter cushions the door for a quiet close

125° concealed hinges allow wide door opening and smooth operation

Model Frame Cabinet Door Cabinet Overall Size Wall Opening Number Type Body Type Depth w h d w h d

Gallery Oversize Recessed or Surface Mount*

72SS304D Frameless Stainless Single 4 24 30 – 231⁄4 29 4

72WH304D Frameless White Single 4 24 30 – 231⁄4 29 4

Note: All measurements are in inches.

* For information on Surface Mount and Semi-recessed Side Mirror Kits, and Gang Attachment Kits, see page 8.

Shown: Gallery Oversize 72SS304DF

Gallery provides the inspiration.

If you previously ordered Gallery Collection from Jensen:

The Jensen number you used to order is now cross referenced on the charts to the right. Use the NuTone model number to order the cabinet, frame and accessories needed for your installation. If you have questions, contact NuTone customer support at 800-325-8351.

The Gallery Collection is a complete “storage system solution.” In fact,

your possibilities are truly infinite when considering the options below.

1. Determine how many cabinets and how much storage you’d like.

Would you prefer one model over a pedestal sink, or do you want to create

a custom storage and design statement with multiple cabinets? All of our

models can be either recessed or surface mounted, and with our Gangable

Attachment Kit you can seamlessly install as many cabinets in a row as

you wish. See photo on page 9.

2. Select your Gallery cabinet style: Keep in mind factors such as…

which materials and colors you’d prefer (stainless steel or painted white

cabinets), do you want internal cabinet mirrors, and would you prefer

170 degree hinges (allowing you to truly utilize the back of the door for

viewing)? Answering these questions will help drive your selection.

3. Determine how deep your walls are and the storage space you

need. Now you can decide on all of your dimensions. 25" or 35" tall?

4" or 6" deep? Consider 6" deep Gallery Deluxe models for unbelievable,

yet hidden storage space—especially in powder rooms over a pedestal sink.

4" and 6" deep cabinets can be recessed or surface mounted, while 6"

cabinets have the option of being semi-recess mounted in a standard wall.

4. To frame or not to frame… now it really gets interesting. If you

prefer a modern or minimalistic style, install a Gallery unit with no frame

at all—either recessed into the wall or with one of our Surface Mount

Side Mirror kits. Or choose one of our beautiful recessed or surface mount

pre-stained hardwood frames, which are fully assembled and stained

out-of-the-box (like a picture frame) for easy installation and perfect-fit

mitered corners.

5. Still not satisfied with your options? No problem. Poplar and

Cherry hardwood frames are available unfinished allowing you to custom-

stain or paint to match your cabinetry. Or you or your professional

carpenter can create your own frame mouldings that perfectly match your

home’s woodwork and cabinetry.

Gallery Deluxe Bath Cabinets Recessed or Surface Mount*

Model Number

72SS244D 72SS344D 72SS246D 72SS346D 72WH244D 72WH344D 72WH246D 72WH346D

* Only models with a 4" depth can be surface mounted and require either a Surface Mount Side Mirror Kit for frameless installations, or a Recessed or Surface Mount frame. See below.

Recessed Frames (for single cabinet only)

Model Number

74WH24 74WH34 74UP24 74UP34 74CY24 74CY34 74UC24 74UC34

Surface Mount Frames (for single cabinet only)

Model Number

75WH24 75WH34 75UP24 75UP34 75CY24 75CY34 75UC24 75UC34

Note: All measurements are in inches.

Surface Mount Side Mirror* Kits (for 4" cabinet depths only)

Model Number

760024

760030

760034

Semi-recessed Side Mirror Kits (for 6" cabinet depths only)

G1530 (for cabinets with a 24" wall opening height) G1540 (for cabinets with a 34" wall opening height)

Horizontal Gang Attachment Kit

Previous Jensen number: G1520

76GK* (for 24", 29" and 34" wall openings)

Example 1: Recess three cabinets in a row (3 cabinets - 1) = 2 Horizontal Gang Attachment Kits. Example 2: Surface mount four cabinets in a row (4 cabinets - 1) = 3 Horizontal Gang

Vertical Gang Attachment Kit

G1525* (for 24", 29" and 34" wall openings)

Example 1: Recess two cabinets in a column (2 cabinets - 1) = 1 Vertical Gang Attachment Kit. Example 2: Surface mount two cabinets in a column (2 cabinets - 1) = 1 Vertical Gang

*To determine the quantity of Gang Kits needed, subtract 1 from the number of cabinets to be ganged. When ganging and surface mounting cabinets, 1 Surface Mount Side Mirror Kit is required for each cabinet.

Former Jensen no.

G1200P24SSGU

G1200P34SSGU

G1206P24SSGU

G1206P34SSGU

G1200P24WHGU

G1200P34WHGU

G1206P24WHGU

G1206P34WHGU

Former Jensen no.

G140024WH

G140034WH

G140024UWH

G140034UWH

G140024CY

G140034CY

G140024UCY

G140034UCY

Former Jensen no.

G145024WH

G145034WH

G145024UWH

G145034UWH

G145024CY

G145034CY

G145024UCY

G145034UCY

Former Jensen no.

G150024

G152430

G150034

Attachment Kits, plus 4 Surface Mount Side Mirror Kits.

Attachment Kit, plus 2 Surface Mount Side Mirror Kits.

Style

Name

Deluxe Stainless Steel 4 15 25 141⁄4 24 4 Deluxe Stainless Steel 5 15 35 141⁄4 34 4 Deluxe Stainless Steel 4 15 25 141⁄4 24 6 Deluxe Stainless Steel 5 15 35 141⁄4 34 6 Deluxe White Steel 4 15 25 141⁄4 24 4 Deluxe White Steel 5 15 35 141⁄4 34 4 Deluxe White Steel 4 15 25 141⁄4 24 6 Deluxe White Steel 5 15 35 141⁄4 34 6

Style Name

Gloss White 213⁄8 313⁄8 Gloss White 213⁄8 413⁄8 Unfinished Poplar 213⁄8 313⁄8 Unfinished Poplar 213⁄8 413⁄8 Dark Cherry 213⁄8 313⁄8 Dark Cherry 213⁄8 413⁄8 Unfinished Cherry 213⁄8 313⁄8 Unfinished Cherry 213⁄8 413⁄8

Style Name

(for cabinets with a 24" wall opening height) (for cabinets with a 29" wall opening height—see page 7 for

product details) (for cabinets with a 34" wall opening height)

Cabinet

Body Shelves

Overall Size

w h

Overall Size

w h

Overall Size Wall Opening

w h w h d

Frame Profiles

31⁄2

Recessed

⁄2

Surface Mount

43⁄4

11⁄2

You provide the imagination.

Gallery Collection lets you

express yourself, so be as

creative as you desire.

Paint or stain your frame

however you wish. Or,

design your own frame

with sophisticated

mouldings. With

Gallery, you’re only

inhibited by your

imagination.

With Gallery Collection, you can also customize your storage. Here we’ve created a tri-view cabinet by recessing and ganging three cabinets together using our Gangable Attachment Kits.

Surrounding the three cabinets is a professionally crafted, custom frame (not supplied or offered by NuTone Premier). It demonstrates how a custom frame can be built to perfectly match your interior design and woodwork.

Shown: Unfinished Poplar frame with custom paint

Gangable Attachment Kit(s) must be used when two or more cabinets are mounted side-by-side to ensure proper attachment and spacing. Cabinets can be “ganged” together in either recessed or surface-mount installations. Shown above, three recessed Gallery Deluxe (72SS244D) cabinets joined by two horizontal Gangable Attachment Kits (76GK).

Shown: Studio V Series model S568N244SSSNP stainless steel cabinet, with Traditional Satin Nickel frame.

Shown: Traditional Frame S568N244SSBZP

Shown: Contemporary Frame S568N244SSCOC

Shown: Traditional Frame S568N246WHSNP with G1530 semi-recessed mirror kit

Studio V Series—in Traditional and Contemporary Frames. Now it’s easy to add

the perfect complement to today’s rich, bath hardware and fixtures. New metal

finish frames in traditional or contemporary profiles provide an alternative to

matching woodwork or cabinetry. With 72 size and style options there’s a sure

fit with any décor and storage need. Stainless steel or white painted cabinet

bodies, glass shelves and 170° Euro-style, soft-close hinges withstand the rigors

of everyday use. Light gathering mirrors on the inside door and cabinet back

double the functionality when open. Studio V Series bath cabinets take style and

sophistication in a fresh, new direction.

S t u d i o V S e r i e s

25" or 35" tall, 4" or 6" deep

170˚ Soft-close hinges

Stainless steel or white painted steel cabinet finishes

Framed 1/2" beveled front mirror

Three adjustable 1/4" thick glass shelves for superior light reflection (Four shelves on 35" model)

Snap-fit shelf supports lock glass shelves in place

Interior mirrors on the back of the cabinet and the inside door add light and functionality

Reversible mounting allows left- or right-hand opening

Shown: Studio V Series model S568N246SSSNP

Model Number

Mirror

Front

Cabinet

Finish

Door Type

Cabinet

Depth

Mirror Shape

Overall Size Wall Opening

w d w h d

Studio V Series Recessed, Semi-recessed and Surface Mount—See Accessory Kits Below.

Previous Jensen model numbers have been modified with the addition of the letter “N”

S568N244 S568N344 S568N246 S568N346

***** ***** ***** *****

Semi-recessed Side Mirror Kits for Studio V Series

G1530 (for 24" high cabinet with 6" depth) G1540 (for 34" high cabinet with 6" depth)

Surface Mount Side Mirror Kits for Studio V Series

Previous Jensen numbers: G150024 & G150034

760024 (for 24" high cabinet with 4" depth) 760034 (for 34" high cabinet with 4" depth)

Bevel Stainless/White Single 4 Rectangle 15 25 141⁄4 24 4 Bevel Stainless/White Single 4 Rectangle 15 35 14 Bevel Stainless/White Single 6 Rectangle 15 25 14 Bevel Stainless/White Single 6 Rectangle 15 35 141⁄4 34 6

Ordering Guidelines

1. Select your base model number.

2. Add the two-letter code for cabinet body option,

“SS” for stainless steel or “WH” for white.

3. Add the three-letter code for frame finish (color) and

style (traditional or contemporary). Example: To order a Studio V Series, 34" tall, 4" deep cabinet with a stainless steel body and a traditional Satin Nickel frame your model number will be S568N344SSSNP.

⁄4 34 4

⁄4 24 6

Shown: Studio V Series model S568N244WHSNC

170° concealed soft-close hinges allow wide door opening and smooth operation

Contemporary Frames

Oil-rubbed Bronze (BZC)

Satin Nickel (SNC)

Copper (COC)

White (WHC)

Traditional Frames

Black (BKP)

Satin Nickel (SNP)

Oil-rubbed Bronze (BZP)

White (WHP)

Espresso (ESP)

Traditional or Contemporary? Whatever

your décor preference is, the City Collection

lets you express yourself. Whether it’s the

timeless beauty of City Traditional or the

sleek, modern design of City Contemporary,

you’re sure to find the perfect complement and

simple sophistication for any décor.

Shown: 62BK244CN (261⁄2" tall,

4" deep with Contemporary

Chestnut Frame)

1 2 0 °

City Collection

⁄2" tall, 4" deep

Powder-coated satin-black cabinet

Reversible mounting allows left- or right-hand door opening

Exterior mirror is premium float glass that provides a deep rich reflection— flat-front available in City Contemporary and 5/8" beveled trim available in City Traditional

Three adjustable glass shelves for superior light reflection

Snap-fit shelf supports lock glass shelves in place

Interior mirrors on the back of the cabinet and the inside door add light and functionality

Rubber bumpers cushion the door for a quiet close

120° concealed hinges allow wide door

Shown: 62BK244CCN

Model Mirror Frame Door Cabinet Overall Size Wall Opening Number Front Finish Type Depth w h d w h d

opening and smooth operation

City Traditional Collection Recessed or Surface Mount*

62BK244TBK

62BK244TCY

⁄8" Bevel Black Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

⁄8" Bevel Cherry Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

62BK244TMP 5⁄8" Bevel Maple Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

62BK244TGK

⁄8" Bevel Oak Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

City Contemporary Collection Recessed or Surface Mount*

62BK244CBK Flat Black Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

62BK244CCY Flat Cherry Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

62BK244CCN Flat Chestnut Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

62BK244CMP Flat Maple Single 4 161⁄2 261⁄2 51⁄4 141⁄4 24 4

*Surface mount installations require an optional Surface Mount Side Mirror Kit model 760024 (see below).

Note: All measurements are in inches.

Surface Mount Side Mirror Kit

760024 (includes two side mirrors and mounting hardware)

Shown: City Traditional Oak 62BK244TGK

Shown: City Traditional Maple 62BK244TMP

Shown: City Traditional Cherry 62BK244TCY

City Traditional

Timeless design is the hallmark of the City Collection Traditional line. Available in fine-grained

woods with exquisite, durable finishes, our City Traditional frames lend simple sophistication to any décor.

The soft curves of the frame profile are enhanced by a crisp bevel on the premium float glass mirror. Give

the door a gentle tug and it glides open to reveal a rich, satin-black cabinet. Mirrored surfaces on the

inside door and the back of the cabinet gather light to add visibility. Locking shelf supports ensure the

adjustable glass shelves remain securely positioned. Fabricated from the best materials, City Traditional

frames will come to be viewed as fine furniture for your home, whether used to complement or contrast

with other textures, colors and finishes. See page 13 for specifications.

Shown: City Traditional Black 62BK244TBK

Shown: City Contemporary Maple 62BK244CMP

Shown: City Contemporary Chestnut 62BK244CCN

Shown: City Contemporary Black 62BK244CBK

Shown: City Contemporary Cherry 62BK244CCY

City Contemporary

Is it modern? Or is it Eurodesign? Whatever you call it, elegant simplicity describes it best. And

regardless of how you design with City Collection Contemporary frames, our four beautiful

wood finishes will cover every need. The shallow bevel of the frame rises from the wall surface to create

a clean and refined appearance. Smooth hinges silently guide the door open to present a satin-black

cabinet. With mirrors on the inside door and the back of the cabinet, as well as adjustable glass shelves,

light is reflected into every corner for superior visibility. Timeless in design, City Contemporary frames

will be a perfect complement to a broad range of colors, textures, and fine fabrics—now, and in

the years ahead. See page 13 for specifications.

Add a splash of color with a bold, vibrant iColor Collection bath cabinet. They’re contemporary, fashionable and sure to reflect your sense of style.

Metallic Onyx cabinet, 65MB244DF

Shown: iColor Collection

170°

iColor™ Collection

25" tall, 4" deep

Powder-coated steel cabinet in two colors

Reversible mounting allows left- or right-hand door opening

Exterior mirror is premium flat-front float glass that provides a deep rich reflection

Three adjustable glass shelves for superior light reflection

Snap-fit shelf supports lock glass shelves in place

Interior mirrors on the back of the cabinet and the inside door add light and functionality

Rubber bumpers cushion the door for a quiet close

Shown: iColor Collection,

Cobalt Blue cabinet, 65CB244DF

We heard it time and again—a bath cabinet is just a bath cabinet. And that got us

™

thinking; why should a product only be what people expect? iColor

Collection helps you

express your sense of style in two bold colors. These fabricated cabinets feature a durable

baked-on powder coat finish, and float glass mirrors to ensure a distortion-free reflection.

™

Whether surface mounted or recessed, iColor

Model Mirror Finish Door Cabinet Overall Size Wall Opening Number Front Type Depth w h d w h d

iColor Collection Recessed or Surface Mount*

65MB244DF Flat Metallic Onyx Single 4 15 25 5 141⁄4 24 4

65CB244DF Flat Cobalt Blue Single 4 15 25 5 141⁄4 24 4

*Surface mount installations require an optional Surface Mount Side Mirror Kit (see below).

Note: All measurements are in inches.

Surface Mount Side Mirror Kit

760024 (includes two side mirrors and mounting hardware)

is a cure for the common cabinet.

170° concealed hinges allow wide door opening and smooth operation

A LBC10 recess mounted, lights

shown not available from NuTone Premier

B A concealed door blends with

the beveled glass around it

C Multi-faceted beveled surfaces

Le Baccarat is a virtual diamond for the bath or powder room,

elegantly blending light and shape. Multi-faceted mirrored surfaces

and a concealed door sit beneath a broad, sweeping arch. With

premium float-glass that provides a deep, distortion-free reflection,

Le Baccarat provides a dazzling viewing experience from every angle.

Le Baccarat

353⁄8" tall, 37⁄8" deep

Multi-faceted 1/4" thick beveled mirrors provide a deep reflection

Eurodesign hinges open 115°

1/4" thick glass shelves for superior light reflection

Mount an accompanying 6-7/8" round magnifying mirror on the inside door to your height preference

Shown: LBC10 recess mounted

Model Frame Door Mirror Overall Size Wall Opening Number Type Type Shape w h d w h d

Le Baccarat Recessed Mount Only LBC10 Frameless Single Arched 24 353⁄8 41⁄8 161⁄2 251⁄4 37⁄8

Note: All measurements are in inches.

Stainless steel shelf supports

Interior back panel mirror

Stainless steel cabinet offers a beautiful aesthetic

Recessed installation only

Speakers Sensing Fans Chimes Heaters Fresh Air Systems

Trash Compactors Ceiling Fans Bath Fans

Range Hoods Intercoms Ironing Centers Central Vacuums

NuTone® is America’s leading brand of residential built-in convenience products including door chimes, central vacuum systems,

stereo intercom systems, ceiling fans, home theater speakers, bath cabinets, ironing centers and ventilation fans.

Broan

is America’s leading brand of residential ventilation products including range hoods, ventilation fans, heater/fan/light combination units, Indoor Air Quality (IAQ) Fresh Air Systems, built-in heaters, whole-house fans, attic ventilators and trash compactors.

Broan-NuTone Storage Solutions – a Division of Broan-NuTone LLC

501 S. Wilhite Street, Cleburne, TX 76031 • 800-325-8351 • Canada 877-896-1119

www.NuTone.com

Broan NuTone Premier User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
