Heating Products
arch 2012
M
Broan Heaters
Broan Heaters. Put the comfort
you want right where it’s needed.
2
Broan Heaters
Why spot heating makes sense in your home.
Think about it—you hastily get ready every morning,
head for work, the office, or school, just when the
central heating system has finished warming the entire
house. It’s about as inefficient as it gets. Spot heating
solves that problem. No longer will you heat an entire
home when you simply need a bit of comfort in the bath
or dressing room, or any other room.
Efficient Heating Element.
Even the most efficient central heating systems send
heat up the chimney. But NuTone spot heaters deliver
every bit of energy back into your home. There’s no
external venting, so the electricity you convert to heat
is delivered directly where you want it.
Simple, Safe and Efficient.
Permanently lubricated motors are quiet and require
no maintenance. They can be operated by a built-in
adjustable thermostat or an optional wall-mount
controller. Heaters may be converted in the field to a
choice of wattages/voltages. And for safety, heaters are
thermal overload protected and the complete heater
assembly conveniently removes from the housing
for cleaning.
3
Broan Heaters—Wall Heaters
High capacity wall heaters for residential and light commercial use. When you need more power for high heat-
loss areas, Broan’s large capacity wall heaters are an ideal solution for lobbies, entrance ways, vestibules or any
area requiring high wattage heating. Our low-profile models feature an energy-saving, built-in fan-delay switch
allowing the heating element to warm up before the fan starts. To ensure proper shutdown, and maximize heat
delivery, the fan remains on as the element cools down.
Models 9810WH & 9815WH
•Quiet fan and downflow action circulates heated air quickly.
•Dual-voltage 120V/240V (see chart for watts)
•Over temperature protected by thermal fuse
•Built-in adjustable thermostat. Quiet thermally-protected
motor and transverse flow blower
•White polymeric heat-resistant grille
4
Broan Heaters—Wall Heaters
Models 192, 194 & 198
Steel-sheathed, plate-finned, heavy-duty
enclosed heating element.
•Adjustable, built-in, heavy-duty, disc-type thermostat
•Manual reset overload protection
•Internal fan delay prevents cold air delivery
Model 192
•Factory wired for 2000W at 240V AC—easily
converts to half-wattage
Model 194
•Factory wired for 3000W at 240V AC—easily
converts to half-wattage
Model 198
•Factory wired for 4000W at 240V AC—easily
converts to half-wattage
Model* Watts Volts Amps
750W–1500W 208 3.61/7.21
192
1000W–2000W 240 4.17/8.33
1125W–2250W 208 5.41/10.82
194
1500W–3000W 240 6.25/12.5
1500W–3000W 208 7.21/14.42
198
2000W–4000W 240 8.33/16.67
9810WH 1000 120/240 9.0/4.5
9815WH 1500 120/240 13.0/6.5
*To be used to supply supplemental heat.
Surface Mounting Kit
Model 85
•Includes all hardware for surface mounting of Broan
High-Capacity heaters
•Color coordinated to match heater grille
•Heavy-duty 22-gauge steel
•Measures 17-3/4"W x 21-5/8"H x 3-3/4"D
•Not for use with models 9810WH and 9815WH
5
Broan Heaters—Wall Heaters
Heat that’s ready when you’re ready. These versatile heaters are factory wired at 500W, 750W, 1000W, 1500W or
2000W, and can be easily converted to other wattages and voltages. Count on Broan Comfort-Flo Heaters to deliver
precisely what you need for your home.
Wall Heater Features
•Sturdy 24-gauge steel housing mounts easily between studs
in any standard wall
•Surface mounted where needed
•Housing mask prevents construction damage to roughed-in units
•Snap-out wiring cover for wiring away from tight corners
•Project Packs available (see below and page 11)
Model 170
•Factory wired for 1000W at 120V AC—easily converts
to 500W at 120V AC or 1000W at 240V AC
Model 174
•Factory wired for 1500W at 120V AC—easily converts
to 750W at 120V AC or 1500W at 240V AC
Model 178
•Factory wired for 2000W at 240V AC—easily converts
to 1000W at 240V AC
Surface Mounting Kit
Model 84
• Includes all hardware for surface mounting of Broan
Comfort-Flo heaters
• White enameled, steel enclosure matches grille color
•12-3/8"W x 9-5/8"H x 3-7/8"D
Model* Watts Volts Amps
500W–1000W 120 4.16/8.33
170 750W 208 3.61
1000W 240 4.16
750W–1500W 120 6.25/12.5
174 1125W 208 5.41
1500W 240 6.25
750W–1500W 208 3.61/7.21
178
1000W–2000W 240 4.16/8.33
*To be used to supply supplemental heat.
Project Packs keep you on schedule: Broan Comfort-Flo
Heaters are available in project packs so you can install
the housing now and decide which finish kit is best suited
for your project later. Housing Units (the shell that holds
the heater) come in packages of four. Finish kits (the
heating element and grille) contain only one product. The
selection matrix on page 11 has more details to help you
select the right Project Pack for your installation.
6
Broan Heaters—Wall Heaters
Register Heaters. These powerful heaters are factory wired at 1000W, 1500W and 2000W and can be easily
converted to half-wattage for added versatility. The low-wall mounting and register-look grille in a neutral white
finish make them as inconspicuous as they are efficient.
Model 120
•Factory wired for 1000W at 120V AC—easily converts
to 500W at 120V, or 1000W at 240V AC
Model 124
•Factory wired for 1500W at 120V AC—easily converts
to 750W at 120V, or 1500W at 240V AC
Model 128
•Factory wired for 2000W at 240V AC—easily converts
to 1000W at 240V AC
Model* Watts Volts Amps
500–1000 120 4.16/8.33
120 750 208 3.61
1000 240 4.16
750–1500 120 6.25/12.5
124 1125 208 5.41
1500 240 6.25
750–1500 208 3.61/7.21
128
1000–2000 240 4. 16/8.33
*To be used to supply supplemental heat.
Line-Voltage Wall Thermostat
Model 86W
•Required for use with models 120,
124 and 128
•Single-pole, 120V/240V AC, 22 amps
•50° to 85° temperature range
•Snap-action, bimetallic sensing strip
7
Broan Heaters—Kickspace and Ceiling
Trimline Kickspace Heaters. If you don’t believe you
have room for auxiliary heat, you haven’t seen Trimline
kickspace heaters. They tuck under cabinet kickspaces,
vanity bases, stairways or any place where space is
limited. Consider them for light-commercial applications
such as ticket/toll booths and checkout counters where
ducting isn’t possible.
Model 112
•With built-in thermostat
•Steel-sheathed, plate-finned, heavy-duty heating element
•Factory wired 1500W at 240V AC, converts to 750W
or 1500W at 120V
Model 114
•Same as 112 without built-in thermostat
•Steel-sheathed, plate-finned, heavy-duty heating element
•Factory wired 1500W at 240V AC, converts to 750W
or 1500W at 120V
•Use Model 90 accessory built-in thermostat if desired
Model* Watts Volts Amps
750 120 6.3
112 and 114
*To be used to supply supplemental heat.
1125 208 5.4
1500 120 12.5
1500 240 6.3
Ceiling Heaters. Fan-forced or infrared bulb heat,
and convenient combinations. The reliable design and
quality construction is all Broan. Either way, you get
energy-saving warmth in compact, easy-to-install units.
Surface-mount Fan Forced Air
Model 154 & 157
Wire Element Heater—Model 154
•Chrome alloy, wire element for instant heat
•Low-profile housing with satin-finish aluminum grille
extends only 2-3/4" from ceiling
•Built-in fan disperses heat evenly
•Automatic overheat protection
•Permanently lubricated motor
•Mounts easily to any standard 3-1/2" or 4" round,
or 4" octagonal ceiling electrical box
Radiant Heater—Model 157
•Exclusive enclosed, sheathed, long-life element diffuses
heat throughout the room
•Low-profile housing with satin-finish aluminum grille
extends only 2-3/4" from ceiling
•Built-in fan disperses heat evenly
•Automatic overheat protection
•Permanently lubricated motor
•Mounts easily to any standard 3-1/2" or 4" round,
or 4" octagonal ceiling electrical box
Model Watts Volts Amps
154 1250 120 10.7
157 1250 120 10.7
8
Broan Heaters—Bulb Heaters
Bulb Heater Fans. Silent warmth and superior ventilation. Trust Broan Bulb Heater/Fans and Bulb Heaters for
energy-saving warmth and instant comfort without ever having to touch your central thermostat. These units deliver
superior performance and excellent ventilation in a compact package.
Bulb Heater/Fan Features
•Quiet, highly efficient polymeric blower wheels
•Polymeric dampers prevent backdrafts and eliminate
mechanical noise
•Polymeric 4" round duct connectors with tapered sleeves
simplify ducting
•Operate fan and heater independently or together
•Attractive, white polymeric grilles
•Compact steel housings feature adjustable mounting brackets
with keyhole slots that span up to 24"
•250-watt R40 or BR40 size infrared bulbs (not included)
•Type IC, UL Listed for 60°C wiring (retrofits)
Model 162
Bulb Heaters Only
•Infrared bulbs deliver energy-saving warmth
•Get instant comfort in the bathroom without turning up
the central thermostat
•250-watt R40/BR40 size infrared bulbs (not included)
•Attractive, white polymeric grilles
•Compact steel housings
•Adjustable mounting brackets with keyhole slots span up to 24"
Model 161
•One-Bulb Heater
•Non-type IC, use 75ºC minimum house wiring
Model 163
•One-Bulb Heater/Fan
Model 164
•Two-Bulb Heater/Fan
•Two-function control (available separately)
Model CFM Sones Watts Volts Amps
162 70 3.5 250* 120 2.5
164 70 3.5 500* 120 4.5
*Infrared bulbs not included
•Two-Bulb Heater
•IC rated
Model Watts Volts Amps
161* 250** 120 2.1
163 500** 120 4.3
*161 is not IC rated
**Infrared bulbs not included
9
Broan Heater—Portable
Why Broan Big Heat®? Because this rugged, reliable heater works as hard as you do. Our portable, electric heater is
the perfect solution to instant heat, with a full 1500 watts and a reliable, ceramic heating element to ensure fast warmup. It will keep you comfortable in nearly any situation—the garage, workshop or on the job. Rugged steel construction,
automatic shut-off if tipped over on its front or back, and overheat protection mean that Broan Big Heat is not only
durable, but safe. No matter where you put it to work, it’s just what you need, right when you need it.
Broan Big Heat® Portable Heater
Model 6201
•Rugged steel construction, durable finish with integrated
carrying handle and rounded bumpers to protect surfaces
•Instant, automatic safety shut-off if tipped over on its
front or back
•Overheat protection shuts off the heater and activates
the “caution” light if excess heat is detected
•Efficient, ceramic heating elements with full 1500 watts
for fast warm-up, 1200 watt setting maintains warmth
using less electricity
•High, low, or fan only settings with quiet operation
•Built-in thermostat to hold the comfort level you select
•6' cord with safety flanged plug
Broan Heater Accessories
Accessory
Number Product
82
83 Thermostat Kit
84 Surface Mount Kit
Low Voltage
Transformer/Relay
Model Watts Volts Amps
6201 1200–1500 120 10.0/12.5
For Heater
Models Description
192, 194, 198
165F, 167F, 170F,
174F, 178F
165F, 165FT, 167F, 167FT, 170, 170F,
170FT, 174, 174F, 174FT,
178, 178F, 178FT
Mounts inside and allows control of line voltage
in Broan High Capacity Heaters.
Built-in thermostat kit for Wall Heaters.
White enameled steel housing for surface
mounting a wall heater.
85 Surface Mount Kit 192, 194, 198
86W Line Voltage Wall Thermostat
90 Thermostat Kit 114
F and FT models are factory wired at 500–750 Watts.
10
Snap action, bi-metallic single
pole rated thermostat for
all heater products.
White enameled steel housing for surface
mounting a high capacity wall heater.
50°–85° rotary thermostat, white finish.
Built-in thermostat kit for kickspace heaters.
Temperature range 40°–130°
Broan Heaters—Wall Control
A B C D E F
A. Model 59W, 59V
•Timer control up to 60 minutes
•Fits single-gang box
•120V, 20 amps; 240V, 10 amps
•Blister packs available
•Operate continuously or for any
set period
B. Model 61W, 61V
•Timer control up to 15 minutes
•Fits single-gang box
•120V, 20 amps; 240V, 10 amps
•Blister packs available
•Operate for any set period up to 15
minutes (no “continuous on” position)
C. Model T24H
•24-Hour programmable timer
•120V, 8 amps inductive load
•Sets up to 36 on/off cycles as short
as 20 minutes
•Manual on/off override switch
•Fits single-gang box
D. Model 69WL, 69VL
•Single-Function Control with
indicator light
•Red light indicates power is on
•For use with Ultra Silent™ Series fan
units, or Remote In-Line Ventilators
•120V, 20 amps
E. Model 69W, 69V
•Single-Function Control
•120V, 15 amps
F. Model 86W
•For use with heater models 120,
124 and 128 (see page 7)
•Single-pole, 120V/240VAC, 22 amps
•50° to 85° temperature range
•Snap-action, bimetallic sensing strip
•Blister packs (P69WL, P69VL)
Heaters
112
114
120
124
128
154 1250 120 10.7 4266 11 Dia 23⁄4 — — Satin Aluminum
157 1250 120 10.7 4266 11 Dia 2
170
174
178
192
194
198
6201 1200/1500 120 10.0/12.5 4095/5120 57⁄8 51⁄4 6 31⁄2 33⁄4 Grey Baked Enamel
9810WH 1000 120/240 9.0/4.5 3413 10
9815WH 1500 120/240 13.0/6.5 5120 10
Heater
Wattage
750 120 6.3 2560 18 3
1125 208 5.4 3840 18 3
1500 120 12.5 5120 18 35⁄8 12 191⁄4 35⁄8
1500 240 6.3 5120 18 35⁄8 12 191⁄4 35⁄8
500/1000 120 4.16/8.33 1707/3413 10
1000 240 4.16 3413 101⁄4 73⁄4 33⁄4 141⁄4 91⁄4
750/1500 120 6.25/12.5 2560/5120 10
1500 240 6.25 5120 101⁄4 73⁄4 33⁄4 141⁄4 91⁄4
750/1500 208 3.61/7.21 2560/5120 10
1000/2000 240
500/1000 120 4.16/8.33 1707/3413 10
750 208 3.61 2560 101⁄4 73⁄4 33⁄4 12 91⁄4
1000 240 4.16 3413 101⁄4 73⁄4 33⁄4 12 91⁄4
750/1500 120 6.25/12.5 2560/5120 10
1125 208 5.41 3840 101⁄4 73⁄4 33⁄4 12 91⁄4
1500 240 6.25 5120 101⁄4 73⁄4 33⁄4 12 91⁄4
750/1500 208 3.61/7.21 2560/5120 10
1000/2000 240 4.16/8.33 3413/6827 101⁄4 73⁄4 33⁄4 12 91⁄4
750/1500 208 3.61/7.21 2560/5120 14
1000/2000 240 4.17/8.33 3413/6827 14
1125/2250 208 5.41/10.82 3840/7677 14
1500/3000 240 6.25/12.5 5120/10236 14
1500/3000 208 7.21/14.42 5120/10240 14
2000/4000 240 8.33/16.67 6827/13653 14
Volts Amps BTU/hr W" H" D" W" H" Grille Finish Housing Finish Kit
4.16/8.33 3413/6827 101⁄4 73⁄4 33⁄4 141⁄4 91⁄4
Housing Dimensions Grille Dimensions Project Packs
5
⁄8 12 191⁄4 35⁄8
5
⁄8 12 191⁄4 35⁄8
1
⁄4 73⁄4 33⁄4 141⁄4 91⁄4
1
⁄4 73⁄4 33⁄4 141⁄4 91⁄4
1
⁄4 73⁄4 33⁄4 141⁄4 91⁄4
3
1
⁄4 73⁄4 33⁄4 12 91⁄4
1
⁄4 73⁄4 33⁄4 12 91⁄4
1
⁄4 73⁄4 33⁄4 12 91⁄4
1
⁄4 20 41⁄4 163⁄8 201⁄4
1
⁄4 20 41⁄4 163⁄8 201⁄4
1
⁄4 20 41⁄4 163⁄8 201⁄4
1
⁄4 20 41⁄4 163⁄8 201⁄4
1
⁄4 20 41⁄4 163⁄8 201⁄4
1
⁄4 20 41⁄4 163⁄8 201⁄4
1
⁄2
1
⁄2
⁄4 — — Satin Aluminum
121⁄2
33⁄8
33⁄8
119⁄16
119⁄16
121⁄2
White Baked Enamel
White Baked Enamel750 208 3.61 2560 101⁄4 73⁄4 33⁄4 141⁄4 91⁄4
White Baked Enamel1125 208 5.41 3840 101⁄4 73⁄4 33⁄4 141⁄4 91⁄4
White Baked Enamel
White Baked Enamel 171H
White Baked Enamel 171H
White Baked Enamel 171H
White Baked Enamel
White Baked Enamel
White Baked Enamel
143⁄4
White Polymeric
143⁄4
White Polymeric
165F*, 165FT**, 167F*,
167FT**, 170F*, 170FT**
165F*, 165FT**, 167F*,
167FT**, 174F*, 174FT**
165F*, 165FT**, 167F*,
167FT**, 178F*, 178FT**
Project Packs. To reduce jobsite damage, Broan Heaters can be ordered in project packs which feature housings packed separately
from the finish kit. Install the housing and when drywall and painting is complete, add the heating element and grille.
*Use Project Pack Model Number 83 Thermostat Kit with these models. **Includes built-in thermostat.
F and FT models are factory wired at 500–750 Watts.
11
Broan. The leader in residential ventilation.
Speakers Sensing Fans Chimes Bath Fans
Trash Compactors Ceiling Fans Medicine Cabinets
Range Hoods Intercoms Ironing Centers Central Vacuums
Broan® is America’s leading brand of residential ventilation products including range hoods, ventilation fans, heater/fan/light
combination units, Indoor Air Quality (IAQ) Systems, built-in heaters, whole-house fans, attic ventilators
and trash compactors.
NuTone® is America’s leading brand of residential built-in convenience products including door chimes, central vacuum systems,
intercom systems, ceiling fans, home theater speakers, medicine cabinets, ironing centers and ventilation fans.
Indoor Air Quality
(IAQ) Systems
Broan-NuTone LLC, 926 W. State Street, Hartford, WI 53027 • 800-558-1711
©2012 Broan-NuTone LLC • Printed in USA • 03/12 99850829C
www.Broan.com
In Canada call 877-896-1119
FPO
Loading...
