QUICK START GUIDE
QUICK START GUIDE
SEE MORE ONLINE WWW.BRAVEN.COM/TUTORIALS
BATTERY INDICATOR LIGHTS
LEFT SIDE RIGHT SIDE
POWER SWITCH
BATTERY CHECK BUTTON
PAIRING / ANSWER-EN D CALL /
PAUSE-RESUME MUSIC
3.5 MM AUDIO-OUT JACK
(daisy-chain)
BRAVEN CHARG ING PORT
VOLUME U P /
SKIP TRACK (pr ess and hold)
EXTERNAL USB
CHARGI NG PORT
VOLUME DOWN /
SKIP BACK (pr ess and hold)
3.5 MM AUDIO-IN JACK
•20% •40% •60% •80% •1 00%
L R
TURN ON & BLUETOOTH® PAIRING
PAIRING TWO TOGETHER – WIRELESS STEREO-PAIRING
USING AS A BLUETOOTH
®
RECEIVER
WATER RESISTANT FEATURES
SEE MORE ONLINE WWW.BRAVEN.COM/TUTORIALS
1
2
3
4
TURN ON & BLUETOOTH PAIRING
To get started press the power
button for 2-3 seconds. When
you release the power button you
will hear the BRAVEN power-up
drone. (When you’re fnished
listening press the same button
again for 2-3 seconds to turn your
BRAVEN off.)
In order to pair your BRAVEN to your cell phone, tablet,
or other Bluetooth enabled source (hereafter referred
to as a “device”), frst activate Bluetooth on the device
(see your device’s instruction manual for information on
activating its Bluetooth settings).
Then press and hold the play button on your BRAVEN
until you hear the BRAVEN pairing call.
1
Next go to your device’s
Bluetooth settings and select
“B710” from the list.
(If asked for a passcode enter
“0000”) Your BRAVEN will
remember the last 8 devices it
has paired with.
PAIRING WITH NFC
If your device is NFC enabled, you can quickly pair via the
B710 speaker’s “NFC Deck”. First, ensure that
NFC on your device is turned on. Then place your NFCenabled device directly over the NFC logo on the base of
the B710 speaker. Hold it in place until you see
a prompt on your device asking you if you want to pair to
the B710 speaker. You may need to adjust the
positioning of the device on the NFC Deck to ensure the
device’s internal NFC transmitter aligns with the B710
speaker’s internal NFC receiver.
NOTE: If your BRAVEN does not have an active
Bluetooth connection and is left on, it will shut itself
off after 30 minutes to preserve the battery. To restart
your BRAVEN you will need to press and hold the power
button for 2-3 seconds.
PAIRING TWO TOGETHER –
WIRELESS STEREO-PAIRING
Want even bigger sound? If you have two B710
units (yeah, you should probably get two), you can
pair them together for left and right stereo using “True
Wireless” technology. Here’s how you do it:
First be sure to disconnect all Bluetooth connections
(if any) on your device and remove any previously paired
B710 speakers from your device.
Next, press and hold the battery check
button on both BRAVEN speakers for
5 seconds until you hear a sonar sound
from both speakers. Within 30 seconds, a
second beep will indicate a True Wireless
connection between the B710
speakers.
Now that the speakers are talking to one another, you need to get
them talking to your device, follow the steps in section 1 to pair
your device with one (not both) of your B710 units.
When you turn off either of the B710 speakers while
connected in True Wireless, both speakers will turn off. When
you’re ready to rock again in True Wireless, press the power
button on both B710 speakers within 5 seconds of
each other. Wait approximately 15 seconds. The B710
speakers will automatically reconnect to each other and to the
previously connected device. You will hear two beeps indicating
True Wireless is reestablished.
2
3
Note: True Wireless technology only supports one active
Bluetooth connection to your device at the same time.
If any other Bluetooth device (other than the paired
B710 speakers) is simultaneously connected
to your device, the B710 audio will distort. If
distortion occurs, power down all other Bluetooth
devices in range of your phone/tablet, other than the
B710. Refresh the Bluetooth connections on your
phone/tablet by turning Bluetooth off and then back on.
True Wireless is now reestablished.
For troubleshooting and tutorial videos, please go to
www.BRAVEN.com/TrueWireless
USING AS A BLUETOOTH
RECEIVER
The B710 has the unique ability to act as a
“Bluetooth Receiver” for other home or audio speaker
systems that are not natively equipped for Bluetooth
connectivity.
Simply connect one end of a 3.5mm/aux cable to the
“AUDIO I
N” port of your home or audio speaker system,
and plug the other end of the cable into the 3.5mm
“OUT” port on the B710 speaker. Then pair
your B710 speaker to your phone or tablet via
Bluetooth.
The audio will play over both the
B710 and your home or
audio speaker system. If you only
want the audio to play over your
other speakers (not through the
B710), press and hold the
B710 volume up (+) and
volume down (-) buttons simult
aneously while the audio is
playing, until the B710 audio stops.
WATER RESISTANT FEATURES
The B710 is IPX5 Water Resistant. B710
speakers are not intended to be submerged in
water, but are resistant to rainfall, water jets, and water
splashing.
IMPORTANT - To ensure your B710 speaker is
prepared for use in a wet environment, remove all cable
connections and tightly close the end water cap. If the
water cap is not properly closed, the B710 will
not be water resistant.
4
