Braun K 3000 Multisystem User Manual
K 3000
Accessories
Accessoires
Aksesuarları
Type 3211
MultiSystem
Braun Infoline
English 4
Français 7
Türkçe 10
16
Türkiye’deki Tüketici Danıs¸ ma Servisi:
TR
0 800 261 19 53
0 800 415 51 27 (Alo Arıza)
3 -211 -179/ 00/ II-00
GB/F /TR/ Arab.
Printed in Germany
Internet:
www.braun.com
AB C
1
5
d
c
e
b
c
a
d
b
2
d
a
a
DE
3
b
b
c
c
FG
4
d
5
d
e
e
f
J
K
6
n
7
e
n
f
f
ö
o
u
v
r
i
r
8
a
H
b
c
8
I
d
e
3
English
K 3000
The Braun K 3000 consists of the basic K 2000
with the stainless steel dough bowl plus a food
processor bowl and a glass liquidiser goblet.
Food processor bowl
(transparent receptacle)
with attachments
Use the food processor bowl for mixing,
chopping, cutting with the universal blade 3
or, when using the discs 5 for slicing,
shredding, grating.
1
Lid with filling tube and pusher
2
Protective cover
3
Universal blade
4
Food processor bowl
5
Discs
Ö
French fries disc
Ü
Julienne disc
á
Reversible slicing disc
à
Reversible shredding disc
â
Grating disc
ä
Disc carrier
(N.B.: All attachments for use with the food
processor bowl with the grey drive shaft are
grey.)
Maximum capacity:
2 l liquid (for milk-shakes 1.5 l).
Small quantities should preferably be
processed in the glass liquidiser goblet 8 with
blade 7.
Universal blade
Caution! The universal blade is very sharp.
The universal blade can be used for mixing,
chopping, cutting, but also for kneading dough
(e.g., yeast dough, max. 1 kg flour plus
ingredients, speed 2–7, approx. 3 mins).
Protective cover
Before use, remove the plastic cover by
standing the universal blade with the cover on
the table and pressing the knob downwards
until the protective cover loosens (A). The
universal blade can only be placed into the food
processor bowl 4 without its cover (B).
After use, replace the cover by standing the
universal blade on the table. The symbol on the
cover must be over the higher part of the
universal blade.
3
2
Slip the protective cover over the knob and hold
the cover with one hand. Pull the knob hard with
the other hand until the universal blade engages
with the cover (C).
Caution! The universal blade is very sharp –
only take hold of it by the plastic knob.
Place all ingredients into the food processor
bowl after attaching the universal blade.
Liquid ingredients may be added through the
filling tube while the motor is running.
After use, always remove the universal blade
before removing the processed food.
Blending soups, milk-shakes etc.
Speed: 7–14, appr. 30 seconds
At maximum capacity of 2 l use speed 8
(to avoid risk of frothing over).
Shakes (maximum 1.5 l): cut fruits, fill in and
pre-mix at speed 14, then add liquid at speed 7
and mix (please note that milk easily frothes
over when mixed; use lower quantity
accordingly).
Cutting, chopping
Speed 2–14 See processing table
Processing examples for the universal blade
The processing times are approximate and depend on the quality and amount of food to be processed and the degree of fineness required.
The number of pulses refers to «auto.pulse».
Product Max. amount Preparation Speed Switch position Time/pulses
Onions 750 g quartered 14 auto.pulse 15 x
Carrots 1000 g in pieces 14 I/on 20 secs
Hard bread rolls (for bread-crumbs) 6 quartered 14 I/on 45–60 secs
Eggs, hard-boiled 10 whole 7 – 9 auto.pulse 10 – 12 x
Apples 750 g quartered 7 – 9 I/on 10 – 15 secs
Meat (lean) 750 g 3 cm cubes 14 I/on 45 secs
Parsley drained 200 g
Nuts, almonds 1000 g whole 14 I/on 45 – 60 secs
Cheese (hard, medium) 500 g 3 cm cubes 14 I/on 60 secs
Cheese (soft) 500 g 3 cm cubes 14 I/on 30 secs
Chocolate 400 g in pieces 14 I/on 30 – 45 secs
Mixed drinks 1.5 litre chop fruits before adding
Mayonnaise (whole eggs, oil,
vinegar, seasoning, mustard)
Recipe example:
Gingerbread Preparation Speed Switch Time
200 g candied lemon peel
100 g hazelnuts chop candied lemon peel and hazelnuts 14 I/on 45 secs
180 g flour, 6 g baking powder add flour and baking powder 14 I/on 5 secs
1000 g honey
(creamy, chilled) then add honey and mix 14 I/on 15 secs
Smooth the mixture onto a greased and floured baking tray and bake at 150 °C for approx. 50-60 minutes. Cut into squares while still warm.
(4 bunches)
1.5 litre room temperature,
remove stalks 14 I/on 30 secs
liquids (pre-mix)
(mix)
add oil slowly
3
14
8
8
14 I/on 75 – 90 secs
I/on 60 secs
4
Discs
Place the disc needed onto the disc carrier
ä
direction of the arrow (D) until it engages.
Remove by turning clockwise.
Push the disc carrier with the disc onto the
drive shaft in the food processor bowl as far as
possible (E). Then place the lid onto the food
processor bowl and lock it (F).
When using discs, always turn the motor
switch to constant operation (position «I/on»).
When processing juicy or soft ingredients, you
will obtain better results at a lower speed. Hard
foods should be processed at a higher speed.
When adding ingredients through the filling
tube (G), always use the pusher. Never reach
into the filling tube when the motor is running.
Discs Ö, Ü, á:
For the most even results, push the food to
be processed into the filling tube when the
appliance is switched off.
Discs
Food can be pushed into the filling tube while
the motor is running.
French fries disc
Speed 2–7
Caution! This disc is ver
The writing must be facing the user.
For best results, fill 4– 5 raw potatoes into the
filling tube at once.
Processing examples: raw potatoes, celery.
Julienne disc
Speed 2–7
Caution! This disc is ver
The writing must be facing the user.
This disc cuts vegetables into strips. lf you
push the vegetables into the filling tube
vertically, the strips will be shorter. lf you push
them in at a slant or horizontally, the strips will
be longer.
Processing examples: cucumbers, carrots,
beetroot, radishes, celery, kohlrabi, raw
potatoes.
5
and turn the disc anti-clockwise in the
à, â
:
Ö
y sharp.
Ü
y sharp.
processed at speed 2–7, hard foods can be
shredded at a speed up to 14.
Processing examples «coarse»: cucumbers,
kohlrabi, beetroot, carrots, raw potatoes,
apples, cabbage.
Processing examples «fine»: cheese
(soft, medium hard), cucumbers, carrots,
raw potatoes, apples.
Grating disc
Speed 7–14
The writing must be facing the user.
Processing examples: raw potatoes (e. g., for
potato pancakes), horseradish, parmigiano
cheese (hard).
â
Glass liquidiser goblet
Use the glass liquidiser goblet 8 for mixing,
chopping and cutting small quantities.
6
Lid
7
Blade
8
Glass liquidiser goblet
Ö
Screw fastening
Ü
Plastic ring
á
Glass goblet
à
Seal
â
Drive shaft with bottom
Maximum capacity: 1l liquid
(for milk-shakes 750 ml).
Larger quantities should preferably be
processed in the food processor bowl 4 with
the universal blade 3.
Important: The maximum processing time in
the glass liquidiser goblet is 1 minute. Liquids
may be processed longer.
Caution! The blade 7 is ver
hold of it by the plastic knob.
Place all ingredients into the glass liquidiser
goblet after having inserted the blade.
Liquids can only be added through the hole
in the lid if the motor is running. After use,
always remove the blade from the goblet
before removing the processed food.
y sharp – only take
Disassembling and assembling
Lid
For cleaning, remove the seal from the inside
of the lid. Please replace the dry seal so that
the plastic clips in the lid fit into the groove of
the seal (H).
Blade
Caution! The blade is very sharp.
Remove the blade from the goblet by taking
hold of the knob and, while pressing down
with your thumb, pulling it off the drive shaft (I).
To insert the blade into the goblet, press it
onto the drive shaft until it clicks.
Glass liquidiser goblet 8
Remove the blade as described above.
To disassemble the goblet (J), first turn it
upside down, reach into it with one hand and
hold the plastic base of the drive shaft.
Then, using the pusher, unscrew the fastening
of the bottom by turning anti-clockwise (D).
Take off the screw fastening (a), the plastic
ring (b) and the goblet (c) one after the other,
so that finally, you only hold the drive shaft (e)
with bottom and seal (d) in your hand.
To re-assemble, please proceed in the reverse
order (K):
Place the seal onto the lower side of the drive
shaft bottom.
Turn the goblet upside down and place the
opening in the goblet bottom over the seal
on the drive shaft bottom. Please, be careful
not to dislocate the seal.
Place the plastic ring (b) onto the goblet
bottom so that the projection on the plastic
ring engages with the groove in the bottom
of the goblet (next to handle).
Fasten all of these parts by turning the screw
fastening (a) clockwise by means of the pusher.
Reversible slicing disc
Speed 2–7
Caution! This disc is ver
lt can be used from both sides (coarse/fine).
Processing examples «coarse»: cucumbers,
kohlrabi, raw potatoes, onions, leeks, salami,
bananas, tomatoes, mushrooms, radishes,
lettuce (rolled up tightly), celery.
Processing examples «fine»: cucumbers, cabbage, raw potatoes, carrots, onions, salami,
radishes.
Reversible shredding disc
Speed 2–14
This disc can be used from both sides (coarse/
fine). Soft foods (e.g., cucumbers) should be
á
y sharp.
à
Blending of soups, milk-shakes,
baby food etc.
Speed 2–14, approx. 1 min
Cut the fruits for milk-shakes into smaller
pieces and process it before adding liquid.
Maximum capacity: 750 ml liquid, otherwise it
could froth over.
Hot foods can also be blended in this heatresistant goblet. Baby food remains warmer
if the glass liquidiser goblet is warmed with
hot water beforehand.
Chopping
Speed 2–14, auto.pulse
Parsley, garlic, onions or nuts can be chopped,
as well as hard bread rolls for bread-crumbing
and meat.
Do not chop: chocolate, parmigiano cheese,
ice, hard spices or coffee.
5
