BOSCH TAS4504 User Manual

TAS 45xxGB/CH

en Instruction manual de Gebrauchsanleitung fr Mode d’emploi it Istruzioni per l’uso

1 English 7 Deutsch 13 Français 19 Italiano

en Safety instructions de Sicherheitshinweise fr Consignes de sécurité it Avvertenze di sicurezza

en At a glance de Auf einen Blick fr Présentation it Panoramica

en Troubleshooting de Hilfe bei Problemen fr Aide en cas de problèmes it Soluzione di guasti

5 4

b d

e/f

c b a

en Risk of electric shock! de Stromschlaggefahr! fr Risque de choc électrique ! it Pericolo di scossa elettrica!

en Risk of burns! de Verbrennungsgefahr! fr Risque de brûlure ! it Pericolo di ustioni!

Safety instructions

Instruction manuals

Please read parts 1 and 2 of these manuals carefully before using the product and keep them for future reference. Passthemon to all users.

Intended use

This appliance is designed for the preparation of small amounts of coffee for domestic use or for use in household-like, non-commercial environments. Household-like environments include, for example, use in staff areas in shops, offices, agricultural and other small businesses, as well as use by guests at bed-and-breakfast establishments, small hotels and similar residential facilities.

Children younger than 8 years may not operate the appliance. This appliance may be used by children aged 8 years and older and by persons with reduced physical, sensory or mental capabilities or who lack experience and / or knowledge if they are supervised or have been given instruction in the safe use of the appliance and have understood the dangers involved. Children may not play with the appliance. Cleaning and user maintenance may be carried out by children of 8 years and older under supervision. The appliance and its connection cable must be kept away from children younger than 8 years of age.

For optimum results, fill the tank only with cool, fresh, non-carbonated water each day. Do not use chemically softened water.

Ambient conditions

Only use the appliance indoors at room temperature and up to 2000 m above sea level.

1 en

Safety instructions

Power connection

Operate and connect the appliance only in accordance with theinstructions given on the nameplate.

Only use your TASSIMO appliance if the power cable and appliance show no signs of damage.

Repairs

Disconnect the appliance from the mains as soon as a fault is detected.

Any repairs, such as replacing a damaged power cable, may only be carried out by our Customer Services team in order to avoid potential danger.

Risk of burns!

Never attempt to open the brewing unit during operation. Pleasenote that any escaping liquids will be very hot. TheTDISC, the piercing unit and the beverage outlet may be very hot immediately after brewing. Allow to cool first. Do not use TDISCs that are damaged. Only use each TDISC once.

Risk of electric shock!

Before cleaning, switch off the appliance using the On / Off switch and disconnect from the mains. Never immerse the appliance or power cable in water.

Risk of injury!

Under no circumstances should you drink the descaling liquid.

Saving energy

You should switch off your TASSIMO appliance after every use in order to save energy.

2en

At a glance

Before reading on, please unfold the illustrations page at the start of the booklet.

1 On / Oﬀ switch 2 Start / Stop button 3 Indicators

a c Status LED S b Fill water tank P c Descale Q

4 Brewing unit

a Lid b TDISC support c TDISC piercing unit d TDISC reading window e Beverage outlet f Splash guard

Disposal

Dispose of packaging in an environmentally-friendly manner. This appliance is labelled in accordance with European Directive 2012/19/EG concerning used electrical and electronic appliances (waste electrical and electronic equipment – WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.

Used BRITA MAXTRA water ﬁlter cartridges can be disposed of with the regular household garbage.

Please ask your specialist retailer about current disposal facilities.

5 Removable water tank

a max mark b ”Descaling” Q mark c Float d Filter cartridge holder e BRITA MAXTRA ﬁlter cartridge

6 BRITA cartridge replacement

indicator

7 Storage compartment

a Orange Service TDISC b Brief cleaning / descaling

instructions

8 Cup stand

(removable and height adjustable)

a Drip grate b Drip tray

9 Cord storage compartment

Info

Bosch is the manufacturer of the TASSIMO machine. Therefore, it cannot provide any delivery guarantee for the TASSIMO T DISCs.

TASSIMO TDISCs are available from specialist retailers.

Or visit www.tassimo.com to discover the large variety of beverages available and to order your discs online.

More information on the use of BRITA ﬁlter cartridges and the ‘Memo’ can be found in the BRITA information guide.

3 en

Troubleshooting

The following table contains solutions to problems or faults which may occur during operation of the appliance and that can be easily rectiﬁed at home. If you are not satisﬁed with the solutions provided here, please contact our Customer Service department. Further customer service information can also be found online: www.tassimo.com

Problem Cause Solution

The appliance is not working and none of the display elements (LEDs) are lighting.

The brewing starts, however there is no beverage dispensed.

The brewing will not start.

The brewing unit cannot be closed.

The appliance has no power supply.

The appliance is no switched on.

The water tank is not inserted correctly.

The water tank was removed during the brewing stage or there is air in the system.

The ﬂoat in the water tank is stuck.

No TDISC inserted. Check that a TDISC has been inserted. The appliance does not

recognise the TDISC bar code.

The brewing unit is not closed properly.

The appliance was not switched on when inserting the TDISC.

The piercing unit and/ or the TDISC support have not been correctly inserted.

The TDISC has not been correctly inserted.

The brewing unit is not closed properly.

Check to see whether the appliance is con nected to the mains.

Make sure the appliance has been switched on.

Check that the water tank is correctly inserted.

Start the cleaning process with the orange Service TDISC. Please refer here to the section â First Time Use, Steps 2 – 14.

Clean the water tank and free the ﬂoat.

Clean the TDISC reading window with a soft, damp cloth.

Smooth out the foil of the TDISC with your ﬁnger so that the bar code can be read.

Use a new TDISC. If the problem persists, contact the TASSIMO

careline. Clean the brewing unit with a soft, damp cloth,

paying particular attention to the lid area. Switch on the appliance before inserting the

TDISC

Press the piercing unit into its holder using both thumbs and check the position of the TDISC support.

Replace the damaged TDISC with a new one. Place the TDISC with the printed side facing downwards so that the tab is resting in the intended slot.

Clean the brewing unit with a soft, damp cloth, paying particular attention to the lid area.

Press the lid down until it audibly clicks into place.

4en

Troubleshooting

Problem Cause Solution

The brewing unit cannot be opened.

Fill water tank R lightsup.

Fill water tankR lights up even though there is enough water in the water tank.

Fill water tank R and Descale Q are ﬂashing simulta neously and it is not possible to prepare drinks.

Descale Q lights up or starts ﬂashing.

Descale Q lights up or starts ﬂashing even though decalciﬁed water has been used.

The quality of the crema has deteriorated.

Water is dripping from the brewing unit.

On the surface below the cup stand there is water.

The brewing unit is still locked.

There is not enough water in the water tank.

The ﬂoat in the water tank is stuck.

The water tank is not inserted correctly.

There is a fault on the machine.

The appliance needs to be descaled.

Even decalciﬁed water contains low amounts of calcium carbonate.

The beverage outlet is sticky or dirty.

Build-up of limescale in the appliance.

The TDISC is damaged or leaky. The TDISC has not been pierced cor

The piercing unit has not been inserted correctly.

This is condensation. Condensation may appear and is not caused

rectly.

Wait until the Status LED S has stopped blinking before attempting to open the

If the brewing unit stays locked, contact the TASSIMO careline.

Fill the tank with cold, fresh water as far as the max mark. Reinsert the water tank.

Clean the water tank and free the ﬂoat.

Check that the water tank has been correctly inserted.

Turn the machine oﬀ using the On / Oﬀ switch, wait approximately 5 minutes and turn the machine back on. If R and Q are still ﬂashing, please contact the TASSIMO careline.

Descale the appliance. Please refer here to the section áDescaling.

Clean the beverage outlet. Please refer here to the section àCleaning.

Clean the brewing unit with the orange Service TDISC. Please refer here to the section àCleaning.

Descale the appliance. Please refer here to the section áDescaling.

Do not use TDISCs that are damaged. Only use each TDISC once.

ait until t

W an end and the appliance has cooled down. Remove the TDISC and clean the brewing unit. Please refer here to the section àCleaning.

Press the piercing unit into its holder using both thumbs (until an audible click is heard).

by any fault with the appliance. Wipe the water away with a cloth.

brewing unit.

he brewing stage has come to

5 en
