Bosch NXF-9130-A4 User Manual

EXTEGRA IP 9000 FX

NXF-9x30

en Software Manual

EXTEGRA IP 9000 FX Table of Contents | en 3

Table of contents

1

2

2.1 Using the camera 6

2.2 Operation with external systems 6

3

3.1 System Requirements 7

3.2 Configuring the Camera 8

3.3 Configuring Audio (Optional) 12

4

4.1 Basic Mode: Device Access 13

4.2 Basic Mode: Date/Time 14

4.3 Basic Mode: Network 14

4.4 Basic Mode: Encoder 15

4.5 Basic Mode: Audio 17

4.6 Basic Mode: Recording 17

4.7 Basic Mode: System Overview 17

5

5.1 Advanced Mode: General 18

5.2 Identification 18

5.3 Password 18

5.4 Date/Time 19

5.5 Display Stamping 20

5.6 Advanced Mode: Web Interface 22

5.7 Appearance 22

5.8 LIVE Functions 23

5.9 Logging 24

5.10 Advanced Mode: Camera 24

5.11 Installer Menu 24

5.12 Encoder Profile 26

5.13 Encoder Streams 29

5.14 Picture Settings 31

5.15 Lens Settings 34

5.16 Miscellaneous 35

5.17 Logs 35

5.18 Audio 36

5.19 Pixel Counter 36

5.20 Advanced Mode: Recording 36

5.21 Storage Management 36

5.22 Recording Profiles 38

5.23 Maximum Retention Time 39

5.24 Recording Scheduler 40

5.25 Recording Status 41

5.26 Advanced Mode: Alarm 41

5.27 Alarm Connections 41

5.28 VCA 43

5.29 Audio Alarm 47

5.30 Alarm E-Mail 48

Short information 5

System overview 6

Configuration 7

Configuration via IP, Basic Mode 13

Configuration via IP, Advanced Mode 18

Bosch Security Systems Software Manual 2015.02 | 1.0 |

4 en | Table of Contents EXTEGRA IP 9000 FX

5.31 Alarm Task Editor 49

5.32 Alarm Rules 49

5.33 Advanced Mode: Interfaces 50

5.34 Alarm Inputs 50

5.35 Alarm Outputs 50

5.36 Advanced Mode: Network 50

5.37 Network Access 50

5.38 DynDNS 53

5.39 Advanced 54

5.40 Network Management 55

5.41 Multicast 56

5.42 Image Posting 57

5.43 Accounts 57

5.44 IPv4 Filter 58

5.45 Encryption 58

5.46 Advanced Mode: Service 58

5.47 Maintenance 58

5.48 Licenses 60

5.49 System Overview 60

6

Operation 61

6.1 LIVE Page 61

6.1.1 Image selection 61

6.1.2 Storage, CPU and network status 61

6.1.3 View Control 62

6.1.4 AUX Control 64

6.1.5 Presets 65

6.1.6 Digital I/O 66

6.1.7 System Log/Event Log 66

6.1.8 Audio 67

6.1.9 Saving snapshots 67

6.1.10 Recording 67

6.1.11 Playback 67

7

Appendix 69

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Short information | en 5

1

Short information

This manual has been compiled with great care and the information it contains has been
thoroughly verified. The text was correct at the time of printing, however, the content can
change without notice. Bosch Security Systems accepts no liability for damage resulting
directly or indirectly from faults, incompleteness or discrepancies between this manual and
the product described.

Trademarks

All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.

More information

For more information please contact the nearest Bosch Security Systems location or visit
www.boschsecurity.com

http://www.boschsecurity.com/catalog_overview.htm

Bosch Security Systems Software Manual 2015.02 | 1.0 |

6 en | System overview EXTEGRA IP 9000 FX

2

2.1

2.2

System overview

Using the camera

To access the features of the camera, use a web browser. The browser provides live viewing of
the camera streams in the interface window, and also allows you to access and change the
extensive list of settings and parameters for camera configuration. Refer to the software
manual for more information on the browser interface.
The camera recording and storage functions include local alarm recording and recording to
iSCSI-based systems. The camera can also use the Bosch Video Recording Manager (VRM) to
control recording and storage. Integration with the many Bosch recording solutions is
seamless.

Operation with external systems

Using a web browser to access the camera’s video streams and functions is the most direct
way of using the camera. The Bosch Video Client can be downloaded and used for multiple­camera viewing, playback and configuration. A Bosch Video Security App is also available for
remote viewing.
If the camera is used in larger surveillance systems, the Bosch Video Management System
offers a perfect integrated solution.
Third-party integrators can easily access the internal feature set of the camera for integration
into large projects. Access to IVA metadata is available to integrators via RTSP.
When connected to external systems, many of the camera configuration parameters are
controlled by the system and not by the settings made via a web browser.

Bosch Video Client

The Bosch Video Client is a free Windows application to view, operate, control, and administer
surveillance cameras and installations at remote locations. It offers a user-friendly interface for
easy live viewing of multiple cameras, playback, forensic search and export.

Bosch Video Management System

The Bosch Video Management System is a unique enterprise IP video surveillance solution that
provides seamless management of digital video, audio and data across any IP network. It is
designed to work with Bosch security products as part of a total video surveillance
management system.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration | en 7

3

3.1

Configuration

System Requirements

The camera requires specific software and hardware to allow a user to view live images and to
configure camera settings over a TCP/IP network. These requirements are:
– A computer with the Microsoft operating system Windows 7 or later
– A connected video monitor
– Network access
– Microsoft Internet Explorer Web browser version 8.0 or later
– VMS software, the Video Client, or a compatible third-party VMS
– A compatible hardware decoder from Bosch Security Systems as a receiver (optional)

Notice!

The Web browser must be configured to enable Cookies to be set from the IP address of the

unit.

In Windows 7, deactivate protected mode on the Security tab under Internet Options. You can

find notes on using Microsoft Internet Explorer in the online Help in Internet Explorer.

You can find notes on using Microsoft Internet Explorer in the online Help in Internet

Explorer.

If you choose to use a computer running Microsoft Internet Explorer or any of the Bosch
software, the computer must conform to the following minimum requirements:
– Operating System: Windows 7 (32 or 64 bits)
– Processor: Intel Pentium Quad Core, 3.0 GHz or comparable
– RAM: 2048 MB
– Free Hard Disk Space: 10 GB
– Video system: NVIDIA GeForce 8600 or higher display with a minimum of 16-bit color
– Network interface: 100/1000-BaseT
– Software:

– Microsoft Internet Explorer, version 8.0 or higher
– Video Client
– DirectX 9.0c

– Oracle Java Virtual Machine 1.6.0_26 or newer
The camera requires specific software and hardware to allow a user to view live images and to
configure camera settings over a TCP/IP network. These requirements are:
– A computer with the Microsoft Windows XP, Vista, or Windows 7 operating system,

network access, and the Microsoft Internet Explorer Web browser version 8.0 or later, or
– A computer with Microsoft Windows XP, Vista, or Windows 7 operating system, network

access, and reception software such as the Bosch Video Management System or the

Video Client, or
– A compatible hardware decoder from Bosch Security Systems as a receiver and a

connected video monitor.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

8 en | Configuration EXTEGRA IP 9000 FX

Notice!

The Web browser must be configured to enable Cookies to be set from the IP address of the

unit.

In Windows 7, deactivate protected mode on the Security tab under Internet Options. You can

find notes on using Microsoft Internet Explorer in the online Help in Internet Explorer. In

Windows Vista, deactivate protected mode on the Security tab under Internet Options.

You can find notes on using Microsoft Internet Explorer in the online Help in Internet

Explorer.

If you choose to use a computer running Microsoft Internet Explorer or any of the Bosch
software, the computer must conform to the following minimum requirements:
– Operating System: Windows XP (Service Pack 3) or Windows 7 (32 or 64 bits)
– Processor: Intel Pentium Quad Core, 3.0 GHz or comparable
– RAM: 2048 MB
– Free Hard Disk Space: 10 GB
– Video system: NVIDIA GeForce 8600 or higher display with a minimum of 16-bit color
– Network interface: 100/1000-BaseT
– Software:

– Microsoft Internet Explorer, version 8.0 or higher
– Video Client
– DirectX 9.0c

– Oracle Java Virtual Machine 1.6.0_26 or newer
The camera includes the means to decode the video via a web browser; however, for more
advanced features such as local recording to PC, snapshot, and full screen display, you must
obtain MPEG-ActiveX.
For the latest versions of the Video Client, DirectX, Oracle Java Virtual Machine, and MPEG­ActiveX software, go to www.boschsecurity.com, navigate to the product page for your camera,
and then download the software from the Software tab.

Notice!

Ensure that the graphics card is set to 16-bit or 32-bit color. If you need further assistance,

contact your PC system administrator.

Maximum Number of Connections

If you do not connect, the unit may have reached its maximum number of connections.
Depending on the unit and network configuration, each camera can have up to 50 Web
browser connections or up to 100 connections via the Bosch Video Management System
(BVMS).

Protected Network

If a RADIUS server is employed in the network for managing access rights (802.1x
authentication), the camera must be configured accordingly, otherwise no communication is
possible.

3.2

Configuring the Camera

To operate the camera in your network, you must assign a valid network IP address to it. If
your network has a DHCP server, the IP address of the camera defaults to the first address
available. If your network does not have a DHCP server, the default IP address of the camera is

192.168.0.1. You may need to change this address if it conflicts with another device on your
network. Refer to Basic Mode: Network, page 14 for more information.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration | en 9

To configure the camera properly for your network, you need the following information:
– Unit IP address: An identifier for the camera on a TCP/IP network. For example,

140.10.2.110 is a valid syntax for an IP address.
– Subnet mask: A mask used to determine what subnet an IP address belongs to.
– Gateway IP address: A node on a network that serves as an entrance to another network.
– Port: An endpoint to a logical connection in TCP/IP and UDP networks. The port number

identifies the use of the port for use through a firewall connection.

Notice!

Ensure that the network parameters of your cameras are available before you begin

configuration.

The camera defaults are as follows:
– IP Address: 192.168.0.1 or first available address (see above)
– Subnet Mask: 255.255.255.0
– Gateway IP Address: 0.0.0.0
The following sections provide instructions about installing the software necessary to view
images over an IP connection, configuring the IP network settings and accessing the camera
images from a Web browser.
The camera has a default IP address of 192.168.0.1. To change the IP address or any network
settings, you can use the Configuration Manager software or the built-in Web server.

Notice!

Contact your local network administrator for a valid IP address, Subnet Mask, and a Gateway

IP Address.

Using the Configuration Manager

Configuration Manager is an optional network utility provided on the Bosch Security Systems
Web site. Use the Configuration Manager Manual to make any configuration changes.

Notice!

Depending on the PC network security settings, the user may need to add the new IP address

to the browser’s trusted sites list for the controls to operate.

Using the built-in Web server

To configure the device using the built-in Web server, do the following:

1. Set the IP address on the PC to 192.168.0.10 to ensure that the PC and the device are on

the same Subnet.

2. Launch your web browser (such as Microsoft Internet Explorer) and navigate to the

following URL: http://192.168.0.1
The web browser opens the LIVE page for the device; a security warning message is
displayed.

3. Check the Always Trust Box, and then click YES.

4. Click the Settings link, located at the top of the LIVE page.

5. In the left pane of the window, click Advanced Mode, and then click Network. The

Network menu expands.

6. Click Network Access to open the Network Access page.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

en | Configuration EXTEGRA IP 9000 FX

10

Figure 3.1: Network Access page

1. Configure the settings on this page based on the addresses provided by your local
network administrator. Note that the text on the Set button changes to Set and Reboot.

2. Click Set and Reboot. The device will reset (go through the reboot sequence, which
usually takes 30 seconds to complete), and then the LIVE page appears, with updated
video and the new IP address.

2015.02 | 1.0 | Software Manual Bosch Security Systems

!

EXTEGRA IP 9000 FX Configuration | en 11

Notice!

Click the Help on this page? link if you need more information.

NOTE: Screenshots of configuration settings in this manual are from an AUTODOME 7000 HD

model. Because of firmware or software updates, the screenshots may differ slightly from the
configuration settings screens in your system. Every effort has been made to ensure that the
information in this manual is accurate and current.
NOTE: Screenshots of configuration settings in this manual are from a MIC 7130 model.
Because of firmware or software updates, the screenshots may differ slightly from the
configuration settings screens in your system. Every effort has been made to ensure that the
information in this manual is accurate and current.

About the SETTINGS Page

The SETTINGS page provides access to the configuration menu, which contains all the unit's
parameters arranged in groups. You can view the current settings by opening one of the
configuration screens. You can change the settings by entering new values or by selecting a
predefined value from a list field.
There are two options for configuring the unit or checking the current settings:
– Basic mode
– Advanced mode
In Basic Mode, the most important parameters are arranged in seven groups. This allows you
to change the basic settings with just a few entries and then put the device into operation.
Advanced Mode is recommended for expert users or system support personnel. You can
access all unit parameters in this mode. Settings that affect the fundamental functionality of
the unit (such as firmware updates) can only be altered in the advanced mode.

Caution!

The settings in the Advanced Mode should only be processed or modified by expert users or

system support personnel.

All settings are backed up in camera memory so they are not lost even if the power fails. The
exception is the time settings, which are lost after 1 hour without power if no central time
server is selected.

Starting Configuration

4 Click the SETTINGS link in the upper section of the window. The Web browser opens a

new page with the configuration menu.

Navigation

1. Click one of the menu items in the left window margin. The corresponding submenu is
displayed.

2. Click one of the entries in the submenu. The web browser opens the corresponding page.

Making Changes

Each configuration screen shows the current settings. You can change the settings by entering
new values or by selecting a predefined value from a list field.
Not every page has a Set button. Changes to pages without a Set button are set immediately.
If a page does show a Set button, you must click the Set button for a change to take effect.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

!

12 en | Configuration EXTEGRA IP 9000 FX

Caution!

Save each change with the associated Set button.

Clicking the Set button saves the settings only in the current field. Changes in any other fields

are ignored.

Some changes only take effect after the unit is rebooted. In this case, the Set button changes
to Set and Reboot.

1. Make the desired changes.

2. Click the Set and Reboot button. The camera reboots and the changed settings are
activated.

3.3

Configuring Audio (Optional)

Enabling Audio Transmission

To transmit audio via the IP connection, follow these steps:

1. Open the LIVE page, and then click the Settings tab.

2. In the left pane, click Advanced, and then click Web Interface. The Web Interface menu
expands.

3. Click LIVE Functions. The LIVE Functions page appears.

4. Click the Transmit Audio radio button to enable for audio.

Activating Audio Reception

To configure audio via the Web browser, follow these steps:

1. Open the LIVE page, and then click the Settings tab.

2. In the left pane, click Advanced Mode, and then click Camera. The Camera menu
expands.

3. Click Audio. The Audio page appears. The page displays the current video image in the
small window next to the slide controls to help you verify the audio source and improve
the Peak levels.

4. Select the protocol in the Audio field to activate audio over IP. (Change the option to
ON.)

Notice!

The audio signal is sent in a separate data stream parallel to the video data, and so increases

the network load. The audio data is encoded according to G.711 or L16 and requires an

additional bandwidth of approximately 80 Kbit/s for each connection.

5. If you wish to configure the input and output gain of the audio signals, set the Line In and
Line Out fields to suit your specific requirements. Changes are effective immediately. The
current level is displayed next to the slide control to help do this. Make sure that the
display does not go beyond the green zone during modulation.

For more information, refer to Audio, page 36.

2015.02 | 1.0 | Software Manual Bosch Security Systems

!

EXTEGRA IP 9000 FX Configuration via IP, Basic Mode | en 13

4

4.1

Configuration via IP, Basic Mode

All parameter groups are described in this chapter in the order in which they are listed in the
configuration menu, from the top of the screen to the bottom.

Basic Mode: Device Access

Camera name

You can give the camera a name to make it easier to identify. The name makes the task of
administering multiple units in larger video monitoring systems easier, for example using the
Bosch Video Management Systems programs.
The device name is used for the remote identification of a unit, in the event of an alarm for
example. For this reason, enter a name that makes it as easy as possible to quickly identify the
location.

Caution!

Do not use any special characters, for example &, in the name.

Special characters are not supported by the system's internal recording management and may

therefore result in the Player or Archive Player being unable to play back the recording.

Password

An AUTODOME 7000 Series camera is generally protected by a password to prevent
unauthorized access to the unit. You can use different authorization levels to limit access.
The camera operates with three authorization levels: service, user and live.
The highest authorization level is service. After entering the correct password, you can access
all the functions of the camera and change all configuration settings.
With the user authorization level, you can operate the unit and also control cameras, for
example, but you cannot change the configuration.
The lowest authorization level is live. It can only be used to view the live video image and
switch between the different live image displays.
You can define and change a password for each authorization level if you are logged in as
service or if the unit is not password protected.
Enter the password for the appropriate authorization level here.

Notice!

Proper password protection is only guaranteed when all higher authorization levels are also

protected with a password. If a live password is assigned, for example, a service and a user

password must also be set. When assigning passwords, you should therefore always start

from the highest authorization level, service, and use different passwords.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Password

The camera is generally protected by a password to prevent unauthorized access to the unit.
You can use different authorization levels to limit access.
The camera operates with three authorization levels: service, user and live.
The highest authorization level is service. After entering the correct password, you can access
all the functions of the camera and change all configuration settings.
With the user authorization level, you can operate the unit and also control cameras, for
example, but you cannot change the configuration.
The lowest authorization level is live. It can only be used to view the live video image and
switch between the different live image displays.
You can define and change a password for each authorization level if you are logged in as
service or if the unit is not password protected.

!

14 en | Configuration via IP, Basic Mode EXTEGRA IP 9000 FX

Enter the password for the appropriate authorization level here.
Note: Proper password protection is only guaranteed when all higher authorization levels are
also protected with a password. If a live password is assigned, for example, a service and a
user password must also be set. When assigning passwords, you should therefore always start
from the highest authorization level, service, and use different passwords.

Confirm password

In each case, enter the new password a second time to eliminate typing mistakes.

Notice!

A new password is only saved when you click the Set button. You should therefore click the

Set button immediately after entering and confirming a password.

4.2

Basic Mode: Date/Time

Device date/Device time/Device time zone

If there are multiple devices operating in your system or network, it is important to
synchronize their internal clocks. For example, it is only possible to identify and correctly
evaluate simultaneous recordings when all units are operating on the same time. If necessary,
you can synchronize the unit with your computer's system settings.

Notice!

Ensure that recording is stopped before synching to the PC.

4 Click the Sync to PC button to copy your computer's system time to the camera.

Time server IP address

The camera can receive the time signal from a time server using various time server protocols,
and then use it to set the internal clock. The unit polls the time signal automatically once every
minute.
4 Enter the IP address of a time server here.

Time server type

Select the protocol that is supported by the selected time server. Preferably, you should
select the SNTP server as the protocol. This supports a high level of accuracy and is required
for special applications and subsequent function extensions.
Select Time server for a time server that works with the protocol RFC 868.

4.3

2015.02 | 1.0 | Software Manual Bosch Security Systems

Basic Mode: Network

The settings on this page are used to integrate the camera into an existing network.
Some changes only take effect after the unit is rebooted. In this case, the Set button changes
to Set and Reboot.

1. Make the desired changes.

2. Click the Set and Reboot button. The camera reboots and the changed settings are
activated.

Caution!

If you change the IP address, subnet mask or gateway address, the camera is only available

under the new addresses after the reboot.

EXTEGRA IP 9000 FX Configuration via IP, Basic Mode | en 15

4.4

Note: If you change the IP address, subnet mask or gateway address, the camera is only

available under the new addresses after the reboot.

DHCP

If a DHCP server is employed in the network for the dynamic assignment of IP addresses, you
can activate acceptance of IP addresses automatically assigned to the camera. Certain
applications (VIDOS, Bosch Video Management Systems, Archive Player, Configuration
Manager) use the IP address for the unique assignment of the unit. If you use these
applications, the DHCP server must support the fixed assignment between IP address and
MAC address, and must be appropriately set up so that, once an IP address is assigned, it is
retained each time the system is rebooted.

IP address

Enter the desired IP address for camera in this field. The IP address must be valid for the
network.

Subnet mask

Enter the appropriate subnet mask for the selected IP address here.

Gateway address

If you want the unit to establish a connection to a remote location in a different subnet, enter
the IP address of the gateway here. Otherwise leave the box as 0.0.0.0.

Basic Mode: Encoder

Non-recording profile

You can select a profile for encoding the video signal.
You can use this to adapt the video data transmission to the operating environment (for
example, network structure, bandwidth, data load).
Pre-programmed profiles are available, each giving priority to different perspectives. When
selecting a profile, details are displayed in the list field.

AUTODOME IP Profiles AUTODOME HD Profiles

High resolution 1

Target bit rate: 2000 kbps
Maximum bit rate: 4000 kbps
Encoding interval: 30.00 ips

High resolution 2
Target bit rate: 1500 kbps
Maximum bit rate: 3000 kbps
Encoding interval: 30.00 ips

Low bandwidth
Target bit rate: 700 kbps
Maximum bit rate: 1500 kbps
Encoding interval: 30.00 ips

DSL
Target bit rate: 400 kbps
Maximum bit rate: 500 kbps
Encoding interval: 30.00 ips

HD Image Optimized

Target bit rate: 2000 kbps
Maximum bit rate: 4000 kbps
Encoding interval: 30.00 ips

HD Balanced

Target bit rate: 4000 kbps
Maximum bit rate: 7000 kbps
Encoding interval: 30.00 ips

HD Bit Rate Optimized

Target bit rate: 25000 kbps
Maximum bit rate: 4500 kbps
Encoding interval: 30.00 ips

SD Image Optimized

Target bit rate: 3300 kbps
Maximum bit rate: 5000 kbps
Encoding interval: 30.00 ips

Bosch Security Systems Software Manual 2015.02 | 1.0 |

16 en | Configuration via IP, Basic Mode EXTEGRA IP 9000 FX

AUTODOME IP Profiles AUTODOME HD Profiles

ISDN (1B)

Target bit rate: 40 kbps
Maximum bit rate: 50 kbps
Encoding interval: 30.00 ips

Modem
Target bit rate: 20 kbps
Maximum bit rate: 22 kbps
Encoding interval: 30.00 ips

GSM
Target bit rate: 7 kbps
Maximum bit rate: 8 kbps
Encoding interval: 30.00 ips

SD Balanced

Target bit rate: 1300 kbps
Maximum bit rate: 2600 kbps
Encoding interval: 30.00 ips

SD Bit Rate Optimized

Target bit rate: 750 kbps
Maximum bit rate: 1500 kbps
Encoding interval: 30.00 ips

DSL Optimized

Target bit rate: 380 kbps
Maximum bit rate: 500 kbps
Encoding interval: 30.00 ips

3G Optimized

Target bit rate: 80 kbps
Maximum bit rate: 100 kbps
Encoding interval: 30.00 ips

Non-recording profile

You can select a profile for encoding the video signal.
You can use this to adapt the video data transmission to the operating environment (for
example, network structure, bandwidth, data load).
Pre-programmed profiles are available, each giving priority to different perspectives. When
selecting a profile, details are displayed in the list field.

Default Profile name

Description

HD Image Optimized For an HD image, the video bit rate and frame quality are

adjusted to ensure that the picture quality is the priority.

HD Balanced For an HD image, the video bit rate and frame quality are

adjusted to a median profile for everyday use.

HD Bit Rate Optimized For an HD image, the video bit rate and frame quality are

adjusted to ensure that the bit rate is the priority.

SD Image Optimized For an SD image, the video bit rate and frame quality are

adjusted to ensure that the picture quality is the priority.

SD Balanced For an SD image, the video bit rate and frame quality are

adjusted to a median profile for everyday use.

SD Bit Rate Optimized For an SD image, the video bit rate and frame quality are

adjusted to ensure that the bit rate is the priority.

DSL Optimized Ideal for encoding on a DSL uplink where bit rate limitations are

critical.

3G Optimized Ideal for encoding on a 3G uplink where bit rate limitations are

critical.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Basic Mode | en 17

4.5

4.6

Basic Mode: Audio

Note for MIC7000 cameras only: These options are available only if you have connected a

VIDEOJET connect device (VJC-7000-90) to your camera.
You can set the gain of the audio signals to suit your specific requirements. The current video
image is shown in the small window next to the slide controls to help you check the audio
source and improve assignments. Your changes are effective immediately.
If you connect via Web browser, you must select the option Transmit Audio on the LIVE
Functions page. (See LIVE Functions, page 23). For other connections, the transmission
depends on the audio settings of the respective system.

Audio

The audio signals are sent in a separate data stream parallel to the video data, and so increase
the network load. The audio data are encoded according to G.711 and require an additional
bandwidth of approx. 80 kbps per connection in each direction. If you do not want any audio
data to be transmitted/received, select Off.

Line In

You can set the line input gain using the slider. Values range from 0 to 31. The default value is

0.

Line Out

You can set the line output gain using the slider. Values range from 0 to 79. The default value
is 0.

Basic Mode: Recording

4.7

You can record the images from the camera on various local storage media or on an
appropriately configured iSCSI system.

Storage medium

1. Select the required storage medium from the list.

2. Click the Start button to start the recording immediately.

Basic Mode: System Overview

The data on this page are for information purposes only and cannot be changed. Keep a
record of this information in case technical assistance is required.

Notice!

You can select all required text on this page with the mouse and copy it to the clipboard with

the [Ctrl]+[C] key combination, for example if you want to send it via e-mail.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

18 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

5

5.1

5.2

Configuration via IP, Advanced Mode

All parameter groups are described in this chapter in the order in which they are listed in the
configuration menu, from the top of the screen to the bottom.

Advanced Mode: General

Identification, page 18
Password, page 18
Date/Time, page 19
Display Stamping, page 20

Identification

Camera name

The camera name makes it easier to identify the remote camera location, in the event of an
alarm for example. It will be displayed in the video screen if configured to do so. The camera
name makes the task of administering cameras in larger video monitoring systems easier, for
example using the BVC or Bosch Video Management Systems Programs.
Enter a unique, unambiguous name for the camera in this field. You can use both lines for this.
Do not use any special characters, for example &, in the name. Special characters are not
supported by the system's internal management.
You can use the second line for entering additional characters; these can be selected from a
table.

1. Click the icon next to the second line. A new window with the character map is opened.

2. Click the required character. The character is inserted into the Result field.

3. In the character map, click the << and >> icons to move between the different pages of
the table, or select a page from the list field.

4. Click the < icon to the right of the Result field to delete the last character, or click the X
icon to delete all characters.

5. Now click the OK button to apply the selected characters to the second line of the

Camera 1 parameters. The window will close.

Camera ID

Each device should be assigned a unique identifier that can be entered here as an additional
means of identification.

Initiator extension

Add text to an initiator name to make identification easier in large iSCSI systems. This text is
added to the initiator name, separated from it by a full stop. (You can see the initiator name in
the System Overview page.)

5.3

2015.02 | 1.0 | Software Manual Bosch Security Systems

Password

The camera is generally protected by a password to prevent unauthorized access to the unit.
You can use different authorization levels to limit access.

Notice!

Proper password protection is only guaranteed when all higher authorization levels are also

protected with a password. If a live password is assigned, for example, a service and a user

password must also be set. When assigning passwords, you should therefore always start

from the highest authorization level, service, and use different passwords.

Password

The camera operates with three authorization levels: service, user and live.

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 19

The highest authorization level is service. After entering the correct password, you can access
all the functions of the camera and change all configuration settings.
With the user authorization level, you can operate the unit and also control cameras, for
example, but you cannot change the configuration.
The lowest authorization level is live. It can only be used to view the live video image and
switch between the different live image displays.
You can define and change a password for each authorization level if you are logged in as
service or if the unit is not password protected.
Enter the password for the appropriate authorization level here.

Confirm password

In each case, enter the new password a second time to eliminate typing mistakes.

Notice!

A new password is only saved when you click the Set button. You should therefore click the

Set button immediately after entering and confirming a password.

5.4

Date/Time

Date format

Select your required date format.

Device date/Device time

Notice!

Ensure that recording is stopped before synching to the PC.

If there are multiple devices operating in your system or network, it is important to
synchronize their internal clocks. For example, it is only possible to identify and correctly
evaluate simultaneous recordings when all units are operating on the same time.

1. Enter the current date. Since the unit time is controlled by the internal clock, there is no
need to enter the day of the week – it is added automatically.

2. Enter the current time or click the Sync to PC button to copy your computer's system
time to the camera.

Note: It is important that the date/time is correct for recording. An incorrect date/time setting
could prevent correct recording.

Device time zone

Select the time zone in which your system is located.

Daylight saving time

The internal clock can switch automatically between normal and daylight saving time (DST).
The unit already contains the data for DST switch-overs up to the year 2018. You can use
these data or create alternative time saving data if required.

Notice!

If you do not create a table, there will be no automatic switching. When changing and clearing

individual entries, remember that two entries are usually related to each other and dependent

on one another (switching to summer time and back to normal time).

1. First check whether the correct time zone is selected. If it is not correct, select the
appropriate time zone for the system, and click the Set button.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

20 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

2. Click the Details button. A new window will open and you will see the empty table.

3. Select the region or the city that is closest to the system's location from the list field
below the table.

4. Click the Generate button to generate data from the database in the unit and enter it into
the table.

5. Make changes by clicking an entry in the table. The entry is selected.

6. Clicking the Delete button will remove the entry from the table.

7. Select other values from the list fields below the table to change the entry. Changes are
made immediately.

8. If there are empty lines at the bottom of the table, for example after deletions, you can
add new data by marking the row and selecting required values from the list fields.

9. Now click the OK button to save and activate the table.

Time server IP address

The camera can receive the time signal from a time server using various time server protocols,
and then use it to set the internal clock. The unit polls the time signal automatically once every
minute.
Enter the IP address of a time server here.

Time server type

Select the protocol that is supported by the selected time server. Preferably, you should
select the SNTP server as the protocol. This supports a high level of accuracy and is required
for special applications and subsequent function extensions.
Select Time server for a time server that works with the protocol RFC 868.

5.5

Display Stamping

Various overlays or “stamps” in the video image provide important supplementary information.
These overlays can be enabled individually and are arranged on the image in a clear manner.
After you set all necessary parameters, click the View Control link to see how the stamping
appears on the LIVE page.

Camera name stamping
This field sets the position of the camera name overlay. It can be displayed at the Top, at the

Bottom or at a position of your choice that you can then specify using the Custom option. Or

it can be set to Off for no overlay information.

1. Select the desired option from the list.

2. If you select the Custom option, additional fields are displayed where you can specify the
exact position (Position (XY)).

3. In the Position (XY) fields, enter the values for the desired position.

Logo

Click Choose File to select a file. Heed the restrictions for file format, logo size, and color
depth. Click Upload to load the file to the camera.
If no logo is selected, Configuration displays the message, “No file chosen.”

Logo position

Select the position for the logo on the OSD: Left or Right.
Select Off (the default value) to disable logo positioning.

Time stamping

This field sets the position of the time overlay. It can be displayed at the Top, at the Bottom or
at a position of your choice that you can then specify using the Custom option. Or it can be
set to Off for no overlay information.

1. Select the desired option from the list.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX

Configuration via IP, Advanced Mode | en 21

2. If you select the Custom option, additional fields are displayed where you can specify the
exact position (Position (XY)).

3. In the Position (XY) fields, enter the values for the desired position.

Display milliseconds

If necessary, you can also display milliseconds. This information can be useful for recorded
video images; however, it does increase the processor's computing time. Select Off if you do
not need to display milliseconds.

Alarm mode stamping

Select On to display a text message overlay in the image in the event of an alarm. It can be
displayed at a position of your choice that you can then specify using the Custom option. Or it
can be set to Off for no overlay information.

1. Select the desired option from the list.

2. If you select the Custom option, additional fields are displayed where you can specify the
exact position (Position (XY)).

3. In the Position (XY) fields, enter the values for the desired position.

Alarm message

Enter the message to be displayed in the image in the event of an alarm. The maximum text
length is 31 characters.

Title OSD

Select On to continuously display sector or shot title overlays in the image. Select Momentary
to display sector or shot title overlays for a few seconds. OSD titles can be displayed at a
position of your choice, or it can be set to Off for no overlay information.

1. Select the desired option from the list.

2. Specify the exact position (Position (XY)).

3. In the Position (XY) fields, enter the values for the desired position.

Camera OSD

Select On to momentarily display camera response information, such as Digital Zoom, Iris
open/close, and Focus near/far overlays in the image. Select Off to display no information.

1. Select the desired option from the list.

2. Specify the exact position (Position (XY)).

3. In the Position (XY) fields, enter the values for the desired position.

Transparent background

Check this box to make the stamp on the image transparent.

Video watermarking

Choose On if you wish the transmitted video images to be “watermarked”. After activation, all
images are marked with a green check. A red check indicates that the sequence (live or saved)
has been manipulated.

Video authentication

Select a method for verifying the integrity of the video in the Video authentication drop-down
box.
If you select Watermarking all images are marked with an icon. The icon indicates if the
sequence (live or saved) has been manipulated.
If you want to add a digital signature to the transmitted video images to ensure their integrity,
select one of the cryptographic algorithms for this signature.
Enter the interval (in seconds) between insertions of the digital signature.

Signature intervals

Select the interval (in seconds) for the signature.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

22 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

5.6

5.7

Advanced Mode: Web Interface

Appearance, page 22
LIVE Functions, page 23
Logging, page 24

Appearance

On this page you can adapt the appearance of the web interface and change the website
language to meet your requirements. If necessary, you can replace the manufacturer's logo
(top right) and the product name (top left) in the top part of the window with individual
graphics.

Notice!

You can use either GIF or JPEG images. The file paths must correspond to the access mode

(for example C:\Images\Logo.gif for access to local files, or http://www.mycompany.com/

images/logo.gif for access via the Internet/Intranet).

When accessing via the Internet/Intranet, ensure that a connection is always available to

display the image. The image file is not stored in the camera.

Website language

Select the language for the user interface here.

Company logo

Enter the path to a suitable graphic if you want to replace the manufacturer's logo. The image
file can be stored on a local computer, in the local network or at an Internet address.

Device logo

Enter the path to a suitable graphic if you want to replace the product name. The image file
can be stored on a local computer, in the local network or at an Internet address.

Notice!

If you want to use the original graphics again, simply delete the entries in the Company logo

and Device logo fields.

Show VCA metadata

When video content analysis (VCA) is activated, additional information is displayed in the live
video stream. For example, in Motion+ mode, the sensor areas for motion detection are
marked.

Show VCA trajectories

When video content analysis (VCA) is activated, check this item to show additional information
that traces the path of objects.

Show overlay icons

Select this checkbox to show overlay icons on the live video image.

Video player

Select the desired video player from the list in the drop-down box. Options are “Auto detect”
(default), Bosch Video SDK, Bosch Autoload Decoder, JPEG

JPEG size

You can specify the size of the JPEG image on the LIVE page. Options are Small, Medium,
Large, 720p, 1080p, and “Best possible” (default).

JPEG interval

You can specify the interval at which the individual images should be generated for the M­JPEG image on the LIVE page.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 23

JPEG quality
You can specify the quality at which the JPEG images appear on the LIVE page.

5.8

LIVE Functions

On this page you can adapt the functions on the LIVE page to your requirements. You can
choose from a variety of different options for displaying information and controls.

1. Check the box for the items that are to be made available on the LIVE page. The selected
items are indicated by a check mark.

2. Check whether the required functions are available on the LIVE page.

Transmit audio

You can only select this option if audio transmission is actually switched on (see Audio, page

36).The audio signals are sent in a separate data stream parallel to the video data, and so

increase the network load. The audio data are encoded according to G.711 and require an
additional bandwidth of approx. 80 kbps per connection in each direction.

Lease time (s)

The lease time in seconds determines the time beyond which a different user is authorized to
control the camera after no further control signals are received from the current user. After
this time interval, the camera is automatically enabled.

Show alarm inputs

The alarm inputs are displayed next to the video image as icons along with their assigned
names. If an alarm is active, the corresponding icon changes color.

Show alarm outputs

Alarm outputs are shown next to the video image as icons, along with their assigned names. If
the alarm output is active, the corresponding icon changes color.

Show event log

The event messages are displayed along with the date and time in a field next to the video
image.

Show system log

The system messages are displayed along with the date and time in a field next to the video
image and provide information about establishing and ending connections, for example.

Allow snapshots

Here you can specify whether the icon for saving individual images (snapshots) should be
displayed below the live image. Individual images can only be saved if this icon is visible.

Allow local recording

Here you can specify whether the icon for saving (recording) video sequences on the local
memory should be displayed below the live image. Video sequences can only be saved if this
icon is visible.

I-frames only stream
Here you can specify whether the LIVE page displays a viewing tab for an I-frame only stream.

Show scene list

Here you can specify whether the View Controls section of the LIVE page displays a drop­down box with the list of scenes set in Advanced Mode > Camera > Scenes and Tours of the

SETTINGS page.

Show ‘Intelligent Tracking’

Here you can specify whether the LIVE page displays the controls for the Intelligent Tracking
feature.

Show ‘Special Functions’

Here you can specify whether the LIVE page displays the Special Functions section.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

24 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Path for JPEG and video files

1. Enter the path for the storage location of individual images and video sequences that you
can save from the LIVE page.

2. If necessary, click Browse to find a suitable directory.

5.9

5.10

5.11

Logging

Save event log

Check this option to save event messages in a text file on your local computer. You can then
view, edit and print this file with any text editor or the standard Office software.

File for event log

1. Enter the path for saving the event log here.

2. If necessary, click Browse to find a suitable directory.

Save system log

Check this option to save system messages in a text file on your local computer. You can then
view, edit and print this file with any text editor or the standard Office software.

File for system log

1. Enter the path for saving the system log here.

2. If necessary, click Browse to find a suitable directory.

Advanced Mode: Camera

Installer Menu

The following options are available only for HD cameras:

Base frame rate

This option allows you to set the frame rate that the camera uses to transmit video. Select
either 25 ips or 30 ips. If you select 25 ips, the camera will stream video at 25 or 50 ips. If you
select 30 ips, the camera will stream video at 30 or 60 ips, depending on the option selected
in the Encoder Stream.

Max. frame rate

This option determines the maximum frame rate that the camera streams video. Select one of
the following options:

Max. Frame Rate Option

25/30 ips (up to 1920 x 1080) H.264 MP 720p25/30 Fixed

50/60 ips (up to 1280 x 720) H.264 MP 720p50/60 Fixed

Notice!

Changing the Base frame rate or Max. frame rate

A change to the Base frame rate or to the Max. frame rate parameter requires a reboot of the

HD camera. The reboot process takes approximately 40 seconds. During this time, no

changes can be made. The cameo image freezes.

This section also displays a graphic that shows the relative image size difference between an
image encoded at 1280 x 720 and at 1920 x 1080.

Orientation

Reverses the image 180º (ideal when mounting upside down). Set the orientation to Normal
(default) or Inverted.

2015.02 | 1.0 | Software Manual Bosch Security Systems

Available Streaming Options

H.264 MP 1080p25/30 Fixed

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 25

Caution!

The camera disables the Privacy Mask function if the orientation is set to Inverted.

SC settings

Click the Default button to restore all camera settings to their original defaults.

SC data

Click the Default button to clear all prepositions, privacy masks, and other configuration
settings defined in the camera’s web server to their default values.

Reboot device

Click the Reboot button to reboot the camera. There is a ten (10) second pause before the
dome starts its homing phase. During the homing phase, the camera pans left and right and
tilts up and down. It also adjusts the lens focus. The entire homing phase lasts approximately
40 seconds.
Click the Reboot button to restart the device. There is a ten (10) second pause before the
camera adjusts the lens focus. The entire reboot sequence lasts approximately 40 seconds.

Factory defaults

Click the Defaults button to restore the configuration settings defined in the camera’s web
server to their default values. A confirmation screen appears. Allow 5 seconds for the camera
to optimize the picture after a mode reset.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

!

26 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

5.12

Encoder Profile

Figure 5.1: Advanced Mode>Camera>Encoder Profile>Profile 1 [HD models only]

2015.02 | 1.0 | Software Manual Bosch Security Systems

For the video signal encoding, you can select a code algorithm and you can change the presets
for the profiles.
You can adapt the video data transmission to the operating environment (for example network
structure, bandwidth, data load). To this end, the camera simultaneously generates two data
streams (Dual Streaming), which compression settings you can select individually, for example
one setting for transmissions to the Internet and one for LAN connections.
Pre-programmed profiles are available, each giving priority to different perspectives.
You can change individual parameter values of a profile and you can also change the name.
You can switch between profiles by clicking the appropriate tabs.

Caution!

The profiles are rather complex. They include a large number of parameters that interact with

one another, so it is generally best to use the default profiles.

Change the profiles only once you are fully familiar with all the configuration options.

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 27

Notice!

In the default setting, Stream 1 is transmitted for alarm connections and automatic

connections. Keep this fact in mind when assigning the profile.

Notice!

All parameters combine to make up a profile and are dependent on one another. If you enter a

setting that is outside the permitted range for a particular parameter, the nearest permitted

value will be substituted when the settings are saved.

IP Profiles (Configuration Parameters)

Profile Target bit rate Maximum bit rate Encoding interval

High resolution 1 2000 kbps 4000 kbps 30.00 ips

High resolution 2 1500 kbps 3000 kbps 30.00 ips

Low bandwidth 700 kbps 1500 kbps 30.00 ips

DSL 400 kbps 500 kbps 30.00 ips

ISDN (1B) 40 kbps 50 kbps 30.00 ips

Modem 20 kbps 22 kbps 30.00 ips

GSM 7 kbps 8 kbps 30.00 ips

HD Profiles (Configuration Parameters)

HD Image Optimized

Target bit rate: 2000 kbps
Maximum bit rate: 4000 kbps
Encoding interval: 30.00 ips

HD Balanced

Target bit rate: 4000 kbps
Maximum bit rate: 7000 kbps
Encoding interval: 30.00 ips

HD Bit Rate Optimized

Target bit rate: 2500 kbps
Maximum bit rate: 4500 kbps
Encoding interval: 30.00 ips

SD Image Optimized

Target bit rate: 3300 kbps
Maximum bit rate: 5000 kbps
Encoding interval: 30.00 ips

SD Balanced

Target bit rate: 1300 kbps
Maximum bit rate: 2600 kbps
Encoding interval: 30.00 ips

Bosch Security Systems Software Manual 2015.02 | 1.0 |

en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

28

HD Profiles (Configuration Parameters)

SD Bit Rate Optimized

Target bit rate: 750 kbps
Maximum bit rate: 1500 kbps
Encoding interval: 30.00 ips

DSL Optimized

Target bit rate: 380 kbps
Maximum bit rate: 500 kbps
Encoding interval: 30.00 ips

3G Optimized

Target bit rate: 80 kbps
Maximum bit rate: 100 kbps
Encoding interval: 30.00 ips

Profile name

If required, enter a new name for the profile.

Target bit rate

To optimize use of the bandwidth in the network, limit the data rate for the device. The target
data rate should be set according to the desired picture quality for typical scenes with no
excessive motion.
For complex images or frequent changes of image content due to frequent movements, this
limit can temporarily be exceeded up to the value entered in the Maximum bit rate field.

Maximum bit rate

This maximum bit rate is not exceeded under any circumstances. Depending on the video
quality settings for the I- and P-frames, this fact can result in individual images being skipped.
The value entered here must be at least 10% higher than the value entered in the Target bit

rate field. If the value entered here is too low, it will be adjusted automatically.

Encoding interval

This parameter determines the interval at which images are encoded and transmitted. For
example, entering or selecting 4 means that only every fourth image is encoded, while the
following there are skipped, which can be particularly advantageous for networks with low
bandwidths. The image rate in (images per second (ips) appears next to the text field or
slider.

Video resolution

Select the desired resolution for the video image.
For standard definition only, options are:
– 240p
– 480p
– 144p
– 288p
– 432p (default)

Expert Settings

If necessary, use the expert settings to adapt the I-frame quality and the P-frame quality to
specific requirements. The setting is based on the H.264 quantization parameter (QP).

GOP structure

Select the structure that you require for the group of pictures, depending on whether you
place greater priority on having the lowest possible delay (IP frames only) or using as little
bandwidth as possible.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 29

Options are IP, IBP, and IBBP.
GOP is not available for megapixel cameras.

I-frame distance

This parameter allows you to set the intervals in which the I-frames will be coded. Auto means
auto mode, whereby the video server inserts I-frames as necessary. Values range from 3 to 60.
An entry of 3 indicates that I-frames are continuously generated. An entry of 4 indicates that
only every fourth image is an I-frame, and so on; the frames in between are coded as P-frames.
Note that the values supported depend on the GOP structure setting. For example, only even
values are supported with IBP; if you have selected IBBP, only 3 or multiples of 3 are
supported.

Min. P-frame QP

This parameter allows you to adjust the image quality of the P-frame and to define the lower
limit for the quantization of the P-frames, and thus the maximum achievable quality of the P­frames. In the H.264-protocol, the Quantization Parameter (QP) specifies the degree of
compression and thus the image quality for every frame. The lower the quantization of the P­frame (QP value), the higher the encoding quality (and thus the best image quality) and the
lower the frame refresh rate depending on the settings for the maximum data rate under
network settings. A higher quantization value results in low image quality and lower network
load. Typical QP values are between 18 and 30.
The basic setting Auto automatically adjusts the quality to the settings for the P-frame video
quality.

I/P-frame delta QP

This parameter sets the ratio of the I-frame quantization (QP) to the P-frame quantization
(QP). For example, you can set a lower value for I-frames by moving the slide control to a
negative value. Thus, the quality of the I-frames relative to the P-frames is improved. The total
data load will increase, but only by the portion of I-frames. The basic setting Auto
automatically adjusts to the optimum combination of movement and image definition (focus).
To obtain the highest quality at the lowest bandwidth, even in the case of increased
movement in the picture, configure the quality settings as follows:

1. Observe the coverage area during normal movement in the preview images.

2. Set the value for Min. P-frame QP to the highest value at which the image quality still
meets your needs.

3. Set the value for I/P-frame delta QP to the lowest possible value. This is how to save
bandwidth and memory in normal scenes. The image quality is retained even in the case
of increased movement since the bandwidth is then filled up to the value that is entered
under Maximum bit rate.

Default
Click Default to return the profile to the factory default values.

5.13

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Encoder Streams

Property

Select one of the H.264 standards for each stream.

Stream 1 (recording) Options are:

- H.264 MP SD

- H.264 MP 720p25/30 Fixed

- H.264 MP 1080p25/30 Fixed;

- H.264 MP 720p50/60 Fixed

30 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Note: In order to select the option “H.264 MP 720p50/60 Fixed” here, you must set the Max.
frame rate field in the Advanced Mode: Camera >Installer Menu to “H.264 MP 720p50/60

Fixed” first.
Note (for dynamic models only): In order to select the option “H.264 MP 1080p25/30 Fixed”
here, you must set the Max.frame rate field in the Advanced Mode: Camera >Installer Menu to
“H.264 MP 1080p25/30 Fixed” first.

Stream 2 Options vary depending on Stream 1 selection.

Options with “H.264 MP 1080p25/30 Fixed” selected for
Stream 1:
– Copy Stream 1
– H.264 MP SD
– H.264 MP 720p8/10 Fixed
– H.264 MP 1080p4/5 Fixed
– H.264 MP upright (cropped)
– H.264 MP D1 4:3 (cropped)

Options with “H.264 MP 720p50/60 Fixed” selected for
Stream 1:
– Copy Stream 1
– H.264 MP SD
– H.264 MP 720p6/7 Fixed
– H.264 MP upright (cropped)
– H.264 MP D1 4:3 (cropped)

Options with “H.264 MP 720p25/30 Fixed” selected for
Stream 1:
– H.264 MP SD
– H.264 MP 720p25/30 Fixed
– H.264 MP upright (cropped)
– H.264 MP D1 4:3 (cropped)
– H.264 MP 1280x960 (cropped)

Option with “H.264 MP SD” selected for Stream 1: H.264 MP
SD

Non-recording profile

Select one of the following profiles for each stream:

HD Profiles (Configuration Parameters)

HD Image Optimized

Target bit rate: 2000 kbps
Maximum bit rate: 4000 kbps
Encoding interval: 30.00 ips

HD Balanced

Target bit rate: 4000 kbps
Maximum bit rate: 7000 kbps
Encoding interval: 30.00 ips

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 31

HD Profiles (Configuration Parameters)

HD Bit Rate Optimized

Target bit rate: 2500 kbps
Maximum bit rate: 4500 kbps
Encoding interval: 30.00 ips

SD Image Optimized

Target bit rate: 3300 kbps
Maximum bit rate: 5000 kbps
Encoding interval: 30.00 ips

SD Balanced

Target bit rate: 1300 kbps
Maximum bit rate: 2600 kbps
Encoding interval: 30.00 ips

SD Bit Rate Optimized

Target bit rate: 750 kbps
Maximum bit rate: 1500 kbps
Encoding interval: 30.00 ips

DSL Optimized

Target bit rate: 380 kbps
Maximum bit rate: 500 kbps
Encoding interval: 30.00 ips

3G Optimized

Target bit rate: 80 kbps
Maximum bit rate: 100 kbps
Encoding interval: 30.00 ips

Preview

Click the Preview button to open a small static preview window for each stream. To enlarge
the preview and view live video, click the 1:1 Live View button.

JPEG stream

Select the resolution, frame rate, and image quality parameters for the M-JPEG stream.
– Resolution: Select the appropriate resolution.
– Max. frame rate: Select one of the following frame rates to be the maximum: 5, 10, 15,

20, 25, or 30 ips.

– Picture quality: This setting allows you to adjust the image quality. Use the slide bar to

choose a quality between Low and High.

Note: The M-JPEG frame rate can vary depending on system loading.

5.14

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Picture Settings

Current mode

Select one of the pre-programmed user modes, optimized with the best settings for a variety
of typical applications, that best defines the environment in which the camera is installed.
– Outdoor – General day-to-night changes with sun highlights and street lighting
– Indoor – Ideal mode for indoor applications where lighting is constant and not changing
– Low light – Optimized for sufficient details at low light
– Motion – Monitoring traffic or fast moving objects; motion artifacts are minimized

en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

32

– Vibrant – Enhanced contrast color reproduction and sharpness
The default setting depends on whether the camera is an in-ceiling camera or a pendant
camera.
Customize the mode, if necessary, for the specific requirements of the site by selecting
different values for the fields below.
In this case, the name of the user mode changes to “Custom.”

White Balance

Adjusts the color settings to maintain the quality of the white areas of the image.
– ATW: allows the camera to continuously adjust color reproduction.
– AWB Hold: places the ATW on hold and saves the color settings.
– Extended ATW (default): allows the camera to constantly adjust for optimal color

reproduction.
– Manual: Red and Blue gain can be manually set to a desired position.
– Sodium Lamp Auto: Automatically adjusts for sodium vapor light to restore objects to

their original color.
– Sodium Lamp: Optimizes the sodium vapor light to restore objects to their original color.
– ATW: allows the camera to continuously adjust color reproduction.
– Indoor: white balance tracking for indoor use.
– Outdoor: white balance tracking for outdoor use.
– AWB Hold: places the ATW on hold and saves the color settings.
– Extended ATW (default): allows the camera to constantly adjust for optimal color

reproduction.
– Manual: Red and Blue gain can be manually set to a desired position.
– Sodium Lamp Auto: Automatically adjusts for sodium vapor light to restore objects to

their original color.
– Sodium Lamp: Optimizes the sodium vapor light to restore objects to their original color.

Red Gain

The red gain adjustment offsets the factory white point alignment (reducing red introduces
more cyan).

Blue Gain

The blue gain adjustment offsets the factory white point alignment (reducing blue introduces
more yellow). It is only necessary to change the white point offset for special scene
conditions.

Saturation

The percentage of light or color in the video image (HD only). Values range from 60% to 200%;
the default is 110%.

Color hue

The degree of color in the video image (HD only). Values range from -14° to 14°; the default is
8°.

Gain control

Adjusts the automatic gain control (AGC). Automatically sets the gain to the lowest possible
value needed to maintain a good picture.
– AGC (default): electronically brightens dark scenes, which may cause graininess in low

light scenes.
– Fixed: no enhancement. This setting disables the Max. Gain Level option.

If you select this option, the camera makes the following changes automatically:

– Night Mode: switches to Color

– Auto Iris: switches to Constant

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX

Configuration via IP, Advanced Mode | en 33

Fixed Gain

Use the slide to select the desired number for fixed gain. The default is 2.

Maximum Gain Level

Controls the maximum value the gain can have during AGC operation. To set the maximum
gain level, choose from:
– Normal
– Medium
– High (default)

AE-response speed

Select the speed of the response of auto exposure. Options are Super slow, Slow, Medium
(default), Fast.

Sharpness

Adjusts the sharpness of the picture. To set the sharpness, use the slider to select a number.
The default is 12.

Shutter Mode

– Fixed: The shutter mode is fixed to a selectable shutter speed.
– AutoSensUp: increases camera sensitivity by increasing the integration time on the

camera. This is accomplished by integrating the signal from a number of consecutive
video frames to reduce signal noise.
If you select this option, the camera makes the following change automatically:
– Auto Iris: switches to Constant
– Shutter: is disabled

Shutter

Adjusts the electronic shutter speed (AES). Controls the time period for which light is
gathered by the collecting device. The default setting is 1/60 second for NTSC and 1/50 for
PAL cameras. The range of settings is from 1/1 to 1/10000.

Auto SensUP limit

This limits the integration time when Auto SensUP (Frame Integration) is active. The default is
1/4. The range of settings is from 1/4 to 1/30.

Shutter limit

The camera tries to hold this shutter value as long as sufficient ambient light is available in the
scene.
Settings range from 1/1 to 1/10000. The default value is 1/2000 for all modes except 'Motion'
(default 1/500).

Backlight compensation

Optimizes the video level for the selected area of the image. Parts outside this area may be
underexposed or overexposed. Select On to optimize the video level for the central area of the
image. The default setting is Off.

High Sensitivity

Adjusts the level of intensity or lux within the image (HD only). Select from Off or On.
Note: In Black and White (Night) mode / low light situations, High Sensitivity turns on
automatically.

Stabilization

This feature is ideal for cameras mounted on a pole or mast, or on another location that
shakes frequently.
Select On to activate the video stabilization feature (if available on your camera) that reduces
camera shake in both the vertical and horizontal axis. The camera compensates for the
movement of the image by up to 2% of the image size.
Select Auto to activate the feature automatically when the camera detects vibration.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

34 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Select Off to deactivate the feature.

Note: This feature is not available on 20x models.

High dynamic range

Select On to activate wide dynamic range, which improves image reproduction in extreme
high-contract scenes.
Select Off to deactivate the feature.
Select Auto to activate high dynamic range when the camera detects an extreme high-contract
scene.
Select Enhanced to activate high dynamic range when the camera detects an extreme high­contract scene. The camera makes multiple, simultaneous exposures of the same scene to
capture details in both bright and dark parts of the scene.

Night mode

Selects night mode (B/W) to enhance lighting in low light scenes. Select from the following
options:
– Monochrome: Forces the camera to stay in Nigh Mode and transmit monochrome images.
– Color: The camera does not switch to Night Mode regardless of ambient light conditions.
– Auto (default): The camera switches out of Night Mode after the ambient light level

reaches a pre-defined threshold.

Night mode threshold

Adjusts the level of light at which the camera automatically switches out of night mode (B/W)
operation. Select a value between 10 and 55 (in increments of 5; default 30). The lower the
value, the earlier the camera will switch to color mode.

Noise Reduction

Turns on the 2D and 3D noise reduction feature.

Noise Reduction Level

Adjusts the noise level to the appropriate level for shooting conditions. Select a value between
1 and 5.

Intelligent Defog

With the Defog mode feature, visibility can be improved significantly when viewing foggy or
other low-contrast scenes.
– On - Defog is always active.
– Off - Defog is disabled.
– Auto - Defog activates automatically as needed.

5.15

2015.02 | 1.0 | Software Manual Bosch Security Systems

Lens Settings

Autofocus

Continuously adjusts the lens automatically to the correct focus for the sharpest picture.
– One Push (default; commonly called “Spot Focus”): activates the Auto Focus feature after

the camera stops moving. Once focused, Auto Focus is inactive until the camera is moved

again.
– Auto Focus: Auto Focus is always active.
– Manual: Auto Focus is inactive.

Autofocus

Continuously adjusts the lens automatically to the correct focus for the sharpest picture.
– One Push (default; commonly called “Spot Focus”): activates the Auto Focus feature after

the camera stops moving. Once focused, Auto Focus is inactive until the camera lens

zooms again.
– Auto Focus: Auto Focus is always active.
– Manual: Auto Focus is inactive.

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 35

Near focus limit

Select the limit for focusing near: 10 cm, 3 m, 5 m, or 10 m.
For indoor cameras, the default value is 10 cm.
For outdoor cameras, the default value is 3 m.

Focus polarity

– Normal (default): focus controls operate normally.
– Reverse: focus controls are reversed.

Focus speed

Use the slider (from 1 to 8) to control how fast the Auto focus will readjust when the focus
becomes blurred.

Auto iris

Automatically adjusts the lens to allow the correct illumination of the camera sensor. This type
of lens is recommended for use where there are low light or changing light conditions.
– Constant (default): camera constantly adjusts to varying light conditions (default).

If you select this option, the camera makes the following changes automatically:
– Gain Control: switches to AGC.
– Shutter Speed: switches to default.

– Manual: camera must be manually adjusted to compensate for varying light conditions.

Iris polarity

Capability to reverse the operation of the iris button on the controller.
– Normal (default): iris controls operate normally.
– Reverse: iris controls are reversed.

Auto iris level

Increases or decreases brightness according to the amount of light. Type a value between 1
and 15.

IR focus correction

Optimizes the focus for IR lighting. Options are: On, Off (default).

Maximum zoom speed

Controls the zoom speed.

Zoom polarity

Capability to reverse the operation of the zoom button on the controller.
– Normal (default): zoom controls operate normally.
– Reverse: zoom controls are reversed.

Digital zoom

Digital zoom is a method of decreasing (narrowing) the apparent angle of view of a digital
video image. It is accomplished electronically, without any adjustment of the camera's optics,
and no optical resolution is gained in the process. Select Off to disable or On to enable this
feature. The default setting is On.

5.16

5.17

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Miscellaneous

Fast address

This parameter allows the appropriate camera to be operated via the numerical address in the
control system. Enter a number between 0000 and 9999, inclusive, to identify the camera.
Note: This is required for identifying cameras connected through a decoder such as the
VIDEOJET decoder 3000 (VJD-3000).

Logs

To save the log file information:

1. Click Download to obtain the log information.

2. Click Save.

36 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

3. Navigate to the directory in which you want to store the log information.

4. Type a name for the log file and click Save.

5.18

Audio

Note for MIC7000 cameras only: These options are available only if you have connected a

VIDEOJET connect device (VJC-7000-90) to your camera.
You can set the gain of the audio signals to suit your specific requirements. The current video
image is shown in the small window next to the slide controls to help you check the audio
source and improve assignments. Your changes are effective immediately.
If you connect via Web browser, you must activate the audio transmission on the LIVE
Functions page. (See LIVE Functions, page 23.) For other connections, the transmission
depends on the audio settings of the respective system.

Audio

The audio signals are sent in a separate data stream parallel to the video data, and so increase
the network load. The audio data are encoded according to G.711 and require an additional
bandwidth of approximately 80 kbps for each connection. If you do not want any audio data to
be transmitted, select Off.

Input volume

You can set the input volume with the slider (from 0 to 31, with 0 as the default).

Line In

You can set the line input gain with the slider (from 0 (zero) to 79, with 0 as the default).
Make sure that the display does not go beyond the green zone during modulation.

Line Out

You can set the line output gain with the slider (from 0 (zero) to 79, with 0 as the default).
Make sure that the display does not go beyond the green zone during modulation.

Recording format

Select a format for audio recording. Select L16 or AAC (Advanced Audio Coding) if you want
better audio quality with higher sampling rates. Note that the L16 standard requires
approximately eight times the bandwidth of the format G.711.

5.19

5.20

5.21

2015.02 | 1.0 | Software Manual Bosch Security Systems

Pixel Counter

Counts the number of pixels in a defined image area. The pixel counter allows the installer to
easily verify that the camera installation fulfills any regulatory or specific customer
requirements, for example, calculating the pixel resolution of the face of a person passing a
doorway monitored by the camera.

Advanced Mode: Recording

Storage Management, page 36
Recording Profiles, page 38
Maximum Retention Time, page 39
Recording Scheduler, page 40
Recording Status, page 41

Storage Management

You can record the images from the camera on various local storage media (user-supplied SD,
SDHC, or SDXC memory card) or on an appropriately configured iSCSI system.
You can record the images from the camera on an appropriately configured iSCSI system.
For long-term, authoritative images in stationary operation, it is essential that you use an
appropriately sized iSCSI system.

!

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 37

It is also possible to let the VRM Video Recording Manager control all recording with accessing
an iSCSI system. This is an external program for configuring recording tasks for video servers.
For further information please contact your local customer service at Bosch Security Systems
Inc.

Device manager

If you activate the Managed by VRM option in this screen, the VRM Video Recording Manager
will manage all recording and you will not be able to configure any further settings here.

Caution!

Activating or deactivating VRM causes the current settings to be lost; they can only be

restored through reconfiguration.

Recording media

Select the required recording media here so that you can then activate them and configure the
recording parameters.

iSCSI Media

If you want to use an iSCSI system as a recording medium, you must set up a connection to
the required iSCSI system and set the configuration parameters.

Notice!

The iSCSI storage system selected must be available on the network and completely set up.

Amongst other things, it must have an IP address and be divided into logical drives (LUN).

1. Enter the IP address of the required iSCSI destination in the iSCSI IP address field.

2. If the iSCSI destination is password protected, enter this into the Password field.

3. Click the Read button. The connection to the IP address will be established. In the

Storage overview field, you can see the corresponding logical drives.

Local Media

The supported local recording media are displayed in the Storage overview field.

Activating and Configuring Storage Media

The storage overview displays the available storage media. You can select individual media or
iSCSI drives and transfer these to the Managed storage media list. You can activate the
storage media in this list and configure them for storage.

Caution!

Each storage medium can only be associated with one user. If a storage medium is already

being used by another user, you can decouple the user and connect the drive with the

camera. Before decoupling, make absolutely sure that the previous user no longer needs the

storage medium.

1. In the Recording media section, click the iSCSI Media and Local Media tabs to display
the applicable storage media in the overview.

2. In the Storage overview section, double-click the required storage medium, an iSCSI LUN
or one of the other available drives. The medium is then added to the Managed storage

media list. In the Status column, newly added media are indicated by the status Not
active.

3. Click the Set button to activate all media in the Managed storage media list. In the
Status column, these are indicated by the status Online.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

!

!

38 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

4. Check the box in the Rec. 1 or Rec. 2 to specify which data stream should be recorded
on the storage media selected. Rec. 1 stores Stream 1, Rec. 2 stores Stream 2. This
means that you can record the standard data stream on a hard drive and record alarm
images on the mobile CF card, for example.

5. Check the boxes for the Overwrite older recordings option to specify which older
recordings can be overwritten once the available memory capacity has been used.

Recording 1 corresponds to Stream 1, Recording 2 corresponds to Stream 2.

Caution!

If older recordings are not allowed to be overwritten when the available memory capacity has

been used, the recording in question will be stopped. You can specify limitations for

overwriting old recordings by configuring the retention time (see Maximum Retention Time,

page 39).

Formatting Storage Media

You can delete all recordings on a storage medium at any time.

Caution!

Check the recordings before deleting and back up important sequences on the computer's

hard drive.

1. Click a storage medium in the Managed storage media list to select it.

2. Click the Edit button below the list. A new window will open.

3. Click the Formatting button to delete all recordings in the storage medium.

4. Click OK to close the window.

Deactivating Storage Media

You can deactivate any storage medium from the Managed storage media list. It is then no
longer used for recordings.

1. Click a storage medium in the Managed storage media list to select it.

2. Click the Remove button below the list. The storage medium is deactivated and removed
from the list.

5.22

2015.02 | 1.0 | Software Manual Bosch Security Systems

Recording Profiles

You can define up to ten different recording profiles. You will then use these recording profiles
in the recording scheduler, where they are linked with the individual days and times (see
Recording Scheduler, page 40).

Notice!

You can change or add to the recording profile description on the tabs on the Recording

Scheduler page (see Recording Scheduler, page 40).

1. Click one of the tabs to edit the corresponding profile.

2. If necessary, click the Default button to return all settings to their default values.

3. Click the Copy Settings button if you want to copy the currently visible settings to other
profiles. A new window will open and you can select the profiles in which you want to
copy the settings.

4. For each profile, click the Set button to save the settings in the unit.

Standard recording

Here you can select the mode for standard recordings.

!

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 39

If you select Continuous, the recording proceeds continuously. If the maximum memory
capacity is reached, older recordings will automatically be overwritten. If you select the Pre-
alarm option, recording will only take place in the pre-alarm time, during the alarm and during
the set post-alarm time.
If you select Off, no automatic recording takes place.

Caution!

You can specify limitations for overwriting older recordings in Continuous mode by

configuring the retention time (see Maximum Retention Time, page 39).

Standard profile

From this field, you can select the encoder profile to be used for recording (see Encoder
Profile, page 26).

Notice!

The recording profile can deviate from the standard setting Active profile and is only used

during an active recording.

Pre-alarm time

You can select the required pre-alarm time from the list field.

Post-alarm time

You can select the required post-alarm time from the list field.

Post-alarm profile

You can select the encoder profile to be used for recording during the post-alarm time (see
Encoder Profile, page 26).
The Standard profile option adopts the selection at the top of the page.

Alarm input / Analysis alarm / Video loss

Here you can select the alarm sensor that is to trigger a recording.

Virtual alarm

Here you can select the virtual alarm sensors that are to trigger a recording, via RCP+
commands or alarm scripts, for example.

Notice!

For more information, please see the Alarm Task Script Language document and the RCP+

documentation. These documents can be found on the product CD supplied.

Recording includes

You can specify whether, in addition to video data and metadata (for example alarms, VCA
data and serial data) should also be recorded. Including metadata could make subsequent
searches of recordings easier but it requires additional memory capacity.

Caution!

Without metadata, it is not possible to include video content analysis in recordings.

5.23

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Maximum Retention Time

You can specify the retention times for recordings. If the available memory capacity of a
medium has been used, older recordings are only overwritten if the retention time entered
here has expired.

40 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Notice!

Make sure that the retention time corresponds with the available memory capacity. A rule of

thumb for the memory requirement is as follows: 1 GB per hour retention time with 4CIF for

complete frame rate and high image quality.

Maximum Retention Time

Enter the required retention time in hours or days for each recording. Recording 1
corresponds to Stream 1, Recording 2 corresponds to Stream 2.

5.24

Recording Scheduler

The recording scheduler allows you to link the created recording profiles with the days and
times at which the camera's images are to be recorded in the event of an alarm.
You can link any number of 15-minute intervals with the recording profiles for each day of the
week. Moving the mouse cursor over the table displays the time below it. This aids orientation.
In addition to the normal weekdays, you can define holidays that are not in the standard
weekly schedule on which recordings are to apply. This allows you to apply a schedule for
Sundays to other days with dates that fall on varying weekdays.

1. Click the profile you want to link in the Time periods field.

2. Click in a field in the table, hold down the mouse button and drag the cursor over all the
periods to be assigned to the selected profile.

3. Use the right mouse button to deselect any of the intervals.

4. Click the Select All button to link all time intervals to the selected profile.

5. Click the Clear All button to deselect all of the intervals.

6. When you are finished, click the Set button to save the settings in the unit.

Holidays

You can define holidays that are not in the standard weekly schedule on which recordings are
to apply. This allows you to apply a schedule for Sundays to other days with dates that fall on
varying weekdays.

1. Click the Holidays tab. Any days that have already been selected will be shown in the
table.

2. Click the Add button. A new window will open.

3. Select the desired date from the calendar. You can select several consecutive calendar
days by holding down the mouse button. These will later be displayed as a single entry in
the table.

4. Click OK to accept the selection. The window will close.

5. Assign the individual holidays to the recording profiles, as described above.

Deleting Holidays

You can delete holidays you have defined yourself at any time.

1. Click the Delete button. A new window will open.

2. Click the date you wish to delete.

3. Click OK. The item will be deleted from the table and the window will close.

4. The process must be repeated for deleting additional days.

Time periods

You can change the names of the recording profiles.

1. Click a profile and then the Rename button.

2. Enter your chosen name and then click the Rename button again.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 41

Activating the Recording

After completing configuration you must activate the recording scheduler and start the
recording. Once recording is underway, the Recording Profiles and Recording Scheduler
pages are deactivated and the configuration cannot be modified.
You can stop the recording activity at any time and modify the settings.

1. Click the Start button to activate the recording scheduler.

2. Click the Stop button to deactivate the recording scheduler. Running recordings are
interrupted and the configuration can be changed.

Recording status

The graphic indicates the recording activity of the camera. You will see an animated graphic
while recording is taking place.

5.25

5.26

5.27

Recording Status

Certain details on the recording status are displayed here for information purposes. You
cannot change any of these settings.

If an error occurs during recording, the Status line for the recording may display informational
icons that provide additional information when you point to them with your mouse.

Advanced Mode: Alarm

Alarm Connections

You can select how the camera responds to an alarm. In the event of an alarm, the unit can
automatically connect to a pre-defined IP address. You can enter up to ten IP addresses to
which the camera will connect in sequence in the event of an alarm, until a connection is
made.

Connect on alarm

Select On so that the camera automatically connects to a predefined IP address in the event
of an alarm.
By setting Follows input 1 the unit maintains the connection that has been automatically
established for as long as an alarm exists on alarm input 1.

Notice!

In the default setting, Stream 2 is transmitted for alarm connections. Bear this fact in mind

when assigning the profile (see Encoder Profile, page 26).

Bosch Security Systems Software Manual 2015.02 | 1.0 |

!

42 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Number of destination IP address

Specify the numbers of the IP addresses to be contacted in the event of an alarm. The unit
contacts the remote stations one after the other in the numbered sequence until a connection
is made.

Destination IP address

For each number, enter the corresponding IP address for the desired remote station.

Destination password

If the remote station is password protected, enter the password here.
In this page, you can save a maximum of ten destination IP addresses and hence up to ten
passwords for connecting to remote stations. If connections to more than ten remote stations
are to be possible, for example when initiating connections via higher-ranking systems such as
VIDOS or Bosch Video Management System, you can store a general password here. The
camera can use this general password to connect to all remote stations protected with the
same password. In this case, proceed as follows:

1. Select 10 from the Number of destination IP address list field.

2. Enter the address 0.0.0.0 in the Destination IP address field.

3. Enter your chosen password in the Destination password field.

4. Define this password as the user password for all remote stations to which a connection
is to be possible.

Notice!

If you enter the destination IP address 0.0.0.0 for destination 10, this address will no longer

be used for the tenth attempt at automatic connection in the event of an alarm. The

parameter is then used only to save the general password.

Video transmission

If the unit is operated behind a firewall, TCP (HTTP port) should be selected as the transfer
protocol. For use in a local network, select UDP.

Caution!

Please note that in some circumstances, a larger bandwidth must be available on the network

for additional video images in the event of an alarm, in case Multicast operation is not

possible. To enable Multicast operation, select the UDP option for the Video transmission

parameter here and on the Network page (see Network Access, page 50).

Stream

Select the number of the stream from the drop-down list.

Remote port

Depending on the network configuration, select a browser port here. The ports for HTTPS
connections will be available only if the On option is selected in the SSL encryption
parameter.

Video output

If you know which unit is being used as the receiver, you can select the analog video output to
which the signal should be switched. If the destination unit is unknown, it is advisable to
select the First available option. In this case, the image is placed on the first free video
output. This is an output on which there is no signal. The connected monitor only displays
images when an alarm is triggered. If you select a particular video output and a split image is
set for this output on the receiver, you can also select from Decoder the decoder in the
receiver that is to be used to display the alarm image.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 43

Notice!

Refer to the destination unit documentation concerning image display options and available

video outputs.

Decoder

Select a decoder of the receiver to display the alarm image. The decoder selected has an
impact on the position of the image in a split screen. For example, you can specify via a VIP XD
that the upper-right quadrant should be used to display the alarm image by selecting decoder

2.

SSL encryption

The data for the connection, for example the password, can be securely transmitted with SSL
encryption. If you have selected the On option, only encrypted ports are offered in the Remote

port parameter.

Notice!

Please note that the SSL encryption must be activated and configured at both ends of a

connection. This requires the appropriate certificates to be uploaded onto the camera.

You can activate and configure encryption of the media data (video and metadata) on the

Encryption page (see Encryption, page 58).

Auto-connect

Select the On option to automatically re-establish a connection to one of the previously
specified IP addresses after each reboot, after a connection breakdown or after a network
failure.

Notice!

In the default setting, Stream 2 is transmitted for automatic connections. Bear this fact in

mind when assigning the profile (see Encoder Profile, page 26).

5.28

Audio

Select On to activate audio alarms.

VCA

The camera has integrated video content analysis (VCA), which can detect and analyze
changes in the signal on the basis of image processing. Such changes can be due to
movements in the camera's field of view.
You can select various VCA configurations and adapt these to your application as required. The
Silent MOTION+ Configuration is active by default. In this configuration, metadata is created
to facilitate searches of recordings; however, no alarm is triggered.

1. Select a VCA configuration and make the required settings.

2. If necessary, click the Default button to return all settings to their default values.

Intelligent Dynamic Noise Reduction (IDNR)

IVA / VCA controls the IDNR feature, which reduces noise based on motion activity in the
scene. When there is no motion in the preset scene, noise reduction is increased. When there
is motion detected in the preset scene, noise reduction is decreased to reduce bandwidth and
optimize storage space.
To disable the IDNR feature, select the OFF option in the VCA configuration field.
To enable the IDNR feature, select a Profile # (1 – 16) or Silent VCA in the VCA configuration
field. If you select a specific profile, you must also select MOTION+ in the Analysis Type field.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

44 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

VCA Profiles

You can configure two profiles with different VCA configurations. You can save profiles on your
computer's hard drive and load saved profiles from there. This can be useful if you want to
test a number of different configurations. Save a functioning configuration and test new
settings. You can use the saved configuration to restore the original settings at any time.

Notice!

If computing power becomes short, the highest priority is always the live images and

recordings. This can lead to impairment of the video content analysis. You should therefore

observe the processor load and optimize the encoder settings or the video content analysis

settings as necessary.

1. Select a VCA profile and enter the required settings.

2. If necessary, click the Default button to return all settings to their default values.

3. Click the Save... button to save the profile settings to another file. A new window is
opened, in which you can specify where you want to save the file and what name you
want to save it under.

4. Click the Load... button to load a saved profile. A new window opens in which you can
select the profile file and specify where to save the file.

VCA configuration

Select one of the profiles here to activate it or edit it.
You can rename the profile.

1. To rename the file, click the icon to the right of the list field and enter the new profile
name in the field.

2. Click the icon again. The new profile name is saved.

Preset

Select Off or Test.

Alarm status

The alarm status is displayed here for information purposes. This means you can check the
effects of your settings immediately.

Aggregation times

Use the slider (from 0 (zero) to 20 (0 is the default) to select the aggregation times.

Analysis type

Select the required analysis algorithm. By default, only MOTION+ is available – this offers a
motion detector and essential recognition of tampering.

Notice!

Additional analysis algorithms with comprehensive functions such as IVMD and IVA are

available from Bosch Security Systems Inc.

If you select one of these algorithms, you can set the corresponding parameters here directly.

You can find information on this in the relevant documents on the product CD supplied.

Metadata is always created for a video content analysis, unless this was explicitly excluded.
Depending on the analysis type selected and the relevant configuration, additional information
overlays the video image in the preview window next to the parameter settings. Options are:
MOTION+, IVA 5.6, IVA 5.6 Flow. With the MOTION+ analysis type, for example, the sensor
fields in which motion is recorded will be marked with rectangles.

2015.02 | 1.0 | Software Manual Bosch Security Systems

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 45

Notice!

On the LIVE Functions page, you can also enable additional information overlays for the LIVE

page (see LIVE Functions, page 23).

Motion detector (MOTION+ only)

For the detector to function, the following conditions must be met:
– Analysis must be activated.
– At least one sensor field must be activated.
– The individual parameters must be configured to suit the operating environment and the

desired responses.

– The sensitivity must be set to a value greater than zero.

Caution!

Reflections of light (off glass surfaces, etc.), switching lights on or off or changes in the light

level caused by cloud movement on a sunny day can trigger unintended responses from the

motion detector and generate false alarms. Run a series of tests at different times of the day

and night to ensure that the video sensor is operating as intended.

For indoor surveillance, ensure constant lighting of the areas during the day and at night.

Sensitivity (MOTION+ only)

The basic sensitivity of the motion detector can be adjusted for the environmental conditions
to which the camera is subject.
The sensor reacts to variations in the brightness of the video image. The darker the
observation area, the higher the value that must be selected.

Minimum object size (MOTION+ only)

You can specify the number of sensor fields that a moving object must cover to generate an
alarm. This is to prevent objects that are too small from triggering an alarm.
A minimum value of 4 is recommended. This value corresponds to four sensor fields.

Debounce time 1 s (MOTION+ only)

The debounce time is intended to prevent very brief alarm events from triggering individual
alarms. If the Debounce time 1 s option is activated, an alarm event must last at least one
second to trigger an alarm.

Select Area (MOTION+ only)

The areas of the image to be monitored by the motion detector can be selected. The video
image is subdivided into 858 square fields. Each of these fields can be activated or
deactivated individually. If you wish to exclude particular regions of the camera's field of view
from monitoring due to continuous movement (by a tree in the wind, etc.), the relevant fields
can be deactivated.
4 Click Select Area to configure the sensor fields. A new window will open.

1. If necessary, click Clear All first to clear the current selection (fields marked yellow).

2. Left-click the fields to be activated. Activated fields are marked yellow.

3. If necessary, click Select All to select the entire video frame for monitoring.

4. Right-click any fields you wish to deactivate.

5. Click OK to save the configuration.

6. Click the close button X in the window title bar to close the window without saving the
changes.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

46 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Sensitivity

Notice!

This and the following parameter are only accessible if the reference check is activated.

The basic sensitivity of the tamper detection can be adjusted for the environmental conditions
to which the camera is subject.
The algorithm reacts to the differences between the reference image and the current video
image. The darker the observation area, the higher the value that must be selected.

Trigger delay (s)

You can set delayed alarm triggering. The alarm is only triggered after a set time interval in
seconds has elapsed and then only if the triggering condition still exists. If the original
condition has been restored before this time interval elapses, the alarm is not triggered. This
allows you to avoid false alarms triggered by short-term changes, for example cleaning
activities in the direct field of vision of the camera.

Global change

You can set how large the global change in the video image must be for an alarm to be
triggered. This setting is independent of the sensor fields selected under Select Area. Set a
high value if fewer sensor fields need to change to trigger an alarm. With a low value, it is
necessary for changes to occur simultaneously in a large number of sensor fields to trigger an
alarm.
This option allows you to detect, independently of motion alarms, manipulation of the
orientation or location of a camera resulting from turning the camera mount bracket, for
instance.

Global change

Activate this function if the global change, as set with the Global change slide control, should
trigger an alarm.

Scene too bright

Activate this function if tampering associated with exposure to extreme light (for instance,
shining a flashlight directly on the lens) should trigger an alarm. The average brightness of the
scene provides a basis for recognition.

Scene too dark

Activate this function if tampering associated with covering the lens (for instance, by spraying
paint on it) should trigger an alarm. The average brightness of the scene provides a basis for
recognition.

Scene too noisy

Activate this function if tampering associated with EMC interference (noisy scene as the result
of a strong interference signal in the vicinity of the video lines), as an example, should trigger
an alarm.

Reference Check

You can save a reference image that is continuously compared with the current video image. If
the current video image in the marked areas differs from the reference image, an alarm is
triggered. This allows you to detect tampering that would otherwise not be detected, for
example if the camera is turned.

1. Click Reference to save the currently visible video image as a reference.

2. Click Select Area and select the areas in the reference image that are to be monitored.

3. Check the box Reference check to activate on-going matching. The stored reference
image is displayed in black and white below the current video image, and the selected
areas are marked in yellow.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 47

4. Select the Disappearing edges or Appearing edges option to specify the reference check
once again.

Disappearing edges

The area selected in the reference image should contain a prominent structure. If this
structure is concealed or moved, the reference check triggers an alarm. If the selected area is
too homogenous, so that concealing and moving the structure would not trigger an alarm, then
an alarm is triggered immediately to indicate the inadequate reference image.

Appearing edges

Select this option if the selected area of the reference image includes a largely homogenous
surface. If structures appear in this area, then an alarm is triggered.

Select Area

You can select the image areas in the reference image that are to be monitored. The video
image is subdivided into 858 square fields. Each of these fields can be activated or
deactivated individually.

Notice!

Select only those areas for reference monitoring in which no movement takes place and that

are always evenly lit, as false alarms could otherwise be triggered.

5.29

1. Click Select Area to configure the sensor fields. A new window will open.

2. If necessary, click Clear All first to clear the current selection (fields marked yellow).

3. Left-click the fields to be activated. Activated fields are marked yellow.

4. If necessary, click Select All to select the entire video frame for monitoring.

5. Right-click any fields you wish to deactivate.

6. Click OK to save the configuration.

7. Click the close button X in the window title bar to close the window without saving the
changes.

Audio Alarm

Note for MIC7000 cameras only: These options are available only if you have connected a

VIDEOJET connect device (VJC-7000-90) to your camera.
The camera can create alarms on the basis of audio signals. You can configure signal strengths
and frequency ranges in such a way that false alarms, for example due to machine noise or
background noise, are avoided.

Notice!

First set up normal audio transmission before you configure the audio alarm here (see Audio,

page 36).

Audio alarm
Select On if you want the device to generate audio alarms.

Name

The name makes it easier to identify the alarm in extensive video monitoring systems, for
example with the VIDOS and Bosch Video Management System programs. Enter a unique and
clear name here.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

!

!

48 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Caution!

Do not use any special characters, for example &, in the name.

Special characters are not supported by the system's internal recording management and may

therefore result in the Player or Archive Player programs being unable to play back the

recording.

Signal Ranges

You can exclude particular signal ranges in order to avoid false alarms. For this reason the
total signal is divided into 13 tonal ranges (mel scale). Check or uncheck the boxes below the
graphic to include or exclude individual ranges.

Threshold

Set up the threshold on the basis of the signal visible in the graphic. You can set the threshold
using the slide control or, alternately, you can move the white line directly in the graphic using
the mouse.

Sensitivity

You can use this setting to adapt the sensitivity to the sound environment. You can effectively
suppress individual signal peaks. A high value represents a high level of sensitivity.

5.30

Alarm E-Mail

As an alternative to automatic connecting, alarm states can also be documented by e-mail. In
this way it is possible to notify a recipient who does not have a video receiver. In this case, the
camera automatically sends an e-mail to a previously defined e-mail address.

Send alarm e-mail
Select On if you want the unit to automatically send an alarm e-mail in the event of an alarm.

Mail server IP address

Enter the IP address of a mail server that operates on the SMTP standard (Simple Mail
Transfer Protocol). Outgoing e-mails are sent to the mail server via the address you entered.
Otherwise leave the box blank (0.0.0.0).

SMTP user name

Enter a registered user name for the chosen mailserver here.

SMTP password

Enter the required password for the registered user name here.

Format

You can select the data format of the alarm message.
– Standard (with JPEG) E-mail with attached JPEG image file.
– SMS E-mail in SMS format to an e-mail-to-SMS gateway (for example to send an alarm by

cellphone) without an image attachment.

Caution!

When a cellphone is used as the receiver, make sure to activate the e-mail or SMS function,

depending on the format, so that these messages can be received.

You can obtain information on operating your cellphone from your cellphone provider.

Image size

Select the appropriate image size: Small, Medium, Large, 720p, 1080p.

Attach JPEG from camera

Click the checkbox to specify that JPEG images are sent from the camera. An enabled video
input is indicated by a check mark.

Destination address

Enter the e-mail address for alarm e-mails here. The maximum address length is 49 characters.

2015.02 | 1.0 | Software Manual Bosch Security Systems

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 49

Sender address

Enter a unique name for the e-mail sender, for example the location of the device. This will
make it easier to identify the origin of the e-mail.
Note: The name must include at least two character groups separated by a blank (for example,
Parking Garage) in order for the system to generate an email from that name, as in “From
Parking Garage”. Text with only one group of characters (for example, Lobby) will not
generate an email.

Test e-mail

You can test the e-mail function by clicking the Send Now button. An alarm e-mail is
immediately created and sent.

5.31

5.32

Alarm Task Editor

Caution!

Editing scripts on this page overwrites all settings and entries on the other alarm pages. This

procedure cannot be reversed.

In order to edit this page, you must have programming knowledge and be familiar with the

information in the Alarm Task Script Language document.

As an alternative to the alarm settings on the various alarm pages, you can enter your desired
alarm functions in script form here. This will overwrite all settings and entries on the other
alarm pages.

1. Click the Examples link under the Alarm Task Editor field to see some script examples. A
new window will open.

2. Enter new scripts in the Alarm Task Editor field or change existing scripts in line with your
requirements.

3. When you are finished, click the Set button to transmit the scripts to the unit. If the
transfer was successful, the message Script successfully parsed is displayed over the
text field. If it was not successful, an error message will be displayed with further
information.

Alarm Rules

The camera features an alarm rule engine. In its simplest form, an alarm rule can define which
input(s) activate which output(s). Basically, an alarm rule allows you to customize the camera
to respond automatically to different alarm inputs.
To configure an alarm rule specify one input from a physical connection, a motion detection
trigger, or from a connection to the camera’s LIVE page. The physical input connection can be
activated by dry contact devices such as pressure pads, door contacts, and similar devices.
Next, specify up to two (2) rule outputs, or the camera’s response to the input. Outputs
include a physical alarm relay, an AUX command, or a preposition scene.

1. Click the Enabled check box to activate the alarm.

2. Choose one of the following alarm Inputs:
Local Input 1: a physical alarm connection.
Local Input 2: a physical alarm connection.
IVA/MOTION+: an alarm when IVA or motion detection is activated.
Connection: an alarm when an attempt is made to access the camera’s IP address.

3. Choose one of the following output commands for both Output 1 and Output 2 settings:
None: no defined command.
Alarm Relay: defines a physical connection from the open collector alarm output.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

50 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Aux On: defines a standard or custom keyboard ON command. Refer to User Command
Table for a list of valid commands.
Note: Only commands 1, 8, 18, 20, 43, 60, 80, 86 are supported. Support for the
remaining commands is scheduled for a future release.
Aux Off: defines a standard or custom keyboard OFF command. Refer to to User
Command Table for a list of valid commands.
Note: Only commands 1, 8, 18, 20, 43, 60, 80, 86 are supported. Support for the
remaining commands is scheduled for a future release.
Shot: defines a preset scene from shot 1-256.

4. Click Set to save and to activate the alarm rules.

5.33

5.34

5.35

Advanced Mode: Interfaces

Alarm Inputs, page 50
Alarm Outputs, page 50

Note: For a MIC camera, physical alarm connections are only applicable when the camera is
connected to optional MIC-ALM-WAS-24 or VJC-7000-90.

Alarm Inputs

Select the type of input for each physical alarm. Select from either N.O. (Normally Open) or
N.C. (Normally Closed) and provide an optional name for each input.

Alarm Outputs

The camera incorporates three (3) open collector alarm or transistor outputs. Use the
following settings to configure the relay for alarm outputs.

Idle state
Specify either Open or Closed idle state.

Operating mode

Select one of the following modes for operation: Bistable, 0.5 s, 1 s, 5 s, 10 s, or 60 s.

Output name

Type an optional name for the relay connection, up to 20 characters.

Trigger output
Click the appropriate Trigger output button to test the relay / output connection.

5.36

5.37

2015.02 | 1.0 | Software Manual Bosch Security Systems

Advanced Mode: Network

Network Access, page 50
DynDNS, page 53
Advanced, page 54
Network Management, page 55
Multicast, page 56
Image Posting, page 57
Accounts, page 57
IPv4 Filter, page 58
Encryption, page 58

Network Access

The settings on this page are used to integrate the camera into an existing network.
Some changes only take effect after the unit is rebooted. In this case, the Set button changes
to Set and Reboot.

1. Make the desired changes.

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 51

2. Click the Set and Reboot button. The camera reboots and the changed settings are
activated.

If the IP address, subnet mask, or gateway address is changed, then the device is only
available under the new addresses after the reboot.

Caution!

If you change the IP address, subnet mask or gateway address, the camera is only available

under the new addresses after the reboot.

Automatic IP assignment

If a DHCP server is employed in the network for the dynamic assignment of IP addresses, you
can activate acceptance of IP addresses automatically assigned to the camera.
Certain applications (Bosch Video Management System, Archive Player, Configuration
Manager) use the IP address for the unique assignment of the unit. If you use these
applications, the DHCP server must support the fixed assignment between IP address and
MAC address, and must be appropriately set up so that, once an IP address is assigned, it is
retained each time the system is rebooted.

IPv4

Fill in the 3 fields in this section of the screen.

IP address

Enter the desired IP address for the camera in this field. The IP address must be valid for the
network.

Subnet mask

Enter the appropriate subnet mask for the selected IP address here.

Gateway address

If you want the unit to establish a connection to a remote location in a different subnet, enter
the IP address of the gateway here. Otherwise leave the box blank (0.0.0.0).

IPv6

Consult with the network administrator before making changes to this section.

IP address

Enter the desired IP address for the camera in this field. The IP address must be valid for the
network. A typical IPv6 address may resemble the following example:
2001:db8: :52:1:1
Consult the network administrator for valid IPv6 address construction.

Prefix length

A typical IPv6 node address consists of a prefix and an interface identifier (total 128 bits). The
prefix is the part of the address where the bits have fixed values or are the bits that define a
subnet.

Gateway address

If you want the unit to establish a connection to a remote location in a different subnet, enter
the IP address of the gateway here. Otherwise leave the box blank (0.0.0.0).

DNS server address 1 / DNS server address 2

The camera is easier to access if the unit is listed on a DNS server. If you wish, for example, to
establish an Internet connection to the camera, it is sufficient to enter the name given to the
unit on the DNS server as a URL in the browser. Enter the IP address of the DNS server here.
Servers are supported for secure and dynamic DNS.

Video transmission

If the unit is operated behind a firewall, TCP (HTTP port) should be selected as the transfer
protocol. For use in a local network, select UDP.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

!

52 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Caution!

Multicast operation is only possible with the UDP protocol. The TCP protocol does not

support multicast connections.

The MTU value in UDP mode is 1,514 bytes.

TCP rate control

Select On to control the rate of transmission control protocol. Select Off if you do not want to
control the TCP rate.

HTTP browser port

Select a different HTTP browser port from the list if required. The default HTTP port is 80. If
you want to allow only secure connections via HTTPS, you must deactivate the HTTP port. In
this case, select Off.

HTTPS browser port

If you wish to allow browser access on the network via a secure connection, select an HTTPS
browser port from the list if necessary. The default HTTPS port is 443. Select the Off option to
deactivate HTTPS ports; only unsecured connections will now be possible.
The camera uses the TLS 1.0 encryption protocol. You may have to activate this protocol via
your browser configuration. You must also activate the protocol for the Java applications (via
the Java control panel in the Windows control panel).

Notice!

If you want to allow only secure connections with SSL encryption, you must select the Off

option for each of the parameters HTTP browser port, RCP+ port 1756 and Telnet support.

This deactivates all unsecured connections. Connections will then only be possible via the

HTTPS port.

You can activate and configure encryption of the media data (video and metadata) on the

Encryption page (see Encryption, page 58).

RCP+ port 1756

To exchange connection data, you can activate the unsecured RCP+ port 1756. If you want
connection data to be transmitted only when encrypted, select the Off option to deactivate
the port.

Telnet support

If you want to allow only secure connections with encrypted data transmission, you must
select the Off option to deactivate Telnet support. The unit will then no longer be accessible
using the Telnet protocol.

Interface mode ETH

If necessary, select the Ethernet link type for the ETH interface. Depending on the unit
connected, it may be necessary to select a special operation type.
Select the type of Ethernet link for the interface for the camera connected to the port labeled
PoE on the PCBA of VIDEOJET connect 7000.
Depending on the device connected, it may be necessary to select a special operation type.
Options are:
– Auto
– 10 Mbps HD (half duplex)
– 10 Mbps FD (full duplex)
– 100 Mbps HD (half duplex)
– 100 Mbps FD (full duplex)

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 53

If necessary, select the type of Ethernet link for the interface for the device connected to the
port labeled ETH 1 on the PCBA of VIDEOJET connect 7000.
Depending on the device connected, it may be necessary to select a special operation type.
Options are:
– Auto
– 10 Mbps HD (half duplex)
– 10 Mbps FD (full duplex)
– 100 Mbps HD (half duplex)
– 100 Mbps FD (full duplex)
Note: Do not select a baud rate for this port unless a device is connected to this port on
VIDEOJET connect 7000.
If necessary, select the type of Ethernet link for the interface for the device connected to the
port labeled ETH 2 on the PCBA of VIDEOJET connect 7000.
Depending on the device connected, it may be necessary to select a special operation type.
Options are:
– Auto
– 10 Mbps HD (half duplex)
– 10 Mbps FD (full duplex)
– 100 Mbps HD (half duplex)
– 100 Mbps FD (full duplex)
Note: Do not select a baud rate for this port unless a device is connected to this port on
VIDEOJET connect 7000.

Network MSS (Byte)

You can set the maximum segment size for the IP packet's user data. This gives you the option
to adjust the size of the data packets to the network environment and to optimize data
transmission. Please comply with the MTU value of 1,514 bytes in UDP mode.

iSCSI MSS (Byte)

You can specify a higher MSS value for a connection to the iSCSI system than for the other
data traffic via the network. The potential value depends on the network structure. A higher
value is only useful if the iSCSI system is located in the same subnet as the camera.

Network MTU (Byte)

The value in the field defaults to 1514.

5.38

DynDNS

Enable DynDNS

DynDNS.org is a DNS hosting service that stores IP addresses in a database ready for use. It
allows you to select the camera via the Internet using a host name, without having to know the
current IP address of the unit. You can enable this service here. To do this, you must have an
account with DynDNS.org and you must have registered the required host name for the unit on
that site.

Notice!

Information about the service, registration process and available host names can be found at

DynDNS.org.

Provider

The value in this field defaults to dyndns.org. Select another option as necessary.

Host name

Enter the host name registered on DynDNS.org for the camera here.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

54 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

User name

Enter the user name you registered at DynDNS.org here.

Password

Enter the password you registered at DynDNS.org here.

Force registration now

You can force the registration by transferring the IP address to the DynDNS server. Entries
that change frequently are not provided in the Domain Name System. It is a good idea to force
the registration when you are setting up the device for the first time. Only use this function
when necessary and no more than once a day, to avoid the possibility of being blocked by the
service provider. To transfer the IP address of the camera, click the Register button.

Status

The status of the DynDNS function is displayed here for information purposes. You cannot
change any of these settings.

Notification mail

Select On to set the system to provide email notification of domain registration.

Mail address

Enter the email address for notification.

5.39

Advanced

The settings on this page are used to implement advanced settings for the network.

Operation

The operation mode determines how the camera communicates with Bosch Cloud-based
Security and Services. For more information about these services and their availability, visit:
http://cloud.boschsecurity.com
– Select Auto to allow the camera to poll the server a few times; if no contact is made, it

stops polling.
– Select On to constantly poll the server.
– Select Off to block polling.

RTSP port

If necessary, select a different port for the exchange of the RTSP data from the list. The
standard RTSP port is 554. Select Off to deactivate the RTSP function.

Authentication

If a RADIUS server is employed in the network for managing access rights, authentication must
be activated here to allow communication with the unit. The RADIUS server must also contain
the corresponding data.
To configure the unit, you must connect the camera directly to a computer using a network
cable. This is because communication via the network is not enabled until the Identity and

Password parameters have been set and successfully authenticated.

Identity

Enter the name that the RADIUS server is to use for identifying the camera.

Password

Enter the password that is stored in the RADIUS server.

NTCIP

Specifies a set of rules and protocols for organizing, describing and exchanging transportation
management information between transportation management applications and
transportation equipment such that they interoperate with each other.
Select a port for NTCIP and the Address from the appropriate drop-down lists.
Note: This field will not appear for cameras without an NTCIP license.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 55

TCP port

The device can receive data from an external TCP sender, for example an ATM or POS device,
and store it as metadata. Select the port for TCP communication. Select Off to deactivate the
TCP metadata function.

Sender IP address

Enter the IP address of the TCP metadata sender here.

5.40

Network Management

SNMP

The camera supports the SNMP V1 (Simple Network Management Protocol) for managing and
monitoring network components, and can send SNMP messages (traps) to IP addresses. The
unit supports SNMP MIB II in the unified code. If you wish to send SNMP traps, enter the IP
addresses of one or two required target devices here.
If you select On for the SNMP parameter and do not enter an SNMP host address, the camera
does not send them automatically, but only replies to SNMP requests. If you enter one or two
SNMP host addresses, SNMP traps are sent automatically. Select Off to deactivate the SNMP
function.

1. SNMP host address / 2. SNMP host address

If you wish to send SNMP traps automatically, enter the IP addresses of one or two required
target units here.

SNMP traps

You can select which traps are to be sent.

1. Click Select. A list is opened.

2. Click the checkboxes to select the required traps. All the checked traps will be sent.

3. Click Set to accept the selection.

UPnP

You can activate the Universal Plug and Play (UPnP) function. If the function is turned on, the
unit responds to requests from the network and is automatically registered on the requesting
computers as a new network device. For example, access to the unit can then be made using
Windows Explorer without knowledge of the IP address of the unit.

Notice!

To use the UPnP function on a computer, both the Universal Plug and Play Device Host and

SSDP Discovery Service must be active in Windows XP and Windows 7.

Quality of service

The camera offers Quality of Service (QoS) configuration options to ensure fast network
response to PTZ data and images. Quality of Service (QoS) is the set of techniques to manage
network resources. QoS manages the delay, delay variation (jitter), bandwidth, and packet
loss parameters to guarantee the ability of a network to deliver predictable results. QoS
identifies the type of data in a data packet and divides the packets into traffic classes that can
be prioritized for forwarding.
Consult with your network administrator for assistance configuring the Audio, Video, Control,
and the Alarm video settings, and to select the appropriate Post-alarm time.
The priority of the different data channels can be set by defining the DiffServ Code Point
(DSCP). Enter a number between 0 and 252 as a multiple of four. For alarm video you can set
a higher priority than for regular video and you can define a Post Alarm Time over which this
priority is maintained.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

56 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

5.41

Multicast

In addition to a 1:1 connection between an encoder and a single receiver (unicast), the
camera can enable multiple receivers to receive the video signal from an encoder
simultaneously. The device either duplicates the data stream itself and then distributes it to
multiple receivers (Multi-unicast) or it sends a single data stream to the network, where the
data stream is simultaneously distributed to multiple receivers in a defined group (Multicast).
You can enter a dedicated multicast address and port for each stream. You can switch
between the streams by clicking the appropriate tabs.

Notice!

Multicast operation requires a multicast-enabled network that uses the UDP and the Internet

Group Management IGMP protocols. Other group management protocols are not supported.

The TCP protocol does not support multicast connections.

A special IP address (class D address) must be configured for multicast operation in a
multicast-enabled network.
The network must support group IP addresses and the Internet Group Management Protocol
(IGMP V2). The address range is from 225.0.0.0 to 239.255.255.255.
The multicast address can be the same for multiple streams. However, it will be necessary to
use a different port in each case so that multiple data streams are not sent simultaneously
using the same port and multicast address.

Notice!

The settings must be made individually for each stream.

Enable

To enable simultaneous data reception on several receivers you need to activate the multicast
function. To do this, check the box. You can then enter the multicast address.

Multicast Address

Enter a valid multicast address for each stream to be operated in multicast mode (duplication
of the data streams in the network).
With the setting 0.0.0.0 the encoder for the relevant stream operates in multi-unicast mode
(copying of data streams in the unit). The camera supports multi-unicast connections for up to
five simultaneously connected receivers.

Notice!

Duplication of data places a heavy demand on the unit and can lead to impairment of the

image quality under certain circumstances.

Port

Assign a different port to each data stream if there are simultaneous data streams at the same
multicast address.
Enter the port address of the required stream here.

Streaming

Click the checkbox to activate multicast streaming mode for the relevant stream. An enabled
stream is indicated by a check mark.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 57

Multicast packet TTL

You can enter a value to specify how long the multicast data packets are active on the
network. This value must be greater than one if multicast is to be run via a router.

5.42

Image Posting

You can save individual JPEG images on an FTP server at specific intervals. You can then
retrieve these images at a later date to reconstruct alarm events if required. In order to
configure image posting, and to save and retrieve JPEG images, you must create an Account in
which to save and access them. If you have not configured an account, the following error
message appears at the top of this page: “No configured account. Configure accounts.” Click
the link to access the Accounts, page 57 page.

Image size

Select the size of the images that you want to save:
– Small
– Medium
– Large
– 720p
– 1080p

File name

You can select how file names will be created for the individual images that are transmitted.
– Overwrite The same file name is always used and any existing file will be overwritten with

the current file.

– Increment A number from 000 to 255 is added to the file name and automatically

incremented by 1. When it reaches 255 it starts again from 000.

– Date/time suffix The date and time are automatically added to the file name. When

setting this parameter, ensure that the unit's date and time are always correctly set.
Example: the file snap011005_114530.jpg was stored on October 1, 2005 at 11:45 and
30 seconds.

Posting interval

Enter the interval in seconds at which the images will be sent to an FTP server. Enter 0 (zero)
if you do not want any images to be sent.

Target

Select the target—the name of the account on the server—to which to save images.

Enable

Click this checkbox to enable face detection.

File format

Select the file format in which to save images. Options are JPEG (default), YUV420, TIFF.

Target

Select the target—the name of the account on the server—to which to save images.

Timeouts

Select the number of timesouts for image posting. The default is 0 (no timeout).

Maximum image width

Enter a number for the maximum width, in pixels, for the saved images.

5.43

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Accounts

In order to configure image posting, and to save and retrieve JPEG images, you must create an
Account in which to save and access them. You can create a maximum of four (4) accounts.

Type

Select the type of account: FTP or Dropbox.

58 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Account name

Enter the name of the account.

IP address

Enter the IP address of the server on which you wish to save the JPEG images.

Login

Enter the login ID for the server.

Password

Enter the password that gives you access to the server. To verify the password, click the
Check button to the right.

Path

Enter the exact path on which you wish to post the images on the server. To browse for the
correct path, click the Browse button to the right.

Maximum bit rate

Enter the maximum bit rate for the JPEG images (in kbps).

5.44

5.45

5.46

5.47

IPv4 Filter

Use this setting to configure a filter that allows or blocks network traffic that matches a
specified address or protocol.

IP Address 1 / 2

Enter the IPv4 address that you want to allow or block

Mask 1 / 2

Enter the subnet mask for the appropriate IPv4 address.

Encryption

A special license, with which you will receive a corresponding activation key, is required to
encrypt user data. You can enter the activation key to release the function on the Licenses
page (see Licenses, page 60).

Advanced Mode: Service

Maintenance, page 58
Licenses, page 60

Diagnostics

System Overview, page 60

Maintenance

Upgrading your camera

The camera allows an operator to update the camera firmware via the TCP/IP network. The
Maintenance page allows updates of the firmware.
For the latest firmware, go to www.boschsecurity.com, navigate to the product page for your
camera, and then download the software from the Software tab.
The preferred method to update your camera is through a direct connection between the
camera and a PC. This method entails connecting the Ethernet cable from the camera directly
to the Ethernet port of a PC.
If the direct-connect method is not practical, you can also update the camera through a Local
Area Network (LAN). You cannot, however, update the camera through a Wide Area Network
(WAN) or via the Internet.

Update server

Enter the path of the server on which to perform the update. Click Check to verify the path.

2015.02 | 1.0 | Software Manual Bosch Security Systems

!

EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 59

Firmware

The camera is designed in such a way that its functions and parameters can be updated with
firmware. To do this, transfer the current firmware package to the unit via the selected
network. It will then be automatically installed there.
In this way, a camera can be serviced and updated remotely without a technician having to
change the installation on site.

Caution!

Before launching the firmware upload make sure that you have selected the correct upload

file. Uploading the wrong files can result in the unit no longer being addressable, in which

case you must replace the unit.

You should never interrupt the installation of firmware. An interruption can lead to the flash-

EPROM being incorrectly programmed. This in turn can result in the unit no longer being

addressable, in which case it will have to be replaced. Even changing to another page or

closing the browser window leads to an interruption.

Upload

1. Enter the full path of the file to upload or click Browse to navigate to the required
firmware file (*.fw).

2. Make certain that the file to be loaded comes from the same unit type as the unit you
want to configure.

3. Next, click Upload to begin transferring the file to the unit. The progress bar allows you to
monitor the transfer.

4. Click OK to the warning message to continue the firmware upload, or Cancel to stop the
upload.
The page displays a progress bar as the firmware is uploaded.
Note: Once the progress bar reaches 100%, the system opens the reset page. Allow the
reset page to complete its action.

Once the upload is complete, the new configuration is activated. The time remaining is shown
by the message going to reset Reconnecting in ... seconds. The unit reboots automatically
once the upload has successfully completed.

Download

1. Click the Download button. A dialog box opens.

2. Follow the on-screen instructions to save the current settings.

Configuration

You can save configuration data for the camera on a computer and then load saved
configuration data from a computer to the unit.

SSL certificate

To be able to work with an SSL encrypted data connection, both ends of a connection must
hold the relevant certificates. You can upload the SSL certificate, comprising one or multiple
files, onto the camera.
If you wish to upload multiple files onto camera, you must select them consecutively.

1. Enter the full path of the file to upload or click Browse to select the required file.

2. Next, click Upload to begin transferring the file to the unit.

3. Once all files have been successfully uploaded, the unit must be rebooted. In the address
bar of your browser, enter /reset after the IP address of camera (for example

192.168.0.10/reset).

The new SSL certificate is valid.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

60 en | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX

Maintenance log

You can download an internal maintenance log from the unit to send it to Customer Service
for support purposes. Click Download and select a storage location for the file.

5.48

5.49

Licenses

You can enter the activation key to release additional functions or software modules.

Notice!

The activation key cannot be deactivated again and is not transferable to other units.

System Overview

The data on this page are for information purposes only and cannot be changed. Keep a
record of this information in case technical assistance is required.

Notice!

You can select all required text on this page with the mouse and copy it to the clipboard with

the [Ctrl]+[C] key combination, for example if you want to send it via e-mail.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Operation | en 61

6

6.1

Operation

LIVE Page

After the connection is established, the LIVE page is initially displayed. It shows the live video
image on the right of the browser window. Depending on the configuration, various text
overlays may be visible on the live video image.

Other information may also be shown next to the live video image. The items shown depend
on the settings on the LIVE Functions page.

Display Stamping

Various overlays or “stamps” in the video image provide important status information. The
overlays provide the following information:

Decoding error. The frame might show artifacts due to decoding errors. If subsequent
frames reference this corrupted frame, they might also show decoding errors as well
but won’t be marked with the “decoding error” icon.

Alarm flag set on media item

Communication error. Any kind of communication error is visualized by this icon.
Cause can be a connection failure to the storage medium, a protocol violation with a
sub component or simply a timeout. An automatic reconnection procedure is started
in the background in order to recover from this error.

Gap; no video recorded

6.1.1

6.1.2

Watermarking not valid

Watermarking flag set on media item

Motion flag set on media item

Discovery of storage not completed. If the information about recorded video is not
cached, a discovery procedure is started in order find all recorded video. During this
time, the “discovery” symbol is shown. While discovery is executed, gaps might be
shown in places which the discovery has not yet reached. The gap will automatically
be replaced by the true video, as soon as the correct information is available.

Image selection

Image Selection

You can view the image of the camera in different displays.
4 Click one of the tabs Stream 1, Stream 2, or M-JPEG below the video image to toggle

between the different displays of the camera image.

Storage, CPU and network status

When accessing the unit with a browser, the local storage, processor and network status icons
are shown in the upper right of the window next to the Bosch logo.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

62 en | Operation EXTEGRA IP 9000 FX

When a local storage card is available, the memory card icon changes color (green, orange or
red) to indicate the local storage activity. If you hover over this icon with the mouse the
storage activity is shown as a percentage.
If you hover over the middle icon, the CPU load is shown.
If you hover over the right-hand icon, the network load is shown.
This information can help with problem solving or when fine tuning the unit. For example:
– if the storage activity is too high, change the recording profile,
– if the CPU load is too big, change the IVA settings,
– if the network load is too big, change the encoder profile to reduce bitrate.

Processor Load

If the camera is accessed via the Web browser, you will see the processor load indicator in the
top left of the window next to the manufacturer's logo.

You can obtain additional information to help when you troubleshoot or fine-tune the unit. The
values indicate the proportions of the individual functions on the encoder load, shown as
percentages.
4 Move the cursor over the graphic indicator. Some additional numerical values are also

displayed.

6.1.3

View Control

View Control

The View Control tab allows you to control camera functions (pan, tilt, zoom, focus, and iris),
navigate through on-screen menus and to view preset scenes (shots).

Ref # Description Ref # Description

1 Tilts the camera up 8 Focus far²

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Operation | en 63

2 Tilts the camera down 9 Focus near²

3 Pans the camera to the left 10 Iris close²

4 Pans the camera to the right 11 Iris open²

5 Pans and tilts the camera in all

directions

12 Sets the pre-set scene for the

corresponding button 1, 2, 3, 4, 5 and 6

6 Zoom out¹ 13 Moves the camera to pre-set scene

numbers 1, 2, 3, 4, 5 and 6

7 Zoom in¹

¹ This function is also accessible by using the mouse scroll wheel while in the Live video
frame.

² This button is also used as the “Enter” button to select menu items from the AUX tab.

To control a peripheral, follow these steps:

1. Click the appropriate controls.

2. Move the mouse cursor over the video image. Additional options for controlling
peripherals are displayed with the mouse cursor.

3. To manually pan throughout the image area, move your cursor over any part of the live

video. The image area displays a directional arrow (

), then click and hold

the right mouse key to pan the camera.

View Control

The View Control tab allows you to control camera functions (zoom, focus, and iris), navigate
through on-screen menus and to view zoom presets.

1

Zoom out

2 Zoom in

3 Focus far

4 Focus near

5 Iris close

6 Iris open

Bosch Security Systems Software Manual 2015.02 | 1.0 |

64 en | Operation EXTEGRA IP 9000 FX

7 Sets the pre-set scene for the corresponding button 1, 2, 3, 4, 5 and 6

8 Zooms the camera to pre-set scene numbers 1, 2, 3, 4, 5 and 6

To control a peripheral, follow these steps:

1. Click the appropriate controls.

2. Move the mouse cursor over the video image. Additional options for controlling
peripherals are displayed with the mouse cursor.

Preset List

The View Control Tab displays a list of all presets with their titles, if any are defined, below
Presets 1-6. To move the camera to a preset scene, select the appropriate preset from the
drop-down list. Refer to Prepositions and Tours to define a preset scene and to specify a title
for the preset.

Figure 6.1: View control tab preset / scene list

6.1.4

AUX Control

Aux Control Tab

The AUX Control tab is used to enter pre-programmed keyboard control commands. These
commands are composed of a command number plus the appropriate function key (Show
scene, Set scene, AUX on, AUX off). A valid combination either issues a command to the
camera or displays an on-screen menu.
To access the AUX Control tab, go to the LIVE page and click the AUX Control tab.
(Refer to the User Command Table for a list of all AUX commands.)
By default, the device is configured for a total of 256 presets.
Some legacy systems may not support presets above 99. In this case, you can set the camera
to use only presets 1-99. Enter 151 on the keypad, and then click AUX on.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Operation | en 65

1 Command number field

2 Keypad (numbers 0-9)

3 Show a preset scene

4 Set a preset scene

5 Initiates a command

6 Deletes a number in the Command Number field

7 Used to select a menu item

8 Stops a command

To Enter a Keyboard Control Command:

1. Place the cursor in the Command Number field.

2. Click the desired command number via the on-screen keypad.

3. Click either the Aux on button or the Aux off button to initiate or stop the command.

4. If the command initiates a menu, use the Up/Down arrows on the View Control to
navigate the menu. Click the Focus button or Iris button to select a menu item.

6.1.5

Bosch Security Systems Software Manual 2015.02 | 1.0 |

Presets

Preset scenes (or shots) are camera positions that are saved in memory for future use.
Set presets with the zoom control option. If your computer mouse has a scroll button, you can
use it to zoom in and out to set presets.

1. Scroll your mouse to zoom in or out to the desired position for the preset.

2. Click any number combination from 1-256 from the on-screen keypad to identify the scene

number.

3. Click the Set scene button. The image area displays a message that indicates which scene

number was saved.

To Set a Preset Shot:

Preset shots (or scenes) are camera positions that are saved in memory for future use.

1. Move your cursor over the live image and wait for the area to display a directional arrow.

2. Click and hold a mouse button to pan to the desired position that you want to save.

3. Click any number combination from 1-256 from the on-screen keypad to identify the
scene number.

66 en | Operation EXTEGRA IP 9000 FX

4. Click the Set scene button. The image area displays a message that indicates which shot
number was saved.

To View a Preset Shot:

1. Click the number of the scene you want to view using the on-screen keypad.

2. Click the Show scene button.

Notice!

For more information about the camera settings and controls, click the Help on this page?

link to open the online help.

6.1.6

6.1.7

Digital I/O

The alarm icon is for information purposes and indicates the status of an alarm input: When an
alarm is triggered, the icon lights up blue. The device’s configuration determines whether the
alarm is displayed, as well as additional details. Refer to the online help for more information.

Triggering Relay

You can switch connected units using the relays in the camera (for example, lights or door
openers).
4 To activate this, click the icon for the relay next to the video image. The icon will be red

when the relay is activated.

System Log/Event Log

System Log

The System Log field contains information about the operating status of the camera and the
connection. You can save these messages automatically in a file (see the online help).

Events such as the triggering or end of alarms are shown in the Event Log field. You can save
these messages automatically in a file (see the online help).

1. If you want to delete the entries, click the delete icon in the top right-hand corner of the
relevant field.

2. If you want to view a detailed log, click the icon in the top right-hand corner of the
relevant field. A new window will open.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Operation | en 67

6.1.8

6.1.9

Audio

Audio function

All users who are connected to the camera via Web browser can receive audio signals from the
camera. Audio signals can only be sent to the camera by the user who connects to the unit
first.

1. On the LIVE page, click anywhere next to the video image to remove the focus from the
ActiveX.

2. Hold down the F12 key to establish a voice connection to the camera. The browser’s
status bar displays the message Send Audio ON.

3. Release the F12 key when you want to stop sending audio signals to the camera. The
status bar displays the message Send Audio OFF.

Notice!

When the voice contact connection to the camera is broken, the next user to make a

connection to the camera can send audio data to the camera.

Saving snapshots

Saving Snapshots

You can save individual images from the video sequence currently shown on the LIVE page in
JPEG format on your computer's hard drive. The icon for recording single images is only visible
if the unit is configured to enable this process.
4 Click the icon. The storage location depends on the configuration of the camera.

6.1.10

6.1.11

Recording

Recording Video Sequences

You can save sections of the video sequence currently shown on the LIVE page on your
computer's hard drive. The icon for recording video sequences is only visible if the unit is
configured to enable this process.
4 Click the icon to start recording. The storage location depends on the configuration of the

camera. A red dot in the icon indicates that recording is in progress.

1. Click the icon again to stop recording.

2. To change the storage location for the recorded video, select Advanced Mode >

Recording > Storage Management from the SETTINGS page.

Image Resolution

Sequences are saved at the resolution that has been preset in the configuration for the
encoder (see Basic Mode: Network, page 14).

Playback

Accessing Recorded Video from the Recordings Page / PLAYBACK
Click Recordings to access the Recordings page from the LIVE page or SETTINGS page (the

Recordings link is only visible if a storage medium has been selected).

Selecting Recordings

All saved sequences are displayed in a list. A track number is assigned to each sequence. Start
time and stop time, recording duration, number of alarms, and recording type are displayed.

Bosch Security Systems Software Manual 2015.02 | 1.0 |

en | Operation EXTEGRA IP 9000 FX

68

To play back recorded video sequences:

1. Select Recording 1 or 2 in the drop-down menu. (The contents for 1 and 2 are identical,
only the quality and location may be different.)

2. Use the arrow buttons to browse the list.

3. Click a track. The playback for the selected sequence starts.

Export to FTP

Click Export to FTP to send the current track to the FTP server. If required, change the times
within the selected range.

Controlling Playback

A time bar below the video image allows quick orientation. The time interval associated with
the sequence is displayed in the bar in gray. A green arrow above the bar indicates the
position of the image currently being played back within the sequence.

The time bar offers various options for navigation in and between sequences.
– Change the time interval displayed by clicking the plus or minus icons. The display can

span a range from two months to a few seconds.

– If required, drag the green arrow to the point in time at which the playback should begin.
– Red bars indicate the points in time where alarms were triggered. Drag the green arrow

to navigate to these points quickly.

Control playback by means of the buttons below the video image. The buttons have the
following functions:

Start/Pause playback

Jump to start of active sequence or to previous sequence

Jump to start of the next video sequence in the list

Continuously select playback speed by means of the speed regulator (slide control):

Bookmarks

In addition, set markers in the sequences, so-called bookmarks, and jump directly to these.
These bookmarks are indicated as small yellow arrows above the time interval. Use the
bookmarks as follows:

Jump to the previous bookmark

Set bookmark

Jump to the following bookmark
Bookmarks are only valid while in the Recordings page; they are not saved with the sequences.
All bookmarks are deleted when leaving the page.

2015.02 | 1.0 | Software Manual Bosch Security Systems

EXTEGRA IP 9000 FX Appendix | en 69

7

Appendix

Alarm
Rule
Output

Y On/Off 7 Play Custom Pre-position

Y On/Off 8 Play Pre-position Tour Activate/Deactivate

Y On/Off 20 Backlight Comp Backlight Compensation

Y On/Off 24 Stabilization Electronic Stabilization

Y On/Off 26 WDR/HDR Activates Wide Dynamic Range/

N On/Off 40 Restore Camera Settings Restores all setting to their

Y On/Off 43 Auto Gain Control AGC–On, Auto, Off

N 50 Playback Tour A Activate/Deactivate, Continuous

Function
Key

Comm.
No.

Command Description

Activate/Deactivate

Tour

(Available only with the
AUTODOME 7000 IP)

High Dynamic Range

original defaults

N 51 Playback Tour A Activate/Deactivate, One Time

N 52 Playback Tour B Activate/Deactivate, Continuous

N 53 Playback Tour A Activate/Deactivate, One Time

Y On/Off 57 Night Mode setting Enables/Disables Night Mode

(Day/ Night only)

Y On/Off 60 On Screen Display On–enable

Off–disable

N On/Off 66 Display Software Version Display software version

information. Issue Once–presents
basic information
Issue Twice (while basic info
displayed) –presents expanded
information (HD models only)

N On/Off 67 IR Focus Correction On -Enable when external IR lamps

are in use with non-IR cameras
Off–disable

Y On/Off 80 Digital Zoom Lock Turns digital zoom on and off

Y On/Off 87 Privacy Masking On–enable

Off–disable

N On/Off 100 Record Tour A On–start recording

Off–stop recording

Bosch Security Systems Software Manual 2015.02 | 1.0 |

70 en | Appendix EXTEGRA IP 9000 FX

Alarm
Rule

Function
Key

Comm.
No.

Command Description

Output

N On/Off 101 Record Tour B On–start recording

Off- stop recording

N On 606 Power Mode ` Temporarily displays current

power mode “24 VAC:”, “POE+”,
“POE++”, or “Unknown”)

N On 911 Camera Reboot Forces the camera to complete the

power on boot sequence.
AUTODOME cameras will complete
“Finding Home”.

Y Set 1-256 Pre-position Programming Set ###

Saves the current PTZ values as a
preset view.

Y Shot 1-256 Pre-position Recall Shot ###

Recalls the previously saved PTZ
preset position.

2015.02 | 1.0 | Software Manual Bosch Security Systems

Bosch Security Systems, Inc.

850 Greenfield Road
Lancaster, PA, 17601
USA

www.boschsecurity.com

© Bosch Security Systems, Inc., 2015

Bosch Sicherheitssysteme GmbH

Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
