Bosch B36CT80SNS, B36CT81SNS Maintance Manual
Fridge-freezer
Réfrigérateur / congélateur combiné
Refrigerador/congelador
B36CT...
en Installation instructions and instructions for use ................ 2
fr Notice de montage et d’utilisation .................................... 34
es Instrucciones de uso y montaje ......................................... 68
en-us
enTable of contents
enInstallation i nstr ucti ons and i nst r uct i ons for use
( Important safety instructions . . . . . . . . . . . . 3
Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
About these instructions . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Restriction of user group. . . . . . . . . . . . . . . . . . . . . 3
Risk of explosion. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Risk of electric shock . . . . . . . . . . . . . . . . . . . . . . . 3
Risk of cold burns . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Risk of Injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Fire hazard/Danger due to refrigerants . . . . . . . . . . 4
Risk of fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Risk of suffocation. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
State of California Proposition 65 Warnings . . . . . . 4
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . 5
7 Environmental protection . . . . . . . . . . . . . . . 5
Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Old appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Installation and connection . . . . . . . . . . . . . . 5
Contents of package. . . . . . . . . . . . . . . . . . . . . . . . 5
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the appliance . . . . . . . . . . . . . . . . . . . . . . 6
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Before using for the first time . . . . . . . . . . . . . . . . 13
Water connection . . . . . . . . . . . . . . . . . . . . . . . . . 13
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . 13
* Getting to know your appliance . . . . . . . . . 14
Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Operating controls. . . . . . . . . . . . . . . . . . . . . . . . . 15
Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1 Operating the appliance . . . . . . . . . . . . . . . . 20
Switching the appliance on . . . . . . . . . . . . . . . . . .20
Switching off and disconnecting the appliance . . . 20
Setting the temperature unit . . . . . . . . . . . . . . . . .20
Setting the temperature. . . . . . . . . . . . . . . . . . . . . 20
Setting cool-fresh compartment. . . . . . . . . . . . . . . 20
Super cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Super freezing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Energy saving mode . . . . . . . . . . . . . . . . . . . . . . .21
Freshness mode . . . . . . . . . . . . . . . . . . . . . . . . . .21
Vacation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the light . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Change filter alarm . . . . . . . . . . . . . . . . . . . . . . . . 22
o Home Connect. . . . . . . . . . . . . . . . . . . . . . . . 23
Setting up Home Connect . . . . . . . . . . . . . . . . . . 23
Installing updates for the Home Connect software 24
Information on data protection . . . . . . . . . . . . . . . 24
U Refrigerator compartment. . . . . . . . . . . . . . 25
Note when storing food . . . . . . . . . . . . . . . . . . . . 25
T Cool-fresh compartment . . . . . . . . . . . . . . . 25
Cool-fresh bin . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Storage recommendations . . . . . . . . . . . . . . . . . . 25
W Freezer compartment. . . . . . . . . . . . . . . . . . 26
V Water dispenser . . . . . . . . . . . . . . . . . . . . . . 26
Before using the appliance for the first time. . . . . 26
Observing drinking water quality . . . . . . . . . . . . . 26
Dispensing water . . . . . . . . . . . . . . . . . . . . . . . . . 26
; Ice maker. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Before using the appliance for the first time. . . . . 27
Switching ice cube production on or off . . . . . . . . 27
= Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
D Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cleaning the appliance interior. . . . . . . . . . . . . . . 28
Cleaning the fittings . . . . . . . . . . . . . . . . . . . . . . . 28
l Odors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
9 Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
> Noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Normal noises . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Preventing noises . . . . . . . . . . . . . . . . . . . . . . . . . 30
3 Faults – what to do? . . . . . . . . . . . . . . . . . . 31
Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Water dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Ice maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4 Customer service. . . . . . . . . . . . . . . . . . . . . 33
Appliance self-test . . . . . . . . . . . . . . . . . . . . . . . . 33
Warranty statement. . . . . . . . . . . . . . . . . . . . . . . . 33
M Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Door alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Temperature alarm . . . . . . . . . . . . . . . . . . . . . . . .22
2
9 Important safety instructions
READ INSTRUCTIONS - DO NOT DISCARD!
(Important safety instructions
Impor t ant safet y i nstr ucti ons
READ INSTRUCTIONS - DO NOT DISCARD!
Important safety instructions en-us
Definitions
9 WARNING
Non-observance of this warning could
result in death or serious injuries.
9 CAUTION
Non-observance of this warning could
result in slight or moderately serious
injuries.
NOTICE: Non-observance of this
information could damage the appliance.
Note: This indicates important information
and/or tips.
About these instructions
■ Read and follow the operating and
installation instructions.They contain
important information on how to install,
use and maintain the appliance.
■ Retain all documents for subsequent use
or for the next owner.
Introduction
■ This appliance complies with the relevant
safety regulations for electrical
appliances.
■ The refrigeration circuit has been
checked for leaks.
Restriction of user group
■ This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
■ Children should be supervised to ensure
that they do not play with the appliance.
Risk of explosion
■ Never use electric devices inside the
appliance (e.g. heaters or electric ice
makers).
■ Do not store products which contain
flammable propellants (e.g. spray cans)
or explosive substances in the appliance.
■ Only store high-proof alcohol tightly
closed and standing up.
■ Do not use other means to accelerate the
defrosting process other than those
recommended by the manufacturer.
Risk of electric shock
Improper installations or repairs may put the
user at considerable risk.
■ When installing the appliance, make sure
that the power cord does not get jammed
or damaged.
■ In order to avoid danger, if the power
cord is damaged, disconnect the
appliance from the power source
immediately. Have the power cord
replaced by the manufacturer, customer
service or a similarly qualified person.
■ Do not use multiple outlets, extension
cords, or adapters.
■ Before servicing the appliance or
carrying out installation work, disconnect
the appliance from the power source or
switch off the fuse.
Before cleaning the appliance, press the
ÿ power button to turn the appliance off.
Glass shelves and other equipment can
be moved while the appliance is
switched on.
■ Never cut through or remove the power
cord's third conductor (grounding
conductor).
■ Never defrost or clean the appliance
using a steam cleaner. The steam may
penetrate electrical parts and cause a
short circuit.
■ The appliance, cord and accessories
should only be repaired or replaced by
the manufacturer or an authorized
service provider.
3
en-us Important safety instructions
9 Important safety instructions
READ INSTRUCTIONS - DO NOT DISCARD!
■ Only use original parts supplied by the
manufacturer.
These parts come with a warranty from
the manufacturer that they satisfy the
safety requirements.
Risk of cold burns
■ Never put frozen food straight from the
freezer compartment into your mouth.
■ Avoid prolonged contact of skin with
frozen food, ice and the tubes in the
freezer compartment.
Risk of Injury
Containers which contain carbonated drinks
may burst.
Do not store containers which contain
carbonated drinks in the freezer
compartment.
Fire hazard/Danger due to refrigerants
The tubes of the refrigeration circuit contain
a small quantity of an environmentally
friendly but flammable refrigerant (R600a).
If the refrigerant escapes, it may injure your
eyes or ignite.
■ Do not damage the tubes.
If the tubes are damaged:
■ Keep open flames and ignition sources
away from the appliance.
■ Ventilate the room.
■ Switch off the appliance and unplug the
power plug.
■ Please contact customer service.
Risk of suffocation
■ Keep children away from the packaging
and its parts.
■ To avoid having children climb into the
appliance, never remove the partition
wall of the frozen food bin (large).
Damage
To avoid damage:
■ Do not stand or lean on the base,
runners or doors.
■ Keep plastic parts and door seals free of
oil and grease.
■ Pull the power plug – not the power cord.
Weight
The appliance is very heavy. The appliance
should always be transported and set up by
at least 2 people.
~ "Installation and connection" on page 5
State of California Proposition 65 Warnings
This product may contain a chemical known
to the State of California, which can cause
cancer or reproductive harm. Therefore, the
packaging of your product may bear the
following label as required by California:
Risk of fire
Portable multi-outlet power strips and
portable power supplies may overheat,
causing a fire.
Never leave portable multi-outlet power
strips or portable power supplies behind the
appliance.
4
Intended use en-us
8Intended use
Intended use
Use this appliance
■ only for cooling and freezing food, ice making
and water dispensing.
■ only in the home and in the home environment.
■ only according to these operating instructions.
This appliance is intended for use at an altitude of
max. 13123 ft (4000 meters) above sea level.
7Environmental protection
Env i r o nment al pr ot ect i on
Packaging
All materials are environmentally safe and
recyclable:
■ Dispose of packaging in an environmentally
responsible manner.
■ Please ask your dealer or inquire at your local
authority about current means of disposal.
Old appliances
5 Installation and
connection
Installation and connect i on
Contents of package
After unpacking, check all parts for damage during
transport.
In the event of damage, contact your dealer or our
after-sales service.
The delivery consists of the following parts:
■ Free-standing appliance
■ Installation material
■ Interior fittings (depending on model)
■ Installation instructions and instructions for use
■ Statement of limited product warranty
■ Information on the energy consumption and
noises
Technical data
Refrigerant, cubic capacity and further technical
specifications can be found on the rating plate.
~ "Getting to know your appliance" on page 14
Valuable raw materials can be reclaimed by
recycling old appliances.
9 WARNING
CHILDREN MAY BECOME LOCKED IN THE APPLIANCE AND SUFFOCATE!
Before disposing of your old appliance:
■ Remove the door.
■ Leave shelves and bins in the appliance to
prevent children from climbing in.
■ Keep children away from the discarded
appliance.
9 CAUTION
REFRIGERANT AND HARMFUL GASES MAY ESCAPE.
Do not damage the tubes of the refrigeration
circuit and insulation.
1. Pull out the power plug.
2. Cut through the power cord.
3. Have the appliance disposed of properly.
5
en-us Installation and connection
Installing the appliance
Installation location
The weight of the appliance may be up to 419 lb
(190 kg) depending on the model. The base must
be sufficiently stable and should not give. If
necessary, reinforce the floor.
Installation dimensions
71
½
″
(1815 mm)
Door opening angle
57
⁷/
″
4
¹/
″
(103 mm)
Pro 4
(112 mm)
1
¾ ″
(45 mm)
⁷/
(1459 mm)
″
Pro 57 ⅞ ″
(1470 mm)
90°90°
118°
10
¹⁵/
(278 mm)
Pro 11 ⅛ ″
(283 mm)
″
43 ⅜
(1102 mm)
Minimum clearances
Leave a clearance of 1/2 ˝ (12.7 mm) above the
appliance.
Observe minimum clearances as follows:
1 ″
(25 mm)
″
35
⅝
″
(905 mm)
28 ¾ ″
(731 mm)
25 ″
(635 mm)
24 ″
(610 mm)
44
⁹/
″
(1132 mm)
72 ″
(1830 mm)
⅛
″
(3,2 mm)
⅛
″
(3,2 mm)
Niche dimensions
If you install the appliance in a niche, adhere to the
following dimensions:
″
25
(635 mm)
″
72
(1830 mm)
36
″
(914 mm)
6
Installation and connection en-us
Ventilation
Never cover or block ventilation openings.
Installing the door handle
1. Fit the handle vertically onto the pre-assembled
bolts.
Note: The holes in the handle must face up and
down.
2. Use a 2.5 mm Allen wrench to tighten the pre-
assembled screws in the handle clockwise from
the bottom.
Aligning the appliance
9 CAUTION
■ To avoid damage to the floor, always move the
appliance with the height-adjustable feet
screwed upwards.
■ The two front height-adjustable feet must
always be in contact with the floor to avoid the
appliance from rolling or tipping when the door
is opened.
2. Use a 2.5 mm Allen wrench to tighten the pre-
assembled screws clockwise in the handle from
the top and bottom.
Installing the drawer handle
1. Insert the handle horizontally onto the pre-
assembled bolts.
Note: The holes in the handle must be facing down.
Rollers are located under the appliance for easy
movement and alignment:
1. Place the appliance vertically on a firm, level
floor.
2. Using a wrench, screw down both of the front
height-adjustable feet so that they touch the floor.
3. Compensate for floor unevenness with the front
height-adjustable feet.
Note: To align, use a level.
13
7
en-us Installation and connection
Align refrigerator compartment doors
Align the vertical gap of the doors:
Note: Remove the contents from the doors, if
present.
1. Remove the screw T20 and cover cap on the
door hinge.
2. Loosen the safety screw.
9 CAUTION
Do not remove the safety screw.
3. Turn the adjustment screw until the desired
position is reached when the door is closed.
– To move the upper end of the door outwards,
turn clockwise.
– To move the upper end of the door inwards,
turn counterclockwise.
4. To check the position, close the door and correct
if necessary.
5. Tighten the safety screw again.
6. Fit the cover cap and screw in the screw T20
again.
8
Installation and connection en-us
Align the horizontal gap between the doors:
9 CAUTION
To avoid damage to the appliance, move the
right-hand door down if the door pillar at the top
collides with the housing.
Note: Remove the contents from the doors, if
present.
1. Open the door and drawer.
2. Lift the door and insert a screwdriver into the door
hinge from below.
3. Push up the adjustable part and turn by 60° until
the desired position is reached.
– The door height can be set at 2 levels,
adjusted by 1/16" (1.5 mm) in each case. The
higher level is followed by the lower. The
adjustable part engages as soon as a position
is reached.
– To move the door up, turn clockwise.
– To move the door down, turn
counterclockwise.
4. To check the position, close the door and drawer
and correct if necessary.
9
en-us Installation and connection
Aligning the drawers
You can align the drawer vertically:
1. Open the drawer as far as it will go and remove
the bin.
2. Remove the center screws on both sides.
Note: If you want to reset the drawer to the factory
settings, keep the screws.
3. Loosen the upper screw on both sides.
Note: Do not remove the screws.
4. Lift the drawer and remove the lower screws on
both sides.
5. Move the drawer up or down to the required
position and insert the lower screw in one of the
available holes.
Note: The drawer can be adjusted by 1/16" (2 mm)
up and down.
10
6. Retighten all the screws.
7. To check the position, close the drawer and
correct if necessary.
Installation and connection en-us
You can adjust the angle of the drawer:
1. Open the drawer as far as it will go and remove
the bin.
2. Remove the center screws on both sides.
Note: If you want to reset the drawer to the factory
settings, keep the screws.
3. Loosen the upper and lower screw on both sides.
Note: Do not remove the screws.
4. Move drawer on the lower screw to the left or
right into the required position and tighten the
screw.
5. Retighten all the screws.
6. To check the position, close the drawer and
correct if necessary.
11
en-us Installation and connection
Saving energy
If you follow the instructions below, your appliance will use less power.
Note: The arrangement of the fittings does not affect the energy consumption of the appliance.
Installing the appliance
Keep the appliance out of direct sunlight. The appliance needs to cool less frequently at low ambient temperaInstall the appliance as far away as possible from heating elements,
cooker and other heat sources:
At least 1¼” (3 cm) from electric or gas cookers.
At least 11¾" (30 cm) from oil or solid-fuel cookers.
Select an installation location at a room temperature of approx. 68 °F
(20 °C).
Do not cover or block the ventilation openings. The appliance needs to cool less frequently if the warm air can
Ventilate the room daily.
Using the appliance
Open the appliance door only briefly. The air in the appliance does not warm up as intensely. The appliance
Transport purchased food in a cooler and place in the appliance
quickly.
Allow warm food and drinks to cool down before placing in the appli-
ance.
Thaw frozen food in the refrigerator compartment to utilize the low
temperature of the frozen food.
Always leave some space between the food and to the back panel. The air can circulate and the humidity will remain constant. The appliPack food airtight.
Do not cover or block the ventilation openings. The appliance consumes less power if the warm air can escape.
Vacuum the ventilation openings once a year or as frequently as
needed.
tures and therefore consumes less power.
escape and therefore consumes less power.
needs to cool less frequently and therefore consumes less power.
ance needs to cool less frequently and therefore consumes less
power.
--------
12
Installation and connection en-us
Before using for the first time
1. Remove information material, adhesive tape and
protective foil.
2. Remove the power cord from the appliance.
3. Clean the appliance.
4. Install the equipment.
~ "Equipment" on page 16
Water connection
9 CAUTION
■ Never bend, crush, modify or cut water hoses.
■ Never pull on the water hose on the rear panel
of the appliance.
■ To avoid damage to the appliance and to
ensure its proper functioning, it should only be
connected to a drinking water line.
■ To avoid water damage, a shut-off valve must
be installed.
Notes
■ Installation and connection of the appliance must
be carried out by a qualified technician.
■ Observe the local regulations for water
connection.
Water pressure of drinking water line
9 CAUTION
To avoid damage to the appliance, a pressure
relief valve must be installed between the
drinking water connection and the hose set if
the water pressure exceeds the maximum
value.
Note: If the water pressure is too low, this will impair
functioning of the appliance.
■ Water pressure min.: 0.2 MPa (2 bar / 29 psi)
■ Water pressure max.: 0.8 MPa (8 bar / 116 psi)
Electrical connection
9 CAUTION
Do not connect the appliance to electronic
energy saver plugs.
Note: You can connect the appliance to mains-
controlled and sine-controlled inverters.
Mains-controlled inverters are used for photovoltaic
systems which are connected directly to the national
grid. Sine-controlled inverters must be used for
isolated applications. Isolated applications, e.g. on
ships or in mountain lodges, are not directly
connected to the national grid.
1. Insert the power cord plug.
2. Check that the power outlet has been installed
according to the regulations and complies with
the requirements.
Requirements for power outlets
Power outlet with protective
conductor:
110 V ... 127 V with
60 Hz
Fuse: 10 A ... 16 A
Maximum simultaneous load
Appliance: 6 A
3. Connect the appliance to an outlet near the
appliance.
The outlet must also be freely accessible
following installation of the appliance.
9 WARNING
RISK OF ELECTRIC SHOCK!
Never use multiple outlets, extension cords
or adapters.
The appliance must be grounded correctly.
Never cut through or remove the power
cord's third conductor (grounding
conductor).
9 WARNING
RISK OF ELECTRIC SHOCK!
If the power cord is too short, never use
multiple outlets or extension cords.Instead,
please contact customer service.
13
en-us Getting to know your appliance
*Getting to know your
appliance
Gett i ng to know your appl i ance
Appliance
#
+
3
(
0
8
@
H
P
X
`
h
)"
)*
)2
):
)B
)J
)R
)Z
)b
)j
1"
1*
12
# Refrigerator compartment
+ Cool-fresh compartment
3 Freezer compartment
( Operating controls
0 Equipment bar
8 Bin (hanging)
@ Shelf (hanging)
H Water dispenser
P Pull-out bin
X Controls for cool-fresh compartment
` Cool-fresh bin
h Ice maker
)" Ice cube bin with ice scoop
1:
)* Interior light
)2 Water filter
): Butter and cheese compartment
)B Bottle shelf (hanging)
)J Rating plate
)R Door pillar with condensation protection
)Z Fixed shelf
)b Storage compartment for large bottles
)j Ethylene absorber
1" Frozen food bin (small)
1* Frozen food bin (flat)
12 Frozen food bin (large)
1: Height-adjustable feet
14
Getting to know your appliance en-us
Operating controls
(08@ H P X `h)")*)2):
( Refrigerator compartment Û super button
Switches super cooling on or off.
0 Refrigerator compartment temperature
display
Indicates the set temperature in °C/°F.
8 Refrigerator compartment Y/X button
Sets the temperature of the refrigerator
compartment.
@ fresh button
Switches freshness mode on or off.
H eco button
Switches energy-saving mode on or off.
P vacation button
Switches vacation mode on or off.
Controls submenu
X ÿ power button
Switches the appliance on or off.
` alarm off button
Switches off the alarm.
h menu button
Opens the menu.
)" change filter button
Switches the change filter alarm off.
)* Freezer compartment ¾ super button
Switches super freezing on or off.
)2 Freezer compartment temperature display
Indicates the set temperature in °C/°F.
): Freezer compartment Y/X button
Sets the temperature of the freezer
compartment.
( Submenu display
Displays the selected submenu.
0 Y/X submenu button
Used to navigate through the submenu.
8 connect button
Opens the Home Connect menu.
@ light settings button
Opens the lighting menu.
H °C/°F button
Opens the temperature unit menu.
P Settings display
Displays the settings of the submenu.
P`hXH(0 @8
X Y/X Settings button
Changes the settings of the submenu.
` alarm off button
Opens the alarm menu.
h change filter button
Opens the filter menu.
15
en-us Getting to know your appliance
Controls for cool-fresh compartment
PXH(0 @8
( 29°F ^ button
Sets the temperature in the cool-fresh
compartment to 29 °F (–2 °C), and the
humidity to low.
0 32°F
^ button
Sets the temperature in the cool-fresh
compartment to 32 °F (0 °C), and the
humidity to low.
8 32°F
^^ button
Sets the temperature in the cool-fresh
compartment to 32 °F (0 °C), and the
humidity to high.
@ 34°F
^ button
Sets the temperature in the cool-fresh
compartment to 34 °F (1 °C), and the
humidity to low.
Equipment
Storage compartment
You can remove the storage compartment:
■ Lift up the storage compartment and remove.
H 40°F
^ button
Sets the temperature in the cool-fresh
compartment to 40 °F (4 °C), and the
humidity to low.
P unlock button cool-fresh compartment
Unlocks the controls of the cool-fresh
compartment.
X Light bar custom|
Lights up if user-defined settings have
been set via the Home Connect app. For
more information, see the Home Connect
app.
Shelf
You can remove and adjust the shelf:
■ Lift shelf and remove.
Notes
■ Do not cover the ventilation openings.
■ Insert shelf carefully to avoid scratching the
appliance.
■ Ensure that the hooks are fully inserted and the
shelf is horizontal.
16
Getting to know your appliance en-us
Equipment bar
You can remove and adjust the equipment bar:
1. Lift equipment bar and remove.
2. When re-inserting, insert hooks on back of the
equipment bar at same height to make the
equipment bar level.
Note: Insert the equipment bar carefully to avoid
scratching the appliance.
Note: You can remove the bin (hanging), the shelf
(hanging) and the bottle shelf (hanging) and move
them laterally.
Pull-out bin
You can remove the bin:
■ Pull out the bin all the way, lift at the front and
remove.
You can insert the bin:
■ Pull out the telescopic rails all the way
■ Place the bin on the telescopic rails and push into
the appliance until it engages.
Fixed shelf
You can remove the shelf:
■ Open the bin, lift the shelf at the front and
remove.
17
en-us Getting to know your appliance
Cool-fresh bin
You can remove the bin:
■ Pull out the bin all the way, lift at the front and
remove.
You can insert the bin:
■ Pull out the telescopic rails all the way
■ Place the bin on the telescopic rails and push into
the appliance until it engages.
Frozen food bin (small)
You can remove the bin:
■ Pull out the bin all the way, lift at the front and
remove.
Ice cube bin
You can remove the ice cube bin:
■ Pull out the frozen food bin (flat) as far as it will
go and remove the ice cube bin.
Notes
■ Use the ice scoop to remove ice cubes from the
ice cube bin.
■ To ensure that ice cube production does not stop
too soon, do not store the ice scoop in the ice
cube bin.
Frozen food bin (flat)
You can take out the frozen food bin (flat):
1. Pull the frozen food bin all the way out.
2. Pull the frozen food bin (flat) out, lift and remove.
You can insert the bin:
■ Pull out the telescopic rails all the way.
■ Place the bin on the telescopic rails and push into
the appliance until it engages.
18
Getting to know your appliance en-us
Frozen food bin (large)
9 CAUTION
To avoid damage to equipment, never remove
the partition wall from the frozen food bin
(large).
You can take out the frozen food bin (large):
1. Pull the freezer compartment drawer all the way
out and remove the frozen food bin (flat).
2. Lift the frozen food bin (large) and remove it.
Change water filter or replace with bypass filter:
Notes
■ When changing, some water will drip from the
filter. Wipe drips dry with a soft cloth.
■ You can dispose of the used filter with your
household garbage.
1. Reach into the lower recess of the filter cover,
pull forwards slightly and move to the bottom left.
2. Turn the filter 90° counterclockwise and remove.
3. Insert the new filter in the filter opening to the
stop and turn 90° clockwise as far as it will go.
4. Move the filter cover up to the right again and
slide back as far as it will go.
Water filter
Note:
After installing a new water filter, for hygiene
reasons discard the ice cubes produced within the
first 24 hours or dispense water for 5 minutes and
discard.
The water filter supplied filters particles and the taste
of chlorine out of the water, not bacteria or microbes:
■ Replace the water filter every 6 months or as
frequently as needed.
You can also use the appliance without an internal
water filter if you use an external water filter system.
To do this, replace the water filter with a bypass filter:
■ The bypass filter filters coarse particles from the
drinking water and can be cleaned as required.
■ The bypass filter can remain in the appliance
permanently and does not need to be changed.
■ Switch off the change filter alarm every 6 months.
~ "Change filter alarm" on page 22
A new water filter or bypass filter can be purchased
from customer service or a specialist dealer.
Ethylene absorber
Fasten the ethylene absorber in the cool-fresh bin.
Note: For more information about installation and
use, see the installation and operating instructions
for the ethylene absorber.
19
en-us Operating the appliance
1Operating the appliance
Operat i ng the appl i anc e
Switching the appliance on
1. Press the ÿ power button.
The appliance begins to cool. The warning sound,
the flashing freezer compartment temperature
display and the illuminated alarm off button
indicate that the freezer compartment is still too
warm.
2. Press the alarm off button.
The warning sound switches off.
3. Set the required temperature.
Operating tips
■ When the appliance has been switched on, it may
take several hours until the set temperatures have
been reached. Do not put in any food until the
selected temperature has been reached.
■ The fully automatic NoFrost system ensures that
the appliance remains frost-free. Defrosting is not
required.
■ The front sides of the housing are partly heated
slightly. This prevents condensation in the area
of the door seal.
Switching off and disconnecting the appliance
Setting the temperature
Recommended temperature
Refrigerator compartment: 37 °F (3 °C)
Cool-fresh compartment: 32 °F (0 °C)
Freezer compartment: 0 °F (–18 °C)
Cooling compartment
■ Keep pressing the Y/X button until the display
indicates the required temperature.
Freezer compartment
■ Keep pressing Y/X button until the display
indicates the required temperature.
Setting cool-fresh compartment
You can set the temperature and humidity of the
cool-fresh bin using pre-defined storage settings:
1. Open refrigerator compartment doors.
2. Press any button of the cool-fresh compartment
controls.
3. Press and hold the unlock cool-fresh
compartment button until the light bar is fully
illuminated.
4. Press the required storage setting button.
5. Close refrigerator compartment doors.
The setting is saved.
Switching off the appliance
■ Press ÿ power button.
The appliance is no longer cooling.
Disconnecting the appliance
If you do not use the appliance for a prolonged
period:
1. Turn off the water supply to the appliance.
2. Remove groceries.
3. Press the ÿ power button.
4. Pull out the power plug or switch off the fuse.
The appliance is no longer cooling.
5. Remove the water filter, empty the ice cube bin
and clean the appliance.
6. Leave the doors and drawers of the appliance
open.
Setting the temperature unit
You can choose between the units °C and °F:
1. Press menu button.
2. Press °C/°F button.
3. Press Y/X Settings button until settings display
shows °C or °F.
4. Press menu button.
The setting is saved.
Super cooling
Super cooling cools the refrigerator compartment as
cold as possible.
Switch on super cooling, e.g.:
■ Before placing large quantities of food into the
compartment
■ For cooling drinks quickly
Note: When super cooling is switched on, increased
operating noises may occur.
After approx. 6 hours, the appliance switches to
normal operation.
Switch super cooling on/off:
■ Press Û super button refrigerator compartment.
When super cooling is switched on, the button
lights up.
20
Operating the appliance en-us
Super freezing
With super freezing, the freezer compartment cools
down to the coldest temperature setting of the
freezer compartment.
Switch on super freezing, e.g.:
■ To quickly freeze food all the way to the center
■ 1 ... 2 hours before freezing food weighing
4.5 lbs (2 kg) or more
■ To increase ice cube production
Note: When super freezing is switched on, increased
operating noise may occur.
After approx. 8 hours, the appliance automatically
returns to normal operation.
Switching super freezing on/off:
■ Press ¾ super button.
When super freezing is switched on, the button is
lit.
Energy saving mode
You can set the appliance to save energy with
energy-saving mode.
The appliance automatically sets the following
temperatures:
■ Refrigerator compartment: 43 °F (6 °C)
■ Cool-fresh compartment: 32 °F (0 °C)
■ Freezer compartment: 6 °F (–14 °C)
Switch energy-saving mode on or off:
■ Press eco button.
The temperature is changed, and the display
shows the new temperature. When energy-saving
mode is switched off, the last temperature
displayed is set.
Freshness mode
Food stays fresh for even longer with freshness
mode.
The appliance automatically sets the following
temperatures:
■ Refrigerator compartment: 36 °F (2 °C)
■ Cool-fresh compartment: 32 °F (0 °C)
The temperature in the freezer compartment remains
unchanged.
Vacation mode
If leaving the appliance for a long period, you can
switch it to energy-saving vacation mode.
The appliance automatically sets the following
temperatures:
■ Refrigerator compartment: 43 °F (6 °C)
■ Cool-fresh compartment: 40 °F (4 °C)
The temperature in the freezer compartment remains
unchanged.
Switching on vacation mode:
■ Press vacation button.
The temperature is changed, and the display
shows the new temperature.
Switching off vacation mode:
■ Press vacation button.
The last temperature displayed is set.
For hygiene reasons, dispense water for
5 minutes and discard.
Sabbath mode
All non-essential functions are switched off so you
can also use the appliance on the Sabbath.
The appliance switches off the following:
■ Super cooling and super freezing
■ Audible signals
■ Interior light
■ Messages on the control panel
■ Water dispenser
■ Ice maker
Note: Background illumination of display is reduced
in Sabbath mode.
Switching on Sabbath mode:
■ Press the vacation button for 10 seconds and
hold it until an audible signal sounds.
When Sabbath mode is switched on, the
alarm off display illuminates.
Switching Sabbath mode off:
■ Press the alarm off display for 5 seconds and
hold it until an audible signal sounds.
Note: After approx. 72 hours, the appliance
automatically returns to normal operation.
Switch freshness mode on or off:
■ Press the fresh button.
The temperature is changed, and the display
shows the new temperature. When freshness
mode is switched off, the recommended
temperature is set.
21
en-us Alarm
Setting the light
You can adjust the brightness levels of the interior
lighting from 0 ... 5:
Note:
0 = lighting off
1 = minimum brightness
5 = maximum brightness
1. Press the menu button.
2. Press the light settings button.
The submenu display shows In.
3. Press Y/X Settings button repeatedly until the
settings display shows the desired brightness
level.
4. Press the menu button.
The setting is saved.
Change filter alarm
The change filter alarm switches on every 6 months,
the change filter button lights up.
Switching off the change filter alarm:
1. Change water filter or replace with bypass filter.
~ "Water filter" on page 19
2. Press and hold the change filter button for
3 seconds.
The change filter alarm switches off, the change
filter button is no longer illuminated. The water
filter timer is reset automatically.
If you replace the water filter before 6 months, reset
the water filter timer manually:
Note:
1 = water filter timer running
0 = reset water filter timer
1. Press the menu button.
2. Press the change filter button.
3. Press Y/X Settings button until settings display
shows 0.
4. Press the menu button.
The setting is saved.
MAlarm
Al a r m
Door alarm
If the appliance door is left open for a while, a
warning sound is switched on and the alarm off
button flashes.
Switching off door alarm:
■ Close the door or press the alarm off button.
The warning sound is switched off and the
alarm off button no longer flashes.
You can switch the door alarm warning sound on or
off:
Note: On = switch on door alarm warning sound
OF = switch off door alarm warning sound
1. Press the menu button.
2. Press the alarm off button.
3. Press the Y/X Settings button until
settings display shows On or OF.
4. Press the menu button.
The setting is saved.
Temperature alarm
If the freezer compartment becomes too warm, the
warning sound switches on and the alarm off button
flashes.
9 CAUTION
DURING THE THAWING PROCESS, BACTERIA MAY DEVELOP AND SPOIL THE FROZEN ITEMS
Do not refreeze partly or completely thawed
food.
Refreeze food only after cooking. The frozen
items should no longer be stored for the
maximum storage period.
Note: The temperature alarm can be set off without
risk to the frozen food in the following situations:
■ The appliance is switching on.
■ If the freezer compartment door has been open
too long.
■ Large quantities of fresh food are being placed
inside.
22
Switching off the temperature alarm:
1. Check that the cause of the temperature alarm
has been eliminated.
2. Press the alarm off button.
The warning sound will be switched off and the
freezer compartment temperature display will
briefly indicate the warmest temperature reached
in the freezer compartment. Then the display
indicates the set temperature again. The warmest
temperature will be measured again and saved.
Note: The alarm off button remains lighted until the
set temperature has been reached again.
Home Connect en-us
o Home Connect
Home Connect
This appliance is Wi-Fi-capable and can be
controlled remotely using a mobile device.
Note: Wi-Fi is a registered trade mark of the Wi-Fi
Alliance.
In the following cases, the appliance functions like a
refrigerator without a network connection and can
still be operated manually via the controls:
■ The appliance is not connected to a home
network.
■ The availability of the Home Connect function
depends on the availability of Home Connect
services in your country. Home Connect services
are not available in every country. You can find
more information on www.home-connect.com.
Note: Please observe the safety information in this
instruction manual. Ensure that this is also observed
if you operate the appliance via the Home Connect
app and are not at home when doing so.
~ "Important safety instructions" on page 3
Follow the instructions in the Home Connect app as
well.
Setting up Home Connect
Notes
■ Take note of the Home Connect supplementary
sheet, which is available for download at http://
www.bosch-home.com together with the
instructions. To do so, enter the E-number of your
appliance in the search field.
■ After switching on the appliance, wait at least two
minutes until the internal device initialization
process has been completed. Only then start
setting up Home Connect.
■ To be able to make settings with Home Connect,
you need to install the Home Connect app on
your end device.
To do this, please take note of the documentation
that has also been supplied from Home Connect.
Follow the steps specified by the app to make the
settings.
■ If the device is not operated for a prolonged
period, the Home Connect menu will close
automatically. You can find information on how to
open the Home Connect menu at the start of the
appropriate chapter.
Automatic connection with the WLAN home network (Wi-Fi)
If a router with WPS function is available, the
refrigerator can be automatically connected to the
home network.
1. Press menu button.
The connect button lights up. The
submenu display shows Cn.
2. Press Y/X submenu button repeatedly until
submenu display shows AC and the
settings display OF.
3. Press Y Settings button.
The appliance is ready for automatic connection.
The settings display shows an animation for
2 minutes.
The appliance is ready for automatic connection
for as long as the animation is displayed.
4. Within those 2 minutes, activate the WPS function
on the home network router (e.g. using
WPS button, note the information in the router
documentation).
If the connection is successful, On flashes in the
settings display.
The refrigerator is ready to connect with the app.
Note: If the settings display shows OF, it was not
possible to establish a connection.
1. Check whether the refrigerator is located within
the range of the WLAN home network (Wi-Fi).
2. Repeat the process or establish the connection
manually.
Manual connection with the WLAN home network (Wi-Fi)
If the available router does not have a WPS function,
or or if this is unknown, you can connect the
refrigerator to the WLAN home network (Wi-Fi)
manually.
1. Press the menu button.
The connect button lights up. The
submenu display shows Cn.
2. Press the Y/X submenu button repeatedly until
submenu display shows SA and the
settings display OF.
3. Press the Y Settings button.
The appliance is ready for manual connection.
The settings display shows an animation.
The appliance is ready for manual connection for
as long as the animation is displayed.
4. The refrigerator has now set up its own WLAN
home network (Wi-Fi) with the network name
HomeConnect.
You can now access this network with your
mobile device.
5. Follow the instructions in the app until the
process is complete.
– If the connection is successful, On flashes in
the settings display.
The device connects automatically to the app.
– If the settings display shows OF, it was not
possible to establish a connection.
Check whether the refrigerator is located
within the range of the WLAN home network
(Wi-Fi).
Repeat the process.
Connecting the refrigerator to the Home Connect app
The appliance automatically connects to the app
with set-up for the first time after a connection to the
WLAN home network has been established (Wi-Fi).
23
en-us Home Connect
If the appliance does not automatically connect to
the app, connect the appliance manually:
1. Press the menu button.
The connect button lights up. The
submenu display shows Cn.
2. Press the Y/X submenu button repeatedly until
the submenu display shows PA and the settings
display OF.
3. Press Y Settings button to connect the
appliance to the app.
The settings display shows an animation.
As soon as the refrigerator and the app are
connected, the settings display shows On.
4. Open the app and wait until the refrigerator is
displayed.
Press Add to confirm the connection between the
app and the refrigerator.
If the refrigerator is not automatically displayed,
click on Add appliance in the app and follow the
instructions. As soon as your refrigerator is
displayed, add it with +.
5. Follow the instructions in the app until the
process is complete.
The submenu display shows PA and the
settings display On.
The refrigerator has been connected to the app.
If the connection fails, check whether the mobile
device is connected to the WLAN home
network (Wi-Fi).
Then try to establish the connection again.
If the settings display shows Er, reset the
Home Connect settings.
Note: On resetting, all Home Connect settings are
reset.
1. Press the menu button.
The connect button lights up. The
submenu display shows Cn.
2. Press the Y/X submenu button repeatedly until
submenu display shows rE and the
settings display OF.
3. Press Y/X Settings button.
The settings display shows an animation for
15 seconds.
The display then shows OF settings.
The Home Connect settings have been reset.
Installing updates for the Home Connect software
The refrigerator checks at regular intervals whether
updates are available for the Home
Connect software.
If an update is available, the submenu display shows
UP:
■ Confirm update in Home Connect app.
Do not switch the refrigerator off during updates.
The settings display shows an animation.The
update is being installed.
Note: All buttons are locked during installation.
■ If installation has been completed successfully,
the settings display shows On.
■ If installation has not been completed
successfully, the settings display shows Er.
Start the update again at a later time.
If installation could not be completed even after
multiple attempts, notify customer service.
Verifying signal strength
You should verify the signal strength if no connection
can be established.
1. Press the menu button.
The connect button lights up. The
submenu display shows Cn.
2. Press the Y/X submenu button repeatedly until
the submenu display shows SI.The
settings display shows a value between 0 (no
reception) and 3 (full reception).
The signal strength should be at least 2. If the
signal strength is too weak, the connection may
be interrupted.
– Place the router and refrigerator closer
together.
– Check that screening walls do not interfere
with the connection.
– Alternatively, install a repeater to make the
signal stronger.
Reset Home Connect settings
If there is a problem when trying to establish a
connection, or if you would like to register the
appliance on a different WLAN home network (Wi-Fi),
the Home Connect settings can be reset:
Press any button to reset the display to the set
temperature.
Information on data protection
The first time your Home Connect appliance is
registered on a WLAN home network connected to
the Internet (Wi-Fi), your appliance will transmit the
following types of data to the Home Connect server
(initial registration):
■ Unique appliance identification (consisting of
appliance codes as well as the MAC address of
the installed Wi-Fi communication module).
■ Security certificate of the Wi-Fi communication
module (to ensure a secure data connection).
■ The current software and hardware version of
your domestic appliance.
■ Status of any previous resetting to factory
settings.
This initial registration prepares the
Home Connect functions for use and is only required
when you want to use these
Home Connect functions for the first time.
Note: Please note that the Home Connect functions
can be utilized only in conjunction with the
Home Connect app. Information on data protection
can be called up in the Home Connect app.
24
Refrigerator compartment en-us
URefrigerator
compartment
Refr i ger at or compar t ment
The refrigerator compartment is suitable for storing
meat, sausages, fish, dairy products, eggs, ready
meals and pastries.
The temperature can be set from +33 °F (1 °C) ...
43 °F (6 °C).
The refrigerator compartment can also be used to
store highly perishable groceries in the short to
medium term. A temperature of +39°F (+4°C) or
lower ensures optimum freshness and hygiene of
the stored groceries.
Note when storing food
■ Store fresh, undamaged food.
The quality and freshness will then be retained for
longer.
■ In the case of convenience products and bottled
goods, do not exceed the minimum sell-by date
or use-by date specified by the manufacturer.
■ To retain aroma, color and freshness, pack
or cover food well before placing it into the
appliance.
This will prevent flavors being transferred
between foods and the plastic parts from
becoming discolored.
■ Leave warm food and drinks to cool down before
placing them into the refrigerator compartment.
TCool-fresh compartment
Coo l - f r e s h compar t ment
With cool-fresh storage, you can keep fresh
foodstuff fresh for up to three times longer than in
the refrigerator compartment – for even longer
freshness and nutrient retention, and consistent
flavor.
You can select pre-defined storage settings directly
using the cool-fresh compartment controls or adjust
the humidity and temperature from 29 °F
(–2 °C) ... 40 °F (4 °C) with the Home Connect app.
Cool-fresh bin
The storage climate in the cool-fresh bin offers ideal
conditions for storing fish, meat and sausage, as
well as fruit and vegetables.
Notes
■ Store food no higher than the bin rim to avoid
detaching the lid of the cool-fresh bin.
■ Never store fruit and vegetables in a cool-fresh
bin with meat or fish.
■ Fruit sensitive to cold (e.g. pineapple, banana,
papaya and citrus fruit), and vegetables sensitive
to cold (e.g. eggplants, cucumbers, zucchini,
peppers, tomatoes and potatoes) should be
stored outside the refrigerator at temperatures of
approx. 46 °F (8 °C) ... 54 °F (12 °C) for optimal
preservation of quality and flavor.
■ Condensation may form in the cool-fresh bin
depending on the type and quantity of food
stored.
Remove condensation with a dry cloth and adjust
the humidity in the cool-fresh bin with the controls
for cool-fresh compartment.
Storage recommendations
Set the pre-defined storage settings depending on
what and how much you are storing.
Note:
^ = low humidity
^^ = high humidity
Meat, fish and seafood 29°F ^ button
Fruit, mixed load with fruit and vegetables,
sausage, cheese and dairy products
Vegetables 32°F ^^ button
Beverages 34°F ^ button
Snacks/Miscellaneous 40°F ^ button
32°F ^ button
25
en-us Freezer compartment
WFreezer compartment
Freez er compar t ment
The freezer compartment is suitable for:
■ storing frozen food
■ making ice cubes
■ freezing food
The temperature can be set from 6 °F (–14 °C) ...
–7 °F (–22 °C).
The freezer compartment can be used to store
perishable foods long-term almost without any
noticeable reduction in quality, as the low
temperatures considerably slow down or stop
deterioration. Appearance, flavor and all valuable
ingredients are largely retained.
The time between putting fresh food in the freezer
compartment and it freezing solid depends on the
following factors:
■ temperature set
■ type of food
■ amount of food in the freezer compartment
■ quantity and type of storage
Observing drinking water quality
All materials used in the water dispenser are
odorless and tasteless.
If the water has an aftertaste, this may be due to the
following causes:
■ Mineral content and chlorine content of the
drinking water
■ Material of the water line leading to the appliance
■ Freshness of the drinking water
Notes
■ If you dispense water again after a long time, it
may taste stale. Allow water to dispense for
5 minutes and discard.
■ You will obtain optimum water quality if you
dispense some water regularly.
Dispensing water
9 CAUTION
To avoid water damage to the floor or to the
appliance, never dispense water without a glass
underneath.
VWater dispenser
You can dispense cold water using the water
dispenser.
Note: The water dispenser will only work when the
appliance is connected to a drinking water supply
and a filter is installed.
Before using the appliance for the first time
■ Once the refrigerator has been connected or a
new water filter has been installed, there will be
air in the water circuit. Keep dispensing water
until it contains no more bubbles. Wipe splashes
dry with a soft cloth.
■ For hygiene reasons, dispense water for
5 minutes and discard.
Notes
■ To avoid water damage, the function
automatically stops after 30 seconds of
continuous water dispensing.If you want to
dispense more water, wait 5 seconds.
■ You can dispense water up to five times in
succession, after which the function stops
automatically.If you want to dispense more water,
wait 2 minutes.
■ The dispensed water is cooled to a palatable
temperature. To obtain a colder drinking
temperature, put additional ice cubes in the
glass.
■ The water may become warmer when dispensing
large amounts of water.
1. Hold the glass under the water dispenser.
2. Push the glass upwards against the dispenser
lever or press è button until the glass contains
the amount of water required.
26
Defrosting en-us
;Ice maker
The ice maker produces ice cubes.
Note: The ice maker will only work when the
appliance is connected to a drinking water supply
and a filter is installed.
Before using the appliance for the first time
■ Switch on ice cube production.
As soon as the freezer compartment reaches the
set temperature, the first batch of ice cubes will
be ready in approximately 4 hours.
■ For hygiene reasons discard the ice produced
within the first 24 hours.
Switching ice cube production on or off
9 WARNING
RISK OF INJURY!
Never reach under or into the ice maker.
Notes
■ Once ready, ice cubes are automatically
discharged into the ice cube bin.
■ Ice cube production stops automatically when the
maximum filling level of the ice cube bin is
reached.
■ You can accelerate ice cube production by
setting a colder freezer compartment temperature
or switching on super freezing. This will slightly
increase energy consumption.
■ If ice cubes taste stale, discard the rest and the
cubes produced over the next 24 hours. If ice
cubes still taste stale, change the water filter.
9 CAUTION
Damage to the appliance!
Never store bottles or food in the ice cube bin
when ice cube production is switched on. This
may block and damage the ice maker.
1. Open the freezer drawer up to the stop.
2. Move up the ice maker flap to open.
3. Press " button for the ice maker.
If ice cube production is switched on, the button
lights up.
4. Close the ice maker flap and freezer
compartment drawer.
=Defrosting
Def r o s t i n g
The fully automatic NoFrost system ensures that the
appliance remains frost-free. Defrosting is not
required.
27
en-us Cleaning
DCleaning
Cleani ng
9 CAUTION
AVOID DAMAGING THE APPLIANCE AND THE EQUIPMENT.
■ Do not use abrasive, chloride-based or acidic
cleaning agents or solvents.
■ Do not use stainless steel cleanser for the
outside of the appliance.
■ Do not use scouring or abrasive sponges.
The metallic surfaces may corrode.
■ Never clean the shelves or bins in the
dishwasher.
The parts may become deformed.
Cleaning the appliance interior
Proceed as follows:
1. Press ÿ power button.
2. Take out food and store in a cool location.
Place ice pack (if available) on the food.
3. Clean the appliance with a soft cloth, lukewarm
water and a little pH-neutral washing-up liquid.
Glass plate partition
Remove the glass plate:
1. Reach into the back of the recess, lift the glass
plate and push right back.
2. Reach into the front of the recess, lift the glass
plate at the front and remove.
9 CAUTION
The rinsing water must not run into the light.
4. Wipe door seal with clean water and dry
thoroughly with a cloth.
5. Switch appliance back on and put in food.
Cleaning the fittings
To clean, take the variable parts out of the
appliance.
~ "Equipment" on page 16
Install the glass plate:
■ Place the glass plate on the partition and push
right to the front.
28
Cleaning en-us
Cool-fresh bin cover
Remove the cover:
1. Open the refrigerator compartment doors and
take out the cool-fresh bin.
2. In the cool-fresh compartment, lift the upper cover
at the front and remove.
Install the cover:
1. Slide the cover symmetrically backwards in the
cool-fresh compartment at the top and hook into
place.
2. Push the cover up and engage.
Telescopic rails
Removing telescopic rails
1. Pull out telescopic rail.
2. Push lock in the direction of the arrow.
3. Detach telescopic rail from the rear pin.
4. Push telescopic rail together, push backwards
above the rear pin, and disengage.
Installing telescopic rails
1. Place the extended telescopic rail on the front
pin.
2. Pull the telescopic rail forwards slightly until it
engages.
3. Insert telescopic rail on the rear pin.
4. Push lock backwards.
4
4
29
en-us Odors
lOdors
Odors
If you notice any unpleasant odors:
1. Switch off the appliance with the on/off ÿ power
button.
2. Take all food out of the appliance.
3. Clean the inside.
4. Clean all packaging.
5. Seal strong-smelling food in order to prevent
odors from forming.
6. Switch the appliance on again.
7. Arrange food in the appliance.
8. After 24 hours, check whether odors are building
up again.
9Lighting
Li ght i ng
Your appliance features a maintenance-free LED
light.
Only customer service or authorized technicians may
repair the light.
>Noises
Noi s e s
Normal noises
Droning: A motor is running, e.g. refrigerating unit,
ventilator, water valve is venting.
Bubbling, buzzing or gurgling: Refrigerant is
flowing through the tubes.
Clicking: Motor, switch, solenoid valves or water
valve are switching on or off.
Cracking: Automatic defrosting is running.
Preventing noises
Appliance is not level: Align appliance using a level.
Adjust the height of the height-adjustable feet.
The appliance is not "free-standing": please move
the appliance away from adjacent furniture or
appliances.
Bins, shelves or storage compartments wobble or
stick: Check the removable fittings and re-insert if
required.
Bottles or receptacles are touching each other:
Move bottles or receptacles away from each other.
30
Loading...
