Bosch AN, 5000 User Manual

FLEXIDOME 5000 AN

VDN-5085

en Installation Manual

FLEXIDOME 5000 AN Table of Contents | en 3

Table of Contents

1Safety 5

1.1 Safety precautions 5

1.2 Important safety instructions 6

1.3 Connection in outdoor applications 7

1.3.1 Safety precautions 7

1.4 Important notices 8

1.5 FCC information 9

1.6 UL certification 10

1.7 Bosch notice 10

2 Introduction 11

2.1 Features 11

3 Installation 12

3.1 Unpacking 12

3.2 Disassembly 13

3.3 Mounting the unit 14

3.3.1 Mounting tips 15

3.3.2 Flush mounting 15

3.3.3 Surface mounting 16

4 Connection and set-up 19

4.1 Power and video connections 19

4.2 Setting up the camera 20

4.2.1 Camera positioning 20

4.2.2 Menu navigation 21

4.2.3 Focal length and focus 23

4.2.4 Heater 23

4.2.5 Closing the unit 24

5 Configuration 25

5.1 Menus 25

5.1.1 Top level menus 25

5.1.2 Menu navigation 26

5.2 Pre-defined modes 27

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

4 en | Table of Contents FLEXIDOME 5000 AN

5.3 Day/Night switching 28

5.4 Camera control communication (Bilinx) 28

5.5 Main menu structure 29

5.5.1 Mode submenu 29

5.5.2 Exposure submenu 30

5.5.3 Day/Night submenu 32

5.5.4 Enhance / Dynamic Engine submenu 34

5.5.5 Color submenu 36

5.5.6 VMD submenu 37

5.5.7 Image Adjustment submenu 38

5.6 Install menu structure 39

5.6.1 Language submenu 40

5.6.2 Lens Wizard submenu 40

5.6.3 Synchronization submenu 41

5.6.4 Connections submenu 41

5.6.5 Test signal submenu 42

5.6.6 Camera ID submenu 42

5.6.7 Privacy masking submenu 44

5.6.8 Flip submenu 44

5.6.9 Defaults submenu 45

6Troubleshooting 46

6.1 Resolving problems 46

6.2 Customer service 47

7 Maintenance 48

7.1 Repairs 48

7.1.1 Transfer and disposal 48

8 Technical Data 49

8.1 Specifications 49

8.1.1 Dimensions 51

8.1.2 Accessories 53

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Safety | en 5

1Safety

1.1 Safety precautions

DANGER!

High risk: This symbol indicates an imminently hazardous
situation such as "Dangerous Voltage" inside the product.
If not avoided, this will result in an electrical shock, serious
bodily injury, or death.

WARNING!

Medium risk: Indicates a potentially hazardous situation.
If not avoided, this could result in minor or moderate bodily
injury.

CAUTION!

Low risk: Indicates a potentially hazardous situation.
If not avoided, this could result in property damage or risk of
damage to the unit.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

6 en | Safety FLEXIDOME 5000 AN

1.2 Important safety instructions

Read, follow, and retain for future reference all of the following
safety instructions. Heed all warnings on the unit and in the
operating instructions before operating the unit.

1. Cleaning - Generally, using a dry cloth for cleaning is
sufficient but a moist, fluff-free cloth or leather shammy
may also be used. Do not use liquid cleaners or aerosol
cleaners.

2. Heat Sources - Do not install the unit near any heat
sources such as radiators, heaters, stoves, or other
equipment (including amplifiers) that produce heat.

3. Water - Never spill liquid of any kind on the unit.

4. Lightning - Take precautions to protect the unit from
power and lightning surges.

5. Controls adjustment - Adjust only those controls specified
in the operating instructions. Improper adjustment of
other controls may cause damage to the unit.

6. Power sources - Operate the unit only from the type of
power source indicated on the label.

7. Servicing - Unless qualified, do not attempt to service this
unit yourself. Refer all servicing to qualified service
personnel.

8. Replacement parts - Use only replacement parts specified
by the manufacturer.

9. Installation - Install in accordance with the manufacturer's
instructions and in accordance with applicable local codes.

10. Attachments, changes or modifications - Only use
attachments/accessories specified by the manufacturer.
Any change or modification of the equipment, not
expressly approved by Bosch, could void the warranty or,
in the case of an authorization agreement, authority to
operate the equipment.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Safety | en 7

1.3 Connection in outdoor applications

1.3.1 Safety precautions

Coax grounding: If an outside cable system is connected to the

unit, ensure that the system is grounded.

U.S.A. models only: Section 810 of the National Electrical Code,
ANSI/NFPA No.70, provides information regarding proper

grounding of the mount and supporting structure, grounding of
the coax to a discharge unit, size of grounding conductors,
location of discharge unit, connection to ground electrodes,
and requirements for the grounding electrode.
Power lines: An outdoor system should not be located in the
vicinity of overhead power lines, electrical lights, or power
circuits, or where it may contact such power lines or circuits.
When installing an outdoor system, extreme care should be
taken to keep from touching power lines or circuits, as this
contact may be fatal. U.S.A. models only - refer to the National
Electrical Code Article 820 regarding installation of CATV
systems.
12 VDC/24 VAC power source: This unit is intended to operate
with a limited power source, this power source must comply
with EN60950. User supplied wiring, from 12 VDC/24 VAC
supply to unit, must be in compliance with electrical codes
(Class 2 power levels). Do not ground the 12 VDC/24 VAC
supply at the terminals or at the unit's power supply terminals.
Connection: The unit has connection terminals on flying leads.
In wet or outdoor installations make use of the VDA-455SMB
accessory or use a field wiring box with Nema 4 or IP66
protection level or better. Make the connections inside the
water tight compartment. After connections are made ensure
that the watertight compartment is tightly closed and cables
and conduits are properly sealed to prevent ingress of water.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

8 en | Safety FLEXIDOME 5000 AN

1.4 Important notices

Disposal - Your Bosch product was developed and

manufactured with high-quality material and components that
can be recycled and reused. This symbol means that
electronic and electrical appliances, which have reached the
end of their working life, must be collected and disposed of
separately from household waste material. Separate collecting
systems are usually in place for disused electronic and
electrical products. Please dispose of these units at an
environmentally compatible recycling facility, per European

Directive 2002/96/EC

CAUTION!

The Low Voltage power supply unit must comply with EN/UL

60950. The power supply must be a SELV-LPS unit or a SELV -

Class 2 unit (Safety Extra Low Voltage - Limited Power Source).

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Safety | en 9

1.5 FCC information

FCC & ICES Information

(U.S.A. and Canadian Models Only)

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
– reorient or relocate the receiving antenna;
– increase the separation between the equipment and

receiver;

– connect the equipment into an outlet on a circuit different

from that to which the receiver is connected;

– consult the dealer or an experienced radio/TV technician

for help.
Intentional or unintentional modifications, not expressly
approved by the party responsible for compliance, shall not be
made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult
the dealer or an experienced radio/television technician for
corrective action.
The user may find the following booklet, prepared by the
Federal Communications Commission, helpful: How to Identify
and Resolve Radio-TV Interference Problems. This booklet is
available from the U.S. Government Printing Office,
Washington, DC 20402, Stock No. 004-000-00345-4.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

10 en | Safety FLEXIDOME 5000 AN

1.6 UL certification

Disclaimer

Underwriter Laboratories Inc. ("UL") has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UL's Standard(s) for Safety for Information
Technology Equipment, UL 60950-1. UL Certification does not
cover the performance or reliability of the security or signaling
aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR
CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR
SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT.

1.7 Bosch notice

More information

For more information please contact the nearest Bosch Security
Systems location or visit www.boschsecurity.com

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Introduction | en 11

2 Introduction

2.1 Features

The FLEXIDOME 5000 Day/Night WDR camera is a small,
discreet, surveillance dome containing a high-performance
camera with integral varifocal lens. It uses a wide dynamic
range 960H CCD sensor for outstanding picture performance.
This surveillence dome can be mounted to an electrical box, to
a wall, to a ceiling or in a corner. The sturdy construction and
the high impact-resistant polycarbon dome protect the camera
module from damage.
The camera is easy to install and ready to use, and offers the
best solution for demanding scene conditions. Features
include:
– 1/3-inch 960H CCD sensor with wide dynamic range
– True Day/Night performance with switchable IR filter
– 720TVL sensor resolution
– High Dynamic Range
– Indoor and outdoor use
– IP66 and NEMA 4X compliant
– High-impact, vandal resistant (IK10)
– Privacy zones
– Detail enhancement
– Bilinx (bi-directional coaxial communication)
– Wide operating temperature range
–Lens wizard
– Six pre-programmed operation modes
– Dynamic noise reduction
– Multiple language on-screen display
– Built-in test pattern generator

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

12 en | Installation FLEXIDOME 5000 AN

3 Installation

3.1 Unpacking

Unpack carefully and handle the equipment with care.
The packaging contains:
– FLEXIDOME 5000 camera
– Important safety instructions
– Quick install instructions
– CD-ROM

– Installation instructions
– Adobe Acrobat Reader

– Plastic bag with mounting hardware (three SX8 4.5-6 mm

mounting plugs and three matching mounting screws), and
special screwdriver bit for tamper-resistant screws

– Plastic bag with two black rubber grommets for surface

mount box
– Lens adjustment cap
If equipment has been damaged during shipment, repack it in
the original packaging and notify the shipping agent or supplier.

WARNING!

Installation should only be performed by qualified service
personnel in accordance with the National Electrical Code
NEC800 (CEC Section 60) or applicable local codes.

CAUTION!

The camera module is a sensitive device and must be handled
carefully.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Installation | en 13

3.2 Disassembly

The flush-mount version consists of the following parts:

Camera module and mounting base

Inner liner (with sealing ring)

Trim ring

Dome

Figure 3.1 Flush-mount

The surface-mount version consists of the following parts:

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

14 en | Installation FLEXIDOME 5000 AN

Surface mounting box

Camera module and mounting base

Inner liner (with sealing ring)

Trim ring

Dome

Figure 3.2 Surface-mount

To disassemble the unit proceed as follows:

1. Use the special screwdriver bit to loosen the three tamper-

resistant screws in the trim ring (the screws remain in

place).

2. Remove the trim ring and dome by pulling them from the

base.

3. Remove the inner liner (with sealing ring) by pulling it off

of the base.

4. Remove the pink protective foam.

3.3 Mounting the unit

There are several ways to mount the unit. The method of
mounting depends on the type of surface and whether other
mounting hardware, such as an electrical box, a surface box or
other accessories are used.

Note:

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Installation | en 15

If the unit is to be surface mounted, then use the Surface Mount
Box (SMB). The SMB is sold as a separate item (VDA-455SMB)
or is included with the unit with the surface mount option.
Other mounting accessories are also sold separately.

3.3.1 Mounting tips

– Use the mounting hole template to assist in marking the

correct position for the camera to be mounted.

– Refer to the dimensions on the mounting hole template to

find the exact position of the screw holes and the entry
hole for the cables.

– Partially screw in two screws for the keyholes and use

them to temporarily hang the camera while the
connections are made.

3.3.2 Flush mounting

Figure?3.3?Flush mounting - hollow surface

1. Solid surface (pre-drill three 8mm holes and fit supplied
plugs)

2. Three screws (supplied with camera)

3. Integrated camera unit and base

4. Cables

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

16 en | Installation FLEXIDOME 5000 AN

Figure?3.4?Flush mounting - electrical box (4S)

1. Two screws (not supplied)

2. Integrated camera unit and base

3. 4S electrical box

3.3.3 Surface mounting

When using the surface mounting box:
– With a side connection, remove the cap covering the side

entrance.

With a rear connection, leave the cap in place.
– Attach the conduit to the mounting box.
– Release the two clips at the bottom of the watertight

connection compartment to remove it from the mounting

box.
– Open the cover of the watertight compartment in the

mounting box by releasing the five clips.
– Run the power and video cables through separate rubber

grommets into the watertight compartment.
– Run the cable from the camera into the watertight

compartment through the supplied grommet.
– Make the connection inside the watertight compartment

and clip on the cover to seal it.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Installation | en 17

Figure 3.5 Surface mounting box VDA-455SMB

Note:

To ensure a watertight cable entry, use round cables of
between 5 and 6 mm (0.2 - 0.24 inches) for power and video
connection.

Note:

Use some silicon spray on the cable to help slide the grommets
onto it.

Figure?3.6?Surface mounting - side connection

1. Solid surface (pre-drill three 8mm holes and fit supplied
plugs)

2. Three screws (supplied with camera)

3. Three screws (M5, supplied)

4. Integrated camera unit and base

5. Surface mounting box (VDA-455SMB)

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

18 en | Installation FLEXIDOME 5000 AN

6. Cables

7. Conduit

Figure?3.7?Surface mounting - rear connection

1. Solid surface (three pre-drilled 8mm holes and fit supplied
plugs)

2. Three screws (supplied with camera)

3. Three screws (M5, supplied)

4. Integrated camera unit and base

5 Surface mounting box (VDA-455SMB)

6. Cap (remove for side-entry cables)

7. Conduit

8. Cables

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Connection and set-up | en 19

4 Connection and set-up

4.1 Power and video connections

The wiring harness has a BNC connector to accept the video
coax cable (with male BNC connector) and two stripped low
voltage power wires for connection to a power connector. A
UTP adapter (VDA-455UTP) is available as an optional accessory
to allow a UTP video cable to be connected to the BNC
connector.
The easiest way to connect the cables is as follows:

1. Bring the building connections through the surface cable
hole so that they hang clear.

2. Partially insert two screws into the pre-drilled holes (or
adapter plate).

3. Using one of the keyholes, hang the mounting base of the
camera module on one screw temporarily; tilt the base
slightly to gain access to the cable connections.

4. Connect the BNC connector of the camera module to the
video coax cable.

5. Connect the stripped power wires (red +, brown –) to the
power supply connector.

Note

For a DC supply the polarity is important. Incorrect polarity
does not damage the camera but it will not switch on.

6. In damp environments ensure that the connections are
sealed. (The surface mounting box and the other mounting
accessories have a sealed compartment for this purpose.)

7. Push the connections back through the surface cable hole.

8. Secure the mounting base of the camera module to the
surface with three screws.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

20 en | Connection and set-up FLEXIDOME 5000 AN

4.2 Setting up the camera

4.2.1 Camera positioning

CAUTION!

The Heater will be hot when in operation - Do not touch.Always
switch the heater off when working on the camera, refer to

Section 4.2.4 Heater, page 23 and Section 5.6.4 Connections
submenu, page 41.

To assist in setting up the camera, connect a monitor to the
miniature 2.5 mm jack socket (2). This socket provides a
composite video signal (with sync). An optional cable (code
number S1460) is available for making this connection. When
the S1460 cable is attached, there is no video available on the
BNC connector to avoid interference.

A

C

B

Figure 4.1 Camera parts

1. Heater

2. Monitor jack socket

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Connection and set-up | en 21

3. Thumbwheels

4. Navigation buttons (5)

5. Focal length

6. Focus
A. Pan-axis rotation
B. Tilt-axis rotation
C. Twist-axis rotation

The physical default position of the camera is that the top of
the image corresponds to the indication TOP.

CAUTION!

CCD image sensors are highly sensitive and require special care
for proper performance and extended lifetime. Do not expose
them to direct sunlight or bright spotlights in operating and
non-operating conditions. Avoid bright lights in the field of view
of the camera.

The camera module position can be adjusted along three axes.
When adjusting the camera position, ensure that the picture
display on the monitor is level. Set the camera to the desired
position by performing the following steps:
– For horizontal adjustment along the pan axis (A), rotate the

camera module in the base. Do not rotate more than 360°.

– To obtain a horizontal horizon (for tilted ceilings or

sidewall mounting), rotate the base of the lens along the
twist axis (C) to align the picture shown on the monitor.
Do not rotate more than 340°.

– For vertical adjustment along the tilt axis (B), loosen

thumbwheels, position camera, then gently tighten
thumbwheels to secure camera. Do not rotate more than
90°.

4.2.2 Menu navigation

Five keys, located on the side panel, are used for navigating
through the menu system.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

22 en | Connection and set-up FLEXIDOME 5000 AN

Up key
Menu/Select key (center)

Right key

Down key

Figure 4.2 Navigation

Left key

– Press the menu/select (center) key to access the menus or

to move to the next or previous menu.

– Press the menu/select key for approximately 2 seconds to

open the Install menu.
– Use the up or down keys to scroll through a menu.
– Use the left or right keys to move through options or to set

parameters.
– When in a menu, quickly double-press the menu/select key

to restore the selected item to its factory default.
– To close all menus at once from any menu, select the Exit

item and hold down the menu/select key until the menu

display disappears.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Connection and set-up | en 23

4.2.3 Focal length and focus

Before adjusting the focal length or focus, place the lens
adjustment cap on the lens to ensure that the image sharpness
is the same as when the dome is in place.

1. Connect a monitor or other display device to either the
camera’s BNC connector or to the optional cable (S1460)
on the monitor jack. (If S1460 is connected, there is no
signal on the BNC connector.)

2. Press and hold the menu/select (center) button until the
Install menu appears.
– The Set focus item is highlighted. Do not change this

selection as the camera is now in a special mode for
adjusting focus.

3. To set the field of view of the varifocal lens, loosen the
focal length screw and turn the mechanism until the
required view is displayed on the monitor. (Image goes out
of focus.)

4. Focus the image on the monitor by loosening the focus
screw and turning the mechanism until the image is in
focus.

5. Re-adjust the focal length if necessary.

6. Repeat these two adjustments until the desired view is in
focus.

7. Tighten both screws.

8. Use the navigation buttons to move to Exit and press the
center button until the menu disappears.

9. Remove the lens adjustment cap from the lens and
disconnect the monitor.

4.2.4 Heater

When using the camera at low temperatures, set the heater
setting to Auto in the Install menu. The heater turns on at
ambient temperatures below 0°C (+32°F).

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

24 en | Connection and set-up FLEXIDOME 5000 AN

4.2.5 Closing the unit

When the camera position is set and all adjustments have been
made, close the unit.

1. Place the inner liner (with attached sealing ring) in
position, aligning its fin with the bracket on the base.

2. Place the dome onto the base and rotate until it clips into
place. (If necessary clean its surface with a soft cloth.)

3. Place the trim ring over the dome.

4. Align the tamper-resistant screws in the trim ring with the
threaded ends in the mounting base.

5. Use the special screwdriver bit supplied to tighten the
three tamper-resistant screws.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 25

5 Configuration

The camera normally provides an optimal picture without the
need for further adjustments. Advanced set-up options are
available in a menu system for getting the best results under
special circumstances.
The camera implements your changes immediately so that
before and after settings are easily compared.

5.1 Menus

5.1.1 Top level menus

There are two upper level menus: a Main menu and an Install
menu. The menus have functions that can be selected directly
or submenus for more detailed set-up.
– To access the Main menu, press the menu/select button

(center) for less than 1 second. The Main menu appears on
the monitor. The Main menu allows you to select and set­up the picture enhancement functions. If you are not happy
with your changes, you can always recall the default values
for the mode.

– The camera also has an Install menu in which the

installation settings can be set. To access the Install menu,
press the menu/select button (center) for longer than 2
seconds.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

26 en | Configuration FLEXIDOME 5000 AN

5.1.2 Menu navigation

Five keys are used for navigating through menu system.

Up button
Menu/Select button (center)

Right button

Down button
Left button

– Use the up or down keys to scroll through a menu.
– Use the left or right keys to move through options or to set

parameters.

– When in a menu, quickly double-press the menu/select key

to restore the selected item to its factory default.

– To close all menus at once hold down the menu/select key

until the menu display disappears or continually select the
Exit item.

Some menus automatically close after about two minutes; other
menus have to be closed manually.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 27

5.2 Pre-defined modes

There are six pre-defined modes with settings to make
configuration easier. You can select one of the six pre-defined
modes in the Install/Mode submenu. The modes are defined as
follows;

1. 24-hour
Default installation mode to provide stable pictures over a
24-hour period. These settings are optimized for out-of­the-box installation.

2. Traffic
Capture high-speed objects using default shutter in
variable lighting conditions.

3. Low light
Provide extra enhancement, such as AGC and SensUp to
make usable pictures in low-light conditions.

4. Smart BLC
Settings optimized to capture details in high contrast and
extremely bright-dark conditions.

5. Low noise
Enhancements are set to reduce picture noise. Useful for
conditional refresh DVR and IP storage systems because
reducing noise reduces the amount of storage required.

6. Vibrant
This mode has enhanced contrast, sharpness and
saturation.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

28 en | Configuration FLEXIDOME 5000 AN

5.3 Day/Night switching

The camera is equipped with a motorized IR filter. The
mechanical IR filter can be removed in low-light or IR
illuminated applications by software configuration settings.
If Auto switching mode is selected, the camera automatically
switches the filter depending on the observed light level. The
switching level is programmable. In Auto switching mode the
camera prioritizes motion (the camera gives sharp images
without motion blur as long as the light level permits) or color
(the camera gives color pictures as long as the light level
permits). The camera recognizes IR illuminated scenes to
prevent unwanted switching to color mode.
There are four different methods of controlling the IR filter:
– via Bilinx communication,
– automatically, based on the observed light levels, or
– as part of the programmable mode profile.

5.4 Camera control communication (Bilinx)

This camera is equipped with a coaxial communications
transceiver (also referred to as Bilinx). In combination with VP­CFGSFT, the camera setting can be changed from any point
along the coaxial cable. All menus can be accessed remotely
giving full control of the camera. With this method of
communication it is also possible to disable the local keys on
the camera.To avoid loss of communication on an installed
camera, the Communication On/Off selection is not available
while using remote control. This function can only be accessed
with the camera buttons. Bilinx communications can only be
disabled using the buttons on the camera.

Disabled camera buttons

When the Bilinx communications link is active, the buttons on
the camera are disabled.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 29

5.5 Main menu structure

Item Selection Description

Mode Submenu Sets up operating modes 1 to 6

Exposure Submenu Exposure control

Day/Night Submenu Day/Night for color/mono operation

Enhance Submenu Picture enhancement and performance

Color Submenu White balance and color rendition

VMD Submenu Video motion detection

Adjustment

Submenu Sets up digital zoom or digital image

stabilization

5.5.1 Mode submenu

Item Selection Description

Mode 1 to 6 Selects operating mode.

Mode ID Alphanumeric Mode name (11 characters maximum)

Copy active
mode

Mode
Defaults

EXIT Returns to main menu.

Available
mode
numbers

Submenu Restores camera to the factory default

Copies current mode settings to the
mode number selected.

settings.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

30 en | Configuration FLEXIDOME 5000 AN

5.5.2 Exposure submenu

Item Selection Description

ALC level -15 to +15 Selects the video level range. A

positive value is more useful for low­light conditions; a negative value is
more useful for very bright
conditions.
Some ALC adjustment may improve
scene content when Smart BLC is
enabled.

ALC speed Slow, medium,

fast

Adjusts the speed of the video level
control loop. For most scenes it
should remain at the default value.

Shutter AES, FL, Fixed AES (auto-shutter) - the camera

automatically sets the optimum
shutter speed.
FL - flickerless mode avoids
interference from light sources
(recommended for DC-iris lenses
only).
FIXED - allows a user defined shutter
speed.

Default (AES)
shutter
or
Fixed shutter

1/50 (PAL)
1/60 (NTSC),
1/100 (PAL)
1/120 (NTSC),
1/250,
1/500,

In DEFAULT (AES) mode, the camera
tries to maintain the selected
shutter speed as long as the light
level of the scene is high enough.
In Fixed mode, selects shutter

speed.
1/1000,
1/2000,
1/4000,
1/10K,
1/100K

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 31

Item Selection Description

Actual shutter Displays the actual shutter value

from the camera to help compare
lighting levels and optimum shutter
speed during set-up.

Gain control On, Fixed On - the camera automatically sets

the gain to the lowest possible value
needed to maintain a good picture.
Fixed - sets Fixed AGC value.

Maximum AGC
or
Fixed AGC

0 to 40 dB Selects the maximum value the gain

can have during AGC operation.
Selects the gain setting for Fixed
gain operation (0 is no gain).

Actual AGC Displays the actual AGC value from

the camera to help compare gain
level with lighting levels and picture
performance.

Sens Up
Dynamic

Off, 2x,
3x, …, 10x

Selects the factor by which the
sensitivity of the camera is
increased.
When active, some noise or spots
may appear in the picture. This is
normal camera behavior. It may also
cause motion blur on moving
objects.

EXIT Returns to main menu.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

32 en | Configuration FLEXIDOME 5000 AN

5.5.3 Day/Night submenu

Item Selection Description

Day/Night Auto, Color,

Monochrome

Auto - the camera switches the IR cut­off filter on and off depending on the
scene illumination level.
Color - the camera always produces a
color signal regardless of light levels.
Monochrome - the IR cut-off filter is
removed, giving full IR sensitivity.

Switch level -15 to +15 Sets the video level in Auto mode at

which the camera switches to
monochrome operation.
A low (negative) value means that the
camera switches to monochrome at a
lower light level. A high (positive) value
means that the camera switches to
monochrome at a higher light level.

Switch delay 1, 2, 3, 5, 10,

20, 30, 60,

Sets the evaluation time in Auto mode
for day to night transitions.

120, 240 s

Priority Motion, Color In AUTO mode:

Color - the camera gives a color image
as long as the light level permits.
Motion - the camera avoids motion blur
as long as the light level permits (it
switches to monochrome earlier than it
would with Color priority).

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 33

Item Selection Description

IR contrast
(mono)

Enhanced,
Normal

Enhanced - the camera optimizes
contrast in applications with high IR
illumination levels. Select this mode
for IR (730 to 940 nm) light sources
and for scenes with grass and green
foliage.
Normal - the camera optimizes contrast
in mono applications with visible light
illumination.

IR
illumination
(mono)

0 to +15 Enter the strength of the external IR

illumination to determine the night to
day transition moment. 0 is no IR
illuminator; +15 is very strong
illumination.

Color burst
(mono)

On, Off Off - the color burst in the video signal

is switched Off in monochrome mode.
On - the color burst remains active
even in monochrome mode (required
by some DVRs and IP encoders).

EXIT Returns to main menu.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

34 en | Configuration FLEXIDOME 5000 AN

5.5.4 Enhance / Dynamic Engine submenu

Item Selection Description

Dynamic
Engine

Contrast
Enhancement

Off,
XF DYNAMIC,
HDR,
Smart BLC

Low,
Medium,
High

Off: - turns off all automatic scene
detail and enhancements (only
recommended for testing).
XF DYNAMIC: - extra internal
processing is enabled for enhancing
the visibilty.
HDR: - adds dual sensor exposure to
the XF DYNAMIC features. In harsh
lighting conditions, pixels from each
exposure are mixed to give a more
detailed image.
Smart BLC: - BLC window and
weighting factor are automatically
defined. Camera dynamically adjusts
these for changing light conditions.

Increases the contrast at medium
brightness levels.
Select Low for high contrast scenes.
Select High for low contrast scenes
(e.g. fog).

Sharpness -15 to +15 Adjusts the sharpness of the picture. 0

corresponds to the default position.
A low (negative) value makes the
picture less sharp. Increasing
sharpness brings out more detail.
Extra sharpness can enhance the
details of license plates, facial features
and the edges of certain surfaces.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 35

Item Selection Description

3D-NR Off,

Low,
Medium,
High

2D-NR Off,

Low,
Medium,
High

Peak White

On, Off Use Peak White Invert to reduce glare

Invert

Automatically reduces the noise in the
picture.
This may cause some motion blur on
exceptionally fast moving objects
immediately in front of the camera.
This can be corrected by widening the
field of view or lowering the selection
value.

Automatically reduces the noise in the
picture.
A high selection may cause blur.
A lower selection improves sharpness
at the cost of more noise

from the CRT/LCD display.
Use in ANPR/LPR applications to
reduce headlight glare.
(Test on-site to ensure that it does
benefit the application and is not
distracting for operators of the security
system.)

EXIT Returns to main menu.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

36 en | Configuration FLEXIDOME 5000 AN

5.5.5 Color submenu

Item Selection Description

White balance ATW indoor,

ATW Outdoor,
ATW hold,
Manual

ATW - Auto tracking white balance
allows the camera to constantly
adjust for optimal color
reproduction.
ATW hold - Puts the ATW on hold and
saves the color settings.
Manual - the Red and Blue gain can
be manually set to a desired position.

Speed Fast,

Medium,

Adjusts the speed of the white
balance control loop.

Slow

Red gain -50 to +50 Manual and ATW hold - adjusts the

Red gain.

Blue gain -50 to +50 Manual and ATW hold - adjusts the

Blue gain.

Saturation -15 to +5 Adjusts the color saturation. -15

gives a monochrome image; 0 gives
the default saturation; +15 gives the
most saturation.

EXIT Returns to main menu.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 37

5.5.6 VMD submenu

Item Selection Description

VMD area Submenu Select 1 of the 4 areas to enter the

area set-up menu to define the
detection area.

VMD mode Off, Silent,

OSD

Off - Video Motion Detection (VMD) is
off.
Silent - video motion generates silent
alarm.
OSD - video motion generates on­screen text message alarm.

VMD
sensitivity

0 to 127 Sets the sensitivity for motion to the

desired level. The longer the white bar,
the more motion is required to acitvate
the VMD alarm. Motion above this level
activates alarm.

OSD alarm
text

Alphanumeric Text for on-screen display alarm (16

characters maximum).

EXIT Returns to main menu.

Selecting an area for VMD masking

To set-up an area for VMD masking, access the area menu by
selecting the VMD Area option from the VMD menu. Upon
entering the Area menu, the current area is displayed with the
upper left corner flashing. The flashing corner of the image can
be moved with the Up, Down, Left, Right arrow keys. Pressing
the Select key moves the flashing cursor to the opposite corner,
which can now be moved. Pressing Select again freezes the
area and exits the area menu.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

38 en | Configuration FLEXIDOME 5000 AN

5.5.7 Image Adjustment submenu

Item Selection Description

Digital Zoom x1, x2, x4, x8,

Select the zoom factor

x16

DIS Off, On Select On to stabilize the image.

EXIT Returns to main menu.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 39

5.6 Install menu structure

Item Selection Description

Language Submenu Select on-screen display (OSD)

language

Lens Wizard Submenu Select to optimize the focus point.

Synchroniza­tion

Connections Submenu Connection parameters

Test signals Submenu Test patterns and texts

Camera ID Submenu Select to access ID submenu

Privacy
masking

Flip Submenu Selects flip submenu

Default ALL Submenu Returns all settings for all modes to

Submenu Sets synchronization parameters

Submenu Sets up a masking area

factory defaults

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

40 en | Configuration FLEXIDOME 5000 AN

5.6.1 Language submenu

Item Selection Description

Language English

Spanish
French
German
Portuguese
Russian
Simplified
Chinese

EXIT Returns to Install menu.

Displays the menus on the OSD in the
chosen language.

5.6.2 Lens Wizard submenu

Item Selection Description

Set focus now Select to fully open the iris. Follow the

instructions for adjusting the focus for
the lens.
After focusing the object of interest
remains in focus under bright and low
light conditions.

EXIT Returns to Install menu.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Configuration | en 41

5.6.3 Synchronization submenu

Item Selection Description

Synchroniza­tion

Vertical phase 0, 1, … 359 Adjusts the vertical phase offset (when

EXIT Returns to Install menu.

Internal
Line lock

Internal - for free running camera
operation.
Line lock - to lock to the AC power
supply

in LINE LOCK mode and a valid power
supply frequency is detected).

5.6.4 Connections submenu

Item Selection Description

Heater Off, Auto Select Auto to enable the

thermostatically controlled heater
function. The heater switches on at
approximately 0°C (+32°F).

Bilinx Comms. On, Off If Off, Bilinx communications is

disabled.

Cable
compensation

Off, Default,
RG59, RG6

Cable compensation is used to avoid
the need for amplifiers in long distance
coaxial connections up to 1000 m
(3000 ft). For optimum results select
the coaxial cable type used or, if
unknown, select default.

Compensation
level

EXIT Returns to Install menu.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

0,1,2 . . .+15 Sets the level of cable compensation

42 en | Configuration FLEXIDOME 5000 AN

5.6.5 Test signal submenu

Item Selection Description

Show camera IDOff, On Select On to overlay the camera ID on

the video test signal.

Test pattern Color bars,

Raster,
Impulse,
Cross
Impulse,
Crosshatch

EXIT Returns to Install menu.

Select the desired test pattern to help
installation and fault-finding.

5.6.6 Camera ID submenu

Item Selection Description

Camera ID Enter a 17-character camera name. Use

Left/Right to change position in the
string; use up/down to select
character. Use Select to exit.

Display ID pos. Off, Top left,

Top right,
Bottom left,
Bottom right

Select the screen position of the
camera ID.

Camera ID
border

MAC address Shows MAC address (factory set,

Ticker bars On, Off The ticker bar moves continuously to

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

On, Off Displays a grey border behind the

camera ID to make it easier to read.

cannot be changed).

show that the image is live and not
frozen or played back.

FLEXIDOME 5000 AN Configuration | en 43

Item Selection Description

Mode ID pos. Off, Top left,

Top right,

Camera mode is displayed on the

screen in the selected position.
Bottom left,
Bottom right

EXIT Returns to Install menu.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

44 en | Configuration FLEXIDOME 5000 AN

5.6.7 Privacy masking submenu

Item Selection Description

Mask 1 to 15 15 different areas can be masked.

Pattern Black, Grey,

White, Noise

Active On, Off Turns each of the masks on or off.

Mosaic On, Off Turns mosaic on or off.

Window Submenu Select to open a window in which to

Selecting an area for privacy masking

To set-up an area for privacy masking, access the area menu by
selecting the Area option from the privacy masking menu. Upon
entering the Area menu, the current area is displayed with the
upper left corner flashing. The flashing corner of the image can
be moved with the Up, Down, Left, Right arrow keys. Pressing
the Select key moves the flashing cursor to the opposite corner,
which can now be moved. Pressing Select again freezes the
area and exits the area menu.

Selects pattern for all masks.

define the mask area.

5.6.8 Flip submenu

Item Selection Description

Flip Off

horizontal
Vertical
Both

EXIT Returns to Install menu.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

Selects the flip mode.

FLEXIDOME 5000 AN Configuration | en 45

5.6.9 Defaults submenu

Item Selection Description

Restore All No, Yes Restores all settings of the six modes

to their default (factory) values. Select

YES then press the Menu/Select

button to restore all values.

When completed the message

RESTORED! is shown.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

46 en | Troubleshooting FLEXIDOME 5000 AN

6 Troubleshooting

6.1 Resolving problems

The following table is intended to help you identify the causes
of malfunctions and correct them when possible.

Malfunction Possible causes Solution

No image
transmission to
remote location.

No connection
established, no
image transmission.

Defective camera. Connect a local monitor

to the camera and check
the camera function.

Faulty cable connections. Check all cables, plugs,

contacts and
connections.

Incorrect cable
connections.

The unit's configuration. Check all configuration

Faulty installation. Check all cables, plugs,

When using DC power
ensure that polarity is
correct.

parameters.

contacts and
connections.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Troubleshooting | en 47

6.2 Customer service

If you cannot resolve a fault, please contact your supplier or
system integrator, or contact Bosch Security Systems
Customer Service directly.

The Installer should write down all information regarding the
unit so that it can be referenced for warranty or repair. The
version numbers of the firmware and other status information
can be seen when the unit starts or by opening the Install
menu. Note down this information and the information found
on the camera label before contacting customer service.

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

48 en | Maintenance FLEXIDOME 5000 AN

7 Maintenance

7.1 Repairs

CAUTION!

Never open the casing of the camera. The unit does not contain
any user serviceable parts. Ensure that all maintenance or
repair work is performed only by qualified personnel (electrical
engineering or network technology specialists). If in doubt,
contact your dealer's technical service center.

7.1.1 Transfer and disposal

The camera should only be passed-on together with this
installation guide. The unit contains environmentally hazardous
materials that must be disposed of according to law. Defective
or superfluous devices and parts should be disposed of
professionally or taken to your local collection point for
hazardous materials.

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Technical Data | en 49

8 Technical Data

8.1 Specifications

Type number VDN-5085-3 VDN-5085-9 VDN-5085-A

Lens 2.8 to 10.5 mm

F1.2

Sensitivity
(30IRE)

Imager 1/3-inch 960H CCD sensor

Maximum
resolution

Rated supply
voltage

SNR > 54 dB

Video output 1 Vpp, 75 Ohm

Synchroniza­tion

Shutter Auto (1/60 [1/50] to 1/100000)

Day/Night Color, Mono, Auto

Sens Up Adjustable from Off to 10x

AGC AGC On or Off (0 - 40 dB) selectable

Dynamic engine XF Dynamic, HDR, Smart BLC

Dynamic Range 94 dB

Dynamic Noise
Reduction

Sharpness Sharpness enhancement level selectable

White Balance ATW indoor, ATW outdoor, ATW hold and manual

Contrast
Enhancement

<0.06 lx
<0.03 lx (mono)

All versions

720TVL

+12 VDC
24 VAC (PAL: 50 Hz; NTSC: 60 Hz)

Internal, Line Lock

Selectable, fixed, flickerless, default

3D-NR, 2D-NR

Low, Medium, High

9 to 22 mm
F1.4

<0.08 lx
<0.04 lx (mono)

18 to 55 mm
F1.5

<0.09 lx
<0.05 lx (mono)

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

50 en | Technical Data FLEXIDOME 5000 AN

Test pattern

Color bar, Raster, Impulse, Cross Impulse, Cross hatch

generator

Video Motion

4 areas, fully programmable
Detection
(VMD)

Privacy Masking 15 independent areas, fully programmable; black, white,

grey, noise

E-zoom Up to 16x

Digital Image

On/Off
Stabilizer

Communication Two-way Bilinx (bi-directional)

Languages
(OSD)

English, Spanish, French, German, Portuguese, Russian,

Simplified Chinese

Modes 6 programmable (preset) modes: 24-hour, Traffic, Low-

light, Smart BLC, Low noise, Vibrant

Peak White

Suppresses highlights in scenes
Invert

Power
consumption

12 VDC 360 mA (700 mA with heater on)

24 VDC 330 mA (650 mA with heater on)

Weight 750 g (1.65 lb)

Operating
temperature

-30°C to +55°C (-22°Fto+131°F)

(-50 °C [-58 °F] with heater enabled)

Controls OSD with softkey operation

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Technical Data | en 51

57.6 (2.27) 57.6 (2.27)

158 (6.22)

39.5 (1.56)

85 (3.35)

33.3 (1.31)

66.5 (2.62)

121 (4.77)

95 (3.7)

mm (in)

8.1.1 Dimensions

Figure 8.1 Dimensions - Flush-mount

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

52 en | Technical Data FLEXIDOME 5000 AN

53.3 (2.1)

53.3 (2.1)

30.8 (1.21)

35 (1.38)

130.5 (5.14)

121 (4.77)

mm (in)

158 (6.22)

Figure 8.2 Dimensions - Surface-mount

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

FLEXIDOME 5000 AN Technical Data | en 53

8.1.2 Accessories

– BNC to UTP transceiver
– Surface Mount Box (SMB)
– Pendant wall mount
– Pendant ceiling mount
–Corner mount
– Bilinx communication interface box and software
Contact a Bosch representative in your area for the latest
available accessories or visit our website at
www.boschsecurity.com

Bosch Security Systems Installation Manual AM18-Q0648 | v1.0 | 2013.03

54 en | Technical Data FLEXIDOME 5000 AN

AM18-Q0648 | v1.0 | 2013.03 Installation Manual Bosch Security Systems

Bosch Security Systems

www.boschsecurity.com

© Bosch Security Systems, 2013
