Installation instructions Notice de montage Instrucciones de instalación Instruções de montagem
Radio / Cassette
Malibu C50
Installation instructions • Notice de montage • Instrucciones de instalación • Instruções de montagem
GB
Safety instructions
When carrying out installation work and making connections please observe the following safety instructions:
- Disconnect the negative terminal of the battery! When doing so, please observe the vehicle manufacturer’s safety instructions.
- Make sure you do not damage vehicle components when drilling any holes.
- The cross sections of the positive and negative cables must not be less than 1.5 mm
2
.
- Incorrect installation may cause interference with electronic vehicle systems or your car radio.
- Do not connect the v ehicle’s plug connectors to the radio!
-You can obtain the adapter cab le required for your vehicle type from any BLAUPUNKT dealer.
F
Consignes de sécurité
Respecter les consignes de sécurité suivantes pendant la durée du montage et du branchement.
- Débrancher le pôle (-) de la batterie ! Respecter les consignes de sécurité du constructeur automobile !
-Veiller à n’endommager aucune pièce du véhicule en perçant des trous.
68
- La section du câble (+) et (-) ne doit pas dépasser 1,5 mm
2
.
- En cas d’erreur d’installation, des perturbations peuvent survenir dans les systèmes électroniques du véhicule ou dans votre autoradio.
- Ne pas brancher les connecteurs du véhicule sur la radio !
- Les câbles d’adaptation nécessaires pour le type de véhicule sont disponibles auprès des revendeurs BLAUPUNKT.
E
Normas de seguridad
Durante el montaje y la conexión es imprescindible observar las siguientes normas de seguridad.
- Desemborne el polo negativo de la batería. Observe las normas de seguridad dadas por el fabricante del vehículo.
- Al perforar agujeros, asegúrese de no dañar ninguna pieza del vehículo.
- La sección transversal del cable positivo y del cable negativo no debe ser menor de 1,5 mm
2
.
- Una instalación incorrecta puede provocar perturbaciones en los sistemas electrónicos del vehículo o en la radio.
No conecte a la radio los conectores ubicados en el vehículo!
- Los cables adaptadores necesarios para su vehículo los encontrará en el comercio especializado en artículos de la marca BLAUPUNKT.
P
Instruções de segurança
Durante a montagem e a ligação do aparelho, queira respeitar as seguintes instruções de segurança.
- Separar o pólo negativo da bateria ! Respeitar ao mesmo tempo as instruções de segurança do fabricante do automóvel.
- Quando se procede à furagem de buracos, prestar atenção para não serem danificadas quaisquer partes do veículo.
- As secções transversais dos cabos positivo e negativo não devem ser inferiores a 1,5 mm
2
.
- Se a montagem for executada de forma incorrecta podem ocorrer avarias nos sistemas electrónicos do automóvel ou no seu auto­rádio.
- Não ligar as fichas existentes do lado do automóvel ao auto-rádio!
- Os cabos adaptadores necessários para o seu automóvel podem ser adquiridos nos revendedores da BLAUPUNKT.
Supplied Mounting Hardware
Materiel de montage fourni
Ferretería de montaje suministrada
Medföljande monteringsdetaljer
Elementos de fixação fornecidos.
A
B
D
C
G
H
I
E
J
ENGLISH
FRANÇAIS
ESP AÑOL
PORTUGUÊS
F
69
1.
Adaptador específico del vehículo, el cual se puede adquirir en el comercio especializado.
Cabo de adaptação específico do automóvel que pode ser adquirido no comércio especializado.
12V
4.
2.
D
C
182
53
165
F
E
Antenna
1-20
A
3.
A
7 607 621 . . .
Car-specific adapter cable which is available at your dealer.
Câble adaptateur spécifique au véhicule, disponible dans le commerce.
70
5.
8 601 910 002
2
B
6.
1
1
2
12V
7.
C-1 C-2 C-3
C
14
2
7
10 131619
9
6
12
3
581114 17
15
18
20
1nc1 Speaker out RR+ 2 Telefon Mute 2 Speaker out RR-
AB
3nc3 Speaker out RF+
B
1
5
3
7
6
2
4
8
4Permanent +12V 4 Speaker out RF­5Aut. antenna 5 Speaker out LF+ 6 Illumination 6 Speaker out LF-
A
345
1
2
7
6
8
7 Kl.15/Ignition 7 Speaker out LR+ 8 Ground 8 Speaker out LR-
C
C1 C2 C3
1 Line Out LR 7 nc 13 Bus - In 2 Line Out RR 8 nc 14 Bus - Out 3 Line Out GND 9 nc 15 Permanent +12V 4 Line Out LF 10 RC +12V 16 +12V 5 Line Out RF 11 Remote Control 17 Bus - GND 6 +12V Amplifier 12 RC - GND 18 AF - GND
19 Line In - L 20 Line In - R
Equalizer Amplifier
ENGLISH
FRANÇAIS
ESP AÑOL
PORTUGUÊS
Remote Control
CD-Changer
71
8.
G
12V
(max. 150 mA)
+
4 Ohm
I
LF
F
R
R
R
-
LR
+
4 Ohm
-
+
4 Ohm
-
+
4 Ohm
-
Relais
10A
H
5
3
1
6
4
2
Telefon Mute (low)
This information is subject to change without notice! Sous réserve de modifications! Modificaciones reservadas! Sob reserva de alterações!
72
Kl. 15 +12V
