Blaupunkt CD35 User Manual
Radio / CD
Kiel CD35 7 645 050 510
Malaga CD35 7 645 060 510
Operating instructions
http://www.blaupunkt.com
2
1
4
3
5
6
11
10
9
8
7
2
CONTROLS
1 Button to switch the device on/
off and operate the volume mute
function.
2 SRC
Short press: Switch sources between CD, CD changer (if connected) and AUX.
Long press: Briefly display the
clock time.
3
device.
4 Volume control
5 CD compartment
6 TRAF RDS button
Short press: Switch traffic-information standby on/off.
Long press: Switch the RDS
function on/off.
7 Arrow buttons
8 MENU button
Short press: Open the settings
menu.
Long press: Start the scan function.
9 AUDIO button to adjust the
bass, treble, balance and fader.
To select an equalizer preset.
To activate, deactivate and adjust the X-BASS function.
: Keys 1 - 6
button
button to eject a CD from the
; BND•TS button
Short press: Select the FM
memory banks and the MW and
LW wavebands (MW/LW only on
the Malaga CD35).
Long press: Start the Travelstore
function.
24
CONTENTS
Notes and accessories .......... 26
Switching on/off .................... 27
Adjusting the volume............. 28
Setting the power-on volume......... 28
Quick volume reduction (mute) ..... 28
Switching the confirmation beep
on/off ............................................ 29
Mute while telephoning ................. 29
Radio mode............................ 29
Adjusting the tuner settings........... 29
Switching to radio mode ............... 30
RDS functions............................... 30
Selecting the waveband /
memory bank ................................ 30
Tuning into a station ...................... 30
Setting the sensitivity of station
seek tuning ................................... 31
Storing stations............................. 31
Storing stations automatically
(Travelstore).................................. 31
Listening to stored stations ........... 32
Scanning receivable stations
(SCAN)......................................... 32
Setting the scanning time.............. 32
Programme type (PTY) ................. 32
Optimising radio reception............ 34
Configuring the display ................. 34
Traffic information ................. 35
CD mode................................ 36
Switching to CD mode.................. 36
Selecting tracks ............................ 36
Fast track selection....................... 36
Fast searching (audible)................ 36
Random track play (MIX)............... 36
Scanning tracks (SCAN) .............. 37
Repeating tracks (REPEAT) .......... 37
Pausing playback (PAUSE)........... 37
Configuring the display ................. 37
Traffic announcements in CD mode .
37
Ejecting a CD ............................... 38
CD-changer mode ................. 38
Switching to CD-changer mode.... 38
Selecting CDs .............................. 38
Selecting tracks ............................ 38
Fast searching (audible)................ 38
Configuring the display ................. 39
Repeating individual tracks or
whole CDs (REPEAT) ................... 39
Random track play (MIX)............... 39
Scanning all the tracks on all the
CDs (SCAN) ................................ 39
Pausing playback (PAUSE)........... 40
CLOCK time ........................... 40
Displaying the clock time .............. 40
Setting the clock time ................... 40
Selecting 12/24-hour clock mode . 40
Displaying the time continuously
when the device is off and the
ignition is on.................................. 41
Briefly displaying the time when
the device is switched off.............. 41
Sound..................................... 41
Adjusting the bass ........................ 41
Adjusting the treble....................... 41
Setting the left/right volume
distribution (balance)..................... 42
Adjusting the front/rear volume
distribution (fader)......................... 42
Equalizer presets .......................... 42
X-BASS .................................. 43
Configuring the level display . 43
External audio sources.......... 44
Specifications ........................ 44
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
25
NOTES AND ACCESSORIES
Notes and accessories
Thank you for choosing a Blaupunkt
product. We hope you enjoy using this
new piece of equipment.
Please read these operating instructions before using the equipment for
the first time.
The Blaupunkt editors are constantly
working on making the operating instructions clearer and easier to understand. However, if you still have any
questions on how to operate the device,
please contact your dealer or the telephone hotline for your country. You will
find the telephone number printed at the
back of this booklet.
We provide a manufacturer guarantee
on our products bought within the European Union. You can view the guarantee conditions at www.blaupunkt.de
or ask for them directly at:
Blaupunkt GmbH
Hotline
Robert Bosch Str. 200
D-31139 Hildesheim
Gerrmany
26
Road safety
Road safety has absolute priority. Only operate your car sound system if the road and traffic conditions
allow you to do so. Familiarise yourself with the device before setting off
on your journey.
You must always be able to hear
police, fire service and ambulance
sirens in good time from inside your
vehicle. For this reason, listen to your
car sound system at a moderate volume level during your journey.
Installation
If you want to install your car sound system yourself, please read the installation and connection instructions that
follow these operating instructions.
Accessories
Only use accessories approved by Blaupunkt.
Remote control
The RC 08 or RC 10 (available as optional accessories) remote control allows you to access the most important
functions of your car sound system safely and conveniently from your steering
wheel.
You cannot switch the device on/off using the remote control.
Amplifiers
You can use all Blaupunkt and Velocity
amplifiers.
CD changers
You can connect the following Blaupunkt
CD changers: CDC A 08, IDC A 09 and
CDC A 03.
SWITCHING ON/OFF
Switching on/off
You can switch the device on/off in the
following ways:
Switching on/off using the vehicle
ignition
If the device is correctly connected to
the vehicle’s ignition and it was not
switched off using button 1, it will
switch on/off simultaneously with the
ignition.
Switching on/off using button 1
➮ To switch on the device, press but-
ton 1.
➮ To switch off the device, press and
hold down button 1 for longer
than two seconds.
The device switches off.
Note:
● To protect the vehicle battery, the
device will switch off automatically
after one hour if the ignition is off.
Switching on by inserting a CD
If the device is switched off and there is
no CD present in the drive,
➮ gently push the CD with its printed
side uppermost into the drive 5
until you feel some resistance.
The drive draws in the CD automatically .
You must not hinder or assist the drive
as it draws in the CD.
The device switches on and starts playing the CD.
Note:
● If the vehicle ignition was switched
off before you inserted the CD, you
will first have to switch on the device by pressing button 1 in order
to start playing the CD.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
27
ADJUSTING THE VOLUME
Adjusting the volume
You can adjust the volume in steps from
0 (off) to 66 (maximum).
To increase the volume,
➮ turn the volume control 4 clock-
wise.
To decrease the volume,
➮ turn the volume control 4 anti-
clockwise.
Setting the power-on volume
Note:
● The device is equipped with a time-
out function. If, for instance, you
press the MENU button 8 and select a menu item, the device will
switch back approx. 8 seconds after the last button was pressed.
Any changes to the settings that
you have made will be saved.
You can set the power-on volume.
➮ Press the MENU button 8.
➮ Press the or button 7 repeat-
edly until “ON VOLUME” appears
in the display.
➮ Adjust the power-on volume using
the
buttons 7.
To help you adjust the setting more easily, the device will increase or decrease
the volume as you make your changes.
If you change the setting to “LAST VOL”,
the volume level that was set the last
time you switched off the device will be
activated again.
Note:
● To protect your hearing, the power-
on volume is limited to a value of
“38”. If the volume level was higher
than this when the device was last
switched off and the “LAST VOL”
setting is activated, the system will
reset the volume to “38” when you
switch the device on again.
When you have finished adjusting the
setting,
➮ press the MENU button 8 twice.
Quick volume reduction (mute)
You can quickly decrease the volume
(mute) to a level preset by you.
➮ Briefly press button 1.
“MUTE” appears in the display .
Cancelling mute
To return to your previously set volume
level,
➮ briefly press button 1 again.
Setting the mute level
You can adjust the mute level.
➮ Press the MENU button 8.
➮ Press the or button 7 repeat-
edly until “MUTE L VL” appears in
the display .
➮ Adjust the mute level using the
buttons 7.
When you have finished adjusting the
setting,
➮ press the MENU button 8 twice.
28
ADJUSTING THE VOLUME
RADIO MODE
Switching the confirmation beep
on/off
The system will play a confirmation beep
for some functions if you keep a button
pressed down for longer than two seconds, for instance, when you assign a
radio station to a station button. Y ou can
switch the beep on/off.
➮ Press the MENU button 8.
➮ Press the or button 7 repeat-
edly until “BEEP ON” or “BEEP
OFF” appears in the display .
➮ Adjust the beep setting using the
buttons 7. “OFF” means the
beep is switched off and “ON”
means the beep is switched on.
When you have finished adjusting the
setting,
➮ press the MENU button 8.
Mute while telephoning
If your device is connected to a mobile
telephone, the car radio’s volume will
be muted as soon as you “pick up” the
telephone. This requires that the mobile telephone be connected to the device as described in the installation instructions.
“PHONE” appears in the display .
Radio mode
This device is equipped with an RDS
radio receiver. Many of the receivable
FM stations broadcast a signal that not
only carries the programme but also
additional information such as the station name and programme type (PTY).
The station name appears in the display as soon as the tuner receives it.
Adjusting the tuner settings
To ensure that the tuner works properly, the device must be configured for the
region in which you are using it. Y ou can
choose between Europe (EUROPE),
United States (USA), South America (SAMERICA) and Thailand (THAI). By
default, the tuner is set to the region in
which the device was sold. If you encounter problems with radio reception,
please check this setting.
The radio functions described in these
operating instructions refer to the EUROPE tuner setting.
➮ Press and hold down the 1 and 5
buttons : simultaneously and
switch on the device again by
pressing button 1.
“TUNER” is displayed.
➮ Select your tuner region using the
or button 7.
To save the setting,
➮ switch the device off and on again
or wait approx. 8 seconds. The car
sound system starts with the last
setting activated (radio, CD, CD
changer or AUX).
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
29
RADIO MODE
Switching to radio mode
If you are in CD, CD-changer or AUX
mode,
➮ press the BND•TS button ;
or
➮ press the SRC button 2 re-
peatedly until the memory bank
(e.g. “FM1”) appears in the display .
RDS functions
The convenient RDS functions AF (Alternative Frequency) and REGIONAL
extend your radio’s range of functions.
● AF: If the RDS function is activat-
ed, the radio automatically tunes
into the best receivable frequency
for the station that is currently set.
● REGIONAL: At certain times, some
radio stations divide their programme into regional programmes
providing different content. You can
use the REG function to prevent
the car radio from switching to alternative frequencies that are
broadcasting different programme
content.
Note:
● REGIONAL must be activated/de-
activated separately in the menu.
Switching the RDS function on/off
If you want to use the RDS functions
(AF and REGIONAL),
➮ press and hold down the TRAF
RDS button 6 for longer than two
seconds.
The RDS function is active when an
RDS symbol lights up in the display .
Switching REGIONAL on/off
➮ Press the MENU button 8.
➮ Press the or button 7 repeat-
edly until “REG” appears in the display . “OFF” or “ON” is displayed
alongside “REG”.
➮ To switch REGIONAL on/off, press
the or button 7.
➮ Press the MENU button 8.
Selecting the waveband /
memory bank
This device can receive programmes
broadcast over the FM frequency range
as well as the MW and L W (AM) wavebands (MW and LW only on the Malaga CD35). There are three memory
banks available for the FM waveband
(FM1, FM2 and FMT) and one for each
of the MW and L W wavebands. Six stations can be stored in each memory
bank.
To switch between the FM memory
banks (FM1, FM2 and FMT) and the
MW and L W wavebands,
➮ briefly press the BND•TS button
;.
Tuning into a station
There are various ways of tuning into a
station.
Automatic station seek tuning
➮ Press the or button 7.
The radio tunes into the next receivable station.
30
RADIO MODE
Tuning into stations manually
You can also tune into stations manually .
Note:
● You can only tune into stations
manually if the RDS function is deactivated.
➮ Press the or button 7.
Browsing through broadcasting
networks (only FM)
If radio stations provide several programmes, you have the option of browsing through their “broadcasting networks”.
Note:
● The RDS function must be activat-
ed before you can use this feature.
➮ Press the or button 7 to
switch to the next station on the
broadcasting network.
Note:
● When using this feature, you will
only be able to switch to stations
that you have received once before
already . To receive the stations,
use the scan function or the Travelstore function.
Setting the sensitivity of station
seek tuning
You can choose whether the radio
should only tune into stations providing
good reception or whether it can also
tune into those with a weak reception.
➮ Press the MENU button 8.
➮ Press the or button 7 repeat-
edly until “SENS” and the currently
set value appear in the display .
“SENS HI6” means that the tuner is set
to the highest sensitivity setting. “SENS
LO1” means it is set to the lowest sensitivity setting.
➮ Set the desired sensitivity using the
buttons 7.
When you have finished adjusting the
setting,
➮ press the MENU button 8.
Note:
● You can set different sensitivity
levels for FM and MW or LW (AM)
(MW/LW only on the Malaga
CD35).
Storing stations
Storing stations manually
➮ Select the memory bank that you
want (FM1, FM2, FMT) or one of
the wavebands (MW or LW) (MW/
LW only on the Malaga CD35).
➮ Tune into the station that you want.
➮ Press and hold down one of the
station buttons 1 - 6 : for longer
than two seconds to assign the station to that button.
Storing stations automatically
(Travelstore)
You can automatically store the six stations providing the best reception in the
region (only FM). The stations are stored
in the FMT memory bank.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
31
Loading...
