Black Widow BW 3000 User Manual

1

OWNERS MANUAL

Standard Features

The following features are standard with your
BW 3000 Security System:

2-two button, 3 channel remote controls
Status indicator (red LED)
Valet / override switch
Multi-tone siren (120db)
Built-in starter interrupt
Dual stage impact detector
Remote panic
Remote chirp mute
Remote sensor bypass
Passive or active arming
Remote keyless entry
Ignition triggered door locks programmable

Optional Features that you may add to
your BW 3000 (Consult with your technician)

Remote trunk pop
Remote auto start
Power window roll up
Flashing parking lights
Back up battery
Additional Sensors: Glass break, Microwave
Hood and trunk protection
Illuminated entry

Note: Some features and options may require
additional parts and labor, and may not be appro­priate for certain vehicles.

BW 3000

System Operation

ARMING OPERATION:

Active Arming-To activate the
alarm, simply press button #1
on your remote control.You
will hear one chirp from your
siren, your parking lights will flash one time
(optional).Your doors will lock, and the LED
will turn solid for 10 seconds then it will start
flashing slowly, the system is now armed.

Passive Arming- If your system was installed
to arm passively, simply turn off your ignition
key and exit the vehicle, the system will arm
30 seconds after the last door is closed. After
you shut off the ignition, the LED will start
flashing rapidly to let you know that the sys­tem is in the Pre Arm state.You can always
arm the system at any time by pressing button
#1 on the remote.

DISARMING OPERATION:

To deactivate alarm press button #1 on your
remote.The siren will chirp twice and your

parking lights will flash twice
(optional), then stay on for 30
seconds or until you either turn
the ignition on or rearm the
system (optional car location
feature).The LED will stop flashing, the doors
will unlock , your system is disarmed. If you
have the (optional) illuminated entry system
installed the interior light will flash twice then
stay on for 30 seconds or until you turn the
ignition on or rearm the system.

VALET MODE:

Valet
mode will
keep your
alarm sys­tem from
passive arming (if programmed to be passive
arming), if you need to have your vehicle ser­viced, or run it through the car wash, etc. To
put your system in Valet Mode,disarm system,
turn the ignition key on and press and hold
your valet/override switch in for approximate­ly 3 seconds, the LED will turn solid, and siren
will chirp once. Your vehicle’s system is in
Valet Mode. If you have the keyless entry fea­tures the remote will still lock and unlock the
vehicle while in Valet Mode.To exit Valet Mode:
Turn ignition key on, press and hold
valet/override switch for approx. 3 seconds,
LED will turn off and siren will chirp 2 times.

EMERGENCY OVERRIDE:

If you lose
your
transmit­ter, or it
fails to
operate the system, unlock door and enter

2

Button 1 LED Button 2

PRESS

PRESS

Press

+

Hold

Press

ON

ON

+

+

vehicle. The siren will sound, insert your igni­tion key and turn the ignition to the ON posi­tion. Then press the Valet/Override Switch,
the system will be overridden and allow you
to start the vehicle.The system will automati­cally go into valet, so it will not passively
rearm. (See Valet operation to take system out
of Valet mode.)

REMOTE PANIC:

For your personal safety you
may activate the siren by
pressing button #1 on your
remote for 3 seconds.This will
trigger the system into the
Panic mode.The siren will sound and the park­ing lights will flash (optional).The panic mode
will run for 45 seconds, or until you press but­ton #1 on your remote again. This feature will
not operate when the ignition is on.

SILENT ARM/DISARM:

If you wish to arm or disarm
your alarm, but do not want
the siren to chirp simply press
button #2 on the remote con­trol, temporarily deleting the
arm or disarm chirps.

CHIRP DELETE:

To turn
off ARM/
DISARM
chirps,
turn igni­tion switch on, then press and hold button #2
until you hear a double chirp. The
Arm/Disarm chirps will remain off until you
repeat the procedure.

ENTRY VIOLATION MEMORY:

In the event that your BW 3000 system is
triggered and runs an entire cycle, when you
return to disarm it instead of the usual 2
chirps you will hear 3 chirps, this is to indicate
that the your system was set off., parking
lights will flash 3 times as well (optional).

TEMPORARY TRIGGER AND
SENSOR BYPASS:

If you
would like
to tem­porarily
arm the
system but only want to have the starter dis­able engaged (the doors, hood, and or trunk,
and any sensors would not trigger the alarm).
Press button# 1 to arm, then within 5 seconds
press button# 2.You will hear a second confir­mation chirp to let you know that the system
will NOT monitor the doors, hood, trunk or
sensors.The starter disable function will be
engaged.

TEMPORARY
SENSOR BYPASS:

If you
would like
to arm
the sys­tem but
want to have it not monitor the shock sensor,
(leaving a pet in the car). Press button #1 to
arm, then within 5 seconds press buttons #
1&2 simultaneously. You will hear a second
chirp to confirm that the sensor will be
bypassed. NOTE: Once you disarm and rearm

the system, the door/hood trigger and sensor
inputs will be monitored

3

3 sec.

Press

Press

Press

Hold

Press

Press

ON

+

+

+

AUTO REARM FEATURE:

If you
would like
your sys­tem to
auto
rearm (if system is remotely disarmed) and a
door is not opened, within 30 seconds the
alarm will automatically rearm the system.This
feature may be disabled by turning ignition to
on and pressing and holding button# 1on the
remote. Siren will chirp twice. Repeat the pro­cedure to enable the feature.

NOTE: This will not work on vehicles with the
illuminated entry feature enabled.

REPLACING STOLEN
OR LOST REMOTE CONTROLS:

Your authorized Black Widow Dealer can pro­gram more remote control transmitters, and
erase the codes of stolen or lost transmitters
at the same time so they will not be able to
operate the system.

LED STATUS INDICATORS

Off= System off in Active mode
Slow Flashing= System Armed
Rapid Flashing= Passive Pre Arm State
Rapid Flashing (after disarm)= System

was triggered while away.

On Solid=In Valet Mode.
On Solid(After Active Arming)= Pre Arm

State,usually approximately 10 seconds.

On Solid (when disarmed, and not in
Valet)= Door/Hood is open.

CHIRP INDICATIONS:

One Chirp= Armed
Two Chirps= Disarmed
Three Chirps= Disarmed, but system was

triggered while away.
Four Chirps= 8 seconds after arming, indi­cates faulty sensor or trigger.
Five Rapid Chirps= Warn away triggered

4

REMOTE CONTROL FEATURE OPERATION

Button Duration Function

1 SHORT ARM/DISARM

1 LONG (3 SEC.) REMOTE PANIC

2 SHORT SILENT ARM/DISARM

2 LONG (3 SEC.) OPTIONAL ACCESSORY

1/2 SHORT/SHORT TEMP.TRIGGER BYPASS

1/1&2 SHORT/SHORT TEMP. SENSOR BYPASS

1&2 SHORT AUX. 3RD CH. OUTPUT

© David Levy Company, Inc., Rev. 4, August 2004 • Cerritos, Ca 90703

Hold

ON

+

Button 1 LED Button 2
