TH67+/TH67/TH67B Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user’s manual. All the
brand and product names are trademarks of their respective companies.
Dichiar azione di confor mità
sintetica
Ai sensi dell’art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short De clar ation of c onform ity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied
Table of Contents
Chapter 1: Introduction ........................................ 1
1.1 Before You Start......................................................................................... 1
1.2 Package Checklist..................................................................................... 1
1.3 Motherboard Features.............................................................................. 2
1.4 Rear Panel Connectors.............................................................................. 3
1.5 Motherboard Layout (TH67+ / TH67)..................................................... 4
1.6 Motherboard Layout (TH67B)................................................................. 5
Chapter 2: Hardware Installation .......................... 6
2.1 Installing Central Processing Unit (CPU) ............................................... 6
2.2 FAN Headers.............................................................................................. 8
2.3 Installing System Memory ........................................................................ 9
2.4 Connectors and Slots................................................................................ 11
Chapter 3: Headers & Jumpers Setup .................. 14
3.1 How to Setup Jumpers............................................................................. 14
3.2 Detail Settings .......................................................................................... 14
Chapter 4: RAID Functions .................................. 19
4.1 Operating System.................................................................................... 19
4.2 Raid Arrays............................................................................................... 19
4.3 How RAID Works ..................................................................................... 19
Chapter 5: T-Series BIOS & Software................... 23
5.1 T-Series UEFI BIOS ................................................................................... 23
5.2 T-Series Software...................................................................................... 26
Chapter 6: Useful Help ........................................ 36
6.1 Driver Installation Note.......................................................................... 36
6.2 Extra Information.................................................................................... 37
6.3 Troubleshooting....................................................................................... 38
Appendix: SPEC In Other Languages ................... 40
German.................................................................................................................. 40
French .................................................................................................................... 42
Italian..................................................................................................................... 44
Spanish ................................................................................................................... 46
Portuguese ............................................................................................................ 48
Polish...................................................................................................................... 50
Russian ................................................................................................................... 52
Arabic..................................................................................................................... 54
Japanese ................................................................................................................ 56
CHAPTER 1: INTRODUCTION
TH67+/TH67/TH67B
1.1 B
EFORE YOU START
Thank you for choosing our product. Before you start installing the
motherboard, please make sure you follow the instructions below:
Prepare a dry and stable working environment with
sufficient lighting.
Always disconnect the computer from power outlet
before operation.
Before you take the motherboard out from anti-static
bag, ground yourself properly by touching any safely
grounded appliance, or use grounded wrist strap to
remove the static charge.
Avoid touching the components on motherboard or the
rear side of the board unless necessary. Hold the board
on the edge, do not try to bend or flex the board.
Do not leave any unfastened small parts inside the
case after installation. Loose parts will cause short
circuits which may damage the equipment.
Keep the computer from dangerous area, such as heat
source, humid air and water.
The operating temperatures of the computer should be
0 to 45 degrees Celsius.
1.2 PACKAGE CHECKLIST
Serial ATA Cable X 3
Rear I/O Panel for ATX Case X 1
User’s Manual X 1
Fully Setup Driver CD X 1
USB 2.0 Cable X1 (optional)
Serial ATA Power Cable X 1 (optional)
Note: The package contents may be different due to area or your motherboard version.
1
Motherboard Manual
1.3 MOTHERBOARD FEATURES
TH67+ / TH67 TH67B
Socket 1155
Int e l Core i7 / i5 / i3 / Pentiu m pro cessor
CPU
Chipset
Super I/O
Main Memory
SATA 2 & 3
LAN
Sound Codec
USB3.0 NEC uPD720200 / Asmedia ASM1042
Slots
Supports Execute D isable B it / Enhanced Intel
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technology
Intel H67 Intel H67
ITE 8728
Prov ides the most common ly used leg acy Sup er
I/O functionality.
Low Pin Count Interface
En viro nment C ont rol in iti at ives ,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guard ian" function
DIMM Slots x 4
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 16GB
Dual Channe l Mode DDR3 me mory mo dule
Supports DDR3 1333/1066
Register ed DIMM and ECC D IMM is not
supported
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
ALC892
5.1 channels audio out
High Definition Audio
PCI slot x1 PCI slot x1
PCI-E Gen2 x16 @ x16 s lot x1 PCI-E Gen2 x16 @ x16 slot x1
PCI-E Gen2 x16 @ x4 slot x1 PCI-E Gen2 x16 @ x4 slot x1
PCI-E Gen2 x1 slot x1 PCI-E Gen2 x1 slot x1
2
Socket 1155
Int e l Core i7 / i5 / i3 / Pentiu m pro cessor
Supports Execute D isable B it / Enhanced Intel
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technology
ITE 8728
Prov ides the most common ly used leg acy Sup er
I/O functionality.
Low Pin Count Interface
En viro nment C ont rol in iti at ives ,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guard ian" function
DIMM Slots x 4
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 16GB
Dual Channe l Mode DDR3 me mory mo dule
Supports DDR3 1333/1066
Register ed DIMM and ECC D IMM is not
supported
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
ALC892
5.1 channels audio out
High Definition Audio
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Serial Port Connector x1 Serial Port Connector x1
SATA 3 Connector x2 SATA 3 Connector x2
SATA 2 Connector x4 SATA 2 Connector x4
Front Panel Connector x1 Front Panel Connector x1
Front Audio Connector x1 Front Audio Connector x1
On Board
Connectors
Back Panel
I/O
Board Size
OS Support
S/PDIF out Connector x1 S/PDIF out Connector x1
CPU Fan Header x1 CPU Fan Header x1
System Fan Header x2 System Fan Header x2
Clear CMOS Head er x1 Clear C MOS Header x1
USB 2.0 Connector x3 USB 2.0 Connector x3
Consumer IR Connector x1 Consumer IR Connector x1
Power Connector (24pin) x1 Power Connector (24pin) x1
Power Connector (8pin) x1 Power Connector (4pin) x1
PS/2 Keyboard / Mouse x1
HDMI Port x1
VGA Port x1
DVI-D Port x1
LAN Port x1
USB2.0 Port (by H67) x2
USB3.0 Port (by NEC uPD720200 /
Asmedia ASM1042) x2
Audio Jack x3
230 (W) x 244 (L) mm 230 (W) x 244 (L) mm
Windows XP / Vista / 7
Biostar reserves the right to add or remove
support for any OS with or without notice
PS/2 Keyboard / Mouse x1
HDMI Port x1
VGA Port x1
DVI-D Port x1
LAN Port x1
USB2.0 Port x4
Audio Jack x3
Windows XP / Vista / 7
Biostar reserves the right to add or remove
support for any OS with or without notice
1.4 REAR PANEL CONNECTORS
PS/2
Keyboar d / Mouse
USB2.0X2
HDM I VGADV I- D
NOTE: Any of 2 HDMI / DVI-D / VGA can provide digital video signals out-put function.
NOTE: USB3.0 ports are backward compatible with USB2.0/USB1.X devices. USB3.0 is
controlled by NEC uPD720200 / Asmedia ASM1042, but, USB2.0/USB1.X is controlled by
H67.
LAN
USB3 .0X2
(For TH67+ & TH67)
USB2 .0X2
(For TH67B)
Line In/
Surro und
Line Out
Mic I n 1/
Bass / Cen ter
3
Motherboard Manual
1.5 MOTHERBOARD LAYOUT (TH67+ / TH67)
USB_KBMS1
HDMI1
DVI1
VGA1
RJ45US B1
AU DIO1
Super
PHS
PH3
PH2
PH1
VTT_LED1
I/O
ATXPW R2
SYS_FAN2
PEX1_1
PEX16_1
LAN
PEX 16_2
Socket 1155
CPU1
BAT1
CPU_FAN1
DD R3 _A 1
H67
DD R3 _A 2
DD R3 _B 1
DB2DR3_
ATXP WR 1
SW_ RST1
SW_ PWR 1
JCMOS1
BIOS
4
CODEC
F_AUDIO1
Note: represents the 1■
JSPDIFOUT1
J_COM1
PCI1
CIR1
SYS_FAN1
st
F_USB3 F_USB2 F_USB1
pin.
SATA2
LED_D2LED_D1
PAN EL1
SATA1
SATA4
SATA3
SATA6 SATA5
TH67+/TH67/TH67B
1.6 MOTHERBOARD LAYOUT (TH67B)
USB_KBMS1
HDMI1
DVI1
VGA1
R J45USB 1
AU DIO1
Super
I/O
ATXPW R2
SYS_FAN2
PEX1_1
PEX16_1
LAN
PEX 16_2
Socket 1155
CPU1
BAT1
CPU_FAN1
DD R3 _A 1
H67
DD R3 _A 2
DD R3 _B 1
DB2DR3_
ATXP WR 1
SW_ RST1
SW_ PWR 1
JCMOS1
BIOS
CODEC
F_AUDIO1
Note: represents the 1■
JSPDIFOUT1
J_COM1
PCI1
CIR1
SYS_FAN1
st
F_USB3 F_USB2 F_USB1
pin.
SATA2
LED_D2LED_D1
PAN EL1
SATA1
SATA4
SATA3
SATA6 SATA5
5
Motherboard Manual
CHAPTER 2: HARDWARE INSTALLATION
2.1 I
NSTALLING CENTRAL PROCESSING UNIT (CPU)
Special Notice:
Remove Pin Cap before installation, and make good preservation
for future use. When the CPU is removed, cover the Pin Cap on the
empty socket to ensure pin legs won’t be damaged.
Step 1: Pull the socket locking lever out from the socket and then raise
the lever up.
Step 2: Remove the Pin Cap.
6
TH67+/TH67/TH67B
Step 3: Look for the triangular cut edge on socket, and the golden dot on
CPU should point forwards this triangular cut edge. The CPU will
fit only in the correct orientation.
Step 4: Hold the CPU down firmly, and then lower the lever to locked
position to complete the installation.
Step 5: Put the CPU Fan and heatsink assembly on the CPU and buckle it
on the retention frame. Connect the CPU FAN power cable into
the CPU_FAN1 to complete the installation.
7
Motherboard Manual
2.2 FAN HEADERS
These fan headers support cooling-fans built in the computer. The fan
cable and connector may be different according to the fan manufact urer.
Connect the fan cable to the connector while matching the black wire to
pin#1.
CPU_FAN1: CPU Fan Header
Pin
1 Ground
41
2 +12V
3
4 Smart Fan
SYS_FAN1/SYS_FAN2: System Fan Headers
Pin
SYS_FAN2
Assignment
FAN RPM r at e
sense
Control
Assignment
1 Ground
2 +12V
3 FAN RPM
rate sense
3
1
SYS_FAN1
Note:
The SYS_FAN1/SYS_FAN2 support 3-pin head connectors; the CPU_FAN1 supports
4-pin head connector. When connecting with wires onto connectors, please note that the
red wire is the positive a nd should be connected to pin#2, and the black wire is Ground
and should be co nnected to GND.
8
TH67+/TH67/TH67B
2.3 INSTALLING SYSTEM MEMORY
A. Memory Modules
DDR3_A1
DDR3_A2
1. Unlock a DIMM slot by pressing the retaining clips outward. Align a
DIMM on the slot such that the notch on the DIMM matches the
break on the Slot.
DDR3_B1
DDR3_B2
2. Insert the DIMM vertically and firmly into the slot until the retaining
chip snap back in place and the DIMM is properly seated.
9
Motherboard Manual
B. Memory Capacity
DIMM Socket
Location
DDR3_A1 512MB/1GB/2GB/4GB
DDR3_A2 512MB/1GB/2GB/4GB
DDR3_B1 512MB/1GB/2GB/4GB
DDR3_B2 512MB/1GB/2GB/4GB
DDR3 Module
Total Memory
Size
Max is 16GB.
C. Dual Channel Memory Installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
Note:
Memory module must be installed in DDR3-A2 or DDR3-B2 to boot the
system.
10
TH67+/TH67/TH67B
2.4 CONNECTORS AND SLOTS
SATA1 ~ SATA6: Serial ATA Connectors
The motherboard has a PCI to SATA Controller with 6 channels SATA interface.
SATA1 & SATA2 satisfy the SATA 3.0 spec and with transfer rate of 6.0Gb/s;
SATA3 ~ SATA6 satisfy the SATA 2.0 spec and with transfer rate of 3.0Gb/s.
Pin
1 Ground
2 TX+
3 TX-
SATA2
4
SATA
6
SATA
SATA1
SATA
SATA
4 Ground
5 RX-
3
6 RX+
5
7 Ground
Assignment
1
74
ATXPWR2: ATX Power Source Connector (TH67+ / TH67)
This connector provides +12V to CPU power circuit. If the CPU power plug is
4-pin, please plug it into Pin 1-2-5-6 of ATXPWR2.
85
Pin
Assignment
1 +12V
2 +12V
14
3 +12V
4 +12V
5 Ground
6 Ground
7 Ground
8 Ground
11
Motherboard Manual
ATXP W R1: AT X Power Source Connector
This connector allows user to connect 24-pin power connector on the ATX
power supply.
12
1
Pin Assignment Pin Assignment
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 Ground 3 Ground
16 PS_ON 4 +5V
17 Ground 5 Ground
18 Ground 6 +5V
19 Ground 7 Ground
20 NC 8 PW_OK
21 +5V 9 Standby Voltage+5V
22 +5V 10 +12V
23 +5V 11 +12V
24 Ground 12 +3.3V
24
13
ATXP W R2: AT X Power Source Connector (TH67B)
This connector provides +12V to CPU power circuit.
43
Pin
12
1 +12V
2 +12V
3 Ground
4 Ground
Assignment
12
Note:
Before you power on the system, please make sure that both ATXPWR1 and ATXPWR2
connectors have been well plugged-in.
TH67+/TH67/TH67B
PEX16_1: PCI-Express Gen2 x16 Slot
- PCI-Express 2.0 compliant.
- Maximum theoretical realized bandwidth of 8GB/s simultaneously per
direction, for an aggregate of 16GB/s totally.
- PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins.
- 2X bandwidth over the PCI-Express 1.1 architecture.
PEX16_2: PCI-Express Gen2 x4 Slot
- PCI-Express 2.0 compliant.
- Maximum theoretical realized bandwidth of 2GB/s simultaneously per
direction, for an aggregate of 4GB/s totally.
PEX1_1: PCI-Express Gen2 x1 Slot
- PCI-Express 2.0 compliant.
- Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total.
- PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins.
PEX16_1
PCI1: Peripheral Component Interconnect Slot
This motherboard is equipped with 1 standard PCI slot. PCI stands for
Peripheral Component Interconnect, and it is a bus standard for expansion
cards. This PCI slot is designated as 32 bits.
PEX1_1
PEX16_2
PCI1
13
Motherboard Manual
CHAPTER 3: HEADERS & JUMPERS SETUP
3.1 H
OW TO SETUP JUMPERS
The illustration shows how to set up jumpers. When the jumper cap is
placed on pins, the jumper is “close”, if not, that means the jumper is
“open”.
Pin opened Pin closed Pin1-2 closed
3.2 D
PANEL1: Front Panel Header
ETAIL SETTINGS
This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, and
speaker connection. It allows user to connect the PC case’s front panel switch
functions.
POW_LED
9
1
SPK
++
HLED
+
On/Off
-
-
RST
16
8
14
Pin Assignment Function Pin Assignment Function
1 +5V 9 N/A
2 N/A 10 N/A
3 N/ A 11 N/A N/A
4 Speaker
5 HDD LED (+) 13 Power LED (+)
6 HDD LED (-)
7 Ground 15 Power button
8 Reset control
Speaker
Connector
Hard drive
LED
Reset button
12 Power LED (+)
14 Power LED (-)
16 Ground
N/A
Power LED
Power-on button
TH67+/TH67/TH67B
F_USB1/F_USB2/F_USB3: Headers for USB 2.0 Ports at Front Panel
These headers allow user to connect additional USB cable on the PC front panel,
and also can be connected with internal USB devices, like USB card reader.
Assignment
Pin
1 +5V (fused)
2 +5V (fused)
3 USB4 USB5 USB+
F_ USB1
USB3 F_
F_USB2
2
10
1
9
6 USB+
7 Ground
8 Ground
9 Key
10 NC
CIR1: Consumer IR Connector
This header is for infrared remote control and communication.
Pin Assignment
1 IrDA serial input
2 Ground
3 Ground
4 Key
5 IrDA serial output
6 IR Power
6
125
15
Motherboard Manual
F_AUDIO1: Front Panel Audio Header
This header allows user to connect the front audio output cable with the PC front
panel. This header allows only HD audio front panel connector; AC’97 connector
is not acceptable.
Pin Assignment
1 Mic Left in
2 Ground
3 Mic Right in
4 GPIO
5 Right line in
6 Jack Sense
7 Front Sense
8 Key
2
9 Left line in
10
10 Jack Sense
1
9
JSPDIFOUT1: Digital Audio-out Connector
This connector allows user to connect the PCI bracket SPDIF output header.
Pin
Assignment
1 +5V
2 SPDIF_OUT
3 Ground
31
16
TH67+/TH67/TH67B
JCMOS1: Clear CMOS Header
Placing the jumper on pin2-3 allows user to restore the BIOS safe setting and
the CMOS data. Please carefully follow the procedures to avoid damaging the
motherboard.
13
Pin 1-2 Close:
Normal Operation
(default).
3
1
Pin 2-3 Close:
Clear CMOS data.
13
※ Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 2-3 close” .
3. Wait for five seconds.
4. Set the jumper to “Pin 1-2 close” .
5. Power on the AC.
6. Reset your desired password or clear the CMOS data.
J_COM1: Serial Port Connector
The motherboard has a Serial Port Connector for connecting RS-232 Port.
Assignment
1 Carrier detect
2 Received data
3 Transmitted data
4 Data terminal ready
5 Signal ground
6 Data set ready
7 Request to send
8 Clear to send
9 Ring indicator
10 NC
210
19
Pin
17
Motherboard Manual
S
On-Board LED Indicators
There are 7 LED indicators on the motherboard showing system status.
PH
PH3
PH2
PH1
VT T_LED1
LED_D1
LED_D2
LED_D1 & LED_D2: Debug Indicators
PHS / PH1 ~ PH3 / VTT_LED1 (TH67+ / TH67): Power Status Indicators
Please refer to the tables below for specific messages:
LED_D1 LED_D2 Message
ON ON Norma l
ON OFF Memory Error
OFF ON VGA Error
OFF OFF Abnormal: CPU / Chipset error.
PHS
PH1~PH3
VTT_LED
ON Phase Active
OFF Phase Inactive
Phase Indicator (TH67+ /
TH67)
On-Board Buttons
There are 2 on-board buttons.
SW_R ST1
SW_PWR 1
SW_RST1: Reset button.
SW_PWR1: Power Switch button.
18
CHAPTER 4: RAID FUNCTIONS
TH67+/TH67/TH67B
4.1 O
Supports Windows Vista and Windows 7.
PERATING SYSTEM
4.2 RAID ARRAYS
RAID supports the following types of RAID arrays:
RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for
many applications.
RAID 1: RAID 1 defines techniques for mirroring data.
RAID 10: RAID 10 combines the techniques used in RAID 0 and RAID 1.
RAID 5: RAID 5 provides fault tolerance and better utilization of disk capacity.
4.3 HOW RAID WORKS
RAID 0:
The controller “stripes” data across multiple drives in a RAID 0 array system. It breaks
up a large f ile into smaller blo cks an d pe rform s disk r ead s and writ es across multip le
drives in parallel. The size of each block is determined by the stripe size parameter,
which you set during the creation of the RAID set based on the system environment. This
technique reduces overall disk access time and offers high bandwidth.
Features and Benefits
Drives: Minimum 2, and maximum is up to 6 or 8. Depending on the
platform.
Uses: Intended for non-critical data requiring high data throughput, or any
environment that does not require fault tolerance.
Benefits: provides increased data throughput, especially for large files. No
capacity loss penalty for parity.
Drawbacks: Does not deliver any fault tolerance. If any drive in the array
fails, all data is lost.
Fault Tolerance: No.
Block 1
Blo ck 3
Blo ck 5
Block 2
Blo ck 4
Blo ck 6
19
Motherboard Manual
RAID 1:
Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1
array system. The mirrored (backup) copy of the data can reside on the same disk or on a
second redundant drive in the array. RAID 1 provides a hot-standby copy of data if the
active volume or drive is corrupted or becomes unavailable because of a hardware failure.
RAID techniques can be applied for high-availability solutions, or as a form of automatic
backup that eliminates tedious manual backups to more expensive and less reliable
media.
Features and Benefits
Drives: Minimum 2, and maximum is 2.
Uses: RAID 1 is ideal for small databases or any other application that
requires fault tolerance and minimal capacity.
Benefits: Provides 100% data redundancy. Should one drive fail, the
controller switches to the other drive.
Drawbacks: Requires 2 drives for the storage space of one drive.
Performance is impaired during drive rebuilds.
Fault Tolerance: Ye s .
20
Block 1
Block 2
Block 3
Block 1
Block 2
Block 3
TH67+/TH67/TH67B
RAID 10:
RAID 1 drives can be stripped using RAID 0 techniques. Resulting in a RAID 10
solution for improved resiliency, performance and rebuild performance.
Features and Benefits
Drives: Minimum 4, and maximum is 6 or 8, depending on the platform.
Benefits: Optimizes for both fault tolerance and performance, allowing for
automatic redundancy. May be simultaneously used with other RAID levels
in an array, and allows for spare disks.
Drawbacks: Requires twice the available disk space for data redundancy,
the same as RAID level 1.
Fault Tolerance: Ye s .
Block 1
Block 3
Block 5
Block 1
Block 3
Block 5
Block 2
Block 4
Block 6
Block 2
Block 4
Block 6
21
Motherboard Manual
RAID 5:
RAID 5 stripes both data and parity information across three or more drives. It writes
data and parity blocks across all the drives in the array. Fault tolerance is maintained by
ensuring that the parity information for any given block of data is placed on a different
drive from those used to store the data itself.
Features and Benefits
Drives: Mi nimu m 3.
Uses: RAID 5 is recommended for transaction processing and general
purpose service.
Benefits: An ideal combination of good performance, good fault tolerance,
and high capacity and storage efficiency.
Drawbacks: Individual block data transfer rate same as a single disk. Write
performance can be CPU intensive.
Fault Tolerance: Yes.
Disk 1
DATA 1
DATA 3
PA RI T Y
DATA 7
DATA 9
PA RI T Y
22
Disk 2
DATA 2
PA RI T Y
DATA 5
DATA 8
PA RI T Y
DATA 11
Disk 3
PA RI T Y
DATA 4
DATA 6
PA RI T Y
DATA 10
DATA 12
TH67+/TH67/TH67B
Y
p
CHAPTER 5: T-SERIES BIOS & SOFTWARE
5.1 T-S
ERIES UEFI BIOS
T-Series UEFI BIOS Features
Overclocking Navigator Engine (O.N.E.)
Self Recovery System (S.R.S)
Smart Fan Function
BIO-Flasher: Update UEFI BIOS file from USB Flash Drive
!! WARNING !!
For better system performance, the UEFI BIOS firmware is being
continuously updated. The UEFI BIOS information described below
in this manual is for your reference only and the actual UEFI BIOS
information and settings on board may be different from this
manual. For further information of setting up the UEFI BIOS,
lease refer to the UEFI BIOS Manual in the Setup CD.
A. Overclocking Navigator Engine (O.N.E.)
O.N.E provides 4 systems allowing users to customize personal overclock
settings: Manual CPU System, Manual Memory System, Manual PWM
System, and Manual Voltage System.
Main Adva nce d Chips et Boot Sec urity O.N. E S ave & Exit
Noti ce: P le ase C lear CM OS if syst em no di splay
a ft er ov erclo ck ing
Star t Pag e [P age - Ma in]
==== Manua l CPU system ====
Fixe d CPU R atio [D isa bled]
CPU Ratio 31
CPU Co re Curre nt Max(Am p) 150
Powe r Lim it 1 Va lue ( Wa tt) 95
Powe r Lim it 2 Sw itch [E nab led]
Powe r Lim it 2 Va lue 11 8
Enha nced In tel S peedS te p Tec h [E nab led]
Turb o Mod e [E nab led]
CPU CIE [E nab led]
Grap hics Co re Ra tio Lim it 22
CPU Clock 10 0
Spre ad Sp ec trum [A uto ]
Versi on x. xx .xxxx . Cop yri ght© 201x, A meric an Me ga trend s, In c.
Notice:
Not all types of Intel CPU perform above overclock setting ideally; the difference will be based on the
selected CPU model.
BIOS SETU P U TILI T
You can s et the entra nce Page
when you en ter U EFI B IOS
Setu p
Selec t Scree n
Selec t Item
Selec t
Ente r
+/-
Chang e Opt.
F1
Gener al He lp
F3
Optim ized De fau lts
F4
Save & Res et
ESC
Exit
23
Motherboard Manual
Y
NOTE
Overclock is an optional process, but not a “must-do” process; it is not
recommended for inexperienced users. Therefore, we will not be responsible
for any hardware damage which may be caused by overclocking. We also
woul d not guarantee any overclocking performance.
B. Self Recovery System (S.R.S.)
This function can’t be seen under UEFI BIOS setup, and is always on whenever
the system starts up.
However, it can prevent system hang-up due to inappropriate overclock
actions.
When the system hangs up, S.R.S. will automatically log in the default UEFI
BIOS setting, and all overclock settings will be re-configured.
C. Smart Fan Function
Smart Fan Function is under “Smart Fan Control” in “Advanced Menu”.
This is a brilliant feature to control CPU/System Temperature vs. Fan speed.
When enabling Smart Fan function, Fan speed is controlled automatically by
CPU/System temperature.
This function will protect CPU/System from overheat problem and maintain the
system temperature at a safe level.
Main Advanced
> PCI Subsystem Settings
> ACPI Settings/WakeUp Event control
> CPU Configuration
> SATA Configuration
> USB Configuration
> SMART FAN Control
> Super IO Configuration
> H/W Monitor
Chip set Boo t
BIOS SETUP UTILIT
Security O.N.E Save & Exit
SMART FAN Control
24
Sele ct Sc re en
Sele ct It em
Ente r
Sele ct
+/-
Chan ge Op t.
F1
General Help
Optimized Defaults
F3
Save & Re set
F4
ESC
Exit
Version x.xx.xxxx. Copyright© 201x, American Megatrends, Inc.
↓
TH67+/TH67/TH67B
Advanced
SMART FAN Control
CPU Smart FAN [Disabled]
> CPU FAN Calibrate
Control Mode [Manual]
FAN Ctrl OFF( C)
FAN Ctrl ON( C)
FAN Ctrl Start value
FAN Ctrl Sensitive
o
o
Version x.xx.xxxx. Copyright© 201x, American Megatrends, Inc.
BIOS SETUP UTILITY
CPU FAN Smart control
function. [Disabled]: Full ON
[Auto]:By parameters below.
Sele ct Scre en
Sele ct Item
Sele ct
Ente r
Chan ge Opt.
+/-
General Help
F1
Optimized Defaults
F3
Save & Re set
F4
ESC
Exit
CPU Smart FAN
This item allows you to control the CPU Smart Fan function.
CPU FAN Calibrate
Press [ENTER] to calibrate CPU FAN.
Control Mode
This item provides several operation modes of the fan.
Fan Ctrl OFF(℃)
When CPU temperature is lower than this value, the CPU fan will keep
lowest RPM. The range is from 0~127, with an interval of 1.
Fan Ctrl On(℃)
When CPU temperature is higher than this value, the CPU fan controller
will turn on. The range is from 0~127, with an interval of 1.
Fan Ctrl Start Value
This item sets CPU FAN Start Speed Value. T he range is from 0~127, with
an interval of 1.
Fan Ctrl Sensitive
The bigger the numeral is, the higher the FAN speed is. The range is from
0~127, with an interval of 1.
25
Motherboard Manual
5.2 T-SERIES SOFTWARE
Installing T-Series Software
1. Insert the Setup CD to the optical drive. The driver installation program
would appear if the Auto-run function has been enabled.
2. Select Software Installation, and then click on the respective software
title.
3. Follow the on-screen instructions to complete the installation.
Launching T-Series Software
After the installation process is completed, you will see the software icon
showing on the desktop. Double-click the icon to launch it.
TOverclocker
TOverclocker presents a simple Windows-based system performance
enhancement and manageability utility. It features several powerful and easy
to use tools such as Overclocking for enhancing system performance, also for
special enhancement on CPU and Memory. Smart-Fan management and PC
health are for monitoring system status. This utility also allows you to make
overclocking profiles saving unlimitedly, and pre-set OC modes are for easy
OC. (The illustration below is for reference only)
26
TH67+/TH67/TH67B
The CPU tab provides information on the CPU and motherboard.
The Memory tab provides information on the memory module(s).
You can select memory module on a specific slot to see its information.
The OC Tweaker tab allows you to change system clock settings and voltages
settings. It also provides six pre-set modes for you:
27
Motherboard Manual
3 Pre-set Modes: V6, V12, AUTO for different overclocking experience.
The HW Monitor tab allows you to monitor hardware voltage, fan speed, and
temperature. Besides, you also can set related values for CPU Smart Fan.
28
TH67+/TH67/TH67B
Pressing TOVERCLOCKER logo
displays information about
manufacturer and software version.
You can update current ver sion by
clicking the button “Live Update.”
Green Power II Utility
BIOSTAR G.P.U II (Green Power Utility) is a new function. The utility enhances
energy efficiency by disabling extra phases while CPU is on light loading; it
features 4+1 power phases, current power saving, and toal power saving. This
tool integrates a friendly GUI to monitor your CPU Usage, CPU Watt, and CPU
Temperature. Moreover, it optimizes power saving and best power efficiency
on your system. (The illustration below is for reference only)
Display manufacturer &
Typical Mode
software version information
Performance
Mode
Medium Mode
Maxi-Energy Mode
Auto Phase Mode
Re set T ime &
Consum ption
Display CPU
information
29
Motherboard Manual
G.P.U Mode Setting
This utility provides five modes, upon your requirements, to improve
system performance or to save power consumption.
Note: Even if the modes saving more power consumption are chosen, the
system still can keep excellent performance.
Auto Phase Mode
System switches the mode automatically according to current system
loading condition.
Performance Mode
This is the mode saving power consumption most. Least energy will
be used in the system.
Typical Mode
Compared with that in Performance Mode, energy consumption in this
mode is a little bit more.
Medium Mode
This is the standard system power saving mode.
Maxi-Energy Mode
This is the best system performance mode.
30
TH67+/TH67/TH67B
e
eHot-Line (Optional)
eHot-Line is a convenient utility that helps you to contact with our
Tech-Support system. This utility will collect the system information which is
useful for analyzing the problem you may have encountered, and then send
these information to our tech-support department to help you fix the problem.
Before you use this uti lity, please set Outlook Express as yo ur default e-mail clie nt application program.
rep resents important
*
information t hat you
must provi de. Withou t
this informat ion, you may
not be able to send ou t
the mail.
This block will show
the infor mation which
would be collected in
the mail.
Send the mail ou t.
Describe co ndition
*
of your syst em.
Save these information to a .txt fil
Exit this dialog.
Select your area or
*
the area clos e to yo u.
Provid e the e-mail
addres s that you woul d
like to send the copy to.
Provide t he name of
*
the memory module
manufactu rer.
Provid e the name of
the power supply
manufac turer and the
model no .
After filling up this information, click “Send”
to send the mail out. A warning dialog would
appear asking for your confirmation; click
“Send” to confirm or “Do Not Send” to cancel.
If you want to save this information to a .txt file, click “Save As…” and then you
will see a saving dialog appears asking you to enter file name.
31
Motherboard Manual
Enter the file name and then click
“Save”. Your system information
will be saved to a .txt file.
We will not share customer ’s data with any other third parties,
so please feel free to provide your system information while using
eHot-Line service.
Open the saved .txt file, you will see
your system information including
motherboard/BIOS/CPU/video/
device/OS information. This
information is also concluded in the
sent mail.
32
If you are not using Outlook Express as your default e-mail client
application, you may need to save the system information to a .txt file
and send the file to our tech support with other e-mail application.
TH67+/TH67/TH67B
BIOS Update
BIOS Update is a convenient utility which allows you to update your
motherboard BIOS under Windows system.
AWARD BIOS AMI BIOS
Clear CMOS function
(Only for AWARD BIOS)
Show current BIOS information
Save cur rent B IOS
to a .bin file
Update BIOS
with a BIOS file
<Backup BIOS>
Once click on this button, the saving
dialog will show. Choose the
position to save file and enter file
name. (We recommend that the file
name should be English/number
and no longer than 7 characters.)
Then click Save.
33
Motherboard Manual
<Update BIOS>
Before doing this, please download the proper BIOS file from the website.
For AWARD BIOS, update BIOS procedure
should be run with Clear CMOS function, so
please check on Clear CMOS first.
Then click Update BIOS button, a
dialog will show for asking you backup
current BIOS. Click Yes for BIOS
backup and refer to the Backup BIOS
procedure; or click No to skip this
procedure.
After the BIOS Backup procedure, the
open dialog will show for requesting the
BIOS file which is going to be updated.
Please choose the proper BIOS file for
updating, then click on Open.
The utility will update BIOS with the
proper BIOS file, and this process may
take minutes. Please do not open any
other applications during this process.
After the BIOS Update process, click on
OK to restart the system.
While the system boots up and the full screen logo shows, press <Delete>
key to enter BIOS setup.
In the BIOS setup, use the Load Optimized Defaults function and then Save and
Exit Setup to exit BIOS setup. B IOS Update is completed.
All the information and content above about the T-Series software are subject to be
changed without notice. For better performance, the software is being continuously
updated. The information and pictures described above are for your reference only.
The actual i nformation and settings on board may be slightly different from this
manual.
34
TH67+/TH67/TH67B
BIOScreen Utility (Optional)
This utility allows you to personalize your boot logo easily. You can choose
JPG or BMP as your boot logo so as to customize your computer.
Please follow the following instructions to update boo logo:
1. Load Image：Choose the picture as the boot logo.
2. Transform：Transform the picture for BIOS and preview the result.
3. Update Bios：Write the picture to BIOS Memory to complete the update.
35
Motherboard Manual
CHAPTER 6: USEFUL HELP
6.1 D
RIVER INSTALLATION NOTE
After you installed your operating system, please insert the Fully Setup
Driver CD into your optical drive and install the driver for better system
performance.
You will see the following window after you insert the CD
The setup guide will auto detect your motherboard and operating system.
Note:
If this window didn’t show up after you insert the Driver CD, please use file browser to
locate and execute the file SETUP.EXE under your optical drive.
A. Driver Installation
To install the driver, please click on the Driver icon. The setup guide will
list the compatible driver for your motherboard and operating system.
Click on each device driver to launch the installation program.
B. Software Installation
To install the software, please click on the Software icon. The setup guide
will list the software available for your system, click on each software title
to launch the installation program.
C. Manual
Aside from the paperback manual, we also provide manual in the Driver
CD. Click on the Manual icon to browse for available manual.
Note:
You will need Acrobat Reader to open the manual file. Please download the latest version
of Acrobat Reader software from
http://www.adobe.com/products/acrobat/readstep2.html
36
6.2 EXTRA INFORMATION
CPU Overheated
If the system shutdown automatically after power on system for
seconds, that means the CPU protection function has been activated.
When the CPU is over heated, the motherboard will shutdown
automatically to avoid a damage of the CPU, and the system may not
power on again.
In this case, please double check:
1. The CPU cooler surface is placed evenly with the CPU surface.
2. CPU fan is rotated normally.
3. CPU fan speed is fulfilling with the CPU speed.
After confirmed, please follow steps below to relief the CPU protection
function.
1. Remove the power cord from power supply for seconds.
2. Wait for seconds.
3. Plug in the power cord and boot up the system.
Or you can:
1. Clear the CMOS data.
(See “Close CMOS Header: JCMOS1” section)
2. Wait for seconds.
3. Power on the system again.
TH67+/TH67/TH67B
37
Motherboard Manual
6.3 TROUBLESHOOTING
Probable Solution
1. There is no power in the system.
Power LED does not shine; the
fan of the power supply does not
work
2. Indicator light on keyboard does
not shine.
System is inoperative. Keyboard lights
are on, power indicator lights are lit,
and hard drives are running.
System does not boot from a hard disk
drive, but can be booted from optical
drive.
System only boots from an optical
drive. Hard disks can be read,
applications can be used, but system
fails to boot from a hard disk.
Screen message shows “Invalid
Configuration” or “CMOS Failure.”
System cannot boot after user installs a
second hard drive.
1. Make sure power cable is
securely plugged in.
2. Replace cable.
3. Contact technical support.
Using even pressure on both ends of
the DIMM, press down firmly until the
module snaps into place.
1. Check cable running from disk to
disk controller board. Make sure
both ends are securely plugged
in; check the drive type in the
standard CMOS setup.
2. Backing up the hard drive is
extremely important. All hard
disks are capable of breaking
down at any time.
1. Back up data and applications
files.
2. Reformat the hard drive.
Re-install applications and data
using backup disks.
Review system’s equipment. Make sure
correct information is in setup.
1. Set master/slave jumpers
correctly.
2. Run SETUP program and select
correct drive types. Call the drive
manufacturers for compatibility
with other drives.
38
TH67+/TH67/TH67B
This page is intentionally left blank.
39
Motherboard Manual
APPENDIX: SPEC IN OTHER LANGUAGES
G
ERMAN
TH67+ / TH67 TH67B
CPU
Chipsatz
Super E/A
Arbeitsspeich
er
SATA 2 & 3
LAN
HD
Audio-Unters
tützung
USB3.0
Steckplätz e
40
Socket 1155
Int e l Core i7 / i5 / i3 / Pentiu m Prozes soren
Unterstützt Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technology
Intel H67 Intel H67
ITE 8728
Biet et die h äuf ig v erwend eten a lten S up er
E/A-Funktionen.
Low Pin Count-Schnittstelle
Umgebungskontrolle,
Hardware-Überwachung
Lüfterdrehzahl-Controller/-Überwachung
"Smart Guardian"-Funktion von ITE
DDR3 DIMM-Steckplätze x 4
Jeder DIMM unterstützt 512MB / 1GB / 2GB /
4GB DDR3.
Max. 16GB Arbeitsspeicher
Dual-Kanal DDR3 Speichermodul
Unterstützt DDR3 1333/1066
registrierte DIMMs. ECC DIMMs werden nicht
unterstützt.
Integrierter Serial ATA-Controller
Datentransferrate bis zu 3.0Gb/s / 6.0 Gb/s
Konform mit der SATA-Spezifikation Version 2.0
/ 3.0.
Realtek RTL8111E
10 / 100 / 1000 Mb/s Auto-Negotiation
ALC892
Unterstützt High-Definition Audio
5.1-Kanal-Audioausgabe
NEC uPD720200 / Asmedia ASM1042
PCI-Steckp latz x1 PCI-Steckp lat z x1
PCI-E Gen2 x 16 @ x16 Steckplatz x1 PCI-E Gen2 x 16 @ x16 Steckplatz x1
PCI-E Gen2 x 16 @ x4 Steckplatz x1 PCI-E Gen2 x 16 @ x4 Steckplatz x1
PCI-E Gen2 x1-Steckplatz x1 PCI-E Gen2 x1-Steckplatz x1
Socket 1155
Int e l Core i7 / i5 / i3 / Pentiu m Prozes soren
Unterstützt Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technology
ITE 8728
Biet et die h äuf ig v erwend eten a lten S up er
E/A-Funktionen.
Low Pin Count-Schnittstelle
Umgebungskontrolle,
Hardware-Überwachung
Lüfterdrehzahl-Controller/-Überwachung
"Smart Guardian"-Funktion von ITE
DDR3 DIMM-Steckplätze x 4
Jeder DIMM unterstützt 512MB / 1GB / 2GB /
4GB DDR3.
Max. 16GB Arbeitsspeicher
Dual-Kanal DDR3 Speichermodul
Unterstützt DDR3 1333/1066
registrierte DIMMs. ECC DIMMs werden nicht
unterstützt.
Integrierter Serial ATA-Controller
Datentransferrate bis zu 3.0Gb/s / 6.0 Gb/s
Konform mit der SATA-Spezifikation Version 2.0
/ 3.0.
Realtek RTL8111E
10 / 100 / 1000 Mb/s Auto-Negotiation
ALC892
Unterstützt High-Definition Audio
5.1-Kanal-Audioausgabe
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Serieller Anschluss x1 Serieller Anschluss x1
SATA 3-Anschluss x2 SATA 3-Anschluss x2
SATA 2-Anschluss x4 SATA 2-Anschluss x4
Fronttafelanschluss x1 Fronttafelanschluss x1
Front-Audioanschluss x1 Front-Audioanschluss x1
Onboard-Ans
chluss
Rückseiten-E
/A
Platinengröße
OS-Unterstüt
zung
S/PDIF- Ausgangsanschluss x1 S/PDIF- Ausgangsanschluss x1
CPU-Lüfter-Sockel x1 CPU-Lüfter-Sockel x1
System-Lüfter-Sockel x2 System-Lüfter-Sockel x2
"CMOS löschen"-Sockel x1 "CMOS löschen "-Sockel x1
USB 2.0-Anschluss x3 USB 2.0-Anschluss x3
Verbraucher-IR Anschluss x1 Verbraucher-IR Anschluss x1
Stromanschluss (24-polig) x1 Stromanschluss (24-polig) x1
St romansch luss (8-p o lig) x 1 St romans chlu s s (4-po l ig ) x1
PS/2-Tastatur / Maus x1
HDMI-Anschluss x1
VGA-Anschluss x1
DVI-D-Anschluss x1
LAN-Anschluss x1
USB 2.0-Anschluss (durch H67) x2
USB 3.0-Anschluss
(durch NEC uPD720200 /
Asmedia ASM1042) x2
Audioanschluss x3
230mm (B) X 244 mm (L) 230mm (B) X 244 mm (L)
Windows XP / Vista / 7
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstützung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
PS/2-Tastatur / Maus x1
HDMI-Anschluss x1
VGA-Anschluss x1
DVI-D-Anschluss x1
LAN-Anschluss x1
USB 2.0-Anschluss x4
Audioanschluss x3
Windows XP / Vista / 7
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstützung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
41
Motherboard Manual
FRENCH
TH67+ / TH67 TH67B
Socket 1155
Pro c esseur s Intel Co re i7 / i5 / i3 / Pent iu m
Prend en ch arge les t echnologies d'exécut ion de
bit de désactivation / Intel SpeedStep®
opt imisée/ d ' arch it e ct ure In t el 64 / de mémo ir e
étendue 64 / de virtualisat ion
ITE 8728
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Int e rfa ce à faib le co mpt e d e b roches
Initiatives de contrôle environnementales,
Mon iteur d e mat ériel
Contrôleur /moniteur de vitesse de ventilateur
Fonction "Gardien intelligent" de l'ITE
Fentes DDR3 DIMM x 4
Chaque DIMM prend en charge des DDR3 de
512Mo / 1Go / 2Go / 4Go
Capacit é mé mo ir e max imal e de 16Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3 1333/1066
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charg e
Contrô leur Serial ATA int é gr é
Taux de transfert jusqu'à 3.0Go/s / 6.0 Gb/s.
Co nfo rme à la sp éc ificat ion SATA Vers io n 2.0 /
3.0
Realtek RTL8111E
10 / 100 / 1000 Mb/s négociation automatique
ALC892
Prise en charg e de l'aud io haute déf inition
Sortie aud io à 5 .1 vo ies
UC
Chipset
Super E/S
Mémoire
principale
SATA 2 & 3
LAN
Prise en
charg e audio
HD
USB3.0
Fentes
Socket 1155
Pro c esseur s Intel Co re i7 / i5 / i3 / Pent iu m
Prend en ch arge les t echnologies d'exécut ion de
bit de désactivation / Intel SpeedStep®
opt imisée/ d ' arch it e ct ure In t el 64 / de mémo ir e
étendue 64 / de virtualisat ion
Intel H67 Intel H67
ITE 8728
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Int e rfa ce à faib le co mpt e d e b roches
Initiatives de contrôle environnementales,
Mon iteur d e mat ériel
Contrôleur /moniteur de vitesse de ventilateur
Fonction "Gardien intelligent" de l'ITE
Fentes DDR3 DIMM x 4
Chaque DIMM prend en charge des DDR3 de
512Mo / 1Go / 2Go / 4Go
Capacit é mé mo ir e max imal e de 16Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3 1333/1066
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charg e
Contrô leur Serial ATA int é gr é
Taux de transfert jusqu'à 3.0Go/s / 6.0 Gb/s.
Co nfo rme à la sp éc ificat ion SATA Vers io n 2.0 /
3.0
Realtek RTL8111E
10 / 100 / 1000 Mb/s négociation automatique
ALC892
Prise en charg e de l'aud io haute déf inition
Sortie aud io à 5 .1 vo ies
NEC uPD720200 / Asmedia ASM1042
Fente PCI x1 Fente PCI x1
Fente PCI-E Gen2 x 16 @ x16 x1 Fente PCI-E Gen2 x 16 @ x16 x1
Fente PCI-E Gen2 x 16 @ x4 x1 Fente PCI-E Gen2 x 16 @ x4 x1
Fente PCI-E Gen2 x1 x1 Fente PCI-E G en2 x1 x1
42
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Port série x1 Port série x 1
Connecteur SATA 3 x2 Connecteur SATA 3 x2
Connecteur SATA 2 x4 Connecteur SATA 2 x4
Connecteur du panneau avant x1 Connecteur du panneau avant x1
Connecteur Audio du panneau avant x1 Connecteur Audio du panneau avant x1
Connecteur de sortie S/PDIF x1 Connecteur de sortie S/PDIF x1
Connecteur
embarqu é
E/S du
panneau
arrière
Dimensions
de la carte
Support SE
Embase de ventilateur UC x1 Embase de ventilateur UC x1
Embase de ventilateur système x2 Embase de ventilateur système x2
Embase d'effacement CMOS x1 Embase d'effacement CMOS x1
Connecteur USB 2.0 x3 Connecteur USB 2.0 x3
Connecteur de IR du consommateur x1 Connecteur de IR du consommateur x1
Connecteur d' aliment at ion x 1
(24 broches)
Connecteur d' aliment at ion x 1
(8 broch es)
Clavier / Souris PS/2 x1
Port HD MI x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB 2.0 (par H67) x2
Port USB 3.0 (par NEC uPD720200 /
Asmedia ASM1042) x2
Fiche aud io x 3
230mm (l) X 244 mm (H) 230mm (l) X 244 mm (H)
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de
supprimer le support de SE avec ou sans
préavis.
Connecteur d' aliment at ion x 1
(24 broches)
Connecteur d' aliment at ion x 1
(4 broch es)
Clavier / Souris PS/2 x1
Port HD MI x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB 2.0 x4
Fiche aud io x 3
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de
supprimer le support de SE avec ou sans
préavis.
43
Motherboard Manual
ITALIAN
TH67+ / TH67 TH67B
Socket 1155
Pro ces sore Int el C ore i7 / i5 / i3 / Pentium
Supporto di Execut e Disable Bit / Enhanced
Intel SpeedStep® / Architettura Intel 64 /
Tecnologia Extended Memory 64 /
Tecnologia Virtualization
ITE 8728
Fo rnis ce le funzionalit à legacy S uper I/O
usate più comunemente.
Interfaccia LPC (Low Pin Count)
Funzioni di controllo dell’ambiente:
Monitoraggio hardware
Co ntroller / Monit o raggio velocit à ventolin a
Funzione "Smart Guardian" di ITE
Alloggi DIMM DDR3 x 4
Ciascun DIMM supporta DDR3 512MB /
1GB / 2GB / 4GB
Capacità massima della memoria 16GB
Modulo di memoria DDR3 a canale doppio
Supporto di DDR3 1333/1066
DIMM registrati e DIMM ECC non sono
supportati
Co ntroller S er ia l ATA in tegrato
Velocità di trasferimento dei dati fino a
3.0Gb/s / 6.0 Gb/s.
Co mp at ibile specif iche SATA Vers io ne 2.0 /
3.0.
Realtek RTL8111E
Negoziazione automatica 10 / 100 / 1000Mb/s
ALC892
Supporto audio High-Definition (HD)
Uscita audio 5.1 canali
CPU
Chipset
Super I/O
Memor ia
principale
SATA 2 & 3
LAN
Supporto
audio HD
USB3.0
Allo g gi
Socket 1155
Pro ces sore Int el C ore i7 / i5 / i3 / Pentium
Supporto di Execut e Disable Bit / Enhanced
Intel SpeedStep® / Architettura Intel 64 /
Tecnologia Extended Memory 64 /
Tecnologia Virtualization
Intel H67 Intel H67
ITE 8728
Fo rnis ce le funzionalit à legacy S uper I/O
usate più comunemente.
Interfaccia LPC (Low Pin Count)
Funzioni di controllo dell’ambiente:
Monitoraggio hardware
Co ntroller / Monit o raggio velocit à ventolin a
Funzione "Smart Guardian" di ITE
Alloggi DIMM DDR3 x 4
Ciascun DIMM supporta DDR3 512MB /
1GB / 2GB / 4GB
Capacità massima della memoria 16GB
Modulo di memoria DDR3 a canale doppio
Supporto di DDR3 1333/1066
DIMM registrati e DIMM ECC non sono
supportati
Co ntroller S er ia l ATA in tegrato
Velocità di trasferimento dei dati fino a
3.0Gb/s / 6.0 Gb/s.
Co mp at ibile specif iche SATA Vers io ne 2.0 /
3.0.
Realtek RTL8111E
Negoziazione automatica 10 / 100 / 1000Mb/s
ALC892
Supporto audio High-Definition (HD)
Uscita audio 5.1 canali
NEC uPD720200 / Asmedia ASM1042
Allo g gio PC I x1 Allogg io PC I x 1
Allo g gio PCI-E Gen2 x 16 @ x1 6 x 1 Allo ggio PCI- E Gen2 x 16 @ x16 x1
Allo g gio PCI- E Gen2 x 16 @ x4 x 1 Allog gio PCI-E Gen2 x 16 @ x4 x 1
Alloggio PCI Express Gen2 x1 x1 Alloggio PCI Express Gen2 x1 x1
44
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Porta seriale x1 Porta seriale x1
Connettore SATA 3 x2 Connettore SATA 3 x2
Connettore SATA 2 x4 Connettore SATA 2 x4
Connettore pannello frontale x1 Connettore pannello frontale x1
Connettore audio frontale x1 Connettore audio frontale x1
Connettore output SPDIF x1 Connettore output SPDIF x1
Connettori
su scheda
I/O pannello
posteriore
Dimensioni
scheda
Sistemi
operat ivi
supportati
Co llet t o re ven tolina CPU x1 Colletto re vent o lina C PU x 1
Co llet t o re ven tolina sis t ema x 2 Co llett o re vent olina sistema x 2
Co llet t o re can ce llaz ione CMO S x1 C ollet tore cancellaz io ne CMOS x 1
Connettore USB 2.0 x3 Connettore USB 2.0 x3
Connettore IR del consumatore x1 Connettore IR del consumatore x1
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(8 pin)
Tastiera / Mouse PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DV I-D x1
Porta LA N x1
Porta USB 2.0 (da H67) x2
Porta USB 3.0 (da NEC uPD720200 /
Asmedia ASM1042) x2
Connettore audio x3
230mm (larghezza) x 244 mm (altezza) 230mm (larghezza) x 244 mm (altezza)
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(4 pin)
Tastiera / Mouse PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DV I-D x1
Porta LA N x1
Porta USB 2.0 x4
Connettore audio x3
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
45
Motherboard Manual
SPANISH
TH67+ / TH67 TH67B
Socket 1155
Pro c esado r Int e l Co r e i7 / i5 / i3 / Pent ium
Admite Bit de deshabilitación de ejecución / Intel
SpeedStep® Mejorado / Int el Architectur e- 64 /
Tecnología Extended Memory 64 / Tecnología de
virtualización
ITE 8728
Le ofrece las funcionalidades heredadas de uso
más común Súper E/S.
Interfaz de cuenta Low Pin
In iciat iv as de cont rol d e ent orn o,
Monitor hardware
Controlador/monitor de velocidad de ventilador
Función "Guardia inteligente" de ITE
Ranuras DIMM DDR3 x 4
Cada DIMM admite DDR de 512MB / 1GB / 2GB
/ 4GB
Capacidad máxima de memoria de 16GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 1333/1066
No admite DIMM registrados o DIMM
comp atib les con ECC
Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3.0 Gb/s / 6.0 Gb/s .
Co mp at ible con la ve rsió n SATA 2.0 / 3.0 .
Realtek RTL8111E
Negociación de 10 / 100 / 1000 Mb/s
ALC892
Soporte de sonido de Alta Definición
Salida de sonido de 5.1 canales
CPU
Conjunto de
chips
Súper E/S
Memoria
principal
SATA 2 & 3
Red Local
Soporte de
sonido HD
USB3.0
Ranuras
Socket 1155
Pro c esado r Int e l Co r e i7 / i5 / i3 / Pent ium
Admite Bit de deshabilitación de ejecución / Intel
SpeedStep® Mejorado / Int el Architectur e- 64 /
Tecnología Extended Memory 64 / Tecnología de
virtualización
Intel H67 Intel H67
ITE 8728
Le ofrece las funcionalidades heredadas de uso
más común Súper E/S.
Interfaz de cuenta Low Pin
In iciat iv as de cont rol d e ent orn o,
Monitor hardware
Controlador/monitor de velocidad de ventilador
Función "Guardia inteligente" de ITE
Ranuras DIMM DDR3 x 4
Cada DIMM admite DDR de 512MB / 1GB / 2GB /
4GB
Capacidad máxima de memoria de 16GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 1333/1066
No admite DIMM registrados o DIMM
comp atib les con ECC
Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3.0 Gb/s / 6.0 Gb/s .
Co mp at ible con la ve rsió n SATA 2.0 / 3.0 .
Realtek RTL8111E
Negociación de 10 / 100 / 1000 Mb/s
ALC892
Soporte de sonido de Alta Definición
Salida de sonido de 5.1 canales
NEC uPD720200 / Asmedia ASM1042
Ranura PCI X1 Ranura PCI X1
Ranura PCI-E Gen2 x16 @ x16 X1 Ranura PCI-E Gen2 x16 @ x16 X1
Ranura PCI-E Gen2 x16 @ x4 X1 Ranura PCI-E Gen2 x16 @ x4 X1
Ranura PCI-E Gen2 x 1 X1 Ranura PCI-E Gen2 x 1 X1
46
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Puert o ser ie X1 Puerto s er ie X1
Conector SATA 3 X2 Conector SATA 3 X2
Conector SATA 2 X4 Conector SATA 2 X4
Conector de panel frontal X1 Conector de panel frontal X1
Conector de sonido frontal X1 Conector de sonido frontal X1
Conector de salida S/PDIF X1 Conector de salida S/PDIF X1
Conectores
en p laca
Panel trasero
de E/S
Ta mañ o d e la
plac a
Soporte de
sistema
operativo
Cabecera de ventilador de CPU X1 Cabecera de ventilador de CPU X1
Cabecera de ventilador de sistema X2 Cabecera de ventilador de sistema X2
Cabecera de borrado de CMOS X1 Cabecera de borrado de CMOS X1
Conector USB 2.0 X3 Conector USB 2.0 X3
Conector de IR del consumidor X1 Conector de IR del consumidor X1
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(8 patillas)
Teclado / Rató n PS/2 X1
Ratón HDMI X1
Puert o VGA X1
Puerto DV I-D X1
Puerto de red local X1
Puerto USB 2.0 (por H67) X2
Puerto USB 3.0 (por NEC uPD720200 /
Asmedia ASM1042) X2
Conector de sonido X3
230mm. (A) X 244 Mm. (H) 230mm. (A) X 244 Mm. (H)
Windows XP / Vista / 7
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso
previo.
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(4 patillas)
Teclado / Rató n PS/2 X1
Ratón HDMI X1
Puert o VGA X1
Puerto DV I-D X1
Puerto de red local X1
Puert o USB 2.0 X4
Conector de sonido X3
Windows XP / Vista / 7
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso
previo.
47
Motherboard Manual
PORTUGUESE
TH67+ / TH67 TH67B
Socket 1155
Pro c essado r Intel Co re i7 / i5 / i3 / Pent ium
Suporta as tecno log ias Execute D isab le Bit /
Enhanced Intel Sp eedStep ® / Intel Arqu ite cture
-64 / Extended Memory 64 / Virtualization
ITE 8728
Proporciona as funcionalidades mais utilizadas
em t ermos da especificação Super I/O.
Interface LPC (Low Pin Count).
In iciat iv as par a cont ro lo do a mb ient e
Monitorização do hardware
Contro lador/Monitor d a velocidade d a vento inha
Função "S mart Gu ard ian" d a ITE
Ranhuras DIMM DDR3 x 4
Cada módulo DIMM suporta uma memória
DDR3 de 512 MB / 1GB / 2GB / 4GB
Capacidad e máx ima de memó r ia:16GB Mód u lo
de memória DDR3 de canal duplo
Suporta módulos DDR3 1333/1066
Os módulos DIMM registados e os DIMM ECC
não são suportados
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3.0 Gb/s
/ 6.0 Gb/s.
Co mpatib ilidad e com a especifica ção SATA
versão 2.0 / 3.0.
Realtek RTL8111E
Auto negociação de 10 / 100 / 1000 Mb/s
ALC892
Suporta a especificação High-Definition Audio
Saída de áudio de 5.1 canais
CPU
Chipset
Especificação
Super I/O
Memória
principal
SATA 2 & 3
LAN
Suporte para
áud io de a lta
definição
USB3.0
Ranhuras
Socket 1155
Pro c essado r Intel Co re i7 / i5 / i3 / Pent ium
Suporta as tecno log ias Execute D isab le Bit /
Enhanced Intel Sp eedStep ® / Intel Arqu ite cture
-64 / Extended Memory 64 / Virtualization
Intel H67 Intel H67
ITE 8728
Proporciona as funcionalidades mais utilizadas
em t ermos da especificação Super I/O.
Interface LPC (Low Pin Count).
In iciat iv as par a cont ro lo do a mb ient e
Monitorização do hardware
Contro lador/Monitor d a velocidade d a vento inha
Função "S mart Gu ard ian" d a ITE
Ranhuras DIMM DDR3 x 4
Cada módulo DIMM suporta uma memória
DDR3 de 512 MB / 1GB / 2GB / 4GB
Capacidad e máx ima de memó r ia:16GB Mód u lo
de memória DDR3 de canal duplo
Suporta módulos DDR3 1333/1066
Os módulos DIMM registados e os DIMM ECC
não são suportados
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3.0 Gb/s
/ 6.0 Gb/s.
Co mpatib ilidad e com a especifica ção SATA
versão 2.0 / 3.0.
Realtek RTL8111E
Auto negociação de 10 / 100 / 1000 Mb/s
ALC892
Suporta a especificação High-Definition Audio
Saída de áudio de 5.1 canais
NEC uPD720200 / Asmedia ASM1042
Ranhura PCI x1 Ranhura PCI x1
Ranhura PCI-E Gen2 x16 @ x16 x1 Ranhura PCI-E Gen2 x16 @ x16 x1
Ranhura PCI-E Gen2 x16 @ x4 x1 Ranhura PCI-E Gen2 x16 @ x4 x1
Ranhura PCI-E Gen2 x 1 x1 Ranhura PCI-E Gen2 x 1 x1
48
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Porta série x1 Po rta série x 1
Conector SATA 3 x2 Conector SATA 3 x2
Conector SATA 2 x4 Conector SATA 2 x4
Conector do painel frontal x1 Conector do painel frontal x1
Conector de áudio frontal x1 Conector de áudio frontal x1
Conector de saída S/PDIF x1 Conector de saída S/PDIF x1
Conectores
na placa
Entradas/Saí
das no painel
traseiro
Tamanho da
plac a
Sistemas
operativos
suportados
Conector da ventoinha da CPU x1 Conector da vento inha da CPU x1
Conector da ventoinha do sistema x2 Conector da vento inha do sistema x2
Conector para limpeza do CMOS x1 Conector para limpeza do CMOS x1
Conector USB 2.0 x3 Conector USB 2.0 x3
Conector de IR do consumidor x1 Conector de IR do consumidor x1
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(8 p inos)
Teclado / Rato PS/2 x 1
Porta HD MI x 1
Porta VGA x1
Porta DV I-D x1
Porta LA N x1
Porta USB 2.0 (por H67) x2
Porta USB 3.0 (por NEC uPD720200 /
Asmedia ASM1042) x2
Tomada de áudio x3
230mm (L) X 244 mm (A) 230mm (L) X 244 mm (A)
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Teclado / Rato PS/2 x 1
Porta HD MI x 1
Porta VGA x1
Porta DV I-D x1
Porta LA N x1
Porta USB 2.0 x4
Tomada de áudio x3
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
49
Motherboard Manual
POLISH
TH67+ / TH67 TH67B
Socket 1155
Pro c esor Intel Co re i7 / i5 / i3 / Penti um
Obsługa Execute D is able Bit / Enhan ced Inte l
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technology
Gniazda DDR3 DIMM x 4
Każde gniazdo DIMM obs ługuje moduły 512 MB
/ 1GB / 2GB / 4GB
Maks. wielkość pamięci 16GB Moduł pamięci
DDR3 z trybem podwójnego kanału
Obsługa DDR3 1333/1066
Brak obsług i Regist ered D IMM oraz ECC D IMM
ITE 8728
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H /W
Kontroler/Monitor prędkości wentylatora
Funkcja ITE "Smart Guard ian"
Zintegrowany kontroler Serial ATA
Transfer danych do 3.0 Gb/s / 6.0 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0 /
3.0.
Realtek RTL8111E
10 / 100 / 1000 Mb/s z automatyczną
negocjacją szybkości
ALC892
Obsługa H igh- D ef inition Aud io
5.1 kanałowe wyjście audio
Procesor
Chipset
Pamięć
główna
Super I/O
SATA 2 & 3
LAN
Obsługa
aud io HD
USB3.0
Gniazda
Socket 1155
Pro c esor Intel Co re i7 / i5 / i3 / Penti um
Obsługa Execute D is able Bit / Enhan ced Inte l
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technology
Intel H67 Intel H67
Gniazda DDR3 DIMM x 4
Każde gniazdo DIMM obs ługuje moduły 512 MB
/ 1GB / 2GB / 4GB
Maks. wielkość pamięci 16GB Moduł pamięci
DDR3 z trybem podwójnego kanału
Obsługa DDR3 1333/1066
Brak obsług i Regist ered D IMM oraz ECC D IMM
ITE 8728
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H /W
Kontroler/Monitor prędkości wentylatora
Funkcja ITE "Smart Guard ian"
Zintegrowany kontroler Serial ATA
Transfer danych do 3.0 Gb/s / 6.0 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0 /
3.0.
Realtek RTL8111E
10 / 100 / 1000 Mb/s z automatyczną
negocjacją szybkości
ALC892
Obsługa H igh- D ef inition Aud io
5.1 kanałowe wyjście audio
NEC uPD720200 / Asmedia ASM1042
Gniazdo PCI x1 Gniazdo PCI x1
Gniazdo PCI-E Gen2 x16 @ x16 x1 Gniazdo PCI-E Gen2 x16 @ x16 x1
Gniazdo PCI-E Gen2 x16 @ x4 x1 Gniazdo PCI-E Gen2 x16 @ x4 x1
Gniazdo PCI-E Gen2 x 1 x1 Gniazdo PCI-E Gen2 x 1 x1
50
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Port szeregowy x1 Port s zeregowy x 1
Złącze SATA 3 x2 Złącze S ATA 3 x2
Złącze SATA 2 x4 Złącze S ATA 2 x4
Złącze panela przedniego x1 Złącze panela przedniego x1
Przedn ie złącze audio x1 Prz edn ie złącze aud io x1
Złącze wyjścia S/PDIF x1 Złącze wyjścia S/PDIF x1
Złącza
wbud owan e
Back Panel
I/O
Wymiary
płyty
Obsluga
systemu
operacyjnego
Złącze główkowe wentylato ra
procesora x1
Złącze główkowe wentylato ra
systemowego x2
Złącze główkowe kasowa nia CMOS x 1 Złącze główkowe kasowa nia CMOS x 1
Złącze USB 2.0 x3 Złącze USB 2.0 x3
Złącze Konsument IR x1 Złącze Konsument IR x1
Złącze zasilania (24 pinowe) x1 Złącze zasilania (24 pinowe) x1
Złącze zas ilania (8 p ino we) x 1 Złącze z as ilania (4 p ino we) x1
Klaw iatura / Mysz PS/2 x1
Port HD MI x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB 2.0 (przez H67) x2
Port USB 3.0 (przez NEC uPD720200 /
Asmedia ASM1042) x2
Gniazdo audio x3
230mm (S) X 244 mm (W) 230mm (S) X 244 mm (W)
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego sys t emu
operacyjnego b ez powiado mienia.
Złącze główkowe wentylato ra
procesora x1
Złącze główkowe wentylato ra
systemowego x2
Klaw iatura / Mysz PS/2 x1
Port HD MI x1
Port VGA x1
Port DVI-D x1
Port LAN x1
Port USB 2.0 x4
Gniazdo audio x3
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego sys t emu
operacyjnego b ez powiado mienia.
51
Motherboard Manual
RUSSIAN
TH67+ / TH67 TH67B
CPU
(центральны
й процессор)
Набо р
микросхем
Основная
память
Super I/O
SATA 2 & 3
Локальна я
сеть
Звуко вая
поддержка
жесткого
диска
USB3.0
Слоты
Socket 1155
Процессор Inte l Co re i7 / i5 / i3 / Pent iu m
Поддержка технологий Execut e Disab le B it /
Enhanced Inte l SpeedStep® / Int el
Architecture-64 / Extend ed Memory 64
Technology / технологии виртуализация
Intel H67 Intel H67
Слоты DDR3 DIMM x 4
Каждый модуль DIMM поддерживает 512МБ /
1ГБ / 2ГБ / 4ГБ DDR3
Максимальная ёмкость памяти 16ГБ
Мод ул ь памяти с двухканальным режимом
DDR3
Поддержка DDR3 1333/1066
Не поддерживает зарегистрированные
модули DIMM and ECC DIMM
ITE 8728
Обеспечивает наиболее используемые
действующие фун кциональны е возможно сти
Super I/O.
Интерфейс с низким количеством выводов
Инициативы по охране окружающей среды,
Аппаратный монитор
Регул ятор скорости вентиля тора/ монитор
Функция ITE "Smart Guard ian"
(Интеллектуальная защита)
Встроенное последовательно е устройство
управлени я ATA
скорость передачи данных до 3.0 гигабит/с /
6.0 гигабит/с.
Соответствие спецификации SATA версия 2.0
/ 3.0.
Realtek RTL8111E
Автоматическое согласование 10 / 100 / 1000
Мб/с
ALC892
Звуко вая поддержка H igh- Def in it ion
5.1канальный звуковой выход
NEC uPD720200 / Asmedia ASM1042
Слот PCI x1 Слот PCI x1
Слот PCI-E Gen2 x16 @ x16 x1 Слот PCI-E Gen2 x16 @ x16 x1
Слот PCI-E Gen2 x16 @ x4 x1 Слот PCI-E Gen2 x16 @ x4 x1
Слот PCI-E Gen2 x 1 x1 Слот PCI-E Gen2 x 1 x1
Socket 1155
Процессор Inte l Co re i7 / i5 / i3 / Pent iu m
Поддержка технологий Execut e Disab le B it /
Enhanced Inte l SpeedStep® / Int el
Architecture-64 / Extend ed Memory 64
Technology / технологии виртуализация
Слоты DDR3 DIMM x 4
Каждый модуль DIMM поддерживает 512МБ /
1ГБ / 2ГБ / 4ГБ DDR3
Максимальная ёмкость памяти 16ГБ
Мод ул ь памяти с двухканальным режимом
DDR3
Поддержка DDR3 1333/1066
Не поддерживает зарегистрированные
модули DIMM and ECC DIMM
ITE 8728
Обеспечивает наиболее используемые
действующие фун кциональны е возможно сти
Super I/O.
Интерфейс с низким количеством выводов
Инициативы по охране окружающей среды,
Аппаратный монитор
Регул ятор скорости вентиля тора/ монитор
Функция ITE "Smart Guard ian"
(Интеллектуальная защита)
Встроенное последовательно е устройство
управлени я ATA
скорость передачи данных до 3.0 гигабит/с /
6.0 гигабит/с.
Соответствие спецификации SATA версия 2.0
/ 3.0.
Realtek RTL8111E
Автоматическое согласование 10 / 100 / 1000
Мб/с
ALC892
Звуко вая поддержка H igh- Def in it ion
5.1канальный звуковой выход
52
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
Последо вательный порт x1 Последоват ельны й порт x1
Разъ ём SATA 3 x2 Ра зъ ём SATA 3 x2
Разъ ём SATA 2 x4 Разъ ём SATA 2 x4
Разъ ём на лицевой панели x1 Разъём на лицевой панели x1
Входной звуковой разъём x1 Входной звуковой разъём x1
Разъ ём вывода для S/PDIF x1 Разъ ём вывода для S/PDIF x1
Встроенный
разъём
Задняя
панель
средств
ввода-вывод
а
Размер
панели
Поддержка
OS
Контактирующее приспособление
вентил ятора центрального процессора x1
Контактирующее приспособление
вентил ятора системы x2
Открытое контактирующее
приспособление CMOS x1
USB 2.0-разъём x3 USB 2.0-разъём x3
Разъ ём едока ИКЫЙ x1 Ра зъём едока ИКЫЙ x1
Разъ ем питания (24 вы вод) x1 Разъем питания (24 вывод) x1
Разъ ем питания (8 вывод) x1 Разъем питания (4 вы вод) x1
Клавиатура / Мышь PS/2 x1
Порт HD MI x 1
Порт VGA x1
Порт DVI-D x1
Порт LAN x1
USB 2.0-порт (по H67) x2
USB 3.0-порт (по NEC uPD720200 /
Asmedia ASM1042) x2
Гнездо для подключения
наушников x3
230мм (Ш) X 244 мм (В) 230мм (Ш) X 244 мм (В)
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять
или удалять средства обеспечения для OS с
или без предварительного уведомления.
Контактирующее приспособление
вентил ятора центрального процессора x1
Контактирующее приспособление
вентил ятора системы x2
Открытое контактирующее
приспособление CMOS x1
Клавиатура / Мышь PS/2 x1
Порт HD MI x 1
Порт VGA x1
Порт DVI-D x1
Порт LAN x1
USB 2.0-порт x4
Гнездо для подключения
наушников x3
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять
или удалять средства обеспечения для OS с
или без предварительного уведомления.
53
Motherboard Manual
ARABIC
TH67B TH67+ / TH67
Socket 1155
تﺎﺠﻟﺎﻌﻣIntel Cor e i7 / i5 / i3/ Pent iu m ﺑ ددﺮﺘ ﻳ ﻰﻟإ ﻞﺼ
تﺎﻴﻨﻘﺕ ﻢﻋﺪﺕExecute D isable B it / Enhanced Int el
SpeedStep® / Intel Architecture- 64 / Ext end ed
Memory 64 Technology / Virtualization
Technology
Intel H67 Intel H67
ﺔﺤﺘﻓDDR3 DIM M دﺪﻋ4
ﺔﺤﺘﻓ ﻞآ ﻢﻋﺪﺕDIMM عﻮﻥ ﻦﻣ ةﺮآاذ ﻢﻋﺪﺕ DDR3 ﺔﺤﺘﻓ ﻞآ ﻢﻋﺪﺕ ﺔﻌﺳ
DIMM عﻮﻥ ﻦﻣ ةﺮآاذ ﻢﻋﺪﺕ DDR3 ﺔﻌﺳ
عﻮﻥ ﻦﻣ ةﺮآاﺬﻟا ﻢﻋﺪﺕDDR3 تﺎﻌﺳ 1066/1333ﺖﻳﺎﺑ ﺎﺠﻴﻣ
ةﺮآاﺬﻟا ﻖﺋﺎﻗر ﻢﻋﺪﺕ ﻻDIMM ﻊﻣ ﻖﻓاﻮﺘﺕ ﻻ ﻲﺘﻟا ﻚﻠﺕو ECC
ﺔﻔﻴﻇ و ﺮﻓﻮﺕSuper I/O ًﺎﻣ ا ﺪ ﺨ ﺘ ﺳ ا ﺮﺜآﻷا .
ﺔﻔﻴﻇو"S mart Guardian" ﻦﻣ IT E
ﻞﻘﻧ تﺎﻧﺎﻴﺒﻟا تﺎﻋﺮﺴﺏ ﻞﺼﺕ ﻰﻟإ 3.0 ﺖﺏﺎﺠﻴﺟ/ ﺔﻴﻧﺎﺛ /
512 و ﺖﻳﺎﺑ ﺎﺠﻴﻣ 1/و 2/
ةﺮآاذ ةﺪﺣوDDR3 ﻘﻟا ﺔﺝودﺰﻣةﺎﻨ
ITE 8728
ﺕﻢﻋﺪ ﺔﻴﻨﻘﺕ Low Pin Co unt Interface
ﺔﺌﻴﺒﻟا ﻲﻓ ﻢﻜﺤﺘﻟا ﻞﺋﺎﺳو:
ةﺰﻬﺝﻷا ﺔﻟﺎﺣ ﺔﻓﺮﻌﻤﻟ ﺐﻗاﺮﻣ
ﺔﺣوﺮﻤﻟا ﺔﻋﺮﺳ ﻲﻓ ﺐﻗاﺮﻣ
ﻢﻜﺤﺘﻣ Serial ATA ﻞﻣﺎﻜﺘﻣ
6.0 ﺖﺏﺎﺠﻴﺟ/ ﺔﻴﻧﺎﺛ
ﺔﻘﺏﺎﻄﻣ تﺎﻔﺹاﻮﻤﻟ SATA راﺪﺹﻹا 2.0 / 3.0.
Realtek RTL8111E
ﻲﺋﺎﻘﻠﺕ ضو ﺎﻔﺕ10/100 ﺖﻳﺎﺑ ﺎﺠﻴﻣ /و ﺔﻴﻥﺎﺙ1ﺖﺑ ﺎﺠﻴﺝ/ﺔﻴﻥﺎﺙ
ALC892
ﻦﻣ ﻒﻳﺮﻌﺘﻟا ﻲﻟ ﺎﻋ تﻮﺼﻟا ﺔﻴﻨﻘﺕ ﻢﻋﺪﺕ
5.1 تﻮﺼﻟا جﺮﺨﻟ تاﻮﻨﻗ
ﺔﺤﺘﻓPCI دﺪﻋ1 ﺔﺤﺘﻓPCI دﺪﻋ1
ﺔﺤﺘﻓPCI-E Gen2 x16 @ x16 دﺪﻋ1 ﺔﺤﺘﻓPCI-E Gen2 x16 @ x16 دﺪﻋ1
ﺔﺤﺘﻓPCI-E Gen2 x16 @ x4 دﺪﻋ1 ﺔﺤﺘﻓPCI-E Gen2 x16 @ x4 دﺪﻋ1
ﺔﺤﺘﻓPC I-E Ge n2 x 1 دﺪﻋ1 ﺔﺤﺘﻓPC I-E Ge n2 x 1 دﺪﻋ1
Socket 1155
تﺎﺠﻟﺎﻌﻣIntel Cor e i7 / i5 / i3/ Pent iu m ﺑ ددﺮﺘ ﻳ ﻰﻟإ ﻞﺼ
تﺎﻴﻨﻘﺕ ﻢﻋﺪﺕExecute D isable B it / Enhanced Int el
SpeedSt ep® / Intel Architecture-64 / Extend ed
Memory 64 Technology / Virtualization
Technology
ﺔﺤﺘﻓ ﻞآ ﻢﻋﺪﺕDIMM عﻮﻥ ﻦﻣ ةﺮآاذ ﻢﻋﺪﺕ DDR3 ﺔﺤﺘﻓ ﻞآ ﻢﻋﺪﺕ ﺔﻌﺳ
DIMM ﻣ ةﺮآاذ ﻢﻋﺪﺕ عﻮﻥ ﻦ DDR3 ﺔﻌﺳ
و4 ﺎﺠﻴﺝﺖﻳﺎﺑ
ﻌﺳ ىﻮﺼﻗ ةﺮآاذ ﺔ16 ﺖﻳﺎﺑ ﺎﺠﻴﺝ
عﻮﻥ ﻦﻣ ةﺮآاﺬﻟا ﻢﻋﺪﺕDDR3 تﺎﻌﺳ 1066/1333ﺖﻳﺎﺑ ﺎﺠﻴﻣ
ةﺮآاﺬﻟا ﻖﺋﺎﻗر ﻢﻋﺪﺕ ﻻDIMM ﻊﻣ ﻖﻓاﻮﺘﺕ ﻻ ﻲﺘﻟا ﻚﻠﺕو ECC
ﺔﻔﻴﻇ و ﺮﻓﻮﺕSuper I/O ًﺎﻣ ا ﺪ ﺨ ﺘ ﺳ ا ﺮﺜآﻷا .
ﺔﻔﻴﻇو"S mart Guardian" ﻦﻣ IT E
ﻖﻧل تﺎﻧﺎﻴﺒﻟا تﺎﻋﺮﺴﺏ ﻞﺼﺕ ﻰﻟإ 3.0 ﺖﺏﺎﺠﻴﺟ/ ﺔﻴﻧﺎﺛ /
NEC uPD720200 / Asmedia ASM1042
512 و ﺖﻳﺎﺑ ﺎﺠﻴﻣ 1/و 2/
ىﻮﺼﻗ ةﺮآاذ ﺔﻌﺳ16 ﺖﻳﺎﺑ ﺎﺠﻴﺝ
ةﺮآاذ ةﺪﺣوDDR3 ﻘﻟا ﺔﺝودﺰﻣةﺎﻨ
ITE 8728
ﺕﻢﻋﺪ ﺔﻴﻨﻘﺕ
Low Pin Co unt Interface
ﻢﻜﺤﺘﻟا ﻞﺋﺎﺳوﺔﺌﻴﺒﻟا ﻲﻓ :
ةﺰﻬﺝﻷا ﺔﻟﺎﺣ ﺔﻓﺮﻌﻤﻟ ﺐﻗاﺮﻣ
ﺔﺣوﺮﻤﻟا ﺔﻋﺮﺳ ﻲﻓ ﺐﻗاﺮﻣ
ﻢﻜﺤﺘﻣ Serial ATA ﻞﻣﺎﻜﺘﻣ
6.0 ﺖﺏﺎﺠﻴﺟ/ ﺔﻴﻧﺎﺛ
ﺔﻘﺏﺎﻄﻣ تﺎﻔﺹاﻮﻤﻟ SATA راﺪﺹﻹا 2.0 / 3.0.
Realtek RTL8111E
ﻲﺋﺎﻘﻠﺕ ضو ﺎﻔﺕ10/100 ﺖﻳﺎﺑ ﺎﺠﻴﻣ /و ﺔﻴﻥﺎﺙ1ﺖﺑ ﺎﺠﻴﺝ/ﺔﻴﻥﺎﺙ
ALC892
ﻦﻣ ﻒﻳﺮﻌﺘﻟا ﻲﻟ ﺎﻋ تﻮﺼﻟا ﺔﻴﻨﻘﺕ ﻢﻋﺪﺕ
ﺔﺤﺘﻓDDR3 DIM M دﺪﻋ4
5.1 تﻮﺼﻟا جﺮﺨﻟ تاﻮﻨﻗ
و4 ﺎﺠﻴﺝﺖﻳﺎﺑ
SATA 2 & 3
ةﺪﺣو ﺔﺠﻟﺎﻌﻤﻟا
ﺔﻳﺰآﺮﻤﻟا
ﺔﻋﻮﻤﺠﻣ ﺢﺋاﺮﺸﻟا
ةﺮآاﺬﻟا ﺔﻴﺴﻴﺋﺮﻟا
Super I/O
ﺔﻜﺒﺷ ﺔﻴﻠﺧاد
ﻢﻋد تﻮﺼﻟا ﻲﻟﺎﻋ
ﻒیﺮﻌﺘﻟا
USB3.0
تﺎﺤﺘﻔﻟا
54
ﻆﻔﺘﺤﺕ Biostar ﺎﻬﻘﺤﺏ ﻲﻓ ﺔﻓ ﺎﺿإ وأ ﺔﻟازإ ﻢﻋﺪﻟا يﻷ مﺎﻈﻧ ﻞﻴﻐﺸﺕ رﺎﻄﺧﺈﺏ
TH67+/TH67/TH67B
TH67B TH67+ / TH67
ﻲﻠﺴﻠﺴﺕ ﺬﻔﻨﻣ دﺪﻋ1 ﻲﻠﺴﻠﺴﺕ ﺬﻔﻨﻣ دﺪﻋ1
ﺬﻔﻨﻣSATA 3 دﺪﻋ2 ﺬﻔ ﻨﻣSATA 3 ﺪﻋ د2
ﺬﻔﻨﻣSATA 2 دﺪﻋ4 ﺬﻔ ﻨﻣSATA 2 دﺪﻋ4
ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮ ﻠﻟا ﺬﻔﻨﻣ دﺪﻋ1 ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮ ﻠﻟا ﺬﻔﻨﻣ دﺪﻋ1
ﻲﻣﺎﻣﻷا تﻮﺼﻟا ﺬﻔﻨﻣ دﺪﻋ1 ﻲﻣﺎﻣﻷا تﻮﺼﻟا ﺬﻔﻨﻣ دﺪﻋ1
جﺮﺥ ﺬﻔﻨﻣS/PDIF دﺪﻋ1 جﺮﺥ ﺬﻔﻨﻣS/PDIF دﺪﻋ1
ﺔﻳﺰآﺮﻤﻟا ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو ﺔﺣوﺮﻣ ﺔﻠﺹو دﺪﻋ1 ﺣوﺮﻣ ﺔﻠﺹوﺔﻳﺰآﺮﻤﻟا ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو ﺔ دﺪﻋ1
مﺎﻈﻨﻟا ﺔﺣوﺮﻣ ﺔﻠﺹو دﺪﻋ2 مﺎﻈﻨﻟا ﺔﺣوﺮﻣ ﺔﻠﺹو دﺪﻋ2
ﺢﺴﻣ ﺔﻠﺹوCMOS دﺪﻋ1 ﺢﺴ ﻣ ﺔﻠﺹوCMOS دﺪﻋ1
ﺬﻔﻨﻣUSB 2.0 دﺪﻋ3 ﺬﻔ ﻨﻣUSB 2.0 دﺪﻋ3
ﺬﻔﻨﻣ ﺔﻜﻠﻬﺘﺴﻣ ﺖﺤﺕ ﺮﻤﺣﻷا دﺪﻋ1 ﺬﻔﻨﻣ ﺔﻜﻠﻬﺘﺴﻣ ﺖﺤﺕ ﺮﻤﺣﻷا دﺪﻋ1
ﺔﻗﺎﻄﻟا ﻞﻴﺹﻮﺕ ﺬﻔﻨﻣ)24سﻮﺑد( دﺪﻋ1 ﺔﻗﺎﻄﻟا ﻞﻴﺹﻮﺕ ﺬﻔﻨﻣ)24سﻮﺑد( دﺪﻋ1
ﺔﻗﺎﻄﻟا ﻞﻴﺹﻮﺕ ﺬﻔﻨﻣ)4ﺲﻴﺑﺎﺑد( دﺪﻋ1 ﺔﻗﺎﻄﻟا ﻞﻴﺹﻮﺕ ﺬﻔﻨﻣ)8ﺲﻴﺑﺎﺑد( دﺪﻋ1
ﺢﻴﺕﺎﻔﻣ ﺔﺣﻮﻟ / سوﺎﻣPS/2 دﺪﻋ1
ﺢﻴﺕﺎﻔﻣ ﺔﺣﻮﻟ / سوﺎﻣPS/2 دﺪﻋ1
ﺬﻓﺎﻨﻣHDMI دﺪﻋ1
ﺬﻓﺎﻨﻣVG A دﺪﻋ1
ﺬﻓﺎﻨﻣDV I-D دﺪﻋ1
ﺔﻴﻠﺤﻣ لﺎﺼﺕا ﺔﻜﺒﺵ ﺬﻔ ﻨﻣ دﺪﻋ 1
ﺬﻓﺎﻨﻣUSB 2.0 ﻋ دﺪ4
تﻮﺹ ﺲﺒﻘﻣ دﺪﻋ3
230 ﻢﻣ)ضﺮﻋ (X 244 ﻢﻣ)عﺎﻔﺕرا( 230 ﻢﻣ)ضﺮﻋ (X 244 ﻢﻣ)عﺎﻔﺕرا(
Windows XP / Vista / 7
ﺔﻴﻠﺤﻣ لﺎﺼﺕا ﺔﻜﺒﺵ ﺬﻔ ﻨﻣ دﺪﻋ 1
(Asmedia ASM1042 ﻦﻣ ﻞﺒﻗ ) دﺪﻋ2
Windows XP / Vista / 7
ﻆﻔﺘﺤﺕ Biostar ﺎﻬﻘﺤﺏ ﻲﻓ ﺔﻓ ﺎﺿإ وأ از إﺔﻟ ﻢﻋﺪﻟا يﻷ مﺎﻈﻧ ﻞﻴﻐﺸﺕ رﺎﻄﺧﺈﺏ
وأ نوﺪﺏ رﺎﻄﺧإ.
ﺬﻓﺎﻨﻣHDMI دﺪﻋ1
ﺬﻓﺎﻨﻣVG A دﺪﻋ1
ﺬﻓﺎﻨﻣDV I-D دﺪﻋ1
ﺬﻓﺎﻨﻣ2.0US B(H67 ﻦﻣ ﻞﺒﻗ ) دﺪﻋ2
ﺬﻓﺎﻨﻣSB3.0U/NEC uPD720200
تﻮﺹ ﺲﺒﻘﻣ دﺪﻋ3
وأ نوﺪﺏ رﺎﻄﺧإ.
ﺬﻓﺎﻨﻤﻟا ﻰﻠﻋ ﺢﻄﺱ
ﺔﺡﻮﻠﻟا
ﺬﻓﺎﻨﻣ ﻞﺧد/جﺮﺧ
ﺔﺡﻮﻠﻟا ﺔﻴﻔﻠﺨﻟا
ﻢﺠﺡ ﺔﺡﻮﻠﻟا
ﻢﻋد ﺔﻤﻈﻧأ ﻞﻴﻐﺸﺘﻟا
55
Motherboard Manual
JAPANESE
TH67+ / TH67 TH67B
Socket 1155
Int e l Core i7 / i5 / i3 / Pentiu m プロセッ サ
CPU
チップセット
メインメモリ
Super I/O
SATA 2 & 3
LAN
HDオ ーディオ
のサポート
USB3.0 NEC uPD720200 / Asmedia ASM1042
スロット
Execute D isab le Bit / Enh anced Intel
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technologyをサ ポートしま す
Intel H67 Intel H67
DDR3 DIMMスロット x 4
各DIMMは 512MB / 1GB / 2GB / 4GB DDR3をサ
ポート
最大メモリ容 量16GB
デュアル チ ャン ネルモードDDR3メモリモジ ュール
DDR3 1333/1066をサ ポート
登録済みDIMMとECC DIMMはサポ ート されません
ITE 8728
もっとも一般 に使 用されるレ ガシーSuper I/O機能を
採用していま す。
低ピンカウン トイ ンターフェ イス
環境コントロ ール イニシアチ ブ、
H/Wモニター
ファン速度コ ント ローラ/ モニター
ITE の「スマート ガー ディアン」 機能
統合シリアルATA コントロー ラ
最高3.0 Gb/秒 / 6.0 Gb/秒のデー タ転送 速度
SATAバージョン2.0 / 3.0仕様に準拠 。
Realtek RTL8111E
10 / 100 / 1000 Mb/秒のオート ネゴシ エーション
ALC892
ハイデフィニ ショ ンオーディ オのサポー ト
5.1 チ ャンネルオ ーディ オアウト
PCIスロット x1 PCIスロット x1
PCI-E Gen2 x16 @ x16スロット x1 PCI-E Gen2 x16 @ x16スロット x1
PCI-E Gen2 x16 @ x4ス ロット x1 PCI-E Gen2 x16 @ x4スロット x1
PCI Express Gen2 x 1スロット x1 PCI Express Gen2 x 1スロット x1
Socket 1155
Int e l Core i7 / i5 / i3 / Pentiu m プロセッ サ
Execute D isab le Bit / Enh anced Intel
SpeedStep® / Intel Architect ure- 64 / Extended
Memory 64 Technology / Virtualization
Technologyをサ ポートしま す
DDR3 DIMMスロット x 4
各DIMMは 512MB / 1GB / 2GB / 4GB DDR3をサ
ポート
最大メモリ容 量16GB
デュアル チ ャン ネルモードDDR3メモリモジ ュール
DDR3 1333/1066をサ ポート
登録済みDIMMとECC DIMMはサポ ート されません
ITE 8728
もっとも一般 に使 用されるレ ガシーSuper I/O機能を
採用していま す。
低ピンカウン トイ ンターフェ イス
環境コントロ ール イニシアチ ブ、
H/Wモニター
ファン速度コ ント ローラ/ モニター
ITE の「スマート ガー ディアン」 機能
統合シリアルATA コントロー ラ
最高3.0 Gb/秒 / 6.0 Gb/秒のデー タ転送 速度
SATAバージョン2.0 / 3.0仕様に準拠 。
Realtek RTL8111E
10 / 100 / 1000 Mb/秒のオート ネゴシ エーション
ALC892
ハイデフィニ ショ ンオーディ オのサポー ト
5.1 チ ャンネルオ ーディ オアウト
56
TH67+/TH67/TH67B
TH67+ / TH67 TH67B
シリアルポー ト x1 シリアルポー ト x1
SATA 3コネクタ x2 SATA 3コネクタ x2
SATA 2コネクタ x4 SATA 2コネクタ x4
フロントパネ ルコ ネクタ x1 フロン トパネルコ ネクタ x1
フロントオー ディ オコネクタ x1 フロン トオーディ オコネ クタ x1
オンボードコ
ネクタ
背面パネル I/O
ボードサイズ
OSサポー ト
S/PDIFアウトコネ クタ x1 S/PDIFアウトコネ クタ x1
CPUファンヘッダ x1 CPUファンヘッダ x1
システムファ ンヘ ッダ x2 システ ムファ ンヘッダ x2
CMOSクリアヘッダ x1 CMOSクリアヘッダ x1
USB 2.0コネ クタ x3 USB 2.0コネクタ x3
消費者IR コネクタ x1 消費者 IR コネクタ x1
電源コネクタ (24 ピン) x1 電源コ ネクタ(24ピン) x1
電源コネクタ (8ピン) x1 電源コネクタ (4ピン) x1
PS/2キーボード / マウ ス x1
HDMIポート x1
VGAポート x1
DVI-Dポート x1
LANポート x1
USB 2.0ポー ト(で H67) x2
USB 3.0ポー ト(で NEC uPD720200 /
Asmedia ASM1042) x2
オーディオジ ャッ ク x3
230mm (幅) X 244 mm (高さ ) 230mm (幅) X 244 mm (高さ)
Windows XP / Vista / 7
Biostarは事前の サポートな しにOSサ ポー トを追加ま
たは削除する 権利 を留保しま す。
PS/2キーボード / マウ ス x1
HDMIポート x1
VGAポート x1
DVI-Dポート x1
LANポート x1
USB 2.0ポー ト x4
オーディオジ ャッ ク x3
Windows XP / Vista / 7
Biostarは事前の サポートな しにOSサ ポー トを追加ま
たは削除する 権利 を留保しま す。
2011/04/14
57
Loading...
