Bg Z-Sub i, Z-1, Z-5, Z-7 Specifications

Z Series

An elegant and stylish performer, the award-winning Z Series by BG is equally

adept at delivering astonishing home theater sound as well as faithful two-channel music.

Using several innovations, such as planar ribbon technology, the Z Series effortlessly

and accurately reproduces the quiet, silky sounds of a classical guitar, the hushed

whispers of the human voice and the high-impact sound from Hollywood movies,

making it a favorite with today’s leading designers. Meticulously constructed with a

reinforced cabinet from the finest hardwoods, the Z Series is a remarkable speaker system

for the eyes, as well as the ears.

As with all our loudspeakers, the Z Series is crafted from the finest

materials with zero tolerance for error and a maximum desire for

discrete high fidelity. The Radia Z Series can turn even modest multi-channel

H i g h P e r f o r m a n c e L o u d s p e a k e r s

p l a n a r t e c h n o l o g y

(2-channel to 7.1-channel) home theater into a powerhouse of music and sound.

The detail and accuracy in a high-performance planar ribbon-based speaker

system must be heard to be believed.

By combining proprietary ribbon technology with aluminum cone woofers,

the Z Series offers unparalleled transparency, resolution, clarity and tonal

accuracy. The award-winning Z-Series offers high performance and quality

craftsmanship at affordable prices. Critics around the world have hailed them

as a remarkable value and you will too.

Lifelike Exclusive planar ribbon technology produces a smooth,

›

open soundstage regardless of listening position or room acoustics.

Seamless Linkwitz-Riley crossovers with linear air core inductors and

›

high-quality polypropylene capacitors integrate seamlessly with woofers
and tweeters for smooth, natural response.

Ultra-reliable Patented planar ribbon drivers provide superior efficiency

›

and power handling for years of trouble-free listening.

T h e P o w e r o f C l a r i t y

All models available in Cherry or Black Ash finish.

›

Z-1

H i g h P e r f o r m a n c e L o u d s p e a k e r s

p l a n a r t e c h n o l o g y

Z Series

Z-7

Z-Sub i

Z-5

D E S C R I P T IO N :

›

Monitor/ Multi-purpose Floorstanding Active subwoofer
Bookshelf LCR (left/center/right)

F R E Q U E N C Y R E S P O N S E * :

›

(-6 dB, half space) (-6 dB, half space) (-6 dB, half space) 25-150 Hz
55 Hz-25 kHz 58 Hz-25 kHz 45 Hz-25 kHz with variable
50 Hz-150 Hz
low pass lter

W O O F E R :

›

5.25” Two 5.25” Two 5.25” 10” paper composite
Aluminum Aluminum Aluminum cone, rubber surround,

Cone, shielded Cone, shielded Cone, shielded coupled with matching

10” passive radiator
and 3” voice coil

T W E E T E R :

›

Neo3 PDR Neo3 PDR Neo3 PDR -

S E N S I T I V IT Y :

›

88 dB/2.83V/1m 89 dB/2.83V/1m 89 dB/2.83V/1m 88 dB/1W/1m (woofer)

I M P E D A N C E:

›

8 ohms 4 ohms 4 ohms 8 ohms (woofer)

P O W E R H A ND L I N G :

›

100 watts 150 watts 150 watts Amplier RMS
power 150 watts

Z-1 Z-5 Z-7 Z-Su b i

Neo3 PDR

Tweeter

Aluminum Cone

Woofer, Shielded

D I M E N S I O NS ( H x W x D ) :

›

13” x 7.1” x 9.5” 6.8” x 19.7” x 9.5” 40” x 6.8” x 10.25” 18.1” x 12.6” x 16.54”

W E I G H T :

›

13 lbs. 22 lbs. 42 lbs. 56 lbs.

›

W A R R AN T Y :

›

Lifetime (limited) Lifetime (limited) Lifetime (limited) Five-year (limited)

* at -6 dB from average level

›

3535 Arrowhead Drive · Carson City, NV 89706 ·

internet:

www.bgcorp.com ·

© Copyrigh t 2006 BG Corp. All rights res erved. Products, features and spe cications sub ject to change without notice.

phone:

775-884-1900 ·

email:

[e-mail]

toll free:

888-8PLANAR (888-875-2627)

03/06
