Beko WTE 12745 X0MSTD User manual [EN,D]

Washing Machine

User’s Manual

Mesin Cuci

Petunjuk Pengguna

EN / ID

Document Number=

WTE 12745 X0MSTD

2820526960_EN/ 09-07-18.(10:50)

This product was manufactured using the latest technology in environmentally friendly conditions.

1 General safety instructions

This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty.

1.1 Life and property safety

Never place the product on a carpet-covered floor. Otherwise, lack of airflow

beneath the machine will cause electrical parts to overheat. This will cause problems with your product.

Unplug the product if it is not in use.

Always have the installation and repairing procedures carried out by the

Authorized Service Agent. The manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorised persons.

The water supply and draining hoses must be securely fastened and remain

undamaged. Otherwise, there is the risk of water leakage.

While there is still water inside the product, never open the loading door or

remove the filter. Otherwise, risk of flooding and injury from hot water will occur.

Do not force open the locked loading door. The door will open immediately

after the washing cycle has ended. If the door does not open, apply the solutions provided for "Loading door cannot be opened." error in the Troubleshooting section. In case of forcing the loading door to open, the door and the lock mechanism may get damaged.

Use detergents, softeners and supplements suitable for automatic washing

machines only.

Follow the instructions on the label of textile products and the detergent

package.

1.2 Children's safety

This product can be used by children at and above 8 years old and by persons

whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. Children should not play with the product. Cleaning and maintenance works should not be performed by children unless they are supervised by someone. Children under the age of 3 should be kept away unless continuously supervised.

Packaging materials are dangerous for the children. Keep packaging

materials in a safe place away from reach of the children.

Washing Machine / User’s Manual

3 / EN

Electrical products are dangerous for the children. Keep children away from

the product when it is in use. Do not allow them to play with the product. Use child lock to prevent children from intervening with the product.

Do not forget to close the loading door when leaving the room where the

product is located.

Store all detergents and additives in a safe place away from the reach of

the children by closing the cover of the detergent container or sealing the detergent package.

1.3 Electrical safety

If the product has a failure, it should not be operated unless it is repaired by

the Authorized Service Agent! There is the risk of electric shock!

This product is designed to resume operating in the event of powering

on after a power interruption. If you wish to cancel the programme, see "Cancelling the programme" section.

Plug the product into a grounded outlet protected by a 16 A fuse. Do not

neglect to have the grounding installation made by a qualified electrician. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations.

Do not wash the product by spraying or pouring water onto it! There is the

risk of electric shock!

Never touch the power cable plug with wet hands! Never unplug by pulling

on the cable. Always press on the plug with one hand and pull out the plug by grabbing with the other hand.

Product should be unplugged during installation, maintenance, cleaning

and repair procedures.

If the power cable is damaged, it must be replaced by the manufacturer,

authorized service or a similarly qualified person (preferably an electrician) or someone designated by the importer in order to avoid possible risks.

1.4 Hot surface safety

4 / EN

The glass of the loading door gets too hot while washing at higher temperatures. Therefore, especially do not allow children touch the loading door glass while washing.

Washing Machine / User’s Manual

Important instructions for environment

2.1 Compliance with WEEE Directive

This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at the end of its service life. Take it to the collection center for the recycling of electrical and electronic equipment. Please consult your local authorities to

learn about these collection centers. Compliance with RoHS Directive: The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

2.2 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

Intended use

• This product has been designed for domestic use. It is not for commercial purposes or it should not be used out of its intended use.

• The product must only be used for washing and rinsing of laundry that are marked accordingly.

• The manufacturer waives any responsibility arisen from incorrect usage or transportation.

• The service life of your product is 10 years. During this period, original spare parts will be available to operate the appliance properly.

Washing Machine / User’s Manual

5 / EN

4 Technical specifications

Complying Commission Delegated Regulation (EU) No 1061/2010

Supplier name or trademark Beko

Model name WTE 12745 X0MSTD

Rated capacity (kg) 12

Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++

Annual Energy Consumption (kWh)

Energy consumption of the standard 60°C cotton programme at full load (kWh) 1,070

Energy consumption of the standard 60°C cotton programme at partial load (kWh) 1,000

Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0,900

Power consumption in ‘off-mode’ (W) 0,440

Power consumption in ‘left-on mode’ (W) 0,640

Annual Water Consumption (l)

Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) B

Maximum spin speed (rpm) 1400

Remaining moisture Content (%) 53

Standard cotton programme

Programme time of the standard 60°C cotton programme at full load (min) 234

Programme time of the standard 60°C cotton programme at partial load (min) 202

Programme time of the standard 40°C cotton programme at partial load (min) 200

Duration of the left-on mode (min) N/A

Airborne acoustical noise emissions washing/spinning (dB) 58/77

Built-in No

Height (cm) 84

Width (cm) 60

Depth (cm) 67

Net weight (±4 kg.) 78

Single Water inlet / Double Water inlet

• Available

Electrical input (V/Hz) 220-240 V / 50Hz

Total current (A) 10

Total power (W) 2000-2350

Main model code 9715

(1)

Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the

consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.

(2)

Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water

consumption will depend on how the appliance is used.

(3)

“Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes to which the information in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient programmes in terms of combined energy and water consumption.

Technical specifications may be changed without prior notice to improve the quality of the product.

(1)

(2)

(3)

Cotton Eco 60°C and 40°C

225

13199

• / -

6 / EN

Washing Machine / User’s Manual

4.1 Installation

• Apply to the nearest authorised service agent for the installation of your product.

• Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility.

• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures.

• Make sure that the installation and electrical connections of the product are performed by authorised service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorised persons.

• Prior to installation, visually check if the product has any defects on it. If so, do not have it installed. Damaged products cause risks for your safety.

4.1.1 Appropriate installation location

• Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other similar surfaces.

• When the washing machine and dryer are placed on top of each other, their total weight –when loaded– amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying capacity!

• Do not place the product on the power cable.

• Do not install the product in the environments where the temperature falls below 0 ºC.

• Leaving a gap at the sides of the machine is suggested to reduce vibration and noise

• On a graduated floor, do not place the product next to the edge or on a platform.

• Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not use them on the product.

4.1.2 Removing packaging reinforcement

Tilt the machine backwards to remove the packaging reinforcement. Remove the packaging reinforcement by pulling the ribbon. Do not make this operation alone by yourself.

4.1.3 Removing the transportation locks

1 Loosen all bolts with an appropriate wrench until they turn freely. 2 Remove the transport safety bolts by turning them slightly. 3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.

CAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be

Washing Machine / User’s Manual

damaged.

Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future.

Install the transport safety bolts in reverse order of the disassembly procedure.

Never move the product without the transportation safety bolts properly fixed in place!

7 / EN

4.1.4 Connecting water supply

40 cm

100 cm

The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure

reducing valve if water pressure is higher.

CAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will

get damaged or the product will switch to protection mode and will not operate.

CAUTION: Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry.

1 Tighten the nuts of the hose by hand. Never use a tool when

tightening the nuts.

2 When hose connection is completed, check whether there is leak

problems at the connection points by opening the taps fully. If any leaks occur, turn off the tap and remove the nut. Retighten the nut carefully after checking the seal. In order to prevent the water leaks and resultant damages, keep the taps closed when you do not use the product.

4.1.5 Connecting the drain hose to the drain

• Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.

CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there

is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine performs water intake and discharge processes without any problem, fix the drain hose securely.

• Connect the drain hose to a minimum height of 40 cm and a maximum height of 100 cm.

• In case the drain hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore, follow the heights described in the figure.

• To prevent the waste water to go back into the machine again and to ensure easy drainage, do not immerse the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too long, cut it short.

• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched between the drain and the machine.

• If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

8 / EN

Washing Machine / User’s Manual

4.1.6 Adjusting the feet

CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced

1 Loosen the lock nuts on the feet by hand. 2 Adjust the feet until the product stands in a stable and balanced way.

3. Tighten all lock nuts by hand again.

4.1.7 Electrical connection

Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations.

• Connection must comply with national regulations.

• The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements. Use of a Groud Fault Circuit Interrupter (GFCI) is recommended.

• Power cable plug must be within easy reach after installation.

• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician install a 16 Amp fuse.

• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.

• Do not make connections via extension cables or multi-plugs.

on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems.

CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.

4.1.8 Initial use

Washing Machine / User’s Manual

CAUTION: Damaged power cables must be replaced by the Authorised Service Agents.

Use an anti-limescale suitable for the washing machines.

Some water might have remained in the product due to the quality control processes in the production. It is not harmful for the product.

Before starting to use the product make sure that the preparations are made which are in line with the “Important Safety and Environment Instructions” and the instructions in the “Installation” section. To prepare the product for washing laundry, perform first operation in Drum Cleaning programme. If this program is not available in your machine, apply the method which is described in the section 4.4.2.

9 / EN

4.2 Preparation

4.2.1 Sorting the laundry

* Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always observe the instructions given on the garment care labels.

4.2.2 Preparing laundry for washing

• Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the product. Remove the metal pieces or wash such clothes by putting them in a laundry bag or pillow case.

• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and brush. Such objects may damage the product or cause noise problem.

• Put small size clothes such as infant's socks and nylon stockings in a laundry bag or pillow case.

• Place curtains in without compressing them. Remove curtain attachment items.

• Fasten zippers, sew loose buttons and mend rips and tears.

• Wash “Machine washable” or “Hand washable” labeled products only with an appropriate programme.

• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them separately.

• Tough stains must be treated properly before washing. If unsure, check with a dry cleaner.

• Only use the dyes / color changers and descaling agents which are appropriate for machine wash. Always follow the instructions on the package.

• Wash trousers and delicate laundry turned inside out.

• Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will reduce piling.

• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken off before placing into the product. Such dusts and powders on the laundry may build up on the inner parts of the product in time and can cause damage.

4.2.3 Tips for energy saving

Following information will help you use the product in an ecological and energy-efficient manner.

• Operate the product in the highest load capacity allowed for the programme you have selected, but do not overload. See, "4.3.3 Programme and consumption table."

• Observe the temperature instructions on the detergent packaging.

• Wash slightly soiled laundry at low temperatures.

• Use faster programmes for small quantities of lightly soiled laundry.

• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.

• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing process.

• Do not use more detergent than the recommended on the detergent packaging.

4.2.4 Loading the laundry

1. Open the loading door.

2. Put the laundry items into the product in a loose manner.

3 Push the loading door to close until you hear a locking sound. Ensure that no items are caught in the door.

The loading door is locked while a programme is running. The door lock will open immediately after the washing programme has ended. Then you can open the loading door. If the door does not open, apply the solutions provided for "Loading door cannot be opened." error in the Troubleshooting section.

4.2.5 Correct load capacity

The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing programme. The product automatically adjusts the water amount according to the weight of the laundry put inside it.

10 / EN

WARNING: Comply with the information in the section "4.3.3 Programme and consumption table". When overloaded,

product's washing performance will drop. Moreover, noise and vibration problems may occur.

Washing Machine / User’s Manual

4.2.6 Using detergent and softener

1 2 3

When using detergent, softener, starch, fabric dye, bleach and descaling agents to be added through the detergent container

Detergent, softener and other cleaning agents

• Add detergent and softener before starting the washing programme.

• Place the detergent bag or the dispensing ball directly among the laundry in the product.

• There is no pre-wash compartment or pre-wash option.

2, read the manufacturer's instructions written on the package and follow the dosages specified. Use a measuring cup, if any.

For programmes where liquid detergent dosing is selected, do not add any powder detergent.

WARNING: Do not use liquid detergents or other cleaning products other than fabric softeners produced for washing

machines to soften the clothes. Only use liquid softeners for washing machines.

1- Liquid detergent compartment 2 - Powder detergent compartment 3 - Softener compartment

Washing agents such as viscous jelly detergents cannot be used in detergent drawers or dosing compartments.

WARNING: Close the detergent drawer before starting the washing programme and never open the drawer while the

4.2.6.1 Auto Dosing

Initial Setup:

Switch on the machine by pressing the on/off button. The dosing symbol ( ) will appear in programmes that permit detergent dosing. If the liquid detergent and softener compartments are empty or the remaining agents in these compartments are below the limits, the dosing symbol will flash in programmes that permit dosing.

Adding Liquid Detergent and Softener

product is running.

• Pull the detergent drawer towards yourself to open it.

• To add liquid detergent (left) and softener (right), open the lid of the relevant container upwards as shown in the image.

Washing Machine / User’s Manual

11 / EN

• When adding liquid detergent or softener, do not exceed the tip of the «Max» label.

MAX

• For coloured and white laundry, it is recommended to fill commonly used liquid detergent in the compartment.

• Despite the fact that the detergent compartments are filled, if 'detergent symbol ' continues to flash, the detergent drawer is not fully closed. Ensure that the drawer is seated in place by pushing it.

WARNING: While the detergent drawer is full with detergent and/or softener:

a- Do not pull the machine, b- Do not change its place, c- Do not tilt the machine to its side or back,

WARNING: To make these actions, first you should take out the drawer from the machine.

WARNING: If you wish to start the programme when there is no detergent in the detergent drawer, please remember

that you must cancel the liquid detergent dosing and wash the laundry with powder detergent.

WARNING: The liquid detergent dosing container must be filled only with liquid detergent, and the softener dosing

container only with softener. Filling these compartments with any kind of liquid or powder chemical other than these may harm your laundry or washing machine.

• Close the lid.

• Close the detergent drawer by pushing it slowly.

• After closing the detergent drawer, the flashing dosing symbol ( ) will start to light up steadily.

• Indicates that the components are filled and the drawer is closed.

4.2.6.2 Dose Selection and Cancellation or Powder Detergent Use

• For some programmes of the machine, liquid detergent could not be selected. In such cases, powder detergent should be used. Please see the Programme Table for details.

• After selecting the temperature, spin speed and auxiliary function, start the programme by pressing the started/pause button.

• The machine will measure the load, and determine the detergent amount depending on the load amount and selected functions. During the washing operation, the detergent intake is not visible, it will be taken in directly with the water.

• If it is requested to use powder detergent in programmes where detergent dosing system activates required amount of powder detergent should be added to the detergent compartment. If you wish to use the detergent compartment in the middle, you need to cancel your liquid detergent selection.

• Programme is started by pressing Start/Pause button. When the machine starts to take in water, the powder detergent will also be taken in.

• If you want to use a liquid detergent whose characteristics are different than that of the detergent in the liquid detergent compartment for once, you must add the different liquid detergent into the middle powder detergent compartment and cancel your liquid detergent selection.

• Softener will be taken in through the detergent dosing system.

12 / EN

Washing Machine / User’s Manual

Liquid detergent and softener dosing symbols will be active or inactive depending on the programme selected on the display.

• If the liquid detergent symbol is on, this means that liquid detergent dosing is active.

• If the softener symbol is on, this means that softener dosing is active.

• If the liquid detergent symbol is off, this means that you can wash your laundry with powder detergent.

• If the softener symbol is off, this means no softener will be used in the rinsing step.

The first position on the display: means liquid detergent is active, softener is on.

If liquid detergent and softener symbols are active on the display, the liquid detergent will become on and the softener will become off after you press the Auto Dosing key for the first time.

When you press the Auto Dosing key for the second time, powder detergent and softener will become on.

When you press the Auto Dosing key for the third time, powder detergent will become on and softener will become off. Finally, when you press it for the fourth time, it will return to the initial position.

4.2.6.3 When the Detergent and/or Softener Run(s) Out:

• When the detergent or softener in the detergent compartment runs out, the “dosing symbol” on the display will flash. When this symbol flashes, you need to add detergent or softener to the dosing compartment. The product can dose for 2 to 3 cycles as of the moment that the symbol flashes.

4.2.6.4 Adding Detergent or Softener to the Wrong Compartment:

• If the detergent or softener is added to the wrong compartments, see 4.4.1 “Cleaning the detergent drawer”.

Washing Machine / User’s Manual

13 / EN

4.2.7 Tips for efficient washing

Light Colours and

Whites

(Recommended temperature range based on soiling level: 40-90°C)

Clothes

Colours

(Recommended temperature range based on soiling level: cold -40°C)

Black/Dark

Colours

(Recommended temperature range based on soiling level: cold -40°C)

Delicates/

Woolens/Silks

(Recommended temperature range based on soiling level: cold -30°C)

Heavily Soiled

(difficult stains such as grass, coffee, fruits and blood.)

Soiling Level

Normally Soiled

(For example, stains caused by body on collars and cuffs)

Lightly Soiled

(No visible stains exist.)

If a special liquid detergent must be used, you can cancel the liquid detergent dosing and add the special detergent to the

powder detergent compartment no 2. In such cases, no time delay function should not be used.

It may be necessary to pre-treat the stains or perform prewash. Powder and liquid detergents recommended for whites can be used at dosages recommended for heavily soiled clothes. It is recommended to use powder detergents to clean clay and soil stains and the stains that are sensitive to bleaches.

Powder and liquid detergents recommended for whites can be used at dosages recommended for normally soiled clothes.

Powder and liquid detergents recommended for whites can be used at dosages recommended for lightly soiled clothes.

Powder and liquid detergents recommended for colors can be used at dosages recommended for heavily soiled clothes. It is recommended to use powder detergents to clean clay and soil stains and the stains that are sensitive to bleaches. Detergents which do not contain bleach should be used.

Powder and liquid detergents recommended for colors can be used at dosages recommended for normally soiled clothes. Detergents which do not contain bleach should be used.

Powder and liquid detergents recommended for colors can be used at dosages recommended for lightly soiled clothes. Detergents which do not contain bleach should be used.

Liquid detergents suitable for colors and dark colors can be used at dosages recommended for heavily soiled clothes.

Liquid detergents suitable for colors and dark colors can be used at dosages recommended for normally soiled clothes.

Liquid detergents suitable for colors and dark colors can be used at dosages recommended for lightly soiled clothes.

Prefer liquid detergents produced for delicate clothes. Woolen and silk clothes must be washed with special woolen detergents.

14 / EN

Washing Machine / User’s Manual

4.3 Operating the product

a b c d e f g

4.3.1 Control panel

3 4 5

Auto Program

CoolClean

SteamTherapy

StainExpert

Shirts

Hygiene+

Duvet

Down Wear

1. Programme Selection knob 2 - Spin Speed Adjustment button 3 - Temperature Adjustment button 4 - Display 5 - Programme Follow-up indicator 6 - On/Off button 7 - Start/Pause button

4.3.2 Display symbols

Cottons

Cottons Eco

Synthetics Daily Express

Xpress Super Short

Dark Care

Jeans

Woollens

Hand Wash

Gentle Care

Spin+DrainRinse

Temperature

Auto

Dosing

Night Mode

Fast+

8 - End Time Adjustment button 9 - Auxiliary Function button 4 10 - Auxiliary Function button 3 11 - Auxiliary Function button 2 12 - Auxiliary Function button 1 13 - Programme Selection LEDs

Time Delay

891011

AntiCrease+ End

Wash

WTE 12745 X0MSTD

On /

Start/ Pause

a- Temperature indicator b- internet Connection indicator c- Steam indicator d- Audio Warning indicator e- No Water indicator f- Dosing symbols g- Start/Pause indicator

The visuals used for machine description in this section are schematic and may not match exactly will the features of your

Washing Machine / User’s Manual

machine.

ik jm ln

h- Programme Follow-up indicator i- Delayed Start Enabled indicator j- Auxiliary Function indicators k- Duration Information Line l- Lock Indicators m- Load indicator n- Speed indicator

15 / EN

4.3.3 Programme and consumption table

Auxiliary functions

Programme

Max. Load (kg)

Water Consumption (l)

Energy Consumption (kWh)

Max. Speed***

Fast+

Extra Rinse

90 12 113 2,45 1400 • • • • • Cold - 90

Cottons

Cottons Eco

Synthetics

Daily Xpress / Xpress Super Short

Daily Xpress / Xpress Super Short+ Fast+ 30 2 48 0,20 1400 • • • • • Cold - 90 Dark Care / Jeans 40 6 99 1,05 1200 * • • • Cold - 40 Woollens / Hand Wash 40 2,5 59 0,55 1200 • • • Cold - 40 Gentle Care 40 5 58 0,60 1200 • • • Cold - 40 Duvet / Down Wear 60 - 105 1,85 1000 • • • Cold - 60 Hygiene+ 90 9 120 2,25 1400 * • 20-90 Shirts 60 5 85 1,50 800 • • • • Cold - 60 StainExpert 60 6 100 2,00 1400 • • • 30-60 SteamTherapy - 1 1 0,17 - -

CoolClean 30 6 60 0,21 1400 • • Cold - 30

Auto Program 60 12 0 - 1400 • • • • • Cold - 60 Drum Cleaning 70 - 85 2,30 700 * • 70

60 12 113 1,40 1400 • • • • • Cold - 90

40 12 110 1,20 1400 • • • • • Cold - 90 60** 12 63,6 1,070 1400 • Cold - 60 60** 6 57,3 1,000 1400 • Cold - 60 40** 6 57,3 0,900 1400 • Cold - 60

60 5 84 1,50 1200 • • • • • Cold - 60

40 5 84 0,95 1200 • • • • • Cold - 60

90 12 85 2,30 1400 • • • • • Cold - 90

60 12 85 1,20 1400 • • • • • Cold - 90

30 12 83 0,20 1400 • • • • • Cold - 90

Auto Dosing

Selectable

temperature

Night Mode

AntiCrease+

range °C

• : Selectable. * : Automatically selected, no canceling. ** : Energy Label programme (EN 60456 Ed.3) *** : If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed. **** : Programme detects the type and quantity of the laundry to automatically adjust water and energy consumption and

programme time.

- : See the programme description for maximum load.

The auxiliary functions in the table may vary according to the model of your machine.

16 / EN

Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.

You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the actual duration of the wash cycle. Duration will be automatically updated soon after the washing starts.

"Selection patterns for auxiliary functions can be changed by the manufacturer company. New selection patterns can be added or removed." "The spin speed of your machine may vary according to the programme; this spin speed cannot exceed the max. spin speed of your machine."

Washing Machine / User’s Manual

4.3.4 Programme selection

1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with

"Programme and consumption table".

Programmes are limited with the highest spin speed appropriate for that particular type of fabric.

2 Select the desired programme with the Programme Selection knob.

When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.

Always select the lowest appropriate temperature. Higher temperature means higher electricity consumption.

4.3.5 Programmes

• Cottons Eco

Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other programmes, it provides high energy and water savings. Actual water temperature may be different from the stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), periods in programme stages may automatically get shorter. In this case, energy and water consumption will decrease more, providing a more economic wash.

• Cottons

You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this programme. When the quick wash function button is pressed, programme duration becomes notably shorter but effective washing performance is ensured with intense washing movements. If the quick wash function is not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.

• Synthetics

You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme. The programme duration gets notable shorter and washing with high performance is ensured. If the quick wash function is not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.

• Woollens / Hand Wash

Use to wash your woolen/delicate laundry. Select the appropriate temperature complying with the tag of your clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.

"Woolens programme of this machine is approved by “The Woolmark Company” for washing machine-washable woolen products provided that the products are washed in accordance with the instructions on the product tag and the instructions published by the manufacturer of this machine. M1422" In UK, Ireland, Hong Kong and India, the Woolmark trademark is a Certification trademark.

• Hygiene+

Use this programme for your laundry (baby clothes, bed sheets, bedlinen, underwear, etc. cotton items) for which you require an anti-allergic and hygienic washing at high temperature with intensive and long washing cycle. The high level of hygiene is ensured thanks to long heating duration and additional rinsing step.

• Programme was tested by the “VDE” institute with the 20°C temperature option selected and it was certified in terms of its efficacy in eliminating bacteria and mould.

Washing Machine / User’s Manual

17 / EN

• Programme was tested by “The British Allergy Foundation” (Allergy UK) with the 60°C temperature option selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and mould.

Allergy UK, is the brand of the British Allergy Association. Seal of Approval is created to guide people that require recommendation about a product that the related product restricts / reduces / eliminates the allergens or reduces the allergen content significantly in the ambient where allergy patients exist. It aims to provide assurance that the products are tested scientifically or examined in a way to provide measurable results.

• Duvet / Down Wear

Use this programme to wash your fiber duvets that bear "machine washable" tag. Check that you have loaded the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the machine paying attention to place it in a way that it will not contact the bellow or the glass. Besides, use this programme to wash your coats, vest, jackets etc. containing feathers with a "machinewashable" label on them.

Do not load more than 1 double fiber duvet (200 x 200 cm).

Do not wash your duvets, pillows and etc. that contain cotton in the machine.

CAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Otherwise,

permanent damage will occur in the machine.

• Spin+Drain

You can use this function to remove the water on the garment of drain the water in the machine.

• Rinse

Use when you want to rinse or starch separately.

• SteamTherapy

Use this programme to reduce the creases and ironing times of a small amount of unspotted cotton, synthetic or mixed laundry.

• Shirts

This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether. It reduces wrinkles. When the quick wash function is selected, the Pre-treatment algorithm is executed.

• Apply the pre-treatment chemical on your garments directly or add it together with the detergent when the machine starts to take water in the powder detergent compartment. Thus, you can obtain the same performance as you obtain with normal washing in a much shorter period of time. Usage life of your shirts increases.

• Daily Xpress / Xpress Super Short

Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme duration can be reduced down to 14 minutes when the quick wash function is selected. When the quick wash function is selected, maximum 2 (two) kg of laundry must be washed.

•

Dark Care / Jeans

Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high performance washing with special drum movement even if the temperature is low. It is recommended to use liquid detergent or woolen shampoo for dark coloured laundry. Do not wash your delicate clothes containing wool or etc.

When this programme is selected, it is normal to hear boiling noises since the steam generator boils water to produce steam.

18 / EN

Washing Machine / User’s Manual

• Auto Program

Use to wash frequently washable cotton, synthetic or blended (cotton+synthetic) clothes. Programme detects the type and quantity of the laundry to automatically adjust water consumption and programme time.

CAUTION: Do not wash your woolen and delicate clothes in this programme.

The maximum washing temperature in Automatic programme depending on the soiling level and laundry type is 60ºC. Washing performance may not be at the desired level for heavily soiled whites and stubborn stains (collar, sock soil, perspiration stain, etc.). In this case, it is recommended to select Cottons programme with prewash and set the temperature to 50-60°C. Many types of clothing are correctly detected and safely washed in Automatic programme.

• Gentle Care

You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20 degrees or by selecting the cold wash option.

• CoolClean

Use to wash your moderately soiled and durable cotton/synthetic laundry. An effective washing is provided thanks to the intense washing action and double jet system.

•

StainExpert

The machine has a special stain programme which enables the removal of different types of stains in the most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked (recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed sheets, duvet covers, pillowcases, bath-beach towels, towels, socks, cotton underwear that are suitable for washing at high temperature and long time). In the automatic stain programme, you can wash 24 types of stains divided into two different groups according to quick function selection. You can see stain groups based on the selection of the quick function. You can find stain groups based on quick function below:

Select a suitable temperature if the temperature shown on the temperature display is not compatible with the warnings on the garment label.

When quick function is selected:

Blood Tea Red Wine

Chocolate Coffee Curry

Pudding Fruit juice Jam

Egg Ketchup Coal

When quick function is not selected:

Butter Sweat Salad Dressing

Grass Collar Soil Make-up

Mud Food Machine Oil

Coke Mayonnaise Baby Food

• Select the stain programme.

• Select the stain you want to clean by locating it in the groups above and selecting the related group with the quick auxiliary function button.

• Read the garment tag carefully and ensure that correct temperature and spin speed are selected.

Washing Machine / User’s Manual

19 / EN

4.3.6 Temperature selection

Whenever a new programme is selected, the recommended temperature for the programme appears on the temperature indicator. It is possible that the recommended temperature value is not the maximum temperature that can be selected for the current programme.

Press the Temperature Adjustment button to change the temperature. Temperature will decrease by steps of 10 °C. Finally, “-” symbol indicating the cold wash option appears on the display.

No change can be made in programmes where temperature adjustment is not allowed.

You can also change the temperature after the washing starts. This change can be made if the washing steps allow it. Changes cannot be made if the steps do not allow it.

If you scroll to cold wash option and press Temperature Adjustment button again, the recommended maximum temperature for the selected programme appears on the display. Press the Temperature Adjustment button again to decrease the

4.3.7 Spin speed selection

Whenever a new programme is selected, the recommended spin speed of the selected programme is displayed on the Spin Speed indicator.

Press the Spin Speed Adjustment button to change the spin speed. Spin speed decreases gradually. Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display.

If you are not going to unload your laundry immediately after the programme completes, you can use Rinse Hold function in order to prevent them from getting wrinkled when there is no water in the machine.

This function holds the laundry in the final rinsing water.

temperature.

It is possible that the recommended spin speed value is not the maximum spin speed that can be selected for the current programme.

Spin Speed Adjustment button only serves for decreasing the spin speed.

Rinse Hold option is indicated with “ı_ı” symbol and No Spin option is indicated with “_” symbol.

20 / EN

Washing Machine / User’s Manual

If you want to spin your laundry after the Rinse Hold function:

- Adjust the Spin Speed.

- Press Start / Pause / Cancel button. The programme will resume. Machine drains the water and spins the laundry. If you want to drain the water at the end of the programme without spinning, use No Spin function.

No change can be made in programmes where spin speed adjustment is not allowed.

You can change the spin speed after the washing starts if the washing steps allow it. Changes cannot be made if the steps do not allow it.

Rinse hold

If you are not going to unload your clothes immediately after the programme completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine. Press Start / Pause button after this process if you want to drain the water without spinning your laundry. Programme will resume and complete after draining the water. If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button. The programme will resume. Water is drained, laundry is spun and the programme is completed.

4.3.8 Auxiliary function selection

Select the desired auxiliary functions before starting the programme. Whenever a programme is selected, frames of the auxiliary function symbol that can be selected together with it illuminates. And when you select an auxiliary function, the interior area of the auxiliary function symbol also starts to illuminate.

Frame of the auxiliary function symbol that cannot be selected with the current programme does not illuminate.

Also the frames of the auxiliary function suitable for the current programme after the washing has started remains illuminated. You can select or cancel the auxiliary functions whose frames are illuminated. If the wash cycle has reached a point where you cannot select the auxiliary function, the function's frame turns off.

Some functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before starting the machine, the function selected first will be canceled and the second auxiliary function selection will remain

active. For example, if you want to select Quick Wash after you have selected the Additional Water, Additional Water will be canceled and Quick Wash will remain active.

An auxiliary function that is not compatible with the programme cannot be selected. (See, "Programme and consumption table")

Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The frame of the auxiliary function will not be illuminated, only inner area will be illuminated.

Washing Machine / User’s Manual

21 / EN

4.3.8.1 Auxiliary functions

• Fast+

When this function is selected, the durations of the relevant programmes get shorter by 50%. Thanks to the optimised washing steps, high mechanic activity and optimum water consumption, high washing performance is achieved in spite of the reduced duration.

• Extra Rinse

This function enables the product to make another rinsing in addition to the one already made after the main wash. Thus, the risk for sensitive skins (babies, allergic skins, etc.) to be effected by the minimal detergent remnants on the laundry can be reduced.

• Night Mode

Use to wash the cottons with lesser energy consumption and silently. Spin steps are cancelled for a silent washing and the cycle ends with the Rinse Hold step. After completion of the programme, run Spin cycle to spin the laundry.

• AutoDosing

With this auxiliary function key, you can change your detergent and dose preferences. For detailed information, see 4.2.6.2 “Detergent and Softener Dose or Powder Detergent Selection“

4.3.8.2 Functions/Programmes Selected by Pressing the Function Keys for 3 Seconds

• Drum Cleaning

Press and hold the auxiliary function button 1 for 3 seconds to select the programme. Use regularly (once in every 1-2 months) to clean the drum and provide the required hygiene. Operate the programme while the machine is completely empty. To obtain better results, put powder lime-scale remover for washing machines when the powder detergent function is selected. When the programme is over, leave the loading door ajar so that the inside of the machine gets dry.

This is not a washing programme. It is a maintenance programme.

Do not run the programme when there is something in the machine. If you try to do so, the machine detects that there is

• Child lock

Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid any changes in a running programme.

To activate the Child Lock: Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1" on the

display is over, "CL On" symbol appears on the display. Release Auxiliary Function button 2 when this warning is displayed.

To deactivate the Child Lock: Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1" on the

display is over, "CL Off" symbol disappears.

load inside and aborts the programme.

You can switch on and off the machine with On / Off button when the Child Lock is active. When you switch on the machine again, programme will resume from where it has stopped.

When the Child Lock is enabled, an audio warning will be given if the buttons are pressed. Audio warning will be canceled if the buttons are pressed five times consecutively.

22 / EN

Washing Machine / User’s Manual

+ 50 hidden pages
