Beko WMY 71283 LMB2 User manual [EN,BG]

Washing Machine

User’s Manual

Пральна машина

Ръководство за употреба

WMY 71283 LMB2

EN/BG

Document Number=

2820525539_EN/ 18-05-16.(15:47)

This product was manufactured using the latest technology in environmentally friendly conditions.

1 General safety instructions

This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed.

1.1 Life and property safety

Never place the product on a carpet-covered floor. Electrical parts will get

overheated since air cannot circulate from under the device. This will cause problems with your product.

Unplug the product if it is not in use.

Always have the installation and repairing procedures carried out by the

Authorized Service Agent. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorized persons.

The water supply and draining hoses must be securely fastened and remain

undamaged. Otherwise, water leak may occur.

While there is still water inside the product, never open the loading door or

remove the filter. Otherwise, risk of flooding and injury from hot water will occur.

Do not force open the locked loading door. Door can be opened a few

minutes after the washing cycle ends. In case of forcing the loading door to open, the door and the lock mechanism may get damaged.

Use detergents, softeners and supplements suitable for automatic washing

machines only.

Follow the instructions on the label of textiles and the detergent package.

1.2 Children's safety

This product can be used by the children who are at the age of 8 and

over and the people whose physical, sensory or mental skills are not fully developed or who do not have necessary required experience and knowledge as long as they are supervised or trained about the safe use of the product and its risks. Children should not play with the device. Cleaning and maintenance works should not be performed by children unless they are supervised by someone. Children of less than 3 years should be kept away unless continuously supervised.

Packaging materials may be dangerous for the children. Keep packaging

materials in a safe place away from reach of the children.

Electrical products are dangerous for the children. Keep the children away

from the product when it is in use. Do not allow them to play with the product. Use child lock to prevent children from intervening with the product.

Washing Machine / User’s Manual

3 / EN

Do not forget to close the loading door when leaving the room where the

product is located.

store all detergents and additives in a safe place away from the reach of

the children by closing the cover of the detergent container or sealing the detergent package.

1.3 Electrical safety

If the product has a failure, it should not be operated unless it is repaired by

the Authorized Service Agent. Risk of electric shock!

This product is designed to resume operating in the event of powering

on after a power interruption. If you wish to cancel the programme, see "Cancelling the programme" section.

Plug the product into a grounded outlet protected by a 16 A fuse. Do not

neglect to have the grounding installation made by a qualified electrician. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations.

Do not wash the product by spraying or pouring water onto it! Risk of electric

shock!

Never touch the power cable plug with wet hands! Do not grab the power

cord to unplug the machine, always unplug it by holding the socket with one hand, and pulling the plug with the other hand.

Product should be unplugged during installation, maintenance, cleaning

and repair procedures.

If the power cable is damaged, it must be replaced by the manufacturer,

after sales service or a similarly qualified person (preferably an electrician) or someone designated by the importer in order to avoid possible risks.

1.4 Hot surface safety

4 / EN

While washing the laundry at high temperatures, the loading door glass will get hot. Considering this fact, during washing operation keep the children away from the loading door of the product to prevent them touching it.

Washing Machine / User’s Manual

2 Important instructions for environment

2.1 Compliance with WEEE Directive

This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at the end of its service life. Take it to the collection center for the recycling of electrical and electronic equipment. Please consult your local authorities to

learn about these collection centers. Compliance with RoHS Directive: The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

2.2 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

3 Intended use

• This product has been designed for domestic use. It is not for commercial purposes or it should not be used out of its intended use.

• The product must only be used for washing and rinsing of laundry that are marked accordingly.

• The manufacturer waives any responsibility arisen from incorrect usage or transportation.

• The service life of your product is 10 years. During this period, original spare parts will be available to operate the appliance properly.

Washing Machine / User’s Manual

5 / EN

4 Technical specifications

Complying Commission Delegated Regulation (EU) No 1061/2010

Supplier name or trademark Beko Model name WMY 71283 LMB2 Rated capacity (kg) 7 Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0.910 Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0.660 Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0.640 Power consumption in ‘off-mode’ (W) 0.500 Power consumption in ‘left-on mode’ (W) 0.500 Annual Water Consumption (l) Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) B Maximum spin speed (rpm) 1200 Remaining moisture Content (%) 53 Standard cotton programme Programme time of the standard 60°C cotton programme at full load (min) 205 Programme time of the standard 60°C cotton programme at partial load (min) 190 Programme time of the standard 40°C cotton programme at partial load (min) 185 Duration of the left-on mode (min) N/A Airborne acoustical noise emissions washing/spinning (dB) 55/76 Built-in No Height (cm) 84 Width (cm) 60 Depth (cm) 50 Net weight (±4 kg.) 64 Single Water inlet / Double Water inlet

• Available Electrical input (V/Hz) 230 V / 50Hz Total current (A) 10 Total power (W) 2200 Main model code 1010

(1)

Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the

consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.

(2)

Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water

consumption will depend on how the appliance is used.

(3)

“Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes to which the information in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient programmes in terms of combined energy and water consumption.

Technical specifications may be changed without prior notice to improve the quality of the product.

(1)

(2)

(3)

Cotton Eco 60°C and 40°C

170

9460

• / -

6 / EN

Washing Machine / User’s Manual

4.1 Installation

• Apply to the nearest authorized service agent for the installation of your product.

• Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility.

• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures.

• Make sure that the installation and electrical connections of the product are performed by authorized service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorized persons.

• Prior to installation, visually check if the product has any defects on it. If so, do not have it installed. Damaged products cause risks for your safety.

4.1.1 Appropriate installation location

• Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other similar surfaces.

• When the washing machine and drier are placed on top of each other, their total weight –when loaded– amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying capacity!

• Do not place the product on the power cable.

• Do not install the product in the environments where the temperature falls below 0 ºC.

• Leave a minimum space of 1 cm between the machine and the furniture.

• On a graduated floor, do not place the product next to the edge or on a platform.

4.1.2 Removing packaging reinforcement

Tilt the machine backwards to remove the packaging reinforcement. Remove the packaging reinforcement by pulling the ribbon. Do not make this operation alone by yourself.

4.1.3 Removing the transportation locks

1 Loose all bolts with an appropriate wrench until they turn freely (C). 2 Remove the transport safety bolts by turning them slightly. 3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel. (P)

CAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be

4.1.4 Connecting water supply

Washing Machine / User’s Manual

damaged.

Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future.

Install the transport safety bolts in reverse order of the disassembly procedure.

Never move the product without the transportation safety bolts properly fixed in place!

The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher.

7 / EN

CAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will

get damaged or the product will switch to protection mode and will not operate.

CAUTION: Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry.

• Tighten the nuts of the hose by hand. Never use a tool when tightening the nuts.

• When hose connection is completed, check whether there is leak problems at the connection points by opening the taps fully. If any leaks occur, turn off the tap and remove the nut. Retighten the nut carefully after checking the seal. In order to prevent the water leaks and resultant damages, keep the taps closed when you do not use the product.

4.1.5 Connecting the drain hose to the drain

• Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.

CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there

is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine performs water intake and discharge processes without any problem, fix the drain hose securely.

• Connect the drain hose to a minimum height of 40 cm and a maximum height of 100 cm.

• In case the drain hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above

100cm

the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore,

40cm

follow the heights described in the figure.

• To prevent the waste water to go back into the machine again and to ensure easy drainage, do not immerse the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too long, cut it short.

• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched between the drain and the machine.

• If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

4.1.6 Adjusting the feet

CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced

8 / EN

on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems.

CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.

Washing Machine / User’s Manual

1 Loosen the lock nuts on the feet by hand. 2 Adjust the feet until the product stands in a stable and balanced way.

3. Tighten all lock nuts by hand again.

4.1.7 Electrical connection

Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations.

• Connection must comply with national regulations.

• Power cable plug must be within easy reach after installation.

• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician install a 16 Amp fuse.

• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.

• Do not make connections via extension cables or multi-plugs.

4.1.8 Initial use

CAUTION: Damaged power cables must be replaced by the Authorized Service Agents.

Before starting to use the product make sure that the preparations are made which are in line with the “Important Safety and Environment Instructions” and the instructions in the “Installation” section. To prepare the product for washing laundry, perform first operation in Drum Cleaning programme. If this program is not available in your machine, apply the method which is described in the section 4.4.2.

Use an anti-limescale suitable for the washing machines.

Some water might have remained in the product due to the quality control processes in the production. It is not harmful for the product.

Washing Machine / User’s Manual

9 / EN

4.2 Preparation

4.2.1 Sorting the laundry

* Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always obey the instructions given on the garment tags.

4.2.2 Preparing laundry for washing

• Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine. Remove the metal pieces or wash the clothes by putting them in a laundry bag or pillow case.

• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and brush. Such objects may damage the product or cause noise problem.

• Put small size clothes such as infant's socks and nylon stockings in a laundry bag or pillow case.

• Place curtains in without compressing them. Remove curtain attachment items.

• Fasten zippers, sew loose buttons and mend rips and tears.

• Wash “machine washable” or “hand washable” labeled products only with an appropriate programme.

• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them separately.

• Tough stains must be treated properly before washing. If unsure, check with a dry cleaner.

• Only use the dyes / color changers and descaling agents which are appropriate to machine wash. Always follow the instructions on the package.

• Wash trousers and delicate laundry turned inside out.

• Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will reduce pilling.

• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken off before placing into the machine. Such dusts and powders on the laundry may build up on the inner parts of the machine in time and can cause damage.

4.2.3 Things to be done for energy saving

Following information will help you use the product in an ecological and energy-efficient manner.

• Operate the product in the highest capacity allowed by the programme you have selected, but do not overload; see, "Programme and consumption table". See, “Programme and consumption table"

• Always follow the instructions on the detergent packaging.

• Wash slightly soiled laundry at low temperatures.

• Use faster programmes for small quantities of lightly soiled laundry.

• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.

• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing process.

• Do not use more detergent than the recommended amount specified on its package.

4.2.4 Loading the laundry

1. Open the laundry cover.

2. Put the laundry items into the machine in a loose manner.

3. Push and close the loading cover until you hear the locking sound. Ensure that no items are caught in the door. The loading door is locked while a programme is running. The door can only be opened a while after the programme comes to an end.

4.2.5 Correct load capacity

The maximum load capacity depends on the type of laundry, the degree of soiling and the washing programme desired. Machine automatically adjusts the water amount according to the weight of the laundry put inside it.

10 / EN

WARNING: Follow the information in the “Programme and consumption table”. When overloaded, machine's washing

performance will drop. Moreover, noise and vibration problems may occur.

Washing Machine / User’s Manual

4.2.6 Using detergent and softener

When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's

Detergent, softener and other cleaning agents

• Add detergent and softener before starting the washing programme.

• While the washing cycle is in progress, do not leave the detergent dispenser open!

• When using a programme without prewash, do not put any detergent into the prewash compartment (compartment nr. "1").

• In a programme with prewash, do not put liquid detergent into the prewash compartment (compartment nr. "1").

• Do not select a programme with prewash if you are using a detergent bag or dispensing ball. Place the detergent bag or the dispensing ball directly among the laundry in the machine.

If you are using liquid detergent, do not forget to place the liquid detergent container into the main wash

compartment (compartment number “2”).

Choosing the detergent type

Detergent type to be used depends on the fabric type and color.

• Use different detergents for coloured and white laundry.

• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) used solely for delicate clothes.

• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.

• Wash woolens with special detergent made specifically for woolens.

Adjusting detergent amount The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and water hardness.

• Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.

• Use lesser detergent for small amounts or lightly soiled clothes.

Using softeners

Pour the softener into the softener compartment of the detergent drawer.

• Do not exceed the (>max<) level sign on the softener compartment.

• If the softener has lost its fluidity, dilute it with water before putting it in the detergent drawer.

Using liquid detergents If the product contains a liquid detergent cup:

instructions written on the package and follow the dosages specified. Use measuring cup if available.

The detergent drawer is composed of three compartments: – (1) for prewash – (2) for main wash – (3) for softener – ( ) in addition, there is a siphon piece in the softener compartment.

CAUTION: Use only detergents manufactured specifically for washing machines.

CAUTION: Do not use Powdered Soap.

• Put the liquid detergent container into the compartment no “2”.

• If the liquid detergent lost its fluidity, dilute it with water before putting it into the detergent container.

Washing Machine / User’s Manual

11 / EN

If the product does not contain a liquid detergent cup:

• Do not use liquid detergent for the prewash in a programme with prewash.

• Liquid detergent stains your clothes when used with Delayed Start function. If you are going to use the Delayed Start function, do not use liquid detergent.

Using gel and tablet detergent

• If the gel detergent thickness is fluidal and your machine does not contain a special liquid detergent cup, put the gel detergent into the main wash detergent compartment during first water intake. If your machine contains a liquid detergent cup, fill the detergent into this cup before starting the programme.

• If the gel detergent thickness is not fluidal or in the shape of capsule liquid tablet, put it directly into the drum before washing.

• Put tablet detergents into the main wash compartment (compartment nr. "2") or directly into the drum before washing.

Using starch

• Put the liquid soda, powder soda or the fabric dye into the softener compartment.

Do not use softener and starch together in a washing cycle. Wipe the inside of the machine with a damp and clean cloth after using starch.

Using limescale remover

• When required, use limescale removers manufactured specifically for washing machines only.

Using bleaches

Add the bleach at the beginning of the washing cycle by selecting a prewash program. Do not put detergent

in the prewash compartment. As an alternative application, select a programme with extra rinse and add the bleaching agent while the machine is taking water from the detergent compartment during first rinsing step.

• Do not use bleaching agent and detergent by mixing them.

• Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. Do not pour the bleach onto the laundry and do not use it with the colored items.

• When using oxygen-based decolorant, select a program which washes the laundry at a low temperature.

• Oxygen-based decolorant can be used with the detergent; however, if it is not at the same consistence, first put detergent in the compartment number “2” in the detergent dispenser and wait for the machine to flush the detergent when taking in water. While the machine continues taking in water, add decolorant in the same compartment.

12 / EN

Washing Machine / User’s Manual

4.2.7 Tips for efficient washing

Light Colours and

Whites

(Recommended temperature range based on soiling level: 40-90 oC)

It may be necessary to pre-treat

Heavily Soiled

(difficult stains such as grass, coffee, fruits and blood.)

Normally Soiled

Soiling Level

(For example, stains caused by body on collars and cuffs)

Lightly Soiled

(No visible stains exist.)

the stains or perform prewash. Powder and liquid detergents recommended for whites can be used at dosages recommended for heavily soiled clothes. It is recommended to use powder detergents to clean clay and soil stains and the stains that are sensitive to bleaches.

Powder and liquid detergents recommended for whites can be used at dosages recommended for normally soiled clothes.

Powder and liquid detergents recommended for whites can be used at dosages recommended for lightly soiled clothes.

Clothes

Colours

(Recommended temperature range based on soiling level: cold -40 oC)

Powder and liquid detergents recommended for colors can be used at dosages recommended for heavily soiled clothes. It is recommended to use powder detergents to clean clay and soil stains and the stains that are sensitive to bleaches. Use detergents without bleach.

Powder and liquid detergents recommended for colors can be used at dosages recommended for normally soiled clothes. Detergents which do not contain bleach should be used.

Powder and liquid detergents recommended for colors can be used at dosages recommended for lightly soiled clothes. Detergents which do not contain bleach should be used.

Black/Dark

Colours

(Recommended temperature range based on soiling level: cold

-40 oC)

Liquid detergents suitable for colors and dark colors can be used at dosages recommended for heavily soiled clothes.

Liquid detergents suitable for colors and dark colors can be used at dosages recommended for normally soiled clothes.

Liquid detergents suitable for colors and dark colors can be used at dosages recommended for lightly soiled clothes.

Delicates/

Woolens/Silks

(Recommended temperature range based on soiling level: cold -30 oC)

Prefer liquid detergents produced for delicate clothes. Woolen and silk clothes must be washed with special woolen detergents.

Washing Machine / User’s Manual

13 / EN

4.3 Operating the product

4.3.1 Control panel

1 2 3 4 5 6 7 8

1 - Programme selection knob 2 - Temperature selection LEDs 3 - Spin speed selection LEDs 4 - Duration information display 5 - Child lock enabled LED 6 - End Time Setting button 7 - Door lock enabled LED

1011121314

8 - Programme follow-up indicator LEDs 9 - On / Off button 10 - Start / Pause button 11 - Auxiliary function buttons 12 - Spin speed adjustment button 13 - Temperature adjustment button 14 - Programme Selection LEDs

(Pump)

express

14 / EN

Eco

Daily

Cottons

RinseDrain

Super short

express

Synthetics

Freshen

Spin

Woollens

Extra rinse

(Rinse Plus)

Delicate 20°

(Gentle Care 20)

Silk+Hand washSteamFinishing Protection BabyProtect+

Hand Wash

wash

BabyProtectCotton

Time delay

Hygiene 20°40° 40’

Sports

Dark wash (Darkcare)

Pre-wash

Dark wash (Darkcare)

Night modeQuick

Automatic Programme

Pet hair removal

Washing Machine / User’s Manual

Duvet

(Bedding)

Mixed 40

(Mix40)

Shirts

4.3.2 Programme selection

1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with

the "Programme and consumption table".

1 Select the desired programme with the “Programme Selection” knob.

Programmes are limited with the highest spin speed appropriate for that particular type of fabric.

When selecting the program you will use, always take fabric type, color, soil degree and permitted water temperature into consideration.

Always prefer the lowest temperature value which is fit to your laundry type. Higher temperature means higher power consumption.

4.3.3 Programmes

•

Cottons

Use for your cotton laundry (such as bed sheets, duvet and pillowcase sets, towels, bathrobes, underwear, etc.). Your laundry will be washed with vigorous washing action for a longer washing cycle.

• Synthetics

Use to wash your synthetic clothes (shirts, blouses, synthetic/cotton blends, etc.). It washes with a gentle action and has a shorter washing cycle compared to the Cottons programme. For curtains and tulle, use the Synthetic 40˚C programme with prewash and anti-creasing functions selected. As their meshed texture causes excessive foaming, wash the veils/tulle by putting little amount of detergent into the main wash compartment. Do not put detergent in the prewash compartment.

• Woollens

Use to wash your woolen clothes. Select the appropriate temperature complying with the tags of your clothes. Use appropriate detergents for woolens.

“The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of machine washable wool products provided that the products are washed according to the instructions on the garment label and those issued by the manufacturer of this washing machine. M1367.” “In UK, Eire, Hong Kong and India the Woolmark trade mark is a Certification trade mark.”

• Cottons Eco

Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other programmes, it provides high energy and water savings. Actual water temperature may be different from the stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), programme time may automatically get shorter. In this case, energy and water consumption will decrease more, providing a more economic wash. This programme is available in the models with the remaining time indicator.

• BabyProtect

Use this programme for your laundry for which you require an anti-allergic and hygienic washing at high temperature with intensive and long washing cycle.

• Gentle Care 20°

Use it to wash your delicate laundry. It washes with a gentler action without any interim spins compared to the Synthetics program. It should be used for laundry for which sensitive wash is recommended.

• Hand Wash

Use to wash your woolen/delicate clothes that bear “not machine-washable” tags and for which hand wash is recommended. It washes laundry with a very gentle washing action to not to damage clothes.

• Daily Xpress

Use this programme to wash your lightly soiled cotton clothes in a short time.

• Xpress Super Short

Use to wash your lightly soiled and unstained cotton laundry in a short time.

• Dark Care

Use this programme to wash your dark colored laundry or colored laundry that you do not want them get faded. Washing is performed with little mechanic action and at low temperatures. It is recommended to use liquid detergent or woolen shampoo for dark coloured laundry.

• Mix 40

Use this programme to wash your cotton and synthetic clothes together without sorting them.

• Shirts

Use to wash the shirts made of cotton, synthetic and synthetic blended fabrics together.

Washing Machine / User’s Manual

15 / EN

• Aqua 40’ 40°

Use this programme to wash your lightly soiled and unstained cotton laundry in a short time.

• Hygiene 20°

Use this programme to remove the odour on the laundry that are worn only for once and do not contain any stains or dirt.

• Rinse

Use when you want to rinse or starch separately.

• Spin + Drain

Use to drain the water in the machine.

4.3.4 Temperature selection

Whenever a new programme is selected, the recommended temperature for the selected programme appears on the temperature indicator. To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually.

If the programme has not reached the heating step, you can change the temperature without switching the machine to

Pause mode.

4.3.5 Spin speed selection

Whenever a new programme is selected, the recommended spin speed of the selected programme is displayed on the spin speed indicator. To decrease the spin speed, press the Spin Speed Adjustment button. Spin speed decreases gradually. Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display. See "Auxiliary function selection" section for explanations of these options.

Rinse Hold

If you are not going to unload your clothes immediately after the programme completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine. Press Start / Pause button after this process if you want to drain the water without spinning your laundry. Programme will resume and complete after draining the water. If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button. The programme resumes. Water is drained, laundry is spun and the programme is completed.

If the programme has not reached the spinning step, you can change the speed without switching the machine to Pause

mode.

Indicative values for Synthetics programmes (EN)

Remaining Moisture

Content (%) **

Load (kg)

Synthetics 60

Synthetics 40

* You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur between the time shown on the display and the real washing time.

** Remaining moisture content values may differ according to the selected spin speed.

3 52 1.10 105/135 45 40 3 49 0.60 105/135 45 40

Water

Consumption (l)

Energy

Consumption

(kWh)

Programme

Duration (min) *

≤ 1000 rpm > 1000 rpm

16 / EN

Remaining Moisture

Content (%) **

Washing Machine / User’s Manual

4.3.6 Programme and consumption table

Auxiliary

functions

Quick Wash

Extra Rinse

Selectable temperature

range °C

Programme (°C)

Max. Load (kg)

Water Consumption (l)

Energy Consumption (kWh)

Max. Speed***

Prewash

60** 7 47 0.91 1200 Cold-60

Cottons Eco

Cottons

Synthetics

Woollens 40 1.5 49 0.25 1200 • Cold-40 Hand Wash 30 1 40 0.25 1200 Cold-30 BabyProtect 60 7 85 1.90 1200 * 30 - 90 Dark Care 40 3 60 0.60 1000 • * Cold-40 Shirts 60 3.5 57 1.00 800 • • • Cold-60 Mix 40 40 3.5 60 0.70 1000 • • Cold-40 Aqua 40’ 40° 40 7 45 0.60 1200 Cold-40 Gentle Care 20° 20 3.5 45 0.15 1200 • 20 Hygiene 20° 20 2 95 0.40 1200 * 20 Xpress Super Short 30 2 35 0.15 1200 • Cold-30

Daily Xpress

• : Selectable. * : Automatically selected, no canceling. ** : Energy Label programme (EN 60456 ) *** : If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.

60** 3.5 40 0.66 1200 Cold-60 40** 3.5 40 0.64 1200 Cold-60

90 7 70 2.20 1200 • • • Cold-90 60 7 70 1.55 1200 • • • Cold-90 40 7 67 0.90 1200 • • • Cold-90 60 3 52 1.10 1200 • • • Cold-60 40 3 49 0.60 1200 • • • Cold-60

90 7 67 2.00 1200 • Cold-90 60 7 67 1.10 1200 • Cold-90 30 7 67 0.25 1200 • Cold-90

- : See the programme description for maximum load.

** “Cotton eco 40°C and Cotton eco 60°C are standard programmes.” These programmes are known as ‘40°C cotton standard programme’ and ‘60°C cotton standard programme’ and indicated with the symbols on the panel.

The auxiliary functions in the table may vary according to the model of your machine.

Washing Machine / User’s Manual

Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.

You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur between the time shown on the display and the real washing time. “Selection patterns for auxiliary functions can be changed by the manufacturer company. New selection patterns can be added or removed.” “The spin speed of your machine may vary according to the programme; this spin speed cannot exceed the max. spin speed of your machine.”

"The manufacturer reserves the right to make modifications in the programmes and auxiliary functions given in the table. While these modifications will not change the machine performance, programme steps and durations can be changed."

17 / EN

+ 39 hidden pages
