Behringer PMP2000 Specification Sheet
Specifications
EUROPOWER PMP2000
800-Watt 14-Channel Powered Mixer with Multi-FX Processor
behringer.com
behringer.com
2 EUROPOWER PMP2000 User Manual
Specifications
Mono Inputs
Microphone inputs
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resistance -122 dB / 125 dB A-weighted
@ 50 Ω source resistance -122 dB / 125 dB A-weighted
@ 150 Ω source resistance -121 dB / 124 dB A-weighted
Frequency response <10 Hz - 100 kHz (-1 dB),
<10 Hz - >200 kHz (-3 dB)
Gain +33 dB, +8 dB with pad
Max. input level +12 dBu @ +8 dB gain
Impedance approx. 2.2 kΩ balanced / 1.1 kΩ unbalanced
Signal-to-noise ratio 110 dB / 114 dB A-weighted
(-11 dBu In @ +33 dB gain)
Distortion (THD + N) 0.001% / 0.0008% A-weighted
Mono Line Inputs
Type ¼" TRS connector, balanced
Monitor Output
Type ¼" TRS connector, unbalanced
Impedance 1.5 kΩ
Max. output level +21 dBu
DSP 24-bit Texas Instruments
Converter 24-bit Sigma-Delta,
64/128-times oversampling
Sampling rate 40 kHz
Main Mix System Data
1
Noise
Main mix @ -∞, -76 dB / -80 dB A-weighted
Channel fader -∞
Main mix @ 0 dB, -72 dB / -76 dB A-weighted
Channel fader -∞
Main Mix @ 0 dB, -71 dB / -75 dB A-weighted
Channel fader @ 0 dB
Power Amp Specifications
RMS @ 1 % THD (sine wave), both channels driven:
Impedance approx. 80 kΩ balanced, 40 kΩ unbalanced
Max. input level 30 dBu
Stereo Line Inputs
Type ¼" TRS connector, unbalanced
Impedance approx. 40 kΩ unbalanced
Max. input level +28 dBu
EQ
Low 60 Hz / ±15 dB
Mid 700 Hz/ ±15 dB
High 6 kHz / ±15 dB
Preamp Outputs Lef t/Mono & Right
Type ¼" TRS connector, unbalanced
Impedance approx. 1.5 kΩ
Max. output level +21 dBu
Power Amp Input s
Type ¼" TRS connector, unbalanced
8 Ω per channel 165 W
4 Ω per channel 250 W
RMS @ 1 % THD (sine wave), bridged mode:
8 Ω 500 W
Peak Power, both channels driven
8 Ω per channel 225 W
4 Ω per channel 350 W
Peak Power, bridged mode
8 Ω 800 W
Loudspeaker Connec tions
Loudspeaker connector Professional speaker con nectors
(compatible to Neutrik Speakon)
Load Impedance
Left/monitor 4/8/16 Ω
Right/mono main 4/8/16 Ω
Bridge 8/16 Ω
Impedance approx. 47 kΩ
Max. input level +21 dBu
