PRO DSP1224P
Technical Specifications
ENGLISH
Version 1.0 March 2001
®
MODULIZER
www.behringer.com
MODULIZER PRO DSP1224P
MODULIZERPRO
Ultra-high performance digital multi-effects processor powered by a 24-bit high-speed digital signal processor (DSP)
DSP1224P
I Cutting edge effects such as 3D Processor, Stereo Imager, Lo-Fi, Super Bass, Ring Modulator, Voice
Canceler etc.
I 24 breathtaking effects such as Ultra Phaser, Harmonic Exciter, Auto Filter, Jetstream Flanger,
Ultra Compressor, Guitar Combo, Speaker Emulation Resonator and more
I Hundreds of effect variations plus two individual parameters and separate low and high EQ section
I True stereo processing performance allows separation of left and right channels in the stereo field for
open-sounding enhancement of the sound sources
I Free MODULIZER design software allows for total remote control via PC (download at www.behringer.com)
I 24-bit A/D and D/A converters with 64/128 times oversampling for ultra-high headroom and resolution
I Internal 24-bit processing with professional 46 kHz sampling rate
I Servo-balanced inputs and outputs on gold-plated XLR and TRS connectors for high signal integrity
I 100 user preset memories to store programs for instant recall
I Accurate eight-segment LED level meters simplify level setting for optimum performance
I “Future-proof” software-upgradeable architecture
I Full MIDI capability allows real-time parameter control and program selection
I High-quality components and exceptionally rugged construction ensures long life and durability
I Internal power supply design for professional application
I Manufactured under the ISO9000 certified management system
2
MODULIZER PRO DSP1224P
SPECIFICATIONS
Analog Inputs
Connectors XLR and 1/4" TRS connector
Type RF filtered, servo balanced input
Impedance 60 kOhms balanced, 30 kOhms unbalanced
Nominal Operating Level -10 dBV to +4 dBu
Max. Input Level +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level
Analog Outputs
Connectors XLR and 1/4" TRS connector
Type Electronically servo-balanced output stage
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Max. Output Level +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level
System specifications
Bandwidth 20 Hz to 20 kHz, +0/-3 dB
Noise >94 dBu, unweighted, 20 Hz to 20 kHz
THD 0.0075 % typ. @ +4 dBu, 1 kHz, Gain 1
Crosstalk < -76 dBu
MIDI Interface
Type 5-Pin-DIN-Socket IN / OUT / THRU
Digital Processing
Converters 24-bit Sigma-Delta, 64/128-times Oversampling
Sampling Rate 46,875 kHz
Display
Type 2 ½-digit numeric LED-Display
Power Supply
Mains Voltages USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General Export Model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Fuse 100 - 120 V ~: T 125 mA H
200 - 240 V ~: T 63 mA H
Power Consumption max. 15 Watts
Mains Connection Standard IEC receptacle
Physical
Dimensions (H * W * D) 1 3/4" (44.5 mm) * 19" (482.6 mm) * 7 1/2" (190.5 mm)
Net Weight ± 2 kg
Shipping Weight ± 3 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time
to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
3
MODULIZER PRO DSP1224P
The information contained in this manual is subject to change without notice. No part of this manual may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any
BEHRINGER Spezielle Studiotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany
purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.
BEHRINGER and MODULIZER are registered trademarks. ALL RIGHTS RESERVED.
© 2001 BEHRINGER Spezielle Studiotechnik GmbH.
Tel. +49 (0) 21 54 / 92 06-0, Fax +49 (0) 21 54 / 92 06-30
