Beckhoff CX2042, CX2062, CX2072 Users guide
Manual | EN
CX20x2
Embedded PC
6/30/2020 | Version: 1.7
Table of contents
Table of contents
1 Notes on the documentation ....................................................................................................................5
1.1 Representation and structure of warnings.........................................................................................6
1.2 Related documents............................................................................................................................7
1.3 Documentation issue status ..............................................................................................................7
2 For your safety...........................................................................................................................................8
2.1 Intended use......................................................................................................................................8
2.2 Staff qualification ...............................................................................................................................8
2.3 Safety instructions .............................................................................................................................9
3 Transport and storage.............................................................................................................................10
4 Product overview.....................................................................................................................................11
4.1 Configuration of the basic CPU module ..........................................................................................13
4.2 Name plate ......................................................................................................................................14
4.3 Module overview..............................................................................................................................15
4.4 Types...............................................................................................................................................16
4.5 Architekture overview ......................................................................................................................17
5 Description of the interfaces ..................................................................................................................19
5.1 USB 3.0 interfaces (X100, X101, X102, X103)................................................................................19
5.2 Ethernet RJ45 (X000, X001) ...........................................................................................................20
5.3 DVI-I (X200).....................................................................................................................................21
5.4 Optional interfaces...........................................................................................................................22
5.4.1 DVI-D (N010) ................................................................................................................... 22
5.4.2 DisplayPort (N011) .......................................................................................................... 23
5.4.3 RS232 (N030).................................................................................................................. 24
5.4.4 RS422/RS485 (N031)...................................................................................................... 25
5.4.5 EtherCAT slave (B110).................................................................................................... 26
5.4.6 PROFIBUS (x310) ........................................................................................................... 27
5.4.7 CANopen (x510) .............................................................................................................. 28
5.4.8 PROFINET RT (x930)...................................................................................................... 29
6 Commissioning........................................................................................................................................30
6.1 Selecting the appropriate CX2100 power supply unit......................................................................30
6.2 Mounting..........................................................................................................................................31
6.2.1 Attaching the power supply unit....................................................................................... 31
6.2.2 Installing the bar clips ...................................................................................................... 31
6.2.3 Note the permissible installation positions ...................................................................... 32
6.2.4 Attaching on mounting rail ............................................................................................... 34
6.2.5 CFast card installation and removal ................................................................................ 35
6.2.6 Installing passive EtherCAT Terminals............................................................................ 36
6.3 Connecting the power supply ..........................................................................................................37
6.4 Switching on ....................................................................................................................................39
6.5 Switching off ....................................................................................................................................39
7 Configuration ...........................................................................................................................................40
7.1 Windows 10 IoT Enterprise LTSB ...................................................................................................40
7.1.1 Identification of the Ethernet interfaces (X000, X001) ..................................................... 40
CX20x2 3Version: 1.7
Table of contents
7.2 Starting the Beckhoff Device Manager ............................................................................................41
7.3 TwinCAT..........................................................................................................................................42
7.3.1 Tree view ......................................................................................................................... 42
7.3.2 Searching for target systems ........................................................................................... 43
7.3.3 Scanning an Embedded PC ............................................................................................ 45
7.3.4 Configuring EtherCAT cable redundancy. ....................................................................... 46
7.3.5 Using a hardware watchdog ............................................................................................ 49
8 NOVRAM...................................................................................................................................................50
8.1 Use under TwinCAT 3 .....................................................................................................................51
8.1.1 Creating a Retain Handler ............................................................................................... 51
8.1.2 Creating and linking variables.......................................................................................... 53
8.1.3 Note the write speed of the Retain Handler..................................................................... 55
8.1.4 Deleting variables under the Retain Handler ................................................................... 56
9 Error handling and diagnostics..............................................................................................................57
9.1 Basic CPU module ..........................................................................................................................57
9.1.1 LEDs on the basic CPU module ...................................................................................... 57
9.1.2 Power supply terminal LEDs in K-bus mode ................................................................... 57
9.1.3 Power supply terminal LEDs in E-bus mode ................................................................... 60
9.2 Faults...............................................................................................................................................61
10 Care and maintenance ...........................................................................................................................62
10.1 Replace the battery .........................................................................................................................62
10.2 Replace the fan cartridge ................................................................................................................63
11 Decommissioning....................................................................................................................................65
11.1 Removing cables .............................................................................................................................65
11.2 Dismantling the Embedded PC .......................................................................................................66
12 Technical data..........................................................................................................................................68
13 Appendix ..................................................................................................................................................70
13.1 Accessories .....................................................................................................................................70
13.2 Certifications....................................................................................................................................71
13.3 Support and Service ........................................................................................................................72
List of tables.............................................................................................................................................73
List of figures...........................................................................................................................................75
CX20x24 Version: 1.7
Notes on the documentation
1 Notes on the documentation
This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with the applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning the components.
It is the duty of the technical personnel to use the documentation published at the respective time of each
installation and commissioning.
The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®, Safety over EtherCAT®,
TwinSAFE®, XFC®, und XTS® and XPlanar®, are registered trademarks of and licensed by Beckhoff
Automation GmbH.
Other designations used in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents:
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702
with corresponding applications or registrations in various other countries.
EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.
CX20x2 5Version: 1.7
Notes on the documentation
1.1 Representation and structure of warnings
The following warnings are used in the documentation. Read and follow the warnings.
Warnings relating to personal injury:
DANGER
Serious risk of injury
Hazard with high risk of death or serious injury.
WARNING
Risk of injury
Hazard with medium risk of death or serious injury.
CAUTION
Slight risk of injury
There is a low-risk hazard that can result in minor injury.
Warnings relating to damage to property or the environment:
NOTE
Damage to the environment or devices
There is a potential hazard to the environment and equipment.
Notes showing further information or tips:
Tip or pointer
This notice provides important information that will be of assistance in dealing with the product or
software. There is no immediate danger to product, people or environment.
CX20x26 Version: 1.7
Notes on the documentation
1.2 Related documents
This documentation contains and describes material that is relevant for the CX20x2 Embedded PC. The
CX20x2 Embedded PC is part of a modular system and belongs to the CX2000 Embedded PC series.
Further information on the devices of the CX2000 Embedded PC series can be found in the associated
documentation. Read and follow in particular the sections on safety in this documentation.
The following important documentation can be viewed at and downloaded from the Beckhoff website:
http://www.beckhoff.de
Document name
CX2100-00x4 power supply unit
CX2100-0914 power supply unit with electronic charging unit for battery pack
Retaining the documentation
This documentation forms part of the Embedded PC. Keep the documentation in the immediate vicinity of the
device throughout its entire service life. Ensure that personnel have access to the documentation at all times.
Pass on the documentation to subsequent users, and in addition ensure that all supplementary information is
included in the documentation.
1.3 Documentation issue status
Version Changes
1.0 First version
1.1 Chapter "Power supply" revised
1.2 Chapter Beckhoff Device Manager revised
1.3 Chapter "Mounting passive EtherCAT Terminals"
adjusted.
1.4 Chapter ”Selecting the appropriate CX2100 power
supply unit“ und ”Technical data“ revised.
1.5 Chapter "Types" and “Device Manager” adjusted.
1.6 Chapter “TwinCAT” revised.
1.7 Chapter “Commissioning” revised.
CX20x2 7Version: 1.7
For your safety
2 For your safety
Read the chapter on safety and follow the instructions in order to protect from personal injury and damage to
equipment.
Limitation of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Unauthorized modifications and changes to the hardware or software configuration, which go
beyond the documented options, are prohibited and nullify the liability of Beckhoff Automation GmbH & Co.
KG.
In addition, the following actions are excluded from the liability of Beckhoff Automation GmbH & Co. KG:
• Failure to comply with this documentation.
• Improper use.
• Use of untrained personnel.
• Use of unauthorized replacement parts.
2.1 Intended use
The CX20x2 Embedded PC series is a modular control system, which is intended for installation on a DIN
rail. The system is scalable, so that the basic PC modules, power supply units, system modules and
extension modules can be assembled and installed in the control cabinet or terminal box as required.
The CX20x2 Embedded PC series is used in conjunction with Bus Terminals for recording digital and analog
signals from sensors and transferring them to actuators or higher-level controllers. The CX20x2 Embedded
PC series combines the worlds of Industrial PC and hardware PLC and is suitable for control tasks.
The Embedded PC is designed for a working environment that meets the requirements of protection class
IP20. This involves finger protection and protection against solid foreign objects up to 12.5 mm, but not
protection against water. Operation of the devices in wet and dusty environments is not permitted, unless
specified otherwise. The specified limits for electrical and technical data must be adhered to.
Improper use
The Embedded PC is not suitable for operation in the following areas:
• Potentially explosive atmospheres.
• Areas with an aggressive environment, e.g. aggressive gases or chemicals.
• Living areas. If the devices are to be used in living areas, the relevant standards and guidelines for
interference emissions must be adhered to, and the devices must be installed in housings or control
boxes with suitable shielding.
2.2 Staff qualification
All operations involving Beckhoff software and hardware may only be carried out by qualified personnel with
knowledge of control and automation engineering. The qualified personnel must have knowledge of the
administration of the Industrial PC and the associated network.
All interventions must be carried out with knowledge of control programming, and the qualified personnel
must be familiar with the current standards and guidelines for the automation environment.
CX20x28 Version: 1.7
For your safety
2.3 Safety instructions
The following safety instructions must be followed during installation and working with networks and the
software.
Mounting
• Never work on live equipment. Always switch off the power supply for the device before installation,
troubleshooting or maintenance. Protect the device against unintentional switching on.
• Observe the relevant accident prevention regulations for your machine (e.g. the BGV A 3, electrical
systems and equipment).
• Ensure standard-compliant connection and avoid risks to personnel. Ensure that data and supply
cables are laid in a standard-compliant manner and ensure correct pin assignment.
• Observe the relevant EMC guidelines for your application.
• Avoid polarity reversal of the data and supply cables, as this may cause damage to the equipment.
• The devices contain electronic components, which may be destroyed by electrostatic discharge when
touched. Observe the safety precautions against electrostatic discharge according to DIN EN
61340-5-1/-3.
Working with networks
• Restrict access to all devices to an authorized circle of persons.
• Change the default passwords to reduce the risk of unauthorized access. Regularly change the
passwords.
• Protect the devices with a firewall.
• Apply the IT security precautions according to IEC 62443, in order to limit access to and control of
devices and networks.
Working with the software
• Use up-to-date security software. The safe function of the PC can be compromised by malicious
software such as viruses or Trojans.
• The sensitivity of a PC against malicious software increases with the number of installed and active
software.
• Uninstall or disable unnecessary software.
Further information about the safe handling of networks and software can be found in the Beckhoff
Information System:
http://infosys.beckhoff.de
Document name
Documentation about IPC Security
CX20x2 9Version: 1.7
Transport and storage
3 Transport and storage
Transport
NOTE
Short circuit due to moisture
Moisture can form during transport in cold weather or in the event of large temperature fluctuations.
Avoid moisture formation (condensation) in the Embedded PC, and leave it to adjust to room temperature
slowly. If condensation has occurred, wait at least 12 hours before switching on the Embedded PC.
Despite the robust design of the unit, the components are sensitive to strong vibrations and impacts. During
transport the Embedded PC must be protected from
• mechanical stress and
• use the original packaging.
Table1: Dimensions and weight of the individual modules.
CX2042 CX2062 CX2072
Dimensions (W x H x D) 204mm x 99mm x 91mm
Weight 1300g
Storage
• The battery should be removed if the Embedded PC is stored at temperatures above 60°C. The
battery should be stored separate from the Embedded PC in a dry environment at a temperature
between 0 °C and 30 °C.
The preset date and time are lost if the battery is removed.
• Store the Embedded PC in the original packaging.
CX20x210 Version: 1.7
Product overview
4 Product overview
The CX2000 product family consists of individual modules, which can be assembled to form a customized
Embedded PC.
The CX2000 product family consists of:
• basic CPU modules,
• CX2100 power supply units,
• system, fieldbus and extension modules,
• and the CX2900 battery pack.
Fig.1: Overview of the CX2000 product family with basic CPU module, power supply unit and modules.
Basic CPU module
The basic CPU module is a fully functional PC and can be used in conjunction with a CX2100 power supply
unit as the smallest possible configuration. The basic configuration of the CX20x2 Embedded PC includes:
• a CFast card slot,
• two independent Gbit Ethernet interfaces,
• four USB 3.0 interfaces,
• and a DVI-I interface.
The basic CPU module can be extended with additional interfaces or storage media, as required. Up to four
system or fieldbus modules can be connected on the left-hand side of the basic CPU module. Up to four
extension modules can be connected on the right-hand side between the basic CPU module and the power
supply unit. Two extension modules for additional storage media (CFast card, SSD) and two extension
modules for a USB extension.
Microsoft Windows 10 IoT Enterprise LTSB can be used as operating system.
The basic CPU module features 128 kB NOVRAM as internal persistent data memory and can be used as
an alternative to a power supply unit with capacitive UPS or an external battery pack. In the event of a power
failure, important data are stored in the NOVRAM and are available again after a restart.
CX20x2 11Version: 1.7
Product overview
The basic CPU module can be ordered ex factory with an optional interface. The optional interface cannot be
retrofitted.
Table2: Available optional interfaces for the CX20x2.
CX20x0-xxxx Optional interfaces
CX20x0-N010 DVI-D, additional DVI-D socket for clone and extended display mode.
CX20x0-N011 DisplayPort, additional DisplayPort for clone and extended display mode
CX20x0-N030 RS232, D-sub connector, 9-pole.
CX20x0-N031 RS422/RS485, D-sub socket, 9-pole.
CX20x0-B110 EtherCAT slave, EtherCAT IN and OUT (2 x RJ45).
CX20x0-M310 PROFIBUS master, D-sub socket, 9-pole.
CX20x0-B310 PROFIBUS slave, D-sub socket, 9-pole.
CX20x0-M510 CANopen master, D-sub connector, 9-pole.
CX20x0-B510 CANopen slave, D-sub connector, 9-pole.
CX20x0-M930 PROFINET RT, controller, Ethernet (2 x RJ-45).
CX20x0-B930 PROFINET RT, device, Ethernet (2 x RJ-45 switch).
CX2100 power supply units
The CX2100 power supply units serve the basic CPU module and all additional modules. Bus Terminals (Kbus) or EtherCAT Terminals (E-bus) can be attached on the right-hand side of the power supply units. The
following power supply unit is available for the CX20x2 Embedded PC:
• CX2100-0014: E-bus/K-bus power supply unit with automatic switchover and passive ventilation.
• CX2100-0914: E-bus/K-bus power supply unit with automatic switching and integrated charging
electronics for an external battery pack.
The power supply units feature an illuminated anti-glare LC display with two rows of 16 characters each for
displaying status messages. Application-specific texts can be displayed with the aid of user programs.
System, fieldbus and extension modules
System or fieldbus modules of type CX2500-xxxx can be connected on the left-hand side of the basic CPU
module. Up to four modules can be connected to the multi-pole connection on the left. Extension modules of
type CX2550 can be connected on the right between the basic CPU module and the power supply unit.
Software
In combination with the TwinCAT automation software the CX20x2 Embedded PC becomes a powerful IEC
61131-3 PLC. In conjunction with EtherCAT and TwinCAT, it is possible to implement very fast control
processes in the microsecond range (XFC eXtreme Fast Control Technology).
It is also possible to execute Motion Control tasks with potentially up to 256 axes. Depending on the required
sampling time, several servo axes can be controlled. Even special functions such as flying saw, electronic
gearbox and cam plate can be realized.
In addition to handling real-time control tasks the TwinCAT real-time kernel leaves enough time for the user
interface (HMI). The high performance of the graphics core integrated in the CPU enables demanding
visualizations with advanced user interfaces to be realized.
CX20x212 Version: 1.7
4.1 Configuration of the basic CPU module
1
2
3
6
4
5
7
8
9
10
Fig.2: Example of a CX2072 Embedded PC.
Table3: Legend for the configuration of the basic CPU module
Product overview
No. Component Description
1 Multi-pole connection (left) Extension through system modules and fieldbus modules of type
CX2500.
2
3
4
5
6
7
8 Multi-pole connection
9
10
Optional interface [}22]
(X300)
DVI-I interface [}21]
(X200)
Battery compartment
[}62] (under the front
flap).
[}62]
RJ45 Ethernet interfaces
[}20] (X000, X001).
USB 3.0 interfaces [}19]
(X100, X101, X102, X103).
Diagnostic LEDs [}57].
(right)
Fan cartridge [}63] (under
the front flap).
CFast card slot [}35].
Space for interfaces such as RS232, EtherCAT, CANopen or
others.
The optional interface must be ordered ex factory and cannot be
retrofitted retrospectively.
Interface for a monitor or Panel.
Power supply for the battery-backed clock for time and date.
For connecting to local networks, internet or EtherCAT.
Interfaces for peripherals such as mouse, keyboard or USB
memory.
Diagnostic LEDs for power supply, TwinCAT, CFast card and
optional interface.
Connection for extension modules of type CX2550 and for power
supply units of type CX2100.
The CX20x2 Embedded PCs feature a fan cartridge as standard.
Slot for industrial CFast cards.
CX20x2 13Version: 1.7
Product overview
1
2
3
4
5
6
7
4.2 Name plate
The CX20x2 Embedded PC features a name plate on the left-hand side of the housing.
Fig.3: CX20x2 name plate.
Table4: Legend for the name plate.
No. Description
1 Information on the power supply unit. 24VDC, 4A max.
2 MAC addresses of the integrated Ethernet ports.
By default, the host name is formed from CX plus the last 3 bytes of the MAC address:
for example, the MAC address: 00-01-05-aa-bb-cc results in the host name CX-aabbcc.
3 Information on:
• serial number,
• hardware version
• and date of manufacture.
4 Information on the model. The last four numerals relate to the configuration of Embedded
PC.
5 Manufacturer information including address.
6 CE compliant.
7 Windows license sticker (optional).
CX20x214 Version: 1.7
4.3 Module overview
Product overview
CX20x2 15Version: 1.7
Product overview
4.4 Types
The basic CPU module can be ordered with different hardware and software options. Use this overview in
conjunction with the information on the name plate to ascertain the hardware, operating system and
TwinCAT version of the basic CPU module.
Fig.4: Nomenclature for the basic CPU module.
The basic CPU module CX2042, CX2062 and CX2072 is available with the following software options:
Table5: CX20x2, ordering information for software.
Module no
operating
system
CX20x2-0100 X - - X -
CX20x2-0150 - X - X -
CX20x2-0155 - X - - X
CX20x2-0170 - - X X -
CX20x2-0175 - - X - X
An CX20x2 Embedded PC with Windows 10 IoT Enterprise LTSB 64 bit requires a CFast card with a
capacity of at least 40GB.
Windows
10 IoT Enterprise
2016 LTSB
64-bit
Windows
10 IoT Enterprise
2019 LTSC
64-bit
no
TwinCAT
TwinCAT 3
XAR
CX20x216 Version: 1.7
Product overview
4.5 Architekture overview
The many-core CX20x2 Embedded PCs all have the same architecture, which is structured as follows:
Fig.5: CX20x0 architecture overview.
The CX20x2 Embedded PCs are based on the Broadwell microarchitecture developed by Intel. The following
CPUs are used:
• Intel® Xeon® D-1527,
• Intel® Xeon® D-1548,
• and Intel® Xeon® D-1567.
In addition to the arithmetic unit, the CPU also houses the memory controller. The memory is connected
directly to the memory controller. The Embedded PCs are available in three memory configurations: 8GB,
16GB and 32GB DDR4 RAM. The memory configuration must be ordered from the factory and is not
expandable.
The CX20x2 Embedded PCs have a graphics card with a separate 2GB RAM memory. This separation of
CPU RAM and GPU RAM prevents inhibitory influences between the two processing units.
The CX20x2 Embedded PCs feature all common interfaces:
• 4 x USB 3.0
• 1x USB 2.0 internal (power supply unit control button / display).
• DVI-I interface. Second interface optional: DVI-D or DisplayPort.
• 1 PCIe lane for each of the two Intel® WGI210IT Gigabit Ethernet controllers.
• LPC interface for super I/O controller for serial interface (CX20x0-N03x).
• 4 PCIe lanes via the multi-pole connection (left).
CX20x2 17Version: 1.7
Product overview
• 1 PCIe to FPGA for K-/E-bus and NOVRAM.
• 2x SATA internal via the multi-pole connection (right).
• 2x USB internal via the multi-pole connection (right).
The interfaces (USB, DVI, and LAN) are standard interfaces. Devices that meet the corresponding standard
can be connected to and operated at these interfaces. A VGA monitor can be connected to the DVI-I
interface with an adapter.
Intel® WGI210IT Gigabit Ethernet controllers are used as network controllers. There are two independent
LAN interfaces. Both LAN interfaces are gigabit-capable and support jumbo frames.
CX20x218 Version: 1.7
Description of the interfaces
5 Description of the interfaces
5.1 USB 3.0 interfaces (X100, X101, X102, X103)
Fig.6: USB 3.0 interfaces X100, X101, X102, X103.
The Embedded PC has four independent USB 3.0 interfaces for connecting keyboards, mice, touchscreens
and other input or data storage devices.
Fig.7: USB 3.0 interface, pin numbering.
Note the power consumption of the individual devices. Each interface is limited to 900mA. The USB 3.0
interface is of type A and corresponds to the USB 3.0 specification.
Table6: USB 3.0 interfaces (X100, X101, X102, X103), connection.
Pin Pinout Description
1 VCC (VBUS) 5 V for USBX
2 D- Minus data channel USBX
3 D+ Plus data channel USBX
4 GND Ground
5 StdA_SSRX- SuperSpeed Receiver-
6 StdA_SSRX+ SuperSpeed Receiver+
7 GND_DRAIN Ground
8 StdA_SSTX- SuperSpeed Transmitter-
9 StdA_SSTX+ SuperSpeed Transmitter+
Shell Shield Drain Wire
CX20x2 19Version: 1.7
Description of the interfaces
X000
X001
LAN 1
LAN 2
LINK / ACT 2
SPEED 2
LINK / ACT 1
SPEED 1
5.2 Ethernet RJ45 (X000, X001)
The two Ethernet interfaces are independent; no switch is integrated. The independent Ethernet interfaces
can be configured in different ways. In delivery state the Ethernet interfaces (X000, X001) are configured for
EtherCAT communication.
Note that an additional switch is required for a line topology.
Fig.8: Ethernet interface X000, X001.
Both Ethernet interfaces reach speeds of 10 / 100 / 1000 Mbit. The LEDs on the left of the interfaces indicate
the connection status. The upper LED (LINK/ACT) indicates whether the interface is connected to a network.
If this is the case the LED is green. The LED flashes when data transfer is in progress.
The lower LED (SPEED) indicates the connection speed. The LED does not light up if the speed is 10 Mbit.
The LED is green if the speed is 100 Mbit. The LED lights up red if the speed is 1000 Mbit (gigabit).
Fig.9: Ethernet interface, pin numbering.
Table7: Ethernet interface X000 and X001, pin assignment.
PIN Signal Description
1 T2 + Pair 2
2 T2 -
3 T3 + Pair 3
4 T1 + Pair 1
5 T1 -
6 T3 - Pair 3
7 T4 + Pair 4
8 T4 -
CX20x220 Version: 1.7
Description of the interfaces
5.3 DVI-I (X200)
The DVI-I interface (X200) transfers digital data and is suitable for connection to digital or analog monitors.
The resolution at the display or the Beckhoff Control Panel depends on the distance from the display device.
The maximum distance is 5 m. Beckhoff offers various Panels with an integrated “DVI extension”. These
make a cable length of up to 50 meters possible.
Fig.10: DVI-I interface X200.
Table8: DVI-I interface X200, pin assignment.
Pin Assignment Pin Assignment Pin Assignment
1 TMDS Data 2- 9 TMDS Data 1- 17 TMDS Data 0-
2 TMDS Data 2+ 10 TMDS Data 1+ 18 TMDS Data 0+
3 TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield 19 TMDS Data 0/5 Shield
4 not connected 12 not connected 20 not connected
5 not connected 13 not connected 21 not connected
6 DDC Clock 14 + 5V Power 22 TMDS Clock Shield
7 DDC Data 15 Ground ( +5V, Analog H/V
Sync)
8 Analog Vertical Sync 16 Hot Plug Detect 24 TMDA Clock -
23 TMDS Clock +
Table9: DVI-I cross, pin assignment.
Pin Assignment
C1 Analog Red Video Out
C2 Analog Green Video Out
C3 Analog Blue Video Out
C4 Analog Horizontal Sync
Table10: DVI-I interface X200, resolution at the monitor.
Resolution in pixels Distance of the interface from the monitor
1920 x 1200 5 m
1920 x 1080 5 m
1600 x 1200 5 m
1280 x 1024 5 m
1024 x 768 5 m
800 x 600 5 m
640 x 480 5 m
The Embedded PC also supports higher resolutions, based on the DVI standard. A maximum resolution of
2560 x 1440 pixels can be set on the Embedded PC. Whether this resolution is achieved depends on the
monitor, the cable quality and the cable length.
CX20x2 21Version: 1.7
Description of the interfaces
5.4 Optional interfaces
5.4.1 DVI-D (N010)
The DVI-D interface (X300) transfers digital data and is suitable for connection to digital displays. If the
optional N010 interface (DVI-D interface) is used, the first DVI-I interface can be operated either in VGA
mode or in DVI mode. The resolution at the display or the Beckhoff Control Panel depends on the distance
from the display device. The maximum distance is 5 m. Beckhoff offers various Panels with an integrated
“DVI extension”. These make a cable length of up to 50 meters possible.
Fig.11: DVI-D interface X300.
Table11: DVI-D interface X300, pin assignment.
Pin Assignment Pin Assignment Pin Assignment
1 TMDS Data 2- 9 TMDS Data 1- 17 TMDS Data 0-
2 TMDS Data 2+ 10 TMDS Data 1+ 18 TMDS Data 0+
3 TMDS Data 2/4 Shield 11 TMDS Data 1/3 Shield 19 TMDS Data 0/5 Shield
4 not connected 12 not connected 20 not connected
5 not connected 13 not connected 21 not connected
6 DDC Clock 14 + 5V Power 22 TMDS Clock Shield
7 DDC Data 15 Ground ( +5V, Analog H/V
Sync)
8 Analog Vertical Sync 16 Hot Plug Detect 24 TMDA Clock -
23 TMDS Clock +
Table12: DVI-D interface X300, resolution at the monitor.
Resolution in pixels Distance of the interface from the monitor
1920 x 1200 5 m
1920 x 1080 5 m
1600 x 1200 5 m
1280 x 1024 5 m
1024 x 768 5 m
800 x 600 5 m
640 x 480 5 m
The Embedded PC also supports higher resolutions, based on the DVI standard. A maximum resolution of
2560 x 1440 pixels can be set on the Embedded PC. Whether this resolution is achieved depends on the
monitor, the cable quality and the cable length.
CX20x222 Version: 1.7
Description of the interfaces
5.4.2 DisplayPort (N011)
The DisplayPort transfers image and audio signal at the same time and is therefore suitable for connecting
panels or monitors to the Embedded PC.
Fig.12: DisplayPort X300.
Version 1.1a of the DisplayPort (DisplayPort++) is installed on the Embedded PC. Adapters from DisplayPort
to DVI-D or DisplayPort to HDMI can be used to connect monitors without DisplayPort to the Embedded PC.
Table13: DisplayPort, pin assignment.
Pin Assignment Pin Assignment
1 LVDS lane 0+ 2 Ground
3 LVDS lane 0- 4 LVDS lane 1+
5 Ground 6 LVDS lane 1-
7 LVDS lane 2+ 8 Ground
9 LVDS lane 2- 10 LVDS lane 3+
11 Ground 12 LVDS lane 3-
13 Config 1 14 Config 2
15 AUX channel+ 16 Ground
17 AUX channel- 18 Hot-plug detection
19 Power supply: ground 20 Power supply: 3.3 V / 500 mA
Table14: DisplayPort X300, resolution at the monitor.
Interface Resolution in pixels
DisplayPort max. 2560 x 1600 @ 60 Hz
DisplayPort with adapter, DisplayPort to DVI-D max. 1600 x 1200 @ 60 Hz
CX20x2 23Version: 1.7
Description of the interfaces
5.4.3 RS232 (N030)
The optional N030 interface provides an RS232 interface (X300). The RS232 interface is implemented on a
9-pin D-sub connector.
Fig.13: RS232 interface X300 with pin numbering.
The maximum baud rate on both channels is 115 kbit. The interface parameters are set via the operating
system or from the PLC program.
Table15: RS232 interface X300, pin assignment.
PIN Signal Type Description
1 DCD Signal in Data Carrier Detected
2 RxD Signal in Receive Data
3 TxD Signal out Transmit Data
4 DTR Signal out Data Terminal Ready
5 GND Ground Ground
6 DSR Signal in Dataset Ready
7 RTS Signal out Request to Send
8 CTS Signal in Clear to Send
9 RI Signal in Ring Indicator
CX20x224 Version: 1.7
