B10
60 cm Side control 4 radiant zone ceramic hob
User Manual for your Baumatic
B10
60 cm Side control 4 radiant zone ceramic hob.
NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
DD 16/02/11
2
Contents
Environmental note |
4 |
|
Important safety information |
5 – 8 |
|
Specifications |
8 |
|
Product and aperture dimensions |
8 |
|
Product specifications |
8 |
|
Standard accessories |
8 |
|
Electrical details |
9 |
|
Ceramic hob surface layout |
9 |
|
Using the ceramic hob |
10 |
|
Before first use |
10 |
|
Control knobs |
10 |
|
Turning on a zone and setting a power level |
10 |
|
Residual heat indicator |
11 |
|
Hob guidelines |
11 |
– 12 |
Cleaning and maintenance |
12 |
|
Cleaning the ceramic hob top |
12 |
|
After each use |
13 |
|
Cleaning table |
13 |
|
Using a ceramic hob scraper |
13 |
|
Using a specialist ceramic hob cleaner |
14 |
|
Installation |
14 |
|
Positioning |
15 |
|
Unpacking the appliance |
15 |
|
Installing the appliance |
16 |
– 17 |
Electrical connection |
18 |
|
Connecting the mains supply cable |
18 |
- 19 |
Replacing the mains supply cable |
19 |
- 20 |
My appliance isn’t working correctly |
20 |
– 21 |
Contact details |
22 |
|
3
Environmental note
oThe packaging materials that Baumatic uses are environmentally friendly and can be recycled.
oPlease discard all packaging material with due regard for the environment.
4
Important safety information
Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department.
General Information
oThis appliance is designed for domestic household use and for the cooking and frying of domestic foodstuffs.
oIMPORTANT: The adjacent furniture and all materials used in the installation must be able to withstand a minimum temperature of 85°C above the ambient temperature of the room it is located in, whilst in use.
o Certain types of vinyl or laminate kitchen furniture are particularly prone to heat damage or discolouration at temperatures below the guidelines given above.
o Any damage caused by the appliance being installed in contravention of this temperature limit, will be the liability of the owner.
o Your new appliance is guaranteed against electrical or mechanical defects, subject to certain exclusions that are noted in Baumatic’s Conditions Of Guarantee. The foregoing does not affect your statutory rights.
oThe use of this appliance for any other purpose or in any other environment without the express agreement of Baumatic Ltd. will invalidate any warranty or liability claim.
oYou should not use this appliance to store items on or as a work surface.
o No modifications to the appliance are permitted by Baumatic Ltd.
oYou should not store or place flammable or highly flammable liquids/materials on top of or near the appliance. Items made from aluminium, plastic or plastic film should also be kept away from the appliance, as they may fuse to the surface.
o Repairs may only be carried out by Baumatic Service
Engineers or their authorised service agent.
5
Child Safety
oBaumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. During and after use, all surfaces will become hot.
oIf it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
oOlder children should only be allowed to utilise the appliance when supervised.
General Safety
The appliance should only be installed and connected by a suitable qualified person.
Care should be taken to ensure that the units and work surfaces that you build the appliance into, meet with the relevant standards.
If you notice any scratches, splits or cracks in the ceramic glass, you should immediately switch off the appliance and disconnect it from your mains supply. Otherwise there is the risk of electric shock occurring.
During use
Any film or stickers that are present on the hob surface when it is delivered should be removed before use.
Care should be used when utilizing the appliance, otherwise there is a risk of burns being caused.
oYou should not allow the electrical connection cables to come into contact with the hob surface when it is hot or any hot cookware.
oIf fat and oil overheats, then it can ignite extremely quickly. For this reason, when cooking with fat and oil the appliance should not be left unattended.
Make sure that all of the cooking zones are switched off after use.
6
Cleaning
o Cleaning of the hob should be carried out on a regular basis.
o IMPORTANT: Before attempting to clean the appliance, it should be disconnected from the mains and cool.
oGreat care should be taken whilst using this appliance and when following the cleaning procedure.
oYou should not use a steam jet or any other high pressure cleaning equipment to clean the appliance.
Installation
This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. Please see the specific section of this booklet that refers to installation.
o Baumatic Ltd. declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
Declaration of conformity
This appliance complies with the following European Directives:
-73/23/EEC dated 19/02/1973 Low Voltage Directive.
-89/336/EEC dated 03/05/1989 EMC Directive inclusive of Amending Directive 92/31/EEC.
-93/68/EEC dated 22/07/1993 CE Marking Directive. -89/109/EEC dated 25/01/1992 Materials that can touch food.
oThe manufacturer declares that the hob is built using certified materials and requires the appliance to be installed in accordance with the standards currently in force. This appliance must be used by a trained person for domestic purposes only.
To avoid damaging your appliance
o The ceramic glass can be damaged by objects falling onto it.
o The ceramic glass edge can be damaged by knocks from cookware.
oCast iron and cast aluminium cookware with damaged bases may scratch the ceramic surface if they are dragged across it.
7
o Pans should be lifted on and off the hob surface and not dragged.
o Cooking zones should not be switched on without cookware placed on it. Also the cookware should not be empty.
Specifications
Product dimensions: |
Aperture dimensions: |
||
Height: |
510 mm |
Height: |
490 mm |
Width: |
580 mm |
Width: |
560 mm |
Depth: |
40 mm |
|
|
Product specifications:
o 2 x 1.70 kW radiant zones (diametre 180 mm) o 2 x 1.20 kW radiant zones (diametre 140 mm) o Side control operation
o 4 x Individual heat indicators o Frameless
Standard accessories
o Ceramic hob scraper
8
