About the Product
HomePlug AV is ready to use out of the box and does not require the installation of driver
software to work. It can be connected to computers, routers, gaming consoles, hubs,
IPTV set-top boxes, and other Ethernet devices regardless of operating system.
How Does It Work?
HomePlug AV Wireless N Extender utilizes the existing electrical wiring in the house as a
path to create a secured network of computers, Ethernet devices and Wireless devices.
With a maximum data rate of up to 200 Mbps, HomePlug AV can reliably handle high
requirement applications like broadband Internet, high definition video streaming, and
Voice over IP.
HomePlug AV converts digital signals to a complex analog signal that traverses along the
electrical wires. When receiving the analog signal, HomePlug AV converts the analog
signal back to digital. To make the signal secured, a 128-bit AES encryption is applied.
A HomePlug AV device can only communicate with other HomePlug AV devices that use
the same Private Network Name. The Private Network Name can be changed manually
using the HomePlug AV Utility software on a computer with a Windows operating system.
When you use the software, you have to manually type the Private Network Name for
the device. Another way to change the Private Network Name is to use the Simple
Connect button. Simple Connect automatically creates an encrypted Private Network
Name. It can also be used to reset the Private Network Name or to add a device into an
existing HomePlug AV network.
Note:
Note: HomePlug AV devices from the Twin Pack are already configured to use a common Private Network
Note:Note:
Name unique for that pair and are ready to use. The HomePlug AV from a Single Pack, on the other hand,
uses a random Private Network Name. You still need to change its Private Network Name to allow it to
communicate with an existing HomePlug AV network.
When a HomePlug AV communicates with another device, the Powerline Activity LED
color will give you an idea about the connection rate: Red means below 30 Mbps; Amber
means 30 to 80 Mbps; and Green means more than 80 Mbps.
Page 5 of 45
User Manual v1.0
Direct Connection
For best performance, connect HomePlug AV Wireless N Extender directly to a wall outlet.
Avoid connecting it to a power strip where other electrical devices are connected. Other
devices create electrical noise that may affect the performance of HomePlug AV.
Page 6 of 45
User Manual
Package Contents
The package contains the following items:
• 1 HomePlug AV Wireless N extender for Single Pack or 2 HomePlug AV Wireless N
extender for Twin Pack
1 Ethernet cable for Single Pack or 2 Ethernet cables for Twin Pack
•
• Resource CD that contains the HomePlug AV Wireless N Extender Utility installer
and the User Manual.
• Easy Start Guide
Device Design
A
B
C
G
F
E
D
Page 7 of 45
User Manual v1.0
Label
Label Status
LabelLabel
Power
PowerPower
Powerline Activity
Powerline ActivityPowerline Activity
Ethernet Activity
Ethernet ActiviEthernet Activi
ty
tyty
Status Description/ Function
StatusStatus
Description/ Function
Description/ FunctionDescription/ Function
Off No power. A Power
On • After Pairing Button is pressed for two seconds,
this LED will blink to confirm the button press.
When Pairing Button is pressed for 10 seconds,
•
this LED will blink to confirm the Private
Network Name reset.
Off Device is not connected to a HomePlug AV network. B Powerline Activity
On • This LED remains on when the device is part of
a HomePlug AV network.
The LED color represents the connection rate
•
within the HomePlug AV network whether it is
Good (Red), Better (Amber), or Best (Green).
The LED flashes to indicate network activity.
•
Off An Ethernet device is not connected. C Ethernet Activi
On
An Ethernet device is connected.
•
The LED flashes to indicate Ethernet activity.
•
D Wireless LED/Button
Wireless LED/Button
Wireless LED/Button Wireless LED/Button
Off Wireless is disabled
ON • Wireless is enabled
• Transmitting/Receiving data via wireless
Button
Press to Enable or Disable Wireless.
•
E Simple Connect Button
Simple Connect Button
Simple Connect ButtonSimple Connect Button
Press for 2 seconds to start pairing.
•
Press for 10 seconds to release the Random
•
NMK.
F Ethernet Port
Ethernet Port Accepts either cross or straight Ethernet cable.
Ethernet Port Ethernet Port
G Reset to Factory Default
Reset to Factory Default Press for 3 seconds to reset to the factory default
Reset to Factory DefaultReset to Factory Default
settings. When you reset to the factory default, all your
configuration changes will be removed.
Page 8 of 45
User Manual
How to Use Simple Connect
Simple Connect provides a more convenient way of creating your HomePlug AV network
without the need to open the HomePlug AV Utility software from a computer. The button
has three main functions which includes:
• Creating a HomePlug AV Network
• Resetting the Private Network Name
• Joining an existing HomePlug AV Network
Simple
Connect
Button
Creating a HomePlug AV Network
To create a HomePlug AV network, you need at least two HomePlug AV devices using
random Private Network Names. When you press Simple Connect Button on both devices,
a common Private Network Name will be automatically generated to enable them to
communicate with each other.
Note:
Note: New HomePlug AVs from a Twin Pack can already communicate with each other out of the box.
Note:Note:
However, if you intend to create a new Private Network Name using Simple Connect for both devices, you
need to reset their Private Network Names to a random key before proceeding.
Page 9 of 45
User Manual v1.0
To create a HomePlug AV network using Simple Connect:
Step 1
Plug your HomePlug AVs side by side where
you can easily observe the LED behavior.
Upon connection, the LEDs will blink
simultaneously and then the Power LED
lights on steadily.
Step 2
Press Simple Connect Button for two seconds
on HomePlug X.
After you release the button, the Power LED
will blink.
If the Power LED did not blink, press Simple
Connect Button again for two seconds.
Note:
Note: Do not press Simple Connect for more than 2
Note:Note:
seconds.
Page 10 of 45
Step 3
Press Simple Connect Button for two seconds
on HomePlug Y.
After you release the button, the Power LED
will blink.
If the Power LED did not blink, press Simple
Connect Button again for two seconds.
Make sure to press Simple Connect Button on
HomePlug Y within two minutes after you
press Simple Connect on HomePlug X.
Note:
Note: The Power LEDs on both devices will switch off
Note:Note:
and on to signify that they are searching for another
device to pair with.
User Manual
Page 11 of 45
User Manual v1.0
Correct
Wrong
Step 4
To confirm if the connection was established,
check the LEDs.
The Power LEDs and the Powerline Activity
LEDs on both HomePlugs are on.
The Power LED on both devices will stop
blinking.
When the Powerline Activity LED on either
HomePlug X or HomePlug Y is off, this means
the pairing is not successful. In this case, you
need to redo the entire process again.
Step 5
Unplug the HomePlug AVs and then connect them to your Ethernet devices using the
Ethernet cables from the product package. After connecting the Ethernet cable, plug the
HomePlugs directly to a wall outlet.
An Ethernet-enabled device can be a router, computer, hub, gaming console, IP phone,
network printer, or IP TV set-top box.
Note:
Note: HomePlug AVs work best when connected directly to a wall socket. Avoid plugging it to a power strip
Note:Note:
or power extension. Other electrical devices in the power strip produce electrical noise that may affect the
performance of the HomePlug.
Page 12 of 45
Resetting the Private Network Name
User Manual
Simple Connect Button allows you to reset the HomePlug AV’s Private Network Name to
a random key. When a HomePlug AV is reset to a random key, it will not be able to
communicate with any other device.
Note:
Note: Resetting the Private Network Name is different from resetting the device to its factory default
Note:Note:
settings. If you intend to reset the device to its factory default settings, press RESET on the device.
Page 13 of 45
User Manual v1.0
To reset the Private Network Name using Simple Connect:
Step 1
Press Simple Connect Button for 10
seconds or wait until ALL LED blinks in
Green to Amber color except for
Wireless LED.
Step 2
To confirm the Private Network Name
reset, the Powerline Activity LED will
switch off.
Joining an Existing HomePlug AV Network
To enable a new device to join an existing network, Simple Connect Button will copy the
Private Network Name of the existing network to the new HomePlug AV. If you pressed
Simple Connect Button from multiple HomePlug AVs, only the signal from the first two
devices will be processed.
To join an existing HomePlug AV network using Simple Connect:
Step 1
Plug HomePlug Z near a HomePlug from an
existing network. Make sure you can easily
observe the LED behavior.
Upon connection, HomePlug Z’s LEDs will blink
simultaneously and then the Power LED lights
on steadily.
Page 14 of 45
Step 2
Blinks after press
Blinks after pressBlinks after press
Blinks after press
Blinks after press
Blinks after pressBlinks after press
Blinks after press
Press Simple Connect Button for two seconds
from a HomePlug AV in an existing network.
After you release the button, the Power LED
will blink.
If the Power LED did not blink, press Simple
Connect Button again for two seconds.
Note:
Note: Do not press Simple Connect for more than 2
Note:Note:
seconds.
Step 3
Press Simple Connect for two seconds
User Manual
on HomePlug Z. After you release the
button, the Power LED will blink. If the
Power LED did not blink, press Simple
Connect again for two seconds.
Make sure to press Simple Connect on
HomePlug Z within two minutes after you
press Simple Connect from the existing
network.
The LEDs on both devices will switch off
and on twice to signify that they are
searching for another device to pair with.
Note:
Note: Do not press Simple Connect for more than
Note:Note:
2 seconds.
Page 15 of 45
User Manual v1.0
Step 4
To confirm if the connection was
established, check the LEDs.
The Power LEDs and the Powerline
Activity LEDs on all HomePlugs are on.
If the Powerline Activity LED on
HomePlug Z is off, this means the pairing
was not successful. You need to repeat
ON
OFF
the process again.
Step 5
Unplug HomePlug Z and then connect it to your Ethernet device using the Ethernet cables
from the product package. After connecting the Ethernet cable, plug HomePlug Z directly
to a wall outlet. An Ethernet-enabled device can be a router, computer, hub, gaming
console, IP phone, network printer, or IP TV set-top box.
Note:
Note: HomePlug AVs work best when connected directly to a wall socket. Avoid plugging it to a power strip
Note:Note:
or power extension. The other electrical devices in the power strip create noise that may affect the
performance of the HomePlug.
Page 16 of 45
User Manual
Determining Connection Rate
Each LED color of the Powerline Activity represents a connection rating. The connection
rating can only be calculated when the device is part of an existing network. The exact
connection rate value can also be viewed using HomePlug AV Utility.
Good (Red) Better (Amber) Best (Green)
Connection rate is
less than 30 Mbps
Connection rate is
between 30 to 80 Mbps
Connection rate is
more than 80 Mbps
Page 17 of 45
User Manual v1.0
AV Wireless N Extender
Use an Ethernet cable to connect
HomePlug AV Wireless N Extender to
Install HomePlug AV Wireless N
Extender Utility to apply manual
configuration changes and monitor
Getting Started
Setting up the device is easy. The flowchart below provides an outline of the steps you
need to complete the installation. There are brief descriptions beside each step to help
you along. Detailed instructions are provided in the subsequent pages.
Plan your Network
Setup the HomePlug
Install HomePlug AV
Wireless N Extender
Utility Software
Ready to Use
your computer or Ethernet device.
device activity.
Page 18 of 45
User Manual
Plan Your Network
Here are ideas on how you can plan your HomePlug AV network.
Local Network
Share ultra fast Internet connection with any computer wherever it is in the house.
Gaming Network
Connect your gaming console to the Internet and compete with other online players.
Page 19 of 45
User Manual v1.0
Entertainment Network
Experience IP TV streaming into your home entertainment system.
Media Network
Realize your high tech lifestyle by converging your IP devices into a single network.
Page 20 of 45
User Manual
Setup the HomePlug AV Wireless N Extender
For Twin Pack
HomePlug AVs from a Twin Pack are preconfigured to have a common Private Network
Name unique for that pair. All you need to do is connect the HomePlug AVs to an
Ethernet device and then plug it to a wall socket.
To setup a pair of HomePlug AVs:
1. Plug one end of the Ethernet cable to your Ethernet device and then connect the
other end to HomePlug AV.
2. Connect the HomePlug AV to a wall socket.
3. Plug one end of the Ethernet cable to your other Ethernet device and then
connect the other end to HomePlug AV.
4. Connect the HomePlug AV to a wall socket.
For Single Pack
A HomePlug AV from a single pack uses a random Private Network Name that prevents it
from communicating with other HomePlug AVs. To add it into an existing network, you
need to use either the Simple Connect button or the HomePlug AV Wireless N Extender
Utility software to change the random Private Network Name to the Private Network
Name being used by the existing HomePlug AV network.
To add a HomePlug AV to an existing network:
1. Plug one end of the Ethernet cable to your Ethernet device and then connect the
other end to HomePlug AV.
2. Connect the HomePlug AV to a wall socket.
3. Add the new HomePlug AV by using either Simple Connect or the HomePlug AV
Utility software. To use Simple Connect, please refer to Joining an Existing
HomePlug AV Network. To use HomePlug AV Utility, please refer to Private
Network Name.
Page 21 of 45
User Manual v1.0
Connecting via Wireless
Before plugging in your HomePlug AV into the wall socket check the sticker and write
down the Wireless SSID.
To add a HomePlug AV to an existing network:
1. Plug one end of the ethernet cable to your Ethernet device and then connect the
other end to the HomePlug AV.
2. Open your Wireless Utility then search for the HomePlug AV Wireless N Extender’s
SSID.
3. Click Connect button from your Wireless utility to connect to your HomePlug AV
Wireless N Extender.
Page 22 of 45
User Manual
HomePlug AV Wireless N Extender
Utility
HomePlug AV Wireless N Extender Utility is a software application that allows you to
configure HomePlug AV and Wireless settings. Installation is straightforward and the user
interface is easy to use.
Note:
Note: To use HomePlug AV Wireless N Extender Utility, you need a computer using a Windows operating
Note:Note:
system with the .NET Framework installed. If you do not have .NET installed, the HomePlug AV installer will
install it for you.
Requirements
Your computer must meet the following requirements:
Windows XP/Vista/ Windows 7
300 MHz Processor
128 Mb of RAM
.NET Framework
Network Interface Card
CD-ROM
128 Mb of free hard disk space
Page 23 of 45
User Manual v1.0
Installation
To install HomePlug AV Wireless N Extender Utility:
1. Insert the Resource CD that comes with HomePlug AV Wireless N Extender into the
CD-ROM drive.
2. Click the Start button, and then click Run.
3. In the Run dialog box, type D:\Setup.exe (where D: is your CD-ROM drive), and
then click OK.
4. Follow the instructions on the installation wizard.
Two applications will be installed in your computer - HomePlug AV Wireless N
Extender Utility will be installed first followed by .NET Framework. The installer
detects any version of .NET Framework in your computer. If .NET Framework is not
installed, a dialog box opens to ask if you would like to install .NET Framework.
Click Yes. The .NET Framework will not be installed if the required version is
already in your computer.
Ope
Operating System
rating System .NET Framework version to be installed
OpeOpe
rating Systemrating System
XP and Vista 32-bit .NET Framework 2.0 32-bit
XP and Vista 64-bit .NET Framework 2.0 64-bit
.NET Framework version to be installed
.NET Framework version to be installed.NET Framework version to be installed
Page 24 of 45
User Manual
Opening HomePlug AV Wireless N
Extender Utility
Two ways to open Utility:
Double click the HomePlug icon on the desktop.
Click the Start button> Programs> HomePlug AV> HomePlug AV Wireless N
Extender, and then click HomePlug AV Wireless N Extender Utility.
The User Interface
The HomePlug AV Wireless N Extender Utility user interface is divided into tabs. These
tabs include:
Home
Homeplug
Wireless
Firmware Upgrade
Page 25 of 45
User Manual v1.0
Home
Home provides a list of all the possible tasks you can perform in the HomePlug AV Utility.
To start a task, you first need to select the network card connected to your HomePlug AV.
This is most helpful when you have more than one network card in your computer. When
you select a network card, the MAC Address of the HomePlug AV connected to your
computer appears. If there is no HomePlug AV connected to your computer, no MAC
address will appear.
After selecting the network card, there are four possible tasks you can perform. These
tasks include:
• Change HomePlug AV settings
Change Wireless Settings
•
• Upgrade the firmware
When you select any task, you will be forwarded to the tab for the selected task.
Home
Home
HomeHome
Page 26 of 45
User Manual
HomePlug
HomePlug allows user to change the Private Network Name, set the QoS and monitor the
Devices on the network. Select the tabs to configure the settings.
Change Private Network Name
•
• Quality of Service
Devices
•
HomePlug
HomePlug
HomePlugHomePlug
Page 27 of 45
User Manual v1.0
Private Network Name
Private Network Name provides the function to manually change the Private Network
Name of local and remote HomePlug AVs. A Private Network Name is a string of 8 to 64
characters enables HomePlug AV devices to communicate with each other.
If you intend to create multiple networks, you can assign different Private Network
Names among your devices. You have to, however, make sure that at least two
HomePlug AVs have a similar Private Network Name. A HomePlug AV that uses a unique
or random Private Network Name will not be able to communicate with other devices.
Private Network Name
Private Network Name
Private Network NamePrivate Network Name
Note:
Note: In case you cannot connect into the network after changing the Private Network Name, please
Note: Note:
power cycle the device. To power cycle, disconnect and then reconnect HomePlug AV from the power
outlet.
Page 28 of 45
User Manual
Local Private Network Name
Local Private Network Name refers to the Private Network Name of the HomePlug AV
that is directly connected to the computer where you use HomePlug AV Utility.
To change the local Private Network Name:
1. Open HomePlug AV Utility.
2. Click Private Network Name.
3. Type the new Private Network Name. This field is case sensitive. It accepts 8 to 64
alphanumeric characters including punctuation marks but no spaces.
4. Click Apply. When the process is complete, the message Settings Applied appears.
Remote Private Network Name
Without leaving your computer, you can change the Private Network Name of remote
HomePlug AV devices, provided they are using the same Private Network Name as your
local HomePlug AV. You cannot change the Private Network Name of remote devices that
is not currently networked with your local HomePlug AV.
Note:
Note: When changing the Private Network Name of remote devices, you will need the Device ID that
Note: Note:
appears on the label pasted on the device. It will be more helpful if you list down the Device ID of all your
HomePlug AVs to enable you to remotely change their settings using the HomePlug AV Utility software.
To change the Private Network Name of a remote HomePlug AV:
1. Open HomePlug AV Utility.
2. Click Private Network Name.
3. Type the new Private Network Name. This field is case sensitive. It accepts 8 to 64
alphanumeric characters including punctuation marks but no spaces.
4. Select Change Private Network Name of remote device.
Page 29 of 45
User Manual v1.0
5. Type the Device ID of the remote device. The Device ID can be found on the label
pasted on the device.
6. Click Apply. When the process is complete, the message Settings Applied appears.
After changing the Private Network Name of the remote HomePlug AV, it will no
longer be able to communicate with your local HomePlug AV, unless you use a
similar Private Network Name for your local HomePlug AV.
Simulate Simple Connect Button
Simulate Simple Connect Button allows you to apply functionalities without manually
pressing the Simple Connect button on a HomePlug AV device. However, this only works
on local devices.
Simple Connect
Simple Connect Select to search and pair with another device, or search and join
Simple ConnectSimple Connect
an existing HomePlug AV network.
NMK Randomize
NMK Randomize Select to reset to a random Private Network Name. A HomePlug
NMK RandomizeNMK Randomize
AV using a random Private Network Name will be disconnected from the
HomePlug network and will not be able to communicate with other devices until
it forms a new network or joins an existing network.
AVLN
AVLN Status
AVLNAVLN
number.
Note:
Note: The Simulate Simple Connect Button functions from HomePlug AV Utility can be used for HomePlug
Note:Note:
AV versions with or without the Simple Connect button on the device.
Status Displays the HomePlug AV Logical Network membership status
StatusStatus
Page 30 of 45
User Manual
To simulate a Simple Connect function:
1. Connect HomePlug AV to your computer.
2. Select a Simulate Simple Connect Button action:
a. Simple Connect
b. PNN Randomize
c. AVLN Status
3. Click Simulate Button Push.
Quality of Service
Quality of Service gives you the capability to prioritize particular applications within your
network. QoS is not enabled by default.
Quality of Service
Quality of Service
Quality of ServiceQuality of Service
Page 31 of 45
User Manual v1.0
QoS Modes:
Online Game/Internet
Online Game/Internet Prioritizes data streaming
Online Game/Internet Online Game/Internet
Audio or Video
Audio or Video Prioritizes data streaming multimedia streaming
Audio or Video Audio or Video
Voice over IP
Voice over IP Prioritizes voice applications
Voice over IPVoice over IP
To enable QoS:
1. Open HomePlug AV Utility.
2. Click Quality of Service.
3. Check Enable QoS.
4. Select a QoS mode.
5. Click Apply. When the process is complete, the message Settings Applied appears.
Page 32 of 45
User Manual
Devices
Devices displays information about remote HomePlug AV’s detected in the network. Only
HomePlug AVs using the same Private Network Name as the local HomePlug AV will
appear in the Remote Devices list.
Devices
Devices
DevicesDevices
Devices displays the following information:
TEI
TEI Displays the Terminal Equipment Identifier.
TEITEI
Device MAC address
Device MAC address Displays the HomePlug AV MAC Address.
Device MAC address Device MAC address
Bridge MAC Address
Bridge MAC Address Displays the MAC Address of the Ethernet network adapter
Bridge MAC Address Bridge MAC Address
connected to the HomePlug AV.
Connection Rate
Connection Rate Displays the Transmit and Receive connection rates.
Connection Rate Connection Rate
Page 33 of 45
User Manual v1.0
Wireless
Wireless allows user to change the Wireless Settings, monitor the wireless clients
connected to the device and control the wireless clients that is allowed to connect to the
network via wireless.
Wireless Status
•
• Wireless Settings
• Wireless Filtering
Wireless
Wireless
WirelessWireless
Wireless Status
Wireless status gives you the summary of the wireless settings of the device and
wireless clients connected to it.
Page 34 of 45
User Manual
Wireless Status
Wireless Status
Wireless StatusWireless Status
SSID
SSID: Displays the wireless SSID of the device.
SSIDSSID
Wireless Security
Wireless Security: Displays the wireless security set to the device.
Wireless SecurityWireless Security
WLAN MAC address
WLAN MAC address: Displays the unique WLAN MAC address of the device.
WLAN MAC addressWLAN MAC address
Wireless Client List
Wireless Client List
Wireless Client ListWireless Client List
Displays the wireless client’s MAC addresses connected to the device. This allows you to
monitor the wireless clients that are connecting to your network.
Wireless Settings
Displays the wireless settings of the device. This allows you to change the wireless
configuration of your device.
Page 35 of 45
User Manual v1.0
Wireless Settings
Wireless Settings
Wireless SettingsWireless Settings
Wireless Enable
Wireless Enable
Wireless EnableWireless Enable
1. Check the box the “Enable” wireless connection then click “Save”.
2. Uncheck the box to “Disable” wireless connection then click “Save”.
SSID
SSID:
SSIDSSID
1. Displays the default Wireless SSID of the device.
2. Enter your desired password then click “Save”.
Mode:
Mode:
Mode: Mode:
1. Displays the wireless mode of the device.
2. Change your wireless mode from the drop down box then click “Save”.
Channel:
Channel:
Channel:Channel:
1. Displays the wireless channel of the device.
2. Set your wireless channel to where it is not populated from the drop down
box then click “Save”.
Page 36 of 45
Broadcast SSID
Broadcast SSID:
Broadcast SSIDBroadcast SSID
1. Select “Enable” to broadcast the wireless SSID.
2. Select “Disable” to hide the wireless SSID.
Security Ty
Security Type
Security TySecurity Ty
pe:
pepe
1. Set your wireless security from the drop down box. User may choose from
None, WEP, WPA, WPA2
WEP, WPA, WPA2 and WPA/WPA2
WEP, WPA, WPA2WEP, WPA, WPA2
WPA/WPA2.
WPA/WPA2WPA/WPA2
User Manual
Encryption Type:
Encryption Type:
Encryption Type:Encryption Type:
1. For WPA, WPA and WPA/WPA2 security type you may select the encryption
type from TKIP, AES and TKIP/AES.
Key/Passphrase:
Key/Passphrase:
Key/Passphrase:Key/Passphrase:
1. Displays the wireless security password.
2. Enter your desired password on the field required then click “Save”.
Wireless Filtering
Wireless Filtering allows you to manage the wireless clients that will have an access to
the network.
Wireless Filtering
Wireless Filtering
Wireless FilteringWireless Filtering
Page 37 of 45
User Manual v1.0
Enable
Enable MAC Filtering
EnableEnable
MAC Filtering:
MAC Filtering MAC Filtering
1. Check the box to “Enable” MAC Filtering.
2. Uncheck the box to “Disable” MAC Filtering.
3. Enter the wireless MAC address that you would like to have an access on
the network to the required field then click “Save”.
Firmware Upgrade
Use Firmware Upgrade to upgrade firmware of HomePlug AV Wireless N Extender. After
upgrading the firmware, HomePlug AV will still retain the same Private Network Name
and MAC address settings. Before you proceed with the upgrade, you need to have the
updated firmware. You can download upgrade files from the product’s Web site.
Firmware Upgrade
Firmware Upgrade
Firmware UpgradeFirmware Upgrade
To upgrade the firmware of a HomePlug AV Wireless N Extender:
1. Connect HomePlug AV Wireless N Extender to the computer where you are using
HomePlug AV Wireless N Extender Utility.
2. Open HomePlug AV Wireless N Extender Utility.
3. Click Firmware Upgrade.
Page 38 of 45
User Manual
4. Click Browse to select the location of the firmware. After you select the location of
firmware file, the upgrade will immediately start.
To reset to factory default:
1. Connect HomePlug AV Wireless N Extender to the computer where you are using
HomePlug AV Utility.
2. Open HomePlug AV Utility.
3. Click Factory Default.
Note:
Note: You can also perform a reset to the factory default when you press the RESET button on the device
Note: Note:
for 2 seconds.
Page 39 of 45
User Manual v1.0
Appendix
Frequently Asked Questions
Can I use HomePlug AV with older HomePlug versions?
All HomePlug AV versions can communicate with each other. HomePlug AV, however, is
not backward compatible with HomePlug 1.0 releases.
If you will use different versions of HomePlug AV in a single network, you need to use
the HomePlug AV Utility software to create a Private Network Name for all devices.
Unlike the new version of HomePlug AV, older versions do not feature the Simple
Connect button, which enables the device to create a common Private Network Name
without using the software.
How does HomePlug AV achieve a higher bandwidth than HomePlug Turbo and
HomePlug 1.0 devices?
HomePlug AV complies with the HomePlug AV standard. It achieves higher data
throughput by using a broader frequency spectrum (2-30 MHz rather than 4-21 MHz), by
using a better access method (Time Division Multiple Access rather than Carrier Sense
Multiple Access/Collision Detection), and by using a better processor with a greater
bitload per Hz.
Can HomePlug AV be used alongside HomePlug 1.0 devices within the network?
HomePlug 1.0 and HomePlug AV standards can coexist but they will not be able to
communicate with each other.
Which operating system (OS) is compatible with HomePlug AV?
HomePlug AV is operating system independent. However, the HomePlug AV Utility
requires a Windows operating system (XP/Vista) with the .NET Framework installed.
How difficult is it to set up a network with HomePlug AV?
HomePlug AV is a plug and play device. Connect it to an Ethernet device, plug it to a wall
socket, and it is ready to use. Even the most inexperienced user can set up the network
Page 40 of 45
User Manual
with ease. Installing the HomePlug AV Utility software is only needed if you intend to
manually change the Private Network Name or view the connection rate.
How many devices do I need to create a HomePlug AV network?
At least two devices are needed to create a HomePlug AV network.
Is HomePlug AV suitable for triple play like the simultaneous use of data, voice,
and video applications?
Yes, triple play is supported.
What data transfer rates do I need for high definition TV?
A variety of HDTV resolutions are available. The following are the most common
resolutions opposite the required transfer rate:
720p, mpeg2: 09-10 Mbps
•
• 720p, mpeg4: 06-08 Mbps
1080i, mpeg2: 12-15 Mbps
•
• 1080i, mpeg4: 08-10 Mbps
Does HomePlug AV have a security mechanism?
Yes. HomePlug AV uses 128-bit AES encryption.
Are Gigabit Ethernet adapters required for use with HomePlug AV?
No. Under ideal conditions, HomePlug AV has a physical gross data rate of up to 200
Mbps. The effective net data rate is somewhat lower. A 100 Mbps Ethernet adapter is
therefore adequate in most cases.
Does the technology support multicast video server streams (IP-TV)?
Yes.
Page 41 of 45
User Manual v1.0
Is HomePlug AV restricted to a specified region?
No. HomePlug AV uses three kinds of pins for different regions. These are:
• (UK) – 3 pins UK plug with switch mode AC power supply
(EUR) – 2 pins Euro plug with switch mode AC power supply
•
• (USA) – 2 pins US plug with switch mode AC power supply
Do I need an Automatic Voltage Regulator (AVR) for HomePlug AV?
No. HomePlug AV can operate in an environment using 100-240V.
How many HomePlug AVs can operate in one household?
Up to 8 devices can be used within the household.
What is the maximum range of HomePlug AV?
The maximum range is 200 meters.
If one HomePlug AV is connected to a LAN switch, is it possible for other computers
in the switch to communicate with other HomePlug AV devices?
Yes.
Can my neighbors access my HomePlug AV network?
Your electric meter prevents any signal from going outside your household. However, we
strongly suggest that you create your own personalized Private Network Name to
prevent unauthorized access into your network.
How much is the power consumption of HomePlug AV on a 230-volt power supply?
HomePlug AV has a power consumption of 4.0 watts.
Can I use HomePlug AV to connect computers located in different floors of the
building?
Yes, as long as the electric wires are connected and do not exceed 200 meters.
Can I use HomePlug AV in an old house with old power supply lines (partly without
separated ground wire)?
Yes. However, performance may be affected because of the quality of the wires.
Page 42 of 45
User Manual
Can I plug HomePlug AV into a multiple socket switch or do I have to plug it directly
to the wall socket?
You can plug HomePlug AV into a multiple socket switch. However, we strongly advise to
plug it directly to a wall socket to achieve optimal performance.
Do I need electrical grounding for the device?
HomePlug AV does not require electrical grounding.
After a blackout, will HomePlug AV switch on automatically?
Yes. If you experience connection issues, unplug the device and plug it back.
What will happen if I connect two HomePlug AVs to the same router?
This will cause collision and slow down the network traffic. To prevent collision, you need
to assign different Private Network Names on each HomePlug AV.
Page 43 of 45
User Manual v1.0
FCC Statement
This equipment has been tested and complies with the specifications for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used according to the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which is found by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment or devices
Connect the equipment to an outlet other than the receiver’s
Consult a dealer or an experienced radio/TV technician for assistance
European Regulations
The product has been designed, tested and manufactured according to the European R&TTE directive 1999/5/EC.
Page 44 of 45
User Manual
Safety Warnings
For your safety, be sure to read and follow all warning notices and instructions.
Do not open the device. Opening or removing the device cover can expose you to
dangerous high voltage points or other risks. Only qualified service personnel can
service the device. Please contact your vendor for further information.
Do not use your device during a thunderstorm. There may be a risk of electric
shock brought about by lightning.
Do not expose your device to dust or corrosive liquids.
Do not use this product near water sources.
Make sure to connect the cables to the correct ports.
Do not obstruct the ventilation slots on the device.
Page 45 of 45
Loading...
