AZATOM® KARA - KR1

Portable Bluetooth Speaker

User Manual

This manual is available to download online at www.azatom.com

Thank you for shopping with AZATOM® Please read this manual carefully before using your new device and keep it safe for future reference.

AZATOM

audio products. All our products are developed by our In-house Team of British Designers.

We are experts in sound engineering and great care and attention goes into the design and manufacture of every

AZATOM® product to ensure class-leading performance

and quality.

Please read the manual thoroughly before operating the device.

Choose a suitable location for the device. Suitable locations are dry, even and anti-slip surfaces on which you may operate the device easily.

This Bluetooth Speaker was designed to travel and come with you on your adventures, all while delivering high quality audio.

®

is a British company specialising in advanced

FREE Earphones with every review left

online at amazon.co.uk or ebay.co.uk

Fill in our easy online form to claim yours!

Contents

Section: Page:

Controls & Interface............................................................................................................

What’s in the Box?..............................................................................................................

Using the KARA-KR1...........................................................................................................

Technical Specications....................................................................................................

Important Safety Information...........................................................................................

Grab your free extended

warranty & keep up to date

with AZATOM® online at

www.azatom.com

1

3

4

6

7

1

Controls & Interface

For technical support call: 01740 629901 or email: info@azatom.com

2

1. “M” - MODE

2. VOLUME- / DOWN

3. MICROPHONE

4. VOLUME+ / UP

5. | ◄ ◄ / P R E V I O U S T R A C K

6. ► ► | / NEXT TRACK

7. LED INDICATOR (BLUE FOR BLUETOOTH MODE / ORANGE FOR AUX-IN MODE)

8. ►| | / P LAY/PAUSE

9. POWER ON/OFF / ANSWER / HANG UP IN HANDS-FREE MODE

10. MICRO USB PORT

11. LED POWER INDICATOR (RED FOR CHARGING / GREEN FOR FULLY CHARGED)

12. 3.5MM AUX-INPUT PORT

FREE Earphones with every review left

online at amazon.co.uk or ebay.co.uk

Fill in our easy online form to claim yours!

3

What’s in the box?

AZATOM® KARA-KR1

User Manual Power Adapter

3.5mm Audio Lead

AZATOM® Warranty Card

For technical support call: 01740 629901 or email: info@azatom.com

4

Using the KARA-KR1

Getting started:

There are two ways of powering your Bluetooth speaker:

1. Connecting to a power source using the charging adapter provided (DC: 5V / 0.5mA)

2. Charging up the built in battery - Recommended option

Switching on your Bluetooth KARA KR-1:

Press and hold POWER until you hear the KARA KR-1 say “POWER, ON”

Pairing with your Bluetooth KARA KR-1:

Pairing with your Bluetooth KARA KR-1 using a Bluetooth enabled device for the rst time:

1. Once powered on the KARA KR-1 will automatically go into BLUETOOTH PAIRING MODE (Indicated by the Blue light flashing rapidly)

If you are prompted to enter a password, please enter “0000“ - When the speaker is connected, it will say out loud “Pairing Successfully”

The KARA KR-1 will auto-reconnect to the last device it was paired with if it’s in range. If the KARA KR-1 has not been connected to a Bluetooth device before, it will make itself visible to Bluetooth devices nearby which are actively searching

2. Once in BLUETOOTH MODE the KARA KR-1 will say out loud “Bluetooth Mode” to conrm, followed by “Pairing”. You then need to activate the Bluetooth on your music player device (iPad, Phone etc.) so that it begins searching for the KARA KR-1 Speakers

3. Once visible, select the speaker on your media player device. It will show up as “AZATOM KR-1”. Most devices require that you select by either tapping or double tapping the speaker name. Please see the user manual for your media player device for full instructions on using it to pair to a device via Bluetooth

Disconnecting from your KARA KR-1:

When you switch off your Bluetooth on your media player device, the KARA KR-1 will let you know its disconnected by saying out loud “Disconnected”

5

Pairing to another Bluetooth enabled device:

If you wish to connect / pair to a different device which has not previously been connected / paired to the KARA KR-1 before, you need to:

1. Switch off or disconnect the Bluetooth on the connected / paired device. This will disconnect the KARA KR-1 from that device (iPad, Phone etc.)

2. Once disconnected from the previous device, the KARA KR-1 will say out loud “ Disconnected”. You can press and hold the PLAY/PAUSE button until the KARA KR-1 goes into PAIRING MODE again and It will say “Pairing” to conrm its mode

If you wish to reconnect to a second Bluetooth device which the speaker has already paired with in

the past, the process is the same as above and when the speaker goes into pairing mode it will nd

the second Bluetooth device

Connecting to more than 1 phone for hands-free:

The KARA KR-1 can connect up to 2 phones at the same time.

1. Connect to the rst phone and then to the second as normal, The second phone will now be

connected

2. Now go back to the rst list of Bluetooth devices on the rst phone and select / connect to the

KARA KR-1 (there is no need to do anything on the speaker itself)

3. The KARA KR-1can now operate as a hands-free speaker from both phones, the speaker buttons will function with the last connected phone

Using your KARA KR-1 as a hands-free device:

When connected to one (or two) phone(s) the KARA KR-1 can operate as a hands-free device.

1. To answer calls, short press the POWER BUTTON (volume can be adjusted on the speaker by

using the volume buttons)

2. A long press of the PLAY/PAUSE button will reject the call

3. During a call short press the PLAY/PAUSE button to hang up

4. Short press the PLAY/PAUSE button twice and it will redial the last number called

Using AUX-IN mode:

The AUX MODE is selected automatically by connecting the AUX cable to the KARA KR-1 You can also press the “M” button until you hear the KARA KR-1 say out loud “AUX Mode”

Connecting a 3.5mm jack cable will prevent the KARA KR-1 from entering Bluetooth mode so please make sure the cable is disconnected if you wish to use Bluetooth devices with your KARA KR-1

When in AUX Mode, the KARA KR-1 buttons can control the KARA KR-1 but not the device connected via the cable

6

Technical Specications

2.0 Stereo output with 1 passive sub-woofer

Power output: 2x 12w Speaker units: 2” 8Ω Bluetooth chip-set: 4.0 Supports: A2DP, AVRCP, HFP, HSP Working Range: 15m Built-in battery: 3.7V, (1x 1800mAh rechargeable Lithium-ion battery) Dimensions: 180mm x 52mm x 113mm Weight: 820g Music streaming time: 20+ Hours

(Depending on the speaker playing music at the same time as charging and volume level)

Grab your free extended

warranty & keep up to date

with AZATOM® online at

www.azatom.com

FREE Earphones with every review left

online at amazon.co.uk or ebay.co.uk

Fill in our easy online form to claim yours!

7

IMPORTANT SAFETY INFORMATION

1. Read these instructions.

2. Keep these instructions. Instructions are also available for download at www.azatom.com

3. Heed all Warnings.

4. Follow all instructions.

5. Do not clean the apparatus near or with water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including ampliers) that produce heat.

9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

10. Only use attachments/accessories specied by

the manufacturer.

11. Unplug this apparatus during light storms or when unused for long periods of time.

12. Refer all servicing to qualied service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally or has been dropped.

13. No naked flame sources, such as lit candles, should be placed on the apparatus.

14. Dispose of used electrical products and batteries safely according to your local authority and regulations.

ADDITIONAL WARNINGS

The apparatus shall not be exposed to dripping

or splashing and no objects lled with liquid,

such as vases, shall be placed on apparatus.

Main plug is used to disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus from the main mains completely, the mains plug should be disconnected from the main socket outlet completely.

Battery shall not be exposed to excessive heat

such as sunshine, re or the like.

RECYCLING ELECTRICAL PRODUCTS

You should now recycle your waste electrical goods and in doing so help the environment.

This symbol means an electrical product should not be disposed of with normal household waste. Please ensure it is taken to a suitable facility for disposal when

nished with.

IMPORTANT: Please read all instructions carefully before use and keep for future reference

• Risk of electric shock.

Do not open

• Read all instructions carefully before use and keep for future reference.

• When servicing, use only identical replacement parts.

My Serial Number:

.....................................................................................................................................

Notes:

.....................................................................................................................................
