AZATOM
®
Droid Portable Bluetooth
USER MANUAL
®
Speaker
www.AZATOM.com
AZATOM is a registered trademark of 4 Cool Technology Ltd
Based in the United Kingdom
®
AZATOM
Thank you for purchasing the AZATOM® Droid Portable Bluetooth® Speaker. This powerful,
portable speaker h as be en d esi gned an d dev elop ed h ere i n th e UK to gi ve great qual i ty s ound
and value on the move. AZATOM® undert akes its own R&D here i n the UK to ensure th at all
our speaker s incorp orate t he lates t acous tic tec hnolog y. The Droi d uses high q ualit y material s
to ensure a rich and powerful sound despite its compact dimensions.
Outstanding features:
• Unique Design with raised feet to improve bass performance
• High Density Drivers with powerful Neodymium Magnets
• Passive Bas s Radiator wi th 2 Bassports ensure strong, deep bass and mid-range
• High Quality Battery gives over 10 hours of Music
• Micro USB Input for charging from a Laptop
• Bluetooth v4.0
• ‘Intelligent Bluetooth’ remembers your device and can automatically reconnect.
• Buttons on Unit allow you to control your music (Play/Pause… Volume Up/Down etc)
through your Bluetooth Device (Phone, Tablet etc.) or direct on the Droid
• Auxiliar y input al l ows t he sp eak er t o b e use d wi t h oth er a udi o players such as M P3, MD,
CD, Laptops, T ablets and M obile Phones
Please read t his User Manu al careful ly before oper ating the AZATOM® Droid and k eep it safe
for future reference.
Getting started….
Check the carton for all the parts. The b ox contains:
1. ‘Droid’ speaker unit
2. MicroUSB to USB Cable
3. 3.5 mm Auxil iary Cable
4. User Manual
Please retai n the box and all pack ing mat erial s, whic h provi de the s afest way to tr ansport your
Speaker.
Controlling your Droid
1. Charge Light: Red Light indicates the Battery is charging, the Light goes out when the
Battery is fully charged.
2. Volume Down ( -)
3. Play/Pause (Short Press for song Play / Pause), Lon g Press for Bluetooth on / off / pair
4. Volume Up (+)
5. Operation Light: Bluetooth and Line-in operation light (more details see General
Instructions)
6. DC Input (MicroUSB Port)
7. Line-in Port
8. Power Switch (ON/OFF)
Droid – General Instruc t ions
The first time you use the Droid Speaker to connect to your Bluetooth Device (Mobile
Phone, Tabl et, Laptop etc.):
1. Switch the unit ON
2. Press the Play / Pause button for 3 seconds to put the speaker into Bluetoot h Mode
3. Then Press t he Play / Paus e Button for a further 5 seconds to put the D roid into
Bluetooth Pairing Mode – the blue light will start to flash rapidly: This signals that the
speaker is in pairing mode and ready to connect to your smartphone, tablet or other
Bluetooth device
4. The Droid will come up on yo ur Bluetooth device as “AZATOM Droid”
5. If your Bluet ooth Device prompts you for a passwor d, enter digits “0000” and press OK
(some devices also ask you to accept the connection)
6. When the con nection is successful the blue light will once every 2 seconds.
When playin g music on your Droid Speak er you can control the volume either using the
buttons on the speaker or from your Bluetooth device.
To disconnect your Bluetooth Device from the Droid Speaker:
1. Choose to disconnect on your Bluetooth Device
2. The blue li ght will revert back to flashing twice ev ery 2 seconds
3. Your Bluetooth Device will automatically reconnect to the Droid Speaker when you open
the Bluetoot h signal on your phone within range of the speaker
The second time you use the Droid Speaker to connect to your Bluetooth Device (Mobile
Phone, Tabl et, Laptop etc.):
1. Open the Bluetooth signal on your Device first. Then switch on the Dr oid Speaker a nd
pairing will be automatic.
2. If the connection has been lost or has failed – pair as per the instructions for the first
time you connect .
Pairing a different Bluetooth Device:
1. Disconnect the first Bluetooth Device
2. Connect the new Device as per the instruct ions for connecting f or the first time.
When connecting your audio device using the AUX (3.5mm Jack) Cable, the Bluetooth
functions will not work. The Blue Light will stay on. You can adjust the volume f r om your
Audio Device or the Droid.
Problem
Solution
Troubleshooting
The speaker doesn’t
seem to work
Cannot Pair / Connect to
my Bluetooth Device
Bluetooth cannot Play and
Pause
Speaker distortion
(sound not normal or
unclear)
NO Sound
(even when the Volume is
turned up, there is no
Sound or very little sound)
• Battery is flat: Charge the unit
• The audio cable is plugged into the Droid but not connected
to your Audio Device
• Droid Speaker is not in Pairing Mode: Long press the Play /
Pause button to put the Droid into pairing mode. The Blue
Light will then flash and the unit is ready for pairing.
• Make sure you are connected via Bluetooth
• Remove any obstructions in the path between the Bluetooth
device and the Droid Speaker
• Ensure you are not out of range of the Droid (usually upto 10
metres)
• Try lowering the Volume
• Try a different song
• Make sure the Droid is charged
• Adjust the volume on the Bluetooth device
• Make sure the Droid is charged
• Pair the Bluetooth Devices again
The Speaker is Heating
up
The speaker will heat up due to extended use, particularly at
high volumes; and also due to a hot environment:
• Stop using the speaker for a short period to allow it to
cool down
• Turn the volume down
• Move to a cooler area
Maximum Output Power
5W THD=10%
Audio Inputs
3.5mm Jack
Power Input
Micro USB cable
Frequency Response
150-18,000Hz (±3dB)
Signal-to-Nois e Ratio
≥60dB
Channel Sep aration
≥40dB
Channel Imbalance
≤3dB
Bluetooth Sensitivit y
-80dBm
Bluetooth Tr ansmitti ng Power
4dBm
Wireless Transmitting Range
≥ 10 metres
Bluetooth® Specification
v.4.0
Driver Size
52mm
Bass Radiat or Dimensions
52mm
Battery Capacity
1,200mAh
Specifications
Disclaimer:
The Droid has been extensively tested to provide reasonable protection against harmful
interference in a resi dent ial environment. The eq uipm ent generates uses and can r adiat e radi o
frequency energy and sho uld be used in accordance with these instructions.
However, the re is no guarantee t hat interferenc e to TV or R adio will not occ ur in a particul ar
install ati on. If this equipment d oes cause any interference or is subject to interference, the us er
is encouraged to try to correct this by one or more of the followin g:
• Reorient or m ove the receiv ing antennae
• Increase the separation between the Droid and other electrical items
• Connect the Droid to a dif ferent power outlet to that of other equipment
Safety Information
When using a n electrical product , basic precautions should always be followed i ncluding the
following:
READ ALL INSTRUCTIONS BEFORE USING
• WARNING: Do not place the Droid t oo close to ears. May cause damag e to eardrums
especially in small c hildren.
• WARNING: Do not use the speaker if it has a damaged cable, plug or housing.
• WARNING: Do not place on a heate d surface.
• WARNING: Only use attachments/accessories specified or provided by the
manufactur er (s uch as the charging cabl e.).
• WARNING：To reduce t he risk of fi re or ele ctric shock; do not exp ose the Droid to rai n
or moisture. Please take care to ensure the Droid does not get wet through the
placement of vas es an d drinks or by placi ng t he sp eak er to o c l ose to a t ap. D o not pl ace
the Droid where it may drop into water such as a bath or sink.
• WARNING: No naked flame sourc es, such as light ed candles, should b e placed on the
unit.
• WARNING: Use the Droid in moder ate climates.
• WARNING: Not to be used by children - this is not a toy.
Correct Disposal of this product: According to the European Directive 2002 / 96 / EC all
electrical and electronic products must be collected separately by a local collection system.
Please act according to your local rules and do not dispose of your old products with your
normal hous ehold waste. This produc t should not be di sposed of with ot her household wast e
in the UK or throu ghou t the EU. To prevent possi ble harm to the en vironm ent or hum an heal th
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources.
