ASUS PRL-DL User Manual

PRL-DL

User Guide

Motherboard

Checklist

E1 172
First Edition

January 2003

Copyright © 2003 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.

ii

ASUS Contact Information

ASUSTeK COMPUTER INC. (Asia-Pacific)

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [e-mail]

Technical Support

MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Support Fax: [phone]
Web Site: www.asus.com.tw

ASUS COMPUTER INTERNATIONAL (America)

Address: 44370 Nobel Drive, Fremont, CA 94538, USA
General Fax: [phone]
General Email: [e-mail]

Features

Technical Support

Support Fax: [phone]
General Support: [phone]
Web Site: www.asus.com
Support Email: [e-mail]

ASUS COMPUTER GmbH (Germany & Austria)

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [e-mail] (for marketing requests only)

Technical Support

Support Hotline: MB/Others: [phone]
Notebook (Tel): [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de

iii

Safeguards

Contents

Notices ............................................................................................ii

ASUS contact information .............................................................. iii

FCC/CDC statements.....................................................................vi

Safety Information ......................................................................... vii

About this guide............................................................................ viii

How this guide is organized ................................................ viii

Conventions used in this guide .............................................ix

Where to find more information .............................................ix

PRL-DL Specifications summary.....................................................x

Product introduction.................................................. Chapter 1

1.1 Welcome! ........................................................................... 1-1

1.2 Package contents............................................................... 1-1

1.3 Special features.................................................................. 1-2

1.3.1 Product highlights .................................................. 1-2

1.3.2 Value-added solutions............................................ 1-4

1.4 Motherboard overview........................................................ 1-6

1.4.1 Major components ................................................. 1-6

1.4.2 Core specifications ................................................ 1-8

Hardware information ................................................ Chapter 2

2.1 Motherboard installation ..................................................... 2-1

2.1.1 Placement direction ............................................... 2-1

2.1.2 Screw holes ........................................................... 2-1

2.2 Motherboard layout ............................................................ 2-2

2.3 Before you proceed ............................................................ 2-3

2.4 Central Processing Unit (CPU)........................................... 2-4

2.4.1 Overview ................................................................ 2-4

2.4.2 Installing the CPU .................................................. 2-5

2.4.3 Installing the CPU heatsink and fan....................... 2-6

2.5 System memory ................................................................. 2-8

2.5.1 Overview ................................................................ 2-8

2.5.2 Memory Configurations.......................................... 2-9

2.5.3 Installing a DIMM ................................................. 2-10

2.5.4 Removing a DIMM ............................................... 2-10

iv

2.6 Expansion slots .................................................................2-11

2.6.1 Installing an expansion card .................................2-11

Contents

2.6.2 Configuring an expansion card .............................2-11

2.6.3 PCI slots .............................................................. 2-13

2.7 Switches and jumpers ...................................................... 2-14

2.7.1 Switches .............................................................. 2-14

2.7.2 Jumpers ............................................................... 2-16

2.8 Connectors ....................................................................... 2-19

2.9 Onboard LEDs.................................................................. 2-26

2.9.1 Port 80h post code LEDs ..................................... 2-27

Powering up ............................................................... Chapter 3

3.1 Starting up for the first time ................................................ 3-1

3.2 Powering off the computer ................................................. 3-2

BIOS setup ................................................................. Chapter 4

4.1 Managing and updating your BIOS .................................... 4-1

4.1.1 Creating a bootable disk ........................................ 4-1

4.1.2 Updating the BIOS ................................................. 4-3

4.2 BIOS Setup program .......................................................... 4-5

4.2.1 BIOS menu bar ...................................................... 4-6

4.2.2 Legend bar............................................................. 4-6

4.3 Main Menu.......................................................................... 4-8

4.3.1 Primary/Secondary/Tertiary Master/Slave ........... 4-10

4.3.2 Keyboard Features .............................................. 4-14

4.4 Advanced Menu ............................................................... 4-15

4.4.1 Chip Configuration ............................................... 4-17

4.4.2 I/O Device Configuration...................................... 4-18

4.4.3 PCI Configuration ................................................ 4-20

4.5 Power Menu ..................................................................... 4-22

4.5.1 Power Up Control ................................................ 4-24

4.5.2 Hardware Monitor ................................................ 4-26

4.6 Boot Menu ........................................................................ 4-27

4.6.1 Slot Configuration ................................................ 4-30

4.7 Server Menu..................................................................... 4-31

4.7.1 Event Log Viewer................................................. 4-32

4.8 Exit Menu ......................................................................... 4-33

Support CD................................................................. Chapter 5

v

FCC/CDC statements

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference
that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

vi

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that
the power cables for the devices are unplugged before the signal
cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.

• Before connecting or removing signal cables from the motherboard,
ensure that all power cables are unplugged.

• Seek professional assistance before using an adpater or extension
cord. These devices could interrupt the grounding circuit.

• Make sure that your power supply is set to the correct voltage in your
area. If you are not sure about the voltage of the electrical outlet you
are using, contact your local power company.

• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.

Operation safety

• Before installing the product and adding devices on it, carefully read all
the documentation that came with the package.

• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a
qualified service technician or your retailer.

vii

About this guide

This user guide contains the information you need when installing this
ASUS motherboard.

How this guide is organized

This manual contains the following parts:

• Chapter 1: Product introduction

This chapter describes the features of this motherboard. It includes
brief descriptions of the special attributes of the motherboard and the
new technology it supports.

• Chapter 2: Hardware information

This chapter lists the hardware setup procedures that you have to
perform when installing system components. It includes description of
the switches, jumpers, and connectors on the motherboard.

• Chapter 3: Powering up
This chapter describes the power up sequence and gives information

on the BIOS beep codes.

• Chapter 4: BIOS setup

This chapter tells how to change system settings through the BIOS
Setup menus. Detailed descriptions of the BIOS parameters are also
provided.

• Chapter 5: OS Installation

This chapter tells how to install SCSI, LAN, and VGA drivers for
various operating systems.

viii

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the
following symbols used throughout this manual.

WARNING: Information to prevent injury to yourself when trying
to complete a task.

CAUTION: Information to prevent damage to the components
when trying to complete a task.

IMPORTANT: Information that you MUST follow to complete a
task.

NOTE: Tips and additional information to aid in completing a task.

Where to find more information

Refer to the following sources for additional information and for product
and software updates.

1. ASUS Websites

The ASUS websites worldwide provide updated information on ASUS
hardware and software products. The ASUS websites are listed in the
ASUS Contact Information on page x.

2. Optional Documentation

Your product package may include optional documentation, such as
warranty flyers, that may have been added by your dealer. These
documents are not part of the standard package.

ix

PRL-DL specifications summary

CPU

Chipsets

Front Side Bus (FSB)
Memory

Onboard LAN
Onboard VGA
Expansion slots

Rear panel I/O

Supports Intel® Xeon™ processors
On-die 512KB L2 cache

RCC Grand Champion Super Lite North Bridge (GCSL)
RCC Champion South Bridge 6.0 (CSB6)

400 MHz / 533 MHz
4 x 184-pin DDR DIMM sockets

Supports PC2100/PC1600 registered ECC DDR DIMMs
Supports 64MB to 4GB system memory

Intel® 82540 Gigabit Ethernet controller
ATI® RAGE-XL PCI-based VGA controller
4 x 64-bit/33MHz PCI slot

2 x 32-bit/33MHz PCI slot
1 x Parallel port

1 x Serial port
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 1.1 ports
1 x RJ-45 ports (with LED)

Internal connectors

BIOS

Special Features

2 x ATA/100 IDE connectors
1 x PIO mode 4 IDE connector
1 x Floppy disk connector
1 x Serial Port 2 (COM2) connector
1 x Serial Port header
CPU/Power/Chassis fan connectors
12V 8-pin Power connector
IDE LED/Power LED connectors
20-pin Front panel connector

4Mbit Flash memory
Award BIOS with Enhanced Server, ACPI, DMI, Green, PnP
Features Plus, VGA & SCSI BIOS

3 x FAN sensor and control
V oltage sensor: VCORE +2.5V, +3V, +5V, +12V, +3VSB,
VBAT
3 x Thermal sensors: 1 x Environment, 2 x CPU (internal
thermal diode)

(Continued on the next page)

x

PRL-DL specifications summary

Form Factor

Support CD contents

* Specifications are subject to change without notice.

Extended ATX form factor: 12 in x 10.5 in

(30.48 cm x 26.67 cm)

Device drivers
Management software
Utilities
Contact information

xi

Chapter 1

This chapter describes the features of the
PRL-DL motherboard. It includes brief
explanations of the special attributes of the
motherboard and the new technology it
supports.

Product introduction

Chapter summary

1.1 Welcome! ........................................................ 1-1

1.2 Package contents .......................................... 1-1

1.3 Special features ............................................. 1-2

1.4 Motherboard overview................................... 1-6

ASUS PRL-DL motherboard

1.1 Welcome!

Thank you for buying the ASUS® PRL-DL motherboard!

The ASUS
technologies making it another standout in the long line of ASUS quality
server motherboards!

The PRL-DL incorporates dual Intel
package coupled with the ServerWorks® Grand Champion Super-Lite
(GCSL) System Set to deliver a reliable and high performance dual­processor server platform.

Before you start installing the motherboard, and hardware devices on it,
check the items in your package with the list below.

PRL-DL motherboard delivers a host of new features and latest

®

Xeon™ processor in a 603/604-pin

1.2 Package contents

Check your PRL-DL package for the following items.

ASUS PRL-DL motherboard

Extended ATX form factor: 12 in x 10.5 in (30.48 cm x 26.67 cm)
ASUS PRL-DL support CD
I/O shield
80-conductor ribbon cable for UltraDMA100/66//33 IDE drives
Ribbon cable for a 3.5-inch floppy drive
Bag of extra jumper caps
PRL-DL User Guide
2 x Intel Box CPU mounting plates

If any of the above items is damaged or missing, contact your retailer.

ASUS PRL-DL motherboard user guide

1-1

1.3 Special features

1.3.1 Product highlights

Latest processor technology

The PRL-DL motherboard supports both Intel® Xeon™ processors via dual
604-pin surface mount ZIF sockets. The processor features the Intel
NetBurst™ micro-architecture that includes hyper-pipelined technology , a
rapid execution engine, a 533MHz or a 400MHz system bus, and an
execution trace cache to offer a significant increase in performance. See
page 2-4 for more information.

DDR memory support

Employing the Double Data Rate (DDR) memory technology, the PRL-DL
motherboard supports up to 4GB of system memory using PC2100/1600
registered ECC DDR DIMMs. The ultra-fast 266MHz memory bus doubles
the speed of the PC100 SDRAM to deliver the required bandwidth for the
latest 3D graphics, multimedia, and Internet applications. See page 2-10.

®

Advanced 64-bit PCI slots

The 64-bit/33MHz PCI slots maximize I/O bandwidth for current 64-bit PCI
cards that support 33MHz bus.

ATA/100 IDE support

The dual-channel bus master IDE connectors comply with the ATA/100
protocol and supports ATA/100, Multi-Word DMA Mode2, PIO modes 3 & 4
IDE devices such as ATAPI IDE CD-ROM, CD-R/RW, ZIP, and LS-120
drives.

Third IDE Channel support

The CSB6 South Bridge chip provides a third IDE with PIO mode 3/4
support which provides more device connectivity in this server system.

1-2

Chapter 1: Product introduction

Onboard LAN

The motherboard comes with the Intel® 82540 Gigabit Ethernet controller
to support the latest LAN technologies.

Onboard VGA

The ATI Rage-XL PCI-based VGA controller integrates an 8MB display
SDRAM to provide onboard video solution.

ASUS PRL-DL motherboard user guide

1-3

1.3.2 Value-added solutions

Temperature, fan, and voltage monitoring

The CPU temperature is monitored by the ASUS ASIC to prevent
overheating and damage. The system fan rotations per minute (RPM) is
monitored for timely failure detection. The system voltage levels are
monitored to ensure stable supply of current for critical components.

Dual function power switch

While the system is ON, pressing the power switch for less than 4 seconds
puts the system to sleep mode or to soft-off mode, depending on the BIOS
setting. Pressing the power switch for more than 4 seconds lets the
system enter the soft-off mode regardless of the BIOS setting.

Remote Ring In

This feature allows the system to wake up remotely through an internal or
external modem, if present.

Wake-Up support

The motherboard includes Wake-On-LAN, Wake-On-Ring, and BIOS
Wake-Up features.

Server management

The motherboard comes with an ASMC connector that supports the
optional ASMC-HE/ME/LE card to comply with server reliability, availability,
and serviceability requirements. Remote management response via
remote diagnostics and troubleshooting still works even when the
operating system has stopped functioning.

ACPI ready

The Advanced Configuration power Interface (ACPI) provides more energy
saving features for operating systems that support OS Direct Power
Management (OSPM).

Concurrent PCI

This feature allows multiple PCI transfers from PCI master buses to the
memory and processor.

1-4

Chapter 1: Product introduction

Chassis intrusion detection

The motherboard supports chassis intrusion monitoring through the ASUS
ASIC. A chassis intrusion event is retained in the system memory for more
protection.

Smart BIOS

The 4Mbit firmware gives an easy-to-use interface that provides more
control and protection to the motherboard. The BIOS has a boot block
write protection and HD/SCSI/MO/ZIP/CD/Floppy boot selection, and is
Year 2000 certified.

Compliance

Both the BIOS and the hardware levels of the motherboard meet the
stringent requirements for SDG 2.0 certification. The new SDG 2.0
requirements for systems and components are based on the following
high-level goals: support for Plug-and-Play compatibility and power
management for configuring and managing all system components, 32-bit
device drivers, and installation procedures for Windows NT/2000/XP.
Color-coded connectors and descriptive icons make identification easy as
required by the PC ‘99 specification.

ASUS PRL-DL motherboard user guide

1-5

1.4 Motherboard overview

Before you install the PRL-DL motherboard, familiarize yourself with its
physical configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.

1.4.1 Major components

The following are the major components of the PRL-DL motherboard as
pointed out in the picture on page 1-7.

1. 604-pin CPU sockets

®

2. ServerWorks
SuperLite (GCSL) North Bridge

3. 24/20-pin ATX power connector

4. 8-pin 12V SSI power connector

5. DDR DIMM sockets

6. DIP switches

7. Serverworks CSB6 South Bridge

8. IDE connectors

9. USB header

10. Floppy connector

1 1. ASUS ASIC

12. Flash ROM

13. LPC Super-I/O controller

14. DIP switches

15. 80-pin ASMB daughterboard
connector

Grand Champion

16. Serial port 2

17. ATI Rage-XL VGA controller

18. 64-bit PCI slots (PCI64-1 to
PCI64-4), 32-bit PCI slots
(PCI-1 & PCI-2)

®

19. Intel

20. PS/2 mouse port

21. Parallel port

22. RJ-45 ports

23. VGA port

24. Serial port 1

25. USB ports 1 and 2

26. Keyboard port

82540 Gigabit Ethernet

controller

1-6

See page 1-8 for the specifications of each component. Refer to
Chapter 2 for detailed information on the components.

Chapter 1: Product introduction

15

8

2

7

19

3

4

6

20 21

18
17

16

15 9

13

1214

1011

26 25 24 23 22

ASUS PRL-DL motherboard user guide

1-7

1.4.2 Core specifications

1

604-pin CPU sockets. A 604-pin surface mount, Zero Insertion

Force (ZIF) socket for the Intel

®

Xeon™ processor with 512KB L2

cache and a 533MHz or a 400MHz system bus that allows up to

4.26GB/s or 3.2GB/s data transfer rate.

2

ServerWorks

®

Grand Champion SuperLite north bridge . CMIC-

SL. The Champion Memory and I/O Controller SuperLite (CMIC-

SL) acts as the host bridge of the Grand Champion SuperLite
(GCSL) SystemSet. The GCSL device interfaces directly to the
processor bus, and integrates the functions of the main memory
controller and the Inter Module Bus (IMB) interface unit. The
processor interface supports a 400/533 MHz Front Side Bus (FSB)
providing a 3.2GB/s or 4.26GB/s bandwidth, memory bandwidth
with up to 4GB registered ECC PC1600/2100 DDR DIMMs, and
two high speed IMBs plus one thin IMB to connect to the south
bridge CSB6.

3

24/20-pin ATX power connector. This power connector is for an

ATX power supply.

4

8-pin 12V SSI power connector. This power connector is for an

ATX power supply.

5

DDR DIMM sockets. These four 184-pin DIMM sockets support up

to 4GB system memory using registered ECC PC1600/2100 DDR
DIMMs.

6

DIP switches. This 5-switch Dual Inline Package (DIP) allows you

to set the CPU external frequency.

7

ServerWorks

®

South Bridge, CSB6 performs as a PCI to LPC
(Low Pin Count) Bridge and integrates PCI master/slave functions,
DMA controller, ATA100 IDE interface, USB contoller, SMBus host,
ACPI and other integral functions.

8

IDE connectors. These dual-channel bus master IDE connectors

support up to four Ultra DMA/100/66, PIO Modes 3 & 4 IDE
devices. Both the primary (blue) and secondary (blue) connectors
are slotted to prevent incorrect insertion of the IDE ribbon cable.

1-8

9

Front USB header. A Front USB header is available for additional

USB port connectors.

Chapter 1: Product introduction

10

Floppy disk connector. This connector accommodates the

provided ribbon cable for the floppy disk drive. One side of the
connector is slotted to prevent incorrect insertion of the floppy disk
cable.

11

12

13

14

15

16

ASUS ASIC. This chip performs multiple system functions that

include hardware and system voltage monitoring, IRQ routing,
among others.

Flash ROM. This 4Mb firmware contains the programmable BIOS
program.

LPC super I/O controller. This Low Pin Count (LPC) interface
provides the commonly used Super I/O functionality. The chipset
supports UART compatible serial ports, one parallel port with EPP
and ECP capabilities, a floppy drive, and PS/2 keyboard and
mouse.

DIP switches. This Dual Inline Package (DIP) switch allows you to
set the frequencies.

50-pin ASMB Connector. This connector supports the ASMB
proprietary Server Management daughter card.

Serial port 2. This 9-pin COM2 port is for pointing devices or other
serial devices.

17

18

19

20
21

22

ATI Rage-XL VGA controller. This PCI-based VGA controller

supports up to 8MB display SDRAM for 1280x1024 and true color
resolutions.

64-bit PCI/32-bit PCI slots. Four 64-bit/33MHz PCI slots and two
32-bit/33MHz PCI expansion slots support bus master PCI cards.

®

Intel

82540 32bit PCI Gigabit Ethernet Controller. This LAN

controller fully supports 10BASE-T/100BASE-TX/1000BASE-T
networking protocols and data rates up to 1000Mbps, 100Mbps,
and 10Mbps.

PS/2 mouse port. This green 6-pin connector is for a PS/2 mouse.
Parallel port. This 25-pin port connects a parallel printer, a

scanner, or other devices.
RJ-45 ports. These ports allows connection to a Local Area

Network (LAN) through a network hub.

ASUS PRL-DL motherboard user guide

1-9

23

VGA port. This port is for a VGA-monitor or other VGA-compatible

devices.

24

25

26

Serial port 1. This 9-pin COM1 port is for pointing devices or other

serial devices.
USB 1.1 ports. These two 4-pin Universal Serial Bus (USB) ports

are available for connecting USB devices.
PS/2 keyboard port. This purple 6-pin connector is for a PS/2

keyboard.

1-10

Chapter 1: Product introduction

Chapter 2

This chapter describes the hardware setup
procedures that you have to perform when
installing system components. It includes
details on the switches, jumpers, and
connectors on the motherboard.

Hardware information

Chapter summary

2.1 Motherboard installation ............................... 2-1

2.2 Motherboard layout ....................................... 2-2

2.3 Before you proceed ....................................... 2-3

2.4 Central Processing Unit (CPU) ..................... 2-4

2.5 System memory ............................................. 2-8

2.6 Expansion slots ............................................2-11

2.7 Switches and jumpers ................................. 2-14

2.8 Connectors ................................................... 2-19

ASUS PRL-DL motherboard

2.1 Motherboard installation

Before you install the motherboard, study the configuration of your chassis
to ensure that the motherboard fits into it. The PRL-DL uses the extended
ATX form factor that measures 12 inches x 10.5 inches (30.5 x 26.67 cm).

Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so may cause you physical injury and
damage motherboard components.

2.1.1 Placement direction

When installing the motherboard, make sure that you place it into the
chassis in the correct orientation. The edge with external ports goes to the
rear part of the chassis as indicated in the image below.

2.1.2 Screw holes

Place screws into the holes indicated by circles to secure the motherboard
to the chassis.

Do not overtighten the screws! Doing so may damage the
motherboard.

Place this side towards
the rear of the chassis

ASUS PRL-DL motherboard user guide

2-1

2.2 Motherboard layout

26.67.cm (10.4in)

PS/2

T: Mouse
B: Keyboard

USB0
USB1

COM1

VGA

RJ-45

JLAN1

CON1

PARALLEL PORT

Intel
82540
Gigabit

Ethernet
JVGA1

STBYLED1

VGA RAM

ATI

RAGE XL

VGA

Controller

COM2

J1

mPGA604mPGA604

PCI64-1 (64-bit, 33MHz 3V)

PCI64-2 (64-bit, 33MHz 3V)

PCI64-3 (64-bit, 33MHz 3V)

PCI64-4 (64-bit, 33MHz 3V)

PCI1 (32-bit, 33MHz 5V)

PCI2 (32-bit, 33MHz 5V)

CON2

SW2

®

PRL-DL

J1
J3

Super

FAN2

I/O

ATX_POWER

CPULED1

ServerWorks
North Bridge

4Mbit
Flash
BIOS

FAN3

CLRCMOS1

CON12V

®

GCSL

JFSB1

FAN1

LED1
LED2
LED3
LED4
LED5
LED6
LED7
LED8

ASUS

ASIC

with Hardware

Monitor

ASUS PANEL1

SW1

DDR DIMM1 (64/72 bit, 184-pin module)

DDR DIMM2 (64/72 bit, 184-pin module)

DDR DIMM3 (64/72 bit, 184-pin module)

DDR DIMM4 (64/72 bit, 184-pin module)

0 1

2 3

4 5

6 7

CSB6

CR2032 3V
Lithium Cell

CMOS Power

®

POWERLED1

FLOPPY1

BUZZ1

USB2.3

ServerWorks
South Bridge

IDE2

IDE1

IDE3

30.7cm (12.08in)

2-2

The PCI2 32-bit, 4-pin CON1 and 80-pin ASMB connector features are
optional. These components are grayed out in the above motherboard
layout.

Chapter 2: Hardware information

2.3 Before you proceed

Take note of the following precautions before you install motherboard
components or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any
component.

2. Use a grounded wrist strap or touch a safely grounded object or to
a metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity.

3. Hold components by the edges to avoid touching the ICs on them.

4. Whenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.

5. Before you install or remove any component, ensure that the

ATX power supply is switched off or the power cord is
detached from the power supply. Failure to do so may cause

severe damage to the motherboard, peripherals, and/or
components.

ASUS PRL-DL motherboard user guide

2-3

2.4 Central Processing Unit (CPU)

r

2.4.1 Overview

The motherboard comes with dual surface mount 604-pin Zero Insertion
Force (ZIF) sockets. The sockets are designed for the Intel Processor in
the 603/604-pin package with 512KB L2 cache. The processor includes
the Intel® NetBurst™ micro-architecture that features the hyper-pipelined
technology, rapid execution engine, 400/533 MHz system bus, and
execution trace cache. Together, these attributes improve system
performance by allowing higher core frequencies, faster execution of
integer instructions, and data transfer rates of up to 4.26GB/s or 3.2GB/s.

®

Intel Xeon™ Processo

®

PRL-DL

Gold Arrow

PRL-DL Socket 604

Note in the illustration that the CPU has a gold triangular mark on one
corner. This mark indicates the processor Pin 1 that should match a
specific corner of the CPU socket.

Incorrect installation of the CPU into the socket may bend the pins and
severely damage the CPU!

The motherboard supports either one or two CPUs. If you are installing
only one CPU, you MUST install it in CPU socket 1.

CPU Socket 2
(outer socket)

2-4

CPU Socket 1
(inner socket)

Chapter 2: Hardware information
