ASUS A7V600B User Manual

A7V600

User Guide

Motherboard

Checklist

E1372 Revised Edition V3

July 2003

No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe.

Contents

Notices ............................................................................................v

Safety information ..........................................................................vi

About this guide............................................................................. vii

ASUS contact information ............................................................ viii

A7V600 specifications summary ....................................................ix

Chapter 1: Product introduction

1.1 Welcome! ........................................................................... 1-2

1.2 Package contents............................................................... 1-2

1.3 Special Features ................................................................ 1-3

1.3.1 Product highlights................................................... 1-3

1.3.2 Value-added solutions ............................................ 1-5

1.4 Motherboard components .................................................. 1-6

1.4.1 Core specifications ................................................. 1-7

Features

1.5 Motherboard layout ............................................................ 1-9

1.6 Before you proceed .......................................................... 1-10

1.7 Motherboard installation ....................................................1-11

1.7.1 Placement direction ..............................................1-11

1.7.2 Screw holes ..........................................................1-11

1.8 Central Processing Unit (CPU)......................................... 1-12

1.8.1 Installing the CPU ................................................ 1-12

1.9 System memory ............................................................... 1-13

1.9.1 DDR400 Qualified Vendor List ............................. 1-13

1.10 Expansion slots ................................................................ 1-14

1.10.1 Configuring an expansion card........................... 1-14

1.10.2 Standard interrupt assignments ......................... 1-14

IRQ assignments for this motherboard ....................... 1-15

1.10.3 AGP slot ............................................................. 1-15

1.10.4 WiFi slot.............................................................. 1-16

1.11 Jumpers............................................................................ 1-17

1.12 Connectors ....................................................................... 1-19

Chapter 2: BIOS information

2.1 Managing and updating your BIOS .................................... 2-2

2.1.1 Using ASUS EZ Flash to update the BIOS ............ 2-2

iii

Safeguards

Contents

2.1.2 Using AFLASH to update the BIOS ....................... 2-4

2.1.3 Recovering the BIOS with CrashFree BIOS 2 ....... 2-7

2.2 BIOS Setup program .......................................................... 2-9

2.2.1 BIOS menu bar ...................................................... 2-9

2.2.2 Legend bar........................................................... 2-10

2.3 Main Menu.........................................................................2-11

2.3.1 Primary and Secondary Master/Slave ................. 2-13

2.3.2 Keyboard Features .............................................. 2-15

2.4 Advanced Menu ............................................................... 2-16

2.4.1 Chip Configuration ............................................... 2-18

2.4.2 I/O Device Configuration...................................... 2-20

2.4.3 PCI Configuration ................................................ 2-22

2.5 Power Menu ..................................................................... 2-23

2.5.1 Power Up Control ................................................ 2-25

2.5.2 Hardware Monitor ................................................ 2-26

2.6 Boot Menu ........................................................................ 2-27

2.7 Exit Menu ......................................................................... 2-29

Chapter 3: Software support

3.1 Install an operating system................................................. 3-2

3.2 Support CD information...................................................... 3-2

3.2.1 Running the support CD ........................................ 3-2

3.2.2 Drivers menu ......................................................... 3-3

3.2.3 Utilities menu ......................................................... 3-3

3.2.4 ASUS Contact Information..................................... 3-4

3.3 ASUS Instant Music Lite..................................................... 3-5

3.4 RAID 0 / RAID 1 / RAID 0 + 1 Configurations .................... 3-7

3.4.1 Install the Serial ATA (SATA) hard disks................. 3-8

3.4.2 Enter VIA

3.4.3 Create Array......................................................... 3-10

3.4.4 Delete Array ......................................................... 3-13

3.4.5 Select Boot Array ................................................. 3-13

3.4.6 Serial Number View ............................................. 3-14

3.5 Marvell

Virtual Cable Tester™ Technology ..................... 3-15

Tech RAID BIOS Utility ........................ 3-9

Notices

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.

• Seek professional assistance before using an adpater or extension cord. These devices could interrupt the grounding circuit.

• Make sure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.

• If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.

Operation safety

• Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the package.

• Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualified service technician or your retailer.

About this guide

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual.

WARNING/DANGER: Information to prevent injury to yourself when trying to complete a task.

CAUTION: Information to prevent damage to the components when trying to complete a task.

IMPORTANT: Information that you MUST follow to complete a task.

NOTE: Tips and additional information to aid in completing a task.

Where to find more information

Refer to the following sources for additional information and for product and software updates.

1. ASUS Websites

The ASUS websites worldwide provide updated information on ASUS hardware and software products. The ASUS websites are listed in the ASUS Contact Information on page viii.

2. Optional Documentation

Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. These documents are not part of the standard package.

vii

ASUS contact information

ASUSTeK COMPUTER INC. (Asia-Pacific)

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112 General Tel: +886-2-2894-3447 General Fax: +886-2-2894-3449 General Email: info@asus.com.tw

Technical Support

MB/Others (Tel): +886-2-2890-7121 (English) Notebook (Tel): +886-2-2890-7122 (English) Desktop/Server (Tel): +886-2-2890-7123 (English) Support Fax: +886-2-2890-7698 Web Site: www.asus.com.tw

ASUS COMPUTER INTERNATIONAL (America)

Address: 44370 Nobel Drive, Fremont, CA 94538, USA General Fax: +1-502-933-8713 General Email: tmd1@asus.com

Technical Support

Support Fax: +1-502-933-8713 General Support: +1-502-995-0883 Notebook Support: +1-510-739-3777 x5110 Web Site: usa.asus.com Support Email: tsd@asus.com

ASUS COMPUTER GmbH (Germany and Austria)

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany General Email: sales@asuscom.de (for marketing requests only) General Fax: +49-2102-9599-31

Technical Support

Support Hotlines: (Components) +49-2102-9599-0

(Notebook PC) +49-2102-9599-10 Support Fax: +49-2102-9599-11 Support Email: www.asuscom.de/kontakt (for online support) Web Site: www.asuscom.de

viii

A7V600 specifications summary

CPU

Chipset

Front Side Bus (FSB) Memory

Expansion slots

Storage

Audio

Socket A for AMD Athlon XP/Athlon/Duron with Thoroughbred/Barton Core support

Northbridge: VIA KT600 Southbridge: VIA VT8237

400/333/266/200Mhz 3 x 184-pin DDR DIMM Sockets support a maximum of 3GB

unbuffered non-ECC PC2700/2100 DDR SDRAM memory. (Note: PC3200 maximum to 2 DIMMs only.)

Visit the ASUS website for the latest qualified DDR400 module list

1 x AGP 8X 6 x PCI 1 x ASUS Proprietary WiFi wireless LAN connector

2 x UltraDMA 133/100/66 2 x Serial ATA with RAID 0, RAID 1 and JBOD support

ADI AD1980 SoundMAX 6-channel CODEC S/PDIF out interface

LAN Special Features

Overclocking Features

Rear Panel I/O

3Com® 3C940 1Gbps Ethernet controller ASUS EZ Flash

Power Loss Restart ASUS C.O.P. (CPU Overheating Protection) ASUS CrashFree BIOS 2 ASUS Instant Music Lite

ASUS JumperFree ASUS C.P.R. (CPU Parameter Recall) CPU, Memory, and AGP Voltage adjustable SFS (Stepless Frequency Selection) from 100Mhz up to 250MHz at 1MHz increment Adjustable FSB/DDR ration with fixed AGP/PCI frequencies

1 x Parallel port 1 x Serial port 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x Audio I/O 4 x USB 2.0 1 x RJ-45 Port 1 x S/PDIF out port

(continued on the next page)

A7V600 specifications summary (Cont’)

Internal I/O Connectors

BIOS features

Industry standard Manageability Form Factor Support CD contents

CPU/Power/Chassis FAN connectors 20 pin ATX power connector Chassis Intrusion GAME/MIDI connector CD/AUX/Modem audio in S/PDIF out connector Front panel audio connector 2 x USB 2.0 connector supports additional 4 USB 2.0 ports 2 x Serial ATA port COM2 connector

2Mb Flash ROM, ASUS Jumperfree, Award BIOS, PnP, DMI2.0, WfM2.0, SM BIOS2.3, ASUS EZ Flash, ASUS CrashFree BIOS 2, ASUS C.P.R.

PCI 2.2, USB 2.0 WfM 2.0. DMI 2.0, WOR, WOL, chassis intrusion ATX form factor: 12 in x 9.6 in (30.5 cm x 24.5 cm) Device drivers

ASUS PC Probe Trend Micro™ PC-cillin 2002 anti-virus software ASUS LiveUpdate Utility

(OEM version)

* Specifications are subject to change without notice.

Chapter 1

This chapter gives information about the ASUS A7V600 motherboard that came with the system.This chapter includes the motherboard layout, jumper settings, and connector locations.

ASUS A7V600 Motherboard

Motherboard Info

1-1

1.1 Welcome!

Thank you for buying the ASUS® A7V600 motherboard!

The ASUS A7V600 motherboard is loaded with the most advanced technologies to deliver the maximum performance for socket A processors. Based on the advanced VIA KT600 chipset with FSB 400 and DDR 400 support, the ASUS A7V600 also features AGP 8X, Serial ATA, USB 2.0 as well as 6-channel audio, Gigabit LAN and S/PDIF out features. Unique ASUS features such as ASUS C.O.P., C.P.R. , CrashFree BIOS2, Q-Fan and more are included to ensure the best user experience and value in a motherboard.

Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.

1.2 Package contents

Check your ASUS A7V600 package for the following items.

ASUS A7V600 motherboard

ATX form factor: 12 in x 9.6 in (30.5 cm x 24.5 cm) ASUS A7V600 series support CD 2 pcs. Serial ATA cable 2-port USB 2.0 module 1 pc. 80-conductor ribbon cable for UltraDMA/66/100/133 IDE drives 40-conductor IDE cable Ribbon cable for a 3.5-inch floppy drive I/O shield Bag of extra jumper caps User Guide

1-2

1.3 Special features

1.3.1 Product highlights

400 FSB K7 Platform

Combining support for the next generation AMD Athlon™ XP processors with 400Mhz Front Side Bus (FSB) with its advanced FastStream64™ Memory Controller Technology and the industry-first integrated Serial ATA/RAID controller on the VIA VT8237 South Bridge, the VIA KT600 provides the highest performance and most feature-rich platform for increased office productivity and enhanced

digital media experience.

DDR400 (PC3200) support

DDR400 (PC3200), the latest and fastest DDR memory standard, supports bandwidth of up to 3.2 GB/s to provide enhanced system performance. (Note: PC3200 maximum to 2 DIMMs only. Visit the ASUS website for the latest qualified DDR400 module list.)

AGP 8X support

AGP 8X (AGP 3.0) is the next generation VGA interface specification that enables enhanced graphics performance with high bandwidth speeds up to 2.12 GB/s. With

a bus of 533Mhz, AGP 8X is twice as fast as AGP 4X.

Serial ATA technology

The motherboard bundles the new Serial AT A technology through the SATA interfaces onboard. The SATA specification allows for thinner, more flexible cables with lower pin count, reduced voltage requirement, up to 150 MB/s data transfer rate.

AI NET solution

The 3Com® 3C940 Gigabit PCI LAN controller chipset is onboard to provide a single-chip solution for LAN on Motherboard (LOM) applications. The 3C940 controller integrates 32-bit 10/100/1000BASE-T Gigabit Ethernet Media Access Control (IEEE 802.3 compliant) and Physical Layer Transceiver solution to support high performance network applications. The controller is equipped with the netdiagnosing utility, VCT (Virtual Cable Tester), that intelligently diagnoses and reports cable faults from a remote location up to 100 meters. This feature helps maintain a more stable network connection.

ASUS A7V600 Motherboard

1-3

ASUS Q-Fan feature

The ASUS Q-Fan technology smartly adjusts the fan speeds according to the system loading to ensure quiet, cool, and efficient operation.

8 x USB 2.0 ports support

USB 2.0 is the latest connectivity standard for next generation components and peripherals. USB 2.0 delivers fast transfer speeds up to 40 times faster at 480 MB/ s, for easy connectivity and ultra-fast data transfers. The higher bandwidth of USB

2.0 allows connection of devices such as high resolution video conferencing cameras, next generation scanners, printers, and fast storage units. USB 2.0 is

backward compatible with USB 1.1.

S/PDIF out port on Rear Panel I/O

The A7V600 provides convenient connectivity to external home theater audio systems via an S/PDIF out interface. Experience 5.1-channel surround sound and

enhanced 3D audio while playing your favorite DVDs or games.

C.O.P. (CPU Overheating Protection)

With AMD® Athlon XP™ installed, the motherboard offers automatic CPU Overheating Protection to prolong the life of the entire system. If the CPU

temperature exceeds the set criteria, the PC shuts down automatically.

ASUS C.P.R. (CPU Parameter Recall)

The C.P.R. feature of the ASUS motherboard BIOS allows automatic resetting to the BIOS previous settings in case the system hands due to overclocking. When the system hangs due to overclocking, C.P.R. eliminates the need to open the system chassis and clear the RTC data. Simply reboot the system, and the BIOS automatically restores the previous value of the CPU parameters.

CrashFree BIOS 2

The CrashFree BIOS 2 feature allows you to restore the original BIOS data from the ASUS support CD in case when the BIOS codes and data are corrupted. This

protection feature eliminates the need to buy a replacement ROM chip.

ASUS EZ Flash BIOS

With the ASUS EZ Flash, you can easily update the system BIOS even before loading the operating system. No need to use a DOS-based utility or boot from a floppy disk.

ASUS Instant Music Lite

This unique feature allows you to playback audio files even without booting the system to Windows™. Just press the ASUS Instant Music Lite special function keys and enjoy the music!

1-4

1.3.2 Value-added solutions

Overclocking

• adjustable CPU frequency multiple in BIOS using the ASUS JumperFree™ solution

• C.P.R. (CPU Parameter Recall)

• adjustable CPU V

• Stepless Frequency Selection (SFS) for fine-tuning system bus frequency from 100MHz up to 250MHz at 1MHz increments

, and DDR memory and AGP voltages

CORE

Temperature, fan, and voltage monitoring

The CPU temperature is monitored by the ASUS ASIC to prevent overheating and damage. The system fan rotations per minute (RPM) is monitored for timely failure detection. The system voltage levels are monitored to ensure stable supply of current for critical components.

Chassis intrusion detection

The motherboard supports chassis intrusion monitoring. A chassis intrusion event is retained in CMOS for more protection.

ASUS update

This utility allows you to update the motherboard BIOS through a user-friendly interface. Connect to the Internet then to the ASUS FTP site nearest you to obtain the latest BIOS version for your motherboard.

ASUS A7V600 Motherboard

1-5

1.4 Motherboard components

2 3 4

20 21

Before you install the motherboard, learn about its major components and available features to facilitate the installation and future upgrades. Refer to the succeeding pages for the component descriptions.

1415

8 9

1-6

2728

Chapter 1: Motherboard Information

1.4.1 Core specifications

CPU socket. Socket 462 (Socket A) surface mount, Zero Insertion Force

(ZIF) socket for the AMD Athlon XP/Athlon/Duron Processors. (Note: When using CPUs with FSB 100, the maximum DDR data transfer rate allowed is only at 266Mhz.)

North bridge controller. The VIA

KT600 supports AGP 8X mode, 400/

333/266/200MHz Front Side Bus, and the latest 400/333/266MHz 64-bit memory bus.

DDR DIMM sockets. These three 184-pin DIMM sockets support up to 3GB

system memory using unbuffered non-ECC PC2700/2100 DDR DIMMs. PC3200 (DDR400) DIMMs support is maximum to 2 DIMMs only.

Visit the ASUS website (www.asus.com) for the latest qualified PC3200 (DDR400) module list.

IDE connectors. These dual-channel bus master IDE connectors support

up to four Ultra DMA133/100/66, PIO Modes 3 & 4 IDE devices. Both the primary (blue) and secondary (black) connectors are slotted to prevent incorrect insertion of the IDE ribbon cable.

ATX power connector. This 20-pin connector connects to an ATX +12V

power supply. The power supply must have at least 1A on the +5V standby lead (+5VSB).

Floppy disk connector. This connector accommodates the provided

ribbon cable for the floppy disk drive. One side of the connector is slotted to prevent incorrect insertion of the floppy disk cable.

AGP slot. This Accelerated Graphics Port (AGP) slot supports 1.5V AGP8X mode graphics cards for 3D graphical applications.

Serial A T A connectors. These two 7-pin connectors accommodate the thin cables for Serial AT A devices.

South bridge controller. The VIA

VT8237 integrated peripheral controller

supports various I/O functions including two Serial ATA ports, 2-channel ATA/133 bus master IDE controller, up to eight USB 2.0 ports, LPC Super I/O interface, AC’97 interface and PCI 2.2 interface.

Super I/O controller. This Low Pin Count (LPC) interface provides the commonly used Super I/O functionality. The chipset supports a highperformance floppy disk controller for a 360K/720K/1.44M/2.88M floppy disk drive, a multi-mode parallel port, two standard compatible UARTs, and a Flash ROM interface.

Flash ROM. This 2Mb firmware contains the programmable BIOS program.

Standby power LED. This LED lights up if there is a standby power on the

motherboard. This LED acts as a reminder to turn off the system power before plugging or unplugging devices.

USB connectors. These two 10-1 pin connectors accomodate the bundled

USB 2.0 module.

ASUS A7V600 Motherboard

1-7

COM2 connector. This 9-pin COM2 connector is for a COM2 cable for an

additional serial port.

19 20

WiFi slot. The WiFi (Wireless Fidelity) slot connects a Wi-Fi wireless

networking module that allows 11Mbps transmission (with a fallback to 5.5, 2 and 1 Mbps) in the 2.4 GHz band. Wi-Fi networks use radio technologies known as IEEE 802.11b to provide a fast reliable wireless connectivity.

PCI slots. These six 32-bit PCI 2.2 expansion slots support bus master PCI cards like SCSI or LAN cards with 133MB/s maximum throughput.

Audio CODEC . The ADI 1980 is an AC’97 compliant audio CODEC for PC multimedia systems.

Gigabit LAN controller. The 3Com

Gigabit LAN delivers transfer rates up to ten times faster than conventional 10/100 Ethernet connections. Ideal for handling large amounts of data such as video, audio and voice.

PS/2 mouse port. This green 6-pin connector is for a PS/2 mouse. Parallel port. This 25-pin port connects a parallel printer, a scanner, or

other devices. RJ-45 port. This port allows connection to a Local Area Network (LAN)

through a network hub.

Line In jack. This Line In (light blue) jack connects a tape player or other

audio sources. In 6-channel mode, the function of this jack becomes Line Out/Front Speaker Out.

Line Out jack. This Line Out (lime) jack connects a headphone or a

speaker. In 6-channel mode, the function of this jack becomes Front Speaker Out.

Microphone. This Mic (pink) jack connects a microphone. In a 6-channel

mode, the function of this jack becomes Center Speaker Out/Subwoofer.

Audio 2, 4 and 6-channel configuration

Connector Headphone/2-Speaker 4-Speaker 6-Speaker

Light Blue Line In Line In Line Out/Front Speaker Out Lime Line Out Front Speaker Out Front Speaker Out Pink Mic In Rear Speaker Out Center Speaker/Subwoofer

USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports

are available for connecting USB 2.0 devices. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports

are available for connecting USB 2.0 devices.

1-8

27 28 29

Serial port (COM1). This 9-pin serial port is for an additional serial device. S/PDIF out jack. This jack connects to external audio output devices. PS/2 keyboard port. This purple 6-pin connector is for a PS/2 keyboard.

Chapter 1: Motherboard Information

1.5 Motherboard layout

24.5cm (9.6in)

PS/2KBMS T: Mouse B: Keyboard

SPDIF_O

COM1

USB1 USB2

USB2.0

T: USB4

B: USB3

Top:Line In Center:Line Out Below:Mic In

3Com

KBPWR

PARALLEL PORT

Top:

RJ-45

Gbit

LAN

3C940

FP_AUDIO

USBPW12 USBPW34

AUX CD

OVER_VOLT1

KT600

Chipset

PWR_FAN

Accelerated Graphics Port (AGP)

PCI1

PCI2

VIA

A7V600

CPU_FAN

Socket 462

ATX Power Connector

DDR DIMM2 (64/72 bit,184-pin module)

DDR DIMM1 (64/72 bit,184-pin module)

DDR DIMM3 (64/72 bit,184-pin module)

PRI_IDE

SEC_IDE

SATA1

VIA

VT8237

South

SATA2

Bridge

FLOPPY

30.5cm (12.0in)

AD1980 CODEC

MODEM

SPDIF_OUT2

PCI3

PCI4

PCI5

PCI6

WIFI

COM2

CR2032 3V Lithium Cell

CMOS Power

Super

I/O

GAME

CLRTC

USB56

USBPW78 USBPW56

USB78

SB_PWR

CHA_FAN

2Mbit

Low Pin

Count

CHASSIS

PANEL

ASUS A7V600 Motherboard

1-9

1.6 Before you proceed

Take note of the following precautions before you install motherboard components or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any component.

2. Use a grounded wrist strap or touch a safely grounded object or to a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity.

3. Hold components by the edges to avoid touching the ICs on them.

4. Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.

5. Before you install or remove any component, ensure that the ATX

power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

When lit, the green LED (SB_PWR) indicates that the system is ON, in sleep mode, or in soft-off mode, a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component.

A7V600

A7V600 Onboard LED

Standby

Power

SB_PWR

OFF

Powere

Off

Install only 1.5V AGP cards on this motherboard to prevent damage to your AGP card or motherboard.

1-10

Chapter 1: Motherboard Information

1.7 Motherboard installation

Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. The motherboard uses the ATX form factor that measures 12 inches x 9.6 inches (30.5 cm x 24.5 cm).

Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause you physical injury and damage motherboard components.

1.7.1 Placement direction

When installing the motherboard, make sure that you place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image below.

1.7.2 Screw holes

Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis.

Do not overtighten the screws! Doing so may damage the motherboard.

Place this side towards the rear of the chassis

ASUS A7V600 Motherboard

1-11

1.8 Central Processing Unit (CPU)

The motherboard provides a Socket A (462) for CPU installation. AMD processors offer gigahertz speeds to support all the latest computing platforms and applications. The A7V600 supports Athlon

A7V600

XP, AthlonTM, Barton™ and DuronTM processors.

CPU NOTCH TO INNER CORNER

AMD™ CPU

A7V600 Socket A

CPU NOTCH

1.8.1 Installing the CPU

Follow these steps to install a CPU:

1. Locate the Socket 462 and open it by pulling the lever gently sideways away from the socket. Then lift the lever upwards. The socket lever must be fully opened (90 to 100 degrees).

2. Insert the CPU with the correct orientation. The notched or golden corner of the CPU must be oriented toward the inner corner of the socket base nearest to the lever hinge.

The CPU should drop easily into place. Do not force the CPU into the socket to avoid bending the pins. If the CPU does not fit, check its alignment and look for bent pins.

LEVER

LOCK

4. Once completely inserted, press the CPU firmly and close the socket lever until it snaps shut.

5. Place the CPU fan and heatsink on the CPU. The heatsink should entirely cover the CPU. Carefully attach the heatsink locking brace to the plastic clips on the socket base. With the added weight of the CPU fan and heatsink locking brace, no extra force is required to keep the CPU in place

1-12

Chapter 1: Motherboard Information

1.9 System memory

The motherboard has three Double Data Rate (DDR) DIMM sockets that supports up to 3GB unbuffered non-ECC PC3200/2700/2100 DDR DIMMs.

A DDR DIMM has the same physical dimensions as an SDR DIMM, but it has a 184-pin footprint compared to the 168-pin of the SDR DIMM. Also, a DDR DIMM is single notched while an SDR DIMM is double notched.

DIMM1

DIMM2

DIMM3

A7V600

80 Pins 104 Pins

A7V600 184-Pin DDR DIMM Sockets

A DDR DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into a socket to avoid damaging the DIMM.

PC3200 maximum to 2 banks only.

1.9.1 DDR400 Qualified Vendor List

The following table lists the DDR400 (PC3200) memory modules that have been tested and qualified for use with this motherboard. Make sure to use only the tested and qualified DDR400 DIMMs listed below.

DDR400 One DIMM support only

Vendor Size Type P/N Chip

Samsung 512MB DS M368L6432ETM-CCC K4H560838E-TCCC KingMax 512MB DS MPXC22D-38KT3R KDL388P4EA-50

Micron 256MB SS MT8VDDT3264AG-40BC4 MT46V32MTG-5BC Micron 512MB DS MT16VDDT6464AG-40BC4 MT46V32M8TG-5BC NANYA 512MB DS NT512D64S8HB1G-5T NT5DS32M8BT-5T Infineon 512MB DS HYS64D64320GU-5-B HYB25D256800BT-5

DDR400 Two DIMM support only

Vendor Size Type P/N Chip

GEIL 512MB DS MAG16UL3264D1TG5A-KC GL3LC32G88TG-5A Micron 512MB DS MT16VDDT6464AG-40BC4 MT46V32M8TG-5BC Nanya 256MB SS NT256D64S88B1G-5T NT5DS32M8BT-5T ADATA 256 SS MDOSS6F3G31JB1EAE K4H560838D-TCC4

ASUS A7V600 Motherboard

1-13

1.10 Expansion slots

The A7V600 motherboard has six (6) expansion PCI slots and one (1) AGP 8X slot. The following sub-sections describe the slots and the expansion cards that they support.

1.10.1 Configuring an expansion card

After physically installing the expansion card, configure the card by adjusting the software settings.

1. Turn on the system and change the necessary BIOS settings, if any.

2. Assign an IRQ to the card. Refer to the tables below.

3. Install the software drivers for the expansion card.

1.10.2 Standard Interrupt Assignments

IRQ Priority Standard Function

0 1 System Timer 1 2 Keyboard Controller 2 N/A Programmable Interrupt 3* 11 Communications Port (COM2) 4* 12 Communications Port (COM1) 5* 13 Sound Card (sometimes LPT2) 6 14 Floppy Disk Controller 7* 15 Printer Port (LPT1) 8 3 System CMOS/Real Time Clock 9* 4 ACPI Mode when used 10* 5 IRQ Holder for PCI Steering 11* 6 IRQ Holder for PCI Steering 12* 7 PS/2 Compatible Mouse Port 13 8 Numeric Data Processor 14* 9 Primary IDE Channel 15* 10 Secondary IDE Channel

*These IRQs are usually available for ISA or PCI devices.

1-14

Chapter 1: Motherboard Information

IRQ assignments for this motherboard

ABCDEFGH

PCI slot — — — shared — — — — PCI slot 2 shared — — — — — — — PCI slot 3 — shared — — — — — — PCI slot 4 — — shared — — — — — PCI slot 5 — — — shared — — — — PCI slot 6 shared — — — — — — — AGP slot shared — — — — — — — USB 1.1 UHCI 1 — — — — shared — — — USB 1.1 UHCI 2 — — — — shared — — — USB 1.1 UHCI 3 — — — — — shared — — USB 1.1 UHCI 4 — — — — — shared — — USB 2.0 EHCI — — — — — — shared — USB Device — — — — — — — shared AC97 Codec — — — — — — shared — Onboard LAN — — shared — — — — — Onboard SATA — — — — shared — — — Onboard IDE — — — — shared — — —

1.10.3 AGP slot

This motherboard has an Accelerated Graphics Port (AGP) slot that supports +1.5V AGP cards only. When you buy an AGP card, make sure that you ask for one with +1.5V specification. Note the notches on the card golden fingers to ensure that they fit the AGP slot on your motherboard.

A7V600

Keyed for 1.5v

A7V600 Accelerated Graphics Port (AGP)

ASUS A7V600 Motherboard

1-15

+ 57 hidden pages
