Anthem MRX 1120, MRX 720, AVM 60 User Manual

MRX 1120/720

A/V RECEIVERS

AVM 60

A/V PROCESSOR

OPERATING MANUAL

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

The lightning ﬂash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the point where

they exit from the apparatus.

11. Only use the attachments/accessories speciﬁed by the manufacturer.

12. Use only with a cart, stand, tripod, bracket or table speciﬁed by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such

as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

WARNING: To reduce the risk of ﬁre or electric shock, do not expose this apparatus to rain or

moisture. Avoid installing this unit where foreign objects may fall onto this unit and/or this unit may be exposed to liquid dripping or splashing. On the top of this unit, do not place:

• Burning objects (i.e. candles), as they may cause ﬁre, damage to this unit, and/or

personal injury.

• Containers with liquid in them, as they may fall and liquid may cause electrical shock to

the user and/or damage to this unit.

Apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids, such as vases, shall be placed on the apparatus.

Do not install this equipment in a conﬁned space such as a case or similar. Install it away from direct sunlight, heat sources, vibration, dust, moisture, and/or cold.

Do not cover this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radiation. If the temperature inside this unit rises, it may cause ﬁre, damage to this unit, and/or personal injury.

Install this unit near the AC outlet and where the AC power plug can be reached easily.

This unit is not disconnected from the AC power source when it is turned off. This state is called the standby mode. In this state, this unit is designed to consume a very small quantity of power. To completely disconnect this apparatus from the AC mains, disconnect the power supply cord plug from the AC receptacle.

NOTE: This product is not an auto voltage Receiver. Connect only to the prescribed AC outlet,

i.e., 120V 60Hz or 220-240V 50Hz.

CAUTION: These servicing instructions are for use by qualiﬁed service personnel only. To reduce

the risk of electric shock, do not perform any servicing other than that contained in the operating instructions, unless you are qualiﬁed to do so.

CAUTION: Changes or modiﬁcations to this equipment not expressly approved by Paradigm

Electronics for compliance could void the user’s authority to operate this equipment.

FCC WARNING: Changes or modiﬁcations not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the unit.

• Connect the equipment into an outlet on a circuit different from that to which the unit is connected.

• Consult the dealer or an experienced radio / TV technician for help.

III

USA CANADA

Når dette produkt installeres som beskrevet i instruktionerne i denne manual,

Der skal opretholdes en afstand på mindst 20 cm mellem produktet og alle

Dette produkt og dets antenne må ikke placeres i nærheden af eller fungere

Produktene våre følger bestemmelsene i følgende EC/EU-direktiv: R&TTE-direktiv

Når dette produktet er montert som angitt i instruksjonene i denne håndboken,

FCC Information (For US customers)

IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT1.

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modiﬁcation not expressly approved Aby Paradigm Electronics Inc. may void your authority, granted by the FCC, to use the product.

CAUTION2.

•

comply with FCC RF exposure compliance requirement, separation distance of at least 20 cm must be maintained between this product and all persons.

• This product and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

• This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

• Operations in the 5.15 - 5.25 GHz band are restricted to indoor usage only.

• For operation within 5.15 - 5.25 GHz / 5.25 - 5.35 GHz / 5.47 - 5.725 GHz frequency range,

it is restricted to indoor environment.

•

This device meets all the other requirements speciﬁed in Part 15E, Section 15.407 of the FCC Rules.

COMPLIANCE INFORMATION3. Product Name:

•

MRX 720 : AV Receiver MRX 1120 : AV Receiver AVM 60 : Pre-Processor

4. NOTE

This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the product OFF and ON, the user is encouraged to try to correct the interference by one or more of and ON, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

Connect the product into an outlet on a circuit different from that to which the receiver is connected.

•

• Consult the local retailer authorized to distribute this type of product or an experienced radio/TV technician for help.

CONTAINS TRANSMITTER MODULE FCC ID: 2AAWQ-CAPRICA2L

•

This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this product may not cause harmful interference, and (2) this product must accept any interference received, including interference that may cause undesired operation. Paradigm Electronics Inc. 205 Annagem Blvd. Mississauga, ON L5T 2V1

RF Exposure Information

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of speciﬁc absorption ratio (SAR). Cet équipement est conforme aux normes d’exposition aux radiations FCC/IC déﬁnies pour un environnement non contrôlé et satisfait les directives d’exposition à la radiofréquence (RF) dans le supplément C des OET65 et RSS-102 des règles d’exposition à la fréquence radio (RF) IC. Cet équipement a de très faibles niveaux d’énergie RF qui sont jugés conformes sans test de taux d’absorption spéciﬁque (SAR).

IC Information (For Canadian customers) Informations sur IC (pour les clients canadiens)

1. PRODUCT CONTAINS TRANSMITTER MODULE IC: 11138A-CAPRICA2L

This product complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this product may not cause harmful interference, and (2) this product must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES- 003.

2. CAUTION

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. (i) the device for operation in the band 5,150-5,250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.(ii) high-power radars are allocated as primary users (i.e. priority users) of the bands 5,250-5,350 MHz and 5,650-5,850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Radiation Exposure Statement:(ii) high-power radars are allocated as primary users (i.e. priority users) of the bands 5,250-5,350 MHz and 5,650-5,850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

•

The maximum antenna gain permitted for devices in the bands 5,250 - 5,350 MHz and 5,470 - 5,725 MHz shall comply with the

e.i.r.p. limit; and

• The maximum antenna gain permitted for devices in the band 5,725 - 5,825 MHz shall comply with the e.i.r.p. limits speciﬁed for point-to-point and non point-to-point operation as appropriate.

APPAREIL

CONTIENT MODULE ÉMETTEUR IC: 11138A-CAPRICA2L

Cet appareil est conforme à la norme CNR-210 du Canada. L’utilisation de ce dispositif est autorisée seulement aux deux conditions suivantes : (1) il ne doit pas produire de brouillage, et (2) l’utilisateur du dispositif doit être prêt à ccepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

2. ATTENTION

Aﬁn de réduire le risque d’interférence aux autres utilisateurs, il faut choisir le type d’antenne et son gain de façon à ce que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne soit pas supérieure au niveau requis pour l’obtention d’une communication satisfaisante.

(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une utilisation à l’intérieur aﬁn de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. (ii) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL. Déclaration d’exposition aux radiations: Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.

•

Le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250 - 5 350 MHz et 5 470 - 5 725 MHz doit se conformer à la limite

de p.i.r.e.;

Le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725 - 5 825 MHz) doit se conformer à la limite de p.i.r.e. spéciﬁée

•

pour l’exploitation point à point et non point à point, selon le cas.

For Canadian customers/Pour les clients canadiens: CAN ICES-3(B)/NMB-3(B)

ENGLISH

DECLARATION OF CONFORMITY1.

Our products following the provisions of EC/EU directives, that as follows; R&TTE Directive 1999/5/EC

2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT

This product, when installed as indicated in the instructions contained in this manual, meets R&TTE directive requirements. Modiﬁcation of the product could result in hazardous Radio and EMC radiation.

CAUTION3.

Separation distance of at least 20 cm must be maintained between this product and all persons.This product and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. 5,150 – 5,350 MHz is restricted to indoor use only

•

DEUTSCH

ÜBEREINSTIMMUNGSERKLÄRUNG1.

EG/EU-Richtlinien: R&TTE Directive 1999/5/EC

. WICHTIGER HINWEIS: NEHMEN SIE KEI2.

VERÄNDERUNGEN AN DIESEM PRODUKT VOR

Wenn dieses Produkt entsprechend dieser Bedienungsanleitung aufgebaut wird, entspricht es den Anforderungen der R&TTE-Richtlinie. Veränderungen am Produkt können zu gefährlicher Funk- und EMV-Strahlung führen.

VORSICHT3.

Zwischen dieses Produkts und Personen muss ein Schutzabstand von 20 cm eingehalten werden. Dieses Produkt und seine Antenne dürfen nicht neben anderen Antennen oder Sendern aufgestellt oder zusammen mit ihnen verwendet werden.

•

5.150 – 5.350 MHz darf nur in geschlossenen Räumen verwendet werden.

FRANÇAIS

DECLARATION DE CONFORMITE1.

Nos produits sont conformes aux dispositions des directives CE/UE comme suit ; R&TTE Directive 1999/5/EC

. MISE EN GARDE IMPORTANTE : NE JAMAIS MODIFI2.

CE PRODUIT

Si toutes les consignes indiquées dans ce mode ont été respectées pendant son installation, ce produit est conforme aux directives R&TTE. Toute modiﬁcation du produit risquerait alors de générer des radiations radio et EMC dangereuses.

3. ATTENTION

L’appareil devra être située à une distance de 20 cm au moins des personnes. Ce produit ainsi que son antenne ne devront en aucun cas être utilisés à proximité d’une autre antenne ou transmetteur.

•

5 150 - 5 350 MHz est limité à une utilisation en intérieur uniquement.

ITALIANO

1. DICHIARAZIONE DI CONFORMITÀ

a quanto previsto dalle direttive EC/EU, come speciﬁcato di seguito: R&TTE Directive 1999/5/EC

2.. AVVERTENZA IMPORTANTE: NON MODIFICA QUESTO PRODOTTO

Se installato come indicato nelle istruzioni del presente manuale, questo prodotto soddisfa i requisiti della direttiva R&TTE. Eventuali modiﬁche apportate al prodotto potrebbero causare pericolose radiazioni radio ed EMC.

3. ATTENZIONE

È necessario mantenere una distanza minima di 20 cm tra questo prodotto e le persone. Questo prodotto e la relativa antenna non devono essere posizionati in prossimità di altre antenne o trasmettitori e non devono essere utilizzati congiuntamente a questi ultimi. La frequenza 5,150 – 5,350 MHz è limitata al solo uso interno.

•

Bestimmungen der folgenden Unsere Produkte unterliegen den

I nostri prodotti sono conformi

ESPAÑOL

DECLARACIÓN DE CONFORMIDAD1.

Nuestros productos cumplen las disposiciones de las directivas de la CE/UE siguientes: R&TTE Directive 1999/5/EC

NOTA IMPORTANTE: NO MODIFIQUE ESTE PRODUCTO2.

Este producto, si es instalado de acuerdo con las instrucciones contenidas en este manual, cumple los requisitos de la directiva R&TTE. La modiﬁcación del producto puede producir radiación de Radio y EMC peligrosa.

3. PRECAUCIÓN

Se debe mantener una separación de al menos 20 cm del producto y las personas. Este producto y su antena no debe instalarse ni utilizarse conjuntamente con otra antena o transmisor.

•

5,150 – 5,350 MHz está restringido al uso en interiores solamente.

NEDERLANDS

EENVORMIGHEIDSVERKLARING1.

Onze producten volgen de voorwaarden van de EG/EU-richtlijnen zoals volgt; R&TTE Directive 1999/5/EC

. BELANGRIJKE MEDEDELING: BRENG AAN D2.

PRODUCT GEEN AANPASSINGEN AAN

Dit product, indien geïnstalleerd volgens de aanwijzingen in deze gebruiksaanwijzing, voldoet aan de vereisten van de R&TTE-richtlijn. Aanpassing van dit product kan gevaarlijke radio- en EMC-straling tot gevolg hebben.

3. LET OP

Houd tussen en personen altijd een afstand van tenminste 20 cm aan. Dit product en zijn antenne mogen niet in de buurt van een andere antenne of zender worden geplaatst of in combinatie daarmee worden gebruikt.

•

5.150 – 5.350 MHz is beperkt tot alleen binnenshuis gebruik.

SVENSKA

1. ÖVERENSSTÄMMELSESINTYG

Våra produkter uppfyller följande föreskrifter i EC/EU-direktiv: R&TTE Directive 1999/5/EC

VIKTIGT: APPARATEN FÅR INTE MODIFIERAS2.

Under förutsättning att apparaten installeras enligt anvisningarna i denna bruksanvisning, uppfyller denna kraven i R&TTE-direktivet. Ev. modiﬁering av apparaten kan resultera i farlig radio- och elektromagnetisk strålning.

FÖRSIKTIGT3.

Se till att det ﬁnns ett avstånd på minst 20 cm mellan apparatens och personer i omgivningen. Apparaten och dess antenn får inte placeras eller användas i närheten av andra antenner eller sändare.

•

5 150 – 5 350 MHz är begränsat till inomhusbruk.

РУССКИЙ

СЕРТИФИКАТ СООТВЕТСТВИЯ1.

Наши продукты соответствуют следующим положениями директивы ЕЭС/ЕС: R&TTE Directive 1999/5/EC

ВАЖНО! НЕ ИЗМЕНЯЙТЕ ДАННЫЙ ПРОДУКТ2.

Продукт, установленный согласно инструкциям в настоящем руководстве, отвечает требованиям директивы R&TTE. Изменение продукта может привести к появлению опасного электромагнитного излучения.

ПРЕДУПРЕЖДЕНИЕ3.

Не приближайтесь к данного изделия ближе, чем на 20 см. Запрещается использовать данный продукт и антенну с другой антенной или передатчиком.

•

5150 – 5350 МГц ограничивается использованием только в помещении.

PROPOSITION 65 WARNING (California only)

This product contains a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov

POLSKI

DEKLARACJA ZGODNOŚCI1.

Nasze produkty zgodnie z postanowieniami KE/UE, tj. R&TTE Directive 1999/5/EC

2. UWAGA: MODYFIKACJA TEGO URZĄDZENIA JEST

ZABRONIONA

Po zainstalowaniu zgodnie z instrukcjami zawartymi w niniejszej instrukcji obsługi urządzenie to będzie spełniać wymogi dyrektywy R&TTE. Wprowadzanie modyﬁkacji do tego urządzenia może skutkować powstaniem niebezpiecznego promieniowania elektromagnetycznego oraz radiowego.

OSTRZEŻENIE3.

Między tego produktu i wszelkimi osobami musi być zachowana odległość przynajmniej 20 cm. Urządzenia wraz z anteną nie można instalować w połączeniu z inną anteną lub nadajnikiem.

•

5 150 – 5 350 MHz to częstotliwość ograniczona do użytkowania jedynie w pomieszczeniach.

DANISH

1. ERKLÆRING OM OVERHOLDELSE

Vores produkter lever op til bestemmelserne i følgende EF-/EU-direktiver; R&TTE-direktivet 1999/5/EF

2. VIGTIG BEMÆRKNING: DU MÅ IKKE ÆNDRE DETTE PRODUKT

overholder det kravene i R&TTE-direktivet. Ændring af produktet kan medføre farlig radio- og EMC-stråling.

FORSIGTIG3.

personer.

sammen med andre antenner eller sendere.

•

5.150 - 5.350 MHz er begrænset til udelukkende indendørs brug.

NORWAY

SAMSVARSERKLÆRING1.

1999/5/EC

VIKTIG MERKNAD: IKKE MODIFISER DETTE PRODUKTET2.

oppfyller det kravene i R&TTE-direktivet. Modiﬁsering av produktet kan resultere i farlig radio- og EMC-stråling.

3. OBS!

Det må opprettholdes en avstand på minst 20 cm mellom dette produktet og alle personer. Dette produktet og antennen må ikke plasseres på samme sted som eller brukes i forbindelse med andre antenner eller sendere.

•

5 150 – 5 350 MHz er kun begrenset til innendørs bruk.

• DECLARATION OF CONFORMITY

Our products following the provisions of EC/EU directives, that as follows; LV: 2006/95/EC EMC: 2004/108/EC RoHS: 2011/65/EU ErP: EC regulation 1275/2008 and its frame work directive 2009/125/EC R&TTE: 1999/5/EC

This product may be operated in the following countries;

AT BE CZ DK FI FR DE GR HU IE

IT NL PL PT SK

ES SE GB NO CH

Indoor use only.

R&TTE Directive 1999/5/EC

III

DO NOT LOCATE IN THE FOLLOWING PLACES:

To ensure long-lasting use, do not locate the unit:

• Exposed to direct sunlight.

• Near sources of heat such as heaters.

Left 0.2 m (8 in) or more

• Highly humid or poorly ventilated.

• Dusty.

• Subjected to mechanical vibrations.

• On wobbly, inclined, or otherwise unstable surfaces.

• Near windows where there is a chance of exposure to rain, etc.

• On top of an ampliﬁer or other component which dissipates a great deal of heat.

To ensure proper heat radiation, ensure clearance from walls and other equipment according to diagram.

IMPORTANT INFORMATION FOR UK CUSTOMERS: DO NOT cut off the mains

plug from this equipment. If the plug ﬁtted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer. If, nonetheless, the mains plug is cut off, REMOVE THE FUSE and dispose of the PLUG immediately, to avoid possible shock hazard by inadvertent connection to the mains supply. If this product is not provided with a mains plug, or one has to be ﬁtted, then follow the instructions given below:

IMPORTANT: DO NOT make any connection to the larger terminal which is marked with the letter “E” or by the safety earth symbol or colored GREEN or GREEN AND YELLOW.

The wires in the mains lead on this product are colored in accordance with the following code:

BLUE – NEUTRAL BROWN – LIVE

As these colors may not correspond with the colored markings identifying the terminals in your plug, proceed as follows:

The BLUE wire must be connected to the terminal marked with the letter “N” or colored BLACK. The BROWN wire must be connected to the terminal marked with the letter “L” or colored RED.

When replacing the fuse, only a correctly rated and approved type should be used, and be sure to re-ﬁt the fuse cover. If in doubt consult a competent electrician.

Above 0.2 m

(8 in) or more

Behind 0.2 m (8 in) or more

Right 0.2 m

(8 in) or more

NOTES ON ENVIRONMENTAL PROTECTION

At the end of its useful life, this product must not be disposed of with regular household waste but must be returned to a collection point for the recycling of electrical and electronic equipment. The symbol on the product, user’s manual and packaging, point this out. The materials can be reused in accordance with their markings. Through re-use, recycling of raw materials or other forms of recycling of old products, you are making an important contribution to the protection of our environment. Your local administrative ofﬁce can advise you of the responsible waste disposal point.

INFORMATION ABOUT COLLECTION AND DISPOSAL OF WASTE BATTERIES (DIRECTIVE 2006/66/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL OF EUROPEAN UNION) (for European customers only)

Batteries bearing any of these symbols indicate that they should be treated as “separate collection” and not as municipal waste. It is encouraged that necessary measures are implemented to maximize the separate collection of waste batteries and to minimize the disposal of batteries as mixed municipal waste. End-users are exhorted not to dispose waste batteries as unsorted municipal waste. In order to achieve a high level of recycling waste batteries, discard waste batteries separately and properly through an accessible collection point in your vicinity. For more information about collection and recycling of waste batteries, please contact your local municipality, your waste disposal service or the point of sale where you purchased the items.

By ensuring compliance and conformance to proper disposal of waste batteries, potential hazardous effects on human health is prevented and the negative impact of batteries and waste batteries on the environment is minimized, thus contributing to the protection, preservation and quality improvement of the environment.

CdHgPb

Anthem and any related party assume no liability for the user’s failure to comply with any requirements.

Anthem, AnthemLogic, ARC, Sonic Frontiers, and Paradigm are trademarks or registered trademarks of Paradigm Electronics Inc. © Paradigm Electronics Inc. All rights reserved. The information contained herein may not be reproduced in whole or in part without our express written permission. We reserve the right to change speciﬁcations or features without notice as design improvements are incorporated.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, Play-Fi, the Symbol, DTS in combination with the Symbol, Play-Fi in combination with the Symbol, DTS:X, and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved

HDMI, the HDMI logo and High-Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

All other trademarks are the property of their respective owners.

LICENSE INFORMATION FOR THE SOFTWARE USED IN THE UNIT

This product contains one or more free or open source software programs originating from third parties. This free and open source software is subject to the terms of the GNU General Public License, GNU Library/Lesser General Public License, or other different and/ or additional copyright licenses, notices, and disclaimers. To understand your rights under these licenses, please refer to the speciﬁc terms of the licenses, notices, and disclaimers, which are provided in the links below.

To receive a copy of the source code for the open source software programs included in this product, please make your request to our customer service center.

Paradigm Electronics will distribute such source code to you on a disc for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling. All of the above referenced licenses, notices, and disclaimers are reproduced and available with such source code. However, note that we make no guarantees concerning the source code. Please also understand that we do not offer support for the contents of the source code. This offer is valid for a period of three (3) years following the date of distribution of this product by Paradigm Electronics.

This section describes software license used for this unit. To maintain the correct content, the original (English) is used.

The Spotify software is subject to third party licenses found here: www.spotify.com/connect/third-party-licenses

GPL (GNU-General Public License)

Linux Kernel 2.6.29 https://kernel.org/ libao http://www.xiph.org/ao/ bridge-utils http://www.linuxfoundation.org/collaborate/workgroups/networking/bridge busybox http://www.busybox.net/ Ebtables http://ebtables.netﬁlter.org/ Wget http://www.gnu.org/software/wget/

LGPL (GNU LESSER GENERAL PUBLIC LICENSE) LICENSE

LIVE555 http://www.live555.com/ mpg123 http://mpg123.de/ ffmpeg http://www.ffmpeg.org/ avahi http://www.avahi.org/

BSD LICENSE

Libupnp http://pupnp.sourceforge.net/ Opus codec http://www.opus-codec.org/

MIT/X DERIVATE LICENSE

CURL http://curl.haxx.se/

ACADEMIC FREE LICENSE (AFL)

dbus http://www.freedesktop.org/wiki/

OPENSSL LICENSE

OpenSSL https://www.openssl.org/

MIT LICENSE

LibXML2 http://www.xmlsoft.org/

OTHERS: https://github.com/abrasive/shairport/blob/master/LICENSES

Abrasive https://github.com/abrasive/shairport

TABLE OF CONTENTS

INTRODUCTION

1 1.1 Before Making Connections

1 1.2 In-Use Notices

2 1.3 Front Panel

3 1.4 MRX 720 Rear Panel

4 1.5 MRX 1120 Rear Panel

5 1.6 AVM 60 Rear Panel

6 1.7 Remote Control

7 1.8 Speaker Positioning

CONNECTIONS

10 2.1 Video Input and Output

11 2.2 Audio Connections

14 2.3 Antenna

14 2.4 Local Area Network

14 2.5 12 Volt Trigger

14 2.6 Infra Red

14 2.7 Power

SETUP

17 3.1 Speaker Setup

19 3.2 Bass Managment

20 3.3 Listener Position

21 3.4 Level Calibration

23 3.5 Input Setup

26 3.6 Preferences / Line Output

28 3.7 Network / Remote Control

31 3.8 General Conﬁguration

33 3.9 Save / Load Settings

34 3.10 System Information

ANTHEM ROOM CORRECTION

36 4.1 Before Starting

36 4.2 ARC Software Installation

37 4.3 Microphone Stand Assembly

37 4.4 Microphone Positioning

37 4.5 Measurement

39 4.6 Manual Mode and Targets

40 4.7 Advanced Subwoofer Targets

41 4.8 Printing A Report

OPERATION

42 5.1 Power On / Off and Volume

42 5.2 Zone 2 Operation

43 5.3 Input Selection

43 5.4 Tuner

44 5.5 DTS Play-Fi

44 5.6 Level Trim

45 5.7 Bass / Treble / Balance

45 5.8 Lip-Sync

45 5.9 Listening Modes

46 5.10 Dolby Volume and Dynamic Range Control

46 5.11 Display Brightness

46 5.12 Info Display

47 Limited Warranty

INTRODUCTION

1.1 BEFORE MAKING CONNECTIONS

Check that you have received all items listed below and report discrepancies to your dealer as soon as possible. In case the unit needs to be transported in the future, keep the packing materials. Retain the invoice that you received from your authorized Anthem dealer at time of purchase – without it, service will not be provided under warranty.

• AVM Processor or MRX Receiver

• Remote control

• FM antenna

• Wireless network antennas (2)

• 2 AAA batteries

• IEC power cord (US / UK / EU / CN types are supplied by factory, other types are normally provided by the local distributor)

Additional items in Anthem Room Correction kit (ARC):

• USB Microphone

• Microphone clip

• Telescopic stand with boom

• USB cable

• CAT5 cable

1.2 IN-USE NOTICES

• Disconnect the power cord before connecting or disconnecting any components.

• If the AVM/MRX was transported or stored in the cold, let it reach room temperature before use.

• Due to continuing advances, operational characteristics may change. If this manual contains discrepancies please check www.anthemAV.com for the latest manual or software.

1.3 FRONT PANEL

(MRX 1120 model shown.)

1 2

1 – Navigation buttons

2 – Display

3 – Volume, level functions, and character selection

4 – Power / standby

5 – Input selection

6 – Zone 2 selection

7 – Level selection

8 – Remote control sensor location

9 – Mode selection

10 – Display brightness

11 – Setup menu selection

12 – (Behind Cover) Headphone jack, HDMI/MHL jack, USB jack for software updates

11 5

910

4678

1.4 MRX 720 REAR PANEL

MRX 720US

2015.10.26

US model shown. EU model is similar.

PRINTING : WHITE FILM NO.:150909-3

3 4

5 6 7

1 – FM antenna connection

2 – Wireless antenna connectors

3 – HDMI inputs - HDMI7 supports MHL

4 – HDMI outputs - HDMI1 supports Audio Return Channel

5 – Local area network connection for IP control and Anthem Room Correction

6 – USB jack for factory service

7 – Wireless setup button

8 – AC input

9 – RS-232 interface (bidirectional) for serial control

10 – IR input and trigger output

11 – Coaxial digital audio inputs

12 – Optical digital audio inputs and output

13 – Speaker connections

14 – Zone 2 audio output

15 – Line audio output

16 – Analog audio inputs

17 – Main pre-out connections

18 – Chassis ground screw

1617

1415

1.5 MRX 1120 REAR PANEL

MRX 1120US

2015.10.26

US model shown. EU model is similar.

PRINTING : WHITE FILM NO.:150907-3

3 4

5 6 7

1 – FM antenna connection

2 – Wireless antenna connectors

3 – HDMI inputs - HDMI7 supports MHL

4 – HDMI outputs - HDMI1 supports Audio Return Channel

5 – Local area network connection for IP control and Anthem Room Correction

6 – USB jack for factory service

7 – Wireless setup button

8 – AC input

9 – RS-232 interface (bidirectional) for serial control

10 – IR input and trigger output

11 – Coaxial digital audio inputs

12 – Optical digital audio inputs and output

13 – Speaker connections

14 – Zone 2 audio output

15 – Line audio output

16 – Analog audio inputs

17 – Main pre-out connections

18 – Chassis ground screw

1617

1415

1.6 AVM 60 REAR PANEL

AVM 60US

2015.10.26

US model shown. EU model is similar.

PRINTING : WHITE FILM NO.:150913-3

3 4

5 6 7

1 – FM antenna connection

2 – Wireless antenna connectors

3 – HDMI inputs - HDMI7 supports MHL

4 – HDMI outputs - HDMI1 supports Audio Return Channel

5 – Local area network connection for IP control and Anthem Room Correction

6 – USB jack for factory service

7 – Wireless setup button

8 – AC input

9 – RS-232 interface (bidirectional) for serial control

10 – IR input and trigger output

11 – Coaxial digital audio inputs

12 – Optical digital audio inputs and output

13 – Balanced outputs

14 – Zone 2 audio output

15 – Line audio output

16 – Analog audio inputs

17 – Main pre-out connections

18 – Chassis ground screw

1617

1415

1.7 REMOTE CONTROL

1 – Main zone power on and standby

2 – Bass, Treble, Balance, Channel Level, Front panel dimmer

3 – Numeric keypad for tuner presets

4 – Input list

5 – Tuner preset

6 – Setup menu

7 – Info and status

8 – Navigation controls

9 – Clear for deleting input conﬁgurations and tuner presets, and clearing new entry

10 – Dolby Volume and Dolby Digital Dynamics

11 – Listening mode

12 – Volume

13 – Last menu entry and Home Button for MHL Sources

14 – Mute

15 – Next/previous tuner preset, setup menu page up/down

16 – Lip-sync

17 – Backlight

18 – Zone 2 controls

The left/right buttons also select previous/next input.

The up/down buttons also control tuner station.

BASS

TREB

BALDIM

LEVEL

SETUP

SELECT

INPUTPRESET

CLEAR

VOL

DYN

LIP-SYNC

MODE

LAST

PG/PR

VOL

ZONE 2

RC-MRX 2

INPUT

1.8 SPEAKER POSITIONING

These illustrations show possible speaker placements.

5.1.2 Conﬁguration

with one pair in-ceiling height speakers

5.1.2 Conﬁguration

with Dolby enabled front speakers

5.1.4 Conﬁguration

with two pair in-ceiling height speakers

5.1.4 Conﬁguration

with Dolby enabled front and rear speakers

7.1.2 Conﬁguration

with one pair in-ceiling height speakers

7.1.2 Conﬁguration

with Dolby enabled front speakers

7.1.4 Conﬁguration

with two pair in-ceiling height speakers

7.1.4 Conﬁguration

with Dolby enabled front and rear speakers

One pair in-ceiling height speakers (side view)

Two pair in-ceiling height speakers (side view)

CONNECTIONS

This section describes connections between system components. Conﬁguration of input and output will be discussed later, in section 3.

2.1 VIDEO INPUT AND OUTPUT

With HDMI connection, video and audio are carried together. Connect HDMI output from MRX to a display with HDMI input – one with the appropriate version of Highbandwidth Digital Content Protection (HDCP) is required to display copy-protected material.

HDMI input 7 is also an MHL input (Mobile High-deﬁnition Link). Use this input if the source component also supports MHL, for example smaller media players that receive power through this interface.

Insert HDMI cables gently because the connector is more delicate than traditional ones. Damaged cables can damage jacks, and replacement jacks are not covered by warranty therefore replacing HDMI cables is recommended if there is any chance that the existing ones have been used improperly.

Use only certiﬁed High Speed cables and connecting devices. Cables and connecting devices that worked in an older setup do not necessarily work with newer video formats such as Deep Color, UHD, or high frame rates. If you are using adapters or port savers, start troubleshooting by eliminating them since they can affect bandwidth.

2.2 AUDIO CONNECTIONS

AUDIO INPUTS AND OUTPUTS

Digital audio sources can be connected using an HDMI, coaxial or optical cable. These connections carry linear PCM, Dolby Digital, and DTS audio formats. HDMI connection is generally preferred to ensure that lossless audio is used where sources provide it although optical/coax can also be used for sources outputting 2-channel PCM, Dolby Digital 5.1, and DTS 5.1 without affecting audio quality.

Audio on the HDMI outputs is 2-channel PCM as this is meant for the TV’s use.

HDMI AUDIO RETURN CHANNEL

If the TV provides audio through HDMI ARC, for example when it accesses streaming media sources, it can send the audio to the MRX through HDMI output 1, eliminating the need for a separate audio connection. CEC control, described in a later section, must be enabled for Audio Return Channel to function.

If the display reads “Dial Norm Offset -4.0 dB” at the start of a movie, it is indicating that the encoded level is higher than standard by 4.0 dB – the playback level of all channels is then automatically reduced by 4 dB.

PREAMP OUTPUTS

The pre-outs are variable according to the volume control and can be used with external ampliﬁcation.

MRX 720 / 1120

AVM 60

The RCA and XLR outputs have a signal at the same time. XLR connection is suitable for longer cables.

LINE OUTPUT AND ZONE 2 OUTPUT

Line output is a 2-channel version of the selected input with ﬁxed output level. This can be used with a headphone amp which has its own volume control.

Zone 2 has its own volume control and can be used two ways:

- For independent source selection, connect the source using analog input, or optical/

coaxial input as long as the source is 2-channel PCM. This connection can be used in conjunction with HDMI connection for the main zone.

- For similar operation as Line Output but with volume control, set Follow Main to Always

in the setup menu (setup is explained later).

OPTICAL AND COAXIAL DIGITAL AUDIO

If HDMI audio from a Dolby Digital, DTS, or 2-channel PCM source is problematic or takes too long to switch, use of coax/optical audio connection is recommended (HDMI video can still be used). Older cable and satellite AVM/MRXs often beneﬁt from this.

The optical output provides a passthrough of coax/optical input.

+ 46 hidden pages
