Technical Service Manual

Alaris® SpO2 Modules

8210 Series (Nellcor

8220 Series (Masimo

ONI

%SpO

PULSE (BPM)

Technology)

Supports: Guardrails® Suite (v7)

Guardrails

Suite MX (v8)

December 2010

CHANNEL

SELECT

MONITOR

CHANNEL

OFF

Alaris® Products

CareFusion San Diego, California http://www.carefusion.com/alaris

Customer Advocacy - North America

E-Mail: CustomerFeedback@carefusion.com

Maintenance and service information support; troubleshooting.

General Contact Information

Clinical and technical feedback.

Phone: 888.876.4287

Technical Support - North America

United States:

Phone:

888.876.4287

Instrument return, service assistance, and order placement.

United States:

Phone: 888.876.4287

Canada:

Phone:

800.387.8309

Customer Care - North America

Canada:

Phone: 800.387.8309

Alaris® SpO2 Modules

Technical Service Manual

TABLE OF CONTENTS

Chapter 1 - General Information

1.1 Introduction ....................................................................................................................................................................................... 1-1

1.2 Features .............................................................................................................................................................................................. 1-1

1.3 Alarms, Errors, Messages ....................................................................................................................................................... 1-2

Chapter 2 - Checkout and Configuration

2.1 Introduction ....................................................................................................................................................................................... 2-1

2.2 New Instrument Checkout ....................................................................................................................................................... 2-1

2.3 Configuration Options and Setup - General

2.3.1 Configuration Notes .................................................................................................................................................................... 2-1

2.3.2 Factory Default Setting .............................................................................................................................................................. 2-2

2.3.3 Configuration Setup Notes

...................................................................................................................................................... 2-2

2.4 Configuration Setup .................................................................................................................................................................... 2-2

2.4.1 Access System Configuration Options ............................................................................................................................ 2-2

2.4.2 Alarm Limits ...................................................................................................................................................................................... 2-3

2.4.3 Limit Mode ......................................................................................................................................................................................... 2-4

2.4.4 Pulse Beep Volume

..................................................................................................................................................................... 2-4

2.4.5 SatSeconds Limits (8210 Series) ....................................................................................................................................... 2-5

2.4.6 Saturation Averaging Time (8220 Series) ..................................................................................................................... 2-5

................................................................................................................ 2-1

Chapter 3 - Preventive Maintenance

3.1 Introduction ....................................................................................................................................................................................... 3-1

3.2 Cleaning .............................................................................................................................................................................................. 3-1

Chapter 4 - Principles of Operation

4.1 Introduction ....................................................................................................................................................................................... 4-1

4.2 General Information .................................................................................................................................................................... 4-1

4.3 8210 Series (Nellcor

Technology) .................................................................................................................................... 4-1

4.4 8220 Series (Masimo® Technology) .................................................................................................................................. 4-2

Chapter 5 - Corrective Maintenance

5.1 Introduction ....................................................................................................................................................................................... 5-1

5.2 Disassembly / Reassembly .................................................................................................................................................... 5-2

5.2.1 Removing Latch Assembly and Feet ................................................................................................................................ 5-3

5.2.2 Removing IUI Connector Assemblies and Rear Case .......................................................................................... 5-4

5.2.3 Removing Frame Assembly

5.2.4 Removing Patient Connector Board Assembly .......................................................................................................... 5-6

5.2.5 Removing Logic Board Assembly

5.2.6 Removing Speaker ...................................................................................................................................................................... 5-8

5.2.7 Removing Nellcor® SpO2 Board and Power Supply Board Assemblies..................................................... 5-9

................................................................................................................................................... 5-5

...................................................................................................................................... 5-7

Alaris® SpO2 Modules

Technical Service Manual

TABLE OF CONTENTS

Chapter 5 - Corrective Maintenance (Continued)

5.2.8 Removing Masimo® SpO2 Board and Power Supply Board Assemblies................................................... 5-10

5.2.9 Removing IUI Bracket Strap and Bracket ..................................................................................................................... 5-11

5.2.10 Removing Display Board Assembly .............................................................................................................................. .... 5-12

5.2.11 Removing Status Indicator Lens ......................................................................................................................................... 5-13

Chapter 6 - Troubleshooting

6.1 Introduction ....................................................................................................................................................................................... 6-1

6.2 Subsystem Codes and Error Code Matrix .................................................................................................................... 6-1

Chapter 7 - Illustrated Part Breakdown

7.1 Introduction ....................................................................................................................................................................................... 7-1

7.2 Illustrations ........................................................................................................................................................................................ 7-1

7.3 Parts List

............................................................................................................................................................................................. 7-1

7.4 Ordering Parts ................................................................................................................................................................................ 7-2

List of Figures

7-1 Front Case Assembly ................................................................................................................................................................. 7-5

7-2 IUI Bracket - Frame .............................................................................................................................. ....................................... 7-6

7-3 Masimo® SpO2 Board - Power Supply Board Assembly ...................................................................................... 7-7

7-4 Nellcor® SpO2 Board - Power Supply Board Assembly ........................................................................................ 7-8

7-5 Frame Assembly - Logic Board View

7-6 Frame - Front Case Assembly .............................................................................................................................................. 7-10

7-7 IUI Assembly .................................................................................................................................................................................... 7-11

7-8 Rear Case Assembly

.................................................................................................................................................................. 7-12

7-9 Rear Label Locations .............................................................................................................................. ................................... 7-13

7-10 Display Board Assembly .............................................................................................................................. ............................ 7-14

7-11 Logic Board Assembly

............................................................................................................................................................... 7-15

7-12 Power Supply Board Assembly (8210 Series) 7-13 Power Supply Board Assembly (8220 Series)

............................................................................................................................... 7-9

........................................................................................................... 7-16

........................................................................................................... 7-17

List of Tables

1-1 Defined Terms ................................................................................................................................................................................. 1-2

5-1 Required Materials, Supplies and Tools ......................................................................................................................... 5-2

5-2 Torque Values

5-3 Level of Testing Guidelines ..................................................................................................................................................... 5-15

6-1 Technical Troubleshooting Guide ....................................................................................................................................... 6-2

6-2 Error Codes ...................................................................................................................................................................................... 6-3

7-1 Parts List............................................................................................................................................................................................. 7-3

Alaris® SpO2 Modules

Technical Service Manual

................................................................................................................................................................................. 5-14

Chapter 1 – GENERAL INFORMATION

CAUTION

To avoid damaging the keypad, do not use sharp objects (such as, pens, pencils) to activate switches.

1.1 INTRODUCTION

This manual describes how to service the

SpO

Modules (8210 and 8220 Series). It is

used in conjunction with the following Alaris System documents and software:

• PC Unit / Pump Module (

8000/8100

Series) Technical Service Manual

• Alaris

System Directions for Use (DFU)

• Maintenance Software and User Manual

8.1 or later)

This manual is intended for personnel experienced in analysis, troubleshooting and repair of analog/digital microprocessorbased electronic equipment.

Reference the Alaris

System DFU for a product introduction, detailed setup and operation procedures, deﬁ nitions (including precaution deﬁ nitions), speciﬁ cations, and other information related to the use of the

Alaris

System.

CAUTION

Any attempt to service this product by anyone other than an authorized CareFusion Service Representative, while the product is under warranty, may invalidate the warranty.

If the

SpO

Module requires service while

under warranty, it must be serviced only by CareFusion authorized service personnel. Reference the "Warranty" and "Service Information" sections in the Alaris

DFU.

1.2 FEATURES

• Functional blood oxygen saturation

percentage, pulse rate, pulse bar, channel identification and scrolling messages display (such as, alerts and alarms).

• Alarm limit settings, trend data and

plethysmographic waveforms display.

• 8210 Series: SatSeconds alarm

Management Technology, to allow monitoring of

%SpO

below selected low

alarm limit for a period of time before an audible alarm sounds.

System

Alaris® SpO2 Modules

Technical Service Manual

1-1

GENERAL INFORMATION

1.2 FEATURES (Continued)

• 8220 Series: Signal Extraction Technology

(SET®) for accurate readings under extreme conditions (such as, low perfusion and motion).

Reference the Alaris

System DFU for a list

of features and definitions.

Table 1-1. Defined Terms

The following table identifies the defined terms used throughout this document for certain trademarked products and product features.

Product / Feature Defined Term

Alaris® PC point-of-care unit PC Unit Alaris® PC unit PC Unit

Alaris

Pump module Pump Module Alaris® SpO2 module SpO2 Module Guardrails® data set Data Set

1.3 ALARMS AND MESSAGES

Alarm messages are displayed on the scrolling Message Display bar. Reference

the Alaris

System DFU for detailed

information. An audio alarm and the Alarm Status

Indicator flash red when an alarm limit is met or exceeded. All alarms can be temporarily silenced by pressing the

SILENCE key on

the PC Unit.

1-2

Alaris® SpO2 Modules

Technical Service Manual

Chapter 2 – CHECKOUT AND CONFIGURATION

CAUTION

Should an instrument be dropped or severely jarred, remove it from use immediately. It should

be thoroughly tested and inspected by qualified service personnel to ensure proper function prior to reuse.

2.1 INTRODUCTION

SpO

This chapter describes initial

Module

setup and configuration. Due to product changes over time, configurations described in this chapter may differ from the instrument being serviced.

2.2 NEW INSTRUMENT CHECKOUT

Prior to placing a new instrument in use, perform a check-in procedure using the Maintenance Software.

When powering up the instrument, verify the instrument beeps and all display segments flash. This confirms that the instrument has performed its self test and is operating correctly. During operation, the instrument continually performs a self test, and alarms and displays a message if it detects an internal malfunction.

Contact CareFusion authorized service personnel if the instrument has physical damage, fails to satisfactorily pass the startup sequence, fails a self test, or continues to alarm.

LED

2.3 CONFIGURATION OPTIONS AND SETUP - GENERAL

Reference the Alaris

System DFU for the

following information:

• System Settings

SpO

•

Module Settings

2.3.1 Configuration Notes

• Changes to factory default values are retained after a power cycle.

• If Factory Default is Yes, then all configuration settings are set to their factory default.

Alaris® SpO2 Modules

Technical Service Manual

2-1

CHECKOUT AND CONFIGURATION

2.3 CONFIGURATION OPTIONS AND

SETUP - GENERAL (Continued)

2.3.1 Configuration Notes (Continued)

• If Factory Default is No, then one or more of the configuration settings has been changed. If desired, Factory Default can be selected and set to Yes, which will set all configuration settings to their factory default.

2.3.2 Factory Default Setting

To allow changes to be made to System Configuration parameters:

1. Hold

OPTIONS key at power up.

System Configuration - Module

Factory default:

Shared Infusion Settings

PC Unit

Pump Module

SPO2 Module

Yes

2.3.3 Configuration Setup Notes

• Pressing

EXIT soft key while in a

System Configuration - Module screen

immediately powers system down, with no "Powering Down" display.

• Pressing

Config -

EXIT soft key while in a System

SPO2 screen returns display to

main System Configuration - Module screen.

• Pressing

CONFIRM soft key while in a

System Configuration option screen:

- accepts existing setting or setting change

- displays next option setting screen (if applicable) or returns display to System Config - SPO2 screen

• Pressing PC Unit’s CANCEL key while in a System Configuration option screen:

- leaves setting unchanged

- returns display to System Config - SPO2

screen

>Select an Option

or EXIT

EXIT

PAGE

DOWN

2. Press Factory default soft key.

3. Press No soft key.

System Configuration

Factory Default Settings?

Selection of Yes sets all System Configuration parameters to the factory default setting.

EXIT

4. To accept change, press

Yes

EXIT soft key.

2.4 CONFIGURATION SETUP

To change an option setting, ensure the

Factory default setting is No.

2.4.1 Access System Configuration Options

1. Hold

OPTIONS key at power up.

System Configuration - Module

Factory default:

Shared Infusion Settings

PC Unit

Pump Module

SPO2 Module

>Select an Option

or EXIT

EXIT

PAGE

DOWN

2-2

Alaris® SpO2 Modules

Technical Service Manual

CHECKOUT AND CONFIGURATION

2.4 CONFIGURATION SETUP (Continued)

2.4.1 Access System Configuration Options

(Continued)

2. Press SPO2 Module soft key. To view additional options, press

PAGE DOWN

soft key.

System Config - SPO2 1 of 2

Adult alarm limits

Limits Mode:

Neonatal alarm limits

Pulse beep volume:

SatSeconds limits:

>Select an Option or EXIT

EXIT

System Config - SPO2 2 of 2

Sat Averaging time: 8

Adult

Off

PAGE

DOWN

System Configuration - SPO2

Adult alarm limits

%SPO2

HIGH

%SPO2

LOW

PULSE

HIGH

PULSE

LOW

>Select Parameter Limit

Off

150

CONFIRM

2. To change an alarm limit, press soft key next to parameter to be changed.

System Configuration - SPO2

Adult alarm limits

%SPO2

HIGH

%SPO2

LOW

PULSE

HIGH

PULSE

LOW

>Enter High %SPO2 Limit

Off

150

CONFIRM

>Select an Option or EXIT

PAG E

EXIT

2.4.2 Alarm Limits

The following displays represent the Adult alarm limits but the same procedure is used for configuring the Neonatal alarm limits.

1. After accessing System Config - options display, press Adult alarm limits or Neonatal alarm limits soft key.

SPO2

3. Enter a numeric value for selected alarm limit. Adult

%SPO2 HIGH limit

can be Off or a numeric value. Numeric values can be entered using keypad

and keys. Prompt changes

or to >Press

ENTER to CONFIRM after

a valid value has been highlighted for

3 seconds.

System Configuration - SPO2

Adult alarm limits

%SPO2

HIGH

%SPO2

LOW

PULSE

HIGH

PULSE

LOW

>Press CONFIRM to Apply Changes

_98

150

Off

CONFIRM

Alaris® SpO2 Modules

Technical Service Manual

2-3

CHECKOUT AND CONFIGURATION

2.4 CONFIGURATION SETUP (Continued)

2.4.2 Alarm Limits (Continued)

4. To accept change, press ENTER key.

• Display highlights next limit and prompts for an entry.

5. To change another alarm limit, press soft key for that parameter and make necessary change.

System Configuration - SPO2

Adult alarm limits

%SPO2

HIGH

%SPO2

LOW

PULSE

HIGH

PULSE

LOW

>Enter High Pulse Limit

6. To accept change(s), press

98 90

150

CONFIRM

soft key.

2. Select Adult or Neonatal by pressing applicable soft key.

• Following display represents

Neonatal alarm limits but same procedure is used for conﬁ guring

Adult alarm limits.

System Configuration - SPO2

Neonatal alarm limits

%SPO2

HIGH

%SPO2

LOW

PULSE

HIGH

PULSE

LOW

>Select Parameter Limit

88 70

120

CONFIRM

3. To change an alarm limit, see "Alarm Limits" section.

To accept settings, press CONFIRM soft key.

2.4.3 Limit Mode

1. After accessing System Config - options display, press Limits Mode soft key.

• Limit Mode cannot be changed

if a Proﬁ le is being used for programming.

System Configuration - SPO2

Limit Mode Setup

Adult

Allows selection between the adult and neonatal modes of operation.

Neonatal

SPO2

2.4.4 Pulse Beep Volume

1. After accessing System Config - options display, press Pulse beep volume soft key

• Following display reﬂ ects that Pulse

Beep Volume is Off. To display volume options, press Louder soft key.

System Configuration - SPO2

Pulse Beep Volume

Softer

>Press CONFIRM

Off

Louder

CONFIRM

SPO2

2-4

Alaris® SpO2 Modules

Technical Service Manual

CHECKOUT AND CONFIGURATION

2.4 CONFIGURATION SETUP (Continued)

2.4.4 Pulse Beep Volume (Continued)

2. To increase volume, press Louder soft key until desired volume level is attained. To turn off pulse beep entirely, press Off soft key.

• Selectable volume levels are

3. Audio sounds for 1 cycle.

and

System Configuration - SPO2

Pulse Beep Volume

Softer

> Press CONFIRM

Off

Louder

CONFIRM

1, 2

3. To accept setting, press CONFIRM soft key.

2.4.5 SatSeconds Limits (

1. After accessing System Config -

8210 Series)

SPO2

options display, press SatSeconds limits soft key.

• Selectable options are Off, or

50 and 100 seconds.

3. To accept settings, press

CONFIRM soft

key.

2.4.6 Saturation Averaging Time (

8220 Series)

1. After accessing System Config - options display, page

2, press Sat.

Averaging time soft key.

System Configuration - SPO2

Masimo Saturation Averaging Time

8 Seconds

Determines the averaging time for the displayed data.

>Press CONFIRM

Increase

Decrease

CONFIRM

2. To change Saturation Averaging Time, press either Increase or Decrease soft key.

• Selectable options are

12, 14 and 16 seconds. Fast sat

is enabled when

2, 4, 8, 10,

2 or 4 seconds is

selected.

10, 25,

SPO2

System Configuration - SPO2

Nellcor SatSeconds Limits

SPO2

Seconds

>Press Increase, Decrease

or Off

Increase

Decrease

Off

CONFIRM

2. To change SatSeconds Limits, press either Increase or Decrease soft key. To turn off SatSeconds Limits, press Off soft key.

3. To accept settings, press key.

Alaris® SpO2 Modules

Technical Service Manual

CONFIRM soft

2-5

CHECKOUT AND CONFIGURATION

THIS PAGE

INTENTIONALLY

LEFT BLANK

2-6

Alaris® SpO2 Modules

Technical Service Manual

Chapter 3 – PREVENTIVE MAINTENANCE

WARNING

Failure to perform regular and preventive

maintenance inspections may result in improper instrument operation.

3.1 INTRODUCTION

Perform regular and preventive maintenance inspections to ensure that the

SpO

remains in good operating condition:

• Perform regular inspections before each

use.

• Perform preventive maintenance

inspections once a year.

Use the Maintenance Software to perform calibration and preventive maintenance.

These requirements and guidelines are intended to complement the intent of the Joint Commission on Accreditation of Healthcare Organizations (

JCAHO)

requirements.

3.2 CLEANING

Reference the Alaris

System DFU.

Module

Alaris® SpO2 Modules

Technical Service Manual

3-1

PREVENTIVE MAINTENANCE

THIS PAGE

INTENTIONALLY

LEFT BLANK

3-2

Alaris® SpO2 Modules

Technical Service Manual

Chapter 4 – PRINCIPLES OF OPERATION

4.1 INTRODUCTION

This chapter describes the

SpO

Module

principles of operation. Reference the PC Unit / Pump Module

8000/8100 Series) Technical Service Manual

( for Alaris

System principles of operation.

4.2 GENERAL INFORMATION

SpO

Module operation is based

on the principles of pulse oximetry. Oxyhemoglobin and deoxyhemoglobin differ in their absorption of red and infrared light (spectrophotometry). The volume of arterial blood in tissue and the light absorbed by the blood changes during the pulse (plethysmography).

Because oxyhemoglobin and deoxyhemoglobin differ in light absorption, the amount of red and infrared light absorbed by blood is related to hemoglobin oxygen saturation.

4.3 8210 Series (Nellcor Technology)

SpO

A pulse oximeter determines

passing red and infrared light into an arteriolar bed and measuring changes in light absorption during the pulsatile cycle. Red and infrared low-voltage light-emitting diodes (

LED) in the oximetry sensor serve as

light sources; a photo diode serves as the photo detector.

To identify the oxygen saturation of arterial hemoglobin, the monitor uses the pulsatile nature of arterial flow. During systole, a new pulse of arterial blood enters the vascular bed, and blood volume and light absorption increase. During diastole, blood volume and light absorption reach their

SpO

lowest point. The

SpO

measurements on the difference

Module bases its

between maximum and minimum absorption (measurements at systole and diastole).

Alaris® SpO2 Modules

Technical Service Manual

4-1

PRINCIPLES OF OPERATION

4.3 8210 series (Nellcor Technology)

(Continued)

By doing so, it focuses on light absorption by pulsatile arterial blood, eliminating the effects of nonpulsatile absorbers (such as, venous blood, tissue and bone).

Because light absorption by hemoglobin is wavelength dependent and the mean wavelength of

LEDs varies, an oximeter

must know the mean wavelength of the sensor’s red

SpO

. During monitoring, the instrument’s

LED to accurately measure

software selects coefficients that are appropriate for the wavelength of that individual sensor’s red

LED. Those

coefficients are then used to determine

SpO

To compensate for differences in tissue thickness, the light intensity of the sensor’s

LEDs is adjusted automatically.

The

SpO

Module measures functional

saturation (oxygenated hemoglobin expressed as a percentage of the hemoglobin that can transport oxygen). It does not detect significant amounts of dysfunctional hemoglobin (such as, carboxyhemoglobin or methemoglobin). In contrast, hemoximeters (such as,

IL482)

report fractional saturation (oxygenated hemoglobin expressed as a percentage of all measured hemoglobin, including measured dysfunctional hemoglobin).

To compare functional saturation measurements to those from an instrument that measures fractional saturation, fractional measurements must be converted as follows:

functional saturation =

fractional saturation

100 - (%carboxyhemoglobin + %methemoglobin)

When saturation is calculated from a blood gas partial pressure of oxygen

x 100

), the calculated value may differ

(

SpO

from the

measurement of the SpO2

Module. This usually occurs because the calculated saturation was not appropriately corrected for the effects of variables that

shift the relationship between

and

pH, temperature, the partial pressure

PCO

of carbon dioxide (

), 2,3-DPG, and

fetal hemoglobin. To compare functional saturation measurements to those from an instrument that measures fractional saturation, fractional measurements must be converted as follows:

Oxyhemoglobin Dissociation Curve

 pH

100

Temperature

PCO

2,3-DPG



Fetal Hb

Saturation (%)

 pH ¯

Temperature

PCO

2,3-DPG

50 100

PO (mmHg)

4.4 8220 Series (Masimo Technology)

SpO

The Signal Extraction Technology

Module uses the Masimo®

(SET®) to decompose the red and infrared pulsatile absorbance signal into an arterial signal plus a noise component. Its value is used to find

SpO

the equation in the Masimo

saturation in an empirically derived

SET® software. The values in an internal look-up table are based on human blood studies against a laboratory co-oximeter on healthy adult volunteers in induced hypoxia states during motion and nonmotion conditions.

4-2

Alaris® SpO2 Modules

Technical Service Manual

Chapter 5 – CORRECTIVE MAINTENANCE

WARNING

Disconnect the SpO2 Module from the Alaris® System prior to performing maintenance. The instrument case should only be opened by qualified personnel using proper grounding techniques.

CAUTION

CMOS devices are sensitive to static electrical

charges and may be damaged during repair if the repair activity is not performed in an electrostatic discharge ( approved

ESD) protected environment using

ESD protective procedures, including

personnel grounding.

5.1 INTRODUCTION

This chapter describes how to disassemble

SpO

and reassemble the The circuit boards used in the

Module.

SpO

are fitted with surface mount devices and are not field repairable. Return circuit boards to an authorized CareFusion Service Center for repair. Attempting circuit board repairs voids all warranties.

For replacement part information, see the "Illustrated Parts Breakdown" chapter. Following any level of maintenance, perform the applicable tests (see "Level of Testing Guidelines" table).

Due to product changes over time, components/assemblies illustrated in this chapter may differ from the instrument being serviced.

Module

Alaris® SpO2 Modules

Technical Service Manual

5-1

CORRECTIVE MAINTENANCE

5.2 DISASSEMBLY / REASSEMBLY

To disassemble the instrument, follow the steps in order from the first step. To reassemble, perform the steps in their reverse order.

CAUTION

To avoid the risk of an electrical hazard or damage to the instrument circuitry, do not

spray fluids directly onto the instrument or allow fluids to enter the instrument.

Before adhering gaskets and labels to the instrument, clean the surface with a cotton swab or soft cloth lightly dampened with

70%

Isopropyl Alcohol.

Table 5-1. Required Materials, Supplies and Tools

NOTE: Contact/source information is subject to change.

• Silicone Grease, Dow Corning Molykote 33, or equivalent (http://www.dowcorning.com)

#1 Phillips Screwdriver

•

#2 Phillips Screwdriver

•

• Needle-Nose Pliers

• Small Diagonal Cutters

• Lint-free cloth (such as, Kimwipes or lint-free tissue)

5-2

Alaris® SpO2 Modules

Technical Service Manual

5.2 DISASSEMBLY / REASSEMBLY (Continued)

CORRECTIVE MAINTENANCE

5.2.1 Removing Latch Assembly and Feet

1. Remove screws (

2) attaching Latch

Assembly to bottom of Rear Case.

2. Remove Latch Assembly components. Pay close attention to Compression Spring location, to ensure proper installation during reassembly.

3. Pull Feet (

2) from underside of module.

Latch Screws

Compression Spring

During Reassembly:

Apply thin layer of Dow Corning Molykote 33 (or equivalent) silicone grease to Feet.

NOTE: The feet press-ﬁ t into the module.

This screw is for locking SpO Module to PC Unit, for fixed configur ations.

Foot (2 PL)

Rear Case

Alaris® SpO2 Modules

Technical Service Manual

5-3

CORRECTIVE MAINTENANCE

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.2 Removing IUI Connector Assemblies and Rear Case

1. Remove screws (

2) attaching each IUI

(left and right) to module.

2. Remove screws (

2) and associated

washers attaching Rear Case to module.

3. Separate Rear Case from Front Case by pulling Rear Case away from module.

During Reassembly:

• Ensure ground clips are still installed on

IUI connectors.

both

Left IUI Screws (2 PL)

Left IUI Connector

IUI Connector Seal

Rear Case Screw and Washer (2 PL)

• To install Right

IUI Connector Gasket,

remove protective backing and adhere to

IUI Connector.

• To install Left

IUI Connector Seal, position

seal on one end of connector and stretch to other end to conform to connector body. Gently press on seal to seat completely. Use lint-free swab to apply alcohol to top, sides, and bottom of seal for lubrication while installing to Rear Case. Do not apply alcohol to contacts or connector.

• Ensure Silicon Tubing in Rear Case is in place and not damaged. (See Figure

7–8)

Right IUI Connector Gasket

Right IUI Connector

5-4

Right IUI Screws (2 PL)

Ground clip at each mounting hole on both IUI Connectors.

Alaris® SpO2 Modules

Technical Service Manual

5.2 DISASSEMBLY / REASSEMBLY (Continued)

CORRECTIVE MAINTENANCE

5.2.3 Removing Frame Assembly

1. Remove screws (

6) attaching Frame

Assembly to Front Case Assembly.

2. Remove

IUI Bracket Strap screw.

3. Separate Frame Assembly from Front Case Assembly .

During Reassembly:

Align Frame and Front Case Assemblies as follows:

• Engage top flange of Frame with square

slot on Status Indicator Lens.

• Align and engage display connectors

2) with Power Supply Board and Logic

( Board connectors.

• Ensure Patient Board connector is centered within square cutout on Front Case.

• Position Keypad Ground Wire between

IUI Bracket Strap and screw.

Logic Board

IUI Bracket Strap Screw

IUI Bracket Strap

Frame Assembly

Front Case Assembly

Keypad Ground Wire (positioned between IUI Bracket Strap and screw)

Alaris® SpO2 Modules

Technical Service Manual

5-5

CORRECTIVE MAINTENANCE

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.4 Removing Patient Connector Board Assembly

1. Use needle nose pliers to remove Christmas Tree Clip securing Patient Connector Board to Frame Assembly.

2. Disconnect Patient Connector Board

J4 on Power Supply Board.

from

Christmas Tree Clip

Patient Connector Board

5-6

Alaris® SpO2 Modules

Technical Service Manual

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.5 Removing Logic Board Assembly

1. Use small diagonal cutters to lift and remove Snap Rivet from Logic Board.

CAUTION

Do not cut rivet.

2. Remove Logic Board.

CORRECTIVE MAINTENANCE

Logic Board

Snap Rivet

Alaris® SpO2 Modules

Technical Service Manual

5-7

CORRECTIVE MAINTENANCE

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.6 Removing Speaker

1. Disconnect Speaker Connector from J6 on Power Supply Board.

2. Use needle nose pliers to remove Christmas Tree Clips (

2) attaching

Speaker to Frame Assembly.

3. Remove Speaker.

Christmas Tree Clip

During Reassembly:

• Bundle excess speaker wires together with a cable tie.

• Use modified Christmas Tree Clip (tip removed) in speaker mounting hole located near Power Supply Board.

5-8

Speaker

Modified Christmas Tree Clip

Speaker Connector (J6)

Alaris® SpO2 Modules

Technical Service Manual

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.7 Removing Nellcor

SpO2 Board and

Power Supply Board Assemblies

1. Use small diagonal cutters to lift and remove Snap Rivets (

2) from Power

Supply Board.

CAUTION

Do not cut rivet.

CORRECTIVE MAINTENANCE

2. Remove Board from Frame Assembly.

3. Remove screws (

washers, from either board, to separate

3) and associated

board assemblies.

Power Supply Board Assembly

Snap Rivets (2 PL)

Nellcor® SpO2 Board

Nylon Standoffs (3 PL)

Power Supply Board

Alaris® SpO2 Modules

Technical Service Manual

5-9

CORRECTIVE MAINTENANCE

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.8 Removing Masimo

SpO2 Board and

Power Supply Board Assemblies

1. Use small diagonal cutters to lift and remove Snap Rivet (

1) from Power

Supply Board.

CAUTION

Do not cut rivet.

2. Remove Board from Frame Assembly.

3. Remove screws (

washers, from either board, to separate

3) and associated

board assemblies.

Power Supply Board Assembly

Snap Rivet

5-10

Masimo® SpO2 Board

Nylon Standoffs (3 PL)

Alaris® SpO2 Modules

Technical Service Manual

Power Supply Board

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.9 Removing IUI Bracket Strap and Bracket

1. Slide IUI Bracket Strap off IUI Bracket.

CORRECTIVE MAINTENANCE

2. Slide

IUI Bracket off Frame.

IUI Bracket

Frame

IUI Bracket Strap

Alaris® SpO2 Modules

Technical Service Manual

5-11

CORRECTIVE MAINTENANCE

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.10 Removing Display Board Assembly

1. Remove screws (3) attaching Display Board to Front Case.

2. Remove cable tie and disconnect Keypad Harness and Backlight Harness from Display Board.

3. Remove Display Board.

Display Board

During Reassembly:

Bundle Backlight Cable, Keypad Harness, and Ground Wire together with a cable tie.

Keypad Backlight Connector

(to Display Board J4 )

Keypad Ground Wire

Keypad Harness

(to Display Board J3)

5-12

Alaris® SpO2 Modules

Technical Service Manual

5.2 DISASSEMBLY / REASSEMBLY (Continued)

5.2.11 Removing Status Indicator Lens

1. Remove screws (2) attaching Status Indicator Lens to Front Case.

2. Remove Status Indicator Lens.

Status Indicator Gasket

CORRECTIVE MAINTENANCE

Status Indicator Lens

Alaris® SpO2 Modules

Technical Service Manual

5-13

CORRECTIVE MAINTENANCE

Table 5-2. Torque Values

Functional Application Item Description Torque Value

FINAL ASSEMBLY

Case Halves IUI Connectors

FRONT CASE

Display Board Assembly Frame Assembly Status Indicator Lens

INTERNAL SUPPORT FRAME

IUI Bracket Strap and Ground Wire SpO

Board Assembly

Power Supply Board Assembly

REAR CASE

Latch Assembly 4-40 x

6-32 x 7/16 6-32 x 7/16

4-40 x

4-40 x 3/4

4-40 x 5/16

4-40 x 6-32 x 7/16 6-32 x 7/16

12 in-lb 12 in-lb

/16

6 in-lb 6 in-lb 6 in-lb

/16

6 in-lb 6 in-lb 6 in-lb

/16 6 in-lb

5-14

Alaris® SpO2 Modules

Technical Service Manual

Table 5-3. Level of Testing Guidelines

Use the Maintenance Software to perform testing.

Tests to Perform

l = Required

Blank = Not Applicable

CORRECTIVE MAINTENANCE

Repair/Replacement of: 

Display Board Front Case / Keypad Logic Board SpO2 Board Patient Connector Board Power Supply Board Rear Case / IUI Connector Miscellaneous:  Instrument Dropped New Instrument Checkout No Fault Found

(instrument not opened)

No Fault Found

(instrument opened)

Alarm Test

Channel ID / IUI Connector Test

Display Test

Keypad Test

Patient Cable Alarm Test

Patient Lead Electrical Leakage

Power On Self Test

Pulse Rate / Saturation Test

Speaker Test

Visual / Instrument Inspection

llllllll

lllllllll

ll l

ll llll l

llllllllll

llll l

llllllllll

Alaris® SpO2 Modules

Technical Service Manual

5-15

CORRECTIVE MAINTENANCE

THIS PAGE

INTENTIONALLY

LEFT BLANK

5-16

Alaris® SpO2 Modules

Technical Service Manual

Chapter 6 – TROUBLESHOOTING

6.1 INTRODUCTION

The

SpO

Module alarms and displays an

error message and/or error code when an operating malfunction occurs. Use the information in this chapter to help diagnose and correct technical problems. Use the Maintenance Software to perform applicable preventive maintenance, calibration, and verification procedures.

6.2 SUBSYSTEM CODES AND ERROR CODE MATRIX

Reference the PC Unit / Pump Module

8000/8100 Series) Technical Service Manual

( for Alaris

System information.

Alaris® SpO2 Modules

Technical Service Manual

6-1

TROUBLESHOOTING

Table 6-1. Technical Troubleshooting Guide

Perform the steps in the order they are listed until the problem/fault is corrected. Before making a

SpO

final diagnosis, visually inspect the

Module for damage. Following repair, use the Maintenance

Software to perform the required tests.

Problem Remedy

Display Problem 1. Check cable connections.

2. Replace Display.

3. Replace Logic Board.

4. Return to factory.

Intermittent Operation 1. Check connections to Logic Board.

2. Replace Logic Board

3. Return to factory.

Instrument Malfunction 1. Turn instrument off and back on to see if problem clears.

2. Reference alarm history for fault detected, and Error Code Tables.

Key Stuck Alarm 1. Turn instrument off and back on to see if problem clears.

2. Replace keypad assembly.

3. Replace Logic Board.

4. Return to factory.

Will Not Turn On 1. Check fuses.

2. Replace Off-Line Switcher.

3. Replace Power Supply Board.

4. Check IUI Connectors.

5. Replace Front Case Assembly.

6. Return to factory.

6-2

Alaris® SpO2 Modules

Technical Service Manual

Table 6-2. Error Codes

TROUBLESHOOTING

Reference the PC Unit / Pump Module (

8000/8100 Series) Technical Service Manual for details on

accessing the Maintenance Mode and viewing the Error Log.

Error Code Subsystem Explanation Response

400 Logic Board Logic Board failure. Cycle power. If error repeats,

replace Logic Board.

410 Keypad Decoder Keyboard processor failure. Cycle power. If error repeats,

replace Display Board.

411 Keypad Decoder Communication Communications failure with

keyboard processor.

430 Keypad Keypad failure. Cycle power. If error repeats,

450 IUI IUI communication failure. Cycle power. If error repeats,

460 Power Supply Board Power Supply Board failure. Cycle power. If error repeats,

Cycle power. If error repeats, check inter-board connections. Cycle power. If error repeats, replace Display Board and/or connectors.

replace front panel.

check IUI connectors. Cycle power. If error repeats, replace IUI connectors.

replace Power Supply Board.

470 SpO

471 SpO

Board SpO2 Board failure. Cycle power. If error repeats,

Board Communication Communications failure with

SpO

Board.

replace SpO

Board.

Cycle power. If error repeats, check inter-board connections. Cycle power. If error repeats, replace SpO

Board and/or connectors.

6200 SpO2 Board Failed "continuous built-in tests". Cycle power. If error repeats,

6210 SpO

replace SpO

Board Communications error. Cycle power. If error repeats,

replace SpO

Board.

6220 SpO2 Board Configurations error. Cycle power. If error repeats,

6230 SpO

replace SpO

Board Received value "out of range". Replace Sensor. If error repeats,

Board.

cycle power. If error still occurs, replace SpO

Board.

6240 SpO2 Board Missing sensor status. Replace Sensor. If error repeats,

cycle power. If error still occurs, replace SpO

Technical Service Manual

Board.

Alaris® SpO2 Modules

6-3

TROUBLESHOOTING

THIS PAGE

INTENTIONALLY

LEFT BLANK

6-4

Alaris® SpO2 Modules

Technical Service Manual

Chapter 7 – ILLUSTRATED PARTS BREAKDOWN

7.1 INTRODUCTION

The illustrated parts breakdown for the instrument is divided into major assemblies and individual parts.

7.2 ILLUSTRATIONS

The exploded views serve as visual aids for identifying the parts of each assembly. If a part/assembly is identified with an item number (appearing in a bubble), that number corresponds with the item number on the parts list. If a part/assembly is not identified with an item number, it is available only as part of a higher assembly or kit.

Due to product changes over time, components/assemblies illustrated in this chapter may differ from the instrument being serviced.

7.3 PARTS LIST

The parts list provides the following information for saleable parts and assemblies:

Item: This number corresponds with number in illustration.

Part Number: This is the Alaris

number needed when placing an order. When a part number is not provided, that

part is either not sold by CareFusion, is provided as part of a kit or higher assembly, or can only be replaced/repaired by CareFusion authorized service personnel.

Description: Descriptive information that may be helpful when placing an order.

QTY: Total number of each item used.

product

Alaris® SpO2 Modules

Technical Service Manual

7-1

ILLUSTRATED PARTS BREAKDOWN

7.4 ORDERING PARTS

Parts can be ordered by writing or calling CareFusion Customer Care (see "General Contact Information" at beginning of this manual). When requesting a part, provide the following information:

• Product name and model number (for

SpO

example,

Module, Model 8210).

• Instrument software version. Reference

Alaris

System DFU for directions on how

to view software version.

• Part number.

• Part description, as provided in parts list.

• For labels, specify required language.

7-2

Alaris® SpO2 Modules

Technical Service Manual

ILLUSTRATED PARTS BREAKDOWN

Table 7-1. Parts List

NOTE: An "assembly" is a preassembled group of parts. A "kit" is a group of unassembled parts.

Item Part Number Description QTY

015 146980-000 Gasket, Status Indicator 1 020

147716-001

146976-000 025 030 032 035 036

146978-000

10011343

144424-100

146646-103

320905

037

10014345

10013006

039

147747-100

146970-102 040 045 047 050 055 060 065 070 075

142833-000 146977-000

320906

141117

146637-106

146992-001

147767-100



142794-000

080 147093-100 Silicon Tubing (10 Ft)

085 146365-000 Rear Case, Unshielded 1 086

10014803 10014804

Front Case:

8210 Series

8220 Series Lens, Status Indicator Keypad Backlight

LED Assembly, Keypad

Board Assembly, Display Standoff, 14 Hex x 0.750, 6-32 Nylon Board Assembly, SpO

Nellcor® (8210 Series)

Masimo

(8220 Series)

Board Assembly, Power Supply:

8210 Series

8220 Series

IUI Bracket

Frame Christmas Tree Clip Speaker Board Assembly, Logic

IUI Bracket Strap

Board Assembly, Patient Connector Silicone Grease, Dow Corning Molykote (or equivalent) Foot, Rubber

(This 10-foot length of tubing is enough for 6 SpO

Modules.

See Figure 7-8.)

Case Assembly Kit, Rear:

(Consists of: Nameplate Label and items 75, 80, 85, 620, 638.

All items are attached except item 638.)

Nellcor

(8210 Series)

Masimo® (8220 Series)

As Required

1 1 1 1 3 1

1 1 3 1 1 1 1

2 1

Alaris® SpO2 Modules

Technical Service Manual

7-3

ILLUSTRATED PARTS BREAKDOWN

Table 7-1. Parts List (Continued)

Item Part Number Description QTY

090 147080-100 Latch Kit

(Consists of: Latch, Compression Spring, Leaf Spring,

Support)

110 320871 Washer, Nylon 6 120 147077-100 IUI Connector Kit, Right

(Consists of: Right IUI Connector, Right Gasket)

130 147078-100 IUI Connector Kit, Left

(Consists of: Left IUI Connector, Left Seal)

620

630

631 638 800 820 825 830 835 840

10014353

147352-000

147381-000 147755-000

147868-000

125569 320851 834031

300348

806112 320855 320908

Patent Label:

8210 Series 8220 Series

Logo Label:

Masimo Nellcor

Defibrillation Rating Label Serial Number Replacement Label Screw, 4-40 x

/16, PHH PNH Cable Tie, 4" Auto Feed Screw, 4-40 x ¾, PHH PNH Snap Rivet, 0.125 diameter, Black Nylon Screw, 6-32 x

/16, PHH PNH Washer, Flat, Stainless Steel Patient Cable:

320886 320930

Masimo Nellcor® 3 Meter

8 Ft

Directions for Use, English:

Alaris® System with Model 8000 PC Unit: 10014346 10014343

Electronic Copy Printed Copy

Maintenance Software: 10013678 10013025

Version 7 Version 8

1 1 8 2 6 2

2 1

 Not sold by CareFusion.

7-4

Alaris® SpO2 Modules

Technical Service Manual

Figure 7-1. Front Case Assembly

ILLUSTRATED PARTS BREAKDOWN

2 PL

800

3 PL

Alaris® SpO2 Modules

Technical Service Manual

7-5

ILLUSTRATED PARTS BREAKDOWN

Figure 7-2. IUI Bracket/Frame

7-6

Alaris® SpO2 Modules

Technical Service Manual

ILLUSTRATED PARTS BREAKDOWN

Figure 7-3. Masimo® SpO2 Board - Power Supply Board Assembly

835

6 PL

3 PL

110

6 PL

Power Supply Board Assembly

830

Alaris® SpO2 Modules

Technical Service Manual

7-7

ILLUSTRATED PARTS BREAKDOWN

Figure 7-4. Nellcor® SpO2 Board - Power Supply Board Assembly

835

3 PL

6 PL

110

6 PL

Power Supply Board Assembly

830

2 PL

7-8

Alaris® SpO2 Modules

Technical Service Manual

Figure 7-5. Frame Assembly - Logic Board View

ILLUSTRATED PARTS BREAKDOWN

Excess speaker wire is bundled together and tied

with Cable Tie (item 820).

Tip is removed from Christmas Tree Clip (item 47)

used in this location.

To Power Supply Board J4

820

Connected to Power

Supply Board J6.

2 PL

830

Alaris® SpO2 Modules

Technical Service Manual

7-9

ILLUSTRATED PARTS BREAKDOWN

Figure 7-6. Frame - Front Case Assembly

LED Assembly Cable (item 32), harness, and

ground wire are bundled together and loosely tied with one Cable Tie (item 820).

Ground wire is positioned between screw (item

800) and IUI Bracket Strap. 825

6 PL

Frame Assembly

800

IUI Bracket Strap

Front Case Assembly

(see Figure 7-1)

1 2

To Display Board J4.

820

(to Display Board J3)

Keypad Ground Wire

Keypad Harness

7-10

Alaris® SpO2 Modules

Technical Service Manual

Figure 7-7. IUI Assembly

IUI Connector Kit, Right (item 120).

IUI Connector Kit, Left (item 130).

835

4 PL

IUI Connector Seal

ILLUSTRATED PARTS BREAKDOWN

IUI Connector Gasket

IUI Connector, Right

IUI Connector, Left

4 PL

835

2 PL

840

630

631

Alaris® SpO2 Modules

Technical Service Manual

7-11

ILLUSTRATED PARTS BREAKDOWN

Figure 7-8. Rear Case Assembly

Latch Kit (item 90).

Rubber Feet (item 75), Rear Case (item 85), and

Silicon Tubing (item 80) are provided as separate items and as part of Rear Case Assembly Kit (item

86).

2 PL

800

Latch Support

Leaf Spring

Compression Spring

2 PL

~18½"

Latch

7-12

Alaris® SpO2 Modules

Technical Service Manual

Figure 7-9. Rear Label Locations

Nameplate Label, which has a regulatory mark,

is not field replaceable as an individual item. It is available only as part of Rear Case Assembly Kit (item 86).

Labels (items 620 and 638) are provided as

separate items and as part of Rear Case Assembly Kit (item 86).

Before adhering Serial Number Replacement

Label (item 638):

1. Print instrument model and serial number on

label with permanent black ink.

2. Apply clear overlay to completely cover label.

ILLUSTRATED PARTS BREAKDOWN

Nameplate Label

620

638

Alaris® SpO2 Modules

Technical Service Manual

7-13

ILLUSTRATED PARTS BREAKDOWN

Figure 7-10. Display Board Assembly

This illustration is for board identification purposes only and does not represent the board's component layout.

DS3

DS5

DS4

DS7

DS8

DS6

DS9

DS1

DS2

7-14

Alaris® SpO2 Modules

Technical Service Manual

ILLUSTRATED PARTS BREAKDOWN

Figure 7-11. Logic Board Assembly

This illustration is for board identification purposes only and does not represent the board's component layout.

Alaris® SpO2 Modules

Technical Service Manual

7-15

ILLUSTRATED PARTS BREAKDOWN

Figure 7-12. Power Supply Board Assembly (8210 Series)

This illustration is for board identification purposes only and does not represent the board's component layout.

7-16

Alaris® SpO2 Modules

Technical Service Manual

ILLUSTRATED PARTS BREAKDOWN

Figure 7-13. Power Supply Board Assembly (8220 Series)

This illustration is for board identification purposes only and does not represent the board's component layout.

Alaris® SpO2 Modules

Technical Service Manual

7-17

ILLUSTRATED PARTS BREAKDOWN

THIS PAGE

INTENTIONALLY

LEFT BLANK

7-18

Alaris® SpO2 Modules

Technical Service Manual

and Guardrails® are registered trademarks of CareFusion, Inc. or one of its subsidiaries. Masimo®, SET®, and Signal Extraction

Alaris Technology® are registered trademarks of Masimo Corporation. Nellcor® is a registered trademark of Tyco Healthcare/Mallinckrodt, Inc. All other trademarks belong to their respective owners.

Alaris Alaris Model 8220 SPO2 tech man Substituting Rechargeable Batteries

Specifications and Main Features

Frequently Asked Questions

User Manual
