Overview

Description Agilent 281 adapters provide a convenient means of coupling between

waveguide and coaxial systems. Power can be transmitted in either directi on,
and each adapter covers the full frequency range of its waveguide size with
an SWR of less than 1.30. The flanges are lapped to a slight, controlled
convexity to assure minimum leakage at the waveguide joint. A probe
transforms the waveguide impedance to the 50-ohm impedance of coaxial
line. Complete specifications for the adapters are given in Table1.

Examples of the waveguide flange and coaxial connectors used on these
adapters are shown in Figure 1. One type of flange and two types of coaxial
connectors are used: Type N female connectors (which are compatible with
connectors conforming to MILS-71), are available on all 281A adapters and
Amphenol precision 7-mm connect ors ( available on the 281B a dapters) . The
7-mm connector features precise alignment, a clearly defined reference
plane, and low RF leakage. In addition, any pair can be connected together
without an adapter. Option 13 adapters have stainless steel Type N female
connectors and are available on the P281B.

Figure 1 Adapters Showing Flange Types and Coaxial Connector Styles

281A/B Adapters Operating and Service Manual1

Specifications

Specifications

Table 1 281A/B Specfications

Model Frequency

Range (GHz)

X281A 8.20 to 12.40 1 x 1/2 WR90 UG135/U N female 1-7/16 37 1/4 0. 1
P281B 12.40 to 18.00 0.702 -0.391 WR62 UG419/U APC-7

1. Maximum Reflection Coefficient: 0.11 (1.25 SWR) over entire frequency range.

2. Typical maximum power handling capability for the Type N and APC-7 connectors is 200 W (refer to caution below).

3. Option 013 furnished with stainless steel Type N female connector.
Option 012 furnished with Type N male connector.
Option 006 adds additional alignment holes.

1

Fits Waveguide Size

Nom. OD(in.) EIA

Equivalent

Flange

Coaxial

Connector

2

3

Length

(in) (mm)

1 26 3/16 0. 1

Weight

(lb) (kg)

CAUTION The power that can be handled will be a function of the size of the center

conductor. The majority of the heat flow will be via conduction. The weak
point is the coax port ion. The waveguide portion i s ca pab le o f hi ghe r power.
These numbers are assuming an ambient temperature of 25 degrees
centigrade and an altitude of sea level. Higher ambient temperatures and
altitude would degrade power-handling capability.

2 281A/B Adapters Operating and Service Manual

Inspection

Mechanical Check If external damage to the shipping carton is evident, the carrier’s agent

Electrical Check The electrical performance of the adapter should be checked as soon as

Inspection and Shipping

Inspection and Shipping

should be present when the adapter is unpacked. Check the adapter for
external damage. If damage is evident, refer to Claims, below, for
recommended claim procedure. If the shipping carton is not damaged, check
the packaging material for signs of stress that indicate rough handling in
transit. If the adapter appears undamaged, perform the electrical check.

possible after receipt against the specifications shown in Table1. If the
adapter does not perform within the specifications, see the following
paragraphs for recommended claim procedure and repackaging the
instrument.

Claims If physical damage is evident, or if the adapter does not meet electrical

specifications when received, notify the carrier and the nearest Agilent
Technologies office

Shipping

Using Original Packaging The same container s and mat er ial used i n fact ory packaging can be obtained

through Agilent offices.
If the adapter is being returned to Agilent Technologies for servicing, attach

a tag indicating the type of service required, return address, and model
number. Also, mark the container FRAGILE to assure careful handling

Using Other Packaging The following general instructions should be used for repackaging with

commercially available materials:

1. Wrap the adapter in heavy paper or plastic. (If shipping to a Agilent
Technologies office or service center, attach a tag indicating the type of
service required, return address, and model number.)

2. Use a strong shipping container. A double-wall carton made of
350-pound test material is adequate.

281A/B Adapters Operating and Service Manual3

Inspection and Shipping

3. Use enough shock-absorbing material (3 to 4-i nch layer) ar ound all sides
of the adapter to provide firm cushion and prevent movement inside the
container.

4. Seal the shipping container securely

5. Mark the shipping container FRAGILE to assure careful handling.

4 281A/B Adapters Operating and Service Manual

Operation

Protest Flanges Care should be taken to protect the face of the flange from any damage that

would prevent close surface-t o-surface contact. Any burring, denting, or
scratching will increases RF leakage and the reflection coefficient of the
joint. The supplied plastic cover should be used to protect the flange when
the adapter is not in use.

Assemble Carefully When connecting an adapter to a waveguide.

1. Make sure the rectangular ports are oriented the same way (i.e., not
"cross-guided").

2. Align ports carefully to minimize reflections.

3. Clamp or bolt flanges securely together so that pressure is evenly
distributed over the contacting surfaces. Loose joints and flange
distortion result in leakage and mismatch.

Operation

Connector Types Type N Connectors

Two versions of the Type N coaxial connector are used on the adapters: one
is used on the 281A model, and the other is used in the Option 13B model.
The version on the 281A model is plated brass and is compatible with
connectors conforming to MIL-C-71. The version on the Option 13B model
is stainless steel and is compatible with connec tors conformi ng to MIL-C-71
or MIL-C-39012. Dimensions of these connectors are given in Figure 2.

Figure 2 Dimensions of Type N Connector s

281A/B Adapters Operating and Service Manual5

Operation

Precision 7 mm Connectors

Except for Option 13, the 281B model adapter ha s a APC-7 pr ecision 7-mm
coaxial connector. These connectors rely on uniform end-to end contact of
both conductors for electrical continuity. Consequently, the condition of the
contacting surfaces is critical: they should be kept clean and smooth. To
prevent damage when the adapter is not in use, the connector’s threaded
sleeve should be fully extended.

Performance Test The maximum SWR for the Adapters are listed in Table1. When making

these measurements, the test results must be less than those listed in Table1
plus the measurement uncertainty of the measurement sy stem. Measurement
may be made using a standard reflectometer setup. To ensure satisfactory
performance, make sure flanges and coaxial connectors are not damaged or
worn.

6281A/B Adapters Operating and Service Manual

Replaceable Parts

The 281A may be disassembled for part replacement, but the 281B should
be returned to Agilent because liquid nitrogen and special wrenches and
gauges are needed for assembly.

The exploded view of Figure 3 gives information for ordering replacement
parts and can be used as an assembly guide. To obtain a replacement part
give the adapter’s full model number and the part number from Table2, and
address the order to the nearest Agilent Technologies office.

Figure 3 281A Replacement Parts

Replaceable Parts

281A/B Adapters Operating and Service Manual7

Replaceable Parts

Table 2 281A Replaceable Parts

Item No. Description Model No. Agilent Part No.

1 RF Connector Body X281A 5020-0213
2 Probe Assembly X281A not applicable

Probe Body

Probe Insulator
3 Probe Case X281A X281A-5
4 X-band X281A 00281-20017

Flange Cap (not shown)

1

00281-20025

1

00281-20106

X-band

P-band

1. This part is a subcomponent of item number 2 (Probe Assembly for X281A).

X281A
P281B

NOTE All 281B adapters should be returned for part replacement.

5040-0354
5040-0358

8 281A/B Adapters Operating and Service Manual
