Programmer’s Guide

Publication number 01670-97021 March 2002

For Safety information, Warranties, and Regulatory information, see the pages behind the Index

Agilent Technologies 1670G-Series Logic Analyzers

In This Book

Introduction to Programming the

Agilent Technologies 1670G

This programmer’s guide contains general information, instrument level commands, logic analyzer commands, oscilloscope module commands, pattern generator module commands, and programming examples for programming the Agilent Technologies 1670G-series logic analyzers. This guide focuses on how to program the instrument over the GPIB and the RS-232-C interfaces. For information on using Ethernet refer to the LAN section of your User’s Guide.

Instruments covered by the Agilent Technologies 1670G-Series Programmer’s Guide

The Agilent 1670G-series logic analyzers are available with or without oscilloscope measurement capabilities and pattern generator capabilities. The Agilent 1670G-series logic analyzer has a hard disk drive and optional Ethernet capability.

What is in the Agilent Technologies 1670G-Series Programmer’s Guide?

The Agilent Technologies 1670G-Series Programmer’s Guide is organized in six parts.

Programming Over GPIB

Programming Over RS-232-C

Programming and

Documentation Conventions

Message Communication

and System Functions

Status Reporting

Error Messages

Common Commands

Instrument Commands

Module Level Commands

SYSTem Subsystem

MMEMory Subsystem

MACHine Subsystem

WLISt Subsystem

SFORmat Subsystem

iii

Part 1 Part 1, consists of chapters 1 through 7 and contains general information about programming basics, GPIB and RS-232-C interface requirements, documentation conventions, status reporting, and error messages.

If you are already familiar with IEEE 488.2 programming and GPIB or RS-232-C, you may want to just scan these chapters. If you are new to programming the system, you should read part 1.

Chapter 1 is divided into two sections. The first section, "Talking to the Instrument," concentrates on program syntax, and the second section, "Receiving Information from the Instrument," discusses how to send queries and how to retrieve query results from the instrument.

Read either chapter 2, "Programming Over GPIB," or chapter 3, "Programming Over RS-232-C" for information concerning the physical connection between the Agilent Technologies 1670G-series logic analyzer and your controller.

Chapter 4, "Programming and Documentation Conventions," gives an overview of all instructions and also explains the notation conventions used in the syntax definitions and examples.

Chapter 5, "Message Communication and System Functions," provides an overview of the operation of instruments that operate in compliance with the IEEE 488.2 standard.

Chapter 6 explains status reporting and how it can be used to monitor the flow of your programs and measurement process.

Chapter 7 contains error message descriptions. Part 2 Part 2, chapters 8 through 13, explains each command in the

command set for the entire logic analyzer. These chapters are organized in subsystems with each subsystem representing a front-panel menu.

The commands explained in this part give you access to common commands, instrument commands, system level commands, disk commands, intermodule measurement, and module level commands. This part is designed to provide a concise description of each command.

Part 3 Part 3, chapters 14 through 27, explains each command in the subsystem command set for the logic analyzer. Chapter 27 contains information on the SYSTem:DATA and SYSTem:SETup commands for the logic analyzer.

STRigger (STRace) Subsystem

The commands explained in this part give you access to all the commands used to operate the logic analyzer portion of the Agilent 1670-series system. This part is designed to provide a concise description of each command.

Part 4 Part 4, chapters 28 through 36 explain each command in the subsystem command set for the oscilloscope. The information covered in Part 4 is only relevant to models containing an oscilloscope.

The commands explained in this part give you access to all the commands used to operate the oscilloscope. This part is designed to provide a concise description of each command.

Part 5 Part 5, chapters 37 through 42 explain each command in the subsystem command set for the pattern generator. The information covered in Part 5 is only relevant to models containing a pattern generator.

The commands explained in this part give you access to all the commands used to operate the pattern generator portion of the Agilent 1670G-series system. This part is designed to provide a concise description of each command.

SLISt Subsystem

SWAVeform Subsystem

SCHart Subsystem

COMPare Subsystem

TFORmat Subsystem

TTRIGger {TTRACe} Subsystem

TWAVeform Subsystem

TLISt Subsystem

SPA Subsystem

SYMBol Commands

DATA and SETup Commands

Oscilloscope Root Level

Commands

ACQuire Subsystem

CHANnel Subsystem

Part 6 Part 6, chapter 43, contains program examples of actual tasks that show you how to get started in programming the Agilent 1670G-series logic analyzers. The complexity of your programs and the tasks they accomplish are limited only by your imagination. These examples are written in HP Basic 6.2; however, the program concepts can be used in any other popular programming language that allows communications over GPIB or RS-232 buses.

DISPlay Subsystem

MARKer Subsystem

MEASure Subsystem

TIMebase Subsystem

TRIGger Subsystem

WAVeform Subsystems

Programming the Pattern

Generator

FORMat Subsystem

SEQuence Subsystem

MACRo Subsystem

SYMBol Subsystem

DATA and SETup Commands

Programming Examples

Index

vii

viii

Part 1 General Information

1 Introduction to Programming the Agilent Technologies 1670G-

Series Logic Analyzer

Talking to the Instrument 1–3

Initialization 1–4 Instruction Syntax 1–5 Output Command 1–5 Device Address 1–6 Instructions 1–6 Instruction Terminator 1–7 Header Types 1–8 Duplicate Keywords 1–9 Query Usage 1–10 Program Header Options 1–11 Parameter Data Types 1–12 Selecting Multiple Subsystems 1–14

Receiving Information from the Instrument 1–15

Response Header Options 1–16 Response Data Formats 1–17 String Variables 1–18 Numeric Base 1–19 Numeric Variables 1–19 Definite-Length Block Response Data 1–20 Multiple Queries 1–21 Instrument Status 1–22

2 Programming Over GPIB

Interface Capabilities 2–3 Command and Data Concepts 2–3 Addressing 2–3 Communicating Over the GPIB Bus (HP 9000 Series 200/300 Controller) 2–4 Local, Remote, and Local Lockout 2–5

Contents–1

Contents

Bus Commands 2–6

3 Programming Over RS-232-C

Interface Operation 3–3 RS-232-C Cables 3–3 Minimum Three-Wire Interface with Software Protocol 3–4 Extended Interface with Hardware Handshake 3–4 Cable Examples 3–6 Configuring the Logic Analyzer Interface 3–8 Interface Capabilities 3–9 RS-232-C Bus Addressing 3–10 Lockout Command 3–11

4 Programming and Documentation Conventions

Truncation Rule 4–3 Infinity Representation 4–4 Sequential and Overlapped Commands 4–4 Response Generation 4–4 Syntax Diagrams 4–4 Notation Conventions and Definitions 4–5 The Command Tree 4–5 Tree Traversal Rules 4–6 Command Set Organization 4–12 Subsystems 4–12 Program Examples 4–13

5 Message Communication and System Functions

Protocols 5–3 Syntax Diagrams 5–5 Syntax Overview 5–7

6 Status Reporting

Event Status Register 6–4 Service Request Enable Register 6–4 Bit Definitions 6–4

Contents–2

Key Features 6–6 Serial Poll 6–7

7 Error Messages

Device Dependent Errors 7–3 Command Errors 7–3 Execution Errors 7–4 Internal Errors 7–4 Query Errors 7–5

Part 2 Instrument Commands

8 Common Commands

*CLS (Clear Status) 8–5 *ESE (Event Status Enable) 8–6 *ESR (Event Status Register) 8–7 *IDN (Identification Number) 8–9 *IST (Individual Status) 8–9 *OPC (Operation Complete) 8–11 *OPT (Option Identification) 8–12 *PRE (Parallel Poll Enable Register Enable) 8–13 *RST (Reset) 8–14 *SRE (Service Request Enable) 8–15 *STB (Status Byte) 8–16 *TRG (Trigger) 8–17 *TST (Test) 8–18 *WAI (Wait) 8–19

Contents

9 Instrument Commands

BEEPer 9–6 CAPability 9–7 CARDcage 9–8 CESE (Combined Event Status Enable) 9–9 CESR (Combined Event Status Register) 9–10 EOI (End Or Identify) 9–11

Contents–3

Contents

LER (LCL Event Register) 9–11 LOCKout 9–12 MENU 9–12 MESE<N> (Module Event Status Enable) 9–14 MESR<N> (Module Event Status Register) 9–16 RMODe 9–18 RTC (Real-time Clock) 9–18 SELect 9–19 SETColor 9–21 STARt 9–22 STOP 9–22 XWINdow 9–23

10 Module Level Commands

ARMLine 10–5 DBLock 10–5 MACHine 10–6 WLISt 10–6

11 SYSTem Subsystem

DATA 11–5 DSP (Display) 11–6 ERRor 11–7 HEADer 11–8 LONGform 11–9 PRINt 11–10 SETup 11–11

12 MMEMory Subsystem

AUToload 12–7 CATalog 12–8 CD (Change Directory) 12–9 COPY 12–10 DOWNload 12–11 INITialize 12–13

Contents–4

LOAD[:CONFig] 12–14 LOAD:IASSembler 12–15 MKDir (Make Directory) 12–16 MSI (Mass Storage Is) 12–17 PACK 12–18 PURGe 12–18 PWD (Present Working Directory) 12–19 REName 12–19 STORe[:CONFig] 12–20 UPLoad 12–21 VOLume 12–22

Part 3 Logic Analyzer Commands

13 MACHine Subsystem

Contents

MACHine 13–4 ARM 13–5 ASSign 13–6 LEVelarm 13–7 NAME 13–8 REName 13–8 RESource 13–9 TYPE 13–10

14 WLISt Subsystem

WLISt (Waveforms/LISting) 14–4 DELay 14–5 INSert 14–6 LINE 14–7 OSTate 14–7 OTIMe 14–8 RANGe 14–8 REMove 14–9 XOTime 14–9 XSTate 14–10 XTIMe 14–10

Contents–5

Contents

15 SFORmat Subsystem

SFORmat 15–6 CLOCk 15–6 LABel 15–7 MASTer 15–9 MOPQual 15–10 MQUal 15–11 REMove 15–12 SETHold 15–12 SLAVe 15–14 SOPQual 15–15 SQUal 15–16 THReshold 15–16

16 STRigger (STRace) Subsystem

Qualifier 16–7 STRigger (STRace) (State Trigger) 16–9 ACQuisition 16–9 BRANch 16–10 CLEar 16–12 FIND 16–13 MLENgth 16–14 RANGe 16–15 SEQuence 16–16 STORe 16–17 TAG 16–18 TAKenbranch 16–19 TCONtrol 16–20 TERM 16–21 TIMER 16–22 TPOSition 16–23

17 SLISt Subsystem

SLISt 17–7 COLumn 17–7

Contents–6

CLRPattern 17–8 DATA 17–9 LINE 17–9 MMODe (Marker Mode) 17–10 OPATtern 17–11 OSEarch 17–12 OSTate 17–13 OTAG 17–14 OVERlay 17–15 REMove 17–15 RUNTil (Run Until) 17–16 TAVerage 17–17 TMAXimum 17–17 TMINimum 17–18 VRUNs 17–18 XOTag 17–19 XOTime 17–19 XPATtern 17–20 XSEarch 17–21 XSTate 17–21 XTAG 17–22

Contents

18 SWAVeform Subsystem

SWAVeform 18–4 ACCumulate 18–5 ACQuisition 18–5 CENTer 18–6 CLRPattern 18–6 CLRStat 18–7 DELay 18–7 INSert 18–8 MLENgth 18–8 RANGe 18–9 REMove 18–10 TAKenbranch 18–10 TPOSition 18–11

Contents–7

Contents

19 SCHart Subsystem

SCHart 19–4 ACCumulate 19–4 CENTer 19–5 HAXis 19–5 VAXis 19–6

20 COMPare Subsystem

COMPare 20–4 CLEar 20–5 CMASk 20–5 COPY 20–6 DATA 20–6 FIND 20–8 LINE 20–8 MENU 20–9 RANGe 20–9 RUNTil (Run Until) 20–10 SET 20–12

21 TFORmat Subsystem

TFORmat (Timing Format) 21–4 ACQMode 21–5 LABel 21–6 REMove 21–7 THReshold 21–8

22 TTRigger (TTRace) Subsystem

Qualifier 22–6 TTRigger (TTRace)(Trace Trigger) 22–8 ACQuisition 22–9 BRANch 22–9 CLEar 22–12 EDGE 22–13 FIND 22–14

Contents–8

MLENgth 22–15 RANGe 22–16 SEQuence 22–17 SPERiod 22–18 TCONtrol (Timer Control) 22–19 TERM 22–20 TIMER 22–21 TPOSition (Trigger Position) 22–22

23 TWAVeform Subsystem

TWAVeform 23–7 ACCumulate 23–7 ACQuisition 23–8 CENTer 23–8 CLRPattern 23–9 CLRStat 23–9 DELay 23–9 INSert 23–10 MLENgth 23–11 MMODe (Marker Mode) 23–12 OCONdition 23–12 OPATtern 23–13 OSEarch 23–14 OTIMe 23–15 RANGe 23–16 REMove 23–16 RUNTil (Run Until) 23–17 SPERiod 23–18 TAVerage 23–18 TMAXimum 23–19 TMINimum 23–19 TPOSition 23–19 VRUNs 23–20 XCONdition 23–21 XOTime 23–21 XPATtern 23–22

Contents

Contents–9

Contents

XSEarch 23–23 XTIMe 23–24

24 TLISt Subsystem

TLISt 24–7 COLumn 24–7 CLRPattern 24–8 DATA 24–9 LINE 24–9 MMODe (Marker Mode) 24–10 OCONdition 24–11 OPATtern 24–12 OSEarch 24–13 OSTate 24–14 OTAG 24–14 REMove 24–15 RUNTil (Run Until) 24–15 TAVerage 24–16 TMAXimum 24–16 TMINimum 24–17 VRUNs 24–17 XCONdition 24–18 XOTag 24–18 XOTime 24–19 XPATtern 24–19 XSEarch 24–20 XSTate 24–21 XTAG 24–21

25 SPA Subsystem

MODE 25–7 OVERView:BUCKet 25–8 OVERView:HIGH 25–9 OVERView:LABel 25–10 OVERView:LOW 25–11 OVERView:MLENgth 25–12

Contents–10

OVERView:OMARker 25–13 OVERView:OVSTatistic 25–14 OVERView:XMARker 25–15 HISTogram:HSTatistic 25–16 HISTogram:LABel 25–17 HISTogram:OTHer 25–18 HISTogram:QUALifier 25–19 HISTogram:RANGe 25–20 HISTogram:TTYPe 25–21 TINTerval:AUTorange 25–22 TINTerval:QUALifier 25–22 TINTerval:TINTerval 25–24 TINTerval:TSTatistic 25–25

26 SYMBol Subsystem

Contents

SYMBol 26–5 BASE 26–5 PATTern 26–6 RANGe 26–7 REMove 26–8 WIDTh 26–8

27 DATA and SETup Commands

Introduction 27–2

Data Format 27–3 SYSTem:DATA 27–4 Section Header Description 27–6 Section Data 27–6 Data Preamble Description 27–6 Acquisition Data Description 27–10 Tag Data Description 27–12 SYSTem:SETup 27–12

Part 4 Oscilloscope Commands

Contents–11

Contents

28 Oscilloscope Root Level Commands

AUToscale 28–3 DIGitize 28–5

29 ACQuire Subsystem

COUNt 29–4 TYPE 29–5

30 CHANnel Subsystem

COUPling 30–4 ECL 30–5 OFFSet 30–6 PROBe 30–7 RANGe 30–8 TTL 30–9

31 DISPlay Subsystem

ACCumulate 31–4 CONNect 31–5 INSert 31–6 LABel 31–7 MINus 31–8 OVERlay 31–8 PLUS 31–9 REMove 31–9

32 MARKer Subsystem

AVOLt 32–6 ABVolt? 32–7 BVOLt 32–7 CENTer 32–8 MSTats 32–8 OAUTo 32–9 OTIMe 32–10

Contents–12

RUNTil (Run Until) 32–11 SHOW 32–12 TAVerage? 32–12 TMAXimum? 32–13 TMINimum? 32–13 TMODe 32–14 VMODe 32–15 VOTime? 32–16 VRUNs? 32–16 VXTime? 32–17 XAUTo 32–18 XOTime? 32–19 XTIMe 32–19

33 MEASure Subsystem

Contents

ALL? 33–4 FALLtime? 33–5 FREQuency? 33–5 NWIDth? 33–6 OVERshoot? 33–6 PERiod? 33–7 PREShoot? 33–7 PWIDth? 33–8 RISetime? 33–8 SOURce 33–9 VAMPlitude? 33–10 VBASe? 33–10 VMAX? 33–11 VMIN? 33–11 VPP? 33–12 VTOP? 33–12

34 TIMebase Subsystem

DELay 34–4 MODE 34–5 RANGe 34–6

Contents–13

Contents

35 TRIGger Subsystem

CONDition 35–5 DELay 35–7 LEVel 35–8 LOGic 35–10 MODE 35–11 PATH 35–12 SLOPe 35–12 SOURce 35–13

36 WAVeform Subsystem

Format for Data Transfer 36–3 Data Conversion 36–5 COUNt? 36–8 DATA? 36–8 FORMat 36–9 POINts? 36–9 PREamble? 36–10 RECord 36–11 SOURce 36–11 SPERiod? 36–12 TYPE? 36–12 VALid? 36–13 XINCrement? 36–13 XORigin? 36–14 XREFerence? 36–14 YINCrement? 36–15 YORigin? 36–15 YREFerence? 36–16

Part 5 Pattern Generator Commands

37 Programming the Pattern Generator

Programming Overview 37–3

Contents–14

Example Pattern Generator Program 37–3 Selecting the Pattern Generator 37–4 Command Set Organization 37–5

Pattern Generator Level Commands 37–7

STEP 37–8 RESume 37–10

38 FORMat Subsystem

FORMat Subsystem 38–2

CLOCk 38–3 DELay 38–4 LABel 38–5 MODe 38–7 REMove 38–8

Contents

39 SEQuence Subsystem

SEQuence Subsystem 39–2

COLumn 39–4 EPATtern 39–5 INSert 39–7 PROGram 39–10 REMove 39–14

40 MACRo Subsystem

MACRo Subsystem 40–2

INSert 40–5 NAME 40–8 PARameter 40–9 PROGram 40–10 REMove 40–13

Contents–15

Contents

41 SYMBol Subsystem

SYMBol Subsystem 41–2

BASE 41–4 PATTern 41–5 RANGe 41–6 REMove 41–7 WIDTh 41–8

42 DATA and SETup Commands

Data and Setup Commands 42–2

SYSTem:DATA 42–4 SYSTem:SETup 42–5

Part 6 Programming Examples

43 Programming Examples

Making a Timing Analyzer Measurement 43–3 Making a State Analyzer Measurement 43–5 Making a State Compare Measurement 43–9 Transferring the Logic Analyzer Configuration 43–14 Checking for Measurement Completion 43–17 Sending Queries to the Logic Analyzer 43–18

Contents–16

Part 1

General Information

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Introduction

This chapter introduces you to the basics of remote programming and is organized in two sections. The first section, "Talking to the Instrument," concentrates on initializing the bus, program syntax and the elements of a syntax instruction. The second section, "Receiving Information from the Instrument," discusses how queries are sent and how to retrieve query results from the mainframe instruments.

The programming instructions explained in this book conform to IEEE Std 488.2-1987, "IEEE Standard Codes, Formats, Protocols, and Common Commands." These programming instructions provide a means of remotely controlling the Agilent Technologies 1670G-series logic analyzer. There are three general categories of use. You can:

• Set up the instrument and start measurements.

• Retrieve setup information and measurement results.

• Send measurement data to the instrument.

The instructions listed in this manual give you access to the measurements and front panel features of the Agilent Technologies 1670G-series logic analyzer. The complexity of your programs and the tasks they accomplish are limited only by your imagination. This programming reference is designed to provide a concise description of each instruction.

1–2

Talking to the Instrument

In general, computers acting as controllers communicate with the instrument by sending and receiving messages over a remote interface, such as GPIB or RS-232-C. Instructions for programming the Agilent Technologies 1670G-series logic analyzer will normally appear as ASCII character strings embedded inside the output statements of a "host" language available on your controller. The host language’s input statements are used to read in responses from the Agilent Technologies 1670G-series logic analyzer.

For example, HP 9000 Series 200/300 BASIC (Y2K updates for currently supported versions of HP BASIC can be found at http://hp.iwcon.com/tm-y2k/cgi-bin/tm_search.pl) uses the OUTPUT statement for sending commands and queries to the Agilent Technologies 1670G-series logic analyzer. After a query is sent, the response can be read in using the ENTER statement. All programming examples in this manual are presented in HP BASIC.

Example This BASIC statement sends a command that causes the logic analyzer’s

machine 1 to be a state analyzer:

OUTPUT XXX;":MACHINE1:TYPE STATE" <terminator>

Each part of the above statement is explained in this section.

1–3

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Initialization

To make sure the bus and all appropriate interfaces are in a known state, begin every program with an initialization statement. BASIC provides a CLEAR command that clears the interface buffer. If you are using GPIB, CLEAR will also reset the parser in the logic analyzer. The parser is the program resident in the logic analyzer that reads the instructions you send to it from the controller.

After clearing the interface, you could preset the logic analyzer to a known state by loading a predefined configuration file from the disk.

Refer to your controller manual and programming language reference manual for information on initializing the interface.

Example This BASIC statement would load the configuration file "DEFAULT " (if it

exists) into the logic analyzer.

OUTPUT XXX;":MMEMORY:LOAD:CONFIG ’DEFAULT ’"

Refer to chapter 12, "MMEMory Subsystem" for more information on the LOAD command.

Example This program demonstrates the basic command structure used to program

the Agilent Technologies 1670G-series logic analyzers.

10 CLEAR XXX !Initialize instrument interface 20 OUTPUT XXX;":SYSTEM:HEADER ON"!Turn headers on 30 OUTPUT XXX;":SYSTEM:LONGFORM ON" !Turn longform on 40 OUTPUT XXX;":MMEM:LOAD:CONFIG ’TEST E’" !Load configuration file 50 OUTPUT XXX;":MENU FORMAT,1" !Select Format menu for machine 1 60 OUTPUT XXX;":RMODE SINGLE" !Select run mode 70 OUTPUT XXX;":START" !Run the measurement

1–4

Figure 1-1

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Instruction Syntax

To program the logic analyzer remotely, you must have an understanding of the command format and structure. The IEEE 488.2 standard governs syntax rules pertaining to how individual elements, such as headers, separators, parameters and terminators, may be grouped together to form complete instructions. Syntax definitions are also given to show how query responses will be formatted. Figure 1-1 shows the three main syntactical parts of a typical program statement: Output Command, Device Address, and Instruction. The instruction is further broken down into three parts: Instruction header, White space, and Instruction parameters.

Program Message Syntax

Output Command

The output command depends on the language you choose to use. Throughout this guide, HP 9000 Series 200/300 BASIC 6.2 is used in the programming examples. If you use another language, you will need to find the equivalents of BASIC Commands, like OUTPUT, ENTER and CLEAR in order to convert the examples. The instructions are always shown between the double quotes.

1–5

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Device Address

The location where the device address must be specified also depends on the host language that you are using. In some languages, this could be specified outside the output command. In BASIC, this is always specified after the keyword OUTPUT. The examples in this manual use a generic address of XXX. When writing programs, the number you use will depend on the cable you use, in addition to the actual address. If you are using an GPIB, see chapter 2, "Programming over GPIB." If you are using RS-232-C, see chapter 3, "Programming Over RS-232-C."

Instructions

Instructions (both commands and queries) normally appear as a string embedded in a statement of your host language, such as BASIC, Pascal or C. The only time a parameter is not meant to be expressed as a string is when the instruction’s syntax definition specifies block data. There are just a few instructions which use block data.

Instructions are composed of two main parts: the header, which specifies the command or query to be sent; and the parameters, which provide additional data needed to clarify the meaning of the instruction. Many queries do not use any parameters.

Instruction Header

The instruction header is one or more keywords separated by colons (:). The command tree in figure 4-1 illustrates how all the keywords can be joined together to form a complete header (see chapter 4, "Programming and Documentation Conventions").

The example in figure 1-1 shows a command. Queries are indicated by adding a question mark (?) to the end of the header. Many instructions can be used as either commands or queries, depending on whether or not you have included the question mark. The command and query forms of an instruction usually have different parameters.

1–6

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Instruction Terminator

When you look up a query in this programmer’s reference, you’ll find a paragraph labeled "Returned Format" under the one labeled "Query." The syntax definition by "Returned format" will always show the instruction header in square brackets, like [:SYSTem:MENU], which means the text between the brackets is optional. It is also a quick way to see what the header looks like.

White Space

White space is used to separate the instruction header from the instruction parameters. If the instruction does not use any parameters, white space does not need to be included. White space is defined as one or more spaces. ASCII defines a space to be a character, represented by a byte, that has a decimal value of 32. Tabs can be used only if your controller first converts them to space characters before sending the string to the instrument.

Instruction Parameters

Instruction parameters are used to clarify the meaning of the command or query. They provide necessary data, such as: whether a function should be on or off, which waveform is to be displayed, or which pattern is to be looked for. Each instruction’s syntax definition shows the parameters, as well as the range of acceptable values they accept. This chapter’s "Parameter Data Types" section has all of the general rules about acceptable values.

When there is more than one parameter, they are separated by commas (,). White space surrounding the commas is optional.

Instruction Terminator

An instruction is executed after the instruction terminator is received. The terminator is the NL (New Line) character. The NL character is an ASCII linefeed character (decimal 10).

The NL (New Line) terminator has the same function as an EOS (End Of String) and EOT (End Of Text) terminator.

1–7

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Header Types

There are three types of headers: Simple Command, Compound Command, and Common Command.

Simple Command Header

Simple command headers contain a single keyword. START and STOP are examples of simple command headers typically used in this logic analyzer. The syntax is: <function><terminator>

When parameters (indicated by <data>) must be included with the simple command header, the syntax is: <function><white_space><data>

Example :RMODE SINGLE<terminator>

Compound Command Header

Compound command headers are a combination of two or more program keywords. The first keyword selects the subsystem, and the last keyword selects the function within that subsystem. Sometimes you may need to list more than one subsystem before being allowed to specify the function. The keywords within the compound header are separated by colons. For example, to execute a single function within a subsystem, use the following:

:<subsystem>:<function><white_space><data><terminator>

Example :SYSTEM:LONGFORM ON

To traverse down one level of a subsystem to execute a subsystem within that subsystem, use the following: <subsystem>:<subsystem>:<function><white_space>

Example :MMEMORY:LOAD:CONFIG "FILE "

1–8

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Common Command Header

Common command headers control IEEE 488.2 functions within the logic analyzer, such as, clear status. The syntax is: *<command header><terminator>

No white space or separator is allowed between the asterisk and the command header. *CLS is an example of a common command header.

Combined Commands in the Same Subsystem

To execute more than one function within the same subsystem, a semicolon (;) is used to separate the functions:

:<subsystem>:<function><white space><data>;<function><white space><data><terminator>

Example :SYSTEM:LONGFORM ON;HEADER ON

Duplicate Keywords

Identical function keywords can be used for more than one subsystem. For example, the function keyword MMODE may be used to specify the marker mode in the subsystem for state listing or the timing waveforms:

• :SLIST:MMODE PATTERN - sets the marker mode to pattern in

the state listing.

• :TWAVEFORM:MMODE TIME - sets the marker mode to time in

the timing waveforms.

SLIST and TWAVEFORM are subsystem selectors, and they determine which marker mode is being modified.

1–9

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Query Usage

Logic analyzer instructions that are immediately followed by a question mark (?) are queries. After receiving a query, the logic analyzer parser places the response in the output buffer. The output message remains in the buffer until it is read or until another logic analyzer instruction is issued. When read, the message is transmitted across the bus to the designated listener (typically a controller).

Query commands are used to find out how the logic analyzer is currently configured. They are also used to get results of measurements made by the logic analyzer.

Example This instruction places the current full-screen time for machine 1 in the

output buffer.

:MACHINE1:TWAVEFORM:RANGE?

In order to prevent the loss of data in the output buffer, the output buffer must be read before the next program message is sent. Sending another command before reading the result of the query will cause the output buffer to be cleared and the current response to be lost. This will also generate a "QUERY UNTERMINATED" error in the error queue. For example, when you send the query :TWAVEFORM:RANGE? you must follow that with an input statement. In BASIC, this is usually done with an ENTER statement.

In BASIC, the input statement, ENTER XXX; Range, passes the value across the bus to the controller and places it in the variable Range.

Additional details on how to use queries is in the next section of this chapter, "Receiving Information for the Instrument."

1–10

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Program Header Options

Program headers can be sent using any combination of uppercase or lowercase ASCII characters. Logic analyzer responses, however, are always returned in uppercase.

Both program command and query headers may be sent in either long form (complete spelling), short form (abbreviated spelling), or any combination of long form and short form.

Programs written in long form are easily read and are almost selfdocumenting. The short form syntax conserves the amount of controller memory needed for program storage and reduces the amount of I/O activity.

The rules for short form syntax are discussed in chapter 4, "Programming and Documentation Conventions."

Example Either of the following examples turns on the headers and long form.

Long form:

OUTPUT XXX;":SYSTEM:HEADER ON;LONGFORM ON"

Short form:

OUTPUT XXX;":SYST:HEAD ON;LONG ON"

1–11

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Parameter Data Types

There are three main types of data which are used in parameters. They are numeric, string, and keyword. A fourth type, block data, is used only for a few instructions: the DATA and SETup instructions in the SYSTem subsystem (see chapter 11); the CATalog, UPLoad, and DOWNload instructions in the MMEMory subsystem (see chapter 12). These syntax rules also show how data may be formatted when sent back from the Agilent 1670G-series logic analyzer as a response.

The parameter list always follows the instruction header and is separated from it by white space. When more than one parameter is used, they are separated by commas. You are allowed to include one or more white spaces around the commas, but it is not mandatory.

Numeric data

For numeric data, you have the option of using exponential notation or using suffixes to indicate which unit is being used. However, exponential notation is only applicable to the decimal number base. Tables 5-1 and 5-2 in chapter 5, "Message Communications and System Functions," list all available suffixes. Do not combine an exponent with a unit.

Example The following numbers are all equal:

28 = 0.28E2 = 280E-1 = 28000m = 0.028K.

The base of a number is shown with a prefix. The available bases are binary (#B), octal (#Q), hexadecimal (#H) and decimal (default).

Example The following numbers are all equal:

#B11100 = #Q34 = #H1C = 28

You may not specify a base in conjunction with either exponents or unit suffixes. Additionally, negative numbers must be expressed in decimal.

1–12

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Parameter Data Types

When a syntax definition specifies that a number is an integer, that means that the number should be whole. Any fractional part would be ignored, truncating the number. Numeric parameters that accept fractional values are called real numbers.

All numbers are expected to be strings of ASCII characters. Thus, when sending the number 9, you send a byte representing the ASCII code for the character "9" (which is 57, or 0011 1001 in binary). A three-digit number, like 102, will take up three bytes (ASCII codes 49, 48 and 50). This is taken care of automatically when you include the entire instruction in a string.

String data

String data may be delimited with either single (’) or double (") quotes. String parameters representing labels are case-sensitive. For instance, the labels "Bus A" and "bus a" are unique and should not be used indiscriminately. Also pay attention to the presence of spaces, because they act as legal characters just like any other. So, the labels "In" and " In" are also two different labels.

Keyword data

In many cases a parameter must be a keyword. The available keywords are always included with the instruction’s syntax definition. When sending commands, either the longform or shortform (if one exists) may be used. Uppercase and lowercase letters may be mixed freely. When receiving responses, upper-case letters will be used exclusively. The use of longform or shortform in a response depends on the setting you last specified via the SYSTem:LONGform command (see chapter 11).

1–13

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Selecting Multiple Subsystems

You can send multiple program commands and program queries for different subsystems on the same line by separating each command with a semicolon. The colon following the semicolon enables you to enter a new subsystem.

Multiple commands may be any combination of simple, compound and common commands.

Example :MACHINE1:ASSIGN2; :SYSTEM:HEADER S ON

1–14

Receiving Information from the Instrument

After receiving a query (logic analyzer instruction followed by a question mark), the logic analyzer interrogates the requested function and places the answer in its output queue. The answer remains in the output queue until it is read, or, until another command is issued. When read, the message is transmitted across the bus to the designated listener (typically a controller). The input statement for receiving a response message from an logic analyzer’s output queue usually has two parameters: the device address and a format specification for handling the response message.

All results for queries sent in a program message must be read before another program message is sent. For example, when you send the query :MACHINE1:ASSIGN?, you must follow that query with an input statement. In BASIC, this is usually done with an ENTER statement.

The format for handling the response messages is dependent on both the controller and the programming language.

Example To read the result of the query command :SYSTEM:LONGFORM? you can

execute this BASIC statement to enter the current setting for the long form command in the numeric variable Setting.

ENTER XXX; Setting

1–15

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Response Header Options

The format of the returned ASCII string depends on the current settings of the SYSTEM HEADER and LONGFORM commands. The general format is

<instruction_header><space><data><terminator>

The header identifies the data that follows (the parameters) and is controlled by issuing a :SYSTEM:HEADER ON/OFF command. If the state of the header command is OFF, only the data is returned by the query.

The format of the header is controlled by the :SYSTEM:LONGFORM ON/OFF command. If long form is OFF , the header will be in its short form and the header will vary in length, depending on the particular query. The separator between the header and the data always consists of one space.

A command or query may be sent in either long form or short form, or in any combination of long form and short form. The HEADER and LONGFORM commands only control the format of the returned data, and, they have no affect on the way commands are sent.

Refer to chapter 11, "SYSTem Subsystem" for information on turning the HEADER and LONGFORM commands on and off.

Example The following examples show some possible responses for a

:MACHINE1:SFORMAT:THRESHOLD2? query: with HEADER OFF:

with HEADER ON and LONGFORM OFF:

:MACH1:SFOR:THR2<white_space><data><terminator>

with HEADER ON and LONGFORM ON:

:MACHINE1:SFORMAT:THRESHOLD2<white_space><data><terminator>

1–16

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Response Data Formats

Both numbers and strings are returned as a series of ASCII characters, as described in the following sections. Keywords in the data are returned in the same format as the header, as specified by the LONGform command. Like the headers, the keywords will always be in uppercase.

Example The following are possible responses to the MACHINE1: TFORMAT: LAB?

’ADDR’ query.

Header on; Longform on

MACHINE1:TFORMAT:LABEL "ADDR ",19,POSITIVE<terminator>

Header on;Longform off

MACH1:TFOR:LAB "ADDR ",19,POS<terminator>

Header off; Longform on

"ADDR ",19,POSITIVE<terminator>

Header off; Longform off

"ADDR ",19,POS<terminator>

Refer to the individual commands in Parts 2 and 3 of this guide for information on the format (alpha or numeric) of the data returned from each query.

1–17

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

String Variables

Because there are so many ways to code numbers, the Agilent Technologies 1670G-series logic analyzer handles almost all data as ASCII strings. Depending on your host language, you may be able to use other types when reading in responses.

Sometimes it is helpful to use string variables in place of constants to send instructions to the Agilent Technologies 1670G-series logic analyzer, such as, including the headers with a query response.

Example This example combines variables and constants in order to make it easier to

switch from MACHINE1 to MACHINE2. In BASIC, the & operator is used for string concatenation.

5 OUTPUT XXX;":SELECT 1" !Select the logic analyzer 10 LET Machine$ = ":MACHINE2" !Send all instructions to machine 2 20 OUTPUT XXX; Machine$ & ":TYPE STATE" !Make machine a state analyzer 30 ! Assign all labels to be positive 40 OUTPUT XXX; Machine$ & ":SFORMAT:LABEL ’CHAN 1’, POS" 50 OUTPUT XXX; Machine$ & ":SFORMAT:LABEL ’CHAN 2’, POS" 60 OUTPUT XXX; Machine$ & ":SFORMAT:LABEL ’OUT’, POS" 99 END

If you want to observe the headers for queries, you must bring the returned data into a string variable. Reading queries into string variables requires little attention to formatting.

Example This command line places the output of the query in the string variable

Result$.

ENTER XXX;Result$

In the language used for this book (HP BASIC 6.2), string variables are casesensitive and must be expressed exactly the same each time they are used.

1–18

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Numeric Base

The output of the logic analyzer may be numeric or character data depending on what is queried. Refer to the specific commands, in Parts 2 and 3 of this guide, for the formats and types of data returned from queries.

Example The following example shows logic analyzer data being returned to a string

variable with headers off:

10 OUTPUT XXX;":SYSTEM:HEADER OFF" 20 DIM Rang$[30] 30 OUTPUT XXX;":MACHINE1:TWAVEFORM:RANGE?" 40 ENTER XXX;Rang$ 50 PRINT Rang$ 60 END

After the program runs, the controller displays: +1.00000E-05

Numeric Base

Most numeric data will be returned in the same base as shown onscreen. When the prefix #B precedes the returned data, the value is in the binary base. Likewise, #Q is the octal base and #H is the hexadecimal base. If no prefix precedes the returned numeric data, then the value is in the decimal base.

Numeric Variables

If your host language can convert from ASCII to a numeric format, then you can use numeric variables. Turning off the response headers will help you avoid accidentally trying to convert the header into a number.

Example The following example shows logic analyzer data being returned to a numeric

variable.

10 OUTPUT XXX;":SYSTEM:HEADER OFF" 20 OUTPUT XXX;":MACHINE1:TWAVEFORM:RANGE?" 30 ENTER XXX;Rang 40 PRINT Rang 50 END

1–19

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Definite-Length Block Response Data

This time the format of the number (such as, whether or not exponential notation is used) is dependent upon your host language. The output will resemble 1.E-5 in BASIC.

Definite-Length Block Response Data

Definite-length block response data, also referred to as block data, allows any type of device-dependent data to be transmitted over the system interface as a series of data bytes. Definite-length block data is particularly useful for sending large quantities of data, or, for sending 8-bit extended ASCII codes. The syntax is a pound sign ( # ) followed by a non-zero digit representing the number of digits in the decimal integer. Following the non zero digit is the decimal integer that states the number of 8-bit data bytes to follow. This number is followed by the actual data.

Indefinite-length block data is not supported on the Agilent Technologies 1670G-series logic analyzer.

For example, for transmitting 80 bytes of data, the syntax would be:

Figure 1-2

Definite-Length Block Response Data

The "8" states the number of digits that follow, and "00000080" states the number of bytes to be transmitted, which is 80.

1–20

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Multiple Queries

You can send multiple queries to the logic analyzer within a single program message, but you must also read them back within a single program message. This can be accomplished by either reading them back into a string variable or into multiple numeric variables.

Example You can read the result of the query :SYSTEM:HEADER?;LONGFORM? into

the string variable Results$ with the command:

ENTER XXX; Results$

When you read the result of multiple queries into string variables, each response is separated by a semicolon.

Example The response of the query :SYSTEM:HEADER?:LONGFORM? with HEADER

and LONGFORM turned on is:

:SYSTEM:HEADER 1;:SYSTEM:LONGFORM 1

If you do not need to see the headers when the numeric values are returned, then you could use numeric variables. When you are receiving numeric data into numeric variables, the headers should be turned off. Otherwise the headers may cause misinterpretation of returned data.

Example The following program message is used to read the query

:SYSTEM:HEADERS?;LONGFORM? into multiple numeric variables:

ENTER XXX; Result1, Result2

1–21

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Instrument Status

Status registers track the current status of the logic analyzer. By checking the instrument status, you can find out whether an operation has been completed, whether the instrument is receiving triggers, and more. Chapter 6, "Status Reporting," explains how to check the status of the instrument.

1–22

Programming Over GPIB

Introduction

This section describes the GPIB interface functions and some general concepts of GPIB. In general, these functions are defined by IEEE

488.1 (GPIB bus standard). They deal with general bus management issues, as well as messages which can be sent over the bus as bus commands.

2–2

Programming Over GPIB

Interface Capabilities

The interface capabilities of the Agilent 1670G-series logic analyzer, as defined by IEEE 488.1 are SH1, AH1, T5, TE0, L3, LE0, SR1, RL1, PP0, DC1, DT1, C0, and E2.

Command and Data Concepts

GPIB has two modes of operation: command mode and data mode. The bus is in command mode when the ATN line is true. The command mode is used to send talk and listen addresses and various bus commands, such as a group execute trigger (GET). The bus is in the data mode when the ATN line is false. The data mode is used to convey device-dependent messages across the bus. These device-dependent messages include all of the instrument commands and responses found in chapters 8 through 27 of this manual.

Addressing

By attaching the logic analyzer printer or controller to the GPIB Port, you automatically place the GPIB interface in "talk-only" or "talk/listen" mode. Talk only mode must be used when you want the logic analyzer to talk directly to a printer without the aid of a controller. Addressed talk/listen mode is used when the logic analyzer will operate in conjunction with a controller. When the logic analyzer is in the addressed talk/listen mode, the following is true:

Each device on the GPIB resides at a particular address ranging from 0 to

•

30. The active controller specifies which devices will talk and which will listen.

•

An instrument, therefore, may be talk-addressed, listen-addressed, or

•

unaddressed by the controller.

2–3

Programming Over GPIB

Communicating Over the GPIB Bus (HP 9000 Series 200/300 Controller)

If the controller addresses the instrument to talk, it will remain configured to talk until it receives:

an interface clear message (IFC)

•

another instrument’s talk address (OTA)

•

its own listen address (MLA)

•

a universal untalk (UNT) command

•

If the controller addresses the instrument to listen, it will remain configured to listen until it receives:

an interface clear message (IFC)

•

its own talk address (MTA)

•

a universal unlisten (UNL) command

•

Communicating Over the GPIB Bus (HP 9000 Series 200/300 Controller)

Because GPIB can address multiple devices through the same interface card, the device address passed with the program message must include not only the correct instrument address, but also the correct interface code. The device address is calculated by multiplying the Interface Select Code by 100, and adding the instrument address.

Interface Select Code (Selects the Interface)

Each interface card has its own interface select code. This code is used by the controller to direct commands and communications to the proper interface. The default is always "7" for GPIB controllers.

Instrument Address (Selects the Instrument)

Each instrument on the GPIB port must have a unique instrument address between decimals 0 and 30. The device address passed with the program message must include not only the correct instrument address, but also the correct interface select code.

2–4

Programming Over GPIB

Local, Remote, and Local Lockout

Example For example, if the instrument address is 4 and the interface select code is 7,

the instruction will cause an action in the instrument at device address 704.

DEVICE ADDRESS = (Interface Select Code) × 100 + (Instrument Address)

Local, Remote, and Local Lockout

The local, remote, and remote with local lockout modes may be used for various degrees of front-panel control while a program is running. The logic analyzer will accept and execute bus commands while in local mode, and the front panel will also be entirely active. If the Agilent 1670G-series logic analyzer is in remote mode, the logic analyzer will go from remote to local with any front panel activity. In remote with local lockout mode, all controls (except the power switch) are entirely locked out. Local control can only be restored by the controller.

CAUTION

Cycling the power will restore local control, but this will also reset certain GPIB states. It also resets the logic analyzer to the power-on defaults and purges any acquired data in the acquisition memory.

The instrument is placed in remote mode by setting the REN (Remote Enable) bus control line true, and then addressing the instrument to listen. The instrument can be placed in local lockout mode by sending the local lockout (LLO) command (see :LOCKout in chapter 9, "Instrument Commands"). The instrument can be returned to local mode by either setting the REN line false, or sending the instrument the go to local (GTL) command.

2–5

Programming Over GPIB

Bus Commands

The following commands are IEEE 488.1 bus commands (ATN true). IEEE

488.2 defines many of the actions which are taken when these commands are received by the logic analyzer.

Device Clear

The device clear (DCL) or selected device clear (SDC) commands clear the input and output buffers, reset the parser, clear any pending commands, and clear the Request-OPC flag.

Group Execute Trigger (GET)

The group execute trigger command will cause the same action as the START command for Group Run: the instrument will acquire data for the active waveform and listing displays.

Interface Clear (IFC)

This command halts all bus activity. This includes unaddressing all listeners and the talker, disabling serial poll on all devices, and returning control to the system controller.

2–6

Programming Over RS-232-C

Introduction

This chapter describes the interface functions and some general concepts of RS-232-C. The RS-232-C interface on this instrument is Agilent’s implementation of EIA Recommended Standard RS-232-C, "Interface Between Data Terminal Equipment and Data Communications Equipment Employing Serial Binary Data Interchange." With this interface, data is sent one bit at a time, and characters are not synchronized with preceding or subsequent data characters. Each character is sent as a complete entity without relationship to other events.

3–2

Programming Over RS-232-C

Interface Operation

The Agilent 1670G-series logic analyzer can be programmed with a controller over RS-232-C using either a minimum three-wire or extended hardwire interface. The operation and exact connections for these interfaces are described in more detail in the following sections. When you are programming an Agilent 1670G-series over RS-232-C with a controller, you are normally operating directly between two DTE (Data Terminal Equipment) devices as compared to operating between a DTE device and a DCE (Data Communications Equipment) device.

When operating directly between two DTE devices, certain considerations must be taken into account. For a three-wire operation, XON/XOFF must be used to handle protocol between the devices. For extended hardwire operation, protocol may be handled either with XON/XOFF or by manipulating the CTS and RTS lines of the RS-232-C link. For both threewire and extended hardwire operation, the DCD and DSR inputs to the logic analyzer must remain high for proper operation.

With extended hardwire operation, a high on the CTS input allows the logic analyzer to send data, and a low disables the logic analyzer data transmission. Likewise, a high on the RTS line allows the controller to send data, and a low signals a request for the controller to disable data transmission. Because three-wire operation has no control over the CTS input, internal pull-up resistors in the logic analyzer assure that this line remains high for proper three-wire operation.

RS-232-C Cables

Selecting a cable for the RS-232-C interface depends on your specific application, and, whether you wish to use software or hardware handshake protocol. The following paragraphs describe which lines of the Agilent 1670G-series logic analyzer are used to control the handshake operation of the RS-232-C bus relative to the system. To locate the proper cable for your application, refer to the reference manual for your computer or controller. Your computer or controller manual should describe the exact handshake protocol your controller can use to operate over the RS-232-C bus. Also in this chapter you will find cable recommendations for hardware handshake.

3–3

Programming Over RS-232-C

Minimum Three-Wire Interface with Software Protocol

With a three-wire interface, the software (as compared to interface hardware) controls the data flow between the logic analyzer and the controller. The three-wire interface provides no hardware means to control data flow between the controller and the logic analyzer. Therefore, XON/OFF protocol is the only means to control this data flow. The three-wire interface provides a much simpler connection between devices since you can ignore hardware handshake requirements.

The communications software you are using in your computer/controller must be capable of using XON/XOFF exclusively in order to use three-wire interface cables. For example, some communications software packages can use XON/XOFF but are also dependent on the CTS and DSR lines being true to communicate.

The logic analyzer uses the following connections on its RS-232-C interface for three-wire communication:

Pin 7 SGND (Signal Ground)

•

Pin 2 TD (Transmit Data from logic analyzer)

•

Pin 3 RD (Receive Data into logic analyzer)

•

The TD (Transmit Data) line from the logic analyzer must connect to the RD (Receive Data) line on the controller. Likewise, the RD line from the logic analyzer must connect to the TD line on the controller. Internal pull-up resistors in the logic analyzer assure the DCD, DSR, and CTS lines remain high when you are using a three-wire interface.

Extended Interface with Hardware Handshake

With the extended interface, both the software and the hardware can control the data flow between the logic analyzer and the controller. This allows you to have more control of data flow between devices. The logic analyzer uses the following connections on its RS-232-C interface for extended interface communication:

3–4

Programming Over RS-232-C

Extended Interface with Hardware Handshake

Pin 7 SGND (Signal Ground)

•

Pin 2 TD (Transmit Data from logic analyzer)

•

Pin 3 RD (Receive Data into logic analyzer)

•

The additional lines you use depends on your controller’s implementation of the extended hardwire interface.

Pin 4 RTS (Request To Send) is an output from the logic analyzer which

•

can be used to control incoming data flow. Pin 5 CTS (Clear To Send) is an input to the logic analyzer which

•

controls data flow from the logic analyzer. Pin 6 DSR (Data Set Ready) is an input to the logic analyzer which

•

controls data flow from the logic analyzer within two bytes. Pin 8 DCD (Data Carrier Detect) is an input to the logic analyzer which

•

controls data flow from the logic analyzer within two bytes. Pin 20 DTR (Data Terminal Ready) is an output from the logic analyzer

•

which is enabled as long as the logic analyzer is turned on.

The RTS (Request To Send), is an output from the logic analyzer which can be used to control incoming data flow. A true on the RTS line allows the controller to send data and a false signals a request for the controller to disable data transmission.

The CTS (Clear To Send), DSR (Data Set Ready), and DCD (Data Carrier Detect) lines are inputs to the logic analyzer, which control data flow from the logic analyzer. Internal pull-up resistors in the logic analyzer assure the DCD and DSR lines remain high when they are not connected. If DCD or DSR are connected to the controller, the controller must keep these lines along with the CTS line high to enable the logic analyzer to send data to the controller. A low on any one of these lines will disable the logic analyzer data transmission. Pulling the CTS line low during data transmission will stop logic analyzer data transmission immediately. Pulling either the DSR or DCD line low during data transmission will stop logic analyzer data transmission, but as many as two additional bytes may be transmitted from the logic analyzer.

3–5

Figure 3-1

Programming Over RS-232-C

Cable Examples

HP 9000 Series 300

Figure 3-1 is an example of how to connect the Agilent 1670G-series to the HP 98628A interface card of an HP 9000 series 300 controller. For more information on cabling, refer to the reference manual for your specific controller.

Because this example does not have the correct connections for hardware handshake, you must use the XON/XOFF protocol when connecting the logic analyzer.

Cable Example

HP Vectra Personal Computers and Compatibles

Figures 3-2 through 3-4 give examples of three cables that will work for the extended interface with hardware handshake. Keep in mind that these cables should work if your computer’s serial interface supports the four common RS-232-C handshake signals as defined by the RS-232-C standard. The four common handshake signals are Data Carrier Detect (DCD), Data Terminal Ready (DTR), Clear to Send (CTS), and Ready to Send (RTS).

Figure 3-2 shows the schematic of a 25-pin female to 25-pin male cable. The following cables support this configuration:

17255D, DB-25(F) to DB-25(M), 1.2 meter

•

17255F, DB-25(F) to DB-25(M), 1.2 meter, shielded.

•

In addition to the female-to-male cables with this configuration, a male-to-male cable 1.2 meters in length is also available:

17255M, DB-25(M) to DB-25(M), 1.2 meter

•

3–6

Figure 3-2

Programming Over RS-232-C

Cable Examples

25-pin (F) to 25-pin (M) Cable

Figure 3-3 shows the schematic of a 25-pin male to 25-pin male cable 5 meters in length. The following cable supports this configuration:

13242G, DB-25(M) to DB-25(M), 5 meter

•

Figure 3-3

25-pin (M) to 25-pin (M) Cable

3–7

Figure 3-4

Programming Over RS-232-C

Configuring the Logic Analyzer Interface

Figure 3-4 shows the schematic of a 9-pin female to 25-pin male cable. The following cables support this configuration:

24542G, DB-9(F) to DB-25(M), 3 meter

•

24542H, DB-9(F) to DB-25(M), 3 meter, shielded

•

45911-60009, DB-9(F) to DB-25(M), 1.5 meter

•

9-pin (F) to 25-pin (M) Cable

Configuring the Logic Analyzer Interface

The RS-232-C menu field in the System External I/O menu allows you access to the RS-232-C Settings menu where the RS-232-C interface is configured. If you are not familiar with how to configure the RS-232-C interface, refer to the Agilent 1670G-Series Logic Analyzers User’s Guide.

3–8

Programming Over RS-232-C

Interface Capabilities

The baud rate, stopbits, parity, protocol, and databits must be configured exactly the same for both the controller and the logic analyzer to properly communicate over the RS-232-C bus. The RS-232-C interface capabilities of the Agilent 1670G-series logic analyzer are listed below:

Baud Rate: 110, 300, 600, 1200, 2400, 4800, 9600, or 19.2k

•

Stop Bits: 1, 1.5, or 2

•

Parity: None, Odd, or Even

•

Protocol: None or Xon/Xoff

•

Data Bits: 8

•

Protocol None With a three-wire interface, selecting None for the protocol does

not allow the sending or receiving device to control data flow. No control over the data flow increases the possibility of missing data or transferring incomplete data.

With an extended hardwire interface, selecting None allows a hardware handshake to occur. With hardware handshake, the hardware signals control dataflow.

Xon/Xoff Xon/Xoff stands for Transmit On/Transmit Off. With this mode, the receiver (controller or logic analyzer) controls dataflow, and, can request that the sender (logic analyzer or controller) stop dataflow. By sending XOFF (ASCII 19) over its transmit data line, the receiver requests that the sender disables data transmission. A subsequent XON (ASCII 17) allows the sending device to resume data transmission.

Data Bits

Data bits are the number of bits sent and received per character that represent the binary code of that character. Characters consist of either 7 or 8 bits, depending on the application. The Agilent 1670G-series supports 8 bit only.

8-Bit Mode Information is usually stored in bytes (8 bits at a time). With 8-bit mode, you can send and receive data just as it is stored, without the need to convert the data.

3–9

Programming Over RS-232-C

RS-232-C Bus Addressing

The controller and the Agilent 1670G-series logic analyzer must be in the same bit mode to properly communicate over the RS-232-C. This means that the controller must have the capability to send and receive 8-bit data.

See Also For more information on the RS-232-C interface, refer to the Agilent

1670G-Series Logic Analyzers User’s Guide. For information on RS-232-C voltage levels and connector pinouts, refer to the Agilent 1670G-Series Logic Analyzers Service Guide.

RS-232-C Bus Addressing

The RS-232-C address you must use is dependent on the computer or controller you are using to communicate with the logic analyzer.

HP Vectra Personal Computers or compatibles

If you are using an HP Vectra Personal Computer or compatible, it must have an unused serial port to which you connect the logic analyzer’s RS-232-C port. The proper address for the serial port is dependent on the hardware configuration of your computer. Additionally, your communications software must be configured to address the proper serial port. Refer to your computer and communications software manuals for more information on setting up your serial port address.

HP 9000 Series 300 Controllers

Each RS-232-C interface card for the HP 9000 Series 300 controller has its own interface select code. This code is used by the controller for directing commands and communications to the proper interface by specifying the correct interface code for the device address.

Generally, the interface select code can be any decimal value between 0 and 31, except for those interface codes which are reserved by the controller for internal peripherals and other internal interfaces. This value can be selected through switches on the interface card. For example, if your RS-232-C interface select code is 9, the device address required to communicate over the RS-232-C bus is 9. For more information, refer to the reference manual for your interface card or controller.

3–10

Programming Over RS-232-C

Lockout Command

To lockout the front-panel controls, use the instrument command LOCKout. When this function is on, all controls (except the power switch) are entirely locked out. Local control can only be restored by sending the :LOCKout OFF command.

Cycling the power will also restore local control, but this will also reset

CAUTION

See Also For more information on the LOCKout command see chapter 9, "Instrument

certain RS-232-C states. It also resets the logic analyzer to the power-on defaults and purges any acquired data in the acquisition memory of all the installed modules.

Commands."

3–11

3–12

Programming and Documentation Conventions

Introduction

This chapter covers the programming conventions used in programming the instrument, as well as the documentation conventions used in this manual. This chapter also contains a detailed description of the command tree and command tree traversal.

4–2

Programming and Documentation Conventions

Truncation Rule

The truncation rule for the keywords used in headers and parameters is: If the long form has four or fewer characters, there is no change in the short

form. When the long form has more than four characters the short form is just the first four characters, unless the fourth character is a vowel. In that case only the first three characters are used.

There are some commands that do not conform to the truncation rule by design. These will be noted in their respective description pages.

Some examples of how the truncation rule is applied to various commands are shown in table 4-1.

Table 4-1

Truncation Examples

Long Form Short Form

OFF OFF DATA DATA START STAR LONGFORM LONG DELAY DEL ACCUMULATE ACC

4–3

Programming and Documentation Conventions

Infinity Representation

The representation of infinity is 9.9E+37 for real numbers and 32767 for integers. This is also the value returned when a measurement cannot be made.

Sequential and Overlapped Commands

IEEE 488.2 makes the distinction between sequential and overlapped commands. Sequential commands finish their task before the execution of the next command starts. Overlapped commands run concurrently; therefore, the command following an overlapped command may be started before the overlapped command is completed. The overlapped commands for the Agilent 1670G-series logic analyzers are STARt and STOP.

Response Generation

IEEE 488.2 defines two times at which query responses may be buffered. The first is when the query is parsed by the instrument and the second is when the controller addresses the instrument to talk so that it may read the response. The Agilent 1670G-series logic analyzers will buffer responses to a query when it is parsed.

Syntax Diagrams

At the beginning of each chapter in Parts 2 and 3, "Commands," is a syntax diagram showing the proper syntax for each command. All characters contained in a circle or oblong are literals, and must be entered exactly as shown. Words and phrases contained in rectangles are names of items used with the command and are described in the accompanying text of each command. Each line can only be entered from one direction as indicated by the arrow on the entry line. Any combination of commands and arguments that can be generated by following the lines in the proper direction is syntactically correct. An argument is optional if there is a path around it. When there is a rectangle which contains the word "space," a white space character must be entered. White space is optional in many other places.

4–4

Programming and Documentation Conventions

Notation Conventions and Definitions

The following conventions are used in this manual when describing programming rules and example.

< > Angular brackets enclose words or characters that are used to symbolize a

program code parameter or a bus command

::= "is defined as." For example, A ::= B indicates that A can be replaced by B in

any statement containing A.

| "or." Indicates a choice of one element from a list. For example, A | B

indicates A or B, but not both.

... An ellipsis (trailing dots) is used to indicate that the preceding element may

be repeated one or more times.

[ ] Square brackets indicate that the enclosed items are optional.

{ } When several items are enclosed by braces and separated by vertical bars (|),

one, and only one, of these elements must be selected.

XXX Three Xs after an ENTER or OUTPUT statement represent the device

address required by your controller.

<NL> Linefeed (ASCII decimal 10).

The Command Tree

The command tree (figure 4-1) shows all commands in the Agilent 1670G-series logic analyzers and the relationship of the commands to each other. Parameters are not shown in this figure. The command tree allows you to see what the Agilent 1670G-series parser expects to receive. All legal headers can be created by traversing down the tree, adding keywords until the end of a branch has been reached.

4–5

Programming and Documentation Conventions

Tree Traversal Rules

Command Types

As shown in chapter 1, in the topic, "Header Types," there are three types of headers. Each header has a corresponding command type. This section shows how they relate to the command tree.

System Commands The system commands reside at the top level of the command tree. These commands are always parsable if they occur at the beginning of a program message, or are preceded by a colon. START and STOP are examples of system commands.

Subsystem Commands Subsystem commands are grouped together under a common node of the tree, such as the MMEMORY commands.

Common Commands Common commands are independent of the tree, and do not affect the position of the parser within the tree. *CLS and *RST are examples of common commands.

Tree Traversal Rules

Command headers are created by traversing down the command tree. For each group of keywords not separated by a branch, one keyword must be selected. As shown on the tree, branches are always preceded by colons. Do not add spaces around the colons. The following two rules apply to traversing the tree:

A leading colon (the first character of a header) or a <terminator> places the parser at the root of the command tree.

Executing a subsystem command places you in that subsystem until a leading colon or a <terminator> is found. The parser will stay at the colon above the keyword where the last header terminated. Any command below that point can be sent within the current program message without sending the keywords(s) which appear above them.

4–6

Programming and Documentation Conventions

Tree Traversal Rules

The following examples are written using HP BASIC 6.2. The quoted string is placed on the bus, followed by a carriage return and linefeed (CRLF). The three Xs (XXX) shown in this manual after an ENTER or OUTPUT statement represents the device address required by your controller.

Example 1 In this example, the colon between SYSTEM and HEADER is necessary since

SYSTEM:HEADER is a compound command. The semicolon between the HEADER command and the LONGFORM command is the required <program message unit separator> . The LONGFORM command does not need SYSTEM preceding it, since the SYSTEM:HEADER command sets the parser to the SYSTEM node in the tree.

OUTPUT XXX;":SYSTEM:HEADER ON;LONGFORM ON"

Example 2 In the first line of this example, the subsystem selector is implied for the

STORE command in the compound command. The STORE command must be in the same program message as the INITIALIZE command, since the <program message terminator> will place the parser back at the root of the command tree.

A second way to send these commands is by placing MMEMORY: before the

STORE command as shown in the fourth line of this example 2.

OUTPUT XXX;":MMEMORY:INITIALIZE;STORE ’FILE ’,’FILE DESCRIPTION’"

OUTPUT XXX;":MMEMORY:INITIALIZE" OUTPUT XXX;":MMEMORY:STORE ’FILE ’,’FILE DESCRIPTION’"

Example 3 In this example, the leading colon before SYSTEM tells the parser to go back

to the root of the command tree. The parser can then see the

SYSTEM:PRINT command.

OUTPUT XXX;":MMEM:CATALOG?;:SYSTEM:PRINT ALL"

4–7

Figure 4-1

Programming and Documentation Conventions

Tree Traversal Rules

Agilent 1670G-Series Command Tree

4–8

Figure 4-1 (continued)

Programming and Documentation Conventions

Tree Traversal Rules

Agilent 1670G-Series Command Tree (continued)

4–9

Programming and Documentation Conventions

Tree Traversal Rules

Table 4-2

Alphabetic Command Cross-Reference

Command Subsystem

ACCumulate SCHart, SWAVeform, TWAVeform,

ACQMode TFORmat ACQuisition STRigger, SWAVeform, TTRigger,

TWAVeform ARM MACHine ASSign MACHine AUToload MMEMory AUTorange TINTerval BASE SYMBol BEEPer Mainframe BRANch STRigger, TTRigger BUCKet OVERView CAPability Mainframe CARDcage Mainframe CATalog MMEMory CD MMEMory CENTer SWAVeform, TWAVeform CESE Mainframe CESR Mainframe CLEar COMPare, STRigger, TTRigger CLOCk SFORmat CLRPattern SLISt, SWAVeform, TLISt, TWAVeform CLRStat SWAVeform, TWAVeform CMASk COMPare COLumn SLISt, TLISt COPY COMPare, MMEMory DATA COMPare, SLISt, SYSTem, TLISt DELay SWAVeform, TWAVeform, WLISt DELete INTermodule DOWNload MMEMory DSP SYSTem EDGE TTRigger EOI Mainframe ERRor SYSTem FIND COMPare, STRigger, TTRigger GLEDge TTRigger HAXis SCHart HEADer SYSTem

Command Subsystem

HIGH OVERView HISTogram SPA, MODE HSTatistic HISTogram HTIMe INTermodule INITialize MMEMory INPort INTermodule INSert INTermodule, SWAVeform, TWAVeform,

WLISt

LABel SFORmat, TFORmat, OVERView,

HISTogram LER Mainframe LEVelarm MACHine LINE COMPare, SLISt, TLISt, WLISt LOAD MMEMory LOCKout Mainframe LONGform SYSTem LOW OVERView MACHine Mainframe MASTer SFORmat MENU COMPare, Mainframe MESE Mainframe MESR Mainframe MKDir MMEMory MLENgth STRigger, SWAVeform, SCHart, TTRigger,

TWAVeform MMEMory Mainframe MMODe SLISt, TLISt, TWAVeform MODE SFORmat, SPA MOPQual SFORmat MQUal SFORmat MSI MMEMory NAME MACHine OCONdition TLISt, TWAVeform OMARker OVERView OPATtern SLISt, TLISt, TWAVeform OSEarch SLISt, TLISt, TWAVeform OSTate SLISt, TLISt, WLISt OTAG SLISt, TLISt OTHer HISTogram

4–10

Table 4-2 (continued)

Alphabetic Command Cross-Reference

Programming and Documentation Conventions

Tree Traversal Rules

Command Subsystem

OTIMe TWAVeform, WLISt OVERlay SLISt OVERView SPA OVSTatistic OVERView PACK MMEMory PATTern SYMBol PRINt SYSTem PURGe MMEMory PWD MMEMory RANGe COMPare, STRigger, SWAVeform,

SYMBol, TTRigger, TWAVeform, WLISt, HISTogram

REMove SFORmat, SLISt, SWAVeform, SYMBol,

TFORmat, TLISt, TWAVeform REName MACHine, MMEMory RESource MACHine RMODe Mainframe RTC Mainframe RUNTil COMPare, SLISt, TLISt, TWAVeform SELect Mainframe SEQuence STRigger, TTRigger SET COMPare SETColor Mainframe SETHold SFORmat SETup SYSTem SKEW INTermodule SLAVe SFORmat SOPQual SFORmat SPA Mainframe SPERiod TTRigger, TWAVeform SQUal SFORmat STARt Mainframe STOP Mainframe STORe MMEMory, STRigger TAG STRigger TAKenbranch STRigger, SWAVeform TAVerage SLISt, TLISt, TWAVeform TCONtrol STRigger, TTRigger TERM STRigger, TTRigger

Command Subsystem

THReshold SFORmat, TFORmat TIMER STRigger, TTRigger TINTerval SPA, MODE, TINTerval TMAXimum SLISt, TLISt, TWAVeform TMINimum SLISt, TLISt, TWAVeform TPOSition STRigger, SWAVeform, TTRigger,

TWAVeform TREE INTermodule TSTatistic TINTerval TTIMe INTermodule TTYPe HISTogram TYPE MACHine UPLoad MMEMory VAXis SCHart VOLume MMEMory VRUNs SLISt, TLISt, TWAVeform WIDTh SYMBol WLISt Mainframe XCONdition TLISt, TWAVeform XMARker OVERView XOTag SLISt, TLISt XOTime SLISt, TLISt, TWAVeform, WLISt XPATtern SLISt, TLISt, TWAVeform XSEarch SLISt, TLISt, TWAVeform XSTate SLISt, TLISt, WLISt XTAG SLISt, TLISt XTIMe TWAVeform, WLISt XWINdow Mainframe

4–11

Programming and Documentation Conventions

Command Set Organization

The command set for the Agilent 1670G-series logic analyzers is divided into 19 separate groups: common commands, system commands, and 17 sets of subsystem commands. Each of the 19 groups of commands is described in a separate chapter in Parts 2 and 3, "Commands." Each of the chapters contain a brief description of the subsystem, a set of syntax diagrams for those commands, and finally, the commands for that subsystem in alphabetical order. The commands are shown in the long form and short form using upper and lowercase letters. As an example AUToload indicates that the long form of the command is AUTOLOAD and the short form of the command is AUT. Each of the commands contain a description of the command, its arguments, and the command syntax.

Subsystems

There are 17 subsystems in this instrument. In the command tree (figure 4-1) they are shown as branches, with the node above showing the name of the subsystem. Only one subsystem may be selected at a time. At power on, the command parser is set to the root of the command tree; therefore, no subsystem is selected. The 17 subsystems in the Agilent 1670G-series logic analyzers are:

SYSTem - controls some basic functions of the instrument.

•

MMEMory - provides access to the disk drives.

•

INTermodule - provides access to the Intermodule bus (IMB).

•

MACHine - provides access to analyzer functions and subsystems.

•

WLISt - allows access to the mixed (timing/state) functions.

•

SFORmat - allows access to the state format functions.

•

STRigger - allows access to the state trigger functions.

•

SLISt - allows access to the state listing functions.

•

SWAVeform - allows access to the state waveforms functions.

•

SCHart - allows access to the state chart functions.

•

COMPare - allows access to the compare functions.

•

TFORmat - allows access to the timing format functions.

•

4–12

Programming and Documentation Conventions

Program Examples

TTRigger - allows access to the timing trigger functions.

•

TWAVeform - allows access to the timing waveforms functions.

•

TLISt - allows access to the timing listing functions.

•

SYMBol - allows access to the symbol specification functions.

•

SPA - allows access to the System Performance Analysis (SPA)

•

functions.

Program Examples

The program examples in the following chapters and chapter 28, "Programming Examples," were written on an HP 9000 Series 200/300 controller using the HP BASIC 6.2 language. The programs always assume a generic address for the Agilent 1670G-series logic analyzers of XXX.

In the examples, you should pay special attention to the ways in which the command and/or query can be sent. Keywords can be sent using either the long form or short form (if one exists for that word). With the exception of some string parameters, the parser is not case-sensitive. Uppercase and lowercase letters may be mixed freely. System commands like HEADer and LONGform allow you to dictate what forms the responses take, but they have no affect on how you must structure your commands and queries.

Example The following commands all set the timing waveform delay to 100 ms.

Keywords in long form, numbers using the decimal format.

OUTPUT XXX;":MACHINE1:TWAVEFORM:DELAY .1"

Keywords in short form, numbers using an exponential format.

OUTPUT XXX;":MACH1:TWAV:DEL 1E-1"

Keywords in short form using lowercase letters, numbers using a suffix.

OUTPUT XXX;":mach1:twav:del 100ms"

In these examples, the colon shown as the first character of the command is optional on the Agilent 1670G-series logic analyzer. The space between DELay and the argument is required.

4–13

4–14

Message Communication and System Functions

Introduction

This chapter describes the operation of instruments that operate in compliance with the IEEE 488.2 (syntax) standard. It is intended to give you enough basic information about the IEEE 488.2 standard to successfully program the logic analyzer. You can find additional detailed information about the IEEE 488.2 standard in ANSI/IEEE Std

488.2-1987, "IEEE Standard Codes, Formats, Protocols, and Common Commands."

The Agilent Technologies 1670G-series logic analyzer is designed to be compatible with other IEEE 488.2 compatible instruments. Instruments that are compatible with IEEE 488.2 must also be compatible with IEEE 488.1 (GPIB bus standard); however, IEEE

488.1 compatible instruments may or may not conform to the IEEE

488.2 standard. The IEEE 488.2 standard defines the message exchange protocols by which the instrument and the controller will communicate. It also defines some common capabilities, which are found in all IEEE 488.2 instruments. This chapter also contains a few items which are not specifically defined by IEEE 488.2, but deal with message communication or system functions.

The syntax and protocol for RS-232-C program messages and response messages for the 1670G-series logic analyzer are structured very similarly to those described by 488.2. In most cases, the same structure shown in this chapter for 488.2 also works for RS-232-C. Because of this, no additional information has been included for RS-232-C.

5–2

Message Communication and System Functions

Protocols

The protocols of IEEE 488.2 define the overall scheme used by the controller and the instrument to communicate. This includes defining when it is appropriate for devices to talk or listen, and what happens when the protocol is not followed.

Functional Elements

Before proceeding with the description of the protocol, a few system components should be understood.

Input Buffer The input buffer of the instrument is the memory area where commands and queries are stored prior to being parsed and executed. It allows a controller to send a string of commands to the instrument which could take some time to execute, and then proceed to talk to another instrument while the first instrument is parsing and executing commands.

Output Queue The output queue of the instrument is the memory area where all output data (<response messages>) are stored until read by the controller.

Parser The instrument’s parser is the component that interprets the commands sent to the instrument and decides what actions should be taken. "Parsing" refers to the action taken by the parser to achieve this goal. Parsing and executing of commands begins when either the instrument recognizes a <program message terminator> (defined later in this chapter) or the input buffer becomes full. If you wish to send a long sequence of commands to be executed and then talk to another instrument while they are executing, you should send all the commands before sending the <program message terminator>.

5–3

Message Communication and System Functions

Protocols

Protocol Overview

The instrument and controller communicate using <program message>s and <response message>s. These messages serve as the containers into which sets of program commands or instrument responses are placed.

<program message>s are sent by the controller to the instrument, and <response message>s are sent from the instrument to the controller in response to a query message. A <query message> is defined as being a <program message> which contains one or more queries. The instrument

will only talk when it has received a valid query message, and therefore has something to say. The controller should only attempt to read a response after sending a complete query message, but before sending another <program message>. The basic rule to remember is that the instrument will only talk when prompted to, and it then expects to talk before being told to do something else.

Protocol Operation

When the instrument is turned on, the input buffer and output queue are cleared, and the parser is reset to the root level of the command tree.

The instrument and the controller communicate by exchanging complete <program message>s and <response message>s. This means that the controller should always terminate a <program message> before attempting to read a response. The instrument will terminate <response message>s except during a hardcopy output.

If a query message is sent, the next message passing over the bus should be the <response message>. The controller should always read the complete <response message> associated with a query message before sending another <program message> to the same instrument.

The instrument allows the controller to send multiple queries in one query message. This is referred to as sending a "compound query." As will be noted later in this chapter, multiple queries in a query message are separated by semicolons. The responses to each of the queries in a compound query will also be separated by semicolons.

Commands are executed in the order they are received.

5–4

Message Communication and System Functions

Syntax Diagrams

Protocol Exceptions

If an error occurs during the information exchange, the exchange may not be completed in a normal manner. Some of the protocol exceptions are shown below.

Command Error A command error will be reported if the instrument detects a syntax error or an unrecognized command header.

Execution Error An execution error will be reported if a parameter is found to be out of range, or if the current settings do not allow execution of a requested command or query.

Device-specific Error A device-specific error will be reported if the instrument is unable to execute a command for a strictly device dependent reason.

Query Error A query error will be reported if the proper protocol for reading a query is not followed. This includes the interrupted and unterminated conditions described in the following paragraphs.

Syntax Diagrams

The example syntax diagram is in this chapter are similar to the syntax diagrams in the IEEE 488.2 specification. Commands and queries are sent to the instrument as a sequence of data bytes. The allowable byte sequence for each functional element is defined by the syntax diagram that is shown.

The allowable byte sequence can be determined by following a path in the syntax diagram. The proper path through the syntax diagram is any path that follows the direction of the arrows. If there is a path around an element, that element is optional. If there is a path from right to left around one or more elements, that element or those elements may be repeated as many times as desired.

5–5

Figure 5-1

Message Communication and System Functions

Syntax Diagrams

Example Syntax Diagram

5–6

Message Communication and System Functions

Syntax Overview

This overview is intended to give a quick glance at the syntax defined by IEEE 488.2. It will help you understand many of the things about the syntax you need to know.

IEEE 488.2 defines the blocks used to build messages which are sent to the instrument. A whole string of commands can therefore be broken up into individual components.

Figure 5-1 is an example syntax diagram and figure 5-2 shows a breakdown of an example <program message>. There are a few key items to notice:

A semicolon separates commands from one another. Each <program

•

message unit> serves as a container for one command. The <program message unit>s are separated by a semicolon.

A <program message> is terminated by a <NL> (new line). The

•

recognition of the <program message terminator>, or <PMT>, by the parser serves as a signal for the parser to begin execution of commands. The <PMT> also affects command tree traversal (Chapter 4, "Programming and Documentation Conventions").

Multiple data parameters are separated by a comma.

•

The first data parameter is separated from the header with one or more

•

spaces. The header MACHINE1:ASSIGN 2,3 is an example of a compound header.

•

It places the parser in the machine subsystem until the <NL> is encountered.

A colon preceding the command header returns you to the top of the

•

command tree.

5–7

Figure 5-2

Message Communication and System Functions

Syntax Overview

<program message> Parse Tree

5–8

Message Communication and System Functions

Syntax Overview

Upper/Lower Case Equivalence

Upper and lower case letters are equivalent. The mnemonic SINGLE has the same semantic meaning as the mnemonic single.

<white space> is defined to be one or more characters from the ASCII set of 0 - 32 decimal, excluding 10 decimal (NL). <white space> is used by several instrument listening components of the syntax. It is usually optional, and can be used to increase the readability of a program.

Suffix Multiplier The suffix multipliers that the instrument will accept are shown in table 5-1.

Table 5-1

Value Mnemonic

1E18 EX 1E15 PE 1E12 T 1E9 G 1E6 MA 1E3 K 1E-3 M 1E-6 U 1E-9 N 1E-12 P 1E-15 F 1E-18 A

5–9

Table 5-2

Message Communication and System Functions

Syntax Overview

Suffix Unit The suffix units that the instrument will accept are shown in table 5-2.

Suffix Referenced Unit

V Volt S Second

5–10

Status Reporting

Introduction

Status reporting allows you to use information about the instrument in your programs, so that you have better control of the measurement process. For example, you can use status reporting to determine when a measurement is complete, thus controlling your program, so that it does not get ahead of the instrument. This chapter describes the status registers, status bytes and status bits defined by IEEE

488.2 and discusses how they are implemented in the Agilent 1670G-series logic analyzers. Also in this chapter is a sample set of steps you use to perform a serial poll over GPIB.

The status reporting feature available over the bus is the serial poll. IEEE 488.2 defines data structures, commands, and common bit definitions. There are also instrument-defined structures and bits.

The bits in the status byte act as summary bits for the data structures residing behind them. In the case of queues, the summary bit is set if the queue is not empty. For registers, the summary bit is set if any enabled bit in the event register is set. The events are enabled via the corresponding event enable register. Events captured by an event register remain set until the register is read or cleared. Registers are read with their associated commands. The *CLS command clears all event registers and all queues except the output queue. If *CLS is sent immediately following a <pr ogra m me ssag e term inat or >, the output queue will also be cleared.

6–2

Figure 6-1

Status Reporting

Status Byte Structures and Concepts

6–3

Status Reporting

Event Status Register

The Event Status Register is an IEEE 488.2-defined register. The bits in this register are latched. Once an event happens which sets a bit, that bit will only be cleared if the register is read.

Service Request Enable Register

The Service Request Enable Register is an 8-bit register. Each bit enables the corresponding bit in the status byte to cause a service request. The sixth bit does not logically exist and is always returned as a zero. To read and write to this register, use the *SRE? and *SRE commands.

Bit Definitions

The following mnemonics are used in figure 6-1 and in chapter 8, "Common Commands":

MAV - message available

Indicates whether there is a response in the output queue.

ESB - event status bit

Indicates if any of the conditions in the Standard Event Status Register are set and enabled.

MSS - master summary status

Indicates whether the device has a reason for requesting service. This bit is returned for the *STB? query.

RQS - request service

Indicates if the device is requesting service. This bit is returned during a serial poll. RQS will be set to 0 after being read via a serial poll (MSS is not reset by *STB?).

6–4

Status Reporting

Bit Definitions

MSG - message

Indicates whether there is a message in the message queue (Not implemented in the Agilent 1670G-series logic analyzer).

PON - power on

Indicates power has been turned on.

URQ - user request

Always returns a 0 from the Agilent 1670G-series logic analyzer.

CME - command error

Indicates whether the parser detected an error.

The error numbers and strings for CME, EXE, DDE, and QYE can be read from a device-defined queue (which is not part of IEEE 488.2) with the query :SYSTEM:ERROR?.

EXE - execution error

Indicates whether a parameter was out of range, or inconsistent with current settings.

DDE - device specific error

Indicates whether the device was unable to complete an operation for device dependent reasons.

QYE - query error

Indicates whether the protocol for queries has been violated.

RQC - request control

Always returns a 0 from the Agilent 1670G-series logic analyzer.

OPC - operation complete

Indicates whether the device has completed all pending operations. OPC is controlled by the *OPC common command. Because this command can appear after any other command, it serves as a general-purpose operation complete message generator.

6–5

Status Reporting

Key Features

LCL - remote to local

Indicates whether a remote to local transition has occurred.

MSB - module summary bit

Indicates that an enable event in one of the status registers has occurred.

Key Features

A few of the most important features of Status Reporting are listed in the following paragraphs.

Operation Complete

The IEEE 488.2 structure provides one technique that can be used to find out if any operation is finished. The *OPC command, when sent to the instrument after the operation of interest, will set the OPC bit in the Standard Event Status Register. If the OPC bit and the RQS bit have been enabled, a service request will be generated. The commands that affect the OPC bit are the overlapped commands.

Example OUTPUT XXX;"*SRE 32 ; *ESE 1" !enables an OPC service

request

Status Byte

The Status Byte contains the basic status information which is sent over the bus in a serial poll. If the device is requesting service (RQS set), and the controller serial-polls the device, the RQS bit is cleared. The MSS (Master Summary Status) bit (read with *STB?) and other bits of the Status Byte are not be cleared by reading them. Only the RQS bit is cleared when read.

The Status Byte is cleared with the *CLS common command.

6–6

Figure 6-2

Status Reporting

Serial Poll

Service Request Enabling

Serial Poll

The Agilent 1670G-series logic analyzer supports the IEEE 488.1 serial poll feature. When a serial poll of the instrument is requested, the RQS bit is returned on bit 6 of the status byte.

6–7

Status Reporting

Serial Poll

Using Serial Poll (GPIB)

This example will show how to use the service request by conducting a serial poll of all instruments on the GPIB bus. In this example, assume that there are two instruments on the bus: a logic analyzer at address 7 and a printer at address 1.

The HP BASIC 6.2 program command for serial poll is

Stat = SPOLL(707) .

The address 707 is the address of the logic analyzer in the this example. The command for checking the printer is

Stat = SPOLL(701) because the

address of that instrument is 01 on bus address 7. This command reads the contents of the GPIB Status Register into the variable called Stat. At that time bit 6 of the variable Stat can be tested to see if it is set (bit 6 = 1).

The serial poll operation can be conducted in the following manner:

1 Enable interrupts on the bus. This allows the controller to see the

SRQ line.

2 Disable interrupts on the bus. 3 If the SRQ line is high (some instrument is requesting service) then

check the instrument at address 1 to see if bit 6 of its status register is high.

4 To check whether bit 6 of an instruments status register is high, use

the following BASIC statement: IF BIT (Stat, 6) THEN

5 If bit 6 of the instrument at address 1 is not high, then check the

instrument at address 7 to see if bit 6 of its status register is high.

6 As soon as the instrument with status bit 6 high is found check the

rest of the status bits to determine what is required.

The SPOLL(707) command causes much more to happen on the bus than simply reading the register. This command clears the bus automatically, addresses the talker and listener, sends SPE (serial poll enable) and SPD (serial poll disable) bus commands, and reads the data. For more information about serial poll, refer to your controller manual, and programming language reference manuals.

After the serial poll is completed, the RQS bit in the Status Byte Register will be reset if it was set. Once a bit in the Status Byte Register is set, it will remain set until the status is cleared with a *CLS command, or the instrument is reset.

6–8

Error Messages

Introduction

This chapter lists the error messages that are returned by the Agilent 1670G-series logic analyzers.

7–2

Agilent Technologies 1670G User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

In This Book

Table of Contents

General Information

Introduction to Programming the Agilent Technologies 1670G-Series Logic Analyzer

Talking to the Instrument

Initialization

Instruction Syntax

Output Command

Device Address

Instructions

Instruction Terminator

Header Types

Duplicate Keywords

Query Usage

Program Header Options

Parameter Data Types

Selecting Multiple Subsystems

Receiving Information from the Instrument

Response Header Options

Response Data Formats

String Variables

Numeric Base

Numeric Variables

Definite-Length Block Response Data

Multiple Queries

Instrument Status

Programming Over GPIB

Interface Capabilities

Command and Data Concepts

Addressing

Local, Remote, and Local Lockout

Bus Commands

Programming Over RS-232-C

Interface Operation

RS-232-C Cables

Minimum Three-Wire Interface with Software Protocol

Extended Interface with Hardware Handshake

Cable Examples

Configuring the Logic Analyzer Interface

Interface Capabilities

RS-232-C Bus Addressing

Lockout Command

Programming and Documentation Conventions

Truncation Rule

Infinity Representation

Sequential and Overlapped Commands

Response Generation

Syntax Diagrams

Notation Conventions and Definitions

The Command Tree

Tree Traversal Rules

Command Set Organization

Subsystems

Program Examples

Message Communication and System Functions

Protocols

Syntax Diagrams

Syntax Overview

Status Reporting

Event Status Register

Service Request Enable Register

Bit Definitions

Key Features

Serial Poll

Error Messages
