1.1 Product Description
The Adept SmartController EX motion controller is a member of Adept’s family of high-performance distributed motion controllers. The Adept SmartController EX motion controller is
designed for use with Adept Python Linear Modules, Adept Cobra s-series robots, the Adept
Viper line of six-axis robots, the Adept sMI6 Module for the SmartMotion product, Adept
SmartServo kits, and Adept Quattro robots.
Chapter 1: Introduction
Figure 1-1. Adept SmartController EX Motion Controller
sDIO Module Expansion Module
The sDIO module expansion module provides 32 optical-isolated digital inputs, 32 optical-isolated outputs, and an IEEE 1394 interface.
Customers can access I/O signals from the following points using these products:
l
the XDIO connector on an Adept SmartController EX motion controller
l
the DeviceNet connector on an Adept SmartController EX motion controller
l
the DIO X1 - X4 connectors on an sDIO module
Optional Adept T20 Pendant
The optional Adept T20 pendant provides a user interface and teach pendant in an ergonomic
and rugged package. The pendant is designed for right- or left-handed use. All gripping and
holding positions enable comfortable and fatigue-free operation.
Adept SmartController EX User’s Guide, Rev. B
Page 9 of 96
Chapter 1: Introduction
The safety features include:
l
Emergency-stop switch (dual channel circuit)
l
3-position enable switch (dual channel circuits)
See the Adept T20 pendant User’s Guide, shipped with each pendant, for complete information
on the product.
Figure 1-2. Adept T20 Pendant
1.2 Dangers, Warnings, Cautions, and Notes in Manual
There are six levels of special alert notation that may be used in Adept manuals. In descending order of importance, they are:
Adept SmartController EX User’s Guide, Rev. B
Page 10 of 96
Chapter 1: Introduction
DANGER:This indicates an imminently hazardous electrical situation
which, if not avoided, will result in death or serious injury.
DANGER:This indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING:This indicates a potentially hazardous electrical situation
which, if not avoided, could result in serious injury or major damage to
the equipment.
WARNING:This indicates a potentially hazardous situation which, if not
avoided, could result in serious injury or major damage to the equipment.
NOTE:Notes provide supplementary information, emphasize a point or procedure, or give a tip
for easier operation.
1.3 Safety Precautions
l
All personnel who install, operate, teach, program, or maintain the system must read
this guide, read the Adept Robot Safety Guide, and complete a training course for their
responsibilities in regard to the system.
l
All personnel who design the robot system must read this guide, read the Adept Robot
Safety Guide, and must comply with all local and national safety regulations for the loca-
tion in which the system is installed.
l
The robot system must not be used for purposes other than described in the robot user’s
guide. Contact Adept if you are not sure of the suitability for your application.
CAUTION:This indicates a situation which, if not avoided, could result in
damage to the equipment.
DANGER:Adept robots can cause serious injury or death, or damage to
themselves and other equipment, if the following safety precautions are
not observed:
l
The user is responsible for providing safety barriers around the robot to prevent anyone
from accidentally coming into contact with the robot when it is in motion.
Adept SmartController EX User’s Guide, Rev. B
Page 11 of 96
Chapter 1: Introduction
l
Power to the robot and its power supply must be locked out and tagged out before any
maintenance is performed.
1.4 What to Do in an Emergency Situation
Press any E-Stop button (a red push-button on a yellow background/field) and then follow the
internal procedures of your company or organization for an emergency situation. If a fire
occurs, use CO2 to extinguish the fire.
1.5 Additional Safety Information
Adept provides other sources for more safety information:
Manufacturer’s Declaration of Compliance (MDOC)
This lists all standards with which each robot complies. See “Manufacturer’s Declaration” on
page 18.
Adept Robot Safety Guide
The Adept Robot Safety Guide provides detailed information on safety for Adept robots. It also
gives resources for more information on relevant standards.
It ships with each robot manual, and is also available from the Adept Document Library. See
"Adept Document Library ".
1.6 Manufacturer’s Declaration
The Manufacturer’s Declaration of Incorporation and Conformity for Adept robot systems can
be found on the Adept website, in the Download Center of the Support section.
http://www.adept.com/support/downloads/file-search
NOTE:The Download Center requires that you are logged in for access. If you are not logged in,
you will be redirected to the Adept website Login page, and then automatically returned to the
Download Center when you have completed the login process.
1.
From the Download Types drop-down list, select Manufacturer Declarations.
2.
From the Product drop-down list, select SmartControls.
3.
Click Begin Search.
The list of available documents is shown in the Search Results area, which opens at the
bottom of the page. You may need to scroll down to see it.
4.
Use the Description column to locate the document for your SmartController, and then
click the corresponding Download ID number to access the Download Details page.
5.
On the Download Details page, click Download to open or save the file.
Adept SmartController EX User’s Guide, Rev. B
Page 12 of 96
1.7 How Can I Get Help?
For details on getting assistance with your Adept software or hardware, you can access the following information sources on the Adept corporate website:
l
For contact information: http://www.adept.com/contact/americas
l
For product support information:
http://www.adept.com/support/service-and-support/main
l
For user discussions, support, and programming examples:
http://www.adept.com/forum/
l
For further information about Adept Technology, Inc.: http://www.adept.com
Related Manuals
This manual covers the installation and maintenance of an Adept SmartController EX motion
controller system, including the sDIO module. There are additional manuals that cover programming the system, reconfiguring installed components, and adding other optional components. The following manuals provide information on advanced configurations and system
specifications.
Chapter 1: Introduction
Table 1-1. Related Manuals
Manual Title Description
Adept Robot Safety Guide Contains safety information for Adept robots.
Adept T20 User’s Guide Contains information on the installation and operation of
the Adept T20 pendant.
Adept ACE User's Guide Describes installation and use of the Adept ACE software.
eV+ OS User Guide Describes the eV+ operating system, including disk file oper-
ations, monitor commands, and monitor command programs.
eV+ Language User's Guide Describes the eV+ language and programming of an Adept
control system.
1 The eV+ manuals are accessible through the Adept Document Library:
Document Library > V+>eV+ Document (preliminary) >[select a manual]
Adept Document Library
The Adept Document Library (ADL) contains documentation for Adept products. You can
access the ADL through either of the following methods:
l
Select Support > Document Library from the menu bar on the Adept website.
l
Type the following URL into your web browser:
http://www.adept.com/Main/KE/DATA/adept_search.htm
Adept SmartController EX User’s Guide, Rev. B
Page 13 of 96
Chapter 1: Introduction
To locate information on a specific topic, use the Document Library search engine on the ADL
main page.
Adept SmartController EX User’s Guide, Rev. B
Page 14 of 96
2.1 Controller Installation
This equipment must be shipped and stored in a temperature-controlled environment. See the
following table. It should be shipped and stored in the Adept-supplied packaging, which is
designed to prevent damage from normal shock and vibration. You should protect the package
from excess shock and vibration.
Ambient temperature 5° to 40° C (41° to 104° F)
Storage and shipment temperature –25° to +55° C (-13° to 131° F)
Humidity range 5 to 90%, non-condensing
Altitude up to 2000 m (6500 ft)
Chapter 2: Installation
Table 2-1. Environmental Specifications
Free space around controller (for proper cooling)
Chassis protection class IP-20 (NEMA Type 1)
10 mm at back, 13 mm on sides (0.4 in., 0.5
in.)
Before Unpacking
Carefully inspect all shipping containers for evidence of damage during transit. If any damage
is indicated, request that the carrier’s agent be present at the time the container is unpacked.
Upon Unpacking
Compare the actual items received (not just the packing slip) with your equipment purchase
order, and verify that all items are present and that the shipment is correct. Inspect each item
for external damage as it is removed from its container. Contact Adept immediately if any
damage is evident. For contact information, see How Can I Get Help? on page 13
Retain all containers and packaging materials. These items may be needed in the future to settle a damage claim.
Perform the following steps to unpack the Adept SmartController EX motion controller and
Front Panel, optional Adept sDIO module Expansion Module, and optional pendant. Refer to
the following sections for information on mounting the equipment.
1.
Remove the Adept SmartController EX motion controller and any optional sDIO module
from their boxes. Place them near the robot, or mount them in a rack. For details, see
Mounting the Adept SmartController EX Motion Controller on page 16.
2.
Remove the optional Front Panel from its box and set it on a flat surface near the Adept
SmartController EX motion controller.
Adept SmartController EX User’s Guide, Rev. B
Page 15 of 96
Chapter 2: Installation
3.
Remove the optional fromT20 pendant its box and place it on a flat surface near the
Front Panel.
Repacking for Relocation
If the controller needs to be relocated, reverse the steps in the installation procedure. Reuse all
original packing containers and materials and follow all safety notes used for installation.
Improper packaging for shipment will void your warranty.
Space Around the Chassis
When the Adept SmartController EX motion controller and/or sDIO module is installed, you
must allow 10 mm at the back of the unit and 13 mm on the sides of the unit for proper air
cooling.
Mounting the Adept SmartController EX Motion Controller
The following mounting options are available for the controller:
l
Rack
l
Panel
l
Table
l
Stack
The controller and compatible Adept units can be mounted with one unit placed on top
of another.
See Mounting the sDIO Module on page 61 for information on mounting the sDIO module.
NOTE:To maintain compliance with many standards, the mounting of the controller and all terminations at the controller must be performed in accordance with local and national regulations.
Rack-Mounting the Adept SmartController EX Motion Controller
To rack-mount the controller in a standard 19-inch equipment rack, install the optional mounting brackets on the side of the controller, as shown in the following figure. These brackets must
be ordered separately. They do not come with the controller.
Adept SmartController EX User’s Guide, Rev. B
Page 16 of 96
Chapter 2: Installation
3X M3 x 6MM
BOTH SIDES
3.8
19.1
2X 25.0
14.2
2X 40356-00004
88.1
44.4
21.8
3.6
TYP.
462.0
482.8
190.0
27.4
14.0
200.5
4X 40356-00000
8X M3 x 6MM
273.9
8.1
16.0
44.9
6.6 346.6
359.8
R3.6 TYP.
16.1
44.9
Figure 2-1. Rack-Mounting the Adept SmartController EX Motion Controller
Panel-Mounting the Adept SmartController EX Motion Controller
To panel-mount the controller, install two brackets on each side at the rear of the unit, as
shown in the following figure. Use the screws from the accessories kit.
Figure 2-2. Panel-Mounting the Adept SmartController EX Motion Controller
Adept SmartController EX User’s Guide, Rev. B
Page 17 of 96
Chapter 2: Installation
4X M3 x 6MM
BOTH SIDES
21.616.0
120.9
16.2
4X 40356-00001
120.9
29.5
391.8
378.6
24.9
R3.6
12.1
24.1
Table-Mounting the Adept SmartController EX Motion Controller
To table-mount the controller, install two brackets on each side near the bottom of the unit, as
shown in the following figure. These brackets must be ordered separately. They do not come
with the controller.
Figure 2-3. Table-Mounting the Adept SmartController EX Motion Controller
Stack-Mounting Components
To stack-mount the Adept SmartController EX Motion Controller and a compatible unit, such
as an Adept SmartVision EX vision controller, install two brackets on each side of the units, as
shown in the following figure. These brackets are supplied with compatible Adept units.
Adept SmartController EX User’s Guide, Rev. B
Page 18 of 96
Chapter 2: Installation
2X 40356-00002
BOTH SIDES
8X M3 x 6MM
BOTH SIDES
186.5
30.7
76.5
28.1 16.0
120.9
155.8
328.9
Figure 2-4. Stack-Mounting the Adept SmartController EX Motion Controller
Memory Card
The Adept SmartController EX motion controller is equipped with a Secure Digital™ (SD)
memory card. The SD card is removable, and can be moved to another Adept SmartController
EX motion controller for testing.
The SD card shipped with all systems is factory-configured and installed by Adept. The SD
card stores the eV+ operating system, application programs, data files, and Adept licenses.
Only the SD card supplied by Adept will work with the Adept SmartController EX motion controller.
NOTE:This SD card is not compatible with the SmartController CX or CS motion controllers.
CAUTION: Use suitable measures for eliminating electrostatic discharge
during removal and installation of the SD card. This includes, but is not
limited to, the use of a grounded wrist strap.
Adept SmartController EX User’s Guide, Rev. B
Page 19 of 96
Chapter 2: Installation
SD Card Slot
CAUTION: Do not remove the SD card when power is connected to the
controller.
Removing an SD Card
To remove an SD card from a Adept SmartController EX motion controller:
1.
Make sure that the controller is disconnected from its power source.
2.
Locate the SD compartment (see the following figure).
Figure 2-5. SD Memory Card Compartment
NOTE:If you are replacing an existing SD, the original must be sent to Adept for replacement.
3.
Press the SD card in, and release. The card will pop out.
Remove the card and return it to Adept. Contact Adept Customer Service.
Installing an SD Card
To install an SD card into a Adept SmartController EX motion controller:
1.
Make sure that the controller is powered off.
2.
Locate the SD card compartment (see the preceding figure).
3.
Carefully remove the SD card from the READ ME FIRST box or shipping container.
Position the card so its contacts are facing towards the controller and to the left. The
label will be facing to the right.
4.
Insert the SD card into the controller.
Once installed, Adept recommends that you do not repeatedly remove and insert the SD card.
Adept SmartController EX User’s Guide, Rev. B
Page 20 of 96
Chapter 2: Installation
Connecting Power
The Adept SmartController EX motion controller and sDIO module require filtered 24 VDC
power.
NOTE:Users must provide their own power supply. Make sure the power cables and power supply
conform to the specifications that follow.
24 VDC Power Specifications
Table 2-2. Specifications for 24 VDC User-Supplied Power Supply
User-Supplied Power
24 VDC (-10%, +5%), 120 W (5 A)
Supply
Circuit Protection Not more than 8 A (below the amper-
age rating of the cable used)
Power Cabling 1.5 - 1.85 mm2(16-14 AWG), full-
cover, braided shield cable, maximum
length 10 meters
Shield Termination Braided shield connected to the
marked frame ground screw on the
right side of the controller (near the
XDC connector). On the other end of
the cable, the shield should be connected to the power supply chassis.
Figure 2-6. User-Supplied 24 VDC Cable
Adept SmartController EX User’s Guide, Rev. B
Page 21 of 96
Chapter 2: Installation
-
+
-
+
User-Provided
Power Supply
24 VDC, 5 A
Optional
Fuse
Adept SmartController EX
Motion Controller
User-Supplied Shielded
Power Cable
Note: Use connector
supplied by Adept at
this end of cable.
Shield from cable
Star washer
M3 x 6 screw
Shield from cable to frame
ground on power supply
Circuit protection < 8A
Frame Ground
NOTE:The power requirements for the user-supplied power supply will vary depending on the
configuration of the Adept SmartController EX motion controller and connected devices. A minimum configuration of the controller, front panel, and pendant will require 2 A at 24 VDC. However, a 24 V, 5 A power supply is recommended to allow for additional current draw from
connected devices, such as external IEEE 1394 devices and digital I/O loads.
24 VDC Power Cabling
In order to maintain compliance with many standards, DC power must be delivered over a
shielded cable, with the shield connected to the frame ground at both ends of the cable, as
shown in the following figure. Conductors should be 1.5 mm2- 1.85 mm2(16 to 14 AWG) in
size. The maximum length for the 24 VDC cable is 10 meters.
Daisy-Chaining Power
Figure 2-7. User-Supplied Power Cable
The Adept SmartController EX motion controller is equipped with two DC power connectors.
These connectors allow the daisy-chaining of power from one controller to another or to an
sDIO module. When daisy-chaining power, the power supply circuit must be limited to the
lesser of 8 Amps or the ampacity of the cabling. This can be done with a circuit breaker or a
fuse. The DC power can be applied to either the XDC1 or XDC2 connector.
CAUTION: Use only one 24 VDC power supply per circuit. Failure to do
this could result in damage to the equipment.
CAUTION: The SmartVision EX vision controller has a higher current
demand and should be wired independently. Do not daisy-chain its
power from a Adept SmartController EX motion controller.
Adept SmartController EX User’s Guide, Rev. B
Page 22 of 96
Chapter 2: Installation
Grounding Point
NOTE:The power switch on the Adept SmartController EX motion controller will shut down both
the controller and the second 24 V port. If you want a secondary device to maintain power after
the controller is shut down, you will have to provide a separate power line to it.
Chassis Grounding
The Adept SmartController EX motion controller is equipped with a grounding point, as
shown in the following figure. Adept recommends connecting a ground wire from the ground
point on the controller to earth ground and that all other interconnected Adept components
share the same electrical ground potential. The ground wire must meet all local regulations.
Additional grounding information for other Adept products is provided in the documentation
for those products.
NOTE:The maximum length for the ground wire for the controller is 3 meters.
Figure 2-8. Chassis Grounding Point
The mounting of the controller and all terminations must be performed in accordance with
local and national regulations.
Installing 24 VDC Connectors
Use the Adept-supplied connector to connect the user-supplied 24 VDC power supply to the
Adept SmartController EX motion controller.
1.
Locate the 24 VDC connector that is shipped with the controller. See the following figure.
2.
Use 14 or 16 gauge wire to connect the 24 VDC power supply to the controller.
3.
Strip 7 mm of insulation from the end of the wire that connects to the positive output of
the 24 VDC supply.
4.
Insert the stripped end of the wire into the opening on the right side of the connector.
5.
Using a small, flat-blade screwdriver (2.5 mm), tighten the screw clamp on the connector.
6.
Visually inspect the connection to ensure that the clamp has closed on the wire, not on
the insulation.
Adept SmartController EX User’s Guide, Rev. B
Page 23 of 96
Chapter 2: Installation
7.
Gently pull on the wire to confirm that it is securely attached to the connector.
8.
Repeat this process to connect the wire from the negative side of the power supply to
the left side of the connector.
9.
Connect the braided shield to the ground screw on the front of the controller.
A ring lug can be used, as shown in the following figure. The ground screw is an M3.
Figure 2-9. 24 V Connector
NOTE:Although no damage will occur, the Adept SmartController EX motion controller will not
turn on if the DC polarities on the XDC connectors are reversed.
IEEE 1394 Cable Specifications
Adept supplies the IEEE 1394 cables to connect the Adept SmartController EX motion controller to other Adept devices in the system. If you need a cable of a different length than those
supplied by Adept, then you must purchase a cable from one of the Adept-approved vendors
listed below:
l
CEI: www.componentsexpress.com
l
Molex, Inc.: www.molex.com
These purchased cables must meet all specifications of the IEEE 1394 standard. Note that
Adept uses 6-pin to 6-pin cables. The maximum length for a 1394 cable is 10 meters. The 1394
Trade Association provides detailed specifications for 1394 cables and other related information. See www.1394ta.org.
Adept SmartController EX User’s Guide, Rev. B
Page 24 of 96
Chapter 2: Installation
WARNING:You must use cables from vendors approved by Adept that
meet all specifications of the IEEE 1394 standard. Using a non-approved
or inferior quality IEEE 1394 cable can cause unpredictable system performance.
2.2 System Cable Installation
The Adept SmartController EX motion controller is used in many Adept systems, including
Adept Python Linear Modules, Adept Cobra s-series robots, the Adept Viper line of six-axis
robots, Adept Quattro robots, and the Adept sMI6 Module for the SmartMotion product.
See your specific product manual for complete details on system cabling for your Adept SmartController system.
Adept SmartController EX User’s Guide, Rev. B
Page 25 of 96
3.1 Connectors and Indicators
1
2 4
7
9
10
11 188
3
5
6
12 13 14 15 16 17
Figure 3-1. SmartController EXConnectors and Indicators
All of the connectors on the Adept SmartController EX motion controller use standard-density
spacing, D-subminiature connectors. For customization purposes, the user needs to provide
connectors of the appropriate gender and pin count, or use optional Adept cables.
Chapter 3: Operation
1.
SD Card Slot
See Installing an SD Card on page 20.
2.
Top Three Status LEDs
The top three two-color LEDs indicate diagnostic test, power control, and communication status.
Table 3-1. Controller LEDs
LED Green Indicates Red Indicates
OK/SF
HPE/ES High Power Enabled E-Stop Open
FW/HD SmartServo Con-
During system bootup, the red OK/SF and HPE/ES LEDs are lit and the red
FW/HD LED blinks. After system bootup, the OK/SF LED should show green. If
the HPE/ES LED shows red, the E-Stop circuit is open. During SD card reads and
System OK System Fault
nection
Read/Write from SD
card
Adept SmartController EX User’s Guide, Rev. B
Page 27 of 96
Chapter 3: Operation
writes, the FW/HD LED pulses red. When a robot is connected on one of the
SmartServo ports, the FW/HD LED shows green
3. Bottom Three Status LEDs
The bottom three LEDs on the front of the Adept SmartController EX motion controller
give the following information about the status of the main controller.
O = Off G = Green R = Red
Table 3-2. LEDStatus Indicators
LED Display
1 2 3
Error
Number
Description
O-O-O 0 No error.
R-O-O 1 System clock is dead or too fast. Clock inter-
rupts are not being received.
O-R-O 2 Hardware configuration error.
O-O-R 4 Memory test failure. Free storage error.
O-R-R 6 Software serial I/O configuration error.
R-R-R 7 Initial display set by hardware before software
has started.
G-O-O 9 Transient display set when PCI is configured.
O-O-G C Uninitialized trap.
G-O-G D Bus error detected.
If the Adept SmartController EX motion controller displays an error, cycle the
power off, then on again. If the problem persists, contact Adept Customer Service.
4.
SW1 DIP switches
The definition for DIP switches on the Adept SmartController EX motion controller is as
follow:
Switch 1:
l
OFF: use IP address from configuration on SD card
l
ON: use default factory IP address (printed on the bottom of the controller)
Switch 2:
l
OFF: normal connection through Ethernet
l
ON: communication through RS-232 on the TERM port
Switch 3 and 4: reserved for future use; always leave in the OFF position.
In normal operation, all switches should be OFF.
Adept SmartController EX User’s Guide, Rev. B
Page 28 of 96
Chapter 3: Operation
5.
SmartServo 1.1, 1.2, and 1.3
These ports connect any Adept SmartServo-compatible product to the controller via the
IEEE-1394 cable. These ports are interchangeable - any one can be used.
WARNING:Remove power from the controller before plugging in or unplugging any IEEE-1394 cables to or from these
connectors. Failure to remove power could result in unpredictable behavior by the system.
6.
Ethernet (Eth 10/100/1000) connectors
The shielded RJ-45 receptacles support 10/100/1000 BaseT Ethernet communications.
The two ports are interchangeable.
NOTE:The default IP address for the controller is located on a label on the bottom side of the controller chassis.
7.
Fieldbus Module
This module is reserved for future use.
8.
USB port
This port is reserved for future use.
9.
RS-232-1 and RS-232-2 connectors
These are RS-232 serial ports for general use. See Installing the Adept ACE Software on
page 32 for more information.
10.
RS-232 and RS-422/485 connectors
These ports support RS-232 and RS-422/485 devices, respectively. See Installing the
Adept ACE Software on page 32 for pin descriptions and locations.
11.
DeviceNet connector
DeviceNet is a field bus for industrial devices. This standard supports a variety of products, including sensors, digital I/O, analog I/O, RS-232, and PLCs. Other DeviceNet product types, such as keypads and displays, can be controlled using the eV+ FCMD
program instruction (see the eV+ Language Reference Guide for details). See Adept DeviceNet on page 85.
12.
XDIO connector
This connector includes 20 signal pairs: 8 digital outputs (100 mA max) and 12 digital
inputs, all of which are fast inputs. The digital outputs are short-circuit protected. This
connector also supplies 24 VDC power for customer equipment. See Connecting UserSupplied Digital I/O Equipment on page 45 for more information.
13.
XUSR connector
Provides switch functions for emergency stop (E-Stop) and Manual/Automatic interfaces
to external push-buttons and other equipment. For example, an external E-Stop can be
Adept SmartController EX User’s Guide, Rev. B
Page 29 of 96
Chapter 3: Operation
connected to the XUSR connector. A line E-Stop from other equipment can be connected.
A muted safety gate that causes an E-Stop only in Automatic mode is included. Also
included are contacts to report the status of E-Stop push-buttons and the Manual/Automatic switch.
NOTE:The Adept SmartController EX motion controller ships with a terminator plug attached to
the XUSR connector. The terminator plug must be installed in the absence of any user-supplied
safety equipment used to close the E-Stop circuit. For more information about the XUSR connector, see Connecting User-Supplied Safety and Power-Control Equipment on page 36.
14.
XSYS connector
Connects to the XSLV connector on an Adept robot or servo controller.
15.
XFP connector
Connects to the optional Front Panel. See Connecting User-Supplied Safety and PowerControl Equipment on page 36 for information.
16.
XMCP connector
The optional Adept T20 pendant plugs into this connector, via the T20 adapter cable,
which has the mating connector for the XMCP connector. The controller ships with a terminator plug in the XMCP connector. The plug must be installed in the absence of a
pendant or the E-Stop circuit will remain open, and you will not be able to start the system.
17.
24 VDC connectors/switch
Connect power from a user-supplied 24 VDC power supply to the XDC1 connector (see
Connecting Power on page 21). If using an sDIO module or an sMI6 module, connect a
separate cable from the unused XDC connector on the controller to the XDC1 connector
on the sDIO module or sMI6 module.
An On/Off switch turns the controller and the second 24 VDC power jack on or off.
Any daisy-chained devices will be turned on or off with this switch.
A ground screw is located immediately below the 24 VDC power jacks.
18.
Belt Encoder connector
This is a 26-pin D-Sub connector for up to four belt encoders in a conveyor-tracking
installation. See Belt Encoder Interface on page 50 for more information.
Adept SmartController EX User’s Guide, Rev. B
Page 30 of 96
3.2 Front Panel
2
3
4
5
1
STOP
R
The following figure shows an Adept Front Panel.
Chapter 3: Operation
Figure 3-2. Front Panel
Before running programs, either the optional Adept Front Panel or user-supplied switches for
High Power On/Off, MAN/AUTO, and E-Stop must be connected to the XFP connector on the
Adept SmartController EX motion controller.
NOTE:Safety regulations dictate the sequence of events required for the user to enable high
power. For instance, a user may be required to press the High Power On button on the Front
Panel after pressing the COMP/PWR button on the pendant or issuing the eV+“enable power”
command. Users cannot jumper this button input and still enable power (see your robot manual
for further details).
1.
XFP connector
Connects to the XFP connector on the controller.
2.
System 5 V Power-On LED
Indicates whether or not power is connected to the controller.
3.
Manual/Automatic Mode Switch
Switches between Manual and Automatic mode. In Automatic mode, executing programs control the mechanism, and the mechanism can run at full speed.
In Manual mode, the system limits mechanism speed and torque, to reduce the risk to
an operator working in the cell. It is the user's responsibility to determine if this is
allowed under local regulations. Manual mode initiates software restrictions on robot
speed, commanding no more than 250 mm/sec as required by RIA and ISO standards.
Please refer to your robot manual for further details.
Adept SmartController EX User’s Guide, Rev. B
Page 31 of 96
Chapter 3: Operation
4.
High Power On/Off Switch & Lamp
Controls high power, which is the flow of current to the robot motors. Enabling high
power is a two-step process. An “Enable Power” request must be sent from the user terminal, an executing program, or a pendant. Once this request has been made, the button
light blinks, and the operator must press the button for high power to be applied. The
default timeout for the button is 10 seconds
NOTE:The default timeout period of 10 seconds is programmable, and can be changed or
disabled, in which case the button does not blink, and does not need to be pressed to enable high power.
5.
Emergency Stop Switch
The E-Stop is a dual-channel, passive E-Stop that supports Category 3 CE safety requirements. It supports a customer-programmable E-Stop delay that maintains motor power
for a programmed time after the E-Stop is activated. This customizable feature allows
the motors to decelerate under servo control to a stop. This can aid in eliminating coasting or overshooting on low friction mechanisms. It can also aid in the reduction of wear
on highly-geared, high-inertia mechanisms, while maintaining safety compliance per all
standards.
Programming the E-Stop Delay
To set the programmable E-Stop delay from the Adept ACE software, go to the object editor for
the robot, and enable Expert Access:
Object > Expert Access
NOTE:This requires a password to enable.
Once enabled, you will be able to see and modify the following three parameters (among
others):
l
Auto Mode E-Stop Shutdown Timeout
l
Hold-to-Run E-Stop Shutdown Timeout
l
Manual Mode E-Stop Shutdown Timeout
Each of these is the time, in seconds, after that mode E-Stop is asserted, in which eV+ is
allowed to decelerate the robot, engage the brakes, and shut down power before the servo
nodes automatically shut down power. The value can be set from 0 (immediate power-off) to
0.512 seconds. If the deceleration is too slow, or the brake-on delay too long, the servo will automatically cut power.
3.3 Installing the Adept ACE Software
WARNING:Make sure that all cables are installed correctly and fully
inserted and screwed down before applying power to the system. Failure
to do this could cause unexpected robot motion. Also, a connector could
be pulled out or dislodged unexpectedly.
Adept SmartController EX User’s Guide, Rev. B
Page 32 of 96
Chapter 3: Operation
You install Adept ACE software from the Adept Software CD-ROM. Adept ACE needs Microsoft .NET Framework. The Adept ACE Setup Wizard scans your PC for .NET, and installs it
automatically, if needed.
1.
Insert the CD-ROM into the CD-ROM drive of your PC. If Autoplay is enabled, the
Adept Software CD-ROM menu is displayed - see Operation on page 27. If Autoplay is
disabled, you will need to manually start the CD-ROM.
NOTE:The online document that describes the installation process opens in the background when
you select one of software installation steps below.
2.
From the Adept Software CD-ROM menu, click Install the Adept ACE Software.
3.
The Adept ACE Setup wizard opens.
Follow the instructions as you step through the installation process.
4.
When the install is complete, click Finish.
5.
After closing the Adept ACE Setup wizard, click Exit on the CD-ROM menu and proceed to the Start-up Procedure.
NOTE:You will have to restart the PC after installing the Adept ACE software.
3.4 Configuring the SmartController
Configuring Serial Ports
The Adept SmartController EX motion controller has four serial I/O ports:
l
RS-232/Term
l
RS-422/485
l
RS-232-1
l
RS-232-2
See Connectors and Indicators on page 27 for the connector locations.
From the Adept ACE software:
1.
Double-click on the controller in the tree structure pane.
This opens the object editor for the controller.
2.
Select Configure > Configure eV+.
3.
Click Configuration.
4.
Select SERIAL
5.
Click Add, to create a new entry
or
Highlight an entry and click Edit, to modify the existing values.
Adept SmartController EX User’s Guide, Rev. B
Page 33 of 96
Chapter 3: Operation
6.
Set the values as appropriate for your port.
7.
Click Accept.
8.
Click Done.
9.
Click Yes, to write the values to the eV+ system disk.
10.
Click Yes to reboot the controller, so the values you just set will take effect.
Figure 3-3. Configuring Serial Ports
RS-232 Connectors
All three types of RS-232 connectors are 9-pin DB9 male (standard PC) connectors. The usersupplied cable to connect to the RS-232 connectors should be a DB9, F/F, null-modem datatransfer cable. The pin assignments are the same for all three connectors and are shown in the
following table.
Adept SmartController EX User’s Guide, Rev. B
Page 34 of 96
Chapter 3: Operation
Table 3-3. RS-232 Connector Pin Assignments
Pin RS-232-1 RS-232-2 RS-232/Term
Signal Type Signal Type
1 Reserved - NC -
2 RXD Input RXD Input
3 TXD Output TXD Output
4 Reserved - NC -
5 GND Ground GND Ground
6 Reserved - NC -
7 RTS Output RTS Output
8 CTS Input CTS Input
9 Reserved - NC -
These ports support the RTS, and CTS signals used for hardware handshaking (also known as
modem control). By default, these signals are not enabled. To configure hardware handshaking
and other communication parameters, use the Adept ACE software. The eV+ designations for
these ports, when referenced in the eV+ ATTACH or FSET instructions, are shown in the following table.
NOTE:To configure the port speed and other communications parameters, use Adept ACE software.
Table 3-4. Serial Connectors and eV+ Designations
Connector eV+ Designation
RS-422/485 LOCAL.SERIAL:1
RS-232/Term LOCAL.SERIAL:2
RS-232-1 SERIAL:1
RS-232-2 SERIAL:2
RS-422/485 Connector
The RS-422/485 connector is a 9-pin DB9 male connector. The pin assignments are shown in
the following table. RS-422 is a point-to-point protocol for connecting to a single destination.
This port can also be configured as a multidrop port (RS-485).
Adept SmartController EX User’s Guide, Rev. B
Page 35 of 96
Chapter 3: Operation
Table 3-5. RS-422/485 Connector Pin Assignments
Pin Signal Type
1 NC
2 RXD+ Input
3 TXD+ Output
4 TXD- Output
5 GND Ground
6 RXD– Input
7 NC
8 EXPIO_5V Output
9 GND Ground
To change the configuration of the RS-422/485 port, see Configuring Serial Ports on page 33.
See the previous table for the eV+ designation when referenced in the eV+ ATTACH or FSET
instructions.
3.5 Connecting User-Supplied Safety and Power-Control Equipment
The user-supplied safety and power-control equipment connects to the system through the
XUSR and XFP connectors on the controller. The XUSR connector (25-pin) and XFP (15-pin)
connector are both female D-sub connectors located on the front panel of the controller. Refer to
the following table for the XUSR pin-out descriptions. Refer to the table Contacts Provided by
the XFP Connector on page 37 for the XFP pin-out descriptions. See the figure CAT-3 E-Stop Circuit on XUSR and XFP Connectors on page 40 for the XUSR wiring diagram.
Adept SmartController EX User’s Guide, Rev. B
Page 36 of 96
Chapter 3: Operation
Table 3-6. Contacts Provided by the XUSR Connector
Pin
Pairs
Description Comments
Voltage-Free Contacts Provided by Customer
1, 14 User E-Stop CH 1 (mushroom push-
N/C contacts, Shorted if NOT Used
button, safety gates, etc.)
2, 15 User E-Stop CH 2 (same as pins
N/C contacts, Shorted if NOT Used
1, 14)
3, 16 Line E-Stop (used for other robot or
N/C contacts, Shorted if NOT Used
assembly line E-Stop interconnection. Does not affect E-Stop
indication (pins 7, 20))
4, 17 Line E-Stop (same as pins 3, 16) N/C contacts, Shorted if NOT Used
5, 18 Muted safety gate CH 1 (causes E-
N/C contacts, Shorted if NOT Used
Stop in Automatic mode only)
6, 19 Muted Safety Gate CH 2 (same as
N/C contacts, Shorted if NOT Used
pins 5, 18)
Voltage-Free Contacts provided by Adept
7, 20 E-Stop indication CH 1 Contacts are closed when Front Panel, pend-
ant, and customer E-Stops are not tripped
8, 21 E-Stop indication CH 2 (same as
pins 7, 20)
Contacts are closed when Front Panel, pend-
ant, and customer E-Stops are not tripped
9, 22 Manual/Automatic indication CH 1 Contacts are closed in Automatic mode
10, 23 Manual/Automatic indication CH 2 Contacts are closed in Automatic mode
11, 12,
No connection
13, 24,
25
Table 3-7. Contacts Provided by the XFP Connector
Pin
Pairs
Description Requirements for User-
Supplied Front Panel
Voltage-Free Contacts Provided by Customer
1, 9 Front Panel E-Stop CH 1 User must supply N/C con-
tacts
2, 10 Front Panel E-Stop CH 2 User must supply N/C con-
tacts
3, 11 Remote Manual/Automatic switch CH 1.
Manual = Open Automatic = Closed
Optional - jumper closed for
Auto Mode-only operation
Adept SmartController EX User’s Guide, Rev. B
Page 37 of 96
Chapter 3: Operation
Pin 1
Pin 8
Pin 9
Pin 15
XFP
Pin
Pairs
4, 12 Remote Manual/Automatic switch CH 2.
Description Requirements for User-
Supplied Front Panel
Optional - jumper closed for
Manual = Open Automatic = Closed
Auto Mode-only operation
6, 14 Remote High Power on/off momentary push-button User must supply momentary
push-button to enable High
Power to system
Non-voltage-Free Contacts
5, 13 Adept Supplied 5 VDC and GND for High Power
On/Off Switch Lamp
User must supply lamp, or
use 1 W, 47 ohm resistor - system will not operate if not
present
a
7, 15
Controller system 5 V power on LED, 5 V, 20mA Optional - indicator only
8 No connection
See the figure Front Panel Schematic on page 41 for a schematic diagram of the Adept Front Panel.
a
Users must exercise caution to avoid inadvertently connecting 24 V signals to these pins, because
this will damage the electronics.
NOTE:The system was evaluated by Underwriters Laboratory with an Adept Front Panel. If you
provide a substitute Front Panel, this could void UL compliance.
Table 3-8. Remote Pendant Connections on the XMCP Connector
Pin XMCP
(15-Pin D-Sub)
Description
1, 9 Pendant E-Stop Push-button CH 1
2, 10 Pendant E-Stop Push-button CH 2
3, 11 Pendant Enable CH 1 (Hold-to-run)
4, 12 Pendant Enable CH 2 (Hold-to-run)
13 Serial GND/Logic GND
7 Pendant TXD: “eV+to Pendant TXD”
8 Pendant RXD: “eV+to Pendant RXD”
14 No connection
Adept SmartController EX User’s Guide, Rev. B
Page 38 of 96
Chapter 3: Operation
Pin XMCP
(15-Pin D-Sub)
Description
15 No connection
Shield Shield GND
6 24 V
5 No connection
Table 3-9. XSYS Connector Pin Assignments
Pin Signal Description
1 ESTOPGND GND Return
2 MANUAL1 Manual Mode ESTOP Ckt. CH 1
3 MANUAL2 Manual Mode ESTOP Ckt. CH 2
4 HIPWRDIS High Power Disable
5 HIPWRREQ High Power Request
6 AUTO1 Auto Mode ESTOP Ckt. CH 1
7 AUTO2 Auto Mode ESTOP Ckt. CH 2
8 N/C No Connection
9 ESTOPSRC 24 V Output to Slave ESTOP
NOTE: The XSYS connector is used to link the E-Stop system to Adept robots. It is not intended
for customer connections.
Adept SmartController EX User’s Guide, Rev. B
Page 39 of 96
Chapter 3: Operation
Logic cyclic
check state
machines
Channel 1
Channel 2
ES1
ES2
Internal Connections
User Supplied Connections
F M
Front Panel
E-Stop
E-Stop
Enable
Pendant
E-Stop
Channel 1
ESTOPSRC
Channel 2
User E-Stop Indication
User E-Stop and
Gate Interlock
(Jumper closed when
not used, MUST open
both channels
independently if used)
ESTOPSRC
ES1
ES2
ES2
ES1
User Manual / Auto Indication
(Manual = Open)
Pendant
Enable
Switch
Manual/Auto
Enable
MM1
MM1
MM2
MM2
XUSER-22
XUSER-23
XUSER-10
XUSER-9
XUSER-17
XUSER-16
XUSER-3
XUSER-4
XUSER-20
XUSER-21
XUSER-8
XUSER-7
XUSER-15
XUSER-14
XUSER-1
XUSER-2
XFP-1
XFP-9
XFP-2
XFP-10
XUSER-6
XUSER-5
XUSER-18
XUSER-19
XSYS-9
XSYS-1
XSYS-7
XSYS-6
XSYS-3
XSYS-2
XSYS-5
Muted Safety Gate
- Active in auto mode
only
(Jumper closed when
not used)
ESTOPSRC
Auto 2
Auto 1
Manual 2
Manual 1
High Power Request
I
limit
= 1.4 A
Connections at Adept Robot or Module system
(No user connections)
24 V
Lamp Control Circuit
with burnout detection
Front Panel
High
Power
On / Off
XFP-5 XFP-6
XFP-13 XFP-14
eV+ High
Power request
24 V
Front Panel
MM1
XFP-3
XFP-4
XFP-11 XFP-12
MM2
Manual/Auto Keyswitch
- Manual = Open (|)
- Manual => (<250 mm/s)
- Auto => 100%
24 V
5 V
Front
Panel
System
Power
LED
XFP-7
XFP-15
Grn
Line E-Stop
(External User
E-Stop system)
The following figure shows an E-Stop diagram for the Adept SmartController EX motion controller. See Introduction on page 9 for a description of the functionality of this circuit.
Figure 3-4. CAT-3 E-Stop Circuit on XUSR and XFP Connectors
Adept SmartController EX User’s Guide, Rev. B
Page 40 of 96
Chapter 3: Operation
ESTOPSRC
24 VS
5 VD
D
SYSPWRLT 7
6
5
4
2
3
1
17
16
8
10
9
11
12
13
14
15
XFP
15PDSUBM
MANUALSRC1
HIPWRREQ
MANUALRLY2
MANUALRLY1
HIPWRLT
ESTOPFP2
ESTOPFP1
HPLT5V
NC
MANUALSRC2
"MANUAL/AUTO""System Power LED"
MANUALSRC1
SW1
MANUALRLY2
MANUALRLY1
MANUALSRC2
24 VS
"HIGH POWER ON/OFF"
SWL1
HIPWRREQ
HPLT5 V
HIPWRLT
D
ESTOPSRC
"EMERGENCY STOP"
SW2
ESTOPFP2
ESTOPFP1
5 VD
D
2-PIN_MINI
SYSPWRLT
Adept Front Panel Schematic
Figure 3-5. Front Panel Schematic
Emergency Stop Circuits
User E-Stop Indication - Remote Sensing of E-Stop
The Adept SmartController EX motion controller provides connections for Emergency Stop (EStop) circuits on the XUSR and XFP connectors. This gives the controller system the ability to
duplicate E-Stop functionality from a remote location using voltage-free contacts. See the figure
CAT-3 E-Stop Circuit on XUSR and XFP Connectors on page 40.
The XUSR connector provides external two-channel E-Stop input on pin pairs 1, 14 and 2, 15.
The XFP connector provides two-channel E-Stop input on pin pairs 1, 9 and 2, 10.
A method has been provided to indicate the status of the ESTOP chain, inclusive of the Front
Panel Emergency Stop push-button, the pendant Emergency Stop push-button, and the User
Emergency Stop Contacts.
NOTE:These pins must be shorted if not used. Both channels must open independently if used.
Although an Emergency Stop will occur, the controller will flag an error state if one channel is jumpered closed and the other channel is opened. It will also flag an error state if the channels are
shorted together.
Adept SmartController EX User’s Guide, Rev. B
Page 41 of 96
Chapter 3: Operation
NOTE: These contacts do not indicate the status of any connections below the User E-Stop contacts. Thus, they will NOT indicate the status of the Line E-Stop, MCP ENABLE, or the Muted
Safety gate. If you have a specific need in this area, contact Adept Customer Service for information on alternate indicating modes.
Two pairs of pins on the XUSR connector (pins 7, 20 and 8, 21) provide voltage-free contacts,
one for each channel, to indicate whether the E-Stop chain, as described above, on that channel
is closed. Both switches are closed on each of the redundant circuits in normal operation (no
E-Stop). The user may use these contacts to generate an E-Stop for other equipment in the workcell. The load on the contacts must not exceed 40 VDC or 30VAC at a maximum of 1 A.
These voltage-free contacts are provided by a redundant, cyclically-checked, positive-drive,
safety relay circuit for Category 3 operation (see the figure CAT-3 E-Stop Circuit on XUSR and
XFP Connectors on page 40 and the table Contacts Provided by the XFP Connector on page 37
for the customer E-Stop circuitry).
Line E-Stop Input
The XUSR connector on the controller contains a two-channel Line E-Stop input for workcell or
other equipment emergency-stop inputs. Generally, the customer E-Stop Indication contact outputs are used to generate an emergency stop in such external equipment. Thus, if one were to
wire the same equipment’s outputs into the customer E-Stop input (that is, in series with the
local robot’s E-Stop push-buttons), a lock-up situation could occur.
The Line E-Stop input comes into the circuit at a point where it cannot affect the customer EStop indication relays and will not cause such a lock-up situation. For any situation where two
systems should be “cross-coupled”, for example, the customer E-Stop indication of one controller is to be connected to the input of another controller, the Line E-Stop input is the point to
bring in the other controller’s output contacts. See the figure CAT-3 E-Stop Circuit on XUSR
and XFP Connectors on page 40 for more information.
Do not use the Line E-Stop for such devices as local E-Stop push-buttons, since their status
should be reported to the outside on the local customer E-Stop indication output contact while
the Line E-Stop inputs will not.
Muted Safety Gate E-Stop Circuitry
Two pairs of pins on the XUSR connector (pins 5, 18 and 6, 19) provide connections for a
safety gate designed to yield an E-Stop allowing access to the workspace of the robot in Manual mode only, not in Automatic mode. It is up to the customer to determine if teaching the
robot in Manual Mode, by a skilled programmer (See "Qualification of Personnel" in the Adept
Robot Safety Guide), wearing safety equipment and carrying an Adept pendant, is allowable
under local regulations. The E-Stop is said to be “muted” in Manual mode (for the customer EStop circuitry, see the figures and tables at the beginning of the section Connecting User-Supplied Safety and Power-Control Equipment on page 36).
The muted capability is useful for a situation where a shutdown must occur if the cell gate is
opened in Automatic mode, but you need to open the gate in Manual mode. If the mute gate is
opened in Automatic mode, the robot defaults to Manual mode operation when power is reenabled. In muted mode, the gate can be left open for personnel to work in the robot cell. However, safety is maintained because of the speed restriction.
Adept SmartController EX User’s Guide, Rev. B
Page 42 of 96
Chapter 3: Operation
CAUTION:If you want the cell gate to always cause a robot shutdown,
wire the gate switch contacts in series with the user E-Stop inputs. Do not
wire the gate switch into the muted safety gate inputs.
Remote Manual Mode
The Front Panel provides for a Manual Mode circuit. See Remote High Power On/Off Control
and your robot manual for further details about the customer Remote Manual Mode circuitry.
The Adept Front Panel, or the user-supplied panel, must be incorporated into the robot workcell to provide a “Single Point of Control” (the pendant) when the controller is placed in Manual mode. Certain workcell devices, such as PLCs or conveyors, may need to be turned off
when the operating mode switch is set to Manual mode. This is to ensure that the robot controller does not receive commands from devices other than from the pendant, the single point
of control.
If the user needs to control the Manual/Automatic mode selection from other control equipment, then a custom splitter cable or complete replacement of the Adept Front Panel may be
required. See Front Panel Schematic on page 41. In this situation, a pair of contacts should be
wired in series with the Adept Front Panel Manual/Automatic mode contacts. Thus, both the
Adept Front Panel and the customer contacts need to be closed to allow Automatic mode.
WARNING:Do not wire user-supplied Manual/Automatic contacts in parallel with the Adept Front Panel switch contact. This would violate the
“Single Point of Control” principle and might allow Automatic (highspeed) mode to be selected while an operator is in the cell.
User Manual/Auto Indication
Two pairs of pins on the XUSR connector (pins 9, 22 and 10, 23) provide a voltage-free
contact to indicate whether the Front Panel and/or remote Manual/Automatic switches are
closed. The user may use these contacts to control other mechanisms (for example, conveyor,
linear modules, etc.) when Manual mode is selected. The load on the contacts should not
exceed 40 VDC or 30 VAC at a maximum of 1 A.
User High Power On Indication
In the Adept SmartController EX motion controller, eV+ controls a normally-open relay contact
on the XDIO connector (pins 45, 46, see the table XDIO Digital I/O Connector Pin Assignments
on page 49), that will close when high power has been enabled. The user can use this feature
to power an indicator lamp or other device, that signals High Power is On. The limit on these
contacts is 1 A at 30 VDC or 30 VAC.`
Remote High Power On/Off Control
The easiest and most effective way to provide the high power on/off control in a remote location is to mount the Adept Front Panel in the desired location with an extension cable.
However, if the user needs to control high power on/off from other control equipment or from
a location other than the Adept Front Panel, then a custom splitter cable will be required. See
the Front Panel schematic (Front Panel Schematic on page 41) for details of the Front Panel’s
Adept SmartController EX User’s Guide, Rev. B
Page 43 of 96
Chapter 3: Operation
wiring. In this situation, a second momentary contact for high power on/off would be placed in
parallel with the Adept Front Panel push-button contact. This second contact should be sup-
pressed when in Manual mode (see the note on “Single Point of Control” below).
This method allows relocating the push-button switch to a more convenient location. Implementation of this method must conform to EN standard recommendations.
NOTE:European standards require that the remote High Power push-button be located outside
of the workspace of the robot.
Pins 6, 14 and 5, 13 of the XFP connector provide this remote capability. Pins 5, 13 provide
power for the lamp, +5 VDC and ground, respectively. Pins 6, 14 are inputs for voltage-free normally-open contacts from a user-supplied momentary push-button switch.
WARNING:To fulfill the “Single Point of Control” requirement, do not place the
Manual/Automatic and High Power On controls in multiple locations. After putting
the robot into Manual mode, the operator should remove the key for safety purposes. The system should not be wired so that a PLC or another operator can put
the system back into Automatic mode.
High Power On/Off Lamp
The Front Panel High Power On/Off Lamp (P/N: 27400-29006) will cause an error, from eV+, if
the lamp burns out. This error prevents High Power from being turned on. This safety feature
prevents a user from not realizing that High Power is enabled because the High Power indicator is burned out. See Changing the Lamp in the Front Panel High-Power Indicator on page
55 for information on changing this lamp.
Remote Front Panel or User-Supplied Control Panel Usage
Users can mount the Front Panel remotely by using an extension cable or by wiring a user-supplied Front Panel (control panel) to the controller using the 15-pin XFP connector. The Front
Panel contains no active components, only switches and lights. Customers should be able to
adapt the Front Panel’s functionality into their own Front Panel design. To automatically control the Front Panel’s signals, use relay contacts instead of switches. See the figure Front Panel
Schematic on page 41 for a schematic drawing of the Front Panel, and see the table Contacts
Provided by the XFP Connector on page 37 for a summary of connections and pin numbers.
NOTE:The system was evaluated by Underwriters Laboratory with an Adept Front Panel. If you
provide a substitute Front Panel, the system may no longer be UL compliant.
Customers can build an extension cable to place the Front Panel in a remote location. The
extension cable must conform to the following specifications:
l
Wire Size: must be larger than 26 AWG.
l
Connectors: must be 15-pin, standard D-sub male and female.
l
Maximum cable length is 10 meters.
Adept SmartController EX User’s Guide, Rev. B
Page 44 of 96
Chapter 3: Operation
NOTE: The XMCP and XFP connectors on the controller can be interchanged without electrical
damage. However, neither the Front Panel nor the pendant will work properly unless they are
plugged into the correct connector.
Remote Pendant Usage
Customers can build an extension cable to place the pendant in a remote location. The extension cable must conform to the following specifications:
l
Wire Size: must be larger than 26 AWG.
l
Connectors: must be 15-pin, standard D-sub male and female.
l
Maximum cable length is 10 meters.
CAUTION:Do not modify the cable that is attached to the pendant. This
could cause unpredictable behavior from the robot system.
3.6 Connecting User-Supplied Digital I/O Equipment
The controller contains two options for connecting Inputs and Outputs (I/O). I/O can be hardwired to the XDIO and/or Controller Area Network (CAN) connectors.
DeviceNet Connector
The DeviceNet connector on the controller is used to interface to a CAN using the DeviceNet
protocol. See Adept DeviceNet on page 85 for details.
XDIO Connector
The XDIO connector on the Adept SmartController EX motion controller is a 50-pin, standard
density D-Sub female connector (see SmartController EXConnectors and Indicators on page 27
for location). There are 12 inputs and 8 outputs, each optically isolated from the circuitry of the
controller. The signals are numbered 1001 through 1012 for the inputs and 1 through 8 for the
outputs. All the signals have independent source and ground connections. These inputs contain the four high-speed inputs that are used by the system for interrupts and latching. The outputs, although independent, have a lower current rating of 100 mA compared to 700 mA for
the extended outputs on the sDIO module (described in sDIO Module on page 61). See the eV+
Language User's Guide for information on digital I/O programming.
The connector also provides 24 V pins for powering customer equipment. There are four 24 V
pins and four ground pins, which are limited to a total of 1 A of current. The source of the 24
V is the XDC connector on the front of the controller.
Input Signals
The XDIO connector handles input signals 1001 to 1012. Each channel has an input and a corresponding return line. See the following table for input specifications. The connector pin-outs
are shown in the table XDIO Digital I/O Connector Pin Assignments on page 49.
Adept SmartController EX User’s Guide, Rev. B
Page 45 of 96
Chapter 3: Operation
Table 3-10. DIO Input Circuit Specifications (XDIO connector)
Operational voltage range 0 to 30 VDC
“Off” state voltage range 0 to 3 VDC
“On” state voltage range 10 to 30 VDC
Typical threshold voltage Vin= 8 VDC
Operational current range 0 to 7.5 mA
“Off” state current range 0 to 0.5 mA
“On” state current range 2.5 to 7.5 mA
Typical threshold current 2.0 mA
Impedance (Vin/Iin) 3.9 K W minimum
Current at Vin= +24 VDC Iin£ 6 mA
Turn-on response time (hardware)
Software scan rate/response time
5 µsec maximum
1 ms scan cycle/
1 ms max response time
Turn-off response time (hardware)
Software scan rate/response time
5 µsec maximum
1 ms scan cycle/
1 ms max response time
NOTE:The input current specifications are provided for reference; voltage sources are typically
used to drive the inputs.
NOTE: When the program task priorities are properly set, there is a 1ms maximum latency for
the fast inputs when used with the eV+ INT.EVENT instruction.
In the following figure, example 1 shows inputs (1001 to 1004) with a negative common, example 2 shows inputs (1005 to 1008) with a positive common, and example 3 shows inputs (1009
to 1012) with an independent power supply (no common).
NOTE: These are examples. Either method can be used on any channel.
Adept SmartController EX User’s Guide, Rev. B
Page 46 of 96
Chapter 3: Operation
Customer power
supply
Example 1
Example 2
Example 3
Customer power
supply
Signal 1001
Signal 1002
Signal 1003
Signal 1004
Signal 1005
Signal 1006
Signal 1007
Signal 1008
Signal 1009
Signal 1010
Signal 1011
Signal 1012
+
–
+
–
+
–
+
–
+
–
+
–
Adept-Supplied Equipment Customer-Supplied Equipment
(Typical Examples)
(equivalent circuit)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
XDIO Connector on Controller - Inputs
Sourcing
Sinking
REACT Input Signals 1001 to 1012
Page 47 of 96
NOTE: Power from pins 41-44 and 47-50 can be substituted for the customer power supply. See
the figure Digital Output Wiring for XDIO Connector on page 49 and the table DIO Input Circuit
Specifications (XDIO connector) on page 46 for additional information.
Inputs 1001 to 1012 (only) may be used by the eV+ REACT and REACTI instructions. See the
eV+ Language Reference Guide for information on these instructions. If you are going to use these
instructions, you should plan your digital I/O channel usage accordingly.
In addition to functioning as normal input signals, all input signals can have the following
special uses:
l
Fast DIO eV+ Interrupt Events (INT.EVENT)
l
Robot and Encoder Position Latch
Figure 3-6. Digital Input Wiring for XDIO Connector
Adept SmartController EX User’s Guide, Rev. B
Chapter 3: Operation
Fast DIO interrupt events (using INT.EVENT) require the optional eV+ Extensions License.
When the program task priorities are properly set, there is a 1ms maximum latency for the
fast inputs when used with the eV+ INT.EVENT instruction.
See the eV+ Language Reference Guide for a description of the INT.EVENT instruction.
Output Signals
The XDIO connector handles output signals 0001 to 0008. Refer to the following table for output specifications. The locations of the signals on the connector are shown in the table XDIO
Digital I/O Connector Pin Assignments on page 49. The XDIO connector provides separate positive and negative connections for each channel (no internal common connections). This
allows the choice of wiring for current-sourcing or current-sinking modes.
Table 3-11. DIO Output Specifications (XDIO connector)
Operating voltage range 0 to 24 VDC
Operational current range, per channel I
£ 100 mA, short-circuit pro-
out
tected,
1 A total at 24 V
V drop across output in “on” condition V drop £ 2.7 V at 100 mA
V drop £ 2.0 V at 10 mA
Output off leakage current I
Turn-on response time (hardware)
Software scan rate/response time
£ 600 µA
out
3 µsec maximum
1 ms scan cycle
1 ms max. response time
Turn-off response time (hardware)
Software scan rate/response time
200 µsec maximum
1 ms scan cycle
1 ms max. response time
The figure Digital Output Wiring for XDIO Connector on page 49 shows two examples of different connections to the digital outputs on the XDIO connector. The examples are negative
common and positive common using the internal 24 V and ground connections.
Example 1: outputs 0001 to 0004 are shown with positive common.
Example 2: outputs 0005 to 0008 are shown with negative common.
NOTE:These are examples. Either method can be used, in any combination, on any channel. Also,
an external customer-provided power supply could have been provided instead of the power provided on the XDIO connector.
Adept SmartController EX User’s Guide, Rev. B
Page 48 of 96
Chapter 3: Operation
Example 1
Example 2
Signal 0001
(equivalent circuit)
Signal 0002
Signal 0003
Signal 0004
Signal 0005
Signal 0006
Signal 0007
Signal 0008
Adept-Supplied Equipment Customer-Supplied Equipment
(Typical Examples)
Load
Load
Load
Load
XDIO Connector on the Controller - Outputs
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
Sourcing
Sinking
+24 V (1 A)
X
X
Ground
Pin Signal Pin Signal Pin Signal Pin Signal
1 Input 1001 2 1001 return 25 Output 0001+ 26 Output 0001–
3 Input 1002 4 1002 return 27 Output 0002+ 28 Output 0002–
5 Input 1003 6 1003 return 29 Output 0003+ 30 Output 0003–
7 Input 1004 8 1004 return 31 Output 0004+ 32 Output 0004–
9 Input 1005 10 1005 return 33 Output 0005+ 34 Output 0005–
11 Input 1006 12 1006 return 35 Output 0006+ 36 Output 0006–
Figure 3-7. Digital Output Wiring for XDIO Connector
Table 3-12. XDIO Digital I/O Connector Pin Assignments
Adept SmartController EX User’s Guide, Rev. B
Page 49 of 96
Chapter 3: Operation
Pin 1
Pin 17
Pin 34
Pin 18
Pin 33
Pin 50
XDIO
Pin Signal Pin Signal Pin Signal Pin Signal
13 Input 1007 14 1007 return 37 Output 0007+ 38 Output 0007–
15 Input 1008 16 1008 return 39 Output 0008+ 40 Output 0008–
17 Input 1009 18 1009 return 41 24 V Outputa42 24 V Output
19 Input 1010 20 1010 return 43 24 V Outputa44 24 V Output
a
a
21 Input 1011 22 1011 return 45 eV+ High
Power On
Indicator +
46 eV+ High
Power On
Indicator –
23 Input 1012 24 1012 return 47 24 V return 48 24 V return
49 24 V return 50 24 V return
a
Limited to combined total of 1 A of current.
Digital I/O Connectors
The XDIO connector on the controller is a 50-pin, standard-density D sub-miniature female
socket. The user-supplied cable must terminate in a suitable 50-pin male D-sub plug. The plug
is not supplied by Adept.
Screw-Terminal Field-Wiring Adapter Blocks
Several manufacturers make screw-terminal field-wiring blocks, usually DIN-rail mountable.
These can be connected to the XDIO via a suitable shielded 50-pin cable (user-supplied).
3.7 Belt Encoder Interface
For use with conveyor tracking, the Adept SmartController EX motion controller supports four
independent external belt encoders through a 26-pin, female, D-sub connector. The pin assignments for the Belt Encoder connector are shown in the following table. See the figure Belt
Encoder Typical Input Circuit on page 53 for a typical input circuit drawing.
NOTE:An adapter cable (Adept P/N: 09550-000) is available to split the 26-pin Adept SmartController EX motion controller connector into two 15-pin connections, compatible with the SmartController CX. The 15-pin adapter is Adept P/N: 09443-000. Each 15-pin adapter provides two M12
connections.
All encoder inputs for the Adept SmartController EX motion controller use a scheme similar to
an RS-422 differential receiver based on industry standard 75175 integrated circuits. The dif-
Adept SmartController EX User’s Guide, Rev. B
Page 50 of 96
Chapter 3: Operation
ference is that a custom resistor network and two differential receivers are used on each of the
A and B inputs. See the figure Belt Encoder Typical Input Circuit on page 53 for a schematic.
Adept strongly recommends using differential encoder outputs for maximum noise immunity.
See the Adept ACE User's Guide for more information on setting up and programming a con-
veyor-tracking application.
NOTE:Conveyor tracking requires the eV+ Extensions License, which can be obtained from
Adept.
Adept SmartController EX User’s Guide, Rev. B
Page 51 of 96
Chapter 3: Operation
BELT ENCODER
Pin 1Pin 9
Pin 10Pin 18
Pin 19Pin 26
Table 3-13. Belt Encoder Connector Pin Assignments
Signal Pin Signal Pin
Encoder 5 V Out 1 ENC2_B-
Encoder Ground 10 ENC3_B+
14
15
ENC1_A+ 2 ENC3_B- 16
ENC1_A- 3 ENC4_B+ 17
ENC2_A+ 4 ENC4_B- 18
ENC2_A- 5 ENC1_Z+ 19
ENC3_A+ 6 ENC1_Z- 20
ENC3_A- 7 ENC2_Z+ 21
ENC4_A+ 8 ENC2_Z- 22
ENC4_A- 9 ENC3_Z+ 23
ENC1_B+ 11 ENC3_Z- 24
ENC1_B- 12 ENC4_Z+ 25
ENC2_B+ 13 ENC4_Z- 26
Adept SmartController EX User’s Guide, Rev. B
Page 52 of 96
Chapter 3: Operation
Encoder
+
–
220
2.2K
26LS33
SmartController EX
Belt Encoder Connector
Typical input circuit,
same for A, B, and I
for both encoders.
2.2K
Encoder Channel 1
Encoder Channel 2
Shield
Enc. Gnd
Enc. Pwr
A –
A +
5 V
B +
B –
I +
I –
Encoder
+
–
A –
A +
B +
B –
I +
I –
Encoder power output: 5 V at 800 mA max.
(1 A current limit)
Figure 3-8. Belt Encoder Typical Input Circuit
Adept SmartController EX User’s Guide, Rev. B
Page 53 of 96
Chapter 3: Operation
Figure 3-9. Belt Encoder Connector
Adept SmartController EX User’s Guide, Rev. B
Page 54 of 96
Chapter 4: Maintenance
4.1 Changing the Lamp in the Front Panel High-Power Indicator
The system is equipped with circuitry to detect the potentially dangerous condition of a
burned-out High Power indicator on the Front Panel. If this lamp is burned out, you cannot
enable high power until the lamp has been replaced. Follow this procedure to replace the High
Power indicator lamp. The Adept part number for the lamp is 27400-29006.
WARNING: Lockout and tagout power before servicing.
WARNING: The procedures and replacement of parts mentioned in this
section should be performed only by trained, authorized personnel. The
access covers on the Adept SmartController EX motion controller are not
interlocked – turn off and disconnect power if covers have to be
removed.
1.
Turn off system power to the controller.
2.
Disconnect the cable between the Front Panel and the controller.
3.
Remove the Front Panel from its mounting location.
4.
Remove the two screws on the back of the Front Panel.
5.
Carefully pull the front cover away from the body of the Front Panel.
You will encounter some resistance, as there are three plug-type connectors that you
need to disconnect as you pull the front cover away from the body.
NOTE:Separate the cover from the body slowly to avoid damaging the two wires that go
between the LED and the PC board inside the body. Pull the front cover as straight away as possible. You do not have to disconnect the wires from the PC board, although you can if needed.
6.
Locate the lamp body in the center of the back side of the front cover. Turn the lamp
body approximately 20° in either direction and then pull straight back.
7.
The lamp body is now free. You can remove the old lamp and insert a new one.
8.
Replace the lamp body by pushing it straight into the lamp housing receptacle. Make
sure the contacts on the lamp body are properly oriented, as shown in the following figure.
9.
Make sure to reconnect the wires from the LED if you disconnected them earlier.
Adept SmartController EX User’s Guide, Rev. B
Page 55 of 96
Chapter 4: Maintenance
High Power On/Off
Lamp Body
Back side of front cover
Wires between LED and
body of Front Panel.
Be careful when separating
front cover from body to avoid
damaging the wires.
10.
Push the front cover into the body, taking care to align all of the plug-type connectors.
Verify that the wires do not get crimped as you reinstall the cover.
11.
Replace the two screws on the back of the body.
12.
Reinstall the Front Panel in its mounting.
13.
Reconnect the cable between the Front Panel and the controller.
Figure 4-1. Lamp Body Contact Alignment
Adept SmartController EX User’s Guide, Rev. B
Page 56 of 96
Chapter 5: Technical Specifications
328.9
189.1
12.1
4.4
186.5
86.0
This chapter shows the dimensions of the Adept SmartController EX motion controller, sDIO
module, Adept Front Panel, and T20 pendant.
5.1 Adept SmartController EX Motion Controller Dimensions
NOTE:The dimensions for the CS and CX SmartController motion controllers were the same as
these.
Figure 5-1. Adept SmartController EX Motion Controller Dimensions
Adept SmartController EX User’s Guide, Rev. B
Page 57 of 96
Chapter 5: Technical Specifications
328.9
186.5
Ground Connection Point
2.5
4.4
5.5
41.6
SF
IEEE-1394
X2
SC-DIO
LINK
*S/N 3563-XXXXX*
X1
24V 0.5A
R
OK
X4
- + - +
1.1 1.2
XDC1 XDC2
X3
5.2 sDIO Module Dimensions
Figure 5-2. sDIO Module Dimensions
Adept SmartController EX User’s Guide, Rev. B
Page 58 of 96
Chapter 5: Technical Specifications
STOP
R
152.4
88.9
129.5
13.1
55.9
38.7
16.5
30
76.2
139.7
6.4
6.4
4X M4 x 18 MM
5.3 Adept Front Panel Dimensions
Figure 5-3. Adept Front Panel Dimensions
Adept SmartController EX User’s Guide, Rev. B
Page 59 of 96
Chapter 5: Technical Specifications
5.4 Adept T20 Pendant Dimensions
Figure 5-4. T20 Pendant Dimensions
Adept SmartController EX User’s Guide, Rev. B
Page 60 of 96
Chapter 6: sDIO Module
The sDIO expansion module provides 32 optically-isolated digital inputs, 32 optically-isolated
outputs, and an IEEE 1394 interface.
6.1 Mounting the sDIO Module
The following mounting options are available for the sDIO module:
l
Rack mounting
l
Panel mounting
l
Table mounting
l
Stack mounting
NOTE:To maintain compliance with local and national standards, the mounting of the sDIO and
all terminations at the sDIO must be performed in accordance with those standards.
Rack-Mounting the sDIO Module
To rack-mount the sDIO module in a standard 19-inch equipment rack, you must first install
the mounting brackets on each side of the unit, as shown in the following figure.
NOTE:These brackets must be ordered separately. They do not come with the sDIO module.
Figure 6-1. sDIO Module
Adept SmartController EX User’s Guide, Rev. B
Page 61 of 96
Chapter 6: sDIO Module
3.6
TYP.
6.1
4.2
31.8
16.0
43.9
14.2
2X 40356-00003
R 3.6
190.0
2X M3 x 6MM
BOTH SIDES
482.8
462.0
14.0
Figure 6-2. Rack-Mounting the sDIO Module
Adept SmartController EX User’s Guide, Rev. B
Page 62 of 96
Chapter 6: sDIO Module
10.0
18.0
346.4
4X M3 x 6 MM
14.0
6.6
16.0
359.6
27.6
273.9
2X 40356-00000
R 3.6
186.5
Panel-Mounting the sDIO Module
To panel-mount the sDIO module, install one bracket on each side of the back of the unit, as
shown in the following figure. Use the screws from the accessories kit.
Figure 6-3. Panel-Mounting the sDIO Module
Table-Mounting the sDIO Module
To table-mount the sDIO module, install two brackets on each side near the bottom of the unit,
as shown in the following figure.
NOTE:These brackets must be ordered separately. They do not come with the sDIO module.
Adept SmartController EX User’s Guide, Rev. B
Page 63 of 96
Chapter 6: sDIO Module
R 3.6
16.3
391.9
16.0
378.7
24.9
24.1
120.8
21.7
4X 40356-00001
12.1
29.5
120.9
4X M3 x 6 MM
BOTH SIDES
Figure 6-4. Table-Mounting the sDIO Module
Stack-Mounting the sDIO Module
See Stack-Mounting Components on page 18 for information on stack-mounting the sDIO module and controller.
6.2 Installing the sDIO Module
The following procedure details the steps required to install the sDIO module.
To install the sDIO module:
1.
Remove the sDIO module from its box and mount it as described in Mounting the sDIO
Module on page 61.
2.
Ensure that the 24 VDC input power to the controller is disconnected.
3.
Connect a 24 VDC cable from the unused XDC port on the controller to the XDC1 port
on the sDIO module. Continue to daisy-chain the input power from each sDIO module
to the next. See Connecting Power on page 21 for cabling requirements.
4. Connect an IEEE 1394 cable from one of the SmartServo ports on the controller to one of
the IEEE 1394 ports on the sDIO module. Continue to daisy-chain IEEE 1394 cables
from each sDIO module to the next.
Adept SmartController EX User’s Guide, Rev. B
Page 64 of 96
Chapter 6: sDIO Module
SF
IEEE-1394
X2
SC-DIO
LINK
*S/N 3563-XXXXX*
X1
24V 0.5A
R
OK
X4
- + - +
1.1 1.2
XDC1 XDC2
X3
1
2 3
7
4 5 6
WARNING:Remove power from the controller before plugging in or
unplugging any IEEE-1394 cables to SmartServo IEEE-1394 connectors.
Failure to remove power could result in unpredictable behavior by the
system.
5.
Connect a user-supplied ground wire to earth ground on each sDIO module.
6.
Connect the 24 VDC input power to the controller.
6.3 sDIO Module Connectors and Indicators
Figure 6-5. sDIO Connectors and Indicators
1.
Status LEDs.
Two LEDs indicate link status of the IEEE 1394 connection and system status.
LINK: Green LED = communication with another device over IEEE 1394 connection
OK.
OK/SF: Red LED = output driver fault detected due to excessive temperature or current
(output is automatically shut down), solid green LED = communication with controller
OK, blinking green = not configured in software.
2.
IEEE 1394 ports: Connects to one of the SmartServo ports on controller or IEEE 1394
ports on additional sDIO modules.
3.
X1 Output: 44-pin female D-sub connector, for digital output signals 0033-0048.
4.
X2 Output: 44-pin female D-sub connector, for digital output signals 0049-0064.
5.
X3 Input: 26-pin female D-sub connector, for digital input signals 1033-1048.
6.
X4 Input: 26-pin female D-sub connector, for digital input signals 1049-1064.
NOTE:For installations that use two or more sDIO modules, the above signal numbers apply to
the signals for the first sDIO module. See Modifying the Default sDIO Configuration on page 66
for information on configuring two or more sDIO modules.
7.
Two 24 VDC connectors: Connect power from the unused XDC connector on the SmartController to the XDC1 connector on the sDIO module (see Connecting Power on page
21 for power specifications).
Adept SmartController EX User’s Guide, Rev. B
Page 65 of 96
Chapter 6: sDIO Module
6.4 Configuring an sDIO Module
The Adept SmartController EX motion controller is preconfigured to support two sDIO modules. Its configuration is based upon an I/O block assignment method that uses 4 bytes per
block and 8 signals per byte, so each byte within a block represents a range of eight Input or
Output signals.
Block numbers for general digital I/O can range from 16 to 31. The default block is 16 for sDIO
#1, and 17 for sDIO #2. Input blocks and output blocks are numbered independently, so you
can use the same number for both an input and an output block. You must be sure that the
block number you specify is not used for the same type of block (Input or Output) in any other
sDIO module or IO Blox devices in your system.
Default sDIO I/O Configuration
Two sDIO modules can be used with the default I/O signal configuration and no additional signal configuration is required. The default configuration consists of the settings shown in the following table. The first sDIO module can use the default configuration; additional modules
must be assigned unique block numbers, between 16 and 31. To use the default signal configuration for the second sDIO module, you need to assign it to block 17 for input and output.
Table 6-1. Default I/O Configuration for sDIO Modules #1 and #2
sDIO #1
Input Signal
Numbers
1033 to 1040 16 1 0033 to 0040 16 1
Block Byte Output Signal
Numbers
Block Byte
1041 to 1048 16 2 0041 to 0048 16 2
1049 to 1056 16 3 0049 to 0056 16 3
1057 to 1064 16 4 0057 to 0064 16 4
sDIO #2
1065 to 1072 17 1 0065 to 0072 17 1
1073 to 1080 17 2 0073 to 0080 17 2
1081 to 1088 17 3 0081 to 0088 17 3
1089 to 1096 17 4 0089 to 0096 17 4
Modifying the Default sDIO Configuration
Blocks 1-15 are typically reserved for robot signals. Blocks 1-6 are preconfigured for Robots 1-6
for the 3000 series hand control signals, including the signals used by the eV+ OPEN, OPENI,
CLOSE, CLOSEI, RELAX, RELAXI statements. See the eV+ documentation for more details
about these statements.
In the following situations, you must go through a configuration process to modify the sDIO
modules:
l
when you have more than two sDIO modules
l
when you choose not to use the default I/O configuration (blocks 16 and 17)
Adept SmartController EX User’s Guide, Rev. B
Page 66 of 96
Chapter 6: sDIO Module
l
when you replace an sDIO module in either of the two preceding situations
NOTE:The first two sDIO modules can use the default signal configuration, with blocks 16 and 17;
each additional sDIO module must be assigned unique block numbers.
In these cases you will use Adept ACE Configuration Tools to select the block number and to
assign the Input and Output signals. Refer to the Adept ACE User'sGuide, Digital I/O Con-
figuration, for details on configuring nodes and gadgets.
From the Adept ACE software:
1.
Double-click on the controller in the tree structure pane.
This will open the object editor for the controller.
2.
Click the Configure tab, check Configure Controller, and click Next.
3.
Click the Configuration tab.
l
Select DIGITAL_INPUT to modify the input settings.
l
Select DIGITAL_OUTPUT to modify the output settings.
4.
Modify or add signal ranges, as needed.
l
If a signal range is not present, click Add to add it.
l
Modify existing values with Edit.
The following table describes the items on the Add/Edit Statement editor window.
Field Description
Input Output
Statement
Type
Item Values
signalid
id
length
signaltype
1
bit
adept for sDIO module; devicenet for DeviceNet con-
input_signal output_signal
1001 - 1999 1 - 999
0 - 31 0 - 31
0 - 31 0 - 31
1-32 1 - 32
nection
Composed
Statement
Provides a preview of the statement, based on the current settings in the Item Values field.
1 id is either the input block or output block for Adept 1394 I/Os
5.
When you have configured all of the I/O, click Done.
Adept SmartController EX User’s Guide, Rev. B
Page 67 of 96
Chapter 6: sDIO Module
Figure 6-6. Controller Configuration Screen, Digital Input
Adept SmartController EX User’s Guide, Rev. B
Page 68 of 96
Chapter 6: sDIO Module
ROBOT 1
XIO
Output Block 1
Byte 1 Byte 2
(97-104)
Internal IO
(3001-3004)
XIO
Input Block 1
Byte 1 Byte 2
(1097-1104)
XIO
(1105-1108)
4 spare
IO Blox 1
Output Block 3
Byte 1 Byte 2
(0105-112)
IO Blox 2
(0113-120)
IO Blox 3 IO Blox 4
(0121-128) (0129-136)
Byte 3 Byte 4
IO Blox 1
Byte 1 Byte 2
(1113-1120)
IO Blox 2
(1121-1128)
IO Blox 3 IO Blox 4
(1129-1136) (1137-1144)
Byte 3 Byte 4
Input Block 3
ROBOT 2
XIO
Input Block 2
Byte 1 Byte 2
(0137-0144)
Internal IO
(3001-3004)
XIO
Output Block 2
Byte 1 Byte 2
(1145-1152)
XIO
(1153-1156)
4 spare
IO Blox 1
Input Block 4
Byte 1 Byte 2
(0145-0152)
IO Blox 2
(0153-0160)
IO Blox 3 IO Blox 4
(0161-0168) (0169-0176)
Byte 3 Byte 4
IO Blox 1
Byte 1 Byte 2
(1161-1168)
IO Blox 2
(1169-1176)
IO Blox 3 IO Blox 4
(1177-1184) (1185-1192)
Byte 3 Byte 4
Output Block 4
Figure 6-7. Input/Output Block Configuration in Dual-robot Systems
Adept SmartController EX User’s Guide, Rev. B
Page 69 of 96
Chapter 6: sDIO Module
Byte 1 Byte 2
Group 2Group 1 Group 3 Group 4
Group 2Group 1 Group 3 Group 4
Group 2Group 1 Group 3 Group 4
Group 2Group 1 Group 3 Group 4
(0033-0040) (0041-0048) (0049-0056) (0057-0064)
Byte 3 Byte 4
Input Block 16
Byte 1 Byte 2
(1033-1040) (1041-1048) (1049-1056) (1057-1064)
Byte 3 Byte 4
Output Block 16
Byte 1 Byte 2
(0065-0072)
Note: for sDIO #3 and #4 (and beyond), the values shown are recommended, but must be configured,
so that the system will support those modules.
(0073-0080) (0081-0088) (0089-0096)
Byte 3 Byte 4
Input Block 17
Byte 1 Byte 2
(1065-1072) (1073-1080) (1081-1088) (1089-1096)
Byte 3 Byte 4
Output Block 17
sDIO #1
sDIO #2
Byte 1 Byte 2
Group 2Group 1 Group 3 Group 4
Group 2Group 1 Group 3 Group 4
Group 2Group 1 Group 3 Group 4
Group 2Group 1 Group 3 Group 4
(0201-0208) (0209-0216) (0217-0224) (0225-0232)
Byte 3 Byte 4
Input Block 18
Byte 1 Byte 2
(1201-1208) (1209-1216) (1217-1224) (1225-1232)
Byte 3 Byte 4
Output Block 18
Byte 1 Byte 2
(0233-0240) (0241-0248) (0249-0256) (0257-0264)
Byte 3 Byte 4
Input Block 19
Byte 1 Byte 2
(1233-1240) (1241-1248) (1249-1256) (1257-1264)
Byte 3 Byte 4
Output Block 19
sDIO #3
sDIO #4
Figure 6-8. Input/Output Block Configuration for Optional sDIO Modules
Adept SmartController EX User’s Guide, Rev. B
Page 70 of 96
Chapter 6: sDIO Module
SF
IEEE-1394
X2
SC-DIO
LINK
*S/N 3563-XXXXX*
X1
24V 0.5A
R
OK
X4
- + - +
1.1 1.2
XDC1 XDC2
X3
SF
IEEE-1394
X2
SC-DIO
LINK
*S/N 3563-XXXXX*
X1
24V 0.5A
R
OK
X4
- + - +
1.1 1.2
XDC1 XDC2
X3
SF
IEEE-1394
X2
SC-DIO
LINK
*S/N 3563-XXXXX*
X1
24V 0.5A
R
OK
X4
- + - +
1.1 1.2
XDC1 XDC2
X3
SF
IEEE-1394
X2
SC-DIO
LINK
*S/N 3563-XXXXX*
X1
24V 0.5A
R
OK
X4
- + - +
1.1 1.2
XDC1 XDC2
X3
1394 cable
1394 cable
1394 cable
1394 cable
24 VDC from
Customer-supplied
power supply
24 VDC cable
24 VDC cable
24 VDC cable
1394 cable
24 VDC cable
Block 16 (default)
Input Signals 1033 to 1064
Output Signals 0033 to 0064
Adept SmartController EX
Motion Controller
Adept sDIO
Module #1
Block 17 (default)
Input Signals 1065 to 1096
Output Signals 0065 to 0096
Adept sDIO
Module #2
Block 18
Input Signals 1201 to 1232
Output Signals 0201 to 0232
Block 19
Input Signals 1233 to 1264
Output Signals 0233 to 0264
Recommended
Configurations
Adept sDIO
Module #3
Adept sDIO
Module #4
6.5 Installing Multiple sDIO Modules
Figure 6-9. Using Multiple sDIO Modules
NOTE:When adding additional sDIO modules, each additional sDIO module must be grounded
per all applicable regulations.
Configuring Multiple sDIO Modules
Up to eight sDIO modules can be added to a system. The first sDIO module occupies the first 4
bytes of block 16. The second sDIO module uses block 17. Additional sDIO modules need to be
configured. Refer to Modifying the Default sDIO Configuration on page 66, and the values in
the figure Input/Output Block Configuration for Optional sDIO Modules on page 70.
Adept SmartController EX User’s Guide, Rev. B
Page 71 of 96
6.6 sDIO Digital I/O Signals
The sDIO module’s digital I/O signals are 64 optically-isolated digital I/O channels (32 output
and 32 input). They are wired to connectors X1 through X4, which are located on the front of
the sDIO module (see the figure sDIO Connectors and Indicators on page 65). The electrical
specifications for the inputs are similar to the XDIO inputs, but have a different wiring configuration. The sDIO inputs cannot be used for REACTI programming or high-speed interrupts.
See the eV+ Language User's Guide for information on digital I/O programming.
NOTE: The signals on the sDIO connectors can be superseded by another sDIO module that is
installed and addressed as sDIO #1. To use two sDIO modules, address the first as sDIO #1 and the
second as sDIO #2.
sDIO Inputs
The 32 input channels are arranged in four groups of eight. Each group is electrically isolated
from the other groups and is optically isolated from the sDIO module’s circuitry. The eight
inputs within each group share a common ground.
The inputs are accessed through the two female 26-pin D-sub input connectors on the front of
the sDIO module. Each connector provides access to two input groups. Each group requires
ten pins: eight input signals, and two ground references. An input is activated by providing a
positive potential on its input pin relative to the ground pin of its group. This type of input is
considered sinking. That is, current must flow into the input pin to turn it on.
Chapter 6: sDIO Module
Table 6-2. sDIO Input Specifications
Operational voltage range 0 to 30 VDC
“Off” state voltage range 0 to 3 VDC
“On” state voltage range 10 to 30 VDC
Typical threshold voltage Vin= 8 VDC
Operational current range 0 to 7.5 mA
“Off” state current range 0 to 0.5 mA
“On” state current range 2.5 to 7.5 mA
Typical threshold current 2.0 mA
Impedance (Vin/Iin) 3.9 K W minimum
Current at Vin= +24 VDC Iin£ 6 mA
Turn on response time (hardware)
Software scan rate/response time
5 µsec maximum
1 ms scan cycle/
1 ms max response time
Turn off response time (hardware)
Software scan rate/response time
5 µsec maximum
1 ms scan cycle/
1 ms max response time
Adept SmartController EX User’s Guide, Rev. B
Page 72 of 96
Chapter 6: sDIO Module
Adept-Supplied Equipment Customer-Supplied Equipment
Signal 1033
Par t Present Sensor
15
Signal 1034
Feeder Empty Sensor
6
Signal 1035
Par t Jammed Sensor
16
Signal 1036
Sealant Ready Sensor
7
Signal 1037
17
Signal 1038
8
Signal 1039
18
Signal 1040
9
Group 1 Return
25
Group 1 Return
26
Signal 1041
10
Signal 1042
1
Signal 1043
11
Signal 1044
2
Signal 1045
12
Signal 1046
3
Signal 1047
13
Signal 1048
4
Group 2 Return
19
Group 2 Return
20
Customer
Power
Supply
+
–
+
–
Customer
Power
Supply
sDIO Module
Input Group 1
Wiring
Te r minal
Block
Ty pical Customer
Input Signals
Input Group 2
X3 Connector – 26-Pin Female D-Sub
Input Group 3
Signals 1049 – 1056
Input Group 4
Signals 1057 – 1064
X4 Connector –
26-Pin Female D-Sub
Adept Digital Input
Cable (optional)
(equivalent circuit)
NOTE:The input current specifications are provided for reference. Voltage sources are typically
used to drive the inputs.
Figure 6-10. Typical sDIO Input Wiring
Adept SmartController EX User’s Guide, Rev. B
Page 73 of 96
Chapter 6: sDIO Module
NOTE: The off-state current range exceeds the leakage current of sDIO outputs. This guarantees
that the inputs will not be turned on by the leakage current from the outputs. This is useful in situations where the outputs are looped-back to the inputs for monitoring purposes.
sDIO Outputs
The 32 output channels are arranged in four groups of eight. Each group is isolated from the
other groups and is optically isolated from the sDIO circuitry. The eight outputs within each
group share a common power supply and a common ground.
The outputs are accessed through the two female 44-pin D-sub output connectors on the front
of the sDIO module. Each connector provides access to two output groups. Each group
requires 19 pins: 8 output signals, 1 test signal, 9 power supply (all tied together), and 1 power
supply ground reference. When an output is on, current will flow in through the power supply
pins and out through the output pins. This type of output is considered sourcing, that is, in the
On condition, current flows out of the output pin. See the figure Typical sDIO Output Wiring
on page 77 for details on typical digital output wiring.
Testing sDIO Outputs
Like many solid-state I/O systems, when an output is off, a small leakage current will flow out
of the output. This will raise the potential of the output to the power supply voltage level if
there is no load. With a load connected, the output will function normally. However, if you
need to test the output with a voltmeter with a load disconnected, you will get a false reading.
The test signal provides a bias that can be used as a pull-down resistor for system-level troubleshooting. When this is connected to an output, the output will assume the ground potential
when it is off.
sDIO LEDs
A pair of two-color LEDs on the sDIO module indicate link status over the IEEE 1394 connection and system status. The upper LED lights green when an IEEE 1394 connection is established. The lower LED blinks green when the software is active and switches to solid green
after the controller software has found and configured the DIO block. The lower LED lights
solid red whenever an output fault (excessive current or temperature) is detected on any of the
32 outputs. Refer to the following table for information about the LEDs and the figure sDIO
Connectors and Indicators on page 65 for information on their location.
NOTE: A fault indication is the result of an over-temperature or over-current condition on one or
more of the outputs, usually due to a short-circuit. As a result, the output driver IC will oscillate on
and off as the chip tries to drive the load.
Note that this red fault LED is active only when:
l
An extended output (for example, a SIGNAL in the range of 33 to 64) has been turned
on by an eV+ command.
l
An activated output has a thermal-overload problem, usually due to a short in the
user’s wiring from the output pin to the user’s ground.
Adept SmartController EX User’s Guide, Rev. B
Page 74 of 96
Chapter 6: sDIO Module
Table 6-3. sDIO Chassis LEDs
Illumination Upper LED (LINK) Lower LED (OK SF)
None No IEEE 1394 link Local software not running
Blinking Green Not Applicable Local software active,
not configured in eV+
Solid Green IEEE 1394 link good Local software active,
and configured in eV+
Blinking Red Not Applicable Output fault
Solid Red Not Applicable Output fault
A diagnostic software indicator is not available for the XDIO outputs. In a short-circuit condition, the XDIO outputs will simply fold back, supplying the maximum short-circuit current
to the output pin.
sDIO Output Power Supply Current Selection
The nine power pins for each group are connected together on the sDIO module’s board, and
the current supplied from the output pins is drawn from these power pins. The number of
power pins used in a particular application depends on the total current supplied through that
group’s outputs. A total of nine power pins are provided to allow for more wire connections to
decrease the voltage drop across the power supply wires.
The supply current should be limited to a maximum of one amp per power pin. Use this limitation to select the number of power pins you need.
For example, each output can source up to 700 mA, giving a maximum total current (for a
group of eight outputs) of 5.6 A that will be required from the power supply. In this case, a
minimum of six power pins should be used. If you experience an excessive voltage drop, make
connections to additional power pins.
The ground connection should connect to the power supply directly, not the ground connection of the load. This will isolate the board from any voltage drop across the ground return
for the load.
Adept SmartController EX User’s Guide, Rev. B
Page 75 of 96
Chapter 6: sDIO Module
Table 6-4. sDIO Output Circuit Specifications
Parameter Value
Power supply voltage range 10 VDC £ V
Under voltage shutdown 5 VDC £ V
sup
£ 8 VDC
usd
£ 30 VDC
Power supply ground current Ig£ 60 mA
Operational current range, per channel
I
£ 700 mA
out
On state resistance (Iout = 0.5 A) Ron £ 0.32 W @ 85° C
(Ron 0.4 W @ 125° C)
Output leakage current I
£ 25 µA
out
Turn on response time 175 µsec. max., 80 µsec typical
(hardware only)
Turn off response time 60 µsec. max., 28 µsec typical
(hardware only)
Output voltage at inductive load
turnoff (Iout = 0.5 A, Load = 1 mH)
(Vsup - 65) £ Vdemag £ (Vsup -
45)
DC short circuit current limit 0.7 A £ ILIM £ 2.5 A
Peak short circuit current Iovpk £ 4 A
CAUTION:The above specs. apply only to the output channels on the
sDIO module. See the table DIO Output Specifications (XDIO connector)
on page 48 for specs. on the XDIO connectors’ digital output channels.
Adept SmartController EX User’s Guide, Rev. B
Page 76 of 96
Chapter 6: sDIO Module
M
Adept-Supplied Equipment
Customer-Supplied Equipment
25
Customer DC
Power
Supply
+
–
sDIO
Output Group 1
Wiring
Terminal
Block
Typical User Loads
X1 Connector – 44-Pin Female D-Sub
Output Group 3
Signals 0049 – 0056
Output Group 4
Signals 0057 – 0064
X2 Connector –
44-Pin Female D-Sub
Adept Digital Output
Cable (optional)
26
38
39
40
41
42
43
44
28
Group 1 Return
29
Group 1 Test
30
Signal 0033
15
Signal 0034
14
Signal 0035
13
Signal 0036
12
Signal 0037
11
Signal 0038
10
Signal 0039
9
Signal 0040
Load
17
Customer AC
Power
Supply
+
–
18
19
31
32
33
34
35
36
21
Group 2 Return
22
Group 2 Test
7
Signal 0041
6
Signal 0042
5
Signal 0043
4
Signal 0044
3
Signal 0045
2
Signal 0046
1
Signal 0047
16
Signal 0048
M
Customer DC
Power
Supply
Connect module
power return
directly to power
supply if possible.
Load
Load
Load
Load
Load
Load
Load
Load
Load
Load
Output Group 2
Group 1
Power Pins
(see text)
Group 2
Power Pins
(see text)
L
N
(equivalent
circuit)
(equivalent
circuit)
Figure 6-11. Typical sDIO Output Wiring
Optional DIO Cables
The cables that connect to the input and output connectors on the sDIO module can be ordered
as a set of four cables: two input cables and two output cables. These cables have a mating
plug on one end and unterminated flying leads on the other end. The wire size of the Adept
cables is 0.18 mm2(24 AWG). You can use these cables to connect to the digital inputs/outputs
in your system or to a wiring block.
The cable set is Adept P/N: 90330-01080.
To comply with IEC 1131, if you choose to supply a wiring block, it should be capable of
accepting wire in the range of 0.18 mm2(24 AWG) to 2.0 mm2(14 AWG).
Labeling Cables
The X3 and X4 input connectors on the front of the sDIO module are similar except that X3
handles the group 1 and group 2 input signals and X4 handles the group 3 and group 4 input
signals. The optional digital input cables can be connected to either X3 or X4. Make sure to
clearly label the cables once you have completed your installation so that the cables do not get
swapped by mistake. See the warning that follows.
Adept SmartController EX User’s Guide, Rev. B
Page 77 of 96
Chapter 6: sDIO Module
The X1 and X2 output connectors are also similar except that X1 handles the group 1 and
group 2 output signals and X2 handles the group 3 and group 4 output signals. The optional
digital output cables can be connected to either X1 or X2. Make sure to clearly label the cables
once you have completed your installation so that the cables do not get swapped by mistake.
See the warning that follows.
WARNING:Clearly label the X1 to X4 digital I/O cables so that they are
always plugged into the correct connectors. Swapping the X3 and X4 or
X1 and X2 cables could cause damage to your equipment. Depending on
the installation, this could potentially cause injury to personnel in the area.
Input and Output Cable Wiring Information
The pinouts, signal names, and wire color information for the input and output cables are
shown in the next four tables.
Adept SmartController EX User’s Guide, Rev. B
Page 78 of 96
Chapter 6: sDIO Module
Table 6-5. X3 Input Cable Pin Assignments
Pin
Number
Signal
Group
Signal
Name
Wire
Color
X3–15 1 1033 red/white
X3–6
1 1034 orange
X3–16 1 1035 green/white
X3–7 1 1036 blue
X3–17 1 1037 blue/white
X3–8 1 1038 white/black
X3–18 1 1039 black/red
X3–9 1 1040 red/black
X3–25 1 group 1 return blue/red
X3–26 1 group 1 return red/green
X3–10 2 1041 green/black
X3–1 2 1042 black
X3–11 2 1043 orange/black
X3–2 2 1044 white
X3–12 2 1045 blue/black
X3–3 2 1046 red
X3–13 2 1047 black/white
X3–4 2 1048 green
X3–19 2 group 2 return white/red
X3–20 2 group 2 return orange/red
X3 26-pin female input connector on sDIO module
Adept SmartController EX User’s Guide, Rev. B
Page 79 of 96
Chapter 6: sDIO Module
Table 6-6. X4 Input Cable Pin Assignments
Pin
Number
Signal
Group
Signal
Name
Wire
Color
X4–15 3 1049 red/white
X4–6 3 1050 orange
X4–16 3 1051 green/white
X4–7 3 1052 blue
X4–17 3 1053 blue/white
X4–8 3 1054 white/black
X4–18 3 1055 black/red
X4–9 3 1056 red/black
X4–25 3 group 3 return blue/red
X4–26 3 group 3 return red/green
X4–10 4 1057 green/black
X4–1 4 1058 black
X4–11 4 1059 orange/black
X4–2 4 1060 white
X4–12 4 1061 blue/black
X4–3 4 1062 red
X4–13 4 1063 black/white
X4–4 4 1064 green
X4–19 4 group 4 return white/red
X4–20 4 group 4 return orange/red
X4 26-pin female input connector on sDIO module
Adept SmartController EX User’s Guide, Rev. B
Page 80 of 96
Chapter 6: sDIO Module
Table 6-7. X1 Output Cable Pin Assignments
Pin
Number
Group
Number
Signal
Name
Wire
Color
X1–30 1 0033 green/black/white
X1–15 1 0034 green/white
X1–14 1 0035 red/white
X1–13 1 0036 black/white
X1–12 1 0037 blue/black
X1–11 1 0038 orange/black
X1–10 1 0039 green/black
X1–9 1 0040 red/black
X1–25 1 power orange/green
X1–26 1 power black/white/red
X1–38 1 power orange/black/green
X1–39 1 power blue/white/orange
X1–40 1 power black/white/orange
X1–41 1 power white/red/orange
X1–42 1 power orange/white/blue
X1–43 1 power white/red/blue
X1–44 1 power black/white/green
X1–28 1 group 1 return white/black/red
X1–29 1 group 1 test red/black/white
X1–7 2 0041 white/black
X1–6 2 0042 blue
X1–5 2 0043 orange
X1–4 2 0044 green
X1–3 2 0045 red
X1–2 2 0046 white
X1–1 2 0047 black
X1–16 2 0048 blue/white
X1–17 2 power black/red
X1–18 2 power white/red
Adept SmartController EX User’s Guide, Rev. B
Page 81 of 96
Chapter 6: sDIO Module
Pin
Number
Group
Number
Signal
Name
Wire
Color
X1–19 2 power orange/red
X1–31 2 power orange/black/white
X1–32 2 power blue/black/white
X1–33 2 power black/red/green
X1–34 2 power white/red green
X1–35 2 power red/black/green
X1–36 2 power green/black/orange
X1–21 2 group 2 return blue/red
X1–22 2 group 2 test red/green
X1 44-pin female output connector on sDIO module
Table 6-8. X2 Output Cable Pin Assignments
Pin
Number
Group
Number
Signal
Name
Wire
Color
X2–30 3 0049 green/black/white
X2–15 3 0050 green/white
X2–14 3 0051 red/white
X2–13 3 0052 black/white
X2–12 3 0053 blue/black
X2–11 3 0054 orange/black
X2–10 3 0055 green/black
X2–9 3 0056 red/black
X2–25 3 power orange/green
X2–26 3 power black/white/red
X2–38 3 power orange/black/green
X2–39 3 power blue/white/orange
X2–40 3 power black/white/orange
Adept SmartController EX User’s Guide, Rev. B
Page 82 of 96
Chapter 6: sDIO Module
Pin
Number
Group
Number
Signal
Name
Wire
Color
X2–41 3 power white/red/orange
X2–42 3 power orange/white/blue
X2–43 3 power white/red/blue
X2–44 3 power black/white/green
X2–28 3 group 3 return white/black/red
X2–29 3 group 3 test red/black/white
X2–7 4 0057 white/black
X2–6 4 0058 blue
X2–5 4 0059 orange
X2–4 4 0060 green
X2–3 4 0061 red
X2–2 4 0062 white
X2–1 4 0063 black
X2–16 4 0064 blue/white
X2–17 4 power black/red
X2–18 4 power white/red
X2–19 4 power orange/red
X2–31 4 power orange/black/white
X2–32 4 power blue/black/white
X2–33 4 power black/red/green
X2–34 4 power white/red/green
X2–35 4 power red/black/green
X2–36 4 power green/black/orange
X2–21 4 group 4 return blue/red
X2–22 4 group 4 test red/green
X2 44-pin female output connector on sDIO module
Adept SmartController EX User’s Guide, Rev. B
Page 83 of 96
DeviceNet is a low-cost communications link that connects industrial devices to a network
and eliminates expensive hard-wiring. The direct connectivity provides improved communication between devices as well as important device-level diagnostics not easily available
using hard-wired I/O interfaces.
7.1 DeviceNet Specifications
Adept Technology is a member of the Open DeviceNet Vendor Association (ODVA), which is
independently run and operated and not directly associated with any one company. The
ODVA controls DeviceNet technical specifications with help from Special Interest Groups
(SIGs). Each SIG develops device profiles for one line of product features to ensure interoperability. These profiles become part of the technical specifications.
The DeviceNet Specification is divided into two volumes and defines the following elements:
Volume 1
l
DeviceNet Communication Protocol and Application (Layer 7 - Application Layer1)
l
Controller Area Network (CAN) and its use in DeviceNet (Layer 2 - Data Link Layer)
Chapter 7: Adept DeviceNet
l
DeviceNet Physical Layer and Media (Layer 1 - Physical Layer)
Volume 2
l
Device profiles to obtain interoperability and interchangeability among like products
DeviceNet incorporates CAN, which defines the syntax or form of the data transmitted. The
DeviceNet application layer defines the semantics or meaning of the data transmitted. For
more information on the basics of a DeviceNet cable system, contact ODVA at:
ODVA Technology and Training Center
4220 Varsity Drive, Suite A
Ann Arbor, MI 48108-5006 USA
Phone Number: 1-734-975-8840
Fax Number: 1-734-922-0027
www.odva.org
1
These layers are based on the Open Systems Interconnect (OSI) model.
Adept SmartController EX User’s Guide, Rev. B
Page 85 of 96
Chapter 7: Adept DeviceNet
7.2 Limitations of the Adept DeviceNet Scanner
The DeviceNet Scanner that Adept has incorporated into the Adept SmartController EX motion
controller hardware and the eV+ operating system currently supports only a subset of full
DeviceNet functionality. The following is a summary of the DeviceNet implementation:
l
Implemented the Master-Slave operation. This is a complete subset of Peer-to-Peer oper-
ation.
l
Implemented the Unconnected Message Manager (UCMM) in its DeviceNet Scanner to
establish connections.
l
UCMM is used to establish I/O Connections.
l
The Adept DeviceNet Scanner can be a Client or a Server on the network.
l
The Adept DeviceNet Scanner currently does not support Cyclic or Change-of-State con-
nections.
l
Only I/O Messaging is supported. I/O messages contain only data.
l
Currently, only the Message Group 2 of the Predefined Master/Slave Connection Set is sup-
ported.
l
Adept Message Group 2 I/O connections support only the I/O Poll Command/Response
Message of the possible message types.
7.3 DeviceNet Port on the Controller
The DeviceNet port on the Adept SmartController EX Motion Controller has the following configuration:
Micro-style 12 mm thread DIN connector (female). See the following table for pin assignments.
Table 7-1. DeviceNet Signal-to-Pin Locations
Pin
Number
1 Drain
2 V+
3 V-
4 CAN_H
5 CAN_L
See the figure DeviceNet Connector Pinouts on page 93 for a drawing of the connectors.
Signal
Name
Connecting DeviceNet Hardware to the Controller
To connect DeviceNet components to the controller, connect a drop line to the female Microstyle 12 mm thread DIN connector on the front of the controller. Then you must configure the
DeviceNet Scanner correctly using the Adept ACE Configuration Tools.
Adept SmartController EX User’s Guide, Rev. B
Page 86 of 96
Chapter 7: Adept DeviceNet
NOTE:Adept does not supply 24 V on the controller to power the DeviceNet bus. A separate
power supply is required to power the components on the DeviceNet bus.
NOTE:It is important that devices connected to the network have a terminating resistor connected between CAN-H (white) and CAN-L (blue). See Termination of the DeviceNet Network on
page 91
Configuring DeviceNet
The Adept SmartController EX motion controller has a default configuration such that, if you
plug in a DeviceNet module configured with MAC_ID 1 and a baud rate of 125 kbps, the first
64 inputs and 64 outputs will automatically be mapped as signals 1289 to 1352 and 257 to
320, respectively. This makes the DeviceNet plug and play.
For other configurations, use the Adept ACE software for software setup. This assigns the controller signals to the physical ports of the DeviceNet nodes. Refer to the Adept ACE User's
Guide for details on configuring DeviceNet.
NOTE:The local setting baud rate must match the DeviceNet node’s setting.
7.4 DeviceNet Physical Layer and Media
The DeviceNet physical layer and media specifications are published in the ODVA manual,
chapter 9, volume 1. It describes possible topologies and components of the physical layer of
the DeviceNet.
The figure Trunk Lines and Drop Lines Made of Thick and Thin Cable on page 88 shows several possible topologies. The DeviceNet specifications also specify system grounding, mixing of
thick and thin cable media, termination, and power distribution.
The basic topology is the trunkline-dropline topology. This topology uses separate twisted-pair
buses for the distribution of signals and power. The specifications allow trunk lines and drop
lines made of thick or thin cable. The baud rate, maximum distance from end-to-end of the network, and cable size are dependent on each other. See the table Features of a DeviceNet Network on page 88 for further details.
Adept SmartController EX User’s Guide, Rev. B
Page 87 of 96
Chapter 7: Adept DeviceNet
Figure 7-1. Trunk Lines and Drop Lines Made of Thick and Thin Cable
DeviceNet allows devices to be powered directly from the bus, and devices can use the same
cable to communicate with other devices on the bus. DeviceNet nodes are hot-pluggable —
you can remove or add components on the bus without powering down the network.
NOTE:This hot-pluggable feature is not fully supported. If you add a new component to the network, you must make changes in the Adept ACE Configuration Tools. Those changes are not
active until you reboot the Adept SmartController EX motion controller.
The power distribution on the network/bus does not need to be in one place. The distribution
of power supplies needs to be well planned because there are certain constraints on the power
supply. In general, power supplies can be placed at any point in the network. The maximum
current rating of a trunk line is 8 amps. DeviceNet allows opto-isolated, externally powered
devices (e.g., AC drive starters and solenoid valves) to operate on the same bus cable. For
detailed information, see the DeviceNet Technical Specifications.
Table 7-2. Features of a DeviceNet Network
Network Size A maximum of 64 nodes [0...63]
Network Length Selectable, end-to-end network distance varies with speed
Baud Rate Distance (thick cable)
125 Kbps 500 m (1,640 ft)
250 Kbps 250 m (820 ft)
500 Kbps 100 m (328 ft)
Data Packets 0-8 bytes
Adept SmartController EX User’s Guide, Rev. B
Page 88 of 96
Chapter 7: Adept DeviceNet
Network Size A maximum of 64 nodes [0...63]
Bus Topology Linear (trunk line/drop line); power and signal on the same net-
work cable
Bus Addressing Multi-Master and Master/Slave special case; polled
System Features Removal and replacement of devices from the network under
power not supported by Adept
The baud rate of the system depends on the length of the network (end-to-end) and the type of
cable. The following table shows how cable selection and trunk line length affect the maximum data rate on the network. The figure DeviceNet Thick Cable on page 89 shows a thick
cable, and the figure DeviceNet Thin Cable on page 90 shows a thin cable.
Table 7-3. DeviceNet Data Rates Relative to Cable Type and Length
Data Rates 125 Kbps 250 Kbps 500 Kbps
Thick Trunk Length 500 m
(1,640 ft)
Thin Trunk Length 100 m
(328 ft)
Maximum Drop Length 6 m
(20 ft)
Cumulative Drop Length 156 m
(512 ft)
250 m
(820 ft)
100 m
(328 ft)
6 m
(20 ft)
78 m
(256 ft)
100 m
(328 ft)
100 m
(328 ft)
6 m
(20 ft)
39 m
(128 ft)
Figure 7-2. DeviceNet Thick Cable
Adept SmartController EX User’s Guide, Rev. B
Page 89 of 96
Chapter 7: Adept DeviceNet
Figure 7-3. DeviceNet Thin Cable
DeviceNet Connectors
DeviceNet allows different connectors, which may be grouped into open and sealed connectors. The open connectors are available with screw or with crimp connectors. The sealed
connectors are available in mini-style and micro-style sizes. See the following figure and table
for more details.
Figure 7-4. DeviceNet Connectors
Table 7-4. DeviceNet Connector Styles
Connector Description
Unsealed screw connector
Uses screws to attach cable wires to a removable connector
Unsealed hard-wired Uses wires attached directly to screw terminals
Sealed mini-style Attaches to taps and thick or thin cable
Sealed micro-style Attaches to thin cable only – has a reduced current rat-
ing
Adept SmartController EX User’s Guide, Rev. B
Page 90 of 96
Chapter 7: Adept DeviceNet
Termination of the DeviceNet Network
The DeviceNet network uses the Controller Area Network (CAN) bus as the physical layer.
This requires that the trunk line of your DeviceNet network be terminated with a resistor at
each end. This terminates the signal lines.
The terminating resistor:
l
Prevents reflection of communication signals on the network.
l
Connects the two signal conductors.
l
Must be sealed if the end node uses a sealed tee.
l
Must be open if the end node uses an open-style tap.
When using the open-style terminating resistor, connect a 121 ohm, ¼ W resistor to CAN_H
and CAN_L (between blue and white data-pair wires).
NOTE:A terminating resistor must also be used whenever a short drop line exceeds 6 m (20 ft).
Figure 7-5. Example of a Terminating Resistor Installation on a DeviceNet Bus
Power Supply and the DeviceNet Bus
The DeviceNet network allows distribution of power supplies on the network cable system. Follow these general rules to achieve safe and reliable operation:
l
Use power supplies rated at 24 V.
l
Minimize installation problems by using a single power supply with sufficient current
to operate all the attached nodes. This must comply with national and international
safety standards.
l
Make sure that each power supply incorporates current-limit protection.
l
Make sure each power supply is temperature compensated.
l
Provide over-current protection for each segment of your DeviceNet cable installation.
NOTE:Adept does not supply the 24 V operating voltage for the DeviceNet bus on the SmartController or any other Adept component.
Adept SmartController EX User’s Guide, Rev. B
Page 91 of 96
Chapter 7: Adept DeviceNet
Power Capabilities of a DeviceNet Cable System
A DeviceNet cable system has several power rating constraints. The cable type and the length
of the cable specify the maximum current on a cable. Thick and thin cable have:
l
24 VDC power rating
l
Optional power-supply tabs
If the power supplies are equipped with Schottky diodes, the optional power supply tabs must
be protected from bus back-feeding of current among the power supplies on the bus. We also
recommended the use of fuse protection for every trunk line in the cable system.
The maximum current rating of a thick cable trunk line is 8 A. Verify that this complies with
your national and international standards. It might be necessary to limit the maximum current
to a lower value if standards in the U.S. or Canada apply. The maximum current value is a
theoretical value. The cable size supports a higher current than 8 A. Depending on the topology of nodes relative to the power supply, higher currents might be possible. See the DeviceNet
technical specifications for further information.
The maximum current rating of a thin cable trunk line is 3 A. If you use the thin cable on a
long line, the resistance of the cable decreases the maximum current value. See the following
table and the DeviceNet technical specifications for further information.
Table 7-5. Maximum Current on a Drop Line Relative to its Length
Length of Drop Line Maximum Current
1.5 m (5 ft) 3 A
2.0 m (6.6 ft) 2 A
3.3 m (10 ft) 1 1.5 A
4.5 m (15 ft) 1 A
6 m (20 ft) 0.75 A
For the calculation of the maximum current at a specific length, use the following formula:
Where:
l= Length of the drop line in meters (m)
i= Maximum current in amps
This calculation applies to the sum of the currents of all the nodes on the selected drop line.
The length (l) is not the cumulative length of the drop line; it is the maximum distance from
any node on the drop line to the trunk line.
Adept SmartController EX User’s Guide, Rev. B
Page 92 of 96
Chapter 7: Adept DeviceNet
It is important to note that voltage differences between the V– and V+ conductors need to be
between 11 V and 25 V. The common-mode voltage between any two places on the V– wire
must not exceed 5 V.
Figure 7-6. DeviceNet Connector Pinouts
Adept SmartController EX User’s Guide, Rev. B
Page 93 of 96
