9800
Overhead Projector
Operating Instructions
Rétroprojecteur
Manual Opérateur
Tageslichtprojektor
Bedienungsanleitung
Retroproyector
Manual del operador
Lavagna Luminosa
Manuale d’Uso
Overhead Prosjektør
Bruksanvisning
Overheadprojector
Handleiding
Retroprojector
Manual do usuário
Thank You
GB
F
D
E
Thank you for choosing 3M overhead projection equipment. This product has been produced in
accordance with 3M’s highest quality and safety standards to ensure a smooth and troublefree use in the
years to come. Your purchase of this product proves that you appreciate this.
For optimum performance we kindly ask you to follow these operating instructions carefully. We hope you
will enjoy using this high performance product in your meeting, training and presentation sessions.
Nous vous remercions de votre décision d’avoir choisi un retroprojecteur 3M. Ce produit offre toutes les
garanties de qualité et sécurité.
Veuillez observer soigneusement manuel d’opération suivant pour que vous puissiez utiliser i’appareil de
façon optimale. Nous espérons que ce produit à haute performance vous fera donnera satisfaction.
Vielen Dank, daβ Sie sich für einen 3M Tageslichtprojektor entschieden haben. Dieses Produkt erfüllt die
höchsten Ansprüche an Qualität und Sicherheit und gewährleistet eine problemlose und störungsfreie
Bedienung für viele Jahre.
Bitte beachten Sie die folgende Bedienungsanleitung sorgfältig, damit Sie das Gerät optimal einsetzen
können. Wir hoffen, daβ Sie bei der Arbeit mit diesem 3M Tageslichtprojektor viel Freude haben werden
und wünschen Ihnen viele erfolgreiche Präsentationen.
Gracias por escoger este equipo de retroproyección 3M. Este producto ha sido construído según los
estándares más altos de calidad y seguridad 3M, para así asegurar su funcionaniemto libre de problemas
durante los siguientes años.
Con la compra de este producto Ud. ha demostrado que aprecia esto. Para un rendimiento óptimo le
recomendamos seguir las instrucciones detalladas en el manual del operador. Esperamos que disfrute al
usar este producto de alto rendimiento en sus reuniónes, cursillos y demostraciones.
I
N
NL
P
Vi ringraziamo di aver scelto una lavagna luminosa della 3M. Questo apparecchio è stato prodotto in
conformità alle norme di qualità e sicurezza per assicurarvi negli anni futuri l’utilizzo senza difficoltà o
problemi. Con l’acquisto di tale prodotto avete mostrato di apprezzare la qualità.
Per un rendimento ottimale Vi preghiamo di leggere accuratamente le seguenti istruzioni.
Speriamo che l’utilizzo di un prodotto di un così elevato rendimento sia di Vostro gradimento durante le
Vostro riunioni di conferenza, di addestramento e di presentazione.
Vi takker for at du har bestemt deg for en overhead projektor fra 3M. Dette produktet oppfyller de høyeste
krav til kvalitet og sikkerhet og garanterer problemløs og feilfri betjening i mange âr.
Vennligst følg vedlagte bruksveiledning onhyggelig, slik at du kan utnytte apparatet optimalt. Vi vil gjerne at
du har mye glede av dette kvalitetsproduktet.
Wij danken u voor de aanschaf van 3M overheadprojectie-apparatuur. Dit produkt is vervaardigd conform
de strengste kwaliteits-en veiligheidsnormen van 3M, zodat u gedurende vele jaren verzekerd bent van
een soepel en storingvrij gebruik. Uw keuze voor 3M geeft aan dat u dit op prijs stelt.
Voor optimale prestaties verzoeken wij u de instructies in deze gebruiksaanwijzing zorgvuldig op te volgen.
Wij hopen dat dit kwaliteitsprodukt u uitstekend van dienst zal zijn tijdens vergaderingen, trainingen en
presentaties.
Agradecemos a escolha dum retroprojector 3M. Este produto foi concebido segundo os mais altos
padrões de qualidade e segurança 3M. A fim de lhe assegurar um funcionamento sem problemas durante
os próximos anos.
Para obter um melhor rendimento do aparelho recomendamos a leitura deste manual. Esperamos que
este produto de elevado rendimento seja do seu agrado e lhe proporcione prazer nas suas reuniõnes,
cursos e demonstrações.
1
Projector to Screen Distance
Projector to screen distance - Liste de distances projecteur/écran de projection Entfernungstabelle Projektor/Projektionswand - Escala de distancia
proyector/superficie de proyección - Tabella delle distanze proiettore/schermo di
proiezione - Avstandstabell eyskastor/projeksjonregg - Afstandstabell
projector/projectieviak - Tabela de diståncias projector/pantalha de projecão
2
127 cm
FL = 342 mm
1
1.5I
x
127 cm
50I x 50I 60I x 60I 70I x 70I 84I x 84I 96I x 96I
152 cm
x
152 cm
177 cm
x
177 cm
213 cm
x
213 cm
243 cm
x
243 cm
9800 EVD
FL = 342 mm
13.5
I
9800 EVD
FL = 342 mm
13.5
9800 EVD
FL = 292 mm
187 cm
(74I)
x
50I
I
I
x = 21.3 cm
(8.4I)
x = 24.1 cm
(9.5I)
x = 26.4 cm
(10.4I)
x = 21.3 cm
(8.4I)
x = 24.1 cm
(9.5I)
x = 26.4 cm
(10.4I)
239 cm
(94I)
215 cm
(85I)
199 cm
(78I)
203 cm
(80I)
183 cm
(72I)
170 cm
(67I)
217 cm
(86I)
x
60I
279 cm
(110I)
251 cm
(99I)
232 cm
(91I)
238 cm
(94I)
214 cm
(84I)
198 cm
(78I)
248 cm
(98I)
x
320 cm
(126I)
287 cm
(113I)
265 cm
(104I)
273 cm
(107I)
244 cm
(96I)
226 cm
(89I)
70I
291 cm
(114I)
x
84I
377 cm
(148I)
338 cm
(133I)
311 cm
(122I)
321 cm
(126I)
288 cm
(113I)
266 cm
(104I)
327 cm
(129I)
x
96I
426 cm
(168I)
381 cm
(150I)
351 cm
(138I)
363 cm
(143I)
324 cm
(128I)
299 cm
(118I)
GB
IMPORTANT SAFEGUARDS
When using your overhead projection equipment,
basic safety precautions should always be
followed, including the following:
1. Read and understand all instructions
before using. Pay particular attention to
areas where this symbol
!
is shown.
2. Close supervision is necessary when any
appliance is used by or near children. Do not
leave appliance unattended while in use.
!
3. Care must be taken as burns can occur from
touching hot parts.
4. Do not operate appliance with a damaged
cord or if the appliance has been dropped or
damaged until it has been examined by a
qualified serviceman.
!
5. Position the cord so that it will not be tripped
over, pulled, or contact hot surfaces.
6. If an extension cord is necessary, a cord with
a current rating at least equal to that of the
appliance should be used. Cords rated for
less amperage than the appliance may
overheat.
7. Always unplug appliance from electrical outlet
before cleaning and servicing and when not in
use. Never yank cord to pull plug from outlet.
Grasp plug and pull to disconnect.
!
8. Let appliance cool completely before putting
away or when replacing lamp.
9. To reduce the risk of electric shock, do not
immerse this appliance in water or other
liquids.
10. To reduce the risk of electric shock, do not
disassemble this appliance, but take it to a
qualified technician when service or repair
work is required. Incorrect reassembling can
cause electric shock when the appliance is
used subsequently.
11. The use of an accessory attachment not
recommended by the manufacturer may
cause a risk of fire, electric shock, or injury to
persons.
12. Do not overload accessory circuit.
13. Connect this appliance to a grounded outlet.
14. Disconnect this unit from its source of supply
before replacing the projection lamp.
!
15. This unit is equipped with optical lenses and
should not be exposed to direct sunlight.
16. Keep ventilation openings free of any
obstructions.
17. This unit is connected by a special cable that,
if it is damaged, has to be replaced by the
same type of cable. This cable can be
ordered from your local 3M dealer and has to
be installed by a qualified serviceman.
SAVE THESE INSTRUCTIONS
The information contained in this manual will help
you operate and maintain your Overhead
Projector.
ENGLISH
3M 9800 Operator’s Guide
4
Product Description and Machine Characteristics
The 3MtOverhead Projector 9800 is designed to be
safe, efficient and easy to use. It features an open head,
ENGLISH
triplet projection lens with 1.3X magnifier, high output
lamp, lamp changer, lamp brightness control, external
colour tuning adjustment, unswitched power outlets for
20c
20a
16
20b
18
23
21
15
2
22
accessories, and lamp interrupt switches to prevent
damage.
Refer to the illustration below to identify the external
machine characteristics for the 9800.
1
3
24
4
19
17
14
5
6
7
8
9
10
12
11
13
Part Identification List
1. Open Projection Head
2. Projection Mirror
3. Triplet Projection Lens
4. 1.3X Magnifier Lens
5. Arm
6. Focus Knob
7. Post
8. Post Latch
9. Post Cradle
10. Carrying Handle
11. Accessory Outlets (design varies by country)
12. Cord Wrap
13. Circuit Breaker (5 amps)
14. Power Cord
15. Stage Glass
16. Top Cover
17. Top Cover Release Latch (with interlock)
18. Colour Tuning Adjustment (left side of machine)
19. Internal Voltage Switch (raise top cover to access)
20. Control Panel Door (with lamp interrupt switch)
a. Lamp Changer Dial
b. High/Low Lamp Brightness Switch
c. Lamp “Burned Out” or “Missing” Indicator
21. Pencil Holder
22. On/Off Power Switch
23. Machine Identification Plate
24. Internal Lamp Voltage Protector (raise top cover to
access)
53M 9800 Operator’s Guide
Set Up Projector
1. Raise the post (1) until it locks into place.
3. Raise projection mirror (3) to screen elevation.
4. Rotate focus knob (4) for sharpest image.
3
4
ENGLISH
2. Plug in power cord (2) and depress on/off power
switch.
Fold Down Projector
1. Unplug power cord (1) and coil onto cord wrap (2).
3
2
1
2. Rotate 1.3X magnifier lens (3) under projector lens.
5. Rotate colour tuning knob for colour-free image.
See Colour Tuning for details.
3. Rotate focus knob (4) clockwise to raise projection
head to maximum position.
4. Release post latch (5) and lower post until it locks
in the post cradle.
5. Rotate focus knob (6) anticlockwise to lower head
until it stops.
6. To move projector, lift from bottom or use the
carrying handle.
63M 9800 Operator’s Guide
Operating The Projector
Read the Important Safeguards before operating the
9800 projector.
ENGLISH
1. Position projector in front of projection screen. The
distance from the screen controls the size of the
projected image.
2. Uncoil power cord and plug into electric outlet.
3. Push power switch “On” to illuminate lamp.
| =ON
O = OFF
4. Rotate projector (1) until projected light beam is
perpendicular (90_) to the screen surface. The
height at the left and right sides of the projected
image should be equal.
5. Adjust angle of projection mirror (2) to raise or
lower the image on the screen.
6. For best results, tilt projection screen (3) toward
projector until the width of the projected image is
equal at both the top and bottom.
7. Place LCD projection panel or film transparency in
the center of stage glass (4).
8. Set lamp brightness to “High” or “Low” position.
See “High/Low Lamp Control” below.
9. Rotate focus knob (5) for sharpest image.
10. Rotate magnifier lens (6) under projector lens to
enlarge LCD projection panel or transparency film
image size by 1.3X. Adjust focus knob (5) for
sharpest image.
Note
The magnifier lens glass and metal frame get
warm to the touch during use. Grasp the
insulated tab to rotate the lens.
Lamp Changer
If the selected lamp (position 1 or 2) is burned out or
missing, a red X appears through the window in the
control panel door.
1. Open control panel door (1).
2. Lamp interrupt switch (2) cuts power to lamps.
3. Rotate lamp changer dial (3) to select alternate
lamp. Turn dial fully until it stops.
4. Close control panel door to illuminate lamp.
Note
Replace burned out or missing lamps to remove
red “X” from control panel door.
High/Low Lamp Control
Activate High/Low switch to select High (brightest) or
Low (normal) lamp illumination. See diagram to left.
1. Open control panel door (1).
2. Lamp interrupt switch (2) cuts power to lamps.
3. Press High/Low switch (4) to set desired
brightness.
a.
b.
4. Close control panel door to illuminate lamp.
Lamp will not illuminate unless Control
Panel door is closed.
= Brightest image, shorter lamp life
= Normal image, longer lamp life
Important
3M 9800 Operator’s Guide
7
Lamp Replacement
EVD 400W 36V
1. Push power switch to “Off” and unplug projector.
2. Release cover latch and lift up top cover.
!
Lamp and adjacent metal parts are hot. Allow lamp
to cool before replacing.
3. After lamp has cooled, release spring clip (1) and
raise condenser lens frame to access lamp.
4. Pull lamp out (2) and discard.
5. Push new lamp (3) fully and squarely into socket.
Do not touch bulb glass with fingers.
6. Close condenser lens frame and secure with spring
clip.
7. Look through condenser lens and check lamp
filament for correct alignment. If filament and its
reflection are not aligned, repeat steps 3, 5 and 6.
NOT
8. Close top cover and plug in power cord.
ALIGNED ALIGNED
ENGLISH
Cleaning
For best performance, keep your projector free of
excess dust and surface dirt.
Daily Cleaning: Use a soft cloth to remove dust from
the stage and projector base areas.
Stage Glass and Lenses: Use 3M lens cleaner and a
soft, lint-free cloth to remove surface dirt from the stage
glass, projector lens, 1.3X magnifier lens and bottom of
Fresnel Lens.
!
Caution
Cleaning the underside of the stage glass or Fresnel
lens is not recommended. Improper cleaning or
disassembly may damage the optics. Contact your
3M Dealer or Service Center for assistance.
Projection Mirror: Use a soft brush to remove surface
dirt from the projection mirror.
!
Caution
The projection mirror is a front-surface mirror and
must not be wiped clean.
3M 9800 Operator’s Guide
8
Colour Tuning
AC Electrical Outlets
Rotate the colour tuning dial to eliminate any
yellow/orange to brown or blue corners. A colour-free
ENGLISH
projection stage will produce the sharpest colour
images.
1. Clear stage area and turn on projector.
2. Rotate dial anticlockwise to remove blue corners.
3. Rotate dial clockwise to remove yellow/orange or
brown corners.
There are two unswitched AC power outlets, connected
to a 5 amp circuit breaker, for powering accessories.
!
Caution
Do not overload outlets with accessories that exceed
a total of 5 amps.
To Reset the Circuit Breaker:
1. Unplug accessories.
2. Push circuit breaker lever down to reset.
Internal Voltage Switch
The voltage switch is located inside the projector body.
Set the switch to high
voltage or low
voltage.
1. Unplug projector from power outlet.
2. Open top cover to access voltage switch.
3. Depress rocker switch for input voltage.
= Normal input voltage
= Very high input voltage
4. Close top cover.
for areas with very high input
for areas with normal input
Lamp Voltage Protector
The lamp voltage protector is a circuit board located
inside the projector body next to the internal voltage
switch. This circuit monitors incoming voltage from
the AC outlet and automatically adjusts lamp voltage to
produce the brightest lumen output with the longest
lamp life.
93M 9800 Operator’s Guide
Troubleshooting
Problem Probable Causes Solution
Lamp does not illuminate but fan motor
runs.
Neither lamp nor fan energize. a. Projector not plugged in.
Fan motor does not run but lamp
illuminates.
Lamp and fan both work but accessory
outlets do not have power.
After replacing a burned out lamp, the
new lamp fails.
Short lamp life: Lamps seem to fail
before expected life span.
Projected image is wider at the top than
bottom (Vertical Keystoning).
Projected image higher on one side
(Horizontal Keystoning).
Projected image is dim. a. Dirty stage glass, lenses, mirrors.
Projected image does not have uniform
brightness.
Yellow/orange to brown or blue colours
appear in corners of image.
Colour, focus or image problem. a. Optics out of alignment. a. Call for service.
c. Control Panel door open.
d. Lamp changer dial not engaged.
e. Lamp not seated properly.
f. Burned out lamp.
b. Stage cover not completely closed.
c. No power at wall outlet.
a. Fan blade/motor obstructed.
b. Burned out fan motor.
a. Outlets overloaded, circuit breaker
tripped.
a. Defective lamp was installed.
b. Possible electrical problem.
a. Defective lamps.
b. High line voltage.
c. Check Internal Voltage Switch
setting.
d. Lamp Voltage Protector setting to
low.
a. Screen not aligned at 90_ angle to
projected light beam.
a. Projector not aligned at 90_ angle to
screen.
b. Condenser lens bracket open or
retaining clip not engaged.
c. High/low lamp control setting
incorrect.
a. Lamp not aligned properly. a. Properly seat lamp in socket and/or
a. Lamp not at best location for
projector to screen distance.
a. Close control panel door.
b. Fully rotate lamp changer dial until it
stops.
c. Seat lamp squarely in socket.
d. Replace lamp.
a. Plug projector into outlet.
b. Close stage cover to engage safety
interlock.
c. Verify outlet has power.
a. Call for service.
b. Call for service.
a. Unplug accessories and reset circuit
breaker. Accessories must not
exceed 5 amps total.
a. Replace lamp.
b. If new lamp fails immediately, you
may have an electrical problem. Call
for service.
a. Document actual lamp life, then
contact Lamp Supplier or 3M Service
Center.
b. Have electrical line checked by an
electrician.
c. Set internal voltage switch to Low
setting.
d. Call for Service.
a. Tilt projection screen toward
projector until image width is equal
at top and bottom.
a. Rotate projector until image height is
equal on both sides.
a. Remove surface dirt.
b. Close and secure lens bracket with
retaining clip.
c. Set control to high for brightest
image.
fully rotate lamp changer into
position 1 or 2.
a. Rotate colour tuning dial to remove
colours in corners.
ENGLISH
3M 9800 Operator’s Guide
10
Service Information
Service Information - Service Information - Service - Información de Servicio Servizio assistenza - Service - 3M–Service - Serviço informativo
GB
Contact
F
Contactez votre distribution ou le bureau de vente 3M où vous avez acheté votre appareil.
D
W
benötigen. Die zentrale Service-Nr
E
Póngase en contacto con su proveedor o con la oficina de ventas 3M, en la que compró su aparato.
I
Contattare il V
N
Henvend deg til forhandleren eller til 3M-salgskontoret hvor du har kjøpt apparatet.
NL
Neem contact op met uw leverancier of de 3M vestiging waar u uw apparaat hebt gekocht.
P
Contacte o serviço de vendas da 3M ou o fornecedor onde adquiriu o seu aparelho.
COUNTRY COMPANY NAME ADDRESS LOCATION
Austria 3M Östereich Ges.m.b.H. Brunner Fieldstraße 63 A-2380 Perchtoldsdorf
Belgium 3M Belgium N.V./S.A. Hermeslaan 7 B-1231 Diegem
Denmark 3M Denmark Fabriksparken 15 DK-2600 Glostrup
Finland Suomen 3M OY PL 26 Sinimaentie 6 02630 Espoo 63
France 3M France Boulevard de l’Oise F-95006 Cergy
Germany 3M Deutschland GmbH Hammfelddamm 6 D-41460 Neuss
Greece 3M Hellas Ltd. Gr 15125 Maroussi Gr-10210 Athens
Ireland 3M Ireland 7th Floor, 3M House –
Italy 3M Italia SpA –
Netherlands 3M Nederland BV Industrieweg 24 NL-2382 NW Zoeterwoude
Norway 3M Norge A/S Hvamveien 6 N-2013 Skjetten
Portugal Minnesota (3M)
Spain 3M España, S.A. Apartado 25
Sweden 3M Svenska AB Bollstanacsvægen 3, Rotebro SE-19189 Sollentuna
Switzerland 3M (Schweiz) AG Eggstraße 93
Turkey 3M Ticaret A.S. Buyukere Cad. Ucyol Mevkii
United Kingdom 3M UK 3M House PO Box 1
your supplier or 3M sales of
enden Sie sich bitte an lhren 3M Händler oder den technischen Kundendienst der 3M, wenn Sie Serviceinformationen
ostro fornitore oppure 3M visual informa, T
fice where you purchased your unit.
. der 3M Deutschland GmbH lautet: T
el. 02-75452630.
el. 02131/14-3086, Fax 02131/167799.
Co. Dublin
Adelphi Centre,
Dun Laoghaire
Sistemi Visual
Via S. Bovio 3
Loc. San Felice
20090 Segrate MI
Rua Conde de Redondo, 98 P-1199 Lisboa Codex
de Portugal, Lda.
Madrid 28027
CH-8803 Rüschlikon
Maslak 80670 Istanbul
Normanin Is
Merkezi No: 414–416
Bracknell
Berkshire RG 1211 JU
11
Safety Points to Note
SAFETY POINTS TO NOTE:
–
Use an alternating current only
U.K. only! How to connect the flex to a plug:
IMPORT
Please read the instructions given below before connecting the flex to a plug.
If in doubt, please consult a qualified electrician. As the colours of the wires in the
mains lead of this appliance may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal which is marked
with the letter E, or the symbol
The wire which is marked brown must be connected to the terminal which is marked
with the letter L or coloured red.
The wire which is coloured blue must be connected to the terminal which is marked
with the letter N or coloured black.
Replacement fuses of 10 amp should be used which have A.S.T
Attention:
The plug, if severed from the mains lead, must be destroyed, as a plug with bared flexible cord is
hazardous if engaged in a live socket outlet.
ANT –
The wires in the mains lead are coloured in accordance with the following code:
Green and Y
Blue Neutral
Brown Live
D
Bescheinigung des Herstellers/Importeurs
ellow Earth
. Check that the supply voltage is the same as that stated on the rating plate of the appliance.
, or coloured green or green and yellow
.A. and B.S. 1362 approval.
.
Green and
Yellow
E
N
L
Blue Brown
WARNING!
THIS APPLIANCE
MUST BE
EARTHED!
Hiermit wird bescheinigt, daβ der
Tageslichtprojektor 9800
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
(Gerät, Typ, Bezeichnung)
in Übereinstimmung mit den Bestimmungen der
82/499 ECC bzw. VDE 0875
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.
(EG–Richtlinie bzw. VDE-Bestimmung))
funkentstört ist.
Der Deutschen Bundespost wurde das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung
zur Überprüfung der Serie auf Einhaltung der Bestimmungen eingeräumt.
230/240 V AC – 50 Hz – 350 W
GB
The models 9800 series fulfill CISPR 14 / EN 55014, EN 60335-1
F
Le type 9800 est conforme à CISPR 14 / EN 55014, EN 60355-1
D
Das Model 9800 erfüllt CISPR 14 / EN 55014, EN 60355-1
E
El modelo 9800 cumple las normas CISPR 14 / EN 55014, EN 60355-1
I
Il modello 9800 è conforme alle norme CISPR 14 / EN 55014, EN 60355-1
N
Modellen 9800 oppfyller CISPR 14 / EN 55014, EN 60355-1
NL
Dit model 9800 is conform met CISPR 14 / EN 55014, EN 60355-1
P
O modelo 9800 cumpre as normas CISPR 14 / EN 55014, EN 60355-1
12
Accessories
Accessories - Accessoires - Zubehör - Accesorios - Accessorio - Tilbehør - Accessories Accessórios
Lens Cleaner
Nettoyant à lentilles
Linsenreiniger
Limpiador para el Lente
Detergente
Rengjøringsmiddel for linsene
Schoonmaakmiddel voor de lens
Limpador de lentes
78-6969-7086-8 HA5795
T
ravel Cover
Couvercle de transport
Transportschutzhaube
Cubierta para V
Copertura da trasporto
Reise beskytter
Reiskap
T
ampa para transporte
78-6969-7969-5 HA5785
iajes
Lamp
Lampe
Lampe
Bombilla
Lampadina
Lampe
Lamp
Lâmpada
EVD
DY
-0210-0010-3 HA6009
-T
A 200 Cart Standard XX-0034-1
-T
A 300 Cart Deluxe XX-0034-1
-
Chariot standard
T
A 200 XX-0034-1
-
Chariot version de luxe
T
A 300 XX-0034-1
-T
A 200 Präsentationswagen
(Standardausführung) XX-0034-1
-T
A 300 Präsentationswagen
(Luxusausführung) XX-0034-1
-
Carro estándar T
-
Carro de lujo T
-T
A 200 Carrello standard XX-0034-1
-T
A 300 Carrello deluxe XX-0034-1
-T
A 200 Rullebord Standard XX-0034-1
-T
A 300 Deluxe Rullebord XX-0034-1
-T
A 200 standard projectietafel (rollend)
XX-0034-1165-7
-T
A 300 luxe projectietafel (rollend)
XX-0034-1164-0
-T
A 200 Carro standard XX-0034-1
-T
A 300 Carro deluxe XX-0034-1
165-7
164-0
A 200 XX-0034-1
A 300 XX-0034-1
Dust Cover
Housse antipoussière
Staubschutzhaube
Cubierta para Polvo
Copertura antipolvere
Støv beskytter
Stofkap
Capa anti-pó
78-6969-7216-1 HA5792
165-7
164-0
165-7
164-0
165-7
164-0
165-7
164-0
165-7
164-0
165-7
164-0
13
Visual Systems Division
6801 River Place Boulevard
Austin, Texas78726-9000
Printed in U.S.A.
E3M 6/96 78-6970-6472-9 Rev.B
Loading...
