3COM NJ220 User Manual

3Com® IntelliJack® Switch NJ220
User Guide
3CNJ220
www.3Com.com
Part No. 10016226 Rev. AA Published June 2007
3Com Corporation 350 Campus Drive Marlborough, MA 01752-3064
Copyright © 2003 – 2007, 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation.
3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.
3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time.
If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following:
All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide.
Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries.
3Com and the 3Com logo are registered trademarks of 3Com Corporation.
Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd.
IEEE and 802 are registered trademarks of the Institute of Electrical and Electronics Engineers, Inc.
All other company and product names may be trademarks of the respective companies with which they are associated.
ENVIRONMENTAL STATEMENT
It is the policy of 3Com Corporation to be environmentally-friendly in all operations. To uphold our policy, we are committed to:
Establishing environmental performance standards that comply with national legislation and regulations.
Conserving energy, materials and natural resources in all operations.
Reducing the waste generated by all operations. Ensuring that all waste conforms to recognized environmental standards. Maximizing the recyclable and reusable content of all products.
Ensuring that all products can be recycled, reused and disposed of safely.
Ensuring that all products are labelled according to recognized environmental standards.
Improving our environmental record on a continual basis.
End of Life Statement
3Com processes allow for the recovery, reclamation and safe disposal of all end-of-life electronic components.
Regulated Materials Statement
3Com products do not contain any hazardous or ozone-depleting material.
Environmental Statement about the Documentation
The documentation for this product is printed on paper that comes from sustainable, managed forests; it is fully biodegradable and recyclable, and is completely chlorine-free. The varnish is environmentally-friendly, and the inks are vegetable-based with a low heavy-metal content.
C
ONTENTS
NSTALLING THE
I
About the IntelliJack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Obtaining Optional Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installing the IntelliJack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Checking the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
I
NSTALLING
System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Installing the Local and Central Configuration Managers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Installing the Web Configuration Manager on a Windows 2000 machine . . . . . . . . . . . . . . . . . . . . . . . . . .21
U
Initializing the NJ220 IntelliJack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Setting Advanced Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SING
THE
Setting Location Information Setting the Group Name Setting the IP Address
Changing the Password Configuring for SNMP
L
THE
OCAL
NJ220 I
C
ONFIGURATION
C
NTELLI
ACK
J
M
ONFIGURATION
ANAGERS
M
ANAGER
SING
U
Discovering NJ220 Devices on Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Viewing Device Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
THE
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Network Identification Port Information Product Information
Hardware Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Switch Status Power Status
Statistics Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
General Counters RMON Counters Saving to a Log File
SNMP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
ENTRAL
C
ONFIGURATION
C
ANAGER
M
Advanced Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Event Alerts
802.1X Settings
Changing Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
General Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Identification Settings Hardware Settings
Priority & VLAN Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Port-Based Settings Other VLAN Settings
Security Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Device Password
802.1X
SNMP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Advanced Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Event Alerts Port-Based Configuration (Flow Control, AutoMDI(X), Data Rate Control)
Restoring Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Finding Computers Connected to IntelliJacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Upgrading the NJ220 Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Viewing Log Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Viewing and Canceling Scheduled Firmware Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
ROUBLESHOOTING
T
Troubleshooting Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
T
ECHNICAL
Where To Go For Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
P
RODUCT
W
ARRANTY
S
UPPORT
S
PECIFICATIONS
AND
THE
NJ220
R
EGULATORY
I
NFORMATION
1
I
NSTALLING
The 3Com NJ220 IntelliJack is a 4-port, managed Ethernet switch that fits into any standard electrical wall outlet or data port opening. It brings switching capabilities to any single port on an Ethernet network by allowing you to connect up to four networking devices, such as computer, printers, and Voice Over IP (VoIP) telephones to the network via one Ethernet port. You can use optional connectors to connect one or two additional devices to separate network segments through the same IntelliJack. All ports feature 10/100 Mbps auto-negotiation.
THE
NJ220 I
NTELLI
J
ACK
Power to the IntelliJack is provided through one of the following methods:
Over the network via an integrated switch that supports Power Over Ethernet
Over the network via an optional single-port or multi-port Ethernet power supply
Locally via an optional local power supply
NOTE: Power Over Ethernet, also known as in-line power, is a method to provide power to equipment over an Ethernet cable, allowing a device to receive both data and power from the same network cable. The NJ220 is ideally powered by a switch or other Power Sourcing Equipment (PSE) that is IEEE
802.3af-compatible. The NJ220 can also be powered by some switches which are not 802.3af-compatible. Consult the 3Com web site for more information.
You can manage the NJ220 IntelliJack using the included Central Configuration Manager or Web Configuration Manager. You can also use a supported SNMP management console as you would with any managed device on your network, but greater management and control is available through the Configuration Manager software. Management features include:
Device discovery
Port status (state, duplex, speed)
Statistics
Port control (port state, flow control, AutoMDI(X), frame rate limit)
802.1P QoS/Priority
802.1Q compatible VLAN
VLAN tag add/remove
Firmware upgrade
Rate limiting
2
1
2
3
C
HAPTER
1: I
NSTALLING

About the IntelliJack

THE
NJ220 I
NTELLI
J
ACK
MAC filtering
802.1x port security
User-configured VLAN IDs for management packets
Port-based “calendar” function
The following diagram shows the front view of the IntelliJack:
Switched ports with LEDs Allow up to four devices to be connected to the network.
Slot for adapter plate
Adapter plate with installed pass-through port connector
A green LED indicates connection status when a device is using a particular port.
Port number 1 is also a power-forwarding port; it can be used with any standard networking device as well as to power a VoIP telephone on a network that uses IEEE
802.3af-compatible Power Over Ethernet. An additional LED indicates when the port is forwarding power to a device connected to that port.
Can be fitted with an adapter plate, which can be installed with up to two pass-through ports.
Can be used for voice or other networking applications. The port bypasses the functionality of the switch, allowing you to set up a connection to a separate network segment or to connect to an analog or digital PBX telephone.
The adapter plates are available from 3Com. However, you must purchase the connectors from the manufacturer. See “Installing the Adapter Plate and Pass-Through Ports” on page 8 for more information.
LEDs
4
5
1
2
3
About the IntelliJack 3
Indicates network connection status.
Indicates power status.
Power socket
Can be used to power the IntelliJack with a local power supply (available for purchase from 3Com); required if your network does not support Power Over Ethernet.
The following diagram shows the back view of the IntelliJack:
Ethernet uplink port (RJ-45 female)
Slot for adapter plate
Adapter plate with installed pass-through port connector
Connects the IntelliJack to the network.
Make sure the port on the network switch to which the IntelliJack is connected is configured as a standard MDI-X port.
Can be fitted with an adapter plate, which can be installed with up to two pass-through ports.
Connects the installed pass-through port to the network.
4
C
HAPTER
1: I
NSTALLING

Before You Begin

THE
NJ220 I
NTELLI
J
ACK
Before you begin installation, register your product at: http://eSupport.3com.com/.
The IntelliJack is available in single- and 20-packs. Before you begin the installation, make sure you have the following items, which are included with the IntelliJack:
1.5 inch, 6x32 screws (2 per IntelliJack) for mounting the IntelliJack to the wall or office cubicle.
Male to male RJ-45 coupler cable (1 per IntelliJack) for connecting the Ethernet cable from the network to the IntelliJack (required only if your network cable is terminated with a female RJ-45 connector).
Additionally, the following items are shipped with the single pack:
Compact disc with User Guide and Configuration Manager software.
Adapter plates for installing connectors to use as pass-through ports. The adapter plates accommodate connectors from suppliers including:
n
Panduit (RJ-45 and RJ-11)

Obtaining Optional Components

n
Avaya (RJ-45 and RJ-11)
Adapter plate screws (2) for mounting the adapter plate to the IntelliJack.
NOTE: The connectors for the adapter plates must be purchased from the manufacturer. For a list of supported connectors, go to the IntelliJack section of www.3com.com/.
The IntelliJack works with the following optional components, all of which are available from 3Com. Order online at www.3com.com or by calling 1-877-949-3266.
Component
Adapter plates
Purpose 3C Number(s)
For installing pass-through port connectors of your choice that allow a direct connection to another network segment or for connecting an analog or digital PBX telephone. Available adapter plates accommodate connectors for the following manufacturers: AMP, Avaya, Hubbell, Ortronics, and Panduit.
3CNJAP-PA-20
3CNJAPB-PA-20
3CNJAP-AV-20
3CNJAPB-AV-20
3CNJAP-AM-20
3CNJAPB-AM-20
3CNJAP-HU-20
3CNJAPB-HU-20
3CNJAP-OR-20
3CNJAPB-OR-20
Single-port Ethernet power supply
Multi-port Ethernet power supply
For providing Power Over Ethernet to locally power a single IntelliJack.
For providing Power Over Ethernet to power up to 24 IntelliJacks.
3CNJPSE
3CNJPSE24
3C17205
Installing the IntelliJack 5
Component Purpose 3C Number(s)
1
2
3
4
5
6
7
8

Installing the IntelliJack

Local power supply
VoIP telephone power cable
Extension ring For ensuring that the IntelliJack is properly
For locally powering a single IntelliJack; required if your network does not support Power Over Ethernet.
For powering a VoIP telephone on a network that uses Capacitive Power Discovery Process-compatible Power Over Ethernet.
mounted to a cubicle; required if the cubicle opening:
Has a depth of fewer than 1.5 inches.
n
Does not support the NEMA-WD6
n
standard.
n
Does not have pre-drilled screw holes for standard mounting.
Installing the IntelliJack consists of the following steps:
Set up the power supply (page 6).
Install the adapter plate and pass-through ports (page 8).
3CNJPSL
3CNJVOIPMOD-NBX
3CNJVOIPMOD-20
3CNJVOIP-CPOD
3CNJVOIP-CPOD-20
3CNJEXTRING
Plan the installation (page 9).
Set up the network cabling at your site (page 10).
Connect the IntelliJack to the network (page 10).
Mount the IntelliJack to the wall or office cubicle (page 11).
Connect the local power supply (page 12; optional) not required if your network supports Power Over Ethernet or if you are using a single-port or multi-port power supply).
Connect network devices to the IntelliJack (page 13).
6
C
HAPTER
1: I
NSTALLING
THE
NJ220 I
NTELLI
J
ACK
The following diagram displays an overview of the recommended installation, where the IntelliJack is being connected to an Ethernet network cable that is terminated with a female RJ-45 connector. Detailed installation instructions are included in the sections that follow.
Setting up the Power
Supply
Power to the IntelliJack can be supplied one of the following ways:
Over the network via an integrated switch that supports Power Over Ethernet.
Over the network via a multi-port Ethernet power supply.
Over the network via a single-port Ethernet power supply.
Locally via a 3Com local power supply.
Before you begin the installation, determine which type of power supply the IntelliJack will use.
NOTE: For a list of power supplies that support the IntelliJack, go to www.3com.com/.
CAUTION: Use only a power supply that is provided or approved by 3Com for use with this IntelliJack. Failure to do so may result in damage to the IntelliJack, or may result in a hazardous situation or personal injury.
Using an Integrated Switch with Power Over Ethernet
To use Power Over Ethernet, you must have a switch on the network that has Power Over Ethernet integrated into it. You must then determine if it is compatible with IEEE 802.3af.
Using a Multi-port Ethernet Power Supply
To use a multi-port Ethernet power supply, you must connect the power supply to your network, as shown in the illustration.
Installing the IntelliJack
7
The multi-port Ethernet power supply from 3Com connects to an existing Ethernet or Fast Ethernet infrastructure with standard Category 5 or Category 5e UTP cabling, and powers up to 24 IntelliJacks. See “Obtaining Optional Components” on page 4 for ordering information. For complete installation instructions, see the multi-port Ethernet power supply documentation.
Using a Single-port Ethernet Power Supply
To use a single-port power supply, connect the power supply to the network hub or switch and to the IntelliJack, as shown in the following illustration. See “Obtaining Optional Components” on page 4 for ordering information. For complete installation instructions, see the single-port Ethernet power supply documentation.
Using the 3Com Local Power Supply
To use the local power supply, make sure you have an electrical outlet near the site where the IntelliJack will be installed. First plug the power cord into the IntelliJack, then plug it into the electrical socket. See page 12 for more details.
8
C
HAPTER
1: I
NSTALLING THE
NJ220 I
NTELLIJACK
Installing the Adapter
Plate and Pass-Through
Ports
Install the blank adapter plate, or if you want to use pass-through ports for connecting an analog or PBX digital telephone or for setting up a connection to a separate network segment, purchase supported connectors and install them on the appropriate IntelliJack adapter plate (included with the single pack; available for purchase separately with the 20-pack).
For a list of connectors that are supported with the IntelliJack adapter plates, as well as any corresponding installation instructions, go to the IntelliJack section on www.3com.com.
NOTE: If you are not planning on installing the adapter plate and pass-through ports, skip this section. Go to “Planning the Installation” on page 9 to begin the installation.
1 Pull the network cable(s) from the wiring closet to the location of the IntelliJack. 2 Thread the network cable(s) through the empty slot on the IntelliJack.
3 Terminate the end of the network cable(s) with the connector(s) you purchased
separately.
Refer to the connector manufacturer’s instructions for terminating the cable. Be sure to test end-to-end system functionality and verify that it is working.
4 Snap the connector(s) into the appropriate adapter plate.
Each adapter plate is labeled with the name of a connector’s manufacturer. Be sure to use the adapter plate that matches the manufacturer of your connector(s).
5 Mount the plate to the IntelliJack using the two adapter plate screws provided.
Installing the IntelliJack 9

Planning the Installation When installed, the back of the IntelliJack extends into a wall or cubicle opening

1.5 inches. Because the depth of some wall and cubicle openings differ, observe the following requirements and recommendations before installing the IntelliJack:
Make sure the wall or cubicle opening where the IntelliJack is being installed
complies with the NEMA-WD6 standard, as described below.
Make sure the distance between the back of the IntelliJack and the inside of
the wall or cubicle opening is at least 1.5 inches (3 inches is recommended).
NOTE: Some cubicle openings have a depth of 1.2 inches. In this case, install the IntelliJack using the extension ring (available for purchase separately; see “Obtaining Optional Components” on page 4) to obtain the minimum 1.5-inch depth.
If installing into a wall junction box, make sure there is enough space between the back of the IntelliJack and the inside of the junction box to maintain an acceptable bend radius on the cable. If you encounter interference or need additional clearance between the IntelliJack and where it sits inside the junction box, use the extension ring.
To ensure proper horizontal cabling functionality, adhere to the following
network cabling standards during installation:
n ANSI/TIA/EIA-568
Commercial Building Telecommunications Cabling Standard
n ANSI/TIA/EIA-569
Commercial Building Standard for Telecommunications Pathways and Spaces
10 CHAPTER 1: INSTALLING THE NJ220 INTELLIJACK
Setting up the Network
Cabling at Your Site
Connecting the
IntelliJack to the
Network
The network cabling at your site (from the wiring closet to the wall or cubicle opening) may already be installed. If it is not, install the cabling following these general guidelines.
CAUTION: It is recommended that a professional cable installer performs these procedures. Be sure to adhere to local safety and regulatory codes during the cable installation.
1 Connect one end of an Ethernet cable to your network. Usually, this connection is
done in a network wiring closet, via the patch panel.
2 Terminate the other end of the cable at the location where the IntelliJack is being
installed (using either a female or male RJ-45 connector).
Refer to the connector manufacturer’s instructions for terminating the cable. Be sure to test the connector and verify it is working.
The method for connecting the IntelliJack to the network is determined by how your network cable is terminated (as described in the previous section, “Setting up the Network Cabling at Your Site”).
If the end of the cable is terminated with a female RJ-45 connector, use the
RJ-45 coupler cable included in the package to connect the IntelliJack to the network cable (recommended installation.)
Installing the IntelliJack 11
If the end of the cable is terminated with a male connector, connect the
network cable directly into the Ethernet uplink port.

Mounting the IntelliJack After connecting the IntelliJack to the network, use the two provided screws to

mount the IntelliJack in any standard NEMA-WD6 cubicle opening or wall outlet.
If the cubicle or wall opening has a depth of fewer than 1.5 inches, does not support the NEMA-WD6 standard, or does not have pre-drilled screw holes, mount the IntelliJack using the extension ring, as shown below.
NOTE: The extension rings are designed to stack on top of one another. If you need more than 0.3 inches of clearance, simply snap an additional extension ring to the back of the IntelliJack.
CAUTION: Make sure the vents along the edges of the IntelliJack faceplate are clear of any obstructions. If necessary, install the extension ring on recessed openings to allow airflow to vents.
12 CHAPTER 1: INSTALLING THE NJ220 INTELLIJACK
Connecting the Local
Power Supply (Optional)
If your network does not support Power Over Ethernet, or if you are not using a single-port or multi-port Ethernet power supply, you must purchase a local power supply from 3Com (see “Obtaining Optional Components” on page 4). To connect the local power supply to the IntelliJack, please follow these steps:
1 Route the power cable through the strain relief of the IntelliJack (as shown in the
diagram below).
2 Securely mount the IntelliJack on a wall.
3 Plug the power cable into the IntelliJack. 4 Secure the local power supply and cable to the wall.
5 Plug the local power supply into the power source.

Checking the LEDs 13

WARNING: Use the local power supply available from 3Com. Failure to do so may result in damage to the IntelliJack, or may result in a hazardous situation.
Connecting Devices to
the IntelliJack
After the IntelliJack is installed and mounted, connect your networking devices (such as computers, printers, etc.) to any of the four switched ports on the front of the IntelliJack.
If you installed the adapter plate with pass-through ports, connect the appropriate device(s) to the port(s).
Checking the LEDs You can verify the IntelliJack installation by checking the LEDs.
LED Description
n On—The IntelliJack is connected to the network and a link has
been established.
n Off—There is no connection to the network.
(LAN)
n On—The IntelliJack is receiving power (local or via the network).
When you first connect power to the IntelliJack, there will be a delay of approximately 5 seconds. The power LED light will blink several times before remaining solid on.
(Power)
n Off—The IntelliJack is not receiving power.
Additionally, each of the switched ports has a green LED which lights when a device is connected. Port 1 also has an amber LED which lights when the IntelliJack is forwarding power to a connected device.
14 CHAPTER 1: INSTALLING THE NJ220 INTELLIJACK
INSTALLING THE
2

System Requirements The machine you install the software on should meet the following requirements:

C
ONFIGURATION MANAGERS
Once you have installed the NJ220 hardware, you need to configure it for use on your particular network. To configure the NJ220, install the Local and Central Configuration managers.
NOTE: You will use the Local Configuration Manager for initial configuration of the NJ220 on your network. It’s usually easiest if you load this software on a laptop and use it to configure IntelliJacks as you install them.
The NJ220 Central Configuration Manager is used for advanced configuration and management of one or more NJ220s on your network. This software should be installed on the machine you plan to use to manage your NJ220s from a remote location—perhaps the same console you use for SNMP management.
Pentium processor

Installing the Local and Central Configuration Managers

Minimum of 15MB disk space
Windows 2000, Windows XP Pro, or Windows NT 4.0 with Service Pack 6
installed (While Windows 95 and Windows 98 are not recommended operating systems for use with management platforms, the Configuration Manager software may work with them) or Windows Vista.
Run the following steps to install the Configuration Manager software:
1 Insert the Configuration Manager software CD into your Windows 2000,
Windows XP Pro, Windows NT, or Windows Vista computer.
16 CHAPTER 2: INSTALLING THE CONFIGURATION MANAGERS
2 If your computer is configured to Auto-Play CDs, the installation will start
automatically. If not, double-click the setup.exe icon on the CD, and you will see this window:
3 Click Next to continue.
Installing the Local and Central Configuration Managers 17
4 Carefully read the license agreement. If you agree, click “Yes, I accept” and Next
to continue.
5 The installation will present Readme Information. This is also found in the
Readme.txt file on the installation CD. Please read the information and click Next to continue.
18 CHAPTER 2: INSTALLING THE CONFIGURATION MANAGERS
6 Enter your user and organization names. You can also specify whether you want
the management programs to be available to just you or to anyone that may use the computer you’re installing these applications on. Select the option you prefer and click Next.
Installing the Local and Central Configuration Managers 19
7 The program files will be installed in the directory C:\Program
Files\3Com\IntelliJack. If you want to change the location of the installation, click Change. Otherwise click Next to accept the default location and continue.
20 CHAPTER 2: INSTALLING THE CONFIGURATION MANAGERS
8 Select a typical or custom setup and click Next. The Typical installation will install
both the Local Configuration Manager and the Central Configuration Manager on your system. The Custom installation option lets you install just one of the programs if you wish.
9 Review the settings you selected and click the Install button.
Installing the Web Configuration Manager 21
10 When the installation has completed, click the Finish button to close the
installation utility.

Installing the Web Configuration Manager

The installation utility will create two shortcut icons on the Desktop--one for the Local Configuration Manager and one for the Central Configuration Manager.
You can also launch the programs from a program group you can access from the Start menu. The program group folder is labeled 3Com IntelliJack and can be found under the Programs menu.
NJ220 IntelliJacks are capable of being discovered and managed through a standard web browser. The Web Configuration Manager lets you access and control IntelliJacks from any Web-enabled computer on your network.
In order to enable the Web Configuration Manager you will need the following:
A servlet-compliant web server or stand alone servlet engine
Internet Explorer 6.0 or later; Netscape 7.0 or later web browser
NJ220 Installation CD
The following instructions assume a scenario where the operating system being used is Microsoft Windows 2000 and the servlet engine is Apache Tomcat, Version 4.1. You may have to slightly alter this process if your specific environment is different. Note that Apache Tomcat requires Sun Microsystems’ Java Development Kit (JDK) 1.4. These are available at no charge from Sun.
Loading...
+ 57 hidden pages
