Zyxel VMG3625-T50B-GB01V1F Product Data Sheet
VMG8623-T50B/VMG3625-T50B/
EMG5523-T50B/EMG3525-T50B Series
Dual-Band Wireless AC/N VDSL2/Ethernet Gateway
The VMG8623-T50B/VMG3625-T50B/EMG5523-T50B/EMG3525-T50B
Series provides high-speed Internet access to meet the worldwide market
requirements for triple-play services. Featuring the built-in 2x2 802.11ac
WLAN function that relieves troublesome wirings, this model offers extreme
coverage for great WiFi user experience. Moreover, the user-oriented
design allows this model to meet every customer’s own style while providing
powerful and practical functions.
Benefits
Ultra speed for UHD IPTV service
The Series supports broadband access performance, which further enables
operators to offer better UHD 4k IPTV services.
AC1200, dual-band WiFi with
867 Mbps* 802.11ac 2x2 Wave 2
technology
TR-069 remote management
(Data model: TR-098/TR-181)
USB 2.0 high throughput for
file sharing
Excellent routing and QoS
capability to prioritize
applications as needed
NAT, firewall with SPI and DoS
for better security
Stand-alone and wall
mountable
Supports VoIP SIP protocol
with 3-way conference
(VMG8623-T50B/EMG5523-T50B)
calls
Datasheet VMG8623-T50B/VMG3625-T50B/
EMG5523-T50B/EMG3525-T50B Series
VDSL2 supports super
vectoring up to profile
(VMG8623-T50B/VMG3625-T50B)
35b
The triple-play powerhouse
The Series is built with sophisticated QoS and multicast traffic shaping features like IGMP v1/2/3 snooping and VLAN
capabilities for premium video delivery services. To wireless IPTV operators, its built-in 2x2, 802.11ac chip is the top choice.
Carrier-class WiFi for seamless mobility
Rated as AC1200, the Series delivers speeds of up to 867 Mbps* over 5 GHz and 300 Mbps* over 2.4 GHz. For better user
experience, four models offer dual-band, d WiFi with performance-boosting features such as Multi-User MIMO (MUMIMO) and Beamforming for simultaneous, lag-free streaming and gaming experiences. In addition, its ability to create
multiple WiFi networks with up to 4 SSIDs helps operators to easily create individual WLAN networks for video, data and
guests.
TR-069 remote management with TR-181 issue-2 support
The Series supports TR-69 that simplifies remote configuration, upgrade and management and therefore improves cost
effectiveness and customer satisfaction. Additional support to the latest TR-181 issue-2 data model also enhances service
providers’ visibility on subscriber LAN networks for improved customer assistance.
Datasheet VMG8623-T50B/VMG3625-T50B/
EMG5523-T50B/EMG3525-T50B Series
2
Specifications
System Specifications
Wireless Standard
• 802.11 b/g/n/ac 2.4 GHz, data rate
300 Mbps
• 802.11 a/n/ac 5 GHz, data rate 867
Mbps
Router/Bridge Features
• IEEE 802.1D transparent bridge &
basic spanning tree
• PPPoE (RFC 2516)
• PPPoA (RFC 2364)
• MAC encapsulation routing/IPoE
• Network Address Translation (NAT)
• NAT virtual server (port forwarding)
• DHCP client/server/relay with DHCP
option 43/60/61/125
• DNS proxy/dynamic DNS
• Static/Policy route
• IGMP v1, v2, v3
• IPv4/IPv6
Wireless
• Wireless Protected Setup (WPS)
• WMM
• WPA2/WPA2-PSK with TKIP & AES
• Security type
• Multi SSID: up to 4
• MU-MIMO support
VLAN/QoS
• 802.1Q VLAN tagging/un-tagging
• Support flexible traffic classification
Firewall & Security
• Generic packet filter
• DoS attack prevention
• Parental control
USB
• File sharing
• 3G back up with external 3G USB
dongle
Management
• Web/HTTP: 3 level log-in via SSH or
Telnet
• Firmware upgrade via web/TFTP/
FTP/TR-069 RPC method
• Text based configuration
• Configuration backup/update/
restore default via Web
• Configurable access control for
remote management (interface and/
port number)
• DSL forum TR-069, TR-098***
• TR-111 and TR-181 i2
• SNMP v1, v2
• Rom-D support
• UPnP port forwarding rules on page
(VMG8623-T50B/EMG5523-T50B)
VoIP
• Section Initiating Protocol (SIP), RFC
3261
• Codec: G.711 a/μ (64K), G.726 (24/32K),
G.722
• G.168 echo cancellation
• Fax/modem detection and passthrough
• Voice Active Detector (VAD)
• Comfort Noise Generator (CNG)
• Dynamic jitter buffer
• DTMF detection and generation
• DTMF relay by in-band and out-ofband (RFC 2833, SIP Info)
• SIP account (URL type included)
• On hook, off hook and flash
detection
• Caller ID
• Call forwarding (No condition, busy,
no answer)
• Call transferring
• Call hold/Call retrieve
• Three way conference
• Call waiting
• DNS SRV
(VMG8623-T50B/VMG3625-T50B)
VDSL
• G.993.1 VDSL
• G.993.2 VDSL2, Band 997, 998, Over
POTS
• Support VDSL profiles: 8a/b/c/d,
12a/b, 17a, and 35b
• G.vector
(VMG8623-T50B/VMG3625-T50B)
ADSL
• G.992.1 (G.dmt)
• G.992.2 (G.lite)
• ANSI T1.413 compliant
• G.992.3 (ADSL2)
• G.992.5 (ADSL2+)
• G.INP support
Hardware Specifications
• WAN: one 10/100/1000 Mbps
• Ethernet port RJ-45
• Wireless:
■
Two internal antennas
(2.4 GHz)
■
Two internal antennas
(5 GHz)
Interface Description
• Ethernet: four 10/100/1000 Mbps
• Ethernet ports RJ-45 (8P8C)
• USB: one USB 2.0 host
• FXS: two RJ-11
• DSL: one RJ-11
(VMG8623-T50B/EMG5523-T50B)
(VMG8623-T50B/VMG3625-T50B)
Button
• One Power on/off button
• One reset button
• One WPS on/off button
• One WLAN on/off button
Status LEDs Indicators:
• Power/System
• WAN
• Internet
• LAN
• WLAN-2.4G/WPS
• WLAN-5G/WPS
• Phone
(VMG8623-T50B/EMG5523-T50B)
Power Consumption
• 12 V DC/ 1.5 A
Environmental Specifications
Temperature:
• Operating: 0°C to 40°C
• Storage: -30°C to 70°C
Humidity:
• Operating humidity:
10 to 90% RH (Non-condensing)
• Storage humidity:
10 to 95% RH (Non-condensing)
Physical Specifications
• Item dimensions :
220 x 153 x 35 mm
(8.66” x 6.02” x 1.38”)
• Item weight : 325 g (0.67 lb.)
Certification
• Safety: CE-LVD
• EMC: CE
Package Content
• Wireless IAD
• Power adapter
• Ethernet cable
• Quick start guide
• Safety warning card
* The maximum wireless data is derived from
IEEE Standard 802.11 specifications. Actual data
transfer rate will vary from network environment
including: distance, network traffic, building site
materials/construction, interference from othe
wireless devices, and other adverse conditions.
Datasheet VMG8623-T50B/VMG3625-T50B/
EMG5523-T50B/EMG3525-T50B Series
3
