ZyXEL o2 HomeBox 6641 Quick Start Manual
What’s in the box?
œ HomeBox 6641
LAN cable (yellow)
DSL connecting cable (grey)
œ configuration CD
• Comprehensive manual and
cabling instructions
• Installation wizard for DSL
and WLAN (Windows 8 / 7 /
Vista / XP SP3)
Power adapter
101508 05/14
Konfi gurations-CD
Es wird keine Software installiert
Handbücher inklusive
Systemvorraussetzungen
Windows 7 / Vista / XP
für die Geräte
œ HomeBox 3232
œ
Box 4421
œ
Box 6431
Version
1.00 - 101457
Telefónica Germany
GmbH & Co. OHG
80992 München
www.o2online.de
Hotline: 55222*
aus dem œ Netz oder
0180 40 55 222*
aus dem dt. Festnetz
* 20 Ct./Anruf
Wichtig. Legen
Sie bitte zuerst
diese CD ein.
Konfi gurations-CD
Es wird keine Software installiert
Handbücher inklusive
Systemvoraussetzungen
Windows 8 / 7 / Vista /
XP SP3
für die Geräte
œ
HomeBox 6641
œ
Box 4421
œ
Box 6431
Version
2.10 - 101505
Telefónica Germany
GmbH & Co. OHG
80992 München
www.o2online.de
Hotline: 55222*
aus dem œ Mobil funknetz oder
0180 40 55 222*
aus dem dt. Festnetz
* 20 Ct./Anruf
Wichtig. Legen
Sie bitte zuerst
diese CD ein.
Quick start guide
œ HomeBox 6641
Comprehensive information
You will find detailed information about setting up and configuring your œ HomeBox 6641 in the comprehensive manual on
the œ CD supplied as well as under http://o2.de/hilfe/o2homebox2.
How to contact us – 7 days a week, 24 hours a day:
On the Internet:
www.dsl.o2.de
Contact options:
www.o2.de/kontakt
By phone:
55 222* from the œ mobile network or
0180 4055 222* from German landlines
By fax:
01805 880 088**
* 20 cents/call ** 14 cents/minute from German landlines; maximum 42 cents/minute from mobile networks
Your œ HomeBox in detail
WLAN/ WPS
and DECT
push-buttons
DSL Power
So ISDN
LAN 1–4
Internet
On/Off
switch
USB (e.g. Printer
or HDD) Reset
LAN 1–4 Phone InfoWLAN DSLPower
LED view
Side view USB connection
Rear side
DECT
Telefónica Germany GmbH & Co. OHG, Postbox 60 09 40, 22209 Hamburg
We appreciate you choosing of œ
and hope that you will now enjoy
the many benefits of your new DSL
connection.
Do you need help with the
installation?
Scan the QR code or visit our website under
http://o2.de/hilfe/o2homebox2 to take a look at the
installation video for the œ HomeBox 6641.
Note: After setting up the router, also
install the DSL Soforthilfe from the folder
area on the œ CD or from our website.
This free œ software helps you with access
to the Internet and optimises your WLAN
connection
e.g. USB mass storage
LED Signal Status
Power
Flashing
System is starting up
Lights up constantly The system has started and is operating
Off
Power supply disconnected or general equipment
fault
Lights up constantly
The unit’s software is updating; unit is restarting
or resetting
LAN 1–4
Flashing Transferring data
Lights up constantly Active connection
Off No active connection
WLAN
Flashing quickly Transferring data
Lights up constantly WLAN active
Flashing WPS activated
Off WLAN not active
DECT
Lights up constantly DECT function on
Flashing DECT scanning for new unit
Off DECT function off
DSL
Flashing slowly Pilot signal transmitting
Flashing quickly The œ HomeBox 6641 is being synchronised.
Lights up constantly DSL connection successfully established
Off Internal DSL fault
Internet
Flashing Transferring data
Lights up constantly Internet connection established
Flashing quickly
Faulty access details
(e.g. incorrect password)
Phone
Flashing
Active call
Lights up constantly
Active line
Off
Line not active
Info
Flashing quickly
Authentication in progress
Lights up constantly
PIN OK; œ phone connection established; when
the unit has completed registration with œ, the
Info LED will disappear
Lights up constantly
1. œHomeBox 6641 is waiting for a PIN
to be entered
2. Incorect PIN, waiting to re-enter PIN
3. Maximum authentication attempts
(5 times) reached
Flashing quickly
PIN OK; waiting for authentication
More information
Install in just 3 steps –
it’s this easy:
Preparing the
installation
Insert the supplied œ CD and
follow the instructions to install
your œ HomeBox. If the œ CD is
not supported by your operating
system* or if you do not have
a CD drive, then manual
installation is possible as an
alternative. To do this, first use
the yellow LAN cable to connect
your œ HomeBox with your
PC or establish a direct WLAN
connection (see ‘Initial setup of
your WLAN’). Then just continue
with point 2.
1 3
Start surfing
Your œ HomeBox 6641 is now
fully configured for access to
the Internet and to make phone
calls.
2
Set up Internet
connection
The following set-up wizard
will help you to configure
and activate your Internet
connection. Alternatively,
you can also complete the
configuration manually by
accessing your œ HomeBox
6641 menu at any time via
your browser at o2.box or
192.168.1.1. You will also find
information about this in the
manual (also on the œ CD or
on our website under
http://o2.de/hilfe/o2homebox2).
*
Note
Customers with a MAC OS or older Windows operating system (Windows XP and previous versions) should please use
the manual on the CD supplied to set up the œ HomeBox. To do that, open the document using Adobe Acrobat Reader.
Initial WLAN set-up
1. Switch on your computer’s WLAN function and ensure
that the WLAN function is activated on your
œ HomeBox 6641. (WLAN LED is lit – activated /
WLAN LED off – activate using push-button)
2. a) Use the œ CD provided to set up the WLAN network via the configuration wizard or configure the WLAN
network using your Windows computer as follows:
b) Double-click on ‘Wireless network connection’. In the new window you will be shown all of the available
wireless networks within range. (The path to open your network settings can vary depending on your
operating system.)
3. Selec t the wireless network from your œ HomeBox 6641. You will find the name
of the network (SSID) and the network keÿ (WPA2 key) on the name plate on the
back of your œ HomeBox 6641.
4. Click ‘Connect’ and enter your WLAN network key (WPA2 key).
5. The W LAN connection has now been completely set up.
On the œ
CD provided, you will find brief instructions in Russian as well as the initial steps
to set up your œ HomeBox.
On the œ
CD provided, you will find brief instructions in Turkish as well as the initial steps
to set up your œ HomeBox.
Cabeling of your œ HomeBox
6641: the connection types
Below you will find an example showing the cabling of your œ HomeBox 6641.
Select the option that matches your connection type and connect the equipment accordingly.
After successfully setting up a connection, ple ase change the WLAN key for the router to maintain security.
You will find more information under http://www.dsl.o2.de/.
Analogue and ISDN connection for œ:
Regardless of the selected product you can still connect analog and ISDN devices for telephony use.
TAE socket Mains socket
Integrated DECT
Integrated 2.4 GHz
and 5 GHz WLAN
LAN cable
USB mass storage
Analogue phone
ISDN phone
DECT phones
Computer
DECT push-
button
WLAN/ WPS
push-buttons
o2 HomeBox 6641
Mat.-Nr.:101505
Serial Number: S317000001
SSID: o2-WLANxx
WPA2-Schlüssel:
MAC-Adresse:EC43F6ABB1D3
ZyXEL Communications Corp.
PN:VMG7947-B40A-DE01V1S
Netzteil:12V
MM/YY:04/13
Made in China
2.5A
XXXX XXXX XXXX XXXX
