ZTE WP822R User Manual
ZTE WP822R
CDMA Wireless Phone
User Manual
Copyright © 2009 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced,
translated or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right
to make modifications on print errors or update specifications without
prior notice.
Release 1.0
Manual number:
Aug, 2009
079584500000
1
Contents
1 General Information ............................................................... 6
1.1 Welcome ...................................................................................... 6
1.2 For Your Safety ................................................................... 6
1.3 Cleaning and Maintenance .......................................................... 9
1.4 Limit Warranty ........................................................................... 10
1.5 Limitation of Liability .................................................................. 11
2 Getting Started ..................................................................... 13
2.1 Configuration ............................................................................. 13
2.2 Technical Specifications ............................................................ 13
2.3 Appearance ............................................................................... 14
2.4 LCD Screen Description ............................................................ 16
2.5 Installation ................................................................................. 17
2.6 Power Supply ............................................................................ 18
2.7 Switching Power ........................................................................ 19
2.8 Connecting to Network .............................................................. 19
3 Basic Operations ................................................................. 20
3.1 Making a Call ............................................................................. 20
3.1.1 Making a Domestic Call ..................................................... 20
3.1.2 Making an International Call .............................................. 20
3.1.3 Dialing a Number in the List ............................................... 21
3.1.4 Hand-free ........................................................................... 21
3.1.5 Redialing ............................................................................ 22
2
3.2 Answering a Call ........................................................................ 22
3.3 During a Call .............................................................................. 22
3.4 Making a Three-way Call ........................................................... 23
3.5 Menu Functions ......................................................................... 23
4 Contacts ............................................................................... 25
4.1 Finding Records ........................................................................ 25
4.2 Viewing Records ........................................................................ 25
4.3 Adding New ............................................................................... 26
4.4 Speed Dial List .......................................................................... 27
4.4.1 Setting Speed Dial ............................................................. 27
4.4.2 Viewing and Making Speed Dial ........................................ 28
4.4.3 Erase contacts in speed dial list ........................................ 28
4.5 Memory Status .......................................................................... 29
5 Messages ............................................................................ 30
5.1 New Message ............................................................................ 30
5.2 Creating Message ..................................................................... 30
5.3 InBox ......................................................................................... 31
5.4 OutBox ....................................................................................... 31
5.5 Erasing Message ....................................................................... 32
5.6 Voice Mail .................................................................................. 32
5.7 Preformatted Message .............................................................. 33
5.8 Message Settings ...................................................................... 33
5.9 Send To Multi ............................................................................ 34
6 Call History .......................................................................... 35
3
7 SMS Services ...................................................................... 37
8 Extra .................................................................................... 38
8.1 Alarm ......................................................................................... 38
8.2 Calculator .................................................................................. 38
8.3 World Clock ............................................................................... 40
8.4 Hotline ....................................................................................... 40
8.5 Autodial Timer ........................................................................... 41
9 Phone Info ........................................................................... 42
10 Settings .............................................................................. 43
10.1 Silence All ................................................................................ 43
10.2 Call Settings ............................................................................ 43
10.2.1 Call Forwarding ................................................................ 43
10.2.2 Call Waiting ...................................................................... 44
10.3 Sound ...................................................................................... 45
10.4 Display ..................................................................................... 45
10.5 Call Timers .............................................................................. 46
10.6 Security .................................................................................... 46
10.7 Voice Privacy ........................................................................... 48
10.8 Minute Alert ............................................................................. 48
11 Text Input............................................................................ 49
11.1 Multitap Mode .......................................................................... 50
11.2 Numbers Mode ........................................................................ 50
11.3 eZiText Mode ........................................................................... 50
11.4 Symbols Mode ......................................................................... 51
4
12 Troubleshooting ................................................................. 52
5
1 General Information
1.1 Welcome
Thank you for choosing ZTE WP822R CDMA Wireless Phone
(hereinafter referred to as “phone”). To guarantee your phone always
in its best condition, please read this manual carefully.
The pictures, symbols and contents in this manual are just for
your reference. They might not be completely identical with your
phone. Please subject to the material object.
1.2 For Your Safety
Some electronic devices are susceptible to electromagnetic
interference sent by phone if inadequately shielded. Please keep
using phone at least 20 cm or as far away as you can from TV
sets, radio and other automated office equipment so as to avoid
electromagnetic interference
Operating phone may interfere with medical devices like hearing
6
aides and pacemakers, or other medical devices in hospital.
Consult a physician or the manufacturer of the medical device
before using phone.
Be aware of the usage limitation when using phone at places
such as oil warehouses, or chemical factories, where there are
explosive gases or explosive products being processed, because
even if your phone is in idle state, it still transmits radio frequency
(RF) energy. Therefore, power off your phone if required.
Do not touch the antenna while calling.
Keep the phone out of the reach of small children. The phone
may cause injury if used as a toy.
Do not put other things on the terminal to avoid overlaying
radiator.
Keep the antenna free from obstructions and position the
antenna straight up. This will ensure best call quality.
Please use original accessories or accessories that are
7
authorized by the manufacturer. Using any unauthorized
accessories may affect your phone’s performance, and violate
related national regulations about telecom terminals, or even
endanger your body.
As your phone can produce electromagnetic field, do not place it
near magnetic items such as computer disks.
Do not expose your phone to direct sunlight or store it in hot
areas. High temperatures can shorten the life of electronic
devices.
Prevent liquid from leaking into your phone.
Please disconnect external power supply and do not use your
phone during thunderstorm.
Unplug the external power adapter or remove battery when your
phone is not in use, esp. for a long period of time.
It is highly recommended to charge the battery before initial use.
The battery might have been discharged during storage and
8
delivery.
Do not unplug the connector of the data cable from phone, and
not install or remove battery, when the power is on.
Keep phone power on and in service area when make
emergency call. Pick up the receiver or press HANDFREE key
and enter emergency call number in status of standby, and then
CALL/REDIAL key to send.
Do not attempt to disassemble the phone by yourself. Non-expert
handling of the devices may damage them.
Keep the antenna at least 20cm away from your body.
1.3 Cleaning and Maintenance
The phone is non-waterproof, please keep it dry and store in
shady and cool place.
If you want to clean your phone, please use clean fabric that is a
bit wet or anti-static. Do not use harsh chemical cleaning solvents
or strong detergents to clean your phone, such as alcohol,
9
dilution agent and benzene. Power-off your phone before you
clean it.
Use phone within a temperature range of -10°C~55°C and a
humidity range of 25%~85%.
1.4 Limit Warranty
The warranty does not apply to defects or errors in the product
caused by:
(a) Reasonable abrasion.
(b) Misuse including mishandling, physical damage, improper
installation, unauthorized disassembly of the product.
(c) Water or any other liquid damage.
(d) Any unauthorized repair or modification.
(e) Power surges, lightning damage, fire, flood or other events
outside ZTE’s reasonable control.
(f) Use of the product with any unauthorized third party
products such as generic chargers.
(g) Any other cause beyond the range of normal usage for
products.
End User shall have no right to reject, return, or receive a
refund for any product from ZTE under the above-mentioned
situations.
This warranty is end user’s sole remedy and ZTE’s sole liability
10
for defective or nonconforming items, and is in lieu of all other
warranties, expressed, implied or statutory, including but not limited
to the implied warranties of merchantability and fitness for a
particular purpose, unless otherwise required under the mandatory
provisions of the law.
1.5 Limitation of Liability
ZTE shall not be liable for any loss of profits or indirect, special,
incidental or consequential damages resulting from or arising out of or
in connection with using this product, whether or not ZTE had been
advised, knew or should have known the possibility of such damages
1.6 Declaration
We, ZTE Corporation, declared that:
The user is cautioned that changes or modifications not
expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with
11
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for
help.
Caution:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
12
2 Getting Started
2.1 Configuration
Parts Quantity
Phone set 1
Handset (Receiver) 1
Ni-MH Battery 1
External Power Adapter 1
Antenna 1
Receiver Line 1
2.2 Technical Specifications
z Frequency Range： TX:824 ～849MHZ
RX:869 ～894MHZ
z External Interface：a. External power socket (DC)
b. Data interface DATA
c. Antenna connector ANT
z Power Supply：100-240V ( AC) 50/60Hz
z Dimension (Length × Width × Thick)：210mm×170mm×72mm
z Battery:
Continuous Standby Time: Approx. 120 hours (Subject to
Network).
13
Continuous Talk Time: Approx. 3 hours (Subject to Network).
Please refer to the real objects for the related parameters about
the battery and charger.
2.3 Appearance
4
1
2
3
Key Description
1. MENU/SELECT key
5
6
7
8
9
10
Enter main Menu, select or confirm options in Menu
and sub-menu.
In condition of character input, confirm the character
chosen.
2. 0~9 Number key
Use the number keys to enter numbers and
characters.
Make Speed Dial.
14
3. # key, * key
4. Up/Down/Left/Right
key (Scrolling key)
5. CLR/BACK key
Differs in different mode, option or function menu.
Scrolling key used as selection key for selecting the
commands and items shown on screen display.
In standby mode, press and hold Up key for seconds
to enable or disable the Silence All, press Left key to
enter Call history menu, press Right key to view
Contacts records.
Move the cursor when inputting letters. Scroll the
cursor in menu option and display.
Press CLR key to erase character while editing or
dialing. Hold CLR key to erase all the characters.
Press BACK key to cancel operating, exit to previous
pop-up window interface.
Lights on when external power supply
6. EXT PWR Indicator
7. MESSAGE key
8. EXIT key
9. CALL/REDIAL key
10. HANDFREE key
connected.
Press MESSAGE key to enter Messages menu.
End an active call or reject calls.
Power on/power off.
Exit from any window interface to standby mode.
In the condition of off-hook or hand free, send
telephone number or redial.
Hand free call.
Note： “Press the key” in manual means pressing certain key once,
“Hold the key” means pressing key for 2 or 3 seconds.
15
2.4 LCD Screen Description
These icons may appear on screen display of your phone.
Signal strength
New Message
Mute
CDMA 1x service mode
Incoming call or calling
Phone lock
Alarm clock
New Voice Mail
Battery Indicator
Voice Privacy
16
Loading...
