User Guide

ZTE Compel™

Copyright © 2014 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced,

translated or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve
the right to make modifications on print errors or update
specifications without prior notice.

microSDHC is a trademark of SD, 3C-LLC.
The Bluetooth® word mark and logos are registered trademarks

owned by Bluetooth SIG, Inc.
SRS TruMedia is a trademark of SRS Labs, Inc. SRS TruMedia

technology is incorporated under license from SRS Labs, Inc.
SRS TruMedia™, a feature-rich audio solution tuned specifically
for mobile devices, provides a cinema-like surround
headphone performance with deep, rich bass.

Version No. : V1.0
Edition Time: July 2014
Manual No. : 079584506476

Devices purchased for use on AT&T’s system are designed for
use exclusively on AT&T’s system. You agree that you won’t
make any modifications to the Equipment or programming to
enable the Equipment to operate on any other system. A voice
plan is required on all voice-capable devices, unless specifically
noted otherwise in the terms governing your agreement. Some
devices or plans may require you to subscribe to a data plan.

Your phone is designed to make it easy for you to access a
wide variety of content. For your protection, we want you to be
aware that some applications that you enable may involve the
location of your phone being shared. For applications available
through AT&T, we offer privacy
an application may use the location of your phone and other
phones on your account. However, the AT&T privacy tools do
not apply to applications
the terms and conditions and the associated privacy
each location-based service to learn how location information
will be used and protected. In addition, your AT&T phone may be
used to access the Internet and to down load, and/or purchase
goods, applications, and services from AT&T or elsewhere from
third parties. AT&T provides tools for you to control access to
the Internet and certain Internet
not be available for certain devices which bypass AT&T controls.

AT&T may collect certain types of information from your device
when you use AT&T services to provide customer support and
to improve its services. For more information on AT&T’s Privacy
Policy, visit att.com/privacy.

controls that let you decide how

available outside of AT&T. Please review

policy for

content. These controls may

Contents

Getting Started .................................................... 1

Phone Setup ..................................................... 1

Powering Your Phone On/Off ...................................2

Getting Around ..................................................4

Get to Know Your Phone ........................................5

Key Functions ....................................................6

Phone Calls ........................................................12

How to Make Calls ..............................................12

How to Receive Calls ...........................................13

Adjusting Your Call Settings ....................................15

Contacts ...........................................................18

Importing and Exporting Contacts ............................18

Creating a Contact .............................................19

Adding a Contact to Favorites .................................19

Searching for a Contact .......................................20

Creating a New Group .........................................20

Entering Text ......................................................21

Google™ Keyboard .............................................21

Google Voice Typing ........................................... 22

TouchPal X Keyboard ..........................................22

Choosing Touch Input Settings ............................... 25

Contents i

Messaging ........................................................26

Message Box ................................................... 26

Sending a Message ............................................ 26

Changing Message Settings ................................... 27

Email .............................................................. 29

Creating an Email Account ....................................29

Receiving Email ................................................ 29

Composing and Sending an Email ............................30

Replying to or Forwarding an Email ...........................30

Deleting an Email Account .....................................31

Email Settings ...................................................31

Connecting to the Internet ..................................... 32

Adding a New GMS/UTMS/LTE Connection .................. 32

Turning on Wi-Fi® .............................................. 33

Connecting to a Wi-Fi Network ............................... 33

Checking the Wi-Fi Network Status ........................... 33

Browsing the Internet ...........................................34

Opening a Web Page .......................................... 34

Browsing Options .............................................. 34

Opening Another Browser Window ...........................35

Using Bookmarks .............................................. 35

Changing Browser Settings ...................................36

Using Google Chrome™ .......................................36

Bluetooth® ....................................................... 37

Using Bluetooth ................................................ 37

Entertainment ...................................................39

Taking Pictures with Your Camera ............................39

Adjusting Camera Settings .................................... 39

Sharing a Picture ...............................................40

Opening Your Gallery .......................................... 41

Shooting Video with Your Camcorder ........................42

Adjusting Your Video Settings .................................42

Adjusting Other Settings ...................................... 42

Sharing a Video ................................................ 43

Playing Your Videos ............................................43

Adding Music to Your Phone ..................................44

Playing Your Music .............................................45

Making Memorable Memos ................................... 47

Applications ......................................................48

Clock ...........................................................48

Calculator ......................................................48

File Manager ...................................................48

Kingsoft Office .................................................49

Note ............................................................49

Task Manager ..................................................49

Timer ...........................................................50

Contents iiiii

Contents

Twitter®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Voice Dialer ....................................................50

Google™ Applications ............................................51

Google Search and Google Now™ .............................51

Gmail™ ......................................................... 52

Google Play

Using Google Calendar ........................................ 54

Google Maps™ .................................................54

Google Music™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Google+™ ...................................................... 55

Hangouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Voice Search ................................................... 55

YouTube™ ......................................................55

Phone Settings ................................................... 56

Mobile Network Services ...................................... 56

Sound Settings ................................................56

Display Settings ................................................ 56

Setting Date and Time ........................................ 57

Language Settings ............................................. 57

Managing Your Device Memory ............................... 57

Security Settings ...............................................58

Managing Applications ........................................60

™ Store

............................................ 53

Factory Reset .................................................. 61

Managing Other Settings ......................................62

For Your Safety ...................................................64

General Safety .................................................64

FCC Regulations ...............................................66

RF Exposure Information (SAR) .............................. 67

Hearing Aid Compatibility (HAC) .............................69

CTIA ............................................................70

Distraction ..................................................... 72

Product Handling .............................................. 72

Electrical Safety ............................................... 76

Interference ...................................................76

Explosive Environments ......................................78

Specifications ....................................................79

Warranty .........................................................80

Limited Warranty .............................................. 81

How to Get Warranty Service ................................. 82

Other Warranty Programs .....................................82

vContentsiv Contents

Getting Started

Phone Setup

Installing the micro-SIM Card and Battery

Power off your phone before installing or
replacing the battery or micro-SIM card.

Remove the back cover as shown.

Insert the micro-SIM card into the card

slot with the cut corner oriented as shown.

Insert the microSDHC™ (sold separately)

with the gold-colored contacts facing down.

Carefully insert the battery with the

contacts located against the metal springs.
Push down on the battery until it is
fully seated.

Replace the back cover.

Getting Started 1vi

Charging the Battery

Note: For best performance, charge the battery fully prior to
using the phone for the first time.

Insert the charger’s connector into the

charging port. Be sure to insert the
connector in the correct orientation.
Do not force the connector into the port.

Plug the charger into a standard

AC wall outlet.

When the battery is fully charged, unplug the charger and

disconnect it from the phone.

Powering Your Phone On/Off

Make sure the micro-SIM card is in your phone and the battery is
charged.

• Press and hold the Power Key to power on your phone.

• To turn it off, press and hold the Power Key to open the

options menu. Tap Power off OK.

Setting Up Your Phone for the First Time

When you first power on your phone after you purchase it or
reset it to factory settings (see Phone Settings – Factory Reset),
you need to set up your phone settings before using it.

Tap the language field to select the language you want to use

and then tap .

If prompted, follow on-screen instructions to connect to a

Wi-Fi network.
Configure the Google location options and tap .
You will be prompted to accept the terms of Google service.

Tap to complete setup.

Switching to Sleep Mode

To save battery power, Sleep Mode suspends your phone in
a low-power-consumption state while the display is off. Your
phone also goes into Sleep Mode by itself when the display is
automatically turned off after a certain period of time, which you
can set by pressing System settings Display Sleep
from the home screen.

Press the Power Key to switch to Sleep Mode.

Waking Up Your Phone

Press the Power Key to activate your screen display.
Tap and hold the screen to unlock the screen.
Note: If you have set an unlock pattern, PIN, or password for

your phone (see Phone Settings – Security) you’ll need to draw
the pattern or enter the PIN/password to unlock your screen.

2 Getting Started

3Getting Started

Getting Around

Touch Control

Use the touch screen to control your phone. The controls on
your touchscreen change dynamically depending on the tasks
you’re performing.

Tap the buttons, icons, or applications to select items or to

open applications. Keep your finger on an item to see the

available options.
Swipe the screen to scroll up, down, left, or right.
Drag and drop to move particular items across the screen.
Pinch with two fingers or double-tap the screen to zoom in/

out on a web page or an image.
Note: You can view the phone screen in portrait or landscape

orientation simply by holding it upright or turning it on its side.

Get to Know Your Phone

Headset jack

Light &

proximity

sensors

Earpiece

Volume

keys

Home

key

Back key

Indicator

Power key

Touch screen

Speaker

Flash

Micro USB
charging
port

Menu
key

Camera

lens

Getting Started Getting Started

54

Key Functions

Key Function
Power Key Press and hold to turn phone on/off, change

sound setting to silent/vibration/sound, set
to Airplane mode, or to restart the phone.

Press to switch your phone to Sleep Mode.
Press to wake up your phone.

Home Key Press to return to the main home screen

from any application or screen.
Press and hold to access Google Now.

Menu Key Press to see the options for the current

screen.
Press and hold to see recently used

applications.

Back Key Press to go to the previous screen.
Volume Keys Adjust the volume of the phone.

Getting Started Getting Started

Home Screens

You can customize your home screens. Set your own wallpaper,
add the widgets or application shortcuts you need, or remove
them as you like.

Status and
notification bar

Widget

Shortcuts

Navigating Your Home Screens

Your phone comes with three home screens, giving you more
space to add more items. Simply swipe your finger to the left or
right to see each home screen.

Choosing Your Wallpaper

Tap and hold a blank part of the home screen and tap

Wallpaper.
Tap Wallpaper for home screen or Wallpaper for lock screen.

Tap Gallery, Live, Photos, or Wallpapers and choose the

image or animation you want to use as the wallpaper.

Favorite shortcuts

76

Tap OK (for Gallery images) or Set wallpaper.
Note: Live wallpapers and Photos are not available for the

lock screen.

Adding Items to Your Home Screen

Tap and hold a blank part of the home screen and tap

Widgets or Apps.
Tap and hold the icon of the item you wish to add and then

drag it to a home screen thumbnail at the bottom.

Removing Items from Your Home Screen

Tap and hold the item you want to delete until appears on

the screen.
Drag the item to and release your finger.

Status and Notification icons

Your phone will tell you exactly what’s going on by showing you
simple icons. Here’s what they mean.

Indicators and Icons

Indicator What it means Indicator What it means

GPRS connected No signal

EDGE connected Signal strength

3G connected

4G LTE
connected

Mobile data in
use

Ringer off

Creating a Folder

On a home screen, tap and hold an app icon and drag it to .
You can add more apps to the folder by dragging icons to the

folder.
Tap the folder to open it and access items in the folder.
To name the folder, open it and tap Folder.
Enter a name and tap Done.

Deleting Items from a Folder

Tap a folder to open it.
Tap and hold an icon and drag it to .

Getting Started Getting Started

Airplane mode Vibrate mode

Battery empty Bluetooth on

Battery low

Battery partially
drained

Battery full Alarm set

/

Battery charging

Connected to a
Wi-Fi network

Wired headset
connected

98

Indicator What it means Indicator What it means

New SMS/MMS

New email Upcoming event

New Gmail
message

Problem with
SMS/MMS
delivery

Missed call

Call in progress Sending data

/

Song is playing

GPS on USB connected

microSDHC
card removed

Call on hold

New Wi-Fi
network
detected

Downloading
data

Updates
available

Using the Notifications Panel

The Notifications panel provides quick
access to alerts including new messages,
emails, and software updates.

• To open the Notications panel, tap
the top of the home screen and swipe
down with your finger.

• Swipe left or right to clear individual
notifications or tap to clear all.

•

Tap to access the full settings menu.

• To close the Notications panel, swipe
up from the bottom of the screen or
press .

Reopen Recently Used Applications

Press and hold from any screen. The phone will display

applications you used recently.

Tap the application you want to open.

Getting Started Getting Started

1110

Phone Calls

How to Make Calls

There are many ways to make a call with your phone, and they’re
all easy to do.

Calling from the Dialer

From the home screen, tap > .
Enter the phone number with the

on-screen keypad. Tap to
delete wrong digits.

Tap to place the call.
Tip: To make international calls, tap

and hold the 0 Key to enter the “+”.

Calling from Your Contacts

From the home screen, tap .
Swipe your finger to scroll the

contacts list and tap next to
the contact you want to call.

Tips:

• You can search for a contact by tapping the search box at the

top of the screen and entering the contact name.

• You can also access your contacts by tapping

All Contacts.

Calling from Your Call History

From the home screen, tap .
Tap next to the number you want to call.

Calling from a Text Message

If a text message contains a phone number that you want to call,
you can make the call while viewing the text message.

From the home screen, tap .
Tap the conversation and then the message that contains the

phone number you need.

Tap the number.
Tap Call.

How to Receive Calls

Answering a Call

Slide down to answer the call.

Rejecting a Call

Slide up to reject the call.
Drag up to send a text message to the caller. Choose the

default message or send a custom one.

Muting a Call

During a call, you can mute your microphone so that the person
you are speaking to cannot hear you, but you can still hear them.

Phone Calls

Phone Calls

1312

Tap Mute to turn your microphone off. To turn your microphone
back on, tap Mute again.

Putting a Call on Hold

During a call, you can put it on hold by tapping More > Hold.
Tip: If you accept an incoming call while you’re on another call,

the first call automatically goes on hold. Tap More > Swap to
switch between the two callers.

Turning the Speakerphone On/Off

Tap Speaker during a call to turn the speakerphone on. Tap
Speaker again to turn off the speakerphone.

Adjusting Your Call Settings

You can open the Call Settings menu by tapping
Settings.

Tap to select a ringtone. You can choose

Phone ringtone

Vibrate pattern

Vibrate when
ringing

from default ringtones, music, and voice
recordings.

Choose from five different vibration
patterns.

Check the box to enable this option.

Adding a Call

During a call, tap More > Add call and dial a number. When you
call another number, the first call automatically goes on hold.

Swapping Calls

To switch between callers, tap More > Swap.

Merging Calls

To merge two calls and create a conference call, tap More >
Merge calls.

Note: The maximum number of callers on a call varies by carrier.

Ending a Call

Tap

to finish a call.

Phone Calls

Select a voicemail service provider

Voicemail

Dialpad touch
tones

Quick responses Edit Quick response to rejected callers.

Fixed Dialing
Numbers

Phone Calls 1514

(your carrier is the default), or edit the
voicemail number if necessary.

Check this box to enable audible touch
tones for numbers on the dial pad.

Restrict outgoing calls to a fixed set of
numbers. To do this you must know your
SIM’s PIN2 code. Not all carriers support
this functionality.

Adjusting Your Call Settings (continued)

Choose a TTY mode after connecting
the TTY device to the phone’s headset

TTY mode

Hearing aids

DTMF tones

Speed dial Set speed dialing keys.

Noise reduction

Auto-Answer

Call Barring
Settings

port.
A TTY device can allow people who

have hearing or speech disabilities to
communicate by telephone.

Turn on/off hearing aid compatibility.
When you turn on the hearing aid
compatibility and use a hearing aid with a
Telecoil to answer the phone, it will help
you hear more clearly during the phone
call.

Set the length of dual-tone multi­frequency (DTMF) signal tones: Normal
or Long.

Check this box to improve the quality of
voice calls.

Set the phone to answer automatically
after one, three, or five seconds.

Forbid certain types of calls.

Phone Calls

Forward your incoming calls to a
different number. You can choose when

Call forwarding

Additional
settings

SIP Accounts Set up Internet calling accounts.

Use Internet
calling

IMS Account Enable/disable IMS service capability.

Phone Calls 1716

to forward: Always forward, Forward
when busy, Forward when unanswered,
or Forward when unreachable.

Caller ID: Choose whether people you
call can see your number.

Call waiting: See new incoming calls while
you’re on another call.

Choose to use Internet calling for all calls
when data network is available, only for
Internet calls, or have the phone ask for
each call.

Contacts

You can add contacts on your phone and synchronize them
with the contacts in your Google account or other accounts that
support contact syncing.

To see your contacts, tap on the home screen. From there,
you can tap the tabs on the top to quickly switch to Favorites
or Groups.

Importing and Exporting Contacts

You can import or export contacts from/to your micro-SIM card,
or microSDHC card. This is especially useful when you need to
transfer contacts between different devices.

Importing Contacts from the SIM Card or Exporting to
the Card

From the Contacts screen, press Import/export.
Choose to import or export contacts. If you have more than

one account set up on your phone, you will need to select the
account to which you’d like to import contacts. If not, your
phone will automatically display the contacts.

Tap the contacts you want to import or export.

• For import, tap and hold a contact and tap Import, or
tap Import all to import all contacts.

• For export, tap the contacts you want to export and tap ,
or tap to export all contacts.

Importing Contacts from microSDHC card or Exporting
to microSDHC card

From the Contacts screen, press Import/export.
Choose to import or export contacts. If you have more than

one account set up on your phone, you will need to select the
account to which you’d like to import contacts.

Note: Files will be saved to/pulled from the microSDHC card

when one is inserted in the phone.

• For import, you should have vCard les saved on the

microSDHC card. If there’s more than one vCard file,
choose to import one, multiple, or all vCard files. Tap the
vCard file and tap OK.

• For export, select a vCard type and tap OK to create the file

on the phone/microSDHC card.

Creating a Contact

From the Contacts screen, tap to add a new contact.
Tap AT&T Address Book to choose where to save the

contact.

Enter the contact name, phone numbers, email addresses,

postal addresses, and other information.

Tap DONE to save the contact.

Adding a Contact to Favorites

From the Contacts screen, tap the contact you want to add

to Favorites.

Contacts18

Contacts 19

Tap next to the contact’s name.

Searching for a Contact

Tap the search box at the top of the Contacts screen.
Enter the contact name you want to search for. Matching

contacts will be listed.

Creating a New Group

From the Contacts screen, tap .
Tap .
If you have added contact accounts other than the phone,

tap to choose an account for the new group.

Enter the group name.
Tap Add member and select the contacts you wish to be the

group members.

If necessary, tap Default below RINGTONE or

NOTIFICATION RINGTONE to set a special ringtone for
incoming calls or messages from the group members.

Tap DONE.
To send messages to the group members, you can tap a

group and then press Send group message.

20

Contacts

Entering Text

When you tap a field that needs text or numbers, a keyboard
automatically appears on the screen. Open the Notifications
panel and tap Choose input method to change input method.

Google Keyboard

The Google keyboard provides a layout similar to a desktop
computer keyboard. Turn the phone sideways and the keyboard
will change from portrait to landscape.

To use the landscape keyboard, from the home screen, press

System settings Display Auto-rotate screen.

Note: The landscape keyboard is not supported in all applications.

• Tap the alphabetic keys to enter letters. Tap and hold the keys

to enter associated accented letters or numbers. For example,
to enter È, tap and hold and the available accented letters
and number 3 appear. Then slide your finger to choose È.

• Tap to use uppercase or lowercase letters. This key also
changes to indicate the current case you are using: for
lowercase, for uppercase, and when locked in uppercase.
Tap and hold to lock the keyboard in uppercase.

Entering Text 21

• Tap to delete any text you have entered.

•

Tap to select numbers and symbols. You can then tap to
access more.

• Tap to enter miniature icons, such as expressions,
astrological signs, and animals.

• Tap to use Google’s networked voice input.

• Tap and hold and then release it to change the input

language or the Google keyboard settings.

Google Voice Typing

Google Voice typing uses the Google voice recognition service
to convert speech to text. You must have a data connection on
a mobile or Wi-Fi network to use it.

Flick down the status bar when entering text and tap Choose

input method Set up input methods Google voice
typing. Tap to access the voice typing feature when you are

using the Google keyboard.

When you see the microphone image, speak what you want

to type.

You can continue entering text to keep it or to delete it.
Tip: Say “comma,” “period,” “question mark,” “exclamation mark,”

or “exclamation point” to enter punctuation.

TouchPal X Keyboard

The TouchPal X keyboard offers three layouts: T+, T12, and T26.

To Switch the Keyboard Layout

Tap to select a layout.

The T26 layout

•

Tap the alphabetic keys to enter letters.

• Tap to use uppercase or
lowercase letters. This key also
changes to indicate the current case
you are using: for lowercase, for
uppercase, and when locked
in uppercase.

• Slide right on to enable word prediction. Slide left on
to disable word prediction.

• Tap to change the input language.

• Tap to enter digits, symbols and emoticons. Tap or to

access more. Tap to go back to entering letters.

• Tap or tap and hold to delete text before the cursor.

• Tap to access the quick settings of TouchPal keyboard.

• Tap to open text editing options. You can select, cut, copy,

paste, and delete text, or move the cursor.

• Tap to use voice input.

• Tap to hide the on-screen keyboard. Tap the text field again

to show the keyboard.

Entering Text22

Entering Text

23

The T12 layout

Tap a key repeatedly until the desired letter or symbol appears.
If word prediction is enabled (
and choose the right word.

The T+ layout

Tap to enter the left letter on the key; Double-tap to enter the
desired letter/symbol on the key. If word prediction is enabled
(

), just tap the keys and choose the right word.

), just tap the keys once

To Enable and Use TouchPal Curve

On the TouchPal X keyboard screen, tap and check the

box next to Curve® - Word gesture and tap OK.

Move your finger from letter to letter on the keyboard to trace

a word without lifting the finger until you reach the end of the
word.

Note: TouchPal Curve is only available in the T26 layout.

Start of

the word

Tips:

• To enter a single letter, tap it.

• Lift your nger at the end of the word. A space is added

automatically when you begin to trace the next word.

®

End of
the word

Choosing Touch Input Settings

Choose the touch input settings by pressing System
settings Language & input from the home screen.

In the KEYBOARD & INPUT METHODS section, you can set
the default input method and choose the settings for input
methods.

Entering Text 25Entering Text24

Messaging

Your SMS (text message) and MMS (multimedia message) are
combined into one menu under .

Message Box

Instead of an inbox and outbox your phone organizes all
messages you sent and received into one box, where messages
exchanged with the same number are grouped into one
message thread on the Messaging screen. You can tap a thread
to see the conversation you have had with someone.

Message threads are sorted in chronological order with the
latest one on top.

Sending a Message

From the home screen, tap .
Tap .

Enter the recipient’s number or name in the To field. As you
type, matching contacts will appear. Tap a suggested contact to
add as a recipient or tap to access your contacts or call logs.

Tap the Type message field and enter your message.

• Press to insert a smiley, contact, or Quick Text.

• If you are sending an MMS, tap to attach a file to the

message.

Tap to send your message.

Messaging26

Note: Add an attachment to a text message and it will be
converted into an MMS automatically. Likewise, if you remove all
attachments from an MMS, it will automatically become a text
message.

Changing Message Settings

The phone’s message settings are pre-configured for you to use
immediately. To change them, press Settings from the
Messaging screen.

Storage settings:

• Delete old messages: Delete old messages as limits

are reached.

• Text message limit: Set the maximum number of text

messages allowed in a single thread.

• Multimedia message limit: Set the maximum number of

multimedia messages allowed in a single thread.

Text (SMS) message settings:

• Manage SIM card messages: Manage the messages stored

on your SIM card.

• Service Center: Enables you to view and edit the service

center number.

Multimedia (MMS) message settings:

• Auto-retrieve: Automatically download multimedia

messages.

• Group messaging: Set to use MMS to send a single message

when there are multiple recipients.

Messaging

27

Display settings:

• Bubble and background: Set the appearance of message

bubble and background.

Notification settings:

• Notifications: Show message notifications in the status bar.

• Select ringtone: Choose a ringtone for your incoming

messages.

• Vibrate: Make your phone vibrate when a new message

arrives.

Signature settings:

• Edit signature: Edit your signature, which can be added

automatically to outgoing messages.

• Add signature: Add the signature to all outgoing messages.

WAP push switch settings:

• Enable wap push receiving: Allow your phone to receive

WAP push.

Emergency alert settings:

• Receive emergency alerts: Choose the types of alerts

you’d like to receive.

• Notification for unread alerts: Set a notification reminder

for every 10 minutes.

• Alerts notification preview: Preview settings for alert tones

and vibration cadence.

Email

With the Email application, you can access your email from
various providers, including Yahoo!® and Gmail.

Creating an Email Account

From the home screen, tap .
Enter your email address and password.
Tap Next to let the phone retrieve the network parameters

automatically.

Note: You can also enter these details manually by tapping
Manual setup or when automatic setup fails.

Follow the on-screen instructions to finish the setup. Your

phone will display your email inbox and start to download
email messages.

Tip: To add more email accounts, open Email to get the Inbox
screen and press Settings ADD ACCOUNT.

Receiving Email

When you are in an email account, tap to download recent
emails.

You can adjust how often your account downloads new email by
pressing Settings name of the account Inbox check
frequency. Tap an option to select it.

Email 29Messaging28

Composing and Sending an Email

After creating an email account, you can compose and send
email messages.

From your inbox, tap .
Tap the To field and enter the recipient’s address or tap

to select a contact or group. When you enter the address,
matching contacts on the phone will be displayed. Separate
each recipient with a comma.

Tip: You can also press Add Cc/Bcc to add more

recipients.

Enter the subject and the content of your email.
Press Attach file to add files to the email.
Tap Send to send the message.

Replying to or Forwarding an Email

From your inbox, open the email you want to reply to or

forward.

Tap or to reply to or forward the email. You can also

tap to reply to all recipients of the email.

Enter the contents/recipients of your email.
Tap Send.

Deleting an Email Account

From your inbox, press Settings.
Tap the account you want to delete and then tap Remove

account.

Tap OK to confirm. All email messages in the account will

be deleted.

Email Settings

General settings apply to all email accounts you add.

From your inbox, press Settings General.
Make the changes you want and press when you’re finished.

Email30

Email

31

Connecting to the Internet

Your phone’s impressive networking capabilities allow you to
access the Internet or your corporate network with ease. You
can use default connection settings to connect to the web via
your mobile network (GSM/UMTS/LTE) or Wi-Fi. The GSM/UMTS/
LTE connection can be enabled/disabled manually. From the
home screen, press System settings Mobile networks
and check or uncheck the Data enabled check box.

Adding a New GSM/UMTS/LTE Connection

To get connected via GSM/UMTS/LTE, you need a data plan
with your service provider. If the GSM/UMTS/LTE settings are not
pre-configured on your phone, please contact your provider to
get the necessary information.

From the home screen, press System settings

Mobile networks Access Point Names.

Tap .
Tap each item to enter the information you receive from your

service provider.

Press Save to complete.

Tip: To set the APN to default settings, press Reset to
default

Continue

.

Turning on Wi-Fi

Wi-Fi provides wireless Internet access over distances of up to
300 feet (90 meters).

Open the Notifications panel and tap WI-FI.

Connecting to a Wi-Fi Network

From the home screen, press System settings

Wi-Fi. The Wi-Fi network points, or “hotspots,” that your

phone has detected are displayed with their names and
security settings.

Tap a network to connect to it. If security features are

implemented, you’ll need to enter a password and then
tap Connect.

To disconnect from a network, tap the network name and

then tap Forget.

Checking the Wi-Fi Network Status

You can check the Wi-Fi network by looking at the icon in the
status bar. Or, tap the network the phone is currently connected
to on the Wi-Fi screen. You can then check the network status
from the pop-up window.

Connecting to the Internet32

Connecting to the Internet 33

Browsing the Internet

Your phone has two options for Internet access. Use the Browser
or Google Chrome to view web pages and search for information.

From the home screen, tap .

Opening a Web Page

• Tap the address bar, enter the website you want to browse,

and tap Go.

• Tap beside the address bar or press Bookmarks. Tap

a bookmark to open it.

• Press Bookmarks. Choose an item from the HISTORY
tab or SAVED PAGES tab.

Browsing Options

While viewing most web pages, you can do the following:

• Scroll: Swipe the screen in any direction.

• Zoom out: Tap the screen or pinch two fingers together.

• Zoom in: Tap the screen or spread two fingers apart.

•

Go back: Press to return to the page you viewed previously.

• Go forward: Press Forward.

• Refresh the page: Press Refresh.

• Find text on the page: Press Find on page and type the

terms you want to search for.

• Send the page URL to friends: Press Share page and
select how you want to send the URL.

Browsing the Internet34

• Follow a link: Tap a link on the web page to open it.

•

Save the page for offline reading: Press Save for offline
reading. To read saved pages, press Bookmarks SAVED
PAGES.

Opening Another Browser Window

You can have multiple windows open in the browser. While in the
browser, tap to open a new window. To view your open
windows, tap . Tap on a window to close it.

Using Bookmarks

To bookmark a web page, open it and tap Save to
bookmarks, or press and then tap Save to bookmarks.
Give the bookmark a name and tap OK.

Editing a Bookmark

From the home screen, tap .
Press Bookmarks.
Tap and hold the bookmark you want to edit until the shortcut

menu pops up.

Tap Edit bookmark.
Edit the name (Label) or location (Address), and then tap OK

to save it.

Deleting a Bookmark

From the home screen, tap .
Press Bookmarks.
Browsing the Internet 35

Tap and hold the bookmark you want to delete until the

shortcut menu pops up.

Tap Delete bookmark OK.

Changing Browser Settings

Press Settings from a browser window to change browser
settings.

Using Google Chrome

Use Google Chrome to browse the Internet. Chrome on your
ZTE Compel can sync bookmarks, browsing history, and opened
tabs from your Google account.

From the home screen, tap Chrome.
Read the terms of service and tap Accept and Continue.
You can choose to Sign in to Chrome to sync it with your

open tabs, bookmarks, and more from your computer. If you
choose No thanks, you can sign in later via the settings menu.

To enter a URL, tap the web address bar, enter an address and

tap Go.

Scroll to navigate and tap links to open them. Use a pinching

gesture to zoom out. Spread your fingers apart to zoom in.
Press to access additional settings.

To open a new browser tab, tap New tab.

Syncing Chrome

From the home screen, tap Chrome Settings
SIGN IN TO CHROME Sign in.

Bluetooth

Bluetooth is a short-range wireless communication technology.
Phones or other devices with Bluetooth capabilities can
exchange information wirelessly within a distance of about 32
feet (10 meters). The Bluetooth devices must be paired before
the communication is performed.

Using Bluetooth

Before you begin, place the Bluetooth device in pairing mode.

From the home screen, press System settings and
slide the Bluetooth switch to the On position to turn on
Bluetooth. When Bluetooth is on, the icon will appear in the
status bar.

Tap Bluetooth. Your phone will automatically search for

Bluetooth devices and will show all visible devices in range.
Tap the device you want to pair with.
If necessary, confirm that the Bluetooth passkeys are the

same between the two devices and tap Pair. Alternately,

enter a Bluetooth passkey and tap Pair.

Pairing is successfully completed when the other device

accepts the connection or the same passkey is entered.

Browsing the Internet36

Bluetooth 37

Notes:

• The Bluetooth passkey may be fixed for certain devices,
such as headsets or hands-free car kits. You can try entering
0000 or 1234 (the most common passkeys), or refer to the
documents for that device.

• To allow compatible Bluetooth devices to find your phone
for pairing, tap Z830 on the Bluetooth settings screen. Your
device will be visible for 2 minutes.

Entertainment

Taking Pictures with Your Camera

Your phone has a 5-megapixel camera.
From the home screen, tap .
Zoom in or out by pressing either Volume Key. To change

color effects, tap and select an option. To change shot
modes, tap and select an option.

Tap to take a picture. To view it, tap the picture

thumbnail in the corner of the screen.

Adjusting Camera Settings

Before taking a photo, you can tap
camera settings.

to open the following

Grid

Self-timer

Auto-review

Bluetooth38

Entertainment 39

Set the composition line to help you to aim the
camera at the subject.

Set a time delay before the camera takes a
picture automatically after you tap the shutter
icon, or turn off this feature.

Set the lapse time for viewing a photo after you
take it.

Adjusting Camera Settings (continued)

Picture size Choose the size of the photo.

Shutter
tone

Turn the shutter tone on or off.

Sharing a Picture

After taking a picture, tap the thumbnail in the corner of the

screen, tap the screen, and then tap . If the icon is not
visible, tap the screen first.

Scroll through options to send via text messaging or email,

Picasa™, and more.

Opening Your Gallery

Gallery helps you view pictures and
play videos. You can also do some
basic editing of your pictures, set them
as wallpaper or contact photos, or
share with friends.

From the home screen, tap

Gallery.

Tap an album.
Tap a photo or video to view it.

Number Function

Tap to return to the album or thumbnails of all

1

the pictures and videos in the album, which are
displayed in a grid.

2

3

Swipe horizontally to see more; double tap a
picture to view it in full screen.

Delete, edit, share, or set the picture as contact

photo, wallpaper, or lock screen wallpaper.
4 Tap for additional settings.
5 Browse the album contents in a slideshow.

1

2

3

5

4

Entertainment40

Entertainment

41

Shooting Video with Your Camcorder

From the home screen, tap .
Zoom in or out by pressing either Volume Key.
Tap to begin recording and to stop.
Tap the video thumbnail in the corner of the screen to view

the video you’ve just taken.

Tip: Take a still photo while recording by tapping .

Adjusting Your Video Settings

Before recording a video, you can tap
following camcorder settings.

Video quality

Choose the video quality as 1280×720,
720×480, 640×480, or MMS Video.

Time lapse Set the lapse time for recording video.

Silence
camcorder

Check this option if you want to capture silent
video clips.

to open the

Adjusting Other Settings

You can tap to open the following other settings.

Geo-tag

Restore defaults Restore default camcorder settings.

Choose to store location information with
each picture or video you take.

Sharing a Video

After recording a video, tap the

thumbnail in the corner of the

1

2

screen, tap the screen, and then
tap .

Scroll through options to send via text

messaging or Gmail, Picasa, and more.

Playing Your Videos

From the home screen, tap Video
Player. This will open your video library

and show the video files saved in your
memory card. Tap a video file to
start playing.

Number Function

1 Video name.
2 Rotate the video.
3 Crop or fit the video to the screen.
4 Pause or resume playback.
5 Use video pop.

6 Tap to save the frame as a separate photo.

7 Tap to lock the screen.

3

7

6

5

4

Entertainment 43Entertainment42

Adding Music to Your Phone

You can add music to your phone’s internal storage or to a
removable microSDHC card (see Phone Setup).

Note: Steps may vary depending on your operating system.
Connect your phone to your computer with a USB cable.
Tap Media device (MTP).

Note: If you have a microSDHC card in your phone, you may be
presented with additional options. Open the Notifications panel
and tap Connected as an installer Media device (MTP).

On your PC, choose to view files through Windows Explorer. If

you have a Mac, visit http://www.android.com/filetransfer to
download the necessary software.

Choose whether you want to add files to your phone’s

internal storage or to the microSDHC card, and then drag and
drop the files you want to transfer.

When you’re finished transferring files, open the Notifications

panel and tap Connected as a media device Charge
only. You may now safely disconnect your phone from the
computer.

Playing Your Music

You can play the audio files stored in

1

your phone’s microSDHC card in Music.
From the home screen, tap

Music to access the music player.

Select Albums/Artists/Songs/

2

Playlists/Folders/Genres to find the

songs you want to play.

Tap an item from the list to start

playing.

Adjust the volume with the

Volume Keys.

3
4

5

Number Function

1 Song and artist information.
2 Album artwork and lyrics (if available).

3 Drag the slider to jump to any part of the song.

4 Tap to open the current playlist.

5

Playback control. Skip songs or pause and resume
playback.

6 Add the song to your favorites.

7

Tap to shuffle the songs in the playlist or toggle
repeat modes.

7

6

Entertainment 45Entertainment44

Creating Playlists

Playlists help you organize your music files.
Tap next to the song in the music library.
Tap Add to playlist.
Tap New.
Type the playlist name and tap Save.

Managing Playlists

Tap the Playlists tab in the music library to see your playlists.
Tap next to a playlist.
Tap Play, Add to favorites, Rename Playlist, or Delete

Playlist.

Adding a Song to a Playlist

Tap next to the song in the music library.
Tap Add to playlist.
Tap a playlist.

Setting a Song as Ringtone

Tap next to the song in the music library.
Tap Use as ringtone.
Tap Phone Ringtone or Notification Ringtone.

Making Memorable Memos

Sound Recorder enables you to record your voice memos.
From the home screen, tap Sound Recorder.
Tap to start recording.
Tap to stop recording or tap OK to cancel recording.
Tap to play the memo.
Tip: You can find your recordings by tapping My records.

Play Any Saved Memo

From the home screen, tap Sound Recorder.
Tap My recordings.
Tap the title of a memo to play it.
Note: You can also tap next to the memo to delete, share,

rename, tag, trim, view file details, or use as a ringtone.

Entertainment 47Entertainment46

Applications

Clock

From the home screen, tap Clock.
Tap a default alarm to configure it or tap to create a new

alarm.
Set up the alarm options, such as time, repeat, and alarm sound.

Tap SAVE to save and exit.
Tap next to an alarm to turn on the alarm.

Calculator

From the home screen, tap Calculator.
Tip: Tap or to open the tip calculator. You can also turn

the phone to landscape to see all of the calculator buttons.

File Manager

From the home screen, tap File Manager. The folders are
organized by category, phone storage, and SD card.

• Tap folders and les to access stored items.

• Tap Phone > to create a new folder in the current directory.

Kingsoft Office

Create, view, and edit Word documents, PowerPoint
presentations, spreadsheets, and other types of files. From the
home screen, tap Kingsoft Office.

Tip: Tap and scroll to view options.

Note

From the home screen, tap Note to save and view your text
notes.

Tap a note category.
Tap to create a new note.
Enter your text and tap Save to save it.

Tap a note to view it. You can also edit, delete, share, or export it.

Task Manager

From the home screen, tap Task Manager to view or stop
applications.

• Tap a task in the Tasks tab to force stop or disable the app,

uninstall the app, clear data and cache, or move the app
between the internal storage and the memory card; or tap
next to a task to close it.

• Tap the Apps tab to manage all the apps on your phone.

• Tap the Resources tab to view the real-time system resources

information.

Applications48

Applications 49

Tip: If your phone is running slow, close applications you are not
using by pressing and holding and swiping left or right on
applications you wish to close.

Timer

From the home screen, tap Clock Stopwatch or
Countdown.

Note: You can set up to 20 laps with the stopwatch.

Twitter

From the home screen, tap Twitter and sign up for or

sign in to your account.

Tap to compose a tweet.

Voice Dialer

From the home screen, tap Voice Dialer and speak a
command.

Google Applications

Signing in to your Google account lets you synchronize Gmail,
Calendar, and Contacts between your phone and the web. If you
don’t have an account, you can easily create one.

Tap a Google application that needs a Google account, such

as Gmail or Google+.

If you’ve got a Google account, tap Existing. Enter your user

name and password and then tap . (Or tap New if you don’t
have a Google account.)

Read the instructions and tap OK.
Set the backup and restore option and tap

Google Search and Google Now

Find whatever you’re looking for with Google Search. Google
Now tailors your search options over time, learning your
preferences and making more accurate predictions for your
needs. Google Now will also keep track of what you’re doing and
appear when you need it, like showing the next appointment on
your calendar and what the traffic is like to get to it.

Performing a Search

From the home screen, tap Google Google. You can type
in search terms, or say “OK Google” to begin a voice search.

You will see results for your search. To search images, places,
and more, tap an option on the bar at the bottom of the screen.
For additional web results, simply scroll down the screen.

.

50

Applications

Google Applications 51

Gmail

Gmail is a web-based email service that’s configured when
you sign in to your Google account. Depending on your
synchronization settings, the Gmail on your phone can be
automatically synchronized with your Gmail account on the web.

Creating and Sending an Email Through Gmail

From the home screen, tap Google Gmail.
Tap .
Enter an email address in the To field. If you’re sending the

email to several people, separate the email addresses with
commas. You can add as many recipients as you want.

Enter the email subject, and then write your email. To add an

attachment, press Attach file.

Tap to send your email.

Adding Another Account

From the home screen, press System settings Add
account Google.

Choose to add an existing account or create a new one and

follow on-screen instructions to finish account setup.

Accessing Account Settings

From your Gmail inbox, tap
Tap an account name, or tap General settings to change

settings for all accounts.

SETTINGS

.

Google Play Store

Google Play Store gives you access to thousands of free and
paid apps, games, books and magazines, music, and movies.

From the home screen, tap Play Store.

Navigating Google Play

From Play Store, you will have multiple ways to search for apps,
games and more.

Tap a category to browse popular apps, games, movies,

books, and music organized by popularity or category.

Tap to search the Play Store for a specific item, such as a

game or app.

To install, tap the app and follow instructions. Once installed,

you will see a notification in the Notifications panel. Open
the app from this notification or by locating the app in the
App tray .

Note: A Google Wallet™ payment method is required to
purchase apps.

Adding a Password

Help prevent unauthorized app purchases by requiring a
password.

While in Google Play, tap SETTINGS Require password
for purchases.

Tap the option you want to use, then enter the Google

password and tap OK.

Google Applications52

Google Applications

53

Using Google Calendar

From the home screen, tap Calendar to use Google Calendar,
Google’s time management application. You can use the
calendar to schedule appointments, including meetings and
other events. Your appointments will be displayed on the screen
as they are scheduled. You can also synchronize appointments
to your Google account, which enables you to manage your
schedule online on your PC.

Accessing Calendar Settings

While in the calendar, press Settings.
Tap an account name, or tap General settings to change

settings for all accounts.

Google Maps

Find local businesses, view maps, and get driving directions.

Google Music

You can access up to 20,000 songs from your music collection
by storing them in the cloud. You can also purchase music
through Google Play with this app.

From the home screen, tap Play Music to access Google
Music.

The app searches your online library and your phone for music
and playlists before displaying your combined music library,
organized by GENRES, ARTISTS, ALBUMS, and SONGS. You can
tap My Library to view your library or tap Playlists to
view existing playlists.

Google+

Connect with friends and family via Google’s social networking
site. Set up circles to organize people into groups for sharing
content. Create hangouts for group video chats, upload photos
and videos, and much more.

Hangouts

With Hangouts, you can bring groups of friends together into a
simple group conversation with text, photos, and video chat.

Voice Search

Find what you’re looking for by speaking your search terms into
your phone.

YouTube

View videos and share your own with your friends, family, and
the world.

Google Applications 55Google Applications54

Phone Settings

Mobile Network Services

From the home screen, press System settings Mobile
networks to enable or disable data service, allow data services

when roaming, or set access point names for data access.
Note: Data roaming may incur significant roaming charges.

Sound Settings

From the home screen, press System settings Sound
to adjust volumes, toggle sound and mute, set up ringtone and
notification sound, and select system sounds.

Tap Silent mode to turn off all sounds except media and alarm,
or enable silent mode with vibration.

Display Settings

You can adjust your phone’s display settings. From the home
screen, press System settings Display.

• Brightness: Set the brightness of the display.

• Wallpaper: Select a background image for the home screen or

lock screen.

• Auto-rotate screen: Change the orientation of some on-

screen content based on the position of the phone.

• Sleep: Set the length of time of inactivity before the screen

turns off.

• Daydream: Control what happens when the phone is docked

and/or sleeping.

• Font size: Set the font size of the text on the screen.

• Pulse notification light: Flash the notification light to notify

you of missed calls, new messages, and other events.

• Touch key light duration: Set the key light duration.

Setting Date and Time

From the home screen, press System settings Date

& time.

Uncheck the Automatic date & time and Automatic time

zone check boxes if you want to set the time, date, and time

zone by yourself.

Set date, time, time zone, and date/time format.

Language Settings

You can change the language of your phone system in two
simple steps.

From the home screen, press System settings

Language & input Language.

Tap a language to select it.

Managing Your Device Memory

From the home screen, press System settings Storage.
You can view the space information of the microSDHC card as
well as the phone storage.

Phone Settings56

Phone Settings 57

• Unmount/Mount SD card: You can unmount the microSDHC

card to safely remove it, or mount the card.

• Erase external SD card: Erase all data on the microSDHC card.

Security Settings

Protect your phone and micro-SIM card from unauthorized use.

Protecting Your Phone with a Screen Unlock Pattern

Creating your screen unlock pattern
From the home screen, press System settings

Security Screen lock Pattern.

With a finger, draw your pattern and tap Continue.
Draw the pattern again and tap Confirm.
Press the Power Key to lock the screen.
Tip: Uncheck the Make pattern visible check box if you want to

hide the pattern as you draw it on the screen.

Unlocking the Screen with Your Pattern

Press the Power Key to wake up the screen.
Draw the pattern you set to unlock the screen.
If you make a mistake, your phone will ask you to try again.

Cannot Recall Your Screen Unlock Pattern?

You have up to five attempts to unlock your phone. If you still
cannot recall the screen unlock pattern, tap Forgot pattern?
and enter your Google account user name and password to
reset the screen unlock pattern.

Note: You must sign in or create a Google account on your
phone before using the preceding method to reset the pattern.

Protecting Your Phone with a PIN or Password

Creating a PIN or Password
From the home screen, press System settings

Security Screen lock.

Tap PIN or Password.

Enter a numeric PIN or any password you like, and tap
Continue.

Enter it again and tap OK to confirm.

Unlocking the Screen with Your PIN or Password

Press the Power Key to wake up the phone.
Enter the PIN or password you set.

Tap .

Cannot Recall Your PIN or Password?

You have up to five attempts to unlock your phone. If you
still cannot recall the PIN or password, you will need to either
contact your carrier for the PUK (PIN Unlock Key) code for the
device or return it for service.

Disabling Screen Lock Settings

If you have created an unlock pattern, PIN or password, you can
disable it.

Phone Settings 59Phone Settings58

From the home screen, press System settings

Security Screen lock.

Draw the screen unlock pattern or enter the PIN/password

you have created.

Tap Next None.

Setting Up Credential Storage

This lets you select applications to access secure certificates
and other credentials.

Enabling Secure Credentials
From the home screen, press System settings

Security.

Tap Install from SD card to install certificates from your

microSDHC card.

Deleting Secure Credentials
From the home screen, press System settings

Security.

Tap Clear credentials OK to clear credentials.

Managing Applications

From the home screen, press System settings Apps to
see apps installed on your phone and manage them.

Tap an app in the DOWNLOADED, RUNNING, or ALL tabs to see
its information. You can stop the app, uninstall the app, clear data

and cache, or move the app between the internal storage and
the memory card.

Note: Not all applications can be moved or uninstalled.
From the home screen, press System settings Security

and check the Unknown sources check box if you want to install
applications from sources other than Google Play Store.

Note: Installing applications from unknown sources may
compromise your phone and personal data.

Make sure that you select an application developed for your
phone and processor type before installing it.

Copy the application file to the microSDHC card and install

the card on your phone.

From the home screen, tap File Manager, and open the

folder where the application file is.
Tap the file to start installation.
Read the installation instructions that come with the

application and follow them to complete the setup.

Factory Reset

Reset your phone to factory default settings. All your personal
data from the phone’s internal storage will be erased, including
your Google account, system and app data and settings, and
downloaded apps. You can also erase the data on the memory
card during the process.

From the home screen, press System settings Backup
& reset Reset to Factory Reset phone Erase everything.

Phone Settings 61Phone Settings60

WARNING! All your personal information and downloaded
applications on your phone will be erased after resetting the
phone.

Managing Other Settings

Search Settings

From the home screen, tap Google Google
Settings.

You can set searchable items.

Voice Interaction

From the home screen, press System settings
Language & input Voice Search or Text-to-speech output to

set text-to-speech and voice recognition options.

Accessibility

From the home screen, press System settings
Accessibility to configure options for accessibility-related

applications.
TalkBack: Device provides spoken feedback, such as describing

what you touch, select, and activate, to help blind and low-vision
users.

Captions: Tap to enable or disable captions.
Magnification gestures: When this feature is turned on, you can

zoom in and out by triple-tapping the screen.

Large text: Enable this to use a large font size.

Power button ends call: When enabled, you can press the
Power Key to end phone calls without turning the screen off.

Auto-rotate screen: Change the orientation of certain

on-screen content based on the position of the device.
Speak passwords: Check this box to enable the speak

passwords function.
Accessibility shortcut: When this feature is turned on, you can

quickly enable the accessibility feature.
Text-to-speech output: Change settings for text to speech and

adjust the rate at which your phone speaks, to help blind and
low-vision users.

Touch & hold delay: Select the time delay for the phone to
distinguish finger touch and hold gestures.

About Phone

From the home screen, press System settings About
phone to check system updates, phone status and battery use,

or view legal information and software version.

Phone Settings 63Phone Settings62

For Your Safety

General Safety

Don’t make or receive
handheld calls while
driving. And never text
while driving.

Keep your phone at least
half an inch (15 mm)
away from your ear or
body while making calls.

Small parts may cause
choking.

Your phone can produce
a loud sound.

Keep away from
pacemakers and other
electronic medical
devices.

Power off when asked to
in hospitals and medical
facilities.

Power off when told to in
aircrafts and airports.

Don’t use at gas
stations.

Your phone may
produce a bright or
flashing light.

Don’t dispose of
your phone in a fire.

Avoid contact with
anything magnetic.

Avoid extreme
temperatures.

Avoid contact with
liquids. Keep your
phone dry.

Don’t take your
phone apart.

For Your Safety64

For Your Safety 65

Power off when near
explosive materials or
liquids.

Don’t rely on your phone for emergency
communications.

Only use approved
accessories.

FCC Regulations

This mobile phone complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.

This mobile phone has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician

for help.

Caution: Changes or modifications not expressly approved
by the party responsible for compliance could void the user‘s
authority to operate the equipment.

RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy set
by the Federal Communications Commission of the United
States, Industry Canada of Canada.

During SAR testing, this device was set to transmit at its highest
certified power level in all tested frequency bands, and placed
in positions that simulate RF exposure in usage against the head
with no separation, and near the body with the separation of 0.4
inches (10 mm). Although the SAR is determined at the highest
certified power level, the actual SAR level of the device while
operating can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as
to use only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the lower
the power output.

The exposure standard for wireless devices employing a unit
of measurement is known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg, and 1.6 W/kg by
Industry Canada.

This device is complied with SAR for general population /
uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and
Canada RSS 102, and had been tested in accordance with the
measurement methods and procedures specified in OET

For Your Safety 67For Your Safety66

Bulletin 65 Supplement C, and Canada RSS 102. This device
has been tested, and meets the FCC, IC RF exposure guidelines
when tested with the device directly contacted to the body.

The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance
with the FCC RF exposure guidelines. SAR information on this
model phone is on file with the FCC and can be found under
the Display Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: SRQ-Z830.

For this device, the highest reported SAR value for usage against
the head is 1.16 W/kg, for usage near the body is 1.32 W/kg.

While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirements.

SAR compliance for body-worn operation is based on a
separation distance of 0.4 inches (10 mm) between the unit and
the human body. Carry this device at least 0.4 inches (10 mm)
away from your body to ensure RF exposure level compliant or
lower to the reported level. To support body-worn operation,
choose the belt clips or holsters, which do not contain metallic
components, to maintain a separation of 0.4 inches (10 mm)
between this device and your body.

RF exposure compliance with any body-worn accessory, which
contains metal, was not tested and certified, and use of such
body-worn accessory should be avoided.

Hearing Aid Compatibility (HAC) Regulations for Mobile Phones

In 2003, the FCC adopted rules to make digital wireless
telephones compatible with hearing aids and cochlear
implants. Although analog wireless phones do not usually cause
interference with hearing aids or cochlear implants, digital
wireless phones sometimes do because of electromagnetic
energy emitted by the phone’s antenna, backlight, or other
components. Your phone is compliant with FCC HAC
regulations (ANSI C63.19- 2011). While some wireless phones
are used near some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or whining
noise. Some hearing devices are more immune than others to
this interference noise and phones also vary in the amount of
interference they generate. The wireless telephone industry has
developed a rating system for wireless phones to assist hearing
device users in finding phones that may be compatible with
their hearing devices. Not all phones have been rated. Phones
that are rated have the rating on their box or a label located
on the box. The ratings are not guarantees. Results will vary
depending on the user’s hearing device and hearing loss. If your
hearing device happens to be vulnerable to interference, you
may not be able to use a rated phone successfully. Trying out
the phone with your hearing device is the best way to evaluate it
for your personal needs.

This phone has been tested and rated for use with hearing aids
for some of the wireless technologies that it uses. However,
there may be some newer wireless technologies used in this
phone that have not been tested yet for use with hearing aids.

For Your Safety 69For Your Safety68

It is important to try the different features of this phone
thoroughly and in different locations, using your hearing aid
or cochlear implant, to determine if you hear any interfering
noise. Consult your service provider or the manufacturer of this
phone for more information on hearing aid compatibility. If you
have questions about return or exchange policies, consult your
service provider or phone retailer.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and
are likely to generate less interference to hearing devices than
phones that are not labeled. M4 is the better/higher of the two
ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and
are likely to be more usable with a hearing device’s telecoil (“T
Switch” or “Telephone Switch”) than unrated phones. T4 is
the better/ higher of the two ratings. (Note that not all hearing
devices have telecoils in them.)

Your phone meets the M3/T4 level rating.

Hearing devices may also be rated. Your hearing device
manufacturer or hearing health professional may help you
find this rating. For more information about FCC Hearing Aid
Compatibility, please go to http://www.fcc.gov/cgb/dro.

CTIA

a)

Do not disassemble or open crush, bend or deform, puncture
or shred.

b) Do not modify or remanufacture, attempt to insert foreign

objects into the battery, immerse or expose to water or other
liquids, expose to fire, explosion or other hazard.

c) Only use the battery for the system for which it is specified.
d) Only use the battery with a charging system that has

been qualified with the system per CTIA Certification
Requirements for Battery System Compliance to IEEE 1725.
Use of an unqualified battery or charger may present a risk of
fire, explosion, leakage, or other hazard.

e) Do not short circuit a battery or allow metallic conductive

objects to contact battery terminals.

f ) Replace the battery only with another battery that has been

qualified with the system per this standard, IEEE-Std-1725.
Use of an unqualified battery may present a risk of fire,
explosion, leakage or other hazard.

g) Promptly dispose of used batteries in accordance with local

regulations.
h) Battery usage by children should be supervised.
i ) Avoid dropping the phone or battery. If the phone or battery

is dropped, especially on a hard surface, and the user

suspects damage, take it to a service center for inspection.
j ) Improper battery use may result in a fire, explosion or other

hazard.
k) The phone shall only be connected to CTIA certified

adapters, products that bear the USB-IF logo or products

that have completed the USB-IF compliance program.
For those host devices that utilize a USB port as a charging

source, the host device’s user manual shall include a statement
that the phone shall only be connected to CTIA certified

For Your Safety 71For Your Safety70

adapters, products that bear the USB-IF logo or products that
have completed the USB-IF compliance program.

Distraction

Driving

Full attention must be given to driving at all times in order to
reduce the risk of an accident. Using a phone while driving
(even with a hands-free kit) can cause distraction and lead to
an accident. You must comply with local laws and regulations
restricting the use of wireless devices while driving.

Operating Machinery

Full attention must be given to operating the machinery in order
to reduce the risk of an accident.

Product Handling

• Do not expose your phone or its accessories to liquid,

moisture, or high humidity.

•

Do not drop, throw, or try to bend your phone or its accessories.

• Do not use harsh chemicals, cleaning solvents, or aerosols to

clean the device or its accessories.

• Do not paint your phone or its accessories.

• Do not attempt to disassemble your phone or its accessories.

Only authorized personnel can do so.

• Do not expose your phone or its accessories to extreme

temperatures, minimum 23°F and maximum 122°F (minimum
– 5°C and maximum + 50°C).

•

Please check local regulations for disposal of electronic products.

• Do not carry your phone in your back pocket as it could break

when you sit down.

General Statement on Handling and Use

You alone are responsible for how you use your phone and any
consequences of its use.

You must always power off your phone wherever the use of
a phone is prohibited. Use of your phone is subject to safety
measures designed to protect users and their environment.

• Always treat your phone and its accessories with care and

keep it in a clean and dust-free place.

• Do not expose your phone or its accessories to open ames or

lit tobacco products.

Small Children

Do not leave your phone and its accessories within the reach
of small children or allow them to play with it. They could hurt
themselves or others, or could accidentally damage the phone.

Your phone contains small parts with sharp edges that may
cause an injury or may become detached and create a choking
hazard.

Demagnetization

To avoid the risk of demagnetization, do not allow electronic
devices or magnetic media close to your phone for a long time.

For Your Safety 73For Your Safety72

Electrostatic Discharge (ESD)

Do not touch the SIM card’s metal connectors.

Antenna

GPS antenna

Diversity

antenna

Bluetooth &

Wi-Fi antenna

Antenna

Do not touch the antenna unnecessarily.

Normal Use Position

When placing or receiving a phone call, hold your phone to your
ear, with the bottom toward your mouth.

Air Bags

Do not place a phone in the area over an air bag or in the air
bag deployment area as an airbag inflates with great force and
serious injury could result.

Store the phone safely before driving your vehicle.

Seizures/Blackouts

The phone can produce a bright or flashing light. A small
percentage of people may be susceptible to blackouts or seizures
(even if they have never had one before) when exposed to flashing
lights or light patterns such as when playing games or watching
video. If you have experienced seizures or blackouts or have a
family history of such occurrences, please consult a physician.

Repetitive Strain Injuries

To minimize the risk of Repetitive Strain Injury (RSI) when texting
or playing games with your phone:

• Do not grip the phone too tightly.

• Press the keys lightly.

• Use the special features that are designed to minimize the

times of pressing buttons, such as Message Templates and
Predictive Text.

• Take lots of breaks to stretch and relax.

Emergency Calls

This phone, like any wireless phone, operates using radio signals,
which cannot guarantee connection in all conditions. Therefore,
you must never rely solely on any wireless phone for emergency
communications.

Loud Noise

This phone is capable of producing loud noises, which may
damage your hearing. Turn down the volume before using
headphones, Bluetooth stereo headsets or other audio devices.

For Your Safety 75For Your Safety74

Phone Heating

Your phone may become warm during charging and during
normal use.

Electrical Safety

Accessories

Use only approved accessories.
Do not connect with incompatible products or accessories.
Take care not to touch or allow metal objects, such as coins or

key rings, to contact or short-circuit in the battery terminals.

Connection to a Car

Seek professional advice when connecting a phone interface to
the vehicle electrical system.

Faulty and Damaged Products

Do not attempt to disassemble the phone or its accessories.
Only qualified personnel can service or repair the phone or its

accessories.
If your phone (or its accessories) has been submerged in water,

punctured, or subjected to a severe fall, do not use it until you
have taken it to be checked at an authorized service center.

Interference

General Statement on Interference

Care must be taken when using the phone in close proximity to
personal medical devices, such as pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum
separation of 6 inches (15 cm) be maintained between a mobile
phone and a pacemaker to avoid potential interference with the
pacemaker. To achieve this, use the phone on the opposite ear
to your pacemaker and do not carry it in a breast pocket.

Hearing Aids

People with hearing aids or other cochlear implants may
experience interfering noises when using wireless devices or
when one is nearby.

The level of interference will depend on the type of hearing
device and the distance from the interference source,
increasing the separation between them may reduce
the interference. You may also consult your hearing aid
manufacturer to discuss alternatives.

Medical Devices

Please consult your doctor and the device manufacturer to
determine if operation of your phone may interfere with the
operation of your medical device.

Hospitals

Power off your wireless device when requested to do so in
hospitals, clinics, or health care facilities. These requests are
designed to prevent possible interference with sensitive medical
equipment.

For Your Safety 77For Your Safety76

Aircraft

Power off your wireless device whenever you are instructed to
do so by airport or airline staff.

Consult the airline staff about the use of wireless devices on
board the aircraft. If your device offers a ‘flight mode’, this must
be enabled prior to boarding an aircraft.

Interference in Cars

Please note that because of possible interference to electronic
equipment, some vehicle manufacturers forbid the use of
mobile phones in their vehicles unless a hands-free kit with an
external antenna is included in the installation.

Explosive Environments

Gas Stations and Explosive Atmospheres

In locations with potentially explosive atmospheres, obey all
posted signs to turn off wireless devices such as your phone or
other radio equipment.

Areas with potentially explosive atmospheres include fueling
areas, below decks on boats, fuel or chemical transfer or
storage facilities, and areas where the air contains chemicals or
particles, such as grain, dust, or metal powders.

Blasting Caps and Areas

Power off your mobile phone or wireless device when in a
blasting area or in areas posted with power off “two-way radios”
or “electronic devices” notices to avoid interfering with blasting
operations.

Specifications

Handset specifications are shown in the following table.

Handset standards GSM 850/1900MHz

UMTS 850/1900MHz

LTE 850/1900 AWS 700MHz
Dimensions (LxWxH) 4.92"(L) x 2.56"(W) x 0.45"(H)
Weight 5.13 oz.
Display 4" WVGA 480 x 800 16M TFT
Camera 5 MP autofocus
Video capture
Removable memory

card
Battery 1,820 mAh
Features

Supported file types AAC, AMR, AWB, M4A, MP3, MIDI, OGA,

Continuous idle time Up to 15 days
Continuous talk time Up to 4.5 hours
Charge time 2.5 hours
WAP browser version WAP2.0

Specifications 79For Your Safety78

Up to 30 fps (VGA) 1080 x 1920 pixels

Up to 32 GB microSDHC card

Bluetooth, Wi-Fi Direct®, Google Maps,

Kingsoft Office, Email, Browser, Play

Store, YouTube, Twitter, Messaging,

Chrome, Gmail, Google, Google+, Play

Music, Voice Search

OGG, WAV

Warranty

ZTE offers you a limited warranty that the enclosed subscriber
unit and its enclosed accessories will be free from defects in
material and workmanship for a period that expires one year
from the date of sale of the Product to you, provided that you
are the original end user purchaser of the Product and provided
that your purchase was made from a supplier authorized by
the Seller. Transfer or resale of a Product will automatically
terminate warranty coverage with respect to that Product. This
limited warranty is not transferable to any third party, including
but not limited to any subsequent purchaser or owner of the
Product. This limited warranty is applicable only to end users in
the United States.

1. This product or phone is warranted for 12 (twelve) months
from date of purchase.

2.

For warranty service information, please call ZTE service
number [phone]
website, http://www.zteusa.com, is also available for
assistance.

3. This warranty only applies if the product has been used in
accordance with the manufacturer’s instructions under
normal use and with reasonable care.

4. What this warranty does not cover:

a) Defects or damages resulting from the misuse of this

product.

(Toll Free). The manufacturer’s

b) Defects or damages from abnormal use, abnormal

conditions, improper storage, exposure to moisture,
dampness or corrosive environments, unauthorized
modifications, unauthorized repair, neglect, rough
handling, abuse, accident, alteration, improper installation,
incorrect voltage application, food or liquid spoilage, acts

of God.
c) Normal wear and tear.
d) If the Product has been opened, modified or repaired

by anyone other than a warranty service center or if it is

repaired using unauthorized spare parts.
e) If the serial number or mobile accessory date code has

been removed, erased, defaced, altered or are illegible in

any way subject to sole judgment of ZTE.

LIMITED WARRANTY

TO THE EXTENT PERMITTED BY APPLICABLE LAW, THIS
LIMITED WARRANTY IS YOUR SOLE AND EXCLUSIVE REMEDY
AGAINST ZTE AND ZTE’S SOLE AND EXCLUSIVE LIABILITY
IN RESPECT OF DEFECTS IN PRODUCT. HOWEVER, THIS
LIMITED WARRANTY SHALL NOT EXCLUDE NOR LIMIT ANY OF
YOUR LEGAL (STATUTORY) RIGHTS UNDER THE APPLICABLE
NATIONAL LAWS.

TO THE EXTENT PERMITTED BY APPLICABLE LAW ZTE DOES
NOT ASSUME ANY LIABILITY FOR LOSS OF OR DAMAGE TO OR
CORRUPTION OF DATA, FOR ANY LOSS OF PROFIT, LOSS OF
USE OF PRODUCTS OR FUNCTIONALITY, LOSS OF BUSINESS,
LOSS OF REVENUES OR LOSS OF ANTICIPATED PROFIT,

Warranty80 Warranty

81

INCREASED COSTS OR EXPENSES OR FOR ANY INDIRECT,
OR SPECIAL OR CONSEQUENTIAL LOSS OR DAMAGE.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, ZTE’S
LIABILITY SHALL BE LIMITED TO THE PURCHASE VALUE OF
THE PRODUCT. THE ABOVE LIMITATIONS SHALL NOT APPLY
TO DEATH OR PERSONAL INJURY CAUSED BY DEFECT OF
PRODUCT IN MATERIAL, DESIGN AND WORKMANSHIP.

How to Get Warranty Service

To obtain warranty service, please call [phone]. Please
have the following information available when you send the
phone in for repair:

• A valid Proof of Purchase

• Return address

• Daytime phone number or fax number

• Model #

• IMEI # (Look for the 15-digit IMEI # behind the battery of the

device.)

• Complete description of the problem

• Transportation prepaid

Other Warranty Programs

You may have other warranty programs with your purchase,
such as warranty exchange. If so, please refer to equipment
package or the original point of sale.

Notes

Warranty82

Notes 83

Notes84
