Zoomlion RT60 User Manual

LOAD CHART MANUAL FOR RT60 ROUGH TERRAIN CRANE

Address:Quantang Indust=rial Park, 2nd Yuanda Road, Changsha Economic and Technological Development Zone, Hunan Province, China

Postcode: 410131 Website: www.zoomlion.com

RT60 ROUGH TERRAIN CRANE

LOAD RATINGS

Edition 1

Dec. 2013

LOAD RATINGS FOR ROUGH TERRAIN CRANE

To owners, users and operators

Zoomlion Cranes appreciates your selection of the ZOOMLION Rough Terrain Crane for your application.

No one should operate the crane unless they read and understand the information in this manual.

When you follow the instructions in this manual, your crane can operate at MAXIMUM EFFICIENCY.

The operator must keep this manual in the cab of the crane.

If there is anything in the manual that you do not understand, speak with us. We (Zoomlion Cranes) are NOT responsible for damages from an operator who does not obey the instructions in the OPERATOR’S MANUAL.

The OPERATOR’S MANUAL is an important part of the crane. If the crane becomes the property of a different person, make sure that the manual stays in the cab of the crane.

THANK YOU!

Mobile Crane Branch Company of ZOOMLION Heavy Industry Science and Technology Co., Ltd.

Copyright

Under the copyright laws, this manual may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine readable form, in whole or part, without the prior written consent of Zoomlion Heavy Industry Science and Technology Co., Ltd.

Copyright © 20XX, Zoomlion Heavy Industry Science and Technology Co., Ltd.

All rights reserved.

RT60 Rough Terrain Crane

I

LOAD RATINGS FOR ROUGH TERRAIN CRANE

Safety

Hazard Indicators

DANGER, WARNING, CAUTION, ATTENTION, NOTE, and IMPORTANT labels are on signs and decals, and as you read this manual to show important instructions. In this manual, DANGER, WARNING, and CAUTION labels are before the paragraph or item to which they apply. ATTENTION, NOTE, and IMPORTANT follow the paragraph or item they apply to. The markers are as follows:

Danger

Refers to a dangerous situation which, if you do not prevent, will cause death or injury.

Warning

Refers to a possible dangerous situation which, if you do not prevent, could cause death or injury.

Caution

Refers to a possible dangerous situation which, if you do not prevent, may cause light or moderate injury.

Attention

Refers to a situation which, if you do not prevent, may cause property or equipment damage.

Note

Refers to a tip or hint in the operation instructions.

Important

Emphasizes the importance of the data in this manual.

This symbol shows a step or procedure that is not approved and can cause a dangerous situation.

II

RT60 Rough Terrain Crane

To Owners, Users and Operators ......................................................................................................

I

Safety

. .................................................................................................................................................

II

1 Informational data .......................................................................................................................

1-1

1.1

Hoist Tackle Chart.................................................................................................................

1-1

1.2

Tire Inflation Chart.................................................................................................................

1-1

1.3

Weights .................................................................................................................................

1-2

1.4

General..................................................................................................................................

1-3

1.5

Definitions .............................................................................................................................

1-3

1.6

Set-up....................................................................................................................................

1-4

1.7

Operation...............................................................................................................................

1-5

2 Lifts with outrigger beams fully extended. ...............................................................................

2-1

2.1 Main Boom Rated Loads . .......................................................................................................

2-2

2.2 10 M Jib Rated Loads.............................................................................................................

2-4

2.3 17 M Jib Rated Loads.............................................................................................................

2-5

3 Lifts with outrigger beams at mid-position . .............................................................................

3-1

3.1 Main Boom Rated Loads . .......................................................................................................

3-1

4 Lifts with outrigger beams fully retracted. ................................................................................

4-1

4.1 Main Boom Rated Loads . .......................................................................................................

4-1

5 Lifts on tires .................................................................................................................................

5-1

5.1 Main Boom Rated Loads . .......................................................................................................

5-1

RT60 Rough Terrain Crane

III

1.1 HOIST TACKLE CHART

This chart only represents the maximum permissible hoist line load per parts of line. You must refer to the proper Lift Charts for machine rated loads.







Table 01 – 1

Line Parts













MAXIMUM PERMISSIBLE HOIST LINE LOAD







LINE PARTS

1

2

3

4

5

6

7

8

9

10

MAXIMUM





















PERMISSIBLE

6000

12000

18000

24000

30000

36000

42000

48000

54000

60000

HOIST LINE





















LOAD (KG)





















MAXIMUM





















PERMISSIBLE

13230

26455

39680

52910

66140

79365

92595

105820

119050

132280

HOIST LINE





















LOAD (LBS)

Wire rope: 19NAT-15*K7-IWRC-1960 MPa 3/4″ROTATION RESISTANT 15×K7 COMPACTED STRAND, GRADE 1960

Weight: 173 Kg/100m (1.16LBS/FT) Minimum breaking strength: 31.1T (30.61TONS)

1.2 TIRE INFLATION CHART







Table 01 – 2 Tire Inflation Chart





RECOMMENDED TIRE PRESSURE



TIRE SIZE

STATIONARY

CREEP 1.6 Km/h 1 MPH

TRAVEL

26.50-25-32PR

580 kpa 85 PSI

580 kpa 85 PSI

450 kpa 65 PSI

RT60 Rough Terrain Crane

01 - 1

1.3 WEIGHTS

Table 01 – 3 Weights

HOOK BLOCK WEIGHTS

Main hook weight: 650 kg 1433 LBS Auxiliary hook weight: 120 kg 265 LBS

MACHINE EQUIPMENT

1.COUNTERWEIGHT: 7000 kg 15432 LBS

2.OUTRIGGER SPREAD: 6.9 m 22.6 ft from

center of outrigger float to center of outrigger float across the longitudinal axis of the machine;

6.9m 22.6 ft from center of outrigger float to

center of outrigger float across the transversal axis of the machine

3.Powered boom length 11.4 m(37.4 ft) retracted to 43 m(141 ft) extended

4.Crane height 3.75 m(12 ft-3.5 in),length 13.66 m(43ft-9.8 in), width 3.3 m(10ft-10in), wheelbase

3.95m(12 ft-11.5 in)

DIMENSIONS ARE FOR MAIN HOOK AND AUXILIARY HOOK.

01 - 2

RT60 Rough Terrain Crane

1.4GENERAL

1.Rated loads as shown on Lifting Charts pertain to this machine as originally manufactured and equipped. Modifications to the machine or use of optional equipment other than that specified can result in a reduction of capacity.

2.Construction equipment can be hazardous if improperly operated or maintained. Operation and maintenance of this machine shall be in compliance with the information in the Operator’s Manual and Maintenance and Service Manual supplied with this machine. If these manuals are missing, order replacements from the manufacturer through your distributor.

3.These warnings do not constitute all of the operating conditions for the crane. The operator and job site supervision must read the Operator’s Manual .

4.This crane and its load ratings are in accordance with ASME/ANSI B30.5. .

1.5DEFINITIONS

1.LOAD RADIUS – The horizontal distance from the axis of rotation before loading to the center of the vertical hoist line or tackle with a load applied.

2.LOAD BOOM ANGLE – It is the angle between the boom base section and the horizontal, after lifting the rated load at the rated radius. The boom angle before loading should be greater to account for deflections. The loaded boom angle

combined with the boom length give only an approximation of the operating radius.

3.WORKING AREA – Areas measured in a circular arc about the centerline of rotation as shown in the diagram.

4.FREELY SUSPENDED LOAD – Load hanging free with no direct external force applied except by the hoist rope.

CRANE WORKING POSITIONS

WITHOUT OUTRIGGERS



WITH OUTRIGGERS

360



360

±3

CL

CL

BOOM

BOOM

OVER FRONT









CENTER OF





ROTATION

THESE LINES DETERMINE THE LIMITS OF WORKING POSITIONS WHITCH CORRESPOND TO THOSE SHOWN ON THE CRANE CAPACITY CHART.

5.Side load – Horizontal force applied to the lifted load either on the ground or in the air.

6.EXTRA-CAUTION ZONE – Tipping can occur with some boom/jib combinations at radii within this area without any load on the hook.

7.BOOM SIDE OF CRANE – The side of the crane over which the boom is positioned when in an OVER SIDE working position.

RT60 Rough Terrain Crane

01 - 3

1.6SET-UP

1.Crane load ratings are based on the crane being leveled and standing on a firm and uniform supporting surface.

2.Crane load ratings on outriggers are

based on all outrigger beams being fully extended / retracted, or in the case of partial extension ratings mechanically pinned in the appropriate position, and the tires raised free of the supporting surface.

3.Crane load ratings on tires depend on appropriate inflation pressure and the tire conditions. Caution must be exercised when increasing air pressures in tires. Consult

Operator’s Manual or Maintenance and Service Manual for precautions.

4.Consult appropriate section of the Operator’s Manual for more exact description of hoist line reeving.

5.The use of more parts of line than required by the load may result in having insufficient rope to allow the hook block to reach the ground.

6.Properly maintained wire rope is essential for safe crane operation. Consult Maintenance and Service Manual for proper maintenance and inspection requirements.

7.When spin-resistant wire rope is used, the allowable rope loading shall be the breaking strength divided by five (5), unless otherwise specified by the wire rope manufacturer.

01 - 4

RT60 Rough Terrain Crane

1.7OPERATION

1.CRANE LOAD RATINGS MUST NOT BE EXCEEDED. DO NOT ATTEMPT TO TIP THE CRANE TO DETERMINE ALLOWABLE LOADS.

2.When either radius or boom length, or both, are between listed values, the smaller of the two listed load ratings shall be used.

3.Do not operate at longer radii than those listed on the applicable Lift Chart (cross

hatched areas

shown on range diagrams) as tipping can occur without a

load on the hook.



4.The boom angles shown on the Lift Charts give an approximation of the operating radius for a specified boom length. The boom angle, before loading, should be greater to account for boom deflection. It may be necessary to retract the boom if maximum boom angle is insufficient to maintain rated radius.

5.All telescopic sections must be extended synchronically.

6.Rated loads include the weight of hook block, slings, and auxiliary lifting devices. Their weights shall be subtracted from the listed rated load to obtain the net load that can be lifted.

When lifting over the jib, the weight of any hood block, slings, and auxiliary lifting devices at the boom head must be added to the load.

Rated lifting capacities are based on correct

reeving. Deductions must be made for excessive reeving. Any reeving over the minimum required, (see Hoist Tackle Chart), is considered excessive and must be accounted for. Deduct for each meter of excessive wire rope before attempting to lift a load.

When jibs are erected but unused, add three (3) times the weight of jib, any hook block, slings, and auxiliary lifting devices at the jib head to the load (jib weight: 952 kg(2099 lbs)).

7.Rated loads do not exceed 85% on outriggers or 75% on tires, of the tipping load as determined by ASME/ANSI B30.5.

8.Rated loads are based on freely suspended loads. No attempt shall be made to drag a load horizontally on the ground in any direction.

RT60 Rough Terrain Crane

01 - 5

9.The user shall operate at reduced ratings to allow for adverse job conditions, such as: soft or uneven ground, out of level conditions, high winds, side loads, pendulum action, jerking or sudden stopping off loads, hazardous conditions, experience of personnel, two-machine lifts, traveling with loads, electric wires, etc, (side pull on boom or jib is hazardous). If wind speed is higher than the maximum permissible value (45 ft/s (13.8 m/s), grade 6) or it is fulminous during crane operation, stop working and completely retract the boom and place it on the boom support for traveling.

10.Load ratings are dependent upon the crane being maintained according to manufacturer’s specifications.

11.It is recommended that load handling devices, including hooks, and hook blocks, be kept away from boom head at all times.

01 - 6
