Introduction

Zilog’s Z8 Encore!® F083A Series MCU is part of the line of Zilog®
microcontroller products. The Z8 Encore! F083A Series MCU Develop­ment Kit (Z8F083A0128ZCOG) ena bles you to become familiar with the
hardware and software tools available with this product. This kit consists
of the 8 KB version of the Z8 Encore! development board that supports
and presents the fea tures of the Z8 Encore! F083A Series. This kit allows
you to write application softwar e and contains all the supporting docu­ments.

The Z8 Encore! F083A Series devic es support up to 8 KB Flash Program
Memory and 256 B register RAM that is pin-for-pin compatible with the
award-winning Z8 Encore! XP F0822 Series Flash Microcontrollers
family.

Z8 Encore!® F083A Series Development Kit

User Manual

1

The Z8 Encore! F083A Serie s device features up to e ight channels of fast
analog-to-digit al conversion (2.15 µs). The ADC on the Z8 Encore!
F083A is one of the fastest 10-bit ADCs availabl e in a 28-pin or smalle r
package. The Z8 Encore! F083A is built for speed to handle ri gorous
application requir ements for motor control, sensor interfacing, ballast
control, and appliance controls. The single-pin debugger and program­ming interface simplifie s code dev elopment and allows easy in-circuit
programming.

This user manual acquaints you with the Z8 Encore! F083A Series MCU
Development Kit, and gives instructions on setting up and using the tools
to start building designs and applications. Z8F083ASJ020 is the silicon
used in the board. For more information, refer to Z8 Encore!
Series Product Specification (PS0263).

UM020604-0508 Introduction

®

F083A

Kit Contents

For information on kit contents, refer to Z8 Encore! XP®/Z8 Encore!®
(F0822, F082A, F1680, and F083A Series) Developme nt Kits Quick S t art
Guide (QS0043).

Z8 Encore!® F083A Series Development Kit

User Manual

2

UM020604-0508 Introduction

Installation

Z8 Encore!® F083A Series Development Kit

User Manual

3

For software installat ion and setup of the Z8 Encore!® F083A Series
Development Kit, refer to Z8 Encore! XP

F1680, and F083A Series) Development Kits Quick Start Guide
(QS0043).

®

/Z8 Encore!® (F0822, F082A,

UM020604-0508 Installation

Z8 Enco re!® F083A Series Development Kit

Z8 Encore!® F083A S e ries Development Board

Introduction

The Z8 Encore!® F083A Series Developmen t Boa rd is a de velopm ent and
prototyping board f or the Z8 Encore! F083A Series MCU. The boa rd pro­vides a tool to eva luate f eatures of Z8 En core! F083A Series MCU, and to
start developing an applica tion be fore building the hardware.

User Manual

4

Figure 1. Z8 Encore!® F083A Series Development Board

(see

Schematic on page 7 for details on com p onents not installed on thi s board)

UM020604-0508 Z8 Enco re!

®

F083A Series

Features

Z8 Enco re!® F083A Series Development Kit

User Manual

The key features of Z8 Encore! F083A Series include:

•

20 MHz eZ8 CPU

•

Up to 8 KB Flash memory with in-circuit programming capability

•

Up to 256 B register RAM

•

100 B non-volatile data storage (NVDS)

•

Up to 23 I/O pins depending upon package

•

Internal precision osc illator (IPO)

•

External crystal oscillator

•

Two enhanced 16-bit timers with capture, compare, and PWM capa­bility

5

•

Watchdog Timer (WDT) with dedicated internal RC oscillator

•

Single-pin, On-Chip Debugger (OCD)

•

Fast 8-channel, 10-bit analog-to-digital converter (ADC)

•

On-chip analog comparator

•

Up to 18 vectored interrupts

•

Voltage Brownout (VBO) protection

•

Power-On Reset (POR)

•

2.7 V to 3.6 V operating voltage

•

Up to thirteen 5 V tolerant input pins

•

20- and 28-pin packages

•

0 °C to +70 °C standard temperature range and -40 °C to +105 °C
extended temperature operating ranges

UM020604-0508 Z8 Enco re!

®

F083A Series

MCU

Z8 Enco re!® F083A Series Development Kit

User Manual

The Z8 Encore! F083A Series MCU is member of a family of Zilog®
microcontroller prod ucts based upon the 8-bit eZ8 core CPU. The Flash
in-circuit programming capa bility a llows for faste r development ti me and
program changes in the field. The eZ8 core CPU is upward compatible
with existing Z8
(SAR) ADC on the Z8 Encore! F083A is one of the fastest 10-bit ADCs
available in a 28-pin or smaller package. The Z8 Encore! F083A is built
for speed to handle rigorous application requirements for motor control,
sensor interfacing, ballast control, and appliance controls.

The development board contains circuitry to support and present all the
features of the Z8 Encore! F083A Series. For more information on the
Z8 Encore!
Product Specification (PS0263) available for download at

w

ww.zilog.com.

®

instructions. The successive approximation register

®

family of devices, refer to Z8 Encore!® F083A Series

6

Jumper Settings

The only jumper available on the Z8 Encore! F083A development board
is JP5, which affects U5 RESET/PD0. Set JP5 as foll ows:

•

JP5 OUT (default): PD0 (GPIO)

•

JP5 IN: RESET when SW1 pressed

External Interface Headers JP1 and JP2

Figure 2 on page 8 displays the external interface headers JP1 and JP2.

UM020604-0508 Z8 Enco re!

®

F083A Series

Schematic

This section includes schemat ics for the Z8 Encore!® F083A Series
Development Board (see Figure 2 and Figure 3 on pa ge 9).

The following components appear in the schematic but are not installed
on the board:

•

C1, C2, C5, C6, C9 , C11 throu gh C18

•

JP3, JP4

•

P1

•

R2 through R5

•

U1, U3, U4

Z8 Encore!® F083A Series Development Kit

User Manual

7

UM020604-0508 Schematic

Z8 Encore!

®

F083A Series Development Kit

User Manual
